JC Xenon Halogen Replacement Lamp,
2-Card
Specification Sheet
Physical Characteristics
Finish .................................................... Clear
Base ...................................................... G4
MOL ...................................................... 1.19"
Item Number 06216
Specifications
Energy Used (Watts) ............................... 10
Domestic Code ....................................... 10T3X 2CD
Volts ...................................................... 12
Filament Type ........................................ C6
Light Center Length (LCL) ....................... 7/8"
Light Appearance (Kelvin) ...................... 2900
Brightness (Lumens) .............................. 100
Average Rated Hours .............................. 5000
Life (in years)*....................................... 4.6
Estimated Yearly Energy Cost**............... $1.20
Country of Origin ................................... China
Warning
DO NOT TOUCH INNER CAPSULE WITH BARE HANDS (use clean gloves, cloth or tissue when handling). Contact with skin oils may result in shorter lamp life.
Remove oils from lamp with alcohol.
The inner capsule of this lamp is pressurized and could shatter, use only in fixtures that provide a protective shield of tempered glass. Use only in fixtures
rated for specified lamp type and voltage. Do not exceed the maximum wattage rating of the fixture. Do not use if outer glass is scratched or broken since
it may break during operation or removal. This lamp gets extremely hot during operation. To avoid risks of burns or other injury, turn power off and allow
lamp to fully cool before attempting to replace. To avoid the possibility of fire, do not operate lamp close to materials that are negatively affected by heat.
Socket condition may affect lamp life. Inspect and replace socket if deterioration has occurred. FOR INDOOR OR OUTDOOR USE. A weather-protected fixture
is recommended for damp locations.
2014 WESTINGHOUSE LIGHTING / 0414 / 103948
Call 1-800-999-2226 or visit www.westinghouselighting.com.
Westinghouse Lighting, Philadelphia, PA 19154-1029, U.S.A. Westinghouse Lighting, a Westinghouse Electric Corporation licensee
“Westinghouse” and “You can be sure...if it’s Westinghouse” are all registered trademarks of Westinghouse Electric Corporation.
* Based on 3 hrs./day
* * Based on 3 hrs./day 11¢/kWh - Cost depends on rates and use.
