Model: SH-C03/SH-C04
3
1
2
56
8
9
4
7
121110
1. nanoSIM/microSD Tray
2. Front Camera
3. Earpiece or Earpiece/Speaker
4. 3.5mm Earphone Jack
5. Mobile Light
6. Rear Camera
7. Fingerprint Sensor
8. Volume Up/Down key
9. Power Key
10. Speaker
11. USB Type-C Connector
12. Microphone
13. microSD Card
14. nanoSIM Card
13 14
Prevention of Hearing Loss.
Changes or modifications to this product not authorized by the manufacturer could void the
compliance and negate your authority to operate the product.
To prevent hearing damage, do not listen at high volume levels for long periods.
The device battery can not be removed, please do not disassemble.
Do not use the device on board an aircraft. The device’s network signals may cause interference
to the navigation system. As a safety measurement, it is prohibited to use devices on board in
most countries.
It is confirmed that the device has a low SAR.
People having active medical implants should preferably keep the device at least 15 cm away
from the implant.
Turn off the device in areas with a potentially explosive atmosphere or where flammable objects
exist such as gas stations, fuel depots, and chemical plants among others. Sparks from these
areas could cause explosion or fire and result in injury or even death.
Do not use hand-held devices while driving a vehicle. Use hands-free devices as an alternative.
Manufacturer
Assembly company: PT. ADI REKA MANDIRI
Address: Gedung Telesindo Tower Lt.3 Jl. Gajah mada, No. 27 A Krukut
Tamansari Jakarta Barat, DKI Jakarta, Indonesia
Sales company: SHARP SINGAPORE ELECTRONICS CORPORATION PTE. LTD.
Address: 438B Alexandra Road, #06-02, Alexandra Technopark, Singapore 119968
body is 1.30
1.126
GSM 900MHz: 31.6 dBm
GSM 1800MHz: 30.3 dBm
UMTS B1 (2100MHz): 25.5 dBm
UMTS B8 (900MHz): 25.3 dBm
LTE FDD B1/3/7/20/28 (2100/1800/2600/800/700MHz): 24 dBm
LTE FDD B8 (900MHz): 24.5 dBm
LTE TDD B38/40 (2600/2300MHz): 24 dBm
Bluetooth 2.4GHz band: 11.57 dBm
Bluetooth LE 2.4GHz band: -1.53 dBm
802.11 b/g/n 2.4GHz band: 17.66 dBm
NFC 13.56 MHz: -15.12 dBuA/m at 10m
THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE
PERSONAL AND NONCOMMERCIAL USE OF A CONSUMER TO (i) ENCODE VIDEO IN
COMPLIANCE WITH THE AVC STANDARD ("AVC VIDEO") AND/OR (ii) DECODE AVC VIDEO THAT
WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NONCOMMERCIAL
ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED TO PROVIDE AVC
VIDEO.NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL
INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C.SEE HTTP://WWW.MPEGLA.COM
