Page 2
Step 1: Carefully unpack and identify all parts packed in
the carton against the parts list. Remove all
protective materials. If you are missing any parts
or are unsure how to proceed with assembly, call
our customer service center immediately at
1-800-416-3511. Do not attempt to assemble
glider if any parts are missing or damaged.
Assemble furniture on a smooth, non-abrasive
surface.
Step 2: Attach the back frame to the seat frame by using two
1/4"x35mm bolts and washers as shown in Figure 1.
Guide the bolts through the holes in the seat frame,
into the pre-drilled holes in the back frame. Hand
tighten only 2-3 turns.
A
FOOT CAP
IMPORTANT!! PLEASE READ ENTIRE INSTRUCTION SHEET BEFORE ASSEMBLY!!
TO EXPEDITE ANY FUTURE WARRANTY CLAIMS, PLEASE KEEP INSTRUCTION SHEET, WARRANTY CARD, AND RECEIPT.
FF
HH
E
H
C
* NOTE: PARTS SHOWN ON PARTS LIST ARE NOT TO SCALE
SG0279
SG0282
SG0283
PARTS LIST
HEX BOLT DRIVER
HW0006
10
1
1
A
B
C
D
E
F
G
H
I
2
Ø6.5 X 1.0 MM WASHER HW0004
1/4" X 35 MM BOLT
HW0142
DESCRIPTION ORDER PART #
QTY
4
1/4" X 30 MM BOLT
HW0038
FOOT CAP
FACTORY ASSEMBLY
FC0013
4
1/4" X 40 MM BOLT
HW0086
1
1
LEFT ARM
RIGHT ARM
BACK FRAME
SEAT FRAME WITH
GLIDER BASE
1
Figure 1
Figure 2
BGR00723K01
B
Step 3: Attach the back frame to the left arm by using two
1/4"x40mm bolts and washers as shown in Figure 2.
Guide the bolts through the holes in the back frame
into the pre-drilled holes in the left arm. Hand tighten
only 2-3 turns. Attach the seat frame to the left arm
by using two 1/4"x30mm bolts and washers as shown
in Figure 2. Guide the bolts through the holes in the
seat frame into the pre-drilled holes in the left arm.
Hand tighten only 2-3 turns. Repeat for the other
arm.
Step 4: Using the hex bolt driver provided, tighten all bolts.
Do not over tighten bolts. Your swivel glider is now
ready for use. If you have any questions, please call
our Customer Service Center at 1-800-416-3511.
SG0280
D
G
H
G
H
Page 1
PATIO FURNITURE & ACCESSORIES
ASSEMBLY INSTRUCTIONS
IMPORTANT
SKU #272-2297
ANNISTON SWIVEL GLIDER BLUE
Customer Service 1-800-416-3511
STOP. PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE
ASSEMBLY. MAKE SURE YOU HAVE ALL THE PARTS AND
HARDWARE AS IDENTIFIED ON THE PARTS LIST.
MISSING PARTS? DAMAGED PARTS? DON'T GO BACK TO THE
RETAILER. WE CAN HELP YOU FASTER.
CALL OUR CUSTOMER SERVICE CENTER AT 1-800-416-3511
BETWEEN 9:00AM AND 5:00PM (EASTERN TIME) MONDAY
THROUGH FRIDAY (CLOSED HOLIDAYS).
OR, VISIT OUR WEBSITE AT: www.agio-usa.com
TO EXPEDITE ANY FUTURE WARRANTY CLAIMS, RETAIN THE
INSTRUCTION SHEET, WARRANTY CARD, AND RECEIPT FOR
FUTURE USE. YOU ARE ENCOURAGED TO REGISTER YOUR
PURCHASE ON OUR WEBSITE AT www.agio-usa.com
FOR ADDITIONAL ONLINE VIDEO SUPPORT ON ASSEMBLY,
TROUBLESHOOTING, AND CARE AND MAINTENANCE OF YOUR
AGIO OUTDOOR FURNITURE, PLEASE VISIT OUR WEBSITE AT:
www.agio-usa.com
ACOV107
CARE AND MAINTENANCE
FRAMES
Cleaning - Use mild soap and warm water. Do not use abrasive materials, cleaners, or bleach products. Rinse with clean water
and dry thoroughly.
Maintenance - Periodically clean and dry thoroughly. Be sure to drain any water accumulated inside the frames. To thoroughly
drain frames, remove foot caps and tilt the frames, if necessary, to remove all water. This is critical. Water allowed to accumulate
inside the frames and then exposed to sub-freezing temperatures can cause damage to the frame tubing. Such damage is not
covered under warranty. Always clean, drain, and dry thoroughly before storing for the winter. For best results, always store or
cover your furniture when not in use. We recommend commercially available outdoor furniture covers. Any small nicks or
scratches can be covered with a light application of touch-up paint.
** When cleaning or moving large or heavy items, always have two people work together. Never drag furniture.
SPECIAL WARNINGS!!!
UMBRELLA USAGE WARNING!
Place the umbrella through the opening and into an umbrella stand made of cast iron, wrought iron, steel plate or blow molded
plastic filled with 20-50 lbs or 9-22 kgs of sand or water. If your table is 72" or 182 cm or larger, we recommend a weight of at
least 50 lbs or 22 kgs or more. NEVER USE AN UMBRELLA WITH A TABLE WITHOUT USING AN UMBRELLA BASE OR
RING AS DESCRIBED ABOVE. ALWAYS REMOVE YOUR UMBRELLA FROM THE TABLE WHEN NOT IN USE.
NEVER USE AN UMBRELLA DURING STORMS OR WINDY CONDITIONS.
LIMITED WARRANTY
·Frames. Frame construction is warranted against defects in material and workmanship for one year from purchase date.
Damage to frames or welds resulting from improper assembly or exposure to water and/or sub-freezing temperatures is not
covered.
·Finishes. Paint finishes are warranted against peeling, cracking and blistering for one year from purchase date provided the
unit has not been scratched or abraded. Chips and scratches resulting from normal wear and tear are not covered.
·Fabrics. Fabric and cushions (if applicable) are warranted against separation at the seams for one year from purchase date.
Fading and/or discoloration resulting from exposure to the elements, oils, spills, fluids, chemicals, or any other cause is not
covered.
·Straps and/or wicker. Straps and/or wicker weave (if applicable) are warranted against separation and tearing for one year
from purchase date. Fading and/or discoloration resulting from exposure to the elements, oils, spills, fluids, chemicals, or
any other cause is not covered.
·Umbrellas. Umbrellas (if applicable) are warranted against defects in material and workmanship only for one year from
purchase date. Umbrella bases (if applicable) are not covered under any circumstance.
·Table tops. Natural stone tabletops only are warranted against defects in materials or workmanship only for one year from
purchase date. All other table tops (including without limitation glass and faux stone) are not covered under any
circumstances.
Warranty limitations: This warranty is subject to the limitations set forth above. In addition, this warranty is made to the original
purchaser only, and is effective only when item(s) is purchased from one of our authorized dealers. This warranty is not
transferable. For warranty replacements based on warranty claims submitted within the first year of purchase, we will pay shipping
and handling charges within the continental North America. After the first year, shipping and handling charges are your
responsibility. We will not be responsible for charges associated with shipments outside the continental North America at any time
or for any reason.
Warranty exclusions: This warranty is subject to the exclusions as set forth above. In addition, the following are excluded from
coverage under this warranty: any item used for commercial, contract or any other non-residential purpose; clearance items, display
models or items purchased "as is"; freight damage; items subject to misuse, abuse, neglect or lack of proper care and maintenance
(including without limitation as provided in any "care and maintenance guide"); normal wear and tear; damage caused by acts of
nature, acts of force majeure, vandalism, fire or other casualty, or improper assembly; hardware against corrosion or rusting;
purchased or replacement parts; and all plastic parts. Also excluded are loss of use or time; inconvenience; money; travel;
packaging; or incidental, special or consequential damages of any kind. Replacement of defective items as provided herein shall
constitute your sole and exclusive remedy for items which are not as warranted. In no event shall our responsibility exceed the
purchase price of the items found to be other than as warranted. This warranty is the exclusive statement of your rights with respect
to the defects in the items you have purchased and supersedes any other express warranty or statement, written or oral, made in
connection with the purchase and sale of such items. When used herein, the term "item" when used in the singular, refers to the
specific item found to be defective, and not to the entire set of which the item is a part.
Some states do not allow exclusion or limitation of incidental or consequential damages, so that limitation above may not
apply to you. This warranty gives you specific legal rights, and you may also have other rights which vary from state to
state.
