PLTWB3
1.0'' Voice Coil Titanium Dome Tweeter
WIRING CONNECTION
Connect the power amplier to the positive
and negative terminals accordingly as shown.
www.PyleUSA.com
D/58mm
H/31mm
H/20mm
d/43.7mm
Questions? Issues?
We are here to help!
Phone: (1) 718-535-1800
Email: suppor[email protected]
Features:
• Die-Cast Aluminum Frame
• 2.3 Inches Full Range Car Speakers
• Enhance Sound System for Car Bass, Crossover Tweeter for Car Component Stereo
• Enhance Lower Frequency Music Note
• Aluminum Housings
• 3 Mounting Options: Flush / Swivel / Surface or Angle Mount
• Wide Range
What's in the Box:
• (1) Pair Tweeter
Technical Specs:
• Cone Type: Titanium Dome
• Voice Coil Diameter: 1.0”
• Magnet Type: NdFeb Magnet, 24.5*3.5mm
• Power Supply: 80 Watts MAX, 40 Watts RMS
• Voice Coil: 1.0”
• Impedance: 4 Ohm
• Sensitivity: 105 dB 1W/1M
• Response: 2.0K Hz-20K Hz
• Product Dimensions: 2.3'' x 2.3'' x 1.2'' -inches
• Cutout Size: 1.72'' –inches
• Mounting Depth: 0.78'' –inches
