PLMRBT65B
PLMRBT65W
Questions or Comments?
We are here to help!
Phone: 1.718.535.1800
PyleUSA.com/ContactUs
Visit Our Website
SCAN ME
PyleUSA.com
USER GUIDE
Dual 6.5’’ Water-Resistant Bluetooth
Marine Speakers
PLMRBT65W - PLMRBT65B
www.PyleUSA.com2 www.PyleUSA.com 3
READ ALL INSTRUCTIONS CAREFULLY BEFORE USING THIS PRODUCT.
RETAIN THIS OWNER’S MANUAL FOR FUTURE REFERENCE.
Features:
• Includes (2) 6.5'' Coaxial Speakers (Active + Passive)
• Bluetooth Wireless Music Streaming Ability
• Marine Grade Construction
• Water-Resistant & Weatherproof Design
• Amplied Master Speaker with Built-in 2-Ch. Digital Amplier
• 2-Way Active Powered Speaker System
• Impressive Wide-Bass Response
• Full Range Stereo Sound Reproduction
• Universal Standard OEM Replacement Size
• Ability to Connect External Devices
• RCA Audio Aux (L/R) Connectors
• Hassle-Free Easy Access Speaker Terminals
• Daisy-Chain Ability (Active to Passive Speaker) as Stereo System
• Reinforced Surround with Dense Speaker Cone
• Rugged Machined Basket & Grill with UV Resistant Housing
• Used For Car, Boat, O-Road & Marine Vehicle Applications
What’s in the Box:
• (1) 6.5’’ -inch Active Speaker
• (1) 6.5’’ -inch Passive Speaker
• (2) Speaker Connection Wires, 9.8’ ft.
• Cut-Out Template
• Mounting Screws
Bluetooth Connectivity:
• Receiver Built-into Active / Master Speaker
• Allows Instant Wireless Music Streaming
• Simple Setup & Hassle-Free Pairing Ability
• Works with All of Today’s Latest Devices (Smartphones, Tablets, Laptops, Computers)
• Bluetooth Version: 4.2
• Bluetooth Network Name: ‘PyleUSA’
• Wireless Range: 30’+ ft.
Sizes / Dimensions:
• Total Diameter: 6.9’’ -inches
• Cut-Out Diameter: 6.75’’ –inches
• Total Depth: 3.97’’ -inches
• Active Speaker Mounting Depth: 3.1’’ -inches
• Passive Speaker Mounting Depth: 2.3’’ -inches
Technical Specs:
• Power Output: 600 Watt MAX (300 Watt RMS)
• Marine Grade Rating: IP-X4
• Speaker Composition: Polypropylene Cone, Butyl Rubber Surround
• Voice Coil: 1.0'', Aluminum (x2)
• Tweeters: 0.5'', Neodymium Dome (x2)
• Impedance: 4 Ohm
• Sensitivity: 90 dB
• Circuit Magnet: 20 oz.
• Frequency Response: 85Hz-20kHz
• Input Voltage: 12V
• Active Speaker Weight: 1.56 lbs.
• Passive Speaker Weight: 1.34 lbs.
FCC INFORMATION
WARNING: Changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This unit generates, uses, and
can radiate radio frequency energy, and if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
o and on, the user is encouraged to try and correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit dierent from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operation.
California Prop 65 Warning
WARNING:
This product may expose you to chemicals, which is known to
the state of California to cause cancer, birth defects and other
reproductive harm. Do not ingest.
For more info go to: www.P65warnings.ca.gov
www.PyleUSA.com4 www.PyleUSA.com 5
Ways to Connect
Bluetooth Connection
Connect the active speaker to a power source using a 12V cable.
Once connected, a red light will illuminate on the active speaker.
It is recommended to install a power switch and a 10-amp fuse between the
power source and the active speaker. Enable Bluetooth on your phone or tablet
and select the Bluetooth connection name ‘PyleUSA’. Upon successful connection,
you will hear a connection tone and a blue light will illuminate on the active
speaker. Conversely, when Bluetooth is disconnected, a disconnection tone will
play and the red light will illuminate again on the active speaker.
Using the Included Speaker Wire for Daisy Chain Connection
Use the included speaker wire to create a daisy chain connection between the
active and passive speakers to complete the stereo system.
RCA Low-Level Input (AUX-IN)
The RCA low-level input allows you to use any AUX-IN source when the Bluetooth
feature is disconnected. When using the AUX-IN feature, the active speaker will
display a green light. When Bluetooth is connected, the Bluetooth signal takes
priority and dominates the audio system.
Optional ‘RCA Output’ for System Expansion
The optional ‘RCA Output’ allows you to connect and expand your audio system.
Additional speaker pairs can receive an audio signal via the Low-Level Input.
On the added active speaker, turn o Bluetooth to prevent connection
conicts. The daisy chain connection between the active and passive speaker in
the added pair works the same way as described in point 2 above. The active
speaker in the added system will show a green light when using RCA/AUX
input. You can use ‘RCA Output’ and ‘Low-Level Input’ to add multiple speaker
pairs, creating an optimal audio system for dierent areas.
Installation
LED INDICATOR
Status
POWER ON
RCA/AUX-IN
Bluetooth Connection
Active Speaker
BLUE
GREEN
RED
“ Bluetooth
Pairing Tone”
1.“Turn on Bluetooth”
2.“Choose PyleUSA”
I
II
III
Active Speaker
RCA Output
to added
Audio System
Audio Signal
AUX-IN
Passive Speaker
WARNING
Don’t mistakenly
connect power wire
into Passive Speaker
Terminal Input to avoid
damage to the speaker
Register Product
Thank you for choosing PyleUSA. By registering your product,
you ensure that you receive the full benets of our exclusive
warranty and personalized customer support. Complete the
form to access expert support and to keep your PyleUSA
purchase in perfect condition.
Start Here
Model Number:
PLMRBT65W
PyleUSA.com/pages/register
