PROFESSIONAL AIR LINE GAUGE
MODEL NO’S: SA37/93.V4, SA37/93B, SA37/94.V3,
SA37/95, SA37/98, SA37/99
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9 Disconnectthetyreinflatorfromtheairsupplybeforechangingaccessories,servicingorperforminganymaintenance.
9 Keepchildrenandunauthorisedpersonsawayfromtheworkarea.
9 Keepthegaugescreenandtyreinflatorclean.
9 ReplacedamagedpartswithgenuineSealeyparts.Unauthorisedpartsmaybedangerousandwillinvalidatethewarranty.
9 Checktyrepressureswhentheyarecold.
8 DO NOTdirectthetyreinflatoroutletatyourselforothersincludinganimals.
8 DO NOTcarrythetyreinflatorbythehose,ortugthehosefromtheairsupply.
8 DO NOTusethetyreinflatorforataskwhichitisnotdesignedtoperform.
8 DO NOToperatethetyreinflatorwhenyouaretiredorundertheinfluenceofintoxicatingmedicines,drugsoralcohol.
8 DO NOToperatethetyreinfltorifpartsaremissingordamaged,thiscouldbedangerous.
8 DO NOTdroporbumpthetyreinflator.
8 DO NOTgetthetyreinflatorwet.
8 DO NOToperatenearapplianceswithstrongmagneticfields,corrosivegassesorcorrosiveliquids.
2. INTRODUCTION
Models SA37/93, SA37/93B, SA37/94 and SA37/95 manufacturedtocomplywithEN12645.Aluminiumbodywithrubberbumper.
Linearpressurescale,dualcalibratedinpsiandbar,withparallaxcorrection.
Models SA37/93 and SA37/93Bhavea0.5mflexiblehosefittedwith240mmtwinpush-onairconnector.ModelSA37/94
isfittedwitha2.5mhosewithclip-onairconnectorforcompliancewithsafetyregulationsrelatingtoinflationofcommercialand
agriculturalvehicletyres.Allaresuppliedwithaserialnumberedcalibrationcertificate.
WarrantyforSA37/93,SA37/94andSA37/95istwoyearsandwarrantyforSA37/93Bisthreeyears.
Model SA37/95: Diecastaluminiumbodywithlargerubberbumper.Linearpressurescale,dualcalibratedinpsiandbar,with
parallaxcorrection.2.5mFlexiblehosefittedwithtwinlock-onairconnector.Suppliedwithaserialnumberedcalibrationcertificate
Models SA37/98 and SA37/99manufacturedfromnylonpolymerandrobustglass.Ergonomiclightweightdesignwithtextured
thumblever.Increasedwindowsizeensuresclearervisionandbetteraccuracy.Linearpressurescale,dualcalibratedin
psiandbar.255mmFlexiblehosewithaclip-onairconnectorfittedtoSA37/98.205mmFlexiblehosewith250mmtwinhold-onair
connectorfittedtoSA37/99.1Yearguarantee*.
3. SPECIFICATION
Models:SA37/93,SA37/93B,SA37/94andSA37/95
Pressurerange:...................................0-9.6bar(0-140psi)
Pressureunits:...........................................................bar,psI
Airsupplyminimum:.........................................5.5bar(80psi)
Airsupplymaximum:.......................................15bar(218psi)
Inletsize:..................................................................1/4”BSP
Models:SA37/98andSA37/99
Pressurerange:...................................0-9.6bar(0-140psi)
Pressureunits:...........................................................bar,psI
Airsupplyminimum:.........................................5.5bar(80psi)
Airsupplymaximum:.......................................13bar(188psi)
Inletsize:..................................................................1/4”BSP
4. OPERATION
4.1. TO READ PRESSURE
4.1.1. Placehold-onchucksquarelyandfirmlyontotyrevalve,beforeeachpressurereadingfullydepressleverandrelease.
4.2. TO INFLATE
4.2.1. Placehold-onchucksquarelyandfirmlyontothevalve.Fullydepressleverforanappropriateperiodthenreleaselevertodisplay
pressure.Checkpressuregaugeandrepeatprocedureuntilcorrectpressurelevelisachieved.
SA37/93.V4,SA37/93B,SA37/94.V3,SA37/95,SA37/98,SA37/99Issue215/06/22
Original Language Version
©JackSealeyLimited
Referto
instructions
background
4.3. TO DEFLATE
4.3.1. Depressleverhalfway(untilaircanbeheardescaping)foranappropriateperiod,fullydepresslevermomentarilythenreleaseto
displaynewpressure.Checkpressuregaugeandrepeatprocedureuntilcorrectpressurelevelisachieved.
5. INSTALLATION
5.1. AIR SUPPLY–Models:SA37/93,SA37/93B,SA37/94andSA37/95-Maximumpressure15Bar(218psi).ModelsSA37/98and
SA37/99-Maximumpressure13Bar(188psi)
5.1.1. Thesupplymustbecleananddry-useasuitablefilter/watertrapifnecessary.
5.2. PIPE WORK
Copperorgalvanisedsteeltubeisrecommendedforthesupplylinefromthecompressor.Thenumberofbendsinthelineshould
bekepttoaminimumandnopocketsorlowpointsshouldbepresenttoallowwatertoaccumulate.Blowthelineclearofany
debrisanddrainoffanyaccumulatedwaterbeforemakingthefinalconnectiontothegauge.
5.3. FLEXIBLE HOSE - Models SA37/93 and SA37/93B
Theflexiblelinetothegaugeshouldbeproperlyratedforthedutyandsupplypressure-hosetoBS5118class2isrecommended.
A1/4”BSPTaper(male)connectionisrequiredtoconnecttothegauge.
5.4. FLEXIBLE HOSE - Model SA37/94 (supplied - 2.5 metres)
Suppliedhosemeetstherequiredstandardsforuseoncommercialandagriculturaltyres.Ifanadditionalextensionhoseisrequired
itmustbeproperlyratedforthedutyandsupplypressure-hosetoBS5118class2isrecommended.
A1/4”BSPTaper(male)connectionisrequiredtoconnecttothegauge.
6. MAINTENANCE
6.1. PERIODIC CHECKS
6.1.1. Forlongserviceandaccuracy,thefollowingactionsshouldbecarriedoutattherecommendedintervals.
6.2. WEEKLY - CHECK OPERATION
6.2.1. Thegaugeshouldbecheckedweeklyforcorrectoperation.Lookforsmoothleveroperationandfast,smoothgaugemovements.
Checkforleaksfromtyreconnectorseals,andforchafingorwearoftheflexiblehoses.Anyproblemsshouldbeimmediately
rectifiedtoensurecalibrationisnotaffected.
6.3. MONTHLY (Model SA37/95)
6.3.1. Removeoilscrew(fig.1)place2-3dropsoflightoilintothegaugemechanism.
6.4. QUARTERLY - CHECK CALIBRATION
Werecommendtheaccuracyofthegaugebecheckedagainstacalibrated‘master’gauge
every3months,oratshorterintervalsdependingonoperator’sownqualityprocedures
manual.
7. TROUBLESHOOTING
7.1. Theseairlinegaugeshavebeenengineeredtogiveyearsoftrouble-freeservice.
Majorfaultsareoftendueeithertoprolongedmistreatmentortoadirty,excessivelywet
airsupply.Thefollowingguidewillenabletheoperatororserviceengineertodiagnoseandcureanyproblemswhichmayarise.
7.1.1. Airleaksfromtyreconnector:Thesealsshouldbereplacedwhenitbecomesdifficulttoobtainaneasy,positiveairtightsealona
tyrevalve.
7.1.2. Damagedflexiblehose(gaugetotyreconnector):Thecompletehoseassemblyshouldbereplacedimmediatelyifanysignofdeep
chafingorcrackingappears.Ensurethatthecentredfilterinthegaugeoutletportdoesnotbecomedislodgedduringreplacement.
7.1.3. Erratichighgaugereadingsorstiff,jerkyleveroperationscausedbyastiffordamagedvalveassembly.Ifnotcuredbyoilingthe
valvemechanismthenreplacethevalveassembly.
7.1.4. Slowtyreinflationcausedbyeitherlowsupplypressure,blockedinletfilter,ordamagedvalvemechanism.
7.1.5. Erraticlowgaugereadingsand/orsluggishgaugeoperation:Gaugedoesnotreturntozerocausedbystiffordamagedgauge
mechanism.Thegaugemustbereturnedtoanauthorisedrepaircentreasspecialequipmentisrequiredtore-checkthecalibration
ofthegaugeafterrepair.
Original Language Version
©JackSealeyLimited
fig.1
SA37/93.V4,SA37/93B,SA37/94.V3,SA37/95,SA37/98,SA37/99Issue215/06/22
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycleunwantedmaterialsinsteadofdisposingofthemaswaste.Alltools,accessoriesandpackagingshouldbesorted,takento
arecyclingcentreanddisposedofinamannerwhichiscompatiblewiththeenvironment.Whentheproductbecomescompletely
unserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersanddisposeoftheproductandfluids
accordingtolocalregulations.
Note:Itisourpolicytocontinuallyimproveproductsandassuchwereservetherighttoalterdata,specificationsandcomponentpartswithoutprior
notice.Pleasenotethatotherversionsofthisproductareavailable.Ifyourequiredocumentationforalternativeversions,pleaseemailorcall
ourtechnicalteamontechnical@sealey.co.ukor01284757505.
Important:NoLiabilityisacceptedforincorrectuseofthisproduct.
Warranty:Guaranteeis24monthsfrompurchasedateSA37/93,SA37/94,SA3795and36monthsforSA37/93B,proofofwhichisrequiredforany
claim.
background
Original Language Version
©JackSealeyLimited
SA37/93.V4,SA37/93B,SA37/94.V3,SA37/95,SA37/98,SA37/99Issue210/06/22
