FAQs can be found at www.espresso-works.com
Email us for any unanswered questions: cs@espresso-works.com
FOR PRODUCT REGISTRATION, PLEASE VISIT WWW.ESPRESSO-WORKS.COM
Read this booklet thoroughly and save these instructions.
Quick Start
Guide
BARISTA SERIES
ESPRESSO & CAPPUCCINO MAKER
With ELECTRIC COFFEE GRINDER, BARISTA ACCESSORIES,
DOUBLE WALLED CAPPUCCINO GLASSES & ESPRESSO CUPS
1
WARNING : When using
electrical appliances, basic safety
precautions should always be
followed, including the following:
1. Read all instructions.
2. This appliance has been
incorporated with a grounded plug.
Please ensure the wall outlet in your
house is well earthed.
3. Do not touch hot surfaces. Use
handles or knobs.
4. To protect against re, electric
shock and injury to persons do not
immerse cord and plug in water or
other liquid.
5. Unplug from outlet when not
in use and before cleaning. Allow
to cool before putting on or taking
off parts, and before cleaning the
appliance.
6. Do not operate any appliance
with a damaged cord or plug or
after the appliance malfunctions, or
was dropped or damaged in any
manner. Please contact us at
cs@espresso-works.com to arrange
for examination, repair or electrical
or mechanical adjustment.
7. Close supervision is necessary
when any appliance is used by or
near children.
8. Do not let the cord hang over
edge of table or counter, or touch hot
surfaces.
9. Do not place on or near a hot gas
or electric burner, or in a heated oven.
10. Do not use outdoors.
11. The use of accessory attachments
not recommended by the appliance
manufacturer may result in re,
electric shock or injury to persons.
12. Always attach plug to appliance
rst, then plug cord into the wall outlet.
To disconnect, turn any control to “off,”
then remove plug from wall outlet.
13. Do not use appliance for other
than intended use and place it in a
dry environment.
14. Scalding may occur if the lid is
removed during the brewing cycles.
15. Be sure that handles are
assembled and fastened properly.
16. See instructions regarding
Handles on below Page.
17. WARNING: To avoid the risk
of injury, do not open the brew
chamber during the brew process.
18. Children should be supervised to
ensure that they do not play with the
appliance.
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS. HOUSEHOLD USE ONLY.
INCLUDED IN YOUR PURCHASE
STAINLESS
STEEL FOLD
DOWN
ESPRESSO
CUP SUPPORT
BUILT-IN MILK
FROTHER &
RESERVOIR WITH
ADJUSTABLE
CONTROL KNOB
120V PLUG-IN
ELECTRIC
COFFEE
GRINDER
EASY CLEAN
REMOVABLE
DRIP TRAY
PORTAFILTER
WITH
BAKELITE
HANDLE
16 CAPPUCCINO ART
STENCIL TEMPLATES
MEASURING
SPOON &
TAMPER
1.4L LARGE
DETACHABLE
WATER TANK
WITH HANDLE
2 HIGH QUALITY
DOUBLE WALLED
CAPPUCCINO
GLASSES
2 PREMIUM
DOUBLE WALLED
ESPRESSO CUPS
BUILT-IN
QUICK
HEATING
TRAY
FILTERS
• 1 X SINGLE
SHOT BASKET
• 1 X DOUBLE
SHOT BASKET
32
1. Unpack the items supplied and check them for completeness and transport damage. If the machine or the power cord has
damage, do not use the machine, but contact our customer service department at [email protected]
2. Remove all packaging materials and any possible protective lm used for protection during transportation.
NOTES
• Never remove the rating plate.
• Keep the original packaging during the warranty period of the machine so that the machine can be properly packaged up if
it needs to be returned. The warranty claim shall lapse if any damage is caused during transport.
KEY
1 Heating tray
2 Brew head
3 Portalter
4 Fold down espresso cup support
5 Cover for the drip tray
6 Drip tray
7 Water tank lid
8 Water tank
9 Control panel
10 Release button for milk frother and reservoir
11 Milk froth dial
12 Milk frother and reservoir cover
13 Milk nozzle lever
14 Milk nozzle
15 Milk frother and reservoir
TECHNICAL DATA
Model number: AEW-3000
Voltage supply: 120 V ~ 60 Hz
Power: 1250W
Pressure: 19-bar pump pressure system
Capacity:
• Water tank: max. 1.4 liters
• Milk frother and reservoir: 390 ml
• Cappuccino glasses: 310 ml
• Espresso cup: 80 ml
• Filter (single cup): 7g coffee powder
• Filter (double cup): 14g coffee powder
7
8
9
10
1
2
3
4
5
6
11
12
13
14
15
CONTROL PANEL
ON / OFF button
SINGLE button
DOUBLE button
Red Indicator Light
Yellow Indicator Light
CAPPUCCINO button
LATTE button
MILK FROTH button CLEAN button
1. Wipe down the espresso machine with a clean, damp cloth. Rinse the water tank, the milk reservoir, the portalter, the two
lters, the drip tray, the cover and the measuring spoon and tamper with a little mild detergent and clear water.
2. Set up the machine in a suitable location, following the safety instructions and the notes provided in this guide.
3. Completely unwind the mains cable and plug into a properly installed power outlet that is easily accessible.
NOTE
• When the machine is rst used, production-related additives (e.g. grease) may cause a small amount of smoke and / or an
odor to be produced. This is normal and not a machine defect.
• Do not place the machine below kitchen wall units or similar cupboards. The rising steam could cause damage to them.
• The surfaces of furniture may possibly contain elements which can attack and soften the adjustable feet of the machine. If
necessary, place a suitable pad below the adjustable feet.
• Do not operate the machine without water. If this does happen, the machine issues an error message (the red indicator light
ashes, and several beeps will sound in succession). Please refer to the Troubleshooting Your Machine chapter on page 17-19.
• Do not pour milk or other liquids into the water tank. Use only water to make coffee.
• Only pour milk or if necessary water for cleaning into the milk reservoir.
• Never overll the portalter.
• Do not use the machine without a suitable container below the brew head and the milk nozzle.
COFFEE GRINDER
• Never use attachments or accessories that are not recommended by the manufacturer. They may cause malfunction or injury.
• Make sure there is no hard object in the grinder chamber before use. This may cause damage to the appliance and personal
injury to persons.
• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
• This appliance is for household use only. Do not use it for professional catering.
• Do not use the appliance outdoors.
BEFORE INITIAL USE
1. Plug the machine into the power source.
2. Fill the water tank and milk reservoir with water.
3. Press the “ON/OFF” button to switch on the machine. Machine will be
ready when the blue lights stop ashing and become steady.
4. Place a suitable sized cup under the brew head.
5. Press the “CAPPUCCINO” button and the machine will draw water
through both the brew head and milk reservoir.
6. The machine is now cleaned and ready for use. Enjoy!
NOTE
• There may still be some production residue on the machine. Please clean
the machine before you rst use it.
• Remove the sticker before use.
FIRST TIME USE
• This machine is only intended to be used to make specialty coffees using coffee powder and cool milk.
• This machine is only designed for use in a personal household and is not intended for commercial applications.
• The machine should only be used as described in the operating instructions. Any other use is deemed to be improper.
INTENDED USE
ON/OFF
DOUBLE
LATTE
CLEAN
SINGLE
CAPPUCCINO
FOAM
54
POWERING UP YOUR MACHINE
STEP 1 INSERT THE DRIP TRAY
Place the cover on the drip tray and
slide into the machine as shown.
STEP 4
Insert the lter into the portalter.
NOTE: Use small lter for normal
cappuccino, latte macchiato or single
espresso. Use large lter for strong
cappuccino, strong latte macchiato or
double espresso.
STEP 7
Plug the machine into a 110/120V
power outlet.
STEP 2
Place the machine in an open space
on a at, dry, solid and heat-resistant
surface.
STEP 5
Using the measuring spoon and tamper
to ll the lter with the correct measure
of ground coffee. Tamp the coffee rmly.
Clean the excess coffee from the rim.
NOTE: Do not pack down the coffee
too tightly. Packing too tightly may
not allow the water to ow properly
through the lter.
STEP 8
Press the “On / Off” button. The
heating process starts and the control
panel will ash at the same time, and
after the control panel stops ashing
and stays lit, it means the heating
process is done. Press any of the
function buttons (Single/Double/
Cappuccino/Latte/Milk Froth) to enjoy
your coffee.
STEP 3
Open the water tank located at the back
of the machine. Open the lid and lift
out the tank using the provided built-in
handle. Fill it with cold water and do not
exceed the max marking. Carefully slide
the water tank back in position. Once
secured, close the tank lid.
STEP 6
Lock the portalter rmly into the brew
head. Twist counterclockwise and
secure it. Place an empty cup under the
portalter.
STEP 9 AUTO OFF FUNCTION
The machine will turn off automatically
after 30 minutes of no usage, and has an
automatic boil-dry protection function.
Press the “On/Off” button to switch it
on again.
PREPARING SINGLE / DOUBLE ESPRESSO
STEP 1
Fill the water tank with water, tamp
coffee powder into the lter and insert
the portalter into the machine correctly.
Power the machine on and wait until the
control panel stops ashing.
STEP 4
Press the button for a single espresso
or button for a double espresso on
the control panel.
NOTE: If the milk reservoir is not
inserted, only these two buttons will be
lit up when the machine is in stand-by
mode.
STEP 2
If desired, pre-heat the cups by placing
them on the heating tray for about 5-10
minutes.
STEP 5
The machine emits a “beep” sound and
the selected function button ashes. The
brewing process begins.
STEP 3
Place a suitable cup under the brew
head.
NOTE: Flip the fold down espresso cup
support on the machine for small cups.
STEP 6
When the brewing process is done,
another “beep” will sound. The control
panel will be fully lit up and the machine
will switch to the stand-by mode
automatically.
NOTE
• You can program your own perfect amount of espresso. Please see the Programming Quantities chapter on page 10.
76
STEP 1
Fill the water tank with water, tamp
coffee powder into the lter and insert
the portalter into the machine correctly.
STEP 4
Fold out the milk nozzle using the lever.
Turn the dial on the milk reservoir cover
for the milk froth.
STEP 6
Press the button for cappuccino
or the button for latte macchiato. A
“beep” sound will be emitted and the
selected function button ashes. When
the brewing process is done, another
“beep” will sound. The control panel
will be fully lit up and the machine
will switch to the stand-by mode
automatically.
STEP 2
Press the release button while pulling
the milk reservoir out from its position
concurrently. Remove the milk reservoir
cover by pressing the release button on
the cover and ipping it up.
STEP 5
Place a suitable cup under the brew
head and milk nozzle. Power the
machine on and wait until the control
panel stops ashing.
STEP 3
Pour milk in the milk reservoir over
the “MIN” label. Do not exceed the
max marking. Place the cover and milk
reservoir back in position. Ensure it ts
correctly with a click sound. Do not use
hot milk.
PREPARING CAPPUCCINO / LATTE MACCHIATO
NOTE
• You can program your own perfect amount of espresso and milk. Please see the Programming Quantities chapter on page 10.
STEP 1
Fill the water tank with water. Fill the
milk reservoir. Fold out the milk nozzle
(please refer to “STEP 4” on page 8).
STEP 2
Select the setting you want using the
dial. Place a suitable cup below the milk
nozzle. Power the machine on and wait
until the control panel stops ashing.
NOTE: For more milk froth, turn the dial
to the top right. For more hot milk, turn
the dial to the bottom left.
STEP 3
Press the button. A “beep” sound will
be emitted and the selected function
button ashes. When the frothing
process is done, another “beep” sounds
The control panel will be fully lit up and
the machine will switch to the stand-by
mode automatically.
FROTHING THE MILK
DIFFERENT BREWS WITH YOUR MACHINE
NOTES
• You can program your own perfect amount of milk. Please see the Programming Quantities chapter on page 10.
ESPRESSO AMERICANO
CAPPUCCINO MACCHIATO
98
PROGRAMMING QUANTITIES
Both the quantity of espresso and the quantity of milk can be programmed for each function. This allows you to set the perfect
quantity of espresso and milk to suit your own taste. The set quantities are saved until a new quantity is set.
ESPRESSO, DOUBLE ESPRESSO, MILK FROTH
1. Fill the machine as if a specialty coffee is to be prepared (see the Powering Up Your Machine chapter on page 6).
2. If necessary, fold out the milk nozzle using the lever.
3. Place a suitable cup below the brew head or the milk nozzle.
4. Select the function that is to be reprogrammed. Press the appropriate button (a beep will sound) and keep it held down (another
beep will sound).
5. The machine starts to prepare espresso or make milk froth.
6. Only let go of the button once the quantity of milk or espresso that you want has passed through. You will hear three beeps. This
quantity is now saved under the corresponding function.
CAPPUCCINO AND LATTE MACCHIATO
This process must be carried out twice for latte macchiato and cappuccino: once for the quantity of espresso and once for the
quantity of milk:
1. On the rst operation, set the quantity of milk you want in the manner described in the previous section. Make sure that the milk
nozzle is folded out and there is a cup below the milk nozzle.
2. Start a second operation by pressing the appropriate button again. A beep will sound.
3. Wait until the quantity of milk has passed through.
4. As soon as the machine starts to make espresso, press the appropriate button again and hold it down. Another beep will sound.
5. Only let go of the button again once the quantity of espresso that you want has passed through. You will hear three beeps. Now
both the quantity of milk and the quantity of espresso are saved under the appropriate function.
PERSONAL PREFERENCES SETTING VOLUME
1. Select any lter to put into the portalter. Position the portalter to the unit.
2. Press any coffee button and keep pressing it down until desired volume is reach.
3. Then release the selected button. The desired volume will set.
RESET TO FACTORY SETTINGS
If the amount of espresso and amount of milk are to be reset to the amounts preset in the factory, proceed as follows:
1. Switch off the machine via the “On / Off” button.
2. Press the and buttons simultaneously and keep them held down.
3. Switch the machine back on via the “On / Off” button. The control panel ashes 5 times and 5 beeps are heard.
4. Let go of the and buttons. The amounts have now been reset to the factory settings.
1. Carefully unpack your espresso machine and remove all packing material. Wipe the grinding chamber, blades with a damp
lint-free cloth or sponge. Handle blades with care becausethey are extremely sharp.
2. Place the coffee grinder on a at surface. Remove the lid.
3. Pour coffee beans into the grinding chamber. Do not use more than 30g of coffee beans.
4. Secure the lid into the motor base. Align the arrow with the “off” marking on the motor base.
5. Connect the coffee grinder to the power supply.
6. Turn the lid clockwise to the “on” mark on the motor base. The coffee grinder will operate. Hold the lid at the “on” position.
7. If the lid is released, it will return to the “off” position and the coffee grinder will stop operating. Turn and hold the lid to the
“on” position if you want the coffee grinder to operate again.
8. View the consistency of the coffee grounds from the transparent lid. Never remove the lid until the blades stop completely.
9. Once the desired ground size has been obtained, disconnect the power cable from the power outlet.
10. Remove the transparent lid and pour out the coffee ground.
NOTE
• Do not run the appliance continuously for more than 30 seconds. After a full 30 second cycle, allow the grinder to rest for
another three minutes before using it again.
USING YOUR COFFEE GRINDER
IMPORTANT
Min. volume for small cup and big cup : 25g
Max. volume for small cup : 100g
Max. volume for big cup : 200g
ABOUT THE SAFETY INSTRUCTIONS
Before using the machine for the rst time, please read the safeguards and safety instructions carefully and keep them for
future reference. If the machine is given to someone else, these operating instructions should also be handed over with it. The
manufacturer and importer do not accept any liability if the information in these operating instructions is not complied with.
EXPLANATION OF THE SYMBOLS
EXPLANATION OF THE SIGNAL WORDS
DANGER Warns of serious injuries and danger to life.
WARNING Warns of possible serious injuries and danger to life.
CAUTION Warns of slight to moderate injuries.
NOTE Warns of damage to property.
Danger symbol
Electric shock risk
Beware of hot surfaces
Risk of re
Suitable for food use
Read operating instructions
before use
The symbols below indicate risks of injury. Read through the associated safety
instructions carefully and follow them.
The machine is equipped with safety features. Nevertheless,
it may still present dangers if it is not used in the intended
way and / or is utilized in some other way. Comply with the
following safety instructions and procedures that are specied in these
operating instructions.
• This machine may be used by children aged 8 and over and by
people with reduced physical, sensory or mental abilities or a lack of
experience and/or knowledge if they are supervised or have received
instruction on how to use the machine safely and have understood
the dangers resulting from failure to comply with the relevant safety
precautions.
• Children must not play with the machine.
• Cleaning and user maintenance may not be performed by children,
unless they are older than 8 years of age and are supervised.
• Children younger than 8 years of age and animals must be kept away
from the machine and the mains cable.
• Keep children and animals away from the packaging material to avoid
any danger of suffocation.
SAFETY INSTRUCTIONS
1110
• Do not make any modications to the machine. Do not replace the
mains cable yourself. If the machine, the mains cable or the power
cord of the machine is damaged, they must be replaced by the
manufacturer, customer service department or authorized retailers in
order to avoid any hazards.
• Please follow the instructions in the Cleaning and Maintenance
chapter on page 15.
DANGER : Electric Shock from Water
• Use the machine only in closed rooms. Do not use the
machine in rooms with high humidity.
• Should the machine fall into water, switch off the power supply
immediately. Do not attempt to pull it out of the water while it is still
connected to the mains power.
• Never touch the machine, power cord with wet hands when these
components are connected to the mains power.
• Make sure that the steam which emerges is not aimed directly at
electrical machines and equipment containing electrical components.
WARNING : Danger of Electric Shock from
Damage and Inappropriate Use
• Only connect the machine to a socket with safety contacts that are
properly installed and matches the technical data of the machine. The
socket must also be readily accessible after connection so that the
connection to the mains can quickly be isolated.
• Do not use the machine in conjunction with extension cables.
DANGER : Risk of Fire
• Do not use the machine in rooms containing easily ignitable
dust or poisonous and explosive fumes.
• Do not connect the machine along with other consumers (with a high
wattage) to a multiple socket in order to prevent overloading and a
possible short circuit (re).
• Do not operate the machine in the vicinity of combustible material. Do
not place any combustible materials (e.g. cardboard, paper, wood or
plastic) in or on the machine.
• Do not cover the machine during operation.
WARNING : Danger of Scalding from Heat,
Hot Steam or Condensation
• Avoid coming into contact with the rising steam. Keep your hands and
head away from the steam outlet openings during the brewing process.
• The portalter gets hot during use. Never attempt to remove the
portalter during the brewing process.
• Be careful when removing the portalter after operating the machine.
There may still be hot water remaining in the portalter. Always allow
this to cool down rst before it is removed / cleaned.
• Never pour water into the water tank or milk into the milk reservoir
when the machine is switched on or during the brewing process.
Always switch off the machine and remove the water tank / milk
reservoir to rell it. Check whether the water tank / milk reservoir has
been inserted correctly before switching it on again.
• Make sure that the milk nozzle is pointing into the cup below the brew
head to prevent any accidental, uncontrolled emission of hot milk from
the milk nozzle.
• Do not move the machine during the brewing process.
• The specialty coffees that are prepared are hot. Be careful when
handling hot liquids.
CAUTION : Hot Surfaces
The machine and the accessories are very hot during and
shortly after use. Only touch the handles and controls while it is in
operation. Allow them to cool down completely before cleaning.
• Note the ll levels (i.e. the min and max markings) on the milk reservoir
and water tank. Fill the milk reservoir and the water tank at least up to
the min marking and no higher than the max marking.
• The machine is not designed to be operated with an external timer or a
separate remote control system.
• Never immerse the machine, mains cable or power cord in water or
other liquids and ensure that they cannot fall into water or become wet.
• The machine must always be disconnected from the mains when it is left
unattended and before assembling, disassembling, lling or emptying
the water tank or milk reservoir or cleaning it.
• In the interest of your own safety, check the machine, the mains
cable and the power cord for damage every time before use. Use the
machine only if it is in working order.
1312
1. Unplug your espresso machine from the power outlet and allow for it to completely cool off before cleaning.
2. Clean the brew head, milk reservoir and the lters after every use.
3. Rinse through the tube in the milk reservoir with clear hot water to remove milk residues after every use.
4. Regularly run the cleaning program to clean the milk reservoir system as well as the brew head on the portalter.
5. Wipe down the housing with a damp cloth. If necessary, use a little mild detergent to remove more intense soiling.
6. Thoroughly dry the machine and all accessories before assembling it again.
7. Check the mains cable regularly for any damage.
NOTE
• Before commencing the cleaning, read the safety instructions in the Important Safeguards and Safety Instructions chapters
on page 2 and page 11 respectively.
• Do not use any toxic, corrosive or abrasive cleaning agents or scouring sponges to clean the machine. These can damage
the surface.
• Never immerse the machine in water.
• Do not use the machine without a suitable container below the brew head and the milk nozzle.
• The water tank and milk reservoir are not suitable to dishwasher.
SELF-CLEANING : QUICK CLEAN OF THE MILK RESERVOIR SYSTEM
The quick clean of the milk reservoir system should be carried out after every use so that no milk residues can remain in the
system and dry on or go moldy.
1. Fill the milk reservoir with water (see the section in the Preparing Cappuccino and Latte Macchiato chapter on page 8).
2. Fold out the milk nozzle using the lever.
3. Press the “On / Off” button to switch on the machine and preheat the water. The control panel ashes during the heating
process.
4. Place a suitable cup below the milk nozzle.
5. As soon as the machine has heated up, the control panel stops ashing. Press the button. A beep will sound. The self-
cleaning will start and the button will ash.
6. Run the program and pour away the contents of the cup after the self-cleaning nishes.
7. Repeat this process if necessary.
INTENSIVE CLEAN OF THE PORTAFILTER AND MILK RESERVOIR SYSTEM
For long term use, we have included a program to avoid any clogging. In this case the yellow light will ash. Please follow the
below “Deep Clean” steps to clear this up.
STEP 1
1. Fill the water tank with water (see the section in the Powering Up Your Machine chapter on page 6).
2. Fill the milk reservoir with water (see the section in the Preparing Cappuccino and Macchiato chapter on page 8).
3. Fold out the milk nozzle using the lever.
4. Press and Hold the “CLEAN” button 4~5secs. The blue lights will illuminate and ash.
5. Cleaning procedure will run for around 15 minutes.
6. The “CLEAN” button will remain illuminated after this step is completed.
STEP 2
1. Press the “CLEAN” button again (around 1sec.)
2. Cleaning procedure will run for around 5 minutes.
3. Once completed, the yellow indicator light will go away after 2 beeps.
COFFEE GRINDER
1. Always switch off and unplug before cleaning.
2. Never left the motor unit, power cable or plug get wet. Only the transparent lid can be immersed in water for cleaning.
3. Clean the lid with water and mild detergent. The lid is not dishwasher-safe. Rinse and dry thoroughly.
• In the event of a re: Do not extinguish with water. Smother the ames
with a reproof blanket or a suitable re extinguisher.
NOTE : Risk of Damage to Material
and Property
• The machine should only be used when it is correctly assembled. Before
each use, ensure a lter and the portalter are inserted, the water tank
and milk reservoir (if applicable) is lled correctly.
• Lay the mains cable in a way that it does not become squashed or bent
and does not come into contact with hot surfaces (also applies to the
hot surfaces of the machine).
• To avoid the machine from being pulled down, the mains cable must not
hang down from the surface on which the machine is placed.
• Switch off the machine and pull the power cord out of the power outlet
if an error occurs during operation, when there is a power cut or before
a thunderstorm.
• Never pull or carry the machine by the mains cable. When you pull it out
of the power outlet, always pull on the power cord and never the mains
cable.
• Protect the machine from other heat sources, naked ames, sub-zero
temperatures, persistent moisture, wet conditions and impacts.
• Use only original spare parts from the manufacturer.
Notes on the Cord
• A short power-supply cord (or detached power-supply cord)
is to be provided to reduce risks resulting from becoming
entangled in or tripping over a long cord.
• Longer detachable power-supply cords or extension cords are available
and may be used if care is exercised in their use.
• If a long detachable power-supply cords or extension cord is used,
(a.) The marked electrical rating of the detachable power-supply cord or
extension cord should be at least as great as the electrical rating of the
appliance. (b.) If the appliance is of the grounded type, the extension
cord should be a grounding type-3 wire cord. (c.) The longer cord
should be arranged so that it will not drape over the counter top or
table top where it can be pulled on by children or tripped over.
CLEANING AND MAINTENANCE
CAUTION
• The “deep clean” process takes around
20 minutes to complete.
• Please DO NOT turn off the machine
or press any buttons to disrupt the
operation.
• Repeat this process if necessary.
1514
WARRANTY
PRODUCT REGISTRATION
EspressoWorks
TM
strongly encourages you to register your purchase. You can register online at www.espresso-works.com
Registering your purchase will allow EspressoWorks
TM
to better serve you with any of your customer service needs.
WHO CAN SEEK WARRANTY COVERAGE
This warranty is extended by EspressoWorks
TM
to the owner of this machine for personal household use only. This warranty
does not apply to products used for commercial, rental or re-sale purposes.
WHAT IS COVERED
EspressoWorks
TM
warrants to the owner that if this machine fails within 1 year from the date of purchase on the purchase
receipt due to a defect in material or workmanship, EspressoWorks
TM
will repair or replace the failed machine or component
part of the machine. Shipping and handling charges may apply. Please retain the original purchase receipt for the duration of
the warranty period. EspressoWorks
TM
reserves the right to refuse a warranty repair if proof of purchase cannot be provided. In
the event of a warranty claim, please return the product with the original purchase receipt.
WHAT IS NOT COVERED
This warranty does not apply to machines that have been used commercially or in non-household applications. This warranty
does not cover cosmetic changes that do not affect performance, such as discoloration or the effects of the use of abrasives or
cleaners or food build up. This warranty is only valid if the machine is used and maintained in accordance with the instructions,
warnings and safeguards contained in the owner’s manual. The warranty does not apply in the event of failure to observe the
operating or assembly instructions.
EspressoWorks
TM
will not be responsible for the cost of any unauthorized warranty repairs.
NO EMPLOYEE OR REPRESENTATIVE OF ESPRESSOWORKS
TM
IS AUTHORIZED TO MAKE ANY ADDITIONAL WARRANTY
OR ANY MODIFICATION TO THIS WARRANTY WHICH MAY BE BINDING UPON ESPRESSOWORKS
TM
. ACCORDINGLY,
PURCHASER SHOULD NOT RELY UPON ANY ADDITIONAL STATEMENTS MADE BY ANY EMPLOYEE OR REPRESENTATIVE
OF ESPRESSOWORKS
TM
. IN NO EVENT, WHETHER BASED ON CONTRACT, INDEMNITY, WARRANTY, TORT (INCLUDING
NEGLIGENCE), STRICT LIABILITY OR OTHERWISE, SHALL ESPRESSOWORKS
TM
BE LIABLE FOR ANY SPECIAL, INDIRECT,
INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING, WITHOUT LIMITATION, LOSS OF PROFIT OR REVENUE.
Some states do not allow limits on warranties. In such states, the above limitations may not apply to you. Outside the U.S.A. and
Canada, other warranties may apply.
For more information, visit www.espresso-works.com
4. Never immerse the monitor base in water for cleaning, or ll the grinder chamber with water for cleaning.
5. Wipe the grinding chamber and blades with a damp cloth, then dry thoroughly. Handle blades and cutting plates with care
becausethey are extremely sharp.
DESCALING
The rst indications that descaling is required are a large amount of steam being produced and slower brewing of the
espresso. The machine indicates at regular intervals that it needs to be descaled. When the yellow control lamp is lit, a
descaling process should be performed. The control lamp goes out as soon as a cleaning or descaling process has been
performed.
Limescale deposits have an adverse effect not only on the quality of the espresso and the water, but they also cause power
losses and shorten the lifespan of the machine. The thicker a limescale layer is, the more difcult it is to remove.
We therefore recommend regularly removing limescale deposits with a descaling agent in accordance with the water quality in
your area and how often the machine is used (approx. every 2 – 6 weeks).
STORAGE
Disconnect the machine from the mains power when it is not going to be used for a prolonged period. Clean the machine
again if necessary and let it dry completely.
Store the machine and all accessories in a dry, clean, frost-free place that is protected from direct sunlight and cannot be
accessed by children or animals.
TROUBLESHOOTING YOUR MACHINE
Problem Reason Solution
The control panel does not light up /
the machine cannot be switched on.
The power cord is not inserted correctly
in the power outlet.
Insert the power cord.
The power outlet is defective. Try another power outlet.
No mains voltage is present. Check the fuse of the mains connection.
The control panel lighting is defective. Please contact us at
The fuse in the fuse box is triggered. Too many machines connected to the
same circuit.
Reduce the number of machines in
the circuit.
No error can be identied. Please contact us at
Water runs out of the machine. There is too much water in the water tank. Do not overll the water tank.
The water tank is not placed in its
mount correctly.
Place the water tank in the correct
position.
Water leaks from the bottom. The drip tray is lled with water. Please clean the drip tray.
for a replacement water tank.
Water leaks from the outer-side of
the lter.
There is some coffee powder on the
lter edge.
Use a damp cloth to wipe away any
residual coffee powder.
A function has been selected, but the
machine beeps constantly and the
red indicator light ashes. The control
panel does not light up.
There is no water in the water tank. 1. Detach the water tank from the
machine and ll it with water (see
the section in the Powering Up Your
Machine chapter on page 6).
2. Place a cup underneath.
3. Press any button. Some water will run
through the water system into the
cup. The machine will stop beeping,
the red indicator light goes out and
the machine can be restarted.
4. Select the function you want again.
The espresso runs very slowly into
the cup.
The brew head or the lter is clogged. Clean the portalter and the lter.
The machine is clogged. Descale the machine (see the Cleaning
and Maintenance chapter on page 15).
The espresso is too weak. There is not enough coffee powder in
the lter.
Pour the right quantity of coffee
powder into the respective lter (see
the Powering Up Your Machine chapter
on page 6).
The set espresso quantity is too much
for the quantity of coffee powder in
the lter.
The perfect amount of espresso to suit
your own taste can be programmed
in the machine (see the Programming
Quantities chapter on page 10).
The coffee beans are not fresh. Use freshly grounded beans for
optimal results. For a stronger brew we
recommend using a dark french roast.
There is a slight taste of acidity in the
espresso.
The machine was not cleaned and
there are residual coffee grounds.
Please refer to the Cleaning &
Maintenance chapter on page 15.
The coffee powder has turned bad after
being stored in a hot and wet place for
long periods of time.
Please use fresh coffee powder, or
store unused coffee powder in a cool
and dry place. After opening a pack of
coffee, reseal it tightly and store it in a
refrigerator to maintain its freshness.
1716
During use, an unpleasant smell is
detected.
Is the machine being used for the rst
time?
A smell often develops when new
machines are rst used. The smell
should disappear once the machine
has been used several times.
Has the machine just been descaled? Rinse out the machine with clear water.
A large amount of steam is produced
in the brewing process.
The machine is clogged. Descale the machine (see the Cleaning
and Maintenance chapter on page 15).
Cappuccino, latte macchiato or milk
froth has been selected, but there is no
milk in the milk reservoir.
Wait until the program has run through.
Allow the machine to cool down a little.
Remove the milk reservoir from the
machine and ll it (see the Preparing
Cappuccino / Latte Macchiato chapter
on page 8). Then run the program again.
The machine is not working.
The power cable was not correctly
plugged into the power outlet.
Plug the power cord into a wall outlet
and if the machine still ceases to
function, please contact us at
BLUE FUNCTION LIGHT FLASHES
MACHINE WARMING UP AFTER TURNING ON
Flashing will occur for around 40 seconds indicating warm up in progress. The machine is ready when
all the blue function lights appear solid with double ashing lights and 2 beeps will sound.
FUNCTION WORKS IN PROGRESS
Blue function light ashes after a function is used. Flashing will occur for around 30 seconds until the
function is ready to be used again. The machine is ready when tthe blue function light appears solid.
MILK RESERVOIR IS NOT PUT IN PLACE
Blue “CAPPUCCINO” , “LATTE” , “MILK FROTH” and “CLEAN” function lights turn off and do
not work when the milk reservoir is not placed properly or missing. Readjust or install the milk reservoir.
Make sure to hear a “click” sound to conrm it is securely in place.
RED INDICATOR LIGHT APPEARS SOLID
WRONG VOLTAGE
Red indicator light appears solid when the machine is plugged into a socket outlet with the incorrect
voltage or wattage is not stable.
1. Please make sure your power supply stable at 120V, 1250W.
2. Please try another socket if needed.
Please contact us at [email protected] if this error persists after following above steps.
RED INDICATOR LIGHT FLASHES
Red indicator light keeps ashing when the machine is out of water, and several beeps sound in succession.
RUN OUT OF WATER IN THE WATER TANK
1. Detach the water tank from the machine and ll it with water.
2. Place a cup underneath.
3. Press any button. Water will run through the system into the cup. The
machine will stop beeping. The red indicator light will delimunate
after 10 seconds. The blue function lights will appear solid.
4. If the blue function lights do not turn on after the above
step, press the “ON/OFF” button. The machine will start to
warm up. All blue function lights will ash for 30-40 seconds.
Once it has warmed up, 2 beeps will sound. The blue
function lights will appear solid.
5. Then the machine is ready to brew.
BREW HEAD IS CLOGGED
1. Clean the brew head and the seal ring.
2. Fill up water tank and install in place.
3. Place a cup underneath and do not install the portalter.
4. Press the “DOUBLE” button. Water will run through the
system into the cup. Repeat 3-5 times. The red indicator
light will eventually delimunate. The blue function lights will
appear solid.
5. Then the machine is ready to brew.
CAUTION
• DO NOT unplug the machine or
press any buttons to disrupt the
operation.
• Please repeat the steps 2-3 times
if the red indicator light ashes
continuously. The machine should
return to its normal settings upon
completion.
YELLOW INDICATOR LIGHT FLASHES
MACHINE IS CLOGGED
For long term storage, we have included a program to avoid any clogging. In this case the yellow
indicator light will ash. Please follow “Deep Clean” steps below to resolve this issue.
STEP 1
1. Fill up water tank and milk reservoir with water up to the
max line. Then install in place.
2. Place a large container which can hold more than 1.5L
water under the brew head. Fold out the milk nozzle on the
milk reservoir by using the level.
3. Press and hold the “CLEAN” button 4-5 seconds.
4. The blue “CLEAN” function light will ash.
5. Cleaning procedure will run for around 15 minutes.
6. The “CLEAN” button will appear solid after this step is
completed.
STEP 2
1. Fill up the water tank to the max level again.
2. Press the “CLEAN” button again (around 1second.)
3. Cleaning procedure at this step will run for around 1-2 minutes.
4. Once completed, the yellow indicator light will deluminate after 2 beeps.
5. Blue function lights will ash up to 40 seconds to warm up. When the blue function lights appear
solid. The machine is ready to use.
NOTE
It is normal that the machine will produce rapid sound during the cleaning procedure. Water will also pour
into the milk reservoir from the water tank. DO NOT turn off or press any buttons until a step is done.
CAUTION
• The whole “Deep Clean” process
takes around 20 minutes to
complete.
• Please monitor the whole process
to avoid water spill.
• DO NOT turn off the machine or
press any buttons to disrupt the
operation.
3.
WATER LEAKS FROM THE MACHINE BOTTOM
SITUATION 1
The drip tray is not placed properly.
SOLUTION
Readjust the drip tray so it can catch
the excess water that ows out normally
during extractions.
SITUATION 2
Water tank is not placed properly.
SOLUTION
Fill up water tank with water at max level.
Then readjust the tank to t snug with
no open areas around the tank.
SITUATION 3
Filled water tank over max line.
SOLUTION
Ensure that the water does not surpass
the max line.
1. 2.
Do not attempt to dismantle your machine.If the cause of failure is not listed above,
please contact us at [email protected]
RESET TO FACTORY SETTINGS
1. Switch off the machine. Do not unplug the machine from the power source.
2. Press and hold the “SINGLE” and “DOUBLE” buttons on the control panel simultaneously. Then press the “ON/ OFF”
button. 5 beeps will sound indicating your machine has successfully reverted to its factory settings.
NOTE
You will have to unlock the machine after resetting before being able to brew.
IMPORTANT
• Please clean the brew head and
the seal ring after every use.
• Do not take out the portarlter
until the the blue function lights
illuminate and water starts owing
into the drip tray. Otherwise the
sudden release of pressure will
cause the coffee coffee grounds to
scatter and clog up the seal ring.
• This would lead to eventual
leakage if not cleaned properly.
1918
MADE IN CHINA
Espresso-Works.com
Complete user instructions, FAQ and usage tips can be found at
Espresso-Works.com
Email us at cs@espresso-works.com
for any unanswered questions
This symbol on the product or in the instructions means that
your electrical and equipment should be disposed at the end
of its life separately from your household wares. There are
separate collection systems for recycling in the EU. For more
information, please contact the local authority or your retailer
where you purchased the product.
FOR HOUSEHOLD USE ONLY
SÓLO PARA USO DOMÉSTICO
UNIQUEMENT POUR UN USAGE À DOMICILE
PARA UTILIZAÇÃO DOMÉSTICO SOMENTE
