1 2 3 4 5 6 7 8
PREMIER 1/4” HEX DRIVE TORQUE
SCREWDRIVER 1-6Nm
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
1. SAFETY
9 Ensure all workshop safety rules, regulations and conditions are complied with when using this tool.
9 Maintain the screwdriver in good condition.
9 The screwdriver is a precision tool, DO NOT drop it or abuse it.
9 Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip shoes.
9 Keep children and unauthorised persons away from the working area.
WARNING! DO NOT use the screwdriver if damaged or thought to be faulty.
9 After use, clean and store in a safe, dry, childproof location.
2. INTRODUCTION
Manufactured from high carbon steel with a contoured aluminium handle for comfort and control. Ideal for automotive based applications
including the replacement of airbags, crash sensors and inertia reel xtures. Also suitable for general factory and workshop use. Quick
release 1/4” Hex drive bit holder. Calibrated in accordance with BS EN 6789:2017. Includes test certicate. Supplied in foam storage tray.
3. SPECIFICATION
4. FEATURES
STS101 Issue 1 23/10/24
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Model No: STS101
Drive: 1/4”Hex
Length: 200mm
Nett Weight: 0.485kg
Range: 1-6Nm
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
MODEL NO: STS101
1 Quick change bit holder
2 Connect bar
3 Adjusting screw nut
4 Main scale
5 Sub-scale
6 Collar
7 Handle
8 Cap
g.1 g.2
5. OPERATION
5.1. USING THE TORQUE SCREWDRIVER
5.1.1. To set the desired torque raise the collar, hold the adjusting screw nut, and rotate the handle to set the desired torque setting, once the
torque setting has been set lock the collar back into place.
5.1.2. For example to set a torque setting of 2.00Nm align the sub dial 0.00 with the main engraving 2.00Nm line. See g.1.
5.1.3. To set a torque setting of 2.20Nm align the sub dial gure of 0.20Nm on the 2.00Nm main engraving line. See g.2.
NOTE: After use always release the tension.
6. MAINTENANCE
8 DO NOT expose the unit to strong magnetic elds, corrosive agents, excessive heat or humidity.
9 Clean only with a damp cloth, do not use proprietary cleaners or solvents to clean this product.
9 When not in use, store in a cool, dry location away from direct sunlight and out of the reach of children.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice. Please note that other versions of this product are available. If you require documentation for alternative versions, please email or call our
technical team on technical@sealey.co.uk or 01284 757505.
Important: No Liability is accepted for incorrect use of this product.
Warranty: This product comes with a lifetime guarantee against manufacturing defects.
