P511 SK37A遥控版
# Be better
# Tip-over protection
# Overheat protection
# Digital adjustable thermostat
# Coverage for Up to 150 Sq. Ft.
# 1500 watts Heating 5260 BTU
# Ceramic heater for Room, Patio, Garage
User Manual and Warranty Ceramic Fan Heater, P511
PRODUCT STRUCTURE
OPERATION AND USE
SPECIFICATIONS
Product
Model
Power
Product size
Function
Manufacturer
Environment
Ceramic Fan Heater
P511
120V AC, 60Hz, 1500W, 12.5A
193*160*272mm / 7.6*6.3*10.7 inch
Fan, Low / High heating
Shenzhen BORK E-Commerce Ltd.
IMPORTANT SAFETY INSTRUCTIONS
READ AND KEEP THIS MANUAL FOR FUTURE REFERENCE.
PREPARING THE HEATER
Thermostat
60-95°F digital termostat
Slogan: Everyday is the most important day.
BORK Group, who commit to creating lifestyle brands, was founded in
California, USA at 2017.
Bork Group, which focus on household, home appliance, personal care
products, is famous as a cost-effective tasteful lifestyle brand at Amazon.
With products as the core, BORK devotes itself to the research,
development, production, sales and service of lifestyle products. Not only
the combination of products, but also the transmission of a way of life,
understanding of life, BORK Group conscientiously do a good job in every
single product. [ NUMIFUN: Trademark Reg. No.90310613 of USA ]
BRAND STORY
WARNING: Risk of Circuit overload !
High wattage 1500W, Rated current: 12.5A.
Do not operate another high wattage appliance
on the same circuit.
Need Receptacle: NEMA #5-20R, 125-volt
grounding receptacle, 20 ampere.
CLEANING AND MAINTENANCE
R
e
q
u
i
r
e
s
1
2
0
v
o
u
t
l
e
t
-
2
0
a
m
p
c
i
r
c
u
i
t
CAUTION: Start-up current (need 20 amp circuit breaker)
Some appliances, such as heating appliances, TV, motors, power tools,
require 1.5 times more watts at start up than the printed rated wattage.
So we recommand to turn on the heater by LOW gear (900w) rstly,
then, after 1 minute, turn on to HIGH gear (1500w).
CAUTION: Thermal protection / Resetting the heater
Overheat Protection System will shut the unit off when a potential
overheat temperature is reached. Unplug the heater and wait 30 mins.
1. Switch off the appliance, unplug it and wait unitl it cools down.
2. Clean the device with a dry towel or vacuum cleaner. Be sure not to
wet the heating element and the switches.
Always UNPLUG it when not in use.
HOUSEHOLD USE ONLY!
1. This product is intended for indoor, non-commercial, household use for
temporarily heating residential rooms. Do not use the product for any other
purpose.
2. Do not leave the product unattended while it is in use. Always unplug the
product from the electrical outlet when it is not in use.
3. Keep the product out of the reach of children and pets. This product is not
intended for use by children.
4. Place the product on a at, steady, stable, heat-resistant surface. Never
place the device directly in front of or under a socket.
5. This product has hot parts inside. Do not use it in areas where gasoline,
paint, or ammable liquids are used or stored, as there may be a risk of re
or explosion.
6. Use the product in a well-ventilated area. This heater is hot when in use. To
avoid burns, do not let bare skin touch a hot surface. Use handle when moving
this heater. Keep combustible materials, such as furniture, pillows, bedding,
paper, clothes, and curtains at least 3 feet (0.9 m) from all sides of the heater.
7. Use this heater only as described in this manual. Any other use may cause
re, electric shock, or personal injury.
8. Do not insert or allow foreign objects to enter any opening on the heater as
this may cause an electric shock, re, or product damage.
9. Do not use this product to dry or heat clothing, shoes, pipes, or other items.
10. This heater is not intended for use in damp/wet locations.
11. Never locate heater where it may fall into a bathtub or water container.
12. Do not move the product when it is heated. Allow the product to thoroughly
cool before handling it.
13. Plug the product into 120V 60Hz electrical outlet with 15A receptacle.
14. Do not allow the Power Cord to hang (e.g., over the edge of a table or
counter) or place/run the Power Cord under rugs, carpeting, or in high-trafc
areas where it may be tripped over or pulled.
15. To disconnect the product, press the Power button on the display panel and
then remove the plug from the electrical outlet. Never pull on the Power Cord
when disconnecting from power outlet.
16. Do not put any stress on the Power Cord where it connects to the product,
as the Power Cord could fray and break.
17. Do not plug or unplug the product from the electrical outlet with wet hands.
18. Keep the Power Cord and product away from heated surfaces.
19. Do not operate any heater with a damaged cord or plug.
0~+40°C / 32-104 °F (Household use)
Breakdown
No power or do
not work
Burning smell
Possible Causes and Solution
1. Overheat protection
Unplug the heater and wait about 30 minutes
to cool down, then plug the unit in again.
2. Tip-over protection
Move the heater to a rm, level surface.
3. Room reaches the desired temperature
Set Thermostat to 95°F or MAX.
4. The power socket is no power.
Try another 120V power socket, whose
receptacle should be at least 20A 125VAC.
5. Breaker/Fuse has been tripped.
Check the breaker of your electrical box -
20
amp circuit breaker
. Do not operate another
high wattage appliance on the same circuit.
1. First use
It is normal for the heater to emit some odor
when it is turned on for the rst time or a long
time not being used. The odor will disappear
once the heater has been running 30 minutes.
2. Check and ensure the surrounding
Remove any combustible items within 0.9
meters(3 ft.).
TROUBLE SHOOTING
WARNING: Do not attempt to repair heater. No user-serviceable parts inside.
Not Hot
Ensure a MINIMUM CLEARANCE of 6 inches
(15cm) from both sides and rear of the heater.
Name of Buyer
Date of Purchase
Where did you buy
Email: [email protected] Connect with us @numifun
Online: www.numi-fun.com Made in China
Work with Delight and Idealism. Made by Innovation
Love me little
Love me long
Extend warranty into 18 months by email us with your information in just
1 minute. Send your purchase information to: [email protected].
Your data may be used by BORK GROUP to provide you with information
about products, services and other offerings by email. Thank you for
registering. Leaving your product unregistered does not impact upon
your warranty rights.
Please record the purchase information.
FOR PROBLEMS AND QUESTIONS, WE CAN HELP.
Default warranty period: 1 year from the date of Purchase.
Within 30 days of purchase, please contact and return to Amazon.
Remark: This product is intended for domestic and ofce use only.
This appliance is intended for 2000 hours’ service life.
Copyright © 2020 NUMIFUN. Trademark: NUMIFUN
Reg. No. 5,942,484 of United States of America
Order Number
WARRANTY
CONTACT US
What is a Ceramic Heater?
Ceramic heaters are a very popular type of portable heater. They use
ceramic plates and aluminum bafes to conduct heat that circulates
warm air throughout an entire room. Electric ceramic heaters provide
quick, focused heating by directing warmth in a matter of seconds.
Control panel
Font cover
Back cover
Air outlet
Base
Tip-over switch
Back cover
Handle
Air inlet
16 AWG
Power cord
1. Set the heater on a at, even and steady surface.
2. Plug into AC 120V 60Hz power supply. (20A 125VAC
receptacle)
NOTE: To prevent personal injury always use a licensed electrician to
install new outlets or circuits. No adapter should be used with this unit.
FAN
TIMER
OSC
HEAT
TEMP +
TEMP -
ON/OFF
CONTROL PANEL & REMOTE
Back side of
Remote
Button battery
CR2025 3V
Positive pole
PUSH
1. REMOVE the insulating sheet for rst use. There are 7 buttons on the
remote, which are equivalent to the functions of the control panel.
2. Point the remote to control panel, and maximum signal range is 16 feet.
ON/OFF
Press button to turn on the heater, again to turn off.
For safety, the fan will continue to cool down in 30s.
FAN / HEAT
Press the FAN/HEAT button to enter into Fan/Heat mode.
Press HEAT button again, it works as low heating --> High
heating --> circularly. The LCD display are FA/LO/HI.
TEMP +/-
In heat mode, Press button to turn up or turn down the
desired temp. from 60-95°F. The LCD display shows the
desired temp. When the room reaches the desired temp.,
the heater will stop heating and enter into standby mode.
TIMER
Press button to set timer: 0-1-2-3-4-5-6-7-8-0H circularly.
OSC
Press button to allow it’s oscillation. Press again to stop.
For safety, the fan will always continue to cool down in 15s before stop.
For better experience, display will be dimmed after 60 seconds.
CAUTION
DO NOT TOUCH
WARNING
DO NOT COVER
WARNING
DO NOT OPEN
CAUTION
HOT SURFACE
