EN
BLANCOCULINA II Mini
WARNING
Magnetic Field.
Can be harmful to
pacemaker wearers.
Pacemaker wearers
stay back 25 cm (10 in).
max.
70°C
158°F
temperature
5 - 71°C
(40 - 160°F)
pressure
1.4 - 8.6 bar
(20 - 125 psi)
After installation, please
pass these instructions
on to the end customer.
BLANCO CANADA INC. and BLANCO AMERICA INC. are subject to the terms below
pleased to offer a:
• Limited Lifetime Warranty with all BLANCO faucets used in interior single-family
domestic installations;
• Limited 10 Year Warranty with all BLANCO faucets used in interior multi-residential
and rental housing installations; and
• Limited 5 Year Warranty with all BLANCO faucets used for commercial purposes in
interior installations.
BLANCO warrants its faucets to be free from all proven manufacturing defects in
material and workmanship. BLANCO will repair or replace at no charge, excluding
labor and freight, any faucet supplied by BLANCO that is proven to be defective
under normal use.
LIMITED WARRANTY FOR COMPONENTS SUBJECT TO ORDINARY WEAR AND TEAR
• Limited 10 Year Warranty for all (i) mechanical components such as handles, cartridges,
sprayheads, spray hoses, aerators and (ii) electronic faucets and components (batteries
are excluded) used in interior single-family domestic installations and interior multi-
residential and rental housing installations.
• Limited 5 Year Warranty for all (i) mechanical components such as handles, cartridges,
spray heads, spray hoses, aerators and (ii) electronic faucets and components
(batteries are excluded) used for commercial purposes in interior installations.
WARRANTY EXCLUSIONS AND OTHER TERMS
BLANCO shall not be liable in case of: (A) improper installation or modication,
damages resulting from abuse, such as heavy impact or dropped objects, improper
care or maintenance, improper applications (such as exposure to corrosive chemicals,
photographic solutions, etc.), and any modications made to the product after it left
BLANCO premises; (B) wear and tear, including chips, scratches and stains that can
occur under normal use; or (C) loss or damage to any person or property whatsoever
resulting from a defective product.
All transportation costs to and from the point of purchase, labor, removal and reinstallation
will be the responsibility of the purchaser.
For greater clarity, accessories that accompany the sink (strainers, waste ttings, waste
chutes etc.) are under separate product-specic warranties.
TO THE EXTENT NOT PROHIBTED BY LAW, NO OTHER WARRANTY, WHETHER
EXPRESS, IMPLIED, OR STATUTORY, INCLUDING ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE SHALL BE
DEEMED TO EXIST IN CONNECTION WITH ANY OF THE GOODS OR SERVICES
SUPPLIED HEREUNDER, AND ALL IMPLIED WARRANTIES, INCLUDING ANY
IMPLIED WARRANTIES FOR A PERIOD GREATER THAN THE WARRANTY PERIOD
CONTAINED IN BLANCO‘S LIMITED WARRANTY, ARE HEREBY EXCLUDED.
BLANCO SHALL NOT BE LIABLE FOR ANY INDIRECT, INCIDENTAL, SPECIAL
OR CONSEQUENTIAL DAMAGES IN ANY WAY RELATED TO THE GOODS OR
SERVICES SUPPLIED HEREUNDER. THE REMEDIES DESCRIBED IN THIS
WARRANTY ARE YOUR SOLE AND EXCLUSIVE REMEDIES AND OUR ENTIRE
LIABILITY FOR ANY BREACH OF THIS WARRANTY.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO
HAVE OTHER RIGHTS WHICH VARY FROM JURISDICTION TO JURISDICTION.
SOME PROVINCES, STATES OR OTHER JURISDICTIONS DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF IMPLIED WARRANTIES OR OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS OR EXCLUSIONS
RELATING TO IMPLIED WARRANTIES, OR INCIDENTAL OR CONSEQUENTIAL
DAMAGES MAY NOT APPLY TO YOU.
This warranty applies only to the products sold and installed in Canada and the U.S.A.
Blanco Canada Inc. will be responsible for this warranty for products sold and installed
in Canada and Blanco America, Inc. will be responsible for this warranty for products
sold and installed in the U.S.A. This warranty supersedes all previous warranties for
any BLANCO sink, faucet, accessory, soap dispenser, and repair part in the U.S.A
and Canada. This is BLANCO‘s exclusive written warranty and the warranty is not
transferable without the prior written consent of Blanco, in its sole and absolute
discretion.
--------------------------------------------------------------------------------------------------------------------------------
To obtain warranty service, please visit the support section
on our website www.blanco.com.
--------------------------------------------------------------------------------------------------------------------------------
124 825 10/2023
Rotates 180°
180°
Ø1 7/8"
Ø1 5/16"
6 11/16"
17 3/8"
9 7/16"
4 3/16"
3 3/16"
2 1/2"
8 1/16"
2 11/16"
3/16"
100°
max. 1 15/16"
BLANCO America Inc.
110 Mount Holly Bypass,
Lumberton, New Jersey 08048
Toll free phone: 1-800-451-5782
Toll free fax: 1-800-213-1963
www.blanco.com
BLANCO Canada Inc.
100 Corporation Drive
Brampton, Ontario L6S 6B5
Toll free phone: 1-877-425-2626
Toll free fax: 1-877-825-2626
BLANCOCULINA II Mini
Tools needed:
-Adjustable wrench
-Channel lock pliers
VERKLEINERUNG 97%
links: Perlator zum Daten sparen :-)
Bitte den Perlator in der Abb. 1 so
in vielen Einzelteilen darstellen.
1
BLANCOCULINA II Mini
Secure faucet to sink/countertop using
mounting hardware (10).
The proper sequence of hardware is:
- triangular reinforcement base,
- rubber washer,
- metal washer,
- mounting nut.
3
Turn the faucet on and let the water run for
at least 20 seconds to ensure the lines and
the faucet are ushed.
Before connecting supply lines to the
water valves, ush each water valve to
remove dirt and particles that can affect
the functioning of the faucet and void
warranty.
4
Remove aerator (8) using the
aerator key (9).
Turn the water off.
Reinstall the aerator.
Double check all connections for leaks.
Connect red supply line to hot water valve
and blue supply line to cold water valve.
Hold line while tightening nut to prevent
line from twisting. Do not over tighten.
5
Open water valves slowly.
INSTALLATION
Place faucet through 1 3/8" hole.
Make sure that the sealing ring on
the upper sink/countertop side
is in its correct position.
Ø 1 3/8"
max. 1 15/16"
2
6
8
min. 20 sec.
10
9
5
13
6
11
12
10
7
8
9
4
3
2
1
Tools needed:
- Adjustable wrench
- Channel lock pliers
7
11
