Charge Cable X 1 Smart Watch X 1 Welcome Guide X1
Please read this Guide carefully before using the product
Product Overview
WELCOME GUIDE
* For safety issue, the product remains low capacity during shipping. Please fully
charge the product before initial use!
For the best experience we recommend using the updated oraimo Health App for
iOS and Android.
iOS 11.0 or above
Android 6.0 or above
OSW-34
oraimo Watch 3 Pro
Home Button
Full Touchscreen
Wrist Strap
Charging Port Heart Rate Sensor
Setting Up Your Smart Watch
Pair With Your Phone
1. Get ready with the oraimo Health App, scan the QR code on your watch or nd the
oraimo Health App in one of these locations, depending on your device:
2. When the App is installed, open it and follow the instructions that help you create
your account, or login to your existing account.
3. Your account asks for information such as height, weight, and gender to make various
calculations and tailor your experience using the app. You can modify your information
in oraimo Health – Account - User.
4. Long press the home button of the watch to turn it on, follow the onscreen instructions
to setup the language, and get ready pairing with the phone.
The Apple App Store
for iPhone.
The Google Play Store
for Android phone.
Scan the QR code to pair:
Use oraimo Health APP to scan QR code
Binding successfully
done
Binding…
BT Call
Before pairing your phone and the watch for the BT Call function, make sure the BT
for call on the watch is switched on:
Method 1:
Press the home button in the main dial, tap the Phone menu item to switch on the BT for call
on the watch.
Device QR code
If you can't pair successfully, try the following methods:
1. Make sure the BT permission is allowed for the app;
2. Make sure the watch is not connected with another phone;
3. Try turning off and on again the BT switch on your phone;
4. If none of these work, try rebooting your phone and the watch,
and repeat the above steps again.
After pairing with your phone, read through this guide to explore the various
functions!
Method 2:
Swipe down from the main dial to enter the below interface, follow the picture to turn
on the BT for call.
In the BT list of the mobile system, connect to "oraimo Watch 3 Pro_Calling" and you
can use the watch to make calls.
In Android
In iOS
oraimo Watch 3 Pro_Calling oraimo Watch 3 Pro_Calling
oraimo Watch 3 Pro_Calling
oraimo Watch 3 Pro_Calling
Getting To Know Your Smart Watch
Wrist Placement
For all-day wear, your watch should usually rest a nger’s width below your wrist bone
and lay at, as you would normally wear a watch.
Charge Your Watch
Connect the metal contacts on the charging dock to those on the back of the device,
then put them on a at surface.
Connect the charging cradle to a power supply, the device's screen will light up and
display the battery level.
Please dry the port, metal contacts, and the device before charging.
Using The Clock And Menus
The home screen is a clock. From here you can swipe to see data about your steps,
activity time, calories, heart rate, and functions like training modes, weather, message,
music, etc.
Power On/Off
• When the watch is powered off, charge the watch or long press the home button for
3 seconds to power it on.
• When the watch is turned on, press and hold the home button for 3 seconds. Choose
Power Off and tap again to conrm. The watch vibrates and turns off. You can also
power off from the “Settings” menu. (Settings – System Settings – Power Off)
When there is something wrong on the watch, please press and hold the home button
for more than 12 seconds to hard reset.
Wake Up the Watch
When you’re not using this product, the display is off. To wake it up:
• Press the home button.
• Turn your wrist towards you. This function, known as “Raise to Wake”, can be turned
off in Settings – Raise to wake. You can also schedule when it’s activated during the day.
1. Make sure your device supports BT 5.3. Make sure your device’s software is or above
iOS 11.0 or Android 6.0.
2. Restart BT and reconnect after 20 seconds.
3. Restart your phone.
4. Make sure your phone is not connected with other devices.
5. Make sure oraimo Health App is running in your phone’s system.
To ensure accuracy of monitoring, please wear the smart watch tightly with a distance
of at least one nger from the wrist bone. Place the optical monitoring sensor on the
skin without any blockage.
Trouble Shooting
Can’t connect with BT.
Can't monitor heart rate, oxygen, and pressure.
Can’t find the watch through BT.
Make sure yourlocationservicesareenabled(GPSisworking), the product has enough
power, it’s not connected with another phone and is powered on, then keep it close to
your phone.
If you still can not nd it, please turn off your phone’s BT function and reconnect after
20 seconds.
Can’t receive notifications after enabling it.
Android phone: Make sure the product is connected with your phone. Allow oraimo
Health App to access notications. If any security App installed, add oraimo Health to
trust list.
iPh: Make sure the product is connected with your phone. Reboot your phone and try
to reconnect with the product.
Is the product waterproof ?
This product supports IP68 waterproof which allows the product to be held in water for
a maximum of 30 minutes at a depth of 1 metre. You can wear it while washing your
hands, having a cold shower or washing your car. Please do not wear it while diving or
scuba diving.
Do I need to connect BT all the time? Will my health and sleep data
stored if not connected to the phone?
Data will be kept in the watch for seven days. When it is reconnected to the phone,
your health and sleep data will be synced automatically. Please remember to
synchronize data with the phone in time to get maximized utility.
Note: Call and message notications only work when BT is connected.
Trouble Shooting
Basic Product Specifications
Display Screen 1.83''TFT，240*284
BT Version V5.3
Battery Capacity 250mAh
Battery Type Lithium polymer battery
Standby Time Up to 7 days * Lab test result
Watch Size 45.69*37.24*12.9mm（without strap）
Weight 43.2g（with strap）
Material ABS/PC
Waterproof IP68
* oraimo Lab test result
(dd/mm/yy)
Address :
Tel. No. :
Date of purchase :
Store name :
Warranty period :
Name :
Warranty Certificate
Warranty Terms & Conditions
All quality-related defects on items sold directly by oraimo or oraimo’s authorized
resellers are covered by an extensive warranty, starting from the date of purchase.
oraimo’s limited warranty is restricted to the country of purchase. The limited
warranty is void on items taken outside the country they were originally bought in or
shipped to directly from an authorized online purchase.
This warranty covers only original oraimo products. It is not applicable to normal
wear and tear, or any defects arising from damage caused by misuse of this product.
Warranty is for the primary product only nor transferable. Any free additional
product(s) are not covered in this warranty.
If the product fails regardless of usage in compliance with the instruction manual
and other written precaution, replacement will be provided free of charge.
To receive replacement, bring the warranty certicate and the product itself to the
store from where you have purchased the product.
Customer Service
365 DAYS WARRANTY
Email: [email protected]
User Manual
Smart Watch
Model: OSW-34
Hereby, ORAIMO TECHNOLOGY LIMITED.
Declares that this Smart Watch is in compliance with the essential requirements and other relevant
provisions of directive 2014/53/EU.
CAUTION：
1.Risk of explosion if battery is replaced by an incorrect type, dispose of used batteries according
to the instructions.
– disposal of a battery into re or a hot oven, or mechanically crushing or cutting of a battery, that
can result in an explosion;
– leaving a battery in an extremely high temperature surrounding environment that can result in an
explosion or the leakage of ammable liquid or gas;
– a battery subjected to extremely low air pressure that may result in an explosion or the leakage
of ammable liquid or gas.
2.EUT Temperature: 0℃～+45℃(Standalone).
Frequency Range(RF)：
BT: 2402-2480MHz (TX/RX);
RF output power （only for CE）:
BT:8.9dBm
BLE :8.77dBm
FCC Caution:
Any Changes or modications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
IMPORTANT NOTE:
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment.
EU Declaration of Conformity
In accordance with EU Directives and Regulations
Company name: ORAIMO TECHNOLOGY LIMITED
Address: FLAT N 16/F BLOCK B UNIVERSAL INDUSTRIAL CENTRE 19-25 SHAN MEI STREET
FOTAN NT HONGKONG
as the manufacturer hereby declares under our sole responsibility that the,
Product(s): Smart Watch
Model name: OSW-34
is in conformity with the essential requirements of the RE Directive 2014/53/EU:
Radio ETSI EN 300 328 V2.2.2 (2019-07)
Article 3.2
EMC ETSI EN 301 489-1 V2.2.3 (2019-11)
Article 3.1(b) DRAFT ETSI EN 301 489-17 V3.2.5 (2022-08);
Safety EN IEC 62368-1:2020+A11:2020
Article 3.1(a)
Health EN 50663:2017, EN 62479:2010
Article 3.1(a)
An EU Type Examination Certicate for this Product was issued in accordance with Annex III
(Module B) of the 2014/53/EU Radio Equipment Directive by Bay Area Compliance Laboratories
Corp. (2014/53/EU Radio Equipment Directive Notied Body Identication Number 1313)
Signed on behalf of ORAIMO TECHNOLOGY LIMITED
(Signature of authorized person)
Nengyong.Wu
Signature:
Manager
Date: 2023-3-16
