Limited One Year Warn
This warranty gives you specific legal rights.
You may also have other rights which va
from state to state.
Dual Electronics Corp. warrants this product
to the original purchaser to be free from
defects in material and workmanship for a
period of one year from the date of the original
purchase.
Dual Electronics Corp. agrees. at our option,
during the warranty period, to repair any defect
in material or workmanship or to fuish an
equal new. renewed or comparable product
(whichever is deemed necessa) in exchange
without charges. subject to verifition of the
defect or malfunction and proof of the date of
purchase. Subsequent replacement produs
are warranted for the balance of the original
warranty period.
Who Is ce This warranty is extended
to the original retail purchaser for products
purchased and used in the U.S.A.
What Is This warranty covers all
defects in material and workmanship in
this product. The following are not covered,
installation/removal costs. damage resulting
from accident. misuse. abuse. neglect. product
modification. improper installation. incorrect
line voltage. unauthorized repair or ilure to
follow instructions supplied with the product.
or damage occurring during retu shipment
of the product.
t to ?
1. Before you ll for seice. check the
troubleshooting guide in your owner's
manual. A slight adjustment of any custom
controls may save you a seice call.
2. If you require seice during the warranty
period, you must carefully pack the product
(preferably in the original package) and ship
it by prepaid transpoation with a copy of
the original receipt from the retailer to an
authorized seice center.
3. Please describe your problem in writing and
include your name. a retu UPS shipping
address (P.O. Box not acceptable). and a
daytime phone number with your shipment.
4. For more information and for the location of
the nearest authorized service center please
contact us by one of the following methods,
• Call us toll-free at 1-866-382-5476
• E-mail us at [email protected]
Exclusion of Certain Damages, This warranty
is exclusive and in lieu of any and all other
warranties. expressed or implied. including
without limitation the implied warranties of
merchantability and fitness for a particular
purpose and any obligation. liability. right.
claim or remedy in contract or tort. whether
or not arising from the company's negligence,
actual or imputed. No person or representative
is authorized to assume for the company any
other liability in connection with the sale of
this product. In no event shall the company be
liable for indirect. incidental or consequential
damages.
Dual Electronics Corporation Toll Free:
1-866-382-5476
Monday-Friday, 9:00 a.m,to 5:00 p.m,EST)
www.dualav.com
©2021 Dual Electronics Corp. All rights
reserved. NSA0521-V01
Printed in China
SBX100
INSTALLATION/OWNER'S MANUAL
10" Subwoofer in Vented Enclosure
with Multiple Mounting Options
Installation
Thank you for purchasing the SBX100 10" Subwoofer in
V
ented Enclosure. Although
Dual has attempted to make sure all of the information contained within this manual is
accurate. please be aware that any part of it is subject to change without notice.
The following instructions should be used as a general guideline
_
, CAUTION
only. If you are unsure about performing any of the procedures
listed below, please consult a professional car audio installation
center.
Be Insllation, please llow these guldeUnes,
1. Be sure to carefully read and understand the instructions before attempting to install
this product.
2. For safety, disconnect the negative terminal from the batte prior to beginning the
installation of your amplifier.
3. Use the highest quality wire and connectors for a reliable installation and to minimize
signal or power loss.
4. Use caution if you drill or cut! Be careful not to cut or drill into gas tanks. fuel lines.
brake or hydraulic lines. vacuum lines or electrical wiring when working on any
vehicle.
5. Never run wires underneath your vehicle. Running wires inside the v
ehicle provides
the best protection from exhaust heat and environmental elements.
6. Avoid running wires over, near or through sharp edged surfaces. Use rubber
grommets to prote any wires routed through metal.
7. When running wires from the amplifier. avoid running it near sources of high current
nneion Diagm
Strip 5/8" off the end of the wires. and connect the SBX100 to an amplifier as shown in the
Connection Diagram below.
2
Installation Diagram
The below diagrams can to be used with the dimensions listed below to
provide measurements for mounting the enclosure.
Design and specifications subject to change without notice.
Dimensions
Specifitions
Sensitivity: 88dB
Frequency response: 25Hz-500Hz
Nominal impedance: 4 Ohm
RMS power output, 175 Watts
Peak power output: 500 Watts
3
