S9F174ND
DA
Fryser Brugsanvisning 2
EN
Freezer User Manual 17
NO
Fryser Bruksanvisning 32
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following data
available: Model, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
VISIT OUR WEBSITE:
To get usage advice, brochures, trouble shooter, service and repair information:
www.smeg.com/services/customer-service
CONTENTS
1. SAFETY INFORMATION.................................................................................17
2. SAFETY INSTRUCTIONS...............................................................................19
3. INSTALLATION............................................................................................... 21
4. CONTROL PANEL.......................................................................................... 23
5. DAILY USE......................................................................................................24
6. HINTS AND TIPS............................................................................................ 25
7. CARE AND CLEANING...................................................................................27
8. TROUBLESHOOTING.....................................................................................28
9. NOISES........................................................................................................... 30
10. TECHNICAL DATA........................................................................................30
11. INFORMATION FOR TEST INSTITUTES.....................................................31
12. ENVIRONMENTAL CONCERNS.................................................................. 31
Subject to change without notice.
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible
for any injuries or damage that are the result of incorrect
installation or usage. Always keep the instructions in a safe
and accessible location for future reference.
ENGLISH 17
1.1 Children and vulnerable people safety
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved. Children aged from 3 to 8 years and
persons with very extensive and complex disabilities are
allowed to load and unload the appliance provided that they
have been properly instructed. Children of less than 3 years
of age should be kept away from the appliance unless
continuously supervised.
• Children should be supervised to ensure that they do not
play with the appliance.
• Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
• Keep all packaging away from children and dispose of it
appropriately.
1.2 General Safety
• This appliance is for storing food and beverages only.
• This appliance is designed for single household domestic
use in an indoor environment.
• This appliance may be used in, offices, hotel guest rooms,
bed & breakfast guest rooms, farm guest houses and other
similar accommodation where such use does not exceed
(average) domestic usage levels.
• To avoid contamination of food respect the following
instructions:
– do not open the door for long periods;
– clean regularly surfaces that can come in contact with
food and accessible drainage systems;
• WARNING: Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
• WARNING: Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
18 ENGLISH
• WARNING: Do not damage the refrigerant circuit.
• WARNING: Do not use electrical appliances inside the food
storage compartments of the appliance, unless they are of
the type recommended by the manufacturer.
• Do not use water spray and steam to clean the appliance.
• Clean the appliance with a moist soft cloth. Only use neutral
detergents. Do not use abrasive products, abrasive
cleaning pads, solvents or metal objects.
• When the appliance is empty for long period, switch it off,
defrost, clean, dry and leave the door open to prevent
mould from developing within the appliance.
• Do not store explosive substances such as aerosol cans
with a flammable propellant in this appliance.
• If the supply cord is damaged, it must be replaced by the
manufacturer, its Authorised Service Centre or similarly
qualified persons in order to avoid a hazard.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must install this
appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Do not use the appliance before installing
it in the built-in structure due to safety
manner.
• Follow the separate instructions for the
appliance installation and door reversing
available on our website.
• Always take care when moving the
appliance as it is heavy. Always use safety
gloves and enclosed footwear.
• Make sure the air can circulate around the
appliance.
• At first installation or after reversing the
door, wait at least 4 hours before
connecting the appliance to the power
supply. This is to allow the oil to flow back
in the compressor.
• Before carrying out any operations on the
appliance (e.g. reversing the door),
remove the plug from the power socket.
• Do not install the appliance close to
radiators or cookers, ovens, or hobs,
unless otherwise specified in the
installation instructions.
• Do not expose the appliance to the rain.
• Do not install the appliance where there is
direct sunlight.
• Do not install this appliance in areas that
are too humid or too cold.
• When you move the appliance, lift it by the
front edge to avoid scratching the floor.
• Protect the floor from scratches when
reversing the appliance door.
• The appliance contains a bag of
desiccant. This is not a toy. This is not
food. Please dispose of it immediately.
2.2 Electrical connection
WARNING!
Risk of fire and electric shock.
ENGLISH 19
WARNING!
When positioning the appliance, ensure
the supply cord is not trapped or
damaged.
WARNING!
Do not use multi-plug adapters and
extension cables.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• The appliance must be earthed.
• Always use a correctly installed
shockproof socket.
• If the domestic power supply socket is not
earthed, connect the appliance to a
separate earth in compliance with current
regulations, consulting a qualified
electrician.
• Make sure not to cause damage to the
electrical components (e.g. mains plug,
mains cable, compressor). Contact the
Authorised Service Centre or an
electrician to change the electrical
components.
• The mains cable must stay below the level
of the mains plug.
• Connect the mains plug to the mains
socket only at the end of the installation.
Make sure that there is access to the
mains plug after the installation.
• Do not pull the mains cable to disconnect
the appliance. Always pull the mains plug.
2.3 Use
WARNING!
Risk of injury, burns, electric shock or
fire.
The appliance contains flammable gas,
isobutane (R600a), a natural gas with a high
level of environmental compatibility. Be
careful not to cause damage to the refrigerant
circuit containing isobutane.
• Do not change the specification of this
appliance.
• Any use of the built-in product as free-
standing is strictly prohibited.
• This appliance is intended to be used at
ambient temperature ranging from 10°C to
38°C. The specified temperature range
guarantees the correct operations of the
appliance.
• Do not put electrical appliances (e.g. ice
cream makers) in the appliance unless
they are stated applicable by the
manufacturer.
• If damage occurs to the refrigerant circuit,
make sure that there are no flames and
sources of ignition in the room. Ventilate
the room.
• Do not let hot items to touch the plastic
parts of the appliance.
• Do not put soft drinks in the freezer
compartment. This will create pressure on
the drink container.
• Do not store flammable gas and liquid in
the appliance.
• Do not put flammable products or items
that are wet with flammable products in,
near or on the appliance.
• Do not touch the compressor or the
condenser. They are hot.
• Do not remove or touch items from the
freezer compartment if your hands are wet
or damp.
• Do not freeze again food that has been
thawed.
• Follow the storage instructions on the
packaging of frozen food.
• Wrap the food in any food contact material
before putting it in the freezer
compartment.
• Do not allow food to come in contact with
the inner walls of the appliance
compartments.
2.4 Care and cleaning
WARNING!
Risk of injury or damage to the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains plug
from the mains socket.
• This appliance contains hydrocarbons in
the cooling unit. Only a qualified person
must do the maintenance and the
recharging of the unit.
20 ENGLISH
2.5 Service
• To repair the appliance contact the
Authorised Service Centre. Use only
original spare parts.
• Please note that self-repair or non-
professional repair can have safety
consequences and might void the
guarantee.
• The following spare parts are available for
at least 7 years after the model has been
discontinued: thermostats, temperature
sensors, printed circuit boards, light
sources, door handles, door hinges, trays
and baskets. Door gaskets are available
for at least 10 years after the model has
been discontinued. The duration may be
longer in your country. For further
information, please visit our website.
• Please note that some of these spare
parts are only available to professional
repairers, and that not all spare parts are
relevant for all models.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the mains
supply.
• Cut off the mains cable and discard it.
• Remove the door to prevent children and
pets to be closed inside of the appliance.
• The refrigerant circuit and the insulation
materials of this appliance are ozone-
friendly.
• The insulation foam contains flammable
gas. Contact your municipal authority for
information on how to discard the
appliance correctly.
• Do not cause damage to the part of the
cooling unit that is near the heat
exchanger.
3. INSTALLATION
WARNING!
Refer to Safety chapters.
WARNING!
Refer to installation instruction document
to install your appliance.
WARNING!
Fix the appliance in accordance with
installation instruction document to avoid
a risk of instability of the appliance.
ENGLISH 21
3.1 Dimensions
B
A
H1
W1
D1
W2
D2
W3
D3
90°
Overall dimensions ¹
H1 mm 1772
W1 mm 546
D1 mm 549
¹ the height, width and depth of the appliance
without the handle
Space required in use ²
H2 (A+B) mm 1816
W2 mm 546
D2 mm 551
A mm 1780
B mm 36
² the height, width and depth of the appliance
including the handle, plus the space
necessary for free circulation of the cooling
air
Overall space required in use ³
H3 (A+B) mm 1816
W3 mm 546
D3 mm 1068
³ the height, width and depth of the appliance
including the handle, plus the space
necessary for free circulation of the cooling
air, plus the space necessary to allow door
opening to the minimum angle permitting
removal of all internal equipment
22 ENGLISH
3.2 Location
To ensure appliance's best functionality, you
should not install the appliance in a place with
direct sunlight. Do not install the appliance
close to radiators or cookers, ovens, or hobs,
unless otherwise specified in the installation
instructions.
Make sure that air can circulate freely around
the back of the cabinet.
This appliance should be installed in a dry,
well ventilated indoor position.
This appliance is intended to be used at
ambient temperature ranging from 10°C to
38°C.
The correct operation of the
appliance can only be guaranteed within
the specified temperature range.
If you have any doubts regarding
where to install the appliance, please turn
to the vendor, to our customer service or
to the nearest Authorised Service Centre.
It must be possible to disconnect the
appliance from the mains power supply.
The plug must therefore be easily
accessible after installation.
3.3 Electrical connection
• Before plugging in, ensure that the voltage
and frequency shown on the rating plate
correspond to your domestic power
supply.
• The appliance must be earthed. The
power supply cable plug is provided with a
contact for this purpose. If the domestic
power supply socket is not earthed,
connect the appliance to a separate earth
in compliance with current regulations,
consulting a qualified electrician.
• The manufacturer declines all
responsibility if the above safety
precautions are not observed.
3.4 Ventilation requirements
The airflow behind the appliance must be
sufficient.
min. 200 cm
2
min.
200 cm
2
min.
38 mm
min.
38 mm
CAUTION!
Refer to the installation instructions for
the installation.
3.5 Door reversibility
Please refer to the separate document with
instructions on installation and door reversal.
CAUTION!
At every stage of reversing the door
protect the floor from scratching with a
durable material.
4. CONTROL PANEL
4
3
21
1. Freezer compartment button
Appliance ON/OFF button
2. Freezer temperature indicators
3. Extra Freeze button
4. Extra Freeze indicator
ENGLISH 23
4.1 Switching on
1. Insert the plug into the wall socket.
2. Press and hold the appliance ON/OFF
button.
Temperature indicators show the set default
temperature.
4.2 Switching off
1. Press and hold the appliance ON/OFF
button.
Temperature indicators switch off.
2. Disconnect the mains plug from the
power socket.
4.3 Temperature regulation
It is not possible to set the
temperature when the Extra Freeze
function is on.
Set the temperature of the appliance by
tapping the freezer compartment button.
Temperature indicators show the set
temperature level.
The temperature range may vary between
-15°C and -24°C (recommended -18°C).
The set temperature will be reached
within 24 h.
After a power failure, the appliance
restores the set temperatures.
4.4 Extra Freeze function
The Extra Freeze function is used to pre-
freeze and fast freeze in sequence in the
freezer compartment. This function
accelerates the freezing of fresh food and, at
the same time, protects foodstuffs already
stored from undesirable warming.
To freeze fresh food activate the
Extra Freeze function at least 24 hours
before placing the food to complete pre-
freezing.
To activate the Extra Freeze function press
Extra Freeze button. The Extra Freeze
indicator lights up.
This function stops automatically after
a maximum 52 hours.
It is possible to deactivate the function by
pressing the freezer compartment button. The
Extra Freeze indicator switches off.
4.5 High temperature alarm
When there is a temperature increase in the
freezer compartment (for example due to an
earlier power failure), the first, third and fifth
freezer temperature indicators flash and the
sound is on.
To suspend the alarm for 1 hour press any
button. The sound switches off. The first, third
and fifth freezer temperature indicators light
steadily for 5 seconds before indicating the
freezer temperature again.
After one hour the alarm restarts until normal
conditions are restored.
If you do not press any button, the sound
switches off after around one hour.
4.6 Door open alarm
If the freezer door is left open for
approximately 80 seconds, freezer
temperature indicators flash and the sound is
on.
During the alarm, you can mute the sound by
pressing any button. The sound switches off
after around one hour.
The alarm deactivates after closing the door.
5. DAILY USE
24 ENGLISH
5.1 Removing drawers
WARNING!
Two top compartments are rotating flaps
with fixed glass shelves. Do not remove
them as you could damage them.
To remove a drawer from a compartment:
1. Pull the drawer out until it stops.
2. Once you reach the end of the runners,
lift slightly the front of the drawer and
remove it from the appliance.
To put the drawer into a
compartment, follow the above steps in
reverse order.
5.2 Freezing fresh food
The freezer compartment is suitable for
freezing fresh food and storing frozen and
deep-frozen food for a long time.
To freeze fresh food activate the Extra
Freeze function at least 24 hours before
placing the food to be frozen in the freezer
compartment.
Store the fresh food evenly distributed in the
first and second compartment or drawer from
the top.
The maximum amount of food that can be
frozen without adding other fresh food during
24 hours is specified on the rating plate (a
label located inside the appliance).
When the freezing process is complete, the
appliance automatically returns to the
previous temperature setting (see "Extra
Freeze function").
For more information refer to "Hints for
freezing".
5.3 Storage of frozen food
When activating an appliance for the first time
or after a period out of use, before putting the
products in the compartment let the appliance
run at least 3 hours with the Extra Freeze
function switched on.
The freezer drawers ensure that it is quick
and easy to find the food package you want.
If large quantities of food are to be stored,
remove all drawers and place the food on
shelves.
Keep the food no closer than 15 mm from the
door.
CAUTION!
In the event of accidental defrosting, for
example due to a power failure, if the
power has been off for longer than the
value shown on rating plate under "rising
time", the defrosted food must be
consumed quickly or cooked immediately
then cooled and then re-frozen. Refer to
"High temperature alarm".
5.4 Thawing
Deep-frozen or frozen food, prior to being
consumed, can be thawed in the refrigerator
or inside a plastic bag under cold water.
This operation depends on the time available
and on the type of food. Small pieces may
even be cooked still frozen.
5.5 Ice-cube production
This appliance is equipped with one or more
trays for the production of ice-cubes.
Do not use metallic instruments to
remove the trays from the freezer.
1. Fill these trays with water.
2. Put the ice trays in the freezer
compartment.
6. HINTS AND TIPS
ENGLISH 25
6.1 Hints for energy saving
• The internal configuration of the appliance
is the one that ensures the most efficient
use of energy.
• Do not open the door frequently or leave it
open longer than necessary.
• The colder the temperature setting, the
higher the energy consumption.
• Ensure a good ventilation. Do not cover
the ventilation grilles or holes.
• Make sure that food products inside the
appliance allow air circulation through
dedicated holes in the rear interior of the
appliance.
6.2 Hints for freezing
• Activate Extra Freeze function at least 24
hours before placing the food inside the
freezer compartment.
• Before freezing wrap and seal fresh food
in: aluminium foil, plastic film or bags,
airtight containers with lid.
• For more efficient freezing and thawing
divide food into small portions.
• It is recommended to put labels and dates
on all your frozen food. This will help to
identify foods and to know when they
should be used before their deterioration.
• The food should be fresh when being
frozen to preserve good quality. Especially
fruits and vegetables should be frozen
after the harvest to preserve all of their
nutrients.
• Do not freeze bottles or cans with liquids,
in particular drinks containing carbon
dioxide - they may explode during
freezing.
• Do not put hot food in the freezer
compartment. Cool it down at room
temperature before placing it inside the
compartment.
• To avoid increase in temperature of
already frozen food, do not place fresh
unfrozen food directly next to it. Place food
at room temperature in the part of the
freezer compartment where there is no
frozen food.
• Do not eat ice cubes, water ices or ice
lollies immediately after taking them out of
the freezer. Risk of frostbites.
• Do not re-freeze defrosted food. If the food
has defrosted, cook it, cool it down and
then freeze it.
6.3 Hints for storage of frozen food
• Freezer compartment is the one marked
with .
• Good temperature setting that ensures
preservation of frozen food products is a
temperature less than or equal to -18°C.
Higher temperature setting inside the
appliance may lead to shorter shelf life.
• The whole freezer compartment is suitable
for storage of frozen food products.
• Leave enough space around the food to
allow air to circulate freely.
• For adequate storage refer to food
packaging label to see the shelf life of
food.
• It is important to wrap the food in such a
way that prevents water, humidity or
condensation from getting inside.
6.4 Shopping tips
After grocery shopping:
• Ensure that the packaging is not damaged
- the food could be deteriorated. If the
package is swollen or wet, it might have
not been stored in the optimal conditions
and defrosting may have already started.
• To limit the defrosting process buy frozen
goods at the end of your grocery shopping
and transport them in a thermal and
insulated cool bag.
• Place the frozen foods immediately in the
freezer after coming back from the shop.
• If food has defrosted even partially, do not
re-freeze it. Consume it as soon as
possible.
• Respect the expiry date and the storage
information on the package.
6.5 Shelf life
Type of food Shelf
life
(month
s)
Bread 3
Fruits (except citrus) 6 - 12
Vegetables 8 - 10
Leftovers without meat 1 - 2
26 ENGLISH
Type of food Shelf
life
(month
s)
Dairy food:
Butter 6 - 9
Soft cheese (e.g. mozzarella) 3 - 4
Hard cheese (e.g. parmesan, ched‐
dar)
6
Seafood:
Fatty fish (e.g. salmon, mackerel) 2 - 3
Lean fish (e.g. cod, flounder) 4 - 6
Shrimps 12
Shucked clams and mussels 3 - 4
Type of food Shelf
life
(month
s)
Cooked fish 1 - 2
Meat:
Poultry 9 - 12
Beef 6 - 12
Pork 4 - 6
Lamb 6 - 9
Sausage 1 - 2
Ham 1 - 2
Leftovers with meat 2 - 3
7. CARE AND CLEANING
WARNING!
Refer to Safety chapters.
7.1 Cleaning the interior
Before using the appliance for the first time,
the interior and all internal accessories should
be washed with lukewarm water and some
neutral soap to remove the typical smell of a
brand-new product, then dried thoroughly.
CAUTION!
Do not use detergents, abrasive
powders, chlorine or oil-based cleaners
as they will damage the finish.
CAUTION!
The accessories and parts of the
appliance are not suitable for washing in
a dishwasher.
CAUTION!
Clean the control panel with a moist
cloth. Do not use any detergents. After
cleaning, wipe the control panel dry with
a soft cloth.
7.2 Periodic cleaning
The equipment has to be cleaned regularly:
1. Clean the inside and accessories with
lukewarm water and some neutral soap.
2. Regularly check the door seals and wipe
them clean to ensure they are clean and
free from debris.
3. Rinse and dry thoroughly.
7.3 Defrosting of the freezer
The freezer compartment is frost free. This
means that there is no build up of frost when
it is in operation, neither on the internal walls,
nor on the foods.
7.4 Period of non-operation
When the appliance is not in use for long
period, take the following precautions:
ENGLISH 27
1. Disconnect the appliance from electricity
supply.
2. Remove all food.
3. Clean the appliance and all accessories.
4. Leave the door open to prevent
unpleasant smells.
8. TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
8.1 What to do if...
Problem Possible cause Solution
The appliance does not operate. The appliance is switched off. Switch on the appliance.
The mains plug is not connected
to the mains socket correctly.
Connect the mains plug to the
mains socket correctly.
There is no voltage in the mains
socket.
Connect a different electrical ap‐
pliance to the mains socket. Con‐
tact a qualified electrician.
The appliance is noisy. The appliance is not supported
properly.
Check if the appliance stands
stable.
Acoustic or visual alarm is on. The cabinet has been recently
switched on.
Refer to "High temperature
alarm" or "Door open alarm".
The temperature in the appliance
is too high.
Refer to "High temperature
alarm" or "Door open alarm".
The door is left open. Close the door.
The compressor operates contin‐
ually.
Temperature is set incorrectly. Refer to "Control panel" chapter.
Too much food is put in at the
same time.
Wait a few hours and then check
the temperature again.
The room temperature is too
high.
Refer to "Installation" chapter.
Food placed in the appliance is
too warm.
Allow food to cool to room tem‐
perature before storing.
The door is not closed correctly. Refer to "Closing the door" sec‐
tion.
The Extra Freeze function is
switched on.
Refer to "Extra Freeze function"
section.
28 ENGLISH
Problem Possible cause Solution
The compressor does not start
immediately after pressing the
"Extra Freeze", or after changing
the temperature.
The compressor starts after a pe‐
riod of time.
This is normal, no error has oc‐
curred.
Door is misaligned or interferes
with ventilation grill.
The appliance is not levelled. Refer to installation instructions.
Door does not open easily. You attempted to re-open the
door immediately after closing.
Wait a few seconds between
closing and re-opening of the
door.
There is too much frost and ice. The door is not closed correctly. Refer to "Closing the door" sec‐
tion.
The gasket is deformed or dirty. Refer to "Closing the door" sec‐
tion.
Food is not wrapped properly. Wrap the food properly.
Temperature is set incorrectly. Refer to "Control panel" chapter.
Appliance is fully loaded and is
set to the lowest temperature.
Set a higher temperature. Refer
to "Control panel" chapter.
Temperature set in the appliance
is too low and the ambient tem‐
perature is too high.
Set a higher temperature. Refer
to "Control panel" chapter.
Water flows on the floor. The melting water outlet is not
connected to the evaporative tray
above the compressor.
Attach the melting water outlet to
the evaporative tray.
Temperature cannot be set. The Extra Freeze function is
switched on.
Switch off Extra Freeze function
manually, or wait until it deacti‐
vates automatically. Refer to "Ex‐
tra Freeze function" section.
The temperature in the appliance
is too low/too high.
The temperature is not set cor‐
rectly.
Set a higher/lower temperature.
The door is not closed correctly. Refer to the "Closing the door"
section.
The food is too hot. Let the food cool down before
storage.
Too much food is stored at the
same time.
Store less food at the same time.
The door has been opened often. Open the door only if necessary.
The Extra Freeze function is
switched on.
Refer to the "Extra Freeze func‐
tion" section.
ENGLISH 29
Problem Possible cause Solution
There is no cold air circulation in
the appliance.
Ensure cold air circulation in the
appliance. Refer to the "Hints and
tips" chapter.
Fifth temperature indicator blinks. Communication problem. Contact the Authorised Service
Centre. The cooling system will
continue to keep food cold, but
temperature adjustment will not
be possible.
First or second temperature indi‐
cator blinks.
Temperature sensor problem. Contact the Authorised Service
Centre. The cooling system will
continue to keep food cold, but
temperature adjustment will not
be possible.
If the problem persists, contact the
Authorised Service Centre.
8.2 Closing the door
1. Clean the door gaskets.
2. If necessary, adjust the door. Refer to
installation instructions.
3. If necessary, replace the defective door
gaskets. Contact the Authorised Service
Centre.
9. NOISES
SSSRRR!
CLICK!
HISSS!
BRRR!
BLUBB!
10. TECHNICAL DATA
The technical information is situated in the
rating plate on the internal side of the
appliance and on the energy label.
The QR code on the energy label supplied
with the appliance provides a web link to the
information related to the performance of the
appliance in the EU EPREL database. Keep
30 ENGLISH
the energy label for reference together
with the user manual and all other documents
provided with this appliance.
It is also possible to find the same information
in EPREL using the link
https://eprel.ec.europa.eu
and the model
name and product number that you find on
the rating plate of the appliance.
See the link
www.theenergylabel.eu
for
detailed information about the energy label.
11. INFORMATION FOR TEST INSTITUTES
Installation and preparation of the appliance
for any EcoDesign verification shall be
compliant with EN 62552 (EU). Ventilation
requirements, recess dimensions and
minimum rear clearances shall be as stated
in this User Manual in "Installation". Please
contact the manufacturer for any other further
information, including loading plans.
12. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol . Put the
packaging in relevant containers to recycle it.
Help protect the environment and human
health by recycling waste of electrical and
electronic appliances. Do not dispose of
appliances marked with the symbol with
the household waste. Return the product to
your local recycling facility or contact your
municipal office.
ENGLISH 31
www.smeg.com
222384199-C-472024
