SwitchPack™ Cable Drive Assembly
47-53-2774, 47-53-2816
L35A
54-05-0005
June 2022
REVISED BULLETIN
SERVICE PARTS LIST
BULLETIN NO.
WIRING INSTRUCTION
DATE
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
CAT. NO.
STARTING
SERIAL NO.
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 --------------- Plastic Button (1)
2 --------------- Button Ramp (1)
3 --------------- Button Mount - B Side (1)
4 --------------- Button Mount - A Side (1)
5 --------------- Compression Spring (1)
6 43-33-0017 Self Tapping Grease Fitting (3)
7 05-81-0072 M4 x 28mm Pan Hd. Phillips Machine Screw (2)
8 02-40-0012 Feed Bearing (Set of two) (3)
9 45-94-0028 Ratchet Bar (1)
11 --------------- Push Bar (1)
12 43-76-0061 Ratchet Housing - Bottom (1)
13 05-81-0074 M5 x 51mm Pan Hd. T-20 Machine Screw (6)
14 05-74-0078 M4 x 14mm Pan Hd. T-20 Machine Screw (10)
16 44-60-0108 Pin (1)
17 44-66-0187 Switch Plate (1)
18 43-72-0026 Bottom Bearing Holder - Left (1)
19 06-82-4003 M4 x 16mm Pan Hd. ST T-20 Screw (8)
21 44-60-0126 Bearing Holder Pin (3)
23 40-50-0173 Double Torsion Spring (1)
24 --------------- Long Friction Spring (1)
25 --------------- Friction Plate (3)
27 43-72-0028 Bottom Bearing Holder - Right (1)
28 44-86-0305 Retaining Ring (2)
29 43-72-0031 Top Bearing Holder (1)
30 42-42-0101 Quick Release Button (1)
31 --------------- Short Friction Spring (1)
32 --------------- Top Ratchet Housing (1)
33 --------------- Feed Handle Halve - Top (1)
34 --------------- Bearing Washer (3)
35 --------------- Bottom Bearing Holder (2)
36 44-60-0116 Pin (1)
39 40-50-0176 Flat Spring Sheet (1)
40 44-94-0036 Pivot Rod (2)
41 34-60-2873 Retaining Ring (2)
43 44-66-0189 Back Plate (1)
45 --------------- Feed Handle Halve - Bottom (1)
46 44-10-0044 Lever Arm Cross Bar (2)
47 34-60-0093 Retaining Ring (1)
48 --------------- O-Ring (1)
50 43-62-0052 Feed Handle (1)
51 44-66-0191 Front Plate/Tube (1)
60 43-72-0033 Bottom Bearing Holder Assembly (2)
61 43-62-0054 Feed Handle Kit (1)
62 43-72-0036 Top Bearing Holder Assembly (1)
63 42-42-0091 Button Kit (1)
64 14-46-0082 Ratchet Bar/Friction Plate Kit (1)
65 43-76-0063 Top Ratchet Housing Assembly (1)
66 12-20-0238 Service Nameplate (Not Shown) (1)
