CRP-JH06 Fuzzy Series
1.08L(2~6Persons) / 1.08L(2~6 )
사용설명서
Operating Instructions
NO.1 CUCKOO
CUCKOO IH PRESSURE JAR COOKER
저희 쿠쿠 IH압력밥솥을 애용해 주셔서
대단히 감사 드립니다.
이 사용설명서는 잘 보관하여 주십시오.
사용 중에 모르는 사항이 있을 때나 기능이 제대로
발휘되지
않을 때 많은 도움이 될 것입니다.
Thank you very much for purchasing
“
CUCKOO
”
IH PRESSURE JAR COOKER
Read the following instruction manual before use. Save this
instruction manual for future reference. This manual will be
useful if you have any questions or have problems operating the
rice cooker.
使用前
Important safeguards
…………………………………………
3
产品规格
…………………………………………………………
4
安全警告
……………………………………………………
9~10
产品部仵名称
…………………………………………………
59
产品清洁方法
……………………………………………
60~61
功能操作部的名称及作用
……………………………………
62
使用时
语音音量调节功能
……………………………………………
62
设置现在时间/夜间语音音量设置功能
……………………
63
煮饭前准备事项
………………………………………………
64
煮饭方法
………………………………………………………
65
调节饭味功能使用方法
/
调节煮饭功能使用方法
…………
66
糙米发芽煮饭方法
……………………………………………
67
锅巴硬度设定方法
……………………………………………
67
超级谷物使用方法
……………………………………………
68
低压蒸/高压蒸使用方法
………………………………………
69
压力检测使用方法
……………………………………………
70
预约煮饭/预约再加热使用方法
…………………………
71~72
목차
사용하기전에
Important safeguards
…………………………………………
3
제품규격
…………………………………………………………
4
안전상의 경고
…
………………………………………………
7~8
각 부분의 이름
…………………………………………………
35
제품 손질 방법
……………………………………………
36~37
기능 조작부의 이름과 역할
……………………………………
3
8
사용할 때
음성 안내 기능의 설정과 해제
…………………………………
38
현재시각의 설정 / 야간음성 볼륨 설정 기능
…………………
39
취사 전 준비사항
………………………………………………
40
취사는 이렇게 하십시오
………………………………………
41
쿠쿠 맞춤 밥맛 / 쿠쿠 맞춤 취사 기능
………………………
42
현미발아는 이렇게 하십시오
……………………………………
43
누룽지 눌음 강화 기능은 이렇게 하십시오
………………………
43
슈퍼곡물은 이렇게 하십시오
……………………………………
44
저압찜/고압찜은 이렇게 하십시오
………………………………
45
압력체크는 이렇게 하십시오
…………………………………
46
예약 취사 / 예약 재가열은 이렇게 하십시오
……………
47~48
밥을 맛있게 보온하려면
…………………………………
49~50
밥을 맛있게 드시려면 이렇게 하십시오
………………………
51
절전기능 / 에너지 아이 기능
…………………………………
52
화면조명 절전기능/버튼잠금기능/
취사 잔여시간 표시기능은 이렇게 하십시오
…………………
53
고장신고 전에
고장신고 전에 확인 하십시오
………………………………
54~56
요리안내
요리안내
……………………………………………………
57~58
CONTENTS
目录
BEFORE USING
Important safeguards
…………………………………………
3
Specifications
…………………………………………………
4
Safety precautions
…………………………………………
5~6
Name of each part
……………………………………………
11
How to clean
……………………………………………
12~13
Function operating part
………………………………………
14
WHEN USING
How to set or cancel voice guide function
………………………
14
How to set current time / Night voice volume Setting
………
15
Before cooking rice
……………………………………………
16
How to cook
……………………………………………………
17
My mode
(CUCKOO Customized taste function)
……………
18
How to use “GABA Rice (BROWN Rice)”
…………………
19
How to make More Crispy Nurungji
…………………………
19
How to Cook Supergrains
……………………………………
20
How to Cook Low/High Press Steam
……………………………
21
How to Use Pressure Check
…………………………………
22
How to use Preset / Preset Reheating Function
………
23~24
To keep cooked rice warm and tasty
…………………
25~26
For the best taste of rice
………………………………………
27
How to use power save / Energy Eye function
………………
28
How to use power save screen light / lock button /
Remaining cooking time display mode
n
…………………………
29
BEFORE ASKING FOR SERVICE
Check before asking for service
…………………………
30~32
COOKING GUIDE
Recipe
……………………………………………………
33~34
CONTENTS
使用时
米饭保温方法
……………………………………………
73~74
如何做美味可口的米饭
………………………………………
75
省电功能 /ENERGY EYE 功能
………………………………
76
画面亮度省电功能/按键锁定功能
/煮饭剩余时间显示功能使用方法
……………………………
77
故障咨询前
常见故障及处理办法
……………………………………
78~80
料理指南
料理指南
…………………………………………………
81~82
3
1
. Read all instructions before using this appliance.
2
. Do not touch hot surfaces. Use handles or knobs.
3. To protect against fire, electric shock and / or injury to persons do not immerse cord, plugs, or Pressure
Cooker Body in water or any other liquid.
4. Close supervision is necessary when this appliance is used by or near children. This appliance is not
intended for use by young children without supervision.
5. Unplug cord from outlet when not in use and before cleaning.
Allow appliance to cool before putting on or taking off parts, and before cleaning the appliance.
6. Do not operate any appliance with a damaged cord or plug, after the appliance malfunctions, or has
been damaged in any manner. Return the appliance to the nearest authorized service facility for
examination, repair or adjustment.
7. The use of accessory attachments not recommended by the appliance manufacturer may result in fire,
electric shock, and / or injury to persons.
8. If the supply cord is damaged, it must be replaced by a special cord or assembly available from the
manufacturer or your service agent.
9. Do not use outdoors.
10. Do not let the cord hang over the edge of a table or counter, or touch hot surfaces.
11. Do not place on or near a hot gas, electric burner, or in a heated oven.
12. Always attach the plug to the appliance first, then plug the cord into the wall outlet. To disconnect, or
set all control to “off”, then remove the plug from the wall outlet.
13. Do not use this appliance for other than its intended use.
14. Extreme caution must be used when moving an appliance containing hot oil or any hot liquids.
15. Oversized foods, metal foil packages, or utensils must not be inserted into the appliance as they are a
risk of fire or electric shock.
16. Fire may occur if the appliance is covered or touching flammable material, including curtains, draperies,
walls, etc while in operation.
17. To reduce the risk of electric shock, cook only in the provided removable container.
18. This appliance cooks under pressure. Improper use may result in scalding injury.
Before operating the unit, properly secure and close the unit. See “Operating Instructions.”
19. Do not cook foods such as applesauce, cranberries, cereals, macaroni, spaghetti, or other foods.
These foods tend to foam, froth, and sputter, and may block the pressure releasing device
20. Before use always check the pressure releasing device for clogging.
21. Do not open the pressure cooker until the unit has cooled and internal pressure has been reduced.
See “Operating Instructions.”
22. Do not use this pressure cooker to fry in oil.
23. the ducts in the pressure regulator allowing the escape of steam should be checked regularly to ensure
that they are not blocked.
24. Appliances can be used by persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.Children shall not play with the appliance.
25. This appliance shall not be used by children. Keep the appliance and its cord out of reach of children.
SAVE THESE INSTRUCTIONS
THIS APPLIANCE IS FOR HOUSEHOLD USE ONLY
WARNING : This appliance generates heat and releases steam during use. Use proper precaution to
prevent risk of burns, fires, other injuries, or damage to property.
1. Keep hands and face away from the Pressure Release Valve when releasing pressure.
2. Take extreme caution when opening the Lid after cooking. Severe burns can result from steam inside.
3. Never open the Lid while the unit is in operation.
4. Do not use without the inner Pot in place.
5. Do not cover the Pressure Valve with anything as an explosion may occur.
6. Do not touch the inner pot nor any heating parts, immediately after use.
Allow the unit to cool down completely first.
This appliance is intended to be used in household and similar applications such as :
- staff kitchen areas in shops, offices and other working environments;
- farm houses;
- by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments.
ADDITIONAL IMPORTANT SAFEGUARDS
IMPORTANT SAFEGUARDS
4
Note:
A. A short power-supply cord (or cord set) is provided to reduce the hazards from entanglement by a longer cord.
B. Extension cord should be used properly.
C. Extension cord usage for the rice cooker:
(1) The correct rated voltage should be used for the rice cooker.
(2) If the appliance is set on the ground, the extension cord should also be set on the ground.
(3) The cord wires and extension cord should always be arranged to prevent hazards to children.
This appliance has a polarized plug : (one blade is wider than the other).
As a safety feature, this plug will fit in a polarized outlet only one way.
If the plug does not properly fit in the outlet, turn the plug over.
If it still does not fit, contact a qualified electrician.
Please, keep this safety feature.
HOW TO USE EXTENSION CORD
SPECIFICATIONS /
제품규격
/
产品规格
CRP-JH06 Fuzzy Series
AC120V, 60Hz
1090W
GLUTIN. RICE
(백미)
HIGH
HEAT GLUTIN. RICE(백미고화력)
SUPER GRAIN(슈퍼곡물)
MIXED RICE(잡곡)
HIGH HEAT MIXED RICE(잡곡고화력)
TURBO GLUTIN. RICE
(백미쾌속)
TURBO MIXED RICE
(잡곡쾌속)
GABA RICE
(현미발아)
BROWN RICE
(현미)
HIGH HEAT BROWN RICE(현미고화력)
LOW PRESS GLUTIN.(백미저압)
NU RUNG JI(누룽지)
0.36~0.72L (2~4cups)
0.36~1.08L (2~6cups)
0.18~0.27L(1~1.5cups)
0.09~0.18L(0.5~1cups)
1.2m
98.0 kPa(1.0 kgf/cm
2
)
6.8kg
26.9cm
39.2cm
26.5cm
Model Name
(모델명)
Power Supply
(전원)
Power Consumption
(소비전력)
Power Cord Length
(전원코드길이)
Pressure
(사용압력)
Weight
(중량)
Width
(폭)
Length
(길이)
Height
(높이)
Cooking Capacity
(취사용량)
Dimension
(치수)
THICK PORRIDGE(된죽)
TIN PORRIDGE(
묽은죽)
5
www.cuckoo.co.kr
ENGLISH
SAFETY PRECAUTIONS
•
This sign is intended to remind and alert that something may cause
problems under the certain situation.
•
Please read and follow the instruction to avoid any harmful situation.
•
Indicates a prohibition
This means that the action it describes
may result in death or severe injury.
This means that the action it describes
may result in injury or property damage.
•
Indicates an instruction
Read the following product safety guide carefully to prevent any accidents and/or serious danger.
‘Warning’ and ‘Caution’ are different as follows.
Warning
Caution
Use a single socket with the rated current above 15A.
•Using several lines in one socket can cause overheating
or fire. Please check the power cord and plug frequently.
•Use an extension cord with the rated current above 15A.
Do not cover the automatic steam outlet or pressure
weight with your hand or face.
Please pay careful attention against water and
chemicals
•It can cause an electric shock or fire.
Do not use the cooker near hot things such as stove,
gas stove or direct ray of light.
•It can cause an electric shock, fire, deformation, malfunction, or
discoloration. Please check the power cord and plug frequecntly.
Do not alter, reassemble, disassemble or repair.
•It can cause fire, electricshock or injury.
•For repair, contact dealeror the service center.
•It can cause burns.
•Especially be careful to keep it out of children’s reach.
Warning Do not
Do not use a rice cooker at a place where dust is
trapped or chemical material is located.
•Do not use any combustible gas or flammable materials
nearby a product.
•It can cause explosion or fire.
Do not use damaged power cord, plug, or loose socket.
•Please check the power cord frequently for damage.
•Serious damage can cause electric shock or fire.
•If the plug is damaged, contact the dealer or a service center.
Do not clean the product with water or pour water in
the product.
Do not over unplug and plug the power cord over
and over.
•It can cause an electric shock or fire.
Do not turn the Lock/Unlock Handle to
“Unlock” while cooking.
•The hot steam or any hot content within the cooker can
cause burns.
•After you finish the cooking do not try to open the cooker
by force until the steam is completely exhausted.
Do not insert metal objects such as pins and wires
or any other external substances in the automatic
steam exhaust outlet or any other slot.
Keep the cooker out of reach of children.
•It can cause burns, electric shock or injury.
Do not use it without the inner pot.
•It can cause electric shock or malfunction.
•Do not pour rice or water without the inner pot.
•If rice or water gets in then do not turn the product over or
shake it, please contact the dealer or service center.
Be careful that both the plug and power cord are not to
be shocked by animal attack or sharp metal materials.
•Damages by impact can cause an electric shock or fire.
Please check the power cord and plug frequently.
Remove a foreign substance on the cord and plug
with a clean cloth.
•It can cause fire. Please check the power cord and plug
frequently.
Don’t spray or put any insecticides or chemicals.
•It can cause an electric shock or fire.
•If cockroaches or any insects get inside the cooker, please call
a dealer or a service center.
Don’t let foreign substances such as needle, cleaning pin,
or metal get in or block the in let/out let pipe or gape.
•It can cause an electric shock or fire.
•Do not put a cleaning pin in a gap or a hole of the
product except when dearing a steam outlet.
Do not open the LID while in heating and cooking.
•It can cause burns.
•If you need to open the lid while cooking, keep pressing
the cancel button for 2 seconds and confirm internal steam
released completely turning the pressure weight over.
Do not use pots that are not designed for the cooker.
Do not use abnormal pot and do not use without the
inner pot.
•It can cause an electric shock or fire.
Do not bend, tie, or pull the power cord by force.
•It can cause an electric shock or short circuit resulting in fire.
Please check the power cord and plug frequently.
Do not cover the automatic steam outlet or pressure
weight with a duster, a towel, or apron, etc.
•It can cause deformation or a breakdown.
•It can cause an explosion by pressure.
•It can cause an electric shock or fire.
•If it contacts water, please separate power cord and contact
dealer and service center.
•It can cause an electric shock or fire.
•Especially be careful to keep it out of reach of children.
6
SAFETY PRECAUTIONS
Clean any dust or external substances off the
temperature sensor and inner pot.
•It can cause a system malfunction or fire.
Do not use it on a rice chest or a shelf.
Do not plug or pull out the power cord with wet hands.
•It can cause an electric shock.
Do not press heavy things on the power cord.
•It can cause an electric shock or fire.
•Please check the power cord and plug frequently
Do not change, extend or connect the power cord
without the advice of a technical expert.
•It can cause an electric shock or fire.
•Do not place the power cord between furniture. It can
cause an electric shock resulting in fire.
Please check the power cord and plug frequently.
•When using on furniture be cautious of steam release
As it can cause damage, fire and and/or electric shock.
Caution Do not
Do not move the product by pulling or using the
power cord.
•Electric short might cause fire.
Please contact a dealer or service center when there
is a strange smell or smoke.
•First pull out the power cord. And contact dealer or the
service center.
Do not use over the maximum capacity.
Please call customer service if the inner pot coating peels off.
•
Inner pot coating may wear away after long use.
•
When cleaning the inner pot, do not use tough scrubber,
metallic scrubber, brush, abrasive metallic etc.
Do not place on rough top or tilted top.
•It can cause burns or breakdowns.
•Be careful to install the power cord to pass without disruption.
Do not hold the cooker by the inner pot handle.
Always turn the Lock/Unlock Handle to “Lock”
when not in use.
•
It can cause deformation by remaining pressure.
After you finish cooking, do not try to open the cooker
by force until the steam is completely exhausted.
•The hot steam or any hot content within the cooker can
cause burns.
•Cautiously open the top cover after cooking is done to
avoid dangerous steam and burns.
Be cautious when steam is being released.
If possible, only use warming function when cooking
white rice. Other foods are easily discolored.
When you pull out the power plug, don’t pull the
power cord. Please, safely pull out the power plug.
•When the steam is released don’t be surprised.
•Please keep the cooker out of reach of children.
•If you inflict impact on power cord, it can cause an electric
shock or fire.
Please clean the body and other parts after cooking.
•After cooking chicken soup, multi cook dishes, and etc.,
the smell may be absorbed.
•Clean the oven packing, top heater plate,
and inner pot every time you cook any of those.
•It can cause alteration or smell.
•Use dry kitchen cleaner or sponge to clean the inner pot,
since rough scrub or metallic ones are abrasive to the coating.
•Depending on the using methods or user's circumstances
inner pot coating might rise.
Please call the customer service for those cases.
•Please, do not pull out the clean steam vent by force.
Wipe off any excessive water on the cooker after
cooking.
•
It can cause odor and discoloration.
Wipe off water that is left behind from dew.
Please contact dealer or service center when either a
button of a product or a product itself is not working
properly.
In case of a blackout during cooking, steam from
a rice cooker will be released automatically.
Thus, the quality of rice is lower than normal.
•
Please start cooking with an indicated amount of rice and water.
•Water can overflow if the amount of water in a pot exceeds the
indicated level of water usage.
•Please start cooking in a status that steam control cap is installed
completely.
Don’t use the cooker near a magnetic field.
•It can cause burns or breakdown.
Do not drop or impact the cooker.
•It can cause a safety problem.
Please surely pull out the plug when not in use.
•It can cause electric shocks or fire.
•Use AC 120V only.
Use product on a flat surface. Do not use on a cushion.
Please avoid using it on an unstable location prone to
falling down.
•It can cause malfunction or a fire. Please check the power
cord and plug frequently.
Don’t use for various purpose for inner pot.
And do not heat up the inner pot on the gas stove.
•It can cause deformation of the inner pot.
•It can cause to spill the inner coating.
Please pull out the plug when not in use.
Please use the cooker for it’s intended purpose.
•It can cause electric shocks or fire.
•It can cause malfunction or smell.
Do not touch the metallic surface of the inner pot
and pressure weight after cooking or warming.
•It can cause burns.
•Remaining hot steam can cause burns when you tilt the
pressure weight while and right after the cooking.
•It can cause overflow or breakdown.
•Do not cook over stated capacity for cooking of chicken
soup and congee.
•It can cause problems and danger. There are portable
handles on the bottom right and left side of the cooker.
Hold the handles with both hands and move it carefully.
NAME OF EACH PART
11
www.cuckoo.co.kr
ENGLISH
Name of each part
Name of each part
Pressure Weight
Always keep it horizontal.It stabilizes
steam inside of the oven. Pressure weight
is twisted, it release steam.
Automatic Steam Exhaust
Outlet (Solenoid valve)
When finished cooking or during warming,
steam is automatically released.
Lock/Unlock Handle
(Set the handle to lock when
cooking or warming the rice)
The handle has to turn to ‘Lock’ for
operation.
Lid Clamp
Turn handle to ‘Unlock’, and then press
Clamp knob to open.
Control Panel
Standby Power Blocking Switch
When the power is not supplied
after the power cable is connected,
check if the switch is (ON).
-Enabled: (ON) -Disabled: (OFF)
(The standby power is blocked, saving the energy)
Soft Steam Cap
Accessories
Manual&Cooking
Guide
Rice Scoop
Rice Measuring Cup
Cleaning Pin
(Attached on the
bottom of the unit)
Steam Plate
Empty the water out of a
dew dish after cooking or
keep warming, Leaving the
water in the dew dish results in bad smell.
Drain Dish
DET. cover Holder
Place the inner pot Into
the body property.
Inner Pot(Oven)
Pressure
Packing
Control Plate
Packing
DET. cover Separator
Power Plug
Power Cord
Temperature Sensor
Control Plate
Packing Cover
Pressure
Control Plate
Pressure Sensor
Pot Handle
DET. cover
Lid Assy
※
In case of a blackout during cooking,
steam from a rice cooker will be
released automatically.
HOW TO CLEAN
12
-To prevent foul odor clean the lid assy after the rice cooker has cooled and the rice cooker is unplugged.
- Clean the body of rice cooker and the cover with a dry towel. Do not use benzene or thinner to clean the
rice cooker. The layer of starch, which is the residue from rice cooking, may appear on the detachable
cover or inside of rice cooker. This layer does not cause any health risk.
- Do not put materials like screws into holes of detachable cover. Check the back cover and front cover.
Detachable cover & Pressure packing
Make sure to clean the clean steam
went after/before use. Do not try to
pull out the clean steam went and
safety packing, clean it with care.
Make sure the clean steam went
and safety packing are installed
completely after/before use. If the
steam vent is detached, or not
attached completely, please
contact customer service.
Wipe the water on the outside and
bottom of the Inner Pot. A rough
sponge, a brush or an abrasive
can cause scratches on the
coating. Use a dishwashing liquid
and a soft cloth or a sponge.
Wipe the main unit with a wet cloth
that has been extracted out of al
water
Make sure to clean the steam
control went before and after
use.
Safety Packing Inner Pot
Moisture Dish of the Main Body
Inside of the Main body
Please fir a rubber packing into the cover plate completely after washing or replacing the rubber packing.
③
After fitting 6 projections to the holes,
please press the rubber packing
around the corner completely as
shown in the picture.
②
To put back the rubber packing,
please fit it to each of 6
projections and holes as shown
in the picture.
Rubber packing guide Oven cover point
①To separate the rubber
packing, please pull it out
from the cover plate as shown
in the picture.
④
Please check that the rubber packing fits into the cover
plate completely. If not, steam may be released from the
crack between the packing and the plate.
※
Keeping the contact area of the Inner Pot
with the pressure packing always clean,
increases the product's durability.
Rubber
packing
contact
surface.
1. Handle must be turned to “ ”(Lock) during Cooking.
When the lamp is turned on it means that it is ready to cook.
2. After cooking, turn the handle from “ ”(Lock) to “ ”(Unlock)
turn the handle to open.
If there is unreleased steam in the Inner pot
it might be hard to turn the handle. In this case twist the pressure
weight and let the excess steam out. Do not open by force.
•
Handle must be turned to “ ”(Unlock) when opening and closing.
•If the lamp does not turn on, it would not
operate the “COOK/TURBO” button. Make
sure the handle is located in “ ”(Lock).
※
Caution
Do not clean the inner pot with any sharp cutlery inside (fork, spoon,
chopsticks, etc.).
- The coating of the inner pot may peel off.
Detachable cover & Pressure packing
After cleaning detachable cover, put it back on the lid
Unless detachable cover is mounted, preset cooking cannot be done. (Alarm may sound while keeping warm.)
③
When you mount the Detachable Cover, hold the
handle of the Detachable Cover, attach it to the Cover,
and push the bottom end unit of the Detachable
Cover until you hear a clicking sound.
②
Wash the cover with cooking
purposeneutral detergent and
sponge frequently, and wipe
off moisture with handkerchief.
※ Please keep clean the edge
of rubber packing, then the
rice cooker last's longer.
①
Hold the handle of the Detachable Cover, press the center of the
button, and pull the handle in the direction of the arrow, and it can
be easily separated from the product to be cleaned.
※ When you separate or mount the Detachable Cover, it could
easily drop, so be sure to hold the handle.
※ If you don’t press the center of the button, the operation may
not be carried out, so be sure to press the center of the button.
I
nner pot contact surface.
D
ET.cover CLOSED
D
ET.cover OPEN
HOW TO CLEAN
13
www.cuckoo.co.kr
ENGLISH
How to clean the pressure weight nozzle.
2.
To close the lid turn the handle to
unlock, in shown in the picture on
the right.
1. Check to make sure the inner pot is
place correctly inside the main body.
3. If there is excess steam inside the
inner pot it might be difficult to lock
the handle. Twist the pressure
weight and allow the excess steam
to release. Then try to turn the
handle again.
Do not try to close the lid by force. It can cause problems.
When lid does not close perfectly
❶Separate dew dish
❷
Separate the drain
ditch cap by pushing
it down.
❸ Clean the drain ditch
cap and dew dish with
a neutral detergent.
❹ Clean the drain
ditch cap with brush
kit.
❺ Securely put in the
dew dish after
cleaning.
How to clean dew dish
•The valve hole of the pressure weight allows steam to release. Check regularly to ensure that it not blocked.
If the valve hole of the pressure weight is blocked, the hot steam and hot content within the cooker can
cause serious injury.
※Do not use the cleaning pin for any other use except to clean the valve hole of the pressure weight.
Cleaning Pin
If the valve of the pressure part is clogged, puncture it with the cleaning pin
How to
disassemble the
pressure weight
▶Under the Lock/Unlock handle is locked(located on “Lock”) turn the pressure weight counter-
clockwise while pulling it up, and pull it out.
▶Puncture the clogged valve hole with the cleaning pin and reassemble it by turning it clockwise.
▶When the pressure weight is properly assembled, it can freely be turned.
Pressure Weight
※
A
tta
c
h
e
d
o
n
th
e
b
o
tto
n
o
f th
e
u
n
it.
Alien
Substance
Soft steam cap
How to clean the soft steam cap
Do not touch the surface of the soft steam cap right after cooking. You can get burned.
❶
D
e
t
a
c
h
t
h
e
s
o
f
t
s
t
e
a
m
c
a
p
l
i
k
e
t
h
e
p
i
c
t
u
r
e
.
❷ Press the hooks in the front in direction of arrow to detach
the bottom case. Clean the parts frequently with a sponge
or a neutral detergent.
※
Before reassembling the packing with the bottom case, please
make sure to put the packing into the packing groove.
※
In order to separate the steam cap into parts, please pull bottom
part downward by pressing the extrusion parts on both sides.
❸ Before reattaching the
parts, fit the bottom case
into the groove of steam
cap perfectly. Press the
hooks in direction of
arrow to assemble the
parts together.
❹ After attaching the
soft steam cap on
the lid as shown in
above picture, press
the cap firmly to
assemble the cap
into the product.
packing
groove of steam cap
packing groove
neutral detergent
FUNCTION OPERATING PART/
HOW TO SET OR CANCEL VOICE GUIDE FUNCTION
14
FUNCTION OPERATING PART
<Screen on standby>
WARM/REHEAT
Button
Used to warm or reheat.
(Refer to page 25)
PRESET/AUTO
CLEAN Button
Used to preset Preferred cooking time
(Refer to page 23~24)
When you use automatic steam
cleaning function
Energy Eye
Refer to page 28
:SLIDE TOUCH
Right selection button
Left selection button
SLIDE Touch
This function is used to select menu or change the time.
Used when changing the function selected by setting button.
MODE Button
This function is used to customize
Individual (Refer to page 18)
Cooking preference,
time-setting (Refer to page 15),
voice volume setting (Refer to page 14),
keep warm temperature setting
(Refer to page 25), and power saving
mode (Refer to page 28).
‘Nurungji(crispy rice)’mode setting
(Refer to page 19), Energy-eye function
(Refer to page 28).
COOK/TURBO
Button
Used to start cooking
(Refer to page 17)
PRESSURE CHECK
Button
This function is used to pressure
checking
(Refer to page 22)
CANCEL Button
This function is used to cancel
a selection or release remaining
Steam in the inner pot.(Refer to page 30)
When using Power saving function
(Refer to page 28)
Display
SET Button
This function is used to select
a function or to button-lock
function. (Refer to page 29)
HIGH HEAT Button
This function is used for to activate
the High heat cooking mode of the
cooking functions such as GLUTIN.
RICE, MIXED RICE, BROWN
RICE(Refer to page 17)
DIRECT TOUCH
This function is used when cooking
GLUTIN. RICE/TURBO GLUTIN. RICE,
MIXED RICE/TURBO MIXED RICE,
, PORRIDGE
※
W
h
e
n
y
o
u
a
n
i
m
a
g
e
l
i
k
e
o
n
e
i
n
t
h
e
r
i
g
h
t
s
i
d
e
o
n
y
o
u
r
d
i
s
p
l
a
y
,
i
t
m
e
a
n
s
t
h
e
r
i
c
e
c
o
o
k
e
r
i
s
i
n
‘
W
a
i
t
i
n
g
’
m
o
d
e
.
※
P
r
e
s
s
‘
C
a
n
c
e
l
’
b
u
t
t
o
n
t
o
e
n
t
e
r
t
h
e
‘
W
a
i
t
i
n
g
’
m
o
d
e
.
※
P
r
e
s
s
t
h
e
b
u
t
t
o
n
u
n
t
i
l
y
o
u
h
e
a
r
t
h
e
b
u
z
z
e
r
s
o
u
n
d
.
T
h
e
i
m
a
g
e
o
f
t
h
e
p
l
a
t
e
m
a
y
d
i
f
f
e
r
e
n
t
.
To enter this function, press ‘MODE’ button 3 times. ‘MODE’ button needs to be pressed for over 0.3 second at the first time.
Voice guide volume control (The function which can control volume and cancel)
▶
‘SET’ button blinks and ‘MODE’, ‘CANCEL’
buttons turn ON.
▶ Keep the button pressed, and the button will turn to Continuous.
▶ Set to desired voice volume, and press ‘SET’ button.
▶ If it is over 7sec without ‘SET’ button, setting time will be cancelde with
voice, “Function setting has been canceled with overtime.”
▶
‘MENU/SELECTION’ button blinks and ‘MODE’, ‘SET’ and
‘CANCEL’buttons turn ON.
“3” sign is displayed when entered volume
control mode by pressing ‘MODE’ button 3 times.
If set value became “OFF” by pressing ‘SELECTION’
button,“VOICE ” blink and voice guide function is off.
Press ‘SELECTION’ button to change the
volume from “1” to “5”.
HOW TO SET CURRENT TIME/
NIGHT VOICE VOLUME REDUCTION
15
www.cuckoo.co.kr
ENGLISH
Press ‘MODE’ button 2 times.
▶ ‘MODE’ button needs to be pressed for over 0.3 second at the first time.
▶ A voice comes up saying “Setting mode for current time. Touch and
slide to set current time then press SET button.”
▶ ‘MODE’, ‘SET’ and ‘CANCEL’ buttons turn ON.
1
ex)8:25am now
How to set current time
When finishing to set time you
▶ ‘SET’ button blinks and ‘MODE’, ‘CANCEL’buttons turn ON.
▶ If it is over 7sec without ‘SET’ button, setting time will be
canceledwith “Function setting has been canceled with
overtime.”, it is canceled due to overtime.
3
Set o'clock and minute as pressing ‘SELECTION’ button.
2
▶
1 min up “ ” button
1 min down “ ” button
▶ 10 min up or down “ ”, “ ” keep pressing.
▶ Careful of setting am,pm.
▶ In case of 12:00 it is 12:00 pm
<Standby mode>
Night Voice Volume Reduction
1. Press ‘MODE’ button 12 times in standby status, and you will enter Night Voice Volume Reduction mode.
When pressing ‘MODE’ button initially, press the button for 0.3 second or longer to enter Night Voice Volume
Reduction mode.
2. When you enter Night Voice Volume Reduction mode, a voice comes up saying “Setting mode for night
time volume. Touch and slide to set Night time volume then press ‘SET’ button”.
3. Press ‘SELECTION’ button, and as process progress bar change, voice volume will change. Select
desired voice volume, and press 'SET' button.
4. Once process progress bar reach full condition through adjustment of ‘SELECTION’ button, a voice
will come saying “Night time volume has been canceled.” Inactivate the function by pressing 'SET' button.
5. If 'Set' button is pressed or no button is pressed for 7 seconds after you enter Night Voice Volume
Reduction mode, the function will be inactivated along with voice “Function setting has been cancelled with
overtime.”, and the system will be back to standby mode.
Example) 60% of voice volume
Night voice volumes by the setting of process progress
Set the function of night voice volume reduction, the function to reduce the volume of voice
during night time (10:00PM-05:59AM) on need-to-do basis. This function works only during night time.
▶
Night Voice Volume Reduction
Zero volume
20% of voice volume
40% of voice volume
60% of voice volume
80% of voice volume
100% of voice volume
BEFORE COOKING RICE
16
※ After cooking in white rice turbo mode or cooking of small serving, discard water.
MIXED RICE
GLUTIN. RICE
Used to cook sticky and nutritious rice.
LOW PRESS GLUTIN.
It is used for soft low-pressure rice without sticking.
How to use the cooking menu
GABA RICE
Used to cook germinated brown rice.
Used to cook a variation of mixed or brown rice.
Nu Rung Ji
Used to cook scorched rice when cooking is done.
SUPER GRAIN
Used to cook a variety of super grain rice.
PORRIDGE
For cooking porridge.
LOW PRESS, HIGH PRESS
AUTO CLEAN
(Steam Cleaning)
Used to cook low pressure and high pressure.
This menu is used to eliminate small soaked
after cooking or warming.
TURBO
GLUTIN. RICE
∙
Pressing ‘COOK/TURBO’ button twice will switch to quick cooking and shorten the cooking time.
(It takes about 14 minutes when you cook the Glutinous rice for 2 persons.)
∙
Use this turbo cooking function only for cooking rice for less than 4 persons. (The condition of the rice will not be good for more than 2 persons.)
∙
If you soak the rice in water for about 20minutes before cooking the rice and then cook the rice in turbo cooking course, the rice will taste good.
HIGH HEAT
(GLUTIN.RICE/MI
XED RICE/GABA
RICE)
Use when cooking more sticky and soothing Cooked Rice.
(Melanozing effect could be increased.)
TURBO
MIXED. RICE
∙ If selected turbo mixed rice, total cooking time will be reduced.
(It takes about 26minutes for cooking mixed rice for 2 persons.)
∙ Turbo mixed rice cooking lessens the quality of food, so only use for less than 4 people.
BABY FOOD
Used to cook various baby food by setting a time manually.
BROWN RICE
Used to cook variation of brown rice.
Use a dry cloth to clean inner pot.
▶
Use a soft scrubber to wash the inner pot.
▶ Do not use rough or metallic scrubber. Otherwise, coating will pilled off.
▶
Do not put anything that are metallic and sharp into the inner pot
while cleaning.(Fork, spoon, chopsticks, knife, and etc.)
1
Use measuring cup to measure desirable cooking amount.
▶ Make the rice flat to the top of measuring cup and it is serving for 1
person. (ex: for 1 servings→1 cups, for 3 servings→ 3 cups)
2
Use another container to wash the rice.
3
Plug the power cord and turn the handle to “ ”.
▶
The lamp turning on means closed perfectly.
6
Please plug the power cord before inserting inner pot in the rice cooker.
▶
Wipe off or remove any substances on the temperature senor or bottom of the inner pot.
▶
Please place the inner pot correctly into the rice cooker.
5
Adjust water level.
▶
Place inner pot on the flat surface to adjust water level.
▶
The marked lines in the inner pot are water level.
❶
If you want to cook old or soft rice, pour more water than measured scale.
❷
Overcooked rice: pour less water than measured scale.
❸ When rice is undercooked or firm/hard: It is caused by differences in rice varieties or
water content (old rice). In this case, please add 1 ~ 10% of more water.
※
This model does not support SOFT GLUTIN.
※
The maximum capacity of each menu, refer to page 17.
4
Rice for 8 persons (8 cups)
❶
❷
❸
HOW TO COOK
17
www.cuckoo.co.kr
ENGLISH
The cooked rice can be light yellow at the bottom of the oven, because this product is designed to improve pleasant flavor and
taste. Especially, melanoizing is more serious at the“ Preset cooking”than jus“t Cooking”. It does not mean malfunction.
※ When mixing other rice with Glutinous, Melanoizing phenomenon could increase more than “Glutinous cook”setting.
Melanoizing phenomenon
Choose menu with ‘SELECTION’button.
Start cooking by pressing ‘COOK/TURBO’ button.
·Please mount detachable cover.
·Please keep “Pressure weight” horizontal.
·Each time ‘MENU/SELECTION’ button is pressed, the selection
switchs in the sequential order, LOW PRESS GLUTIN. → SUPER GRAIN → GABA RICE →
NU RUNG JI → GLUTIN.RICE → HIGH HEAT GLUTIN.RICE → MIXED RICE → HIGH
HEAT MIXED RICE → BROWN RICE → HIGH HEAT BROWN RICE → PORRIDGE →
AUTO CLEAN → BABY FOOD → LOW PRESS STEAM → HIGH PRESS STEAM.
·If the button is pressed, repeatedly, the menu switchescontinuously in sequential order.
·The one of following cooking menu modes: GLUTIN. RICE, MIXED RICE, BROWN RICE,
PORRIDGE will be immediately proceededto start cooking by pressing the ‘DIRECT
TOUCH’ button of eachcooking menu mode.
·Pressing the ‘HIGH HEAT’ button within 5 seconds after proceedingthe one of following
cooking menu modes: GLUTIN. RICE, MIXEDRICE, BROWN RICE will initiate the high
temperaturecooking of each cooking menu mode.
·In the cases of GLUTIN. RICE, HIGH HEAT GLUTIN. RICE, MIXED RICE, HIGH HEAT
MIXED RICE, LOW PRESS GLUTIN, BROWN RICE,HIGH HEAT BROWN RICE, GABA
RICE, SUPER GRAIN the menu remains memorized once each cooking is completed, so for
continuous use of the same menu, no selection of menu is required.
·You must turn lid handle to lock before cooking.
Then press the ‘COOK/TURBO’ button, and
sound “GLUTIONUS RICE, Cuckoo starts cooking
at a pressure of 2 atmosphere.”
·Unless lid handle is not turned to close, you get
alarm with “ ” , and sound “Close the lid then
turn the handle to the lock position.”
·The actual cooking time may vary depending on
the cooking capacity, water temperature, and
cooking conditions.
1 2
The end of cooking
·When cooking is completed, warming will start with
the voice “Glutinous rice has been completed.”.
·If you want to stop warming, Push ‘CANCEL’ button for more
than 0.3 seconds.
·When cooking ends, stir rice equally and immediately. If you
don't stir rice at once and keep it stagnant, rice will go bad
and smell bad.
·If the lid handle is not working well, take out the steam
completely out of inner pot by turning over pressure weight.
·While cooking, do not press cancel button.
4
ex) In case of selecting LOW PRESS GLUTIN.
▶
You can hear a voice, LOW PRESS GLUTIN.
ex) In case of cooking GLUTIN.RICE.
Steaming.
·The cooktime remaining on the display is shown
from cooking thoroughly.
·The cook time is different according to the menu.
·Be careful not to burn yourself from the automatic
steam outlet.
3
ex) In case of 10minutes left.
Cookin
g
t
ime by Menu
Me
n
u
Division
GL
UTIN.
RI
CE
TU
RBO
G
LUT
I
N
.
R
ICE
HIGH HEAT
GL
U
TIN.
RICE
MIXED
RI
CE
TURB
O
MIXE
D
RICE
HIGH
HEAT
MI
XED RICE
L
O
W PRE
S
SURE
G
L
UTIN.
Nu
Ru
n
g
Ji
BROWN
RICE
H
I
GH
H
EAT
BR
OWN
R
I
C
E
SUPER
GRAIN
THIICK
PORRIDGE
THIN
PORRIDGE
LO
W PRESS
STEAM
HIG
H PRESS
STEAM
BABY
FO
O
D
PRESSURE
CHECK
A
UT
O CL
EA
N
(S
te
a
m Cle
a
n
in
g
)
CAP
A
C
I
TY
2
~
6
P
ERS
ONS
2
~
4
P
E
RSONS
2
~
6
P
E
RSONS
2
~
4
P
ERS
ONS
2~
4
PE
RSONS
2
~
4
P
ERS
ONS
2
~
4
P
E
RS
ONS
2~
4
P
E
RSONS
2
~
4
P
ERS
ONS
2~4
PERSONS
2~4
PERSONS
1~1.5
CUPS
0.5~
1
CUPS
See de
taile
d gu
ide to
cooking
by the menus.
Pour
water
up to
the line 2 for
GLUTIN.
RICE
Pour
water
up to
the line 2 for
GLUTIN.
RICE
COOKING
T
IME
Approx.
25~31min
Approx.
14~19min
Approx.
26~32min
Approx.
40~44min
Approx.
31~35min
Approx.
43~47min
Approx.
38~45min
Approx.
39~43min
Approx.
50~54min
Approx.
51~56min
Approx.
42~46min
Approx.
83~87min
Approx.
84~96min
Approx.
17
min
Approx.
22min
PRS
S
URE
DIS
P
LAY
2.0
atm
2.0
atm
2.0
atm
2.0
atm
2.0
atm
2.0
atm
1.2
atm 2.0
atm 2.0
atm
2.0
atm
2.0
atm
2.0
atm
2.0
atm
1.4
atm
2.0
atm
2.0
atm
Real-time
pressure
2.0
atm
MY MODE (CUCKOO Customized Taste Function)
18
▶ CUCKOO’s patented technology based on variable circuit design. User can select the degree of “softness” and
“glutinosity & tastiness” to meet a user’s desire.
What is “MY MODE”?
▶Longer “SOFT” Time : rice becomes soft and glutinous. (selectable in 4 steps)
▶Longer “SWEET” Time : rice becomes tastier(selectable in 4 steps) [melanoizing will occur]
▶Both functions above can be selected simultaneously or separatetly
How to Use “MY MODE”
To enter Customized Rice Taste Setting Mode,
select desire menuand press ‘MODE’ button
once for 0.3 second or longer.
❶
“MENU”setting screen
To enter “Customized Rice Taste Setting Mode”, select the menu in which Customized Rice Taste is supported such as GLUTIN. RICE, HIGH HEAT GLUTIN. RICE, MIXED
RICE, HIGH HEAT MIXED RICE, BROWN RICE, HIGH HEAT BROWN RICE, GABA RICE, Nu Rung Ji, SUPER GRAIN and press the ‘MODE’ button for 0.3 second or longer.
How to Use “MY MODE”
❷
“MY MODE” setting screen
Select desired heating extension time by
pressing the button, and press ‘SET’
button.
Set up desired customized rice taste.
And press ‘‘SET’ button’.
(If you press ‘CANCEL’ or do not press
a button within 7 seconds, the function
will deactivate and return to the
standby mode.)
Select desired swelling time
by pressing the button.
❸-1
Soft time control mode
❸-2
Sweet time control mode
❹Setting the completed screen after
❶ If you press the ‘MODE’ button 6times, customized cooking function is setup.
How to use Cuckoo Customized cooking function
1. ‘CUCKOO customized cooking function’ applies to GLUTIN. RICE, HIGH HEAT GLUTIN. RICE, TURBO GLUTIN. RICE, MIXED RICE, HIGH HEAT MIXED
RICE, TURBO MIXED RICE, BROWN RICE, HIGH HEAT BROWN RICE, GABA RICE,LOW PRESS GLUTIN., SUPER GRAIN
2. Set up the step of customized cooking function to taste. The scorch can occur when cooking in high level mode.
3. Cook is subject to be set differently depending on the percentage of water content and the condition of rice.
- High step : for cooking cereals, old rice and soft-boiled rice.
- Low step : for cooking the year’s crop of rice
While cooking you can control the heating temperature (both high an low) depending on, your prefenence.
Initialization is set up “ ” get step by step as the case may be.
Cuckoo customized cooking function
❷ “MY MODE” setting screen
Push the ‘SELECTION’ button, then the
screen will be changed as above picture.
Push the ‘SELECTION’ button, then the screen
will be changed as above picture.
❹-1High level mode
If you press the ‘SET’ button to complete your
customized cooking. (If you press ‘CANCEL’
or do not press a button within 7 seconds, the
function will deactivate and return to the
standby mode.)
❺Setting completed
screen after
❹-2 Low level mode
❸“MENU”setting screen
Make the menu changed by
pressing ‘SELECTION’ button.
HOW TO USE GABA RICE (BROWN RICE) /
HOW TO MAKE MORE CRISPY NURUNGJI
19
www.cuckoo.co.kr
ENGLISH
Using “GABA” Menu
In order to promote germination, soak brown rice for 16 hours in water
Method of Pre-germination
▶
Put washed brown rice in an appropriate container, pour sufficient amount of water to soak the rice.
▶
Pre-germination shall not exceed 16 hours. Make sure to rinse the rice clean with flowing water before using
“GABA” menu. Be careful not to rinse too much or else the embyros that are required to germinate may wear off.
▶
Unique smell may be generated according to the soaking time of pre-germination
▶
When pre-germination has been completed, wash the rice and insert the inner pot. Pour appropriate amount of
water and use “GABA” menu.
▶
During summer or hot temperature environment, an odor may be generated. Reduce germination time and wash
clean when cooking.
1
Turn the Cover Coupling Handle toward “ ” (Lock),
and press the Select button to select GABA RICE.
▶
When GABA RICE is selected, 3H will be displayed on the display panel.
2
Precautions for GABA RICE
❶
If smaller germ is preferred, omit pre-germination process. Select “GABA RICE” menu, time, and start cooking
(nutrients ingredients do not vary significantly by the size of germ).
❷
GABA RICE cooking feeds up to 4 people.
❸
City water can be used for germination. However, filtered or drinkable water is recommended.
Germination may not be properly performed in hot or boiled water even after cooking.
❹
Germination rate and germ growth may differ by the type of brown rice, condition, or period of storing.
- The brown rice should be within 1 year from harvest, and not long since pounded.
❺
In GABA mode, preset on 3H may not be possible. If you want to preset the GABA, set up BROWN RICE menu .
❻
The taste of rice could be different depending on a kind of brown rice. Use customized taste function or control the
amount of water for your taste.
❼
Depending on the user’s environment or the condition of the rice, the sprout may not be visible.
How to make More Crispy Nurungji
When cooking with “Nurungji” option, you can scorch the cooked rice on the bottom in different levels according to
your preference.
▶
How to set More Crispy Nurungji function (This mode is selected ‘OFF’ when the product is delivered from the factory)
1. In the Standby mode, press the ‘MODE’ button 8times to enter More Crispy Nurungji setting mode.
(‘MODE’ button needs to be pressed for over 0.3 second at the first time.)
2. When you press the ‘SELECTION’ button, More Crispy Nurungji setting function will be selected or canceled.
3. After doing your desired setting, if you press the SET button, the setting will be saved.
4. If you press the CANCEL button or 7 seconds have passed without any button’s being pressed, the function will be
canceled.
Press the COOK/TURBO button.
▶
If you press the COOK/TURBO button or the SET button and press the
COOK/TURBO button, Gaba Rice mode will be activated for the set time,
and it will start cooking immediately after completing germination.
▶
The ‘COOK’ icon will be displayed along with the remaining time.
3
B
rown rice has richer nutrients than polished rice. However, brown rice is rather tough and hard to be digested.
By germination, the enzymes in the brown rice are activated, generating nutrients, and are easier to digest.
What is Germinated Brown rice?
HOW TO COOK SUPER GRAINS
20
Press the SET button, and set the time with the Select button.
▶
Every time you press the right Select button or the left Select button, the supergrain soaking time is
repeatedly selected to be 0H (0 hour) or 3H (3 hours).
▶
The supergrain soaking time can be selected to be 0 hour or 3 hours.
2
Press the Cook/Turbo button.
▶
When you press the Cook/Turbo button or the SET button and press the
Cook/Turbo button, soaking begins for the set time. When the soaking is
completed, cooking immediately begins.
▶
During soaking, ‘Cook’ is displayed, along with the remaining time.
3
Turn the Cover Coupling Handle toward “ ” (Lock),
and press the Select button to select Supergrain.
▶
When the Supergrain menu is selected, 0H is displayed on the Display.
1
What are supergrains?
Precautions for Cooking Supergrains
❶
When cooking supergrains, use the Mixed Grains Water Level. You can cook up to four servings.
❷
There may be differences in melanozing or rice condition depending on the kind of supergrain.
Adjust the water volume to suit your taste, or use the Customized Taste function.
❸
In case of the Supergrain menu, reservation is not available.
❹
When you cook hard grains, select 3H (3 hours) for soaking before cooking.
❺
If you want softer texture, cook by the following method.
▶
When you cook ‘chick peas,’ soak chick peas for four to six hours at room temperature before cooking.
▶When you cook ‘oats,’ soak oats for 30 minutes to one hour at room temperature before cooking.
❻
When cooking is finished and the product has warmed, mix the cooked rice well.
Precautions for Cooking Kamut
❶
Separately wash kamut and rice. Put kamut in the Inner Pot (in order to soften kamut’s texture), and then put rice in
the Inner Pot. Then, adjust the water volume with the Mixed Grains Water Level.
❷
Select the Supergrain Menu, and set the soaking time to be 3H (3 hours) with the Select button, and then press the
Cook/Turbo button.
❸
When cooking is finished and the product has warmed, mix the cooked rice well.
Supergrains have a better nutritional balance than that of rice, and contain an abundance of various vitamins, minerals,
a
ntioxidants, and dietary fiber. It is a good alternative to rice, and is an excellent nutritional source for supplementing nutrition.
Characteristics of Supergrains
❶
Kamut (for antioxidant effects): Kamut contains selenium, which removes active oxygen from your body.
❷
Oats (for preventing constipation): Oats possess rich unsaturated fatty acids and fiber.
❸
Chick peas (for weight loss): Chick peas contain arginine, which helps burn fat and expand blood vessels.
❹
Green lentils (for recovery from fatigue): Green lentils contain rich protein, Vitamin B, and iron.
❺
Quinoa (for preventing adult diseases): Quinoa possesses unsaturated fatty acids, which reduce cholesterol.
How to Use Supergrain Menu
HOW TO COOK LOW/HIGH PRESS STEAM
21
www.cuckoo.co.kr
ENGLISH
HOW TO COOK LOW/HIGH PRESS STEAM
Coupling Handle toward “ ” (Lock), and press the Select
button to select low-pressure steaming or high-pressure
steaming.
▶
The SET button blinks, and the Cancel button and the Cook/Turbo
button are turned on.
▶ When the Low-Pressure Steaming menu or the High-Pressure
Steaming menu is selected, the time is displayed on the Display.
1
Press the Cook/Turbo button.
▶
The Cook/Turbo button blinks, and the Setup button, the SET button,
the Keep Warm/Reheat button, the Reserve/Auto Clean button, the
Pressure Check button, and the Cancel button are all turned on. Press
the Cook/Turbo button, and the low-pressure steaming or the high-
pressure steaming begins.
When low-pressure steaming or the high-pressure steaming begins,
“Cook” is displayed, along with the remaining time.
3
Press the right Select button, and
the time for low-pressure
steaming/high-pressure steaming
will be increased by five minutes.
(After 90 minutes, it decreases
by 10 minutes.)
▶
If you keep pressing it, the time
turns into Nonstop.
2.
Press the left Select button,
and the time for low-pressure
steaming/high-pressure
steaming will be decreased
by five minute
(After 90 minutes, it decreases
by 10 minutes.)
▶If you keep pressing it, the
time turns into Nonstop.
3.
The time for low-
pressure
steaming/high-
pressure steaming
is adjustable from
10 to 120 minutes.
Select the desired time, and
press the SET button. Then,
the Voice Guide will say,
“Press the Cook button or
the Reserve button.”
4.
4
How to Reserve Low-Pressure Steaming or High-Pressure Steaming
2
Press the SET button, and set the cooking time with the Select button.
▶
The Reserve button, the Cancel button, and the Cook/Turbo button are
turned on.
The Voice Guide will say, “Set the cooking time with the slide touch,
and press the Cook button.”
▶ Press the SET button, and the Voice Guide will say, “Press the Cook
button or the Reserve button.”
1.
5.
Press the Select button, select the time for
low-pressure steaming or the high-
pressure steaming, and press the SET
button. Then, press the Cook/Turbo button.
3.
Press the Select button,
adjust the cooking finish
time, and press the SET
button.
2.
Turn the Cover
Coupling Handle
toward “ ”
(Lock), and press
the Reserve/Auto
Clean button.
1.
Check if the
current time is
correct.
4.
Press the Select button, select
the low-pressure steaming or
the high-pressure steaming,
and press the SET button.
HOW TO USE PRESSURE CHECK
22
How to Use Pressure Check
Add water to the Inner Pot up to Glutin Water Level 2, put the Cover on,
and turn the Cover Coupling Handle toward “ ” (Lock).
▶
The Voice Guide will say, “This is the Pressure Check function. Add water up to
Glutin Water Level 2, and press the Cook button or the Pressure Check button.”
▶
The Cook/Turbo button and the Pressure Check button blink, and
the Cancel button is turned on.
2
Press the Pressure Check button in the Standby mode.
1
▶
The Voice Guide will say, “The pressure is normal. Perform
pressure check on a regular basis to ensure a great taste every time.”
When the pressure check result is good, “Good” is
successively displayed.
4
▶
When Pass or Fail is displayed, this indication will automatically be turned off in one minute.
▶ Press the Cancel button, and it will be immediately canceled.
▶ Turn the power ON, and it will be canceled.
How to Turn Off Pass or Fail Display
6
▶
When the pressure check result is poor, “EP1 ~ EP6” blinks.
5
▶
The Voice Guide will say, “CUCKOO begins pressure check.”
▶ If you press the Cook/Turbo button without turning the Cover Coupling Handle
toward “ ” (Lock), pressure check is not performed.
▶ The remaining time and the actual pressure are displayed at regular intervals.
Press the Pressure Check button or the Cook/Turbo button,
and pressure check begins.
3
Precautions for Using Pressure Check
❶
Adjust water level to Glutin Water Level 2.
❷
Use water at a temperature of 10-30℃.
❸
Perform the pressure check when the product has cooled down.
No accurate pressure check can be performed when the product is heated (right after cooking is finished, right after
keeping warm is finished).
❹
The indicated pressure may be different from the actual pressure.
This is a function to check if pressure has leaked or the steam discharge apparatus is defective by checking the
pressure in the product.
<Standby mode>
The Voice Guide will say, “Check the packing, perform the pressure check again, and if there is any problem, contact our Customer Service
Center. ” It appears when the packing is aged or pressure is leaked because of foreign substances on the packing. Check the packing and
perform the pressure check again. If the packing is not defective, contact our Customer Service Center.
The Voice Guide will say, “Check the packing, perform the pressure check again, and if there is any problem, contact our Customer Service Center.
” It appears when the packing is aged or pressure is leaked because of foreign substances on the packing.
Check the packing and perform the pressure check again. If the packing is not defective, contact our Customer Service Center.
The Voice Guide will say, “Pressure check was not properly done. Please do it again in the right order.”
It appears when you perform the pressure check without the Cover on.
Put the Cover on, turn the Cover Coupling Handle toward “ ” (Lock), and perform the pressure check again.
The Voice Guide will say, “There is a problem with steam discharge. Please contact our Customer Service Center.”
It appears when there is a problem with the Weight. Please contact our Customer Service Center.
The Voice Guide will say, “Pressure check was not properly done. Please do it again in the right order.”
It appears when you perform the pressure check with the product heated (right after cooking is finished, right after keeping warm is finished).
Please perform the pressure check again when the product has cooled down.
▶
▶
▶
▶
HOW TO USE PRESET / PRESET REHEATING FUNCTION
23
www.cuckoo.co.kr
ENGLISH
❶
Make sure that the current time is correct.
▶
Refer to page 15 for how to set the current time.
❷
Turn the lid handle to the lock position and a lock icon will be displayed on
the screen. Then press the ‘PRESET/AUTO CLEAN’ button.
▶ The preset time is set to 06:30 AM when the product is delivered from the factory.
If you want to preset reheating to this time, it is not required for you to set time.
❸
Press the SET button, and press the SELECTION button to set the preset
time.
▶ The preset time is increased by 10 minutes each time you press the “ ” Button
▶ The preset time is increased by 10 minutes each time you press the “ ” Button
❹
Press the SELECTION button to select the desired menu.
❺
Press the COOK/TURBO button.
▶ Once cook is completed with preset time, preset time is stored in the memory.
▶ Don't need to set up time again.
※Please be careful not to change from AM to PM.
※When the current time is not correct, set the current time correctly.
※If you press the PRESET/AUTO CLEAN button without turning the Lock/Unlock handle toward 'Lock,' the presetting will not be conducted
※If you want to preset the GABA, set up BROWN RICE menu.
※When it is in KEEP WARM mode, press CANCEL to exit KEEP WARM mode, then select your desired preset time.
※If a small amount of rice is cooked, it could be finished earlier than time you programmed it.
How to preset timer for cooking
For example, if it is nine o’clock in the evening and you want to have warm breakfast at seven forty the next morning.
How to use Preset Reheating function
▶
Use this function when the cooked rice is not kept warm in the rice cooker but you still want to enjoy a hot meal at your convenience.
▶
It takes three hours before it's fully warmed up: Please use the function at least three hours before you enjoy your meal
For example, if it is nine o’clock in the evening and you want to have warm breakfast at seven forty the next morning:
❶
Make sure that the current time is correct.
▶
Refer to page 15 for how to set the current time.
❷
Turn the lid handle to the lock position and a lock icon will be displayed on the screen.
Then press the ‘PRESET/AUTO CLEAN’ button.
▶
If you press the PRESET/AUTO CLEAN button without turning the Lock/Unlock handle toward
'Lock,' the
presetting will not be conducted.
❸
Press the ‘WARM/REHEAT’ button and Preset Reheating mode begins.
❹
PRESS the SELECTION button to preset the completion hour of reheating
▶ The preset time is increased by 10 minutes each time you press the “ ” button.
▶ The preset time is decreased by 10 minutes each time you pressthe “ ” button.
❺
Press the ‘SET’ button.
❻
Press the ‘WARM/REHEAT’ button.
▶ Reheating is completed as scheduled.
▶The cooker memorizes the hour that you have preset: You may press the ‘WARM/REHEAT’ button
directly without having to preset the time again from the beginning.
※Please be careful not to change from AM to PM.
※ When the current time is not correct, set the current time correctly.
HOW TO USE PRESET / PRESET REHEATING FUNCTION
24
PRESET COOKTIME
Menu
Class
GLUTI
N.
RI
CE
HI
GH HEA
T
GLUTI
N.
RI
CE
MIXE
D
RICE
HI
GH HE
AT
MIX
ED RICE
LOW PRESS
GLUTIN.
NU RUNG JI
BROWN
RICE
HIGH HEAT
BROWN
RICE
Porridge
LOW/HIGH
PRESS
STEAM
BABY
FOOD
AUTO CLEAN
(Steam Cleaning)
PRE
S
ET
COOK
TIM
E
(36m
in+
My m
ode
time )
~13hours
(42m
in+
My m
ode
time )
~13hours
(51min+
My mode
time )
~13hours
(53min+
M
y m
ode
time )
~13hours
50min
~13hours
(49min+
My mode
time )
~13hours
(59min+
My mode
time )
~13hours
(61min+
My mode
time )
~13hours
110min
~13hours
From
(1minutes
+My mode)
to 13hours
From
(1minutes
+My mode)
To 13hours
27min
~13hours
Precautions for PRESET / PRESET REHEATING Cooking
Precautions for Preset Cooking
▶
If the rice is old and dry, the result may not be good.
▶
If the rice is not well cooked, add more water by about half-scale.
▶
If the preset time is longer, melanization could be increased.
▶
Washed rice has a lot of settled starch, and crust can be made in case of preset cooking.
If you wash the washed rice in running water before cooking or make the quantity of rice small, the crust
will be less.
1
Changing preset time.
▶
Press ‘CANCEL’ button for more than 0.3 seconds and restart it to change the preset time.
3
If the preset time is shorter than available range.
▶
If the preset time is shorter than the available range, cooking/reheating will begin immediately.
4
In case the preset time is over 13 hours.
▶
“ ” will be displayed and the preset time will be changed to 13 hours automatically. If cooking is preset
to AM07:00 of the following day at PM5:00 of the day, where preset time is 14 hours, “ ” will be
displayed, and preset time automatically changes to AM06:00. (Maximum preset time is 13 hours)
※
If the preset time is over 13 hours, it can cause bad smell and discoloration.
The limited preset time is set up to be under 13 hours because the rice spoils easily during the summer time.
※
When you want to finish presetting at 12:00 p.m., preset the time to be 12:00 p.m.
※
Use this function when you want to finish cooking between 1 hour to 13 hours after the current time.
※
During the preset cooking, if you want to check the current time, press the SET/MODE button.
Then, the current time will appear for about two seconds.
5
Precautions for preset reheating
▶
When leaving cooked rice at ambient temperature for a prolonged period of time, moisture is evaporated from
cooked rice. In such a case, the reheating preset may cause dehumidifying or melanosing (slightly burnt) of
cooked rice.
▶
If there is an excessive amount of cooked rice in the pot, it may not sufficiently be reheated.
It is recommended to set reheating for no more than 3 people. (approx. half of the inner pot)
▶
Reheating of cold- or frozen-stored cooked rice may cause insufficient heating, dehumidifying or melanosing
(slightly burnt) after completion of reheating.
▶
Put cold-stored cooked rice into the inner pot, beat rice with a scoop, and then reheat rice.
▶
Reheating of frozen-stored cooked rice shall be performed only after thawing the rice.
2
TO KEEP COOKED RICE WARM AND TASTY
25
www.cuckoo.co.kr
ENGLISH
<Finishing reheat>
Having a Meal
▶If you want to have warm rice, press the ‘WARM/REHEAT’ button. Then ‘Reheat’ function will be started and you
can eat fresh rice in 9 minutes.
▶To use reheating in standby status after power is applied, turn lid combining hand grip to Locked location,
press ‘WARM/REHEAT’ button, and the cooker will convert to Heat Preservation mode.
Here press ‘WARM/REHEAT’ button once more.
▶The frequent use of the “Reheat” function may cause the cooked rice to be discolored or dried. Use it once or twice per day.
▶If a separate heating appliance or gas burner is used to cook rice, put the cooked rice into the cooker and press the ‘ WARM/REHEAT’ button to keep the rice warm. At
this time, “ ” is shown on the display. (Like this, transferring hot rice to a cold cooker may cause the rice to be discolored or develop an odor)
▶After 24 hours of heat preservation, the lamp of heat preservation time lapse blinks, indicating that long time has passed in heat preservation condition.
▶In case the lid combining hand grip is in open status during heat preservation, the cooker does not go for reheating. For reheating, lock the lid combining hand grip to
(Locked) position, and then press ‘ WARM/REHEAT’ button.
▶If the lid combining hand grip is turned to open status during reheating, function display will show “ ”. At this time, reheating will be cancelled, and heat
preservation will proceed.
<Keep warming> <Reheating>
‘ ’ indicates the time elapsed as
warming time.
When the reheat finishes with the
beep sound, keep warming
function will be operated and show
the time elapsed.
The lamp blinks and “ ” indicator
will show the reheat remaining
time displayed in minutes with the
mark going around clockwise.
❷-1
Press ‘SELECTION’ button to
change the temperature as
❷-2
Press ‘SELECTION’ button to
change the temperature as
➡
Controlling Method of Warming Temperature
If the temperature in the rice cooker is not set properly, an odor or the color of the rice may change even
though it is cleaned frequently and boiled up. Temperature needs to be set.
❸
Select the menu you want, then the press
the ‘MODE’ button and set-up time will be
automatically entered with a buzzer. (If
you press the ‘CANCEL’ button or do not
press a button within 7 seconds, the
function will be cancelled and returned to
standby mode.)
※The reference temperature programmed when the
product is shipped may differ from the Instruction.
1.When you smell bad odors and the rice is too watery: The keep warm temperature is too low. In this case, increase the “Keep Warm” temperature by 1-2℃ .
2. When the rice has a yellowish color or is too dry: The Keep Warm temp is too high. In this case, decrease the “Keep Warm” temperature by 1-2 ℃.
Device Temperature Control
To raise temperature
To lower temperature
➡
❶
Press the “MODE" button once
during warming or press the
“MODE” button 4 times in
standby mode to enter the
warming temperature setting
mode.
At the time, 74 means current
warming temperature.
TO KEEP COOKED RICE WARM AND TASTY
26
❷-1
Press the right select button.
❸
If you set your desired temperature
and press the SET button, the set
temperature will be entered
automatically. (When you press the
CANCEL button or 7 seconds have
passed without any button's being
pressed, the function will be
canceled.)
How to Operate My Mode Function.
Use it while opening the lid when there is too much water or rice becomes too soft.
❶
In standby mode, push the ‘MODE’
button 5times.
The voice says that it is
programmed warming
mode, control the
temperature you want.
➡
❷-2
Press the left select button.
➡
❶Press the MODE button in mode 7 to access the sleeping mode settings.
(‘MODE’ button needs to be pressed for over 0.3 second at the first time.)
❷When you press the ‘SELECTION’ button, the Screensaver function will be selected or canceled.
After doing your desired setting, if you press the SET button, the setting will be saved.
❸If you press the CANCEL button or 7 seconds have passed without any button’s being pressed,the function will
be canceled.
❶Press the MODE button in mode 7 to access the sleeping mode settings.
(‘MODE’ button needs to be pressed for over 0.3 second at the first time.)
❷When you press the ‘SELECTION’ button, the Screensaver function will be selected or canceled.
After doing your desired setting, if you press the SET button, the setting will be saved.
❸If you press the CANCEL button or 7 seconds have passed without any button’s being pressed, the function will
be canceled.
How to activate “SLEEPING” mode.
When keeping rice warm for a long time, set up the temperature low to prevent the following quality of rice:
smelly, dry, change of color; from PM10:00 ~ AM 04:00.
▶
If you need to keep the rice warm during sleeping, do not use this function. This function makes the rice cooler than normal. In summer,
the rice can be spoiled and may smell bad because of high temperature. If possible, do not use the “Custom-made warming” mode while
sleeping.
▶
This function is set up as cancel state.
▶
How to release
▶
How to set up
FOR THE BEST TASTE OF RICE
27
www.cuckoo.co.kr
ENGLISH
Cook tasty rice with Cuckoo pressure rice cooker
W
hen measuring the rice, use the measuring cup. (The amount
of the rice may vary depending on the quality of the rice.) Place
the inner pot on a flat surface and adjust the water to the water
level in the inner pot.
If amount of water and amount of rice is different, the rice can
be crisp or hard.
If possible, buy a small amount of rice and keep the rice some
place where it can ventilate well and avoids a direct ray of light.
It can help prevent evaporation of rice moisture. If the rice has
been unsealed for long, rice can be dry and stale. In this case,
you should pour half of water more. It’s tastier.
If the rice is too dry, rice can be crisp even though it is
measured properly.
If possible, do not use the preset time function when rice is too
dry and pour half of water more. If you set “Preset” over the 10
hours or “Preset” dried rice, rice can be crisp or half cooked.
Even in worse condition, rice can be cooked with different taste
on each level.
If the preset time is longer, the melanoizing effect could be
increased.
Wipe the top cover heating part well for any rice or external
substance.
Especially clean the top of the cover for external substance.
When measuring the rice, Use the measuring cup. (The amount
of the rice may vary depending on the quality of the rice.) Place
the inner pot on a flat surface and adjust the water to water level
in the inner pot.
If possible, buy a small amount of rice and keep the rice some
place where it ventilates well and avoids a direct ray of light.
It can prevent evaporation of rice moisture. If the rice has been
unsealed for long, rice can be dry and stale. In this case, you
should pour the half of water more. It’s tastier.
Wipe the top cover heating part well for any rice or external
substance.
If rice is kept warm for a long period of time, rice color and the
odor will change.
It’s better to set “warm” less than 12 hours.
If rice is kept warm for a long period of time, rice color will
change, as well as odor.
If possible, do not use the preset time function when rice is too
dry and pour the half of water more. If you set “Preset” over the
10 hours or “Preset” dried rice, rice can be crisp or half cooked.
Even worse condition, rice can be cooked different tastes each
level.
For the best taste of rice, check the following points carefully.
It will be hard to open the lid during warming, or right after it has
finished cooking, So push the pressure weight to the side and
allow the steam to release.
Make sure the handle is in the “Lock” position during warming or
reheating.
It is recommended to evenly stir the cooked rice after cooking.
The rice taste is improved. (For a small quantity of rice, pile up the
rice on the center area of the inner pot to keep warm)
Do not keep the scoop inside the pot while warming the rice.
When using a wooden scoop it can create serious bacteria and
odors.
It will be hard to open the lid during warming or right after it has
finished cooking. So push the pressure weight to the side and
allow the steam to release.
Make sure the handle is in the “Lock” position during warming or
reheating.
It would be better to warm the rice for less than 12 hours because
of odors and color change. The cooked rice, which cooked by
pressure cooker, is more prone to changing color than the rice
cooked by general cooker.
During warm mode, the rice can rise and turn white. In this case,
mix the rice.
After 24 hours of heat preservation, the lamp of heat preservation
time lapse blinks, indicating that long time has passed in heat
preservation condition.
It is recommended to evenly stir the cooked rice after cooking.
The rice taste is improved. (For a small quantity of rice, pile up the
rice on the center area of the inner pot to keep warm).
The mixed and brown rice cannot be in such good condition as
white rice while in warm function due to their characteristics.
Therefore, do not keep mixed and brown rice in function for a long
period of time.
Do not keep the rice spatula inside the pot while warming the rice.
When using a wooden rice spatula, it can create serious bacteria
and odors.
Do not mix small amount of rice or leftovers with the rice under
keeping warm. Doing so may cause an odor. (Use a microwave
oven for the cold rice.)
Cautions for Keeping Warm
When Odors are Rising During the Warming Mode
▶Clean the lid frequently. It can cause growth of bacteria and odors.
▶Even though exterior looks clean, there might be germs and it can cause odor so please be sure to use automatic
sterilization (steam cleaning) menu for cleaning. Clean the inner pot completely after automatic cleaning function is
done.
▶Clean the inner pot properly to prevent rice from smelling after you cook soups and steamed dishes.
HOW TO USE POWER SAVE/
ENERGY EYE FUNCTION
28
What is POWER SAVE mode?
If power cord is not unplugged, little bit of electricity will be still wasted. It is called standby electric power.
The power SAVE mode is technology which minimizes this electricity consumption.
▶
How to start power saving
When ‘CANCEL’ button is pushed for 3
seconds at waiting state, Saving power
function is set up.
Automatic Method
If the standby time is chosen as number other than “OFF” at the automatic power saving mode, the automatic
saving power function will be operative. If you move lid handle or push any button before passing waiting time,
the waiting time which is reduced will go back to the setting.
Manual Method
▶
How to end power saving
Method 1) Push any button then it will be returned to
waiting mode.
Method 2) If lid handle is turned to open or close, power
saving mode will be canceled and back to
waiting Mode.
1. If you push ‘MODE’ button 9 times at the standby state, automatic power saving mode is set up.
(‘MODE’ button needs to be pressed for over 0.3 second at the first time.)
2. After doing your desired setting, if you press the SET button, the setting will be saved.
3. If you press the CANCEL button or 7 seconds have passed without any button’s being pressed, the function will be canceled.
Energy Eye function
The luminance sensor automatically recognizes ambient brightness during, warming and preset timer for
minimizing power consumption of the product. If you want the power saving mode to start when it's darker than
the current level(Step 2), set the mode to Step 1. If you want the mode to start when it's brighter than the current
level, set the mode to Step 3. (The power saving mode of CUCKOO is set to Step 2 at the factory.)
1. Press the ‘MODE’ button 13 times in standby status and you will enter the Energy Eye mode.
(‘MODE’ button needs to be pressed for over 0.3 second at the first time.)
2. Each time you press the ‘SELECTION’, the Energy Eye shifts from OFF to Step 1 to Step 2 to Step 3.
When OFF is displayed, a voice comes up saying “The Energy Eye function is canceled”.
3. After selecting your desired step, press the SET button to save the set value.
4. If you press the CANCEL button or 7 seconds have passed without any button's being pressed, the function will not
be set but canceled.
(When selecting Energy Eye function)
(When deactivating Energy Eye function)
▶
How to set up
HOW TO USE POWER SAVE SCREEN LIGHT / LOCK
BUTTON / REMAINING COOKING TIME DISPLAY MODE
29
www.cuckoo.co.kr
ENGLISH
Display POWER SAVE SCREEN LIGHT Mode
This mode adjusts the brightness of the display during cooking, warming or reservation cooking.
▶
How to set and unset the mode
(This mode is selected ‘On’ when the product is delivered from the factory)
1. In the Standby mode, press the ‘MODE’ button 10times to activate the Display POWER SAVE SCREEN LIGHT mode.
(‘MODE’ button needs to be pressed for over 0.3 second at the first time.)
2. When you press the ‘SELECTION’ button, the Screensaver function will be selected or canceled.
3. After doing your desired setting, if you press the SET button, the setting will be saved.
4. If you press the CANCEL button or 7 seconds have passed without any button’s being pressed, the function will be canceled.
How to Set “LOCK BUTTON”
1. Button will be locked if ‘SET’ button is pressed for 2 seconds or longer during
cooking, presetting, warming, reheating or in standby condition.
2. When set, the Button Lock display will flicker on the screen.
Lock can be set for touch button to prevent accidental touch during cleaning or by children.
※ Any button other than ‘SET’ button is pressed while button lock is set, buzzer will sound.
※ Press the SET button for 2 seconds or longer to cancel the button lock and set the desired function.
※ Button lock function is cancelled automatically when the power is OFF even though the button lock function is already set.
▶
How to set up
1. Button will be released if ‘SET’ button is pressed for 2 seconds or longer during
cooking, presetting, warming, reheating or in standby condition.
2. When released, the Button Lock display will disappear on the screen.
Remaining Cooking Time Display Mode
This mode sets on or off the remaining cooking time display which appears periodically during the cooking.
(The displayed remaining cooking time may vary from the actual one depending on the cooking volume and process.)
1.In the Standby mode, press the ‘MODE’ button 11 times to activate the Remaining Cooking Time Display mode.
(‘MODE’ button needs to be pressed for over 0.3 second at the first time.)
2. If you press the CANCEL button or 7 seconds have passed without any button's being pressed, the function will be canceled.
※
Remaining Cooking Time Display
mode set off
※
Remaining Cooking Time Display
mode set on
▶
How to release
30
CHECK BEFORE ASKING
FOR SERVICE
▼If there is a problem with your cooker, check the following details before requesting service to your dealer.
Sometimes the cooker may not operate as desired if used incorrectly.
Case
When cannot turn to “Unlock”.
When the lid cannot open
although the lid handle is
turned to "Unlock".
When the steam exhausted
between the lid.
When the ‘CANCEL’ button
does not operate while
cooking.
Check points
•Did you turn the “lid” handle while cooking?
•Did you turn the “lid” handle before
exhausting steam completely?
•Is there an external substance on the
packing?
•Is packing too old?
•Is the inner pot hot?
•Is currently the setting to lock mode?
Do the following
When you hear weird noises
during cooking and warming
Brown rice is not germinated
properly
•Is there a wind blowing sound when
cooking the rice?
•Is there a “Chi” sound when warming
the rice?
•Does the amount of rice exceed the
specified maximum capacity?
•Is bean(other grains) too dry?
•Don’t open the lid while cooking. If you want to open
lid while cooking, press the ‘CANCEL’ button more
than 0.3 seconds and release the steam.
•Pull the pressure handle to the side once and allow
the steam to completely.
•Because of the pressure.
•Pull the pressure handle to aside once and exhaust
the steam completely.
•Clean the packing with duster.
•Keep the packing clean.
•If the steam is exhausted through the lid, please
power off and contact the service center and dealer.
•Packing life cycle is 12 month, please replace the
packing per 1 year.
•Keep pressing the ‘CANCEL’ button for 2 seconds
for safety reason if you want to cancel while
cooking.
•Be careful of hot steam emission or hot contents
spattered from the automatic steam outlet during
cancellation.
•Please press ‘SET’ button for over 2 seconds to
release.
•Is the inner pot inserted?
•Check the rated voltage?
•Put the specified maximum capacity of brown rice.
•Old rice or contaminated rice may not be
germinated properly.
When the Pressure
“Cook/Turbo” Timer
button does not operate
with “ ”
•Did you turn the lid Handle
to “Lock”
•Is “Lock” lamp on?
When the button cannot
operate with “ ”
•Is the inner pot inserted?
•Check the rated voltage?
•
Please turn the “lid” handle to “Lock”.
•Please insert inner pot.
•This product is 120V only.
31
www.cuckoo.co.kr
ENGLISH
CHECK BEFORE ASKING
FOR SERVICE
▼If there is a problem with your cooker, check the following details before requesting service to your dealer.
Sometimes the cooker may not operate as desired if used incorrectly.
Case Check points Do the following
When the Pressure
“Cook/Turbo” Timer
button does not operate
with “ ”
When the rice is badly sticky.
•Did you turn the lid Handle
to “Lock”
•Is “Lock” lamp on?
•
Is there any rice or any other alien
substance on the temperature sensor or
the bottom surface of the inner pot?
When the button cannot
operate with “ ”
•Is the inner pot inserted?
•Check the rated voltage?
•
Clean all the alien substances on the
temperature sensor or the bottom surface
of the inner pot.
When “ ” is showed on
the LCD.
When the time cannot be
preset.
When the lid cannot close
•Check the rated Voltage?
•Is the current time correct?
•Is AM or PM set properly?
•Did you set the reservation time over
13 hours?
•Cut the power and contact customer service.
•It is normal to get “ ” when putting only water.
•This is only for 120V.
•Is the inner pot correctly inserted in the
main body?
•Is the lid handle on the top cover set to
“Lock”?
•Is there hot food in the inner pot?
•Micom memory is out.
•Please cut the power and contact customer service
“ ” mark shows up
during the product operation
•Please insert inner pot.
•This product is 120V only.
•
Please turn the “lid” handle to “Lock”.
When “ ”, “ ” are
shown on the LCD by turns
•Micom power is out
•Please cut the power and contact customer service
When “ ”, “ ” are
shown on the LCD by turns
•The sensor is broken
•Please cut the power and contact customer service
When “ ”, “ ” are
shown on the LCD by turns
•Is there power cut while in cooking?
•Set the current time(Refer to page 15).
•Check the AM and PM.
•Maximum reservation time is 13 hours.
•Please put in the inner pot correctly.
•Please turn the “lid” handle to “Lock”
•Pull the pressure handle to aside once.
When the rice is not cooked.
When the rice is not well
cooked.
•
COOK/TURBO button is pressed?
•
Is there power cut while in cooking?
•
Did you use the measuring cup for the rice?
•
Did you put proper amount of water?
•
Did you rinse the rice before cooking?
•
Did you put rice in water for a long time?
•
Is the rice old or dry?
•
Press the COOK/TURBO button once.
And check “ ”sign on the display.
•
Re-press the ‘COOK/TURBO’ button.
•
Refer to page 16~17.
•
Add water about half the notch and then cook.
32
C
H
E
C
K
B
E
F
O
R
E
A
S
K
I
N
G
F
O
R
S
E
R
V
I
C
E
▼If there is a problem with your cooker, check the following details before requesting service to your dealer.
Sometimes the cooker may not operate as desired if used incorrectly.
Case
Rice is too watery or stiff.
Check points
•
Is the menu selected correctly?
•
Did you properly measure water?
•
Did you open the top cover before
cooking was finished?
Do the following
Bean (other grains)is half
cooked.
•
Is bean (other grains) too dry?
•
Soak or steam beans and other grains before
cooking in the pressure cooker in order to avoid
partially cooked beans or grains. Beans should
be soaked for -2-minutes or steamed for-2-
minutes prior to cooking, depending on your
taste.
•
Select the correct menu.
•
Properly measure water.
•
Open the top cover after cooking finished
When the water overflows.
•
Did you use the measuring cup?
•
Did you use proper amount of water?
•
Is the menu selected correctly?
•
Refer to page
16~17.
When you smell odors while
warming.
If “ ” sign is appears.
•
Did you close the top cover?
•
Please check it the power cord is plugged.
•
Did it warm over 12 hours?
•
Is there any other substance such as rice
scoop or cold rice?
•
Is been (other grains) too dry?
•
Select the correct menu.
•
Properly measure water.
•
Open the top cover after cooking finished
•
It shows on the display when pressing
“Start” button again, or when the cooking
has finished and you've never ever open
turned the handle to “Unlock”
•
It can be solved by turning handle to “Unlock” and
then turn to “Lock”
“ , , ”
Signs show up.
•
Temperature sensor or fan motor does
not work properly.
•
Unplug the power cord and call the Service center.
Warming passed time mark
blinks during keeping warm.
•
24 hours has not passed yet after Keeping
warm
•
This function alarms if the rice remained warm for
more than 24 hours.
Rice has gotten cold or a lot of
water flow during Keeping warm
•
Keeping warm was set in “Sleeping” mode
•
Keep warm after cancelling or setting “Sleep
Keeping Warm” mode depending on the necessity.
“ ” sign shows up
•
Detachable cover is not mounted
•
Mount detachable cover(Refer to page 12)
•
If “ ” sign is displayed continuously even
though you already installed detachable cover,
please contact customer service.
The power is not on after plug in
the power cord,
•
Please turn on the standby power switch button.
•
Detachable cover is not mounted
Alarm sounds or reheating does
not work while keeping warm
•
Mount detachable cover(Refer to page 12).
“
”
Sign shows up
•
Appears when an overpressure occurs.
•
Unplug the power cord and call the Service
center
“”,“”
Sign shows up
•
Pressure sensor does not work properly.
•
Unplug the power cord and call the Service
center
“”,“”,“ ”,
“”,“”,“ ”,
Sign shows up
•
Appears when there is an abnormality
after pressure check.
•
Refer to How to use pressure check and use it
correctly.
Recipe
33
www.cuckoo.co.kr
ENGLISH
Recipe Ingredients
Delicious
Rice
Mixed
Rice
Well
being
Rice
SUPER
GRAIN
Glutin.
Rice
Rice 4 cups
* The “cup” in ingredients means a measuring cup
in the rice cooker. 1 cup (180cc) is for one person.
※
Please refer to our website (www.cuckoo.co.kr) for more information.
※ After cooking reter to page 12 of the notes upon the inner pot washing.
Directions
1. Put clean-washed rice in the inner pot and pour water up
to the line for Glutin Rice. (Glutin Rice : 4, Pea Rice : 3)
2. Lock the lid, and push the Pressure GLUTIN. RICE button.
Boiled
Fresh
Germinated
Brown Rice
Brown rice 4 cups
1. Wash and put brown rice and prepared ingredients into the
inner pot. Pour water up to the line 4 for GABA rice.
2. Lock the lid and select the GABA RICE with the SELECTION
button. Press the COOK/TURBO button. (Set time: 3Hours)
Boiled
Brown
Rice with
Red
Beans
Brown rice 1 cup, rice 2 cups and red
beans 1/3 cup
1. Wash and put brown rice into the inner pot. Pour water up to
the line 3 for GABA rice.
2. Lock the lid and Press the Pressure BROWN RICE button.
Green
Tea Rice
Blended
with
Chicken
Chest
Flesh
2 cups of brown rice, 3g of green tea leaf, 10g of
green tea powder, 4 nuggets of chicken chest
flesh, a little bit of olive oil, a little bit of salt, a little
bit of pepper, 5g of celery, a little bit of lime, a
little bit of rosemary
1. Wash and put brown rice and prepared ingredients into the
inner pot. Pour water up to the line 2 for GABA rice.
2. Lock the lid and select the GABA RICE with the SELECTION
button. Press the COOK/TURBO button.
(Set time: 3Hours)
Mushro
om Tian
2 cups of brown rice, 20g of brown gravy sauce,
a little bit of salt, 2 sheets of sesame leaves, 1/3
pieces of pumpkin, a pack of shimeji mushroom
※ Mushroom may be chosen as preferred in the family.
Saessak
Bibimbap
(rice with
sprout
and
vegetables)
2 cups of brown rice and some sprouts and vegetables.
※ Seasoning red pepper paste : Red pepper paste 1/2cup, beef
(crushed)40g, sesame oil 1tablespoon, honey 1 tablespoon and sugar
1tablespoon, 1/3 cup of water
Pea
Rice
3 cups of rice, 1/2 cup of pea, 1 tablespoonful
of sake, 1.5 teaspoonful of salt.
※ Boil pea before cooking.
Kamut
Rice
Rice 2+1/3 cups, kamut 2/3 cup
(The ratio between rice and kamut is desirable to be
8:2.)
1. Separately wash kamut and rice, add kamut first into the Inner Pot,
put rice in, and add water up to Mixed rice Water Level 3.
2. Put the Cover on, select the SUPER GRAIN menu with the
SELECTION button, set the soaking time to be three hours, and press
the COOK/TURBO button.
※ If you want kamut to become softer, soak it in water before cooking.
Oat
Rice
Rice 2 cups, oats 1 cup
(The ratio between rice and oat is desirable to be 7:3.)
1. Wash rice and super grains, add them into the Inner Pot, and add water up to
Mixed rice Water Level 3.
2. Put the Cover on, select the SUPER GRAIN menu with the SELECTION button,
set the soaking time to be 0 hour, and press the COOK/TURBO button.
※ If you want super grains to become softer, soak them in water before cooking.
Chick
Pea
Rice
Rice 2+1/3 cups, chick pea 2/3 cup
(The ratio between rice and chick pea is desirable to be
8:2.)
Booled Barly
2 cups of rice, a cup of barley
1. Drain the grains after washing.
2. Put clean rice with prepared ingredients with some salt and
pour water up to the line 3 for mixed rice.
3. Lock the lid and Press the Pressure MIXED RICE button.
1. Put clean-washed rice and barley in the inner pot and pour
water up to the line 3 for mixed rice.
2. Lock the lid and Press the Pressure MIXED RICE button.
Five-grain
Rice
Rice 1.5cup, millet1/3cup, glutinous
rice1/2cup, red beans 1/3cup,
sorghum1/3cup and salt 1 teaspoon
Recipe
34
LOW/HIGH Press Steam Cooking Time Table
COOKING
Steamed RiceCake
Steamed Rib
Steamed Chicken
Boiled Pork
Five-flavor Pork
Hard-boiled Cuttlefish
Steak
55min
45min
40min
40min
35min
10min
25min
45min
35min
30min
30min
30min
10min
20min
40min
25min
35min
25min
40min
20min
20min
30min
25min
25min
15min
30min
20min
15min
COOKING
Steamed Blue Crab
Steamed Fish
Steamed Clam
Steamed Bean Curd
Multi-Flavor Glutinous Rice
Japchas
Steamed Dumpling
COOKING TIME
LOW PRESSSTEAM
HIGH PRESS STEAM
LOW PRESSSTEAM
HIGH PRESS STEAM
COOKING TIME
COOKING
Steamed Eggplant
Steamed Pumpkin
Steamed Chestnut
Steamed Sweet Potato
Steamed Potato
Steamed Corn
Fresh Cream Cake
40min
25min
35min
25min
40min
20min
20min
15min
15min
20min
25min
30min
30min
40min
20min
15min
20min
15min
20min
45min
15min
20min
15min
20min
15min
20min
45min
15min
COOKING
Boiled egg
Steamed egg
Rice cake gratin
Shrimp ketchup fried rice
Rice pizza
Butter chocolate cake
Tteokbokki
COOKING TIME
LOW PRESSSTEAM
HIGH PRESS STEAM
LOW PRESSSTEAM
HIGH PRESS STEAM
COOKING TIME
Recipe Ingredients
SUPER
GRAIN
PORRI
DGE
Green
lentil
Rice
Rice 2 cups, green lentil 1 cup
(The ratio between rice and green lentil is desirable
to be 7:3.)
Directions
1. Wash rice and super grains, add them into the Inner Pot, and add water up to
Mixed rice Water Level 3.
2. Put the Cover on, select the SUPER GRAIN menu with the SELECTION button,
set the soaking time to be 0 hour, and press the COOK/TURBO button.
※ If you want super grains to become softer, soak them in water before cooking.
White
Porridge
- Thick porridge : Rice 1 cup
- Thin porridge : Rice 0.5 cup
1. Put the prepared ingredients in the inner pot and pour water up to the
appropriate line depending on the quantity of food to be served.
(Thick porridge: water up to the line 1 for Thick porridge,
Thin porridge : water up to the line 0.5 for Thin porridge)
2. Lock the lid and Press the Pressure PORRIDGE button.
Pine Nut
Porridge
Rice 1 cup, pine nut 1/2cup and some salt
Abalone
Porridge
A cup of rice, 1 tablespoonful of sesame oil,
1 piece of abalone, a little bit of salt
Red Bean
Porridge
Rice 2/3cup, 1/3 cups of red bean, 2/3
cups of glutinous rice
※ Please refer to our website (www.cuckoo.co.kr) for more information.
Special
Chicken
Porridge
Rice 1cup, chicken 100g, chicken soup 300cc,
green pepper 1 unit, red pepper 1 unit and some salt
※ Seasoning : Chopped scallion 1 tablespoon,
crushed garlic 1 tablespoon, soy sauce 2
tablespoons, some ground sesame mixed with
salt, sesame oil 2 teaspoons and some ground
pepper
1. Put the prepared ingredients in the inner pot and pour water
up to the appropriate line depending on the quantity of food
to be served.
(Pine Nut Porridge, Special Chicken Porridge: water up to the
line 1.5 for Thick porridge, Abalone Rice Porridge, Red Bean
Porridge: water up to the line 1 for Thick porridge)
2. Lock the lid and Press the Pressure PORRIDGE button.
Quinoa
Rice
Rice 2 cups, quinoa 1 cup
(The ratio between rice and quinoa is
desirable to be 7:3.)
BABY
FOOD
1. Put the prepared ingredients in the inner pot.
2. Lock the lid, select the BABY FOOD menu with the
SELECTION button After setting the cooking time, press
the COOK/TURBO button.
(Sweet potato apple porridge: 15 minutes,
Sweet pumpkin soup: 10 minutes,
Tuna vegetable soft rice: 10 minutes,
Steamed rice, tofu, and vegetables: 15 minutes.)
S
w
e
e
t
P
o
t
a
t
o
A
p
p
l
e
P
o
r
r
i
d
g
e
70g of Sweet potato, 70g of apple,
2 Tablespoon, some honey
S
w
e
e
t
P
u
m
p
k
i
n
S
o
u
p
70g of Sweet potato, 70g of apple,
2 Tablespoon, some honey
T
u
n
a
v
e
g
e
t
a
b
l
e
S
o
f
t
R
i
c
e
50g of rice, 30g of tuna(can), 10g of
paprika,10g of carrot, 1/2 cup of water,
some butter, some laver powder
S
t
e
a
m
e
d
R
i
c
e
,
T
o
f
u
,
a
n
d
V
e
g
e
t
a
b
l
e
s
50g of rice, 30g of bean curd, 10g of
carrot, 10g of green pumpkin, 1/2 egg,
Milk 4 tablespoons
MEMO
83
www.cuckoo.co.kr
100% Recycled paper 383-573F Rev.0
CUCKOO ELECTRIC RICE COOKER/WARMER
LIMITED WARRANTY
KEY Company, P&K USA TRADING CORP and Cuckoo Trading Canada will repair at its option replace,
without charge, your product which proves to be defective in material or workmanship under normal use,
during the warranty period listed below from the date of original purchase. This warranty is good only to the
original purchaser of the product during the warranty period. P&K USA TRADING CORP. covers the east and
the central districts, KEY Company covers the west and the central districts, Cuckoo Trading Canada covers
the whole Canada.
WARRANTY PERIOD
MODEL# #LABOR PARTS HOW SERVICE IS HANDLED
CRP-JH10 1YEAR 1YEAR The East and the Central Districts
Call : 718 888 9144
Address : 129-04 14th Avenue College Point, NY 11356, USA
The West and the Central Districts.
Call : 323 780 8808
Address : 1137 E. 1st Street, L.A, CA 90033, USA
Canada (TORONTO)
Call : 905 707 8224
Address : #D8-7398 Yonge Street Thornhill Ontario Canada L4J 8J2
Canada (VANCOUVER)
Call : 604 540 1004
Address : 945 Lougheed Hwy Coquitlam BC Canada V3K 3T4
No other express warranty is applicable to this product. THE DURATION OF ANY IMPLIED WARRANTIES,
INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY, IS LIMITED TO THE DURATION OF
THE EXPRESS WARRANTY HEREIN. CUCKOO ELECTRONICS CO.,LTD, SHALL NOT BE LIABLE FOR
THE LOSS, THE USE OF THE PRODUCT, INCONVENIENCE, LOSS OR ANY OTHER DAMAGES,
DIRECT OR CONSEQUENTIAL, ARISING OUT OF THE USE OF, OR INABILITY TO USE, THIS PRODUCT
OR FOR ANY BREACH OF ANY EXPRESS OR IMPLIED WARRANTY, INCLUDING THE IMPLIED
WARRANTY OF MERCHANTABILITY APPLICABLE TO THIS PRODUCT
.
Some states do not allow the exclusion or limitation of incidental or consequential damages or limitations on
how long an implied warranty lasts : so these limitations or exclusions may apply to you. This warranty gives
you specific legal rights and you may also have other rights which vary from state to state.
THE ABOVE WARRANTY DOES NOT APPLY IN THESE CASES:
✽To damages problems which result from delivery or improper installation.
✽To damages problems which result from misuse, abuse, accident, alteration,
or incorrect electrical current or voltage.
✽To serve call which do not involve defective workmanship or material and explaining the operation of the unit.
Therefore, these costs are paid by the consumer. Customer assistance numbers :
To Prove warranty Coverage :
▶
Retain your Sales Receipt to prove date of purchase
▶
Copy of your Sales Receipt must submitted at the time
warranty service is provided.
To Obtain Product, Customer, or Service Assistance and Nearest Authorized service center,
Parts Distributor or Sales Dealer:
The West and the Central Districts.
Call : 323 780 8808
Address : 1137 E. 1st Street, L.A,
CA 90033, USA
Canada (Toronto)
Call : 905 707 8224
Address : #D8-7398 Yonge Street
Thornhill Ontario Canada
L4J 8J2
Canada (Vancouver)
Call : 604 540 1004
Address : 103-4501 North Road
Burnaby BC Canada
V3R 4R7
The East and the Central Districts
Call : 718 888 9144
Address :129-04 14th Avenue
College Point, NY 11356, USA
