Corded Upright Vacuum
with Lift-Away Technology
& Anti Hair Wrap Brush-Roll
NZ690UK Series
INSTRUCTIONS
sharkclean.co.uk
3sharkclean.co.uk 2 sharkclean.co.uk
Important Safety Instructions � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4
Getting to Know Your Shark®
Vacuum � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 6
Assembly � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 8
Power Cord � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �9
Settings � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 10
Brush-Roll Indicator Light� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 10
Cleaning Modes � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 11
Emptying the Dust Cup � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 12
Maintenance � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 13
Cleaning The Filters � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 13
Nozzle Maintenance � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 13
Cleaning The Brush-Roll � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 13
Checking For Blockages � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 14
Available Accessories � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 15
Troubleshooting Guide � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 16
Guarantee Terms and Conditions � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 17
TECHNICAL SPECIFICATIONS
Voltage: 220-240V~, 50-60Hz
Body Motor Watts: 750W
Nozzle Watts: 80W
TIP: You can find
the model and serial
numbers on the QR
code label located on
the back of your unit.
TIP: You can locate
the date code on one
of the prongs of the
power cordplug.
RECORD THIS INFORMATION
Model Number: ������������������������������
Serial Number �������������������������������
Date Code: ����������������������������������
Date of Purchase (Keep receipt): ����������������
Store of Purchase: ����������������������������
This marking indicates that this product should not be disposed with other
household wastes throughout the UK. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of material sources. To return
your used device, please use the return and collection systems or contact
the retailer where this product was purchased. They can take this product
for environmentally safe recycling.
REGISTER YOUR PURCHASE
TO BENEFIT FROM YOUR PRODUCT'S EXTENDED
GUARANTEE, SIMPLY REGISTER YOUR PURCHASE
AT:
sharkclean.co.uk/register-guarantee
0800 862 0453
Scan QR code using mobile device
THANK YOU
for purchasing the Shark® Corded Upright Vacuum with Lift-Away Technology
& Anti Hair Wrap Brush-Roll�
PLEASE READ CAREFULLY
AND KEEP FOR FUTURE REFERENCE�
This instruction manual is designed to help you get a complete
understanding of your new Shark® Corded Upright Vacuum
with Lift-Away® Technology & Anti Hair Wrap Brush-Roll�
If you have any questions, please call the customer
service line on 0800 862 0453�
Benefits of registering your product and creating
an account:
• Get easier, faster product support and access to
guarantee information
• Access troubleshooting and product care instructions
• Be among the first to know about exclusive product
promotions
Please note, products purchased directly from Shark®
are automatically registered.
CONTENTS
5sharkclean.co.uk 4 sharkclean.co.uk
SAVE THESE INSTRUCTIONS
SAVE THESE INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
SAVE THESE INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
WARNING
REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, INJURY,
OR PROPERTY DAMAGE:
WARNING: Children should be
supervised to ensure that they do
not play with the appliance.
GENERAL WARNINGS
1 Inspect power cord and plug for any
damage before use. DO NOT use vacuum
cleaner with a damaged cord or plug.
Turn o all controls before plugging in
or unplugging the vacuum cleaner. Store
your vacuum cleaner with the power
cord secured around the two cord hooks.
To minimise the risk of power cord
damage, do not allow the motorised
brush-roll to ingest the cord. If this
occurs, immediately shut o power to
the vacuum and remove the cord.
2 Your vacuum cleaner consists of a
motorised nozzle, wand, hose, and/
or vacuum pod. This device contains
electrical connections, electrical wiring,
and moving parts that potentially present
risk to the user.
3 Use only identical replacement parts.
4 Carefully observe and follow the
instructions provided below to avoid
improper use of the appliance. DO NOT
use the vacuum for any purpose other
than those described in this manual.
5 Before use, carefully inspect all parts
for any damage. DO NOT use if any
parts are damaged.
6 The use of an extension cord is NOT
recommended.
7 CAUTION: This vacuum cleaner contains
electrical connections. This vacuum
contains no serviceable parts.
USE WARNINGS
8 This appliance can be used by persons
with reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning
use of the appliance in a safe way and
understand the hazards involved.
9 DO NOT allow the appliance to be used
by children. Keep the appliance and its
cord out of reach of children. Do not
allow to be used as a toy.
Close supervision is necessary when used
near children.
CLEANING AND USE
10 Always turn o the vacuum cleaner
before connecting or disconnecting any
motorised nozzles or other accessories.
11 DO NOT handle plug or vacuum cleaner
with wet hands.
12 DO NOT use without filters in place.
13 Only use Shark
®
branded filters and
accessories. Damage caused by the use
of non-Shark
®
parts may not be covered
by your guarantee.
14 DO NOT damage the power cord:
a) DO NOT pull or carry vacuum cleaner
by the cord or use the cord as a handle.
b) DO NOT unplug by pulling on cord.
Grasp the plug, not the cord.
c) DO NOT run the vacuum cleaner
over the power cord, close a door on
the cord, pull the cord around sharp
corners, or leave the cord near heated
surfaces.
15 DO NOT put any objects into nozzle
or accessory openings. DO NOT use
with any opening blocked; keep free
of dust, lint, hair, and anything that
may reduce airflow.
16 DO NOT use if nozzle or accessory
airflow is restricted. If the air paths
or the motorised floor nozzle become
blocked, turn the vacuum cleaner o
and unplug from electrical socket.
Remove all obstructions before you
plug in and turn on the unit again.
17 Keep nozzle and all vacuum openings
away from hair, face, fingers, uncovered
feet, or loose clothing.
18 DO NOT use if vacuum cleaner
is not working as it should, or
has been dropped, damaged, left
outdoors, or dropped into water.
19 If the supply cord is damaged, it
must be replaced by the manufacturer,
its service agent or similar qualified
persons in order to avoid a hazard.
20 Use extra care when cleaning
on stairs.
21 DO NOT leave the vacuum cleaner
unattended while plugged in.
22 When powered on, keep the vacuum
cleaner moving over the carpet surface
at all times to avoid damaging the
carpet fibres.
23 DO NOT place vacuum cleaner
on unstable surfaces such as chairs
or tables.
24 DO NOT use to pick up:
a) Liquids
b) Large objects
c) Hard or sharp objects
(glass, nails, screws, or coins)
d) Large quantities of dust (drywall dust,
fireplace ash, or embers). DO NOT use
as an attachment to power tools for
dust collection.
e) Smoking or burning objects (hot coals,
cigarette butts, or matches)
f) Flammable or combustible materials
(lighter fluid, petrol, or kerosene)
g) Toxic materials (chlorine bleach,
ammonia, or drain cleaner)
25 DO NOT use in the following areas:
a) Poorly lit areas
b) Wet or damp surfaces
c) Outdoor areas
d) Spaces that are enclosed and may
contain explosive or toxic fumes or
vapours (lighter fluid, petrol, kerosene,
paint, paint thinners, mothproofing
substances, or flammable dust)
Turn o all controls before plugging
in or unplugging the vacuum.
26 Unplug from electrical socket when
not in use and before any maintenance
or cleaning.
27 To clean: Wipe down the unit with water
only. Washing with cleaning chemicals
could damage the unit.
28 During cleaning or routine maintenance,
DO NOT cut anything other than
hair, fibres, or string wrapped around
the brush-roll.
29 Allow all filters to air-dry completely
before replacing in the vacuum to
prevent liquid from being drawn into
electrical parts.
30 Make sure the dust cup and all filters
are in place after routine maintenance.
IMPORTANT SAFETY INSTRUCTIONS
FOR HOUSEHOLD USE ONLY • PLEASE READ ALL INSTRUCTIONS
BEFORE USING THIS VACUUM�
IF YOU HAVE DELICATE OR WOOL CARPETS, PARTICULARLY LOOP PILE,
PLEASE TRY THE VACUUM ON A HIDDEN AREA FIRST TO ENSURE THE
SPINNING BRUSH-ROLLS DO NOT DAMAGE OR UNPICK CARPET FIBRES�
7sharkclean.co.uk 6 sharkclean.co.uk
WELCOME!
Congratulations
on your purchase.
Use this instruction
manual to learn about
your new vacuum’s
great features. From
assembly to use to
maintenance, you will
find it all in here.
L
N
O
MAIN UNIT
A Suction Control Slider
B Handle
C Hose
D Handle Release Button
E Power Switch
F Wand Release Button
G Wand
H Dust-Cup Release Latch
I Lift-Away Pod
J Dust-Cup Empty Buttons
K Lift-Away Pod Button
L Motorised Floor Nozzle
M Brush-Roll Indicator Light
N Headlights
O Anti-Hair Wrap Brush-Roll
GETTING TO KNOW YOUR SHARK® CORDED UPRIGHT VACUUM WITH
LIFT-AWAY TECHNOLOGY AND ANTI HAIR WRAP BRUSH-ROLL�
Wand
Release
A
B
K
E
F
I
C
D
G
H
J
M
9sharkclean.co.uk 8 sharkclean.co.uk
ASSEMBLY ASSEMBLY
Tool Storage Posts
Upper Cord Hook
Lower Cord Hook
POWER CORD
For cord access, rotate upper hook down
and remove cord�
Use cord holder on the side of wand to hold
cord in place while vacuuming�
UPPER CORD HOOK CORD HOLDER
1. Insert Wand into pod
2. Insert Handle into wand�
3. Attach Hose to back of vacuum pod�
(Click)
1
(Click)
2
(Click)
3
NOTE: Ensure all parts firmly CLICK into place before operating�
11sharkclean.co.uk 10 sharkclean.co.uk
Select surface setting:
O Power O
I Hard Floor
For hard floors, small area rugs or
delicate carpets - the brush-roll will spin
but at a slower speed�
II Carpet
For carpets�
NOTE: All accessories are compatible with both the wand and the handle� Included accessories
will vary by model�
NOTE: Brush-Roll will continue to spin in all modes
CLEANING MODES
To engage brush-roll, step on floor nozzle
and tilt handle back firmly�
Step on the pedal on the floor nozzle to lift
o the pod�
WHAT DOES THE BRUSH-ROLL INDICATOR LIGHT MEAN?
Solid Green: The brush-roll is spinning and working as intended�
Solid Red: There is a jam in the brush-roll area� Turn o and unplug the vacuum and remove
any blockages in the nozzle�
Flashing Red: The motorised floor nozzle is overheating� Turn the vacuum o and wait a
minimum of 60 minutes for the unit to cool down�
Press the Wand Release button and pull up on
the wand to detach it from the pod�
Press the Handle Release button and pull up on
the handle to detach it from the wand�
Attach an optional cleaning accessory to
handle or wand�
UPRIGHT MODE LIFT AWAY MODE
POWER/SURFACE SWITCH
INDICATOR LIGHT
ABOVE-FLOOR—WAND
ACCESSORIES—WAND
ABOVE-FLOOR—HANDLE
ACCESSORIES—HANDLE
Wand
Release
SETTINGS
BRUSH-ROLL INDICATOR LIGHT
The Suction Control Slider located on the
handle allows you to adjust the suction
depending on the floor type�
MIN: to reduce suction and increase
manoeuvrability on carpets�
MAX: to increase suction on hard floors�
SUCTION CONTROL
13sharkclean.co.uk 12 sharkclean.co.uk
MAINTENANCE
EMPTYING THE DUST CUP
To remove Dust Cup, pull up on the release
button located on the side of dust cup handle�
Tilt dust cup forward, then lift to remove�
To reattach, place the bottom of dust cup
onto the pod and then tilt until it clicks
into place�
Hold the dust cup over the bin and press the
release button to open bottom of dust cup�
To remove collected debris from Lint Screen,
lift the tab at the top of the dust cup to
open the lid� Remove debris from lint screen
toclean�
Regularly rinse the filters to maintain your vacuum's suction power.
Rinse filters with cold water only� Allow all filters to air-dry for at least 24 hours before
reinstalling them to prevent liquid from being drawn into electronic parts�
IMPORTANT: DO NOT use soap when cleaning the filters�
IMPORTANT: Unplug the power cord before performing any maintenance�
Post-Motor
Filter
Foam
Felt
Filter
Door
RINSE PRE-MOTOR FILTERS
EVERY MONTH
1 Pre-Motor (foam and felt):
With the dust cup removed, take out the
foam and felt filters, and rinse with water� Tap
loose dirt o filters between washes
as needed�
RINSE POST-MOTOR FILTER EVERY YEAR
To remove the Post-Motor Filter, first pull
the tab on the bottom of the filter door, then
lift o the door� Press the tab on the side of
the Post-motor filter�
To reattach the door, align the top first, then
press in the bottom until it clicks into place�
ANTI HAIR WRAP BRUSH-ROLL
If any hair is wrapped around the brush-roll, continue vacuuming using Carpet/Low Pile mode on
a bare floor surface, a low-pile carpet, or a small area rug in MAX suction mode� This will allow
the Anti Hair Wrap brush-roll to remove the hair wrap and send it to the dust cup�
If you run over a hard or sharp object or notice a noise change while vacuuming, check for
blockages or objects caught in the brush-roll�
If some fibres remain wrapped around the brush-roll after continued use, clear them from the
brush-roll�
NOZZLE MAINTENANCE
CLEANING THE FILTERS
15sharkclean.co.uk 14 sharkclean.co.uk
CHECKING FOR BLOCKAGES
MAINTENANCE
Detach handle from wand and
check openings for blockages�
HANDLE BLOCKAGES
Detach hose from handle by
pressing on the release button at
the top of the hose� Detach
the hose from the pod, and
check openings for blockages�
HOSE BLOCKAGES
Detach dust cup from vacuum
pod� Empty dust cup, remove
debris from lint screen, and
check for blockages�
DUST CUP BLOCKAGES
Detach wand from pod and
handle, and check both ends for
blockages�
WAND BLOCKAGES
Check the opening at the
top of the nozzle for any
blockages�
NOZZLE BLOCKAGES
AVAILABLE ACCESSORIES
A
D
C
B
A
Crevice Tool
Clean tight spaces, reach skirting boards
and ceilings with this slim crevice tool�
B
Upholstery Tool
Remove pet hair and dust from curtains and
other delicate fabrics and upholstery�
C
Dusting Brush
Dusts and cleans a multitude of delicate
surfaces�
D
2 in 1 Duster Crevice Tool
Two cleaning tools in one—the crevice tool
gives you extended cleaning reach for small
spaces, while the soft dusting brush cleans
a multitude of surfaces�
E
Pet Power Brush
Picks up pet hair and loose debris, and
powerfully deep cleans dander out of
upholstery and other surfaces�
F
Multi Surface Tool
A single convertible tool for cleaning tough
pet messes two ways: use the sti bristle
brush to clean stuck-on debris, or take o
the bristles to reveal an upholstery tool
perfect for removing stubborn pet hair and
large piles of debris�
NOTE: Not all accessories come with all units� Please refer to the packaging panels for your unit's configuration�
To order additional accessories, visit sharkclean.co.uk�
NOTE: Torch not included�
E
F
IMPORTANT: Unplug the cord before performing any maintenance�
17sharkclean.co.uk 16 sharkclean.co.uk
TROUBLESHOOTING GUIDE
WARNING: To reduce the risk of shock and unintended operation, turn
power o and unplug unit before servicing�
Power cord caught in brush-roll or floor nozzle�
• To minimise the risk of power cord damage, DO NOT run the vacuum over the power
cord. If this occurs, immediately shut o power to the vacuum and remove the cord from
the brush-roll or nozzle.
• Inspect power cord and plug for any damage before use. DO NOT use vacuum cleaner
with a damaged cord or plug. Turn o all controls before plugging in or unplugging the
vacuum cleaner. Store your vacuum cleaner with the power cord secured around the two
cord hooks.
Vacuum is not picking up debris� No suction or light suction�
(Refer to Maintenance section for more information�)
• Check filters to see if they need cleaning. Follow instructions for rinsing and drying the
filters before re-inserting back into the vacuum.
• Dust cup may be full; empty dust cup.
• Check hose, hose connections, nozzles, and accessories for blockages; clear blockages if
required.
• Remove any string, carpet fibres or hair that may be wrapped around the brush-roll.
Vacuum lifts area rugs�
• Turn o the unit to disengage the brush-roll and restart with the POWER button
for suction only cleaning.
• Suction is powerful. Take care when vacuuming area rugs or rugs with delicately
sewn edges.
• Turn o the unit and disengage the area rug from the brush-roll and restart the unit.
Brush-roll does not spin�
• If brush-roll indicator light on the floor nozzle turns red, the brush-roll has stopped
spinning. Immediately turn o and unplug vacuum, disconnect the nozzle and remove
blockage before reconnecting and turning vacuum back on.
• Pull the handle toward you and release the floor nozzle to disengage the
auto-o feature.
• Immediately turn o and unplug vacuum, disconnect the nozzle and remove blockage
before reconnecting and turning vacuum back on.
Vacuum turns o on its own or brush-roll Indicator Light flashes red�
This vacuum cleaner is equipped with a motor protective thermostat. If for some reason
your vacuum overheats, the thermostat will automatically turn the suction motor o. Should
this occur, perform the following steps to restart the thermostat:
1. Turn the unit o.
2. Unplug the vacuum.
3. Empty the dust cup and clean filters (see page previous page)
4. Check for blockages in hose, accessories and inlet openings.
5. Allow the unit to cool for a minimum of 45 minutes.
6. Plug in the vacuum.
7. Restart the unit by turning the power on.
Note: If vacuum still does not start, visit sharkclean.co.uk/customer-care or contact
customer service on: 0800 862 0453.
The Shark Guarantee
When a consumer buys a product in the UK,
they get the benefit of legal rights relating to the
quality of the product (your “legal rights”). You
can enforce your legal rights against your retailer,
including Shark if you bought your appliance from
sharkclean.co.uk. However, at Shark we are so
confident about the quality of our products that
we give the owner an additional, free parts and
labour manufacturer’s guarantee of up to 5 years.
The guarantee it comes with is an important
consideration - and reflects how much
confidence the manufacturer has in its
product and manufacturing quality.
The manufacturer’s guarantee does
not aect your legal rights.
How long are new Shark
machines guaranteed for?
Our manufacturer’s guarantee lasts for
one year from the date of purchase as
standard, or for five years if you register
your purchase with us within 28 days.
How do I register my Shark guarantee?
If you have purchased your Shark appliance
directly from sharkclean.co.uk your guarantee
is registered automatically. If you bought it from
anywhere else in the UK, you can register your
guarantee online within 28 days of purchase.
• To register online, please visit sharkclean.
co.uk/register-guarantee or scan the
QR code in your instruction booklet.
• Keep a note of the date you
purchased the machine.
IMPORTANT:
• Keep your receipt if you bought your Shark
appliance from anywhere except sharkclean.co.uk.
You will need it to claim under your guarantee.
• The free Shark guarantee only applies in the UK.
What are the benefits of registering
my free Shark guarantee?
When you register your guarantee, you will
get an extra four years of cover. We’ll also
have your details to hand if we ever need to
get in touch. If you further agree to receive
communications from us, you can also receive
tips and advice on how to get the best out of
your Shark appliance and hear the latest news
about new Shark technology and launches.
What is covered by the
free Shark guarantee?
Repair or replacement (at Shark’s discretion) of
your Shark machine, including all parts and labour.
What is not covered by
the free Shark guarantee?
• Normal wear and tear.
• Accidental damage or faults caused by negligent
use or care, misuse, neglect, careless operation
or handling of the Shark appliance which is
not in accordance with the Shark Operating
Manual supplied with your machine.
• Damage caused by use of the Shark
appliance for anything other than normal
domestic household purposes.
• Damage caused by use of parts not
assembled or installed in accordance
with the operating instructions.
• Damage caused by use of parts and accessories
which are not Shark Genuine Components
• Faulty installation (except where
installed by Shark).
• Repairs or alterations carried out by
parties other than Shark or its agents.
How can I claim under
the free Shark guarantee?
Contact our customer service helpline on 0800 862
0453. For service hours please visit our website
under ‘Contact Us’. It’s free to call, and you’ll be
put straight through to a Shark representative.
You’ll also find online support at support.
sharkclean.co.uk. The Shark representative will
go through some troubleshooting with you, and
if we conclude that the item has failed, we will
send you a replacement part or a returns label
to send the defective item back to us free of
charge. When you have delivered the defective
product to us, we will send you a replacement.
Please remember that the item will need
to be boxed when you return it to us.
It can be any suitable box, it does not
have to be the original packaging.
Where can I buy genuine
Shark spares and accessories?
Shark spares and accessories are developed by
the same engineers who developed your Shark
appliance. You’ll find a full range of Shark spares,
replacement parts and accessories for all Shark
machines at sharkclean.co.uk. Please remember
that damage caused by the use of non-Shark
spares may not be covered under your guarantee.
FIVE (5)YEAR LIMITED GUARANTEE
19sharkclean.co.uk 18 sharkclean.co.uk
NOTESNOTES
Illustrations may dier from actual product. We are constantly striving to improve
our products, therefore the specifications contained herein are subject to change
withoutnotice.
LIFT-AWAY and SHARK are registered trademark of SharkNinja Operating LLC in the
United Kingdom.
© 2024 SharkNinja Operating LLC
NZ690UKSeries�66�IB�MP�240221�Mv2
@sharkcleaninguk
@sharkcleanuk
@sharkcleanuk
SharkNinja Europe Limited,
1st/2nd Floor Building 3150,
Thorpe Park, Century Way,
Leeds, England, LS15 8ZB, UK
+44 (0)800 862 0453
www�sharkclean�co�uk
SharkNinja Germany GmbH,
Rotfeder-Ring-9,
60327 Frankfurt am Main,
Germany
www�sharkclean�eu
