54-49-9000
SERVICE PARTS LIST
BULLETIN NO.
MILWAUKEE TOOL
l
www.milwaukeetool.com
13135 W. LISBON RD., BROOKFIELD, WI 53005
Drwg. 1
EXAMPLE:
Component Parts (Small #) Are Included
When Ordering The Assembly (Large #).
0
00
48-22-9000 3/8" SAE Socket Set
48-22-9001 3/8" Metric Socket Set
SOCKET SETS
Dec. 2016
REVISED BULLETIN
DATE
CATALOG NO.
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
1
2
3 4 5 6 7 8 9 10 11 12
13 14 15 16 17 18 19 20
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 44-84-0375 3/8" Socket Wrench (1)
2 43-24-0006 6" Extension (1)
3 42-04-3755 3/8"-1/4" Adapter (1)
4 42-04-3750 3/8" Hex Adapter (1)
5 45-34-3125 5/16" Socket (1)
6 45-34-3750 3/8" Socket (1)
7 45-34-4375 7/16" Socket (1)
8 45-34-5000 1/2" Socket (1)
9 45-34-5625 9/16" Socket (1)
10 45-34-6250 5/8" Socket (1)
11 45-34-6875 11/16" Socket (1)
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
12 45-34-7500 3/4" Socket (1)
13 45-34-0010 10mm Socket (1)
14 45-34-0012 12mm Socket (1)
15 45-34-0013 13mm Socket (1)
16 45-34-0014 14mm Socket (1)
17 45-34-0015 15mm Socket (1)
18 45-34-0117 17mm Socket (1)
19 45-34-0118 18mm Socket (1)
20 45-34-0119 19mm Socket (1)
21 42-55-9000 SAE Socket Set Fabric Case (Not Shown) (1)
22 42-55-9001 Metric Set Fabric Case (Not Shown) (1)
