/05_8239 210 98393
DVD VIDEO PLAYER
DVP630 • DVP632
DVD
PLAYER
DVD
PLAYER
01-36 DVP630_EU_051 18/03/2004, 10:04 AM1
/05_8239 210 98393
Important notes for users in the
U.K.
Mains plug
This apparatus is fitted with an approved 13
Amp plug. To change a fuse in this type of plug
proceed as follows:
1 Remove fuse cover and fuse.
2 Fix new fuse which should be a BS1362 5 Amp,
A.S.T.A. or BSI approved type.
3 Refit the fuse cover.
If the fitted plug is not suitable for your jack
outlets, it should be cut off and an appropriate
plug fitted in its place.
If the mains plug contains a fuse, this should
have a value of 5 Amp. If a plug without a fuse
is used, the fuse at the distribution board
should not be greater than 5 Amp.
Note: The severed plug must be disposed to
avoid a possible shock hazard should it be
inserted into a 13 Amp jack elsewhere.
How to connect a plug
The wires in the mains lead are coloured with
the following code: blue = neutral (N),
brown = live (L).
¶ As these colours may not correspond with the
colour markings identifying the terminals in
your plug, proceed as follows:
– Connect the blue wire to the terminal
marked N or coloured black.
– Connect the brown wire to the terminal
marked L or coloured red.
– Do not connect either wire to the earth
terminal in the plug, marked E (or e) or
coloured green (or green and yellow).
Before replacing the plug cover, make certain
that the cord grip is clamped over the sheath
of the lead - not simply over the two wires.
Copyright in the U.K.
Recording and playback of material may
require consent. See Copyright Act 1956 and
The Performer’s Protection Acts 1958 to 1972.
CAUTION
Use of controls or adjustments or
performance of procedures other
than herein may result in hazardous
radiation exposure or other unsafe
operation.
VAROITUS
Muiden kuin tässä esitettyjen
toimintojen säädön tai asetusten
muutto saattaa altistaa vaaralliselle
säteilylle tai muille vaarallisille
toiminnoille.
CAUTION
VISIBLE AND INVISIBLE LASER
RADIATION WHEN OPEN.
AVOID EXPOSURE TO BEAM.
ADVARSEL
SYNLIG OG USYNLIG
LASERSTRÅLING VED ÅBNING
UNDGÅ UDSÆTTELSE FOR STRÅLING
VARNING
SYNLIG OCH OSYNLIG
LASERSTRÅLNING NÄR DENNA DEL
ÄR ÖPPNAD BETRAKTA EJ STRÅLEN
VARO!
AVATTAESSA OLET ALTTIINA
NÄKYVÄLLE JA NÄKYMÄTTÖMÄLLE
LASER SÄTEILYLLE. ÄLÄ KATSO
SÄTEESEEN
VORSICHT
GEFAHR VON SICHTBARER UND
UNSICHTBARER LASERSTRAHLUNG
BEI GEÖFFNETEM GEHÄUSE.
ATTENTION
RAYONNEMENT LASER VISIBLE ET
INVISIBLE EN CAS D’OUVERTURE
EXPOSITION DANGEREUSE AU
FAISCEAU
01-36 DVP630_EU_051 18/03/2004, 10:04 AM2
/05_8239 210 98393
DK
Advarsel: Usynlig laserstråling ved
åbning når sikkerhedsafbrydere er ude
af funktion. Undgå utsættelse for
stråling.
Bemærk: Netafbryderen er sekundært
indkoblet og ofbryder ikke strømmen
fra nettet. Den indbyggede netdel er
derfor tilsluttet til lysnettet så længe
netstikket sidder i stikkontakten.
S
Klass 1 laseraparat
Varning! Om apparaten används på
annat sätt än i denna bruksanvisning
specificerats, kan användaren utsättas
för osynlig laserstrålning, som
överskrider gränsen för laserklass 1.
Observera! Stömbrytaren är sekundärt
kopplad och bryter inte strömmen från
nätet. Den inbyggda nätdelen är
därför ansluten till elnätet så länge
stickproppen sitter i vägguttaget.
SF
Luokan 1 laserlaite
Varoitus! Laitteen käyttäminen muulla
kuin tässä käyttöohjeessa mainitulla
tavalla saattaa altistaa käyttäjän
turvallisuusluokan 1 ylittävälle
näkymättömälle lasersäteilylle.
Oikeus muutoksiin varataan. Laite ei
saa olla alttiina tippu-ja roiskevedelle.
Huom. Toiminnanvalitsin on kytketty
toisiopuolelle, eikä se kytke laitetta irti
sähköverkosta. Sisäänrakennettu
verkko-osa on kytkettynä
sähköverkkoon aina silloin, kun pistoke
on pistorasiassa.
Due to the inconsistency of disc formats
provided by various disc manufacturers, your
DVD system may require a playability
enhancement or upgrade. As DVD technology
advances, these enhancements will become
common and will be easy to complete.
Go to www.p4c.philips.com for software
upgrade.
‘CONSUMERS SHOULD NOTE THAT NOT
ALL HIGH DEFINITION TELEVISION SETS
ARE FULLY COMPATIBLE WITH THIS
PRODUCT AND MAY CAUSE ARTIFACTS
TO BE DISPLAYED IN THE PICTURE. IN
CASE OF 525 OR 625 PROGRESSIVE SCAN
PICTURE PROBLEMS, IT IS RECOMMENDED
THAT THE USER SWITCH THE
CONNECTION TO THE ‘STANDARD
DEFINITION’ OUTPUT. IF THERE ARE
QUESTIONS REGARDING OUR TV SET
COMPATIBILITY WITH THIS MODEL 525p
AND 625p DVD PLAYER, PLEASE CONTACT
OUR CUSTOMER SERVICE CENTER.’
The apparatus shall not be exposed to dripping
or splashing and that no objects filled with
liquids, such as vases, shall be placed on
apparatus.
01-36 DVP630_EU_051 18/03/2004, 10:04 AM3
/05_8239 210 98393
General Information
CAUTION
(WARNING LOCATION: ON THE
BACKPLATE OF THE SET)
NEVER MAKE OR CHANGE
CONNECTIONS WITH THE
POWER SWITCHED ON.
This DVD player is in conformity
with the EMC directive and low-
voltage directive.
Manufactured under license from Dolby
Laboratories. “Dolby”, “Pro Logic” and the
double-D symbol are trademarks of Dolby
Laboratories.
Laser safety
This unit employs a laser. Due to possible
eye injury, only a qualified service person
should remove the cover or attempt to
service this device.
NOTE:
PICTURES SHOWN MAYBE
DIFFERENT BETWEEN
COUNTRIES.
LASER
Type Semiconductor laser
GaAlAs
Wave length 650 nm (DVD)
780 nm (VCD/CD)
Output Power 7 mW (DVD)
10 mW (VCD/CD)
Beam divergence 60 degree
For Customer Use:
Read carefully the information located at
the bottom of your DVD VIDEO player
and enter below the Serial No. Retain this
information for future reference.
Model No. DVD VIDEO 630 • 632
Serial No. _______________
Environmental Information
All unnecessary packaging has been
omitted. The packaging has been made
easy to separate into three materials:
cardboard (box), polystyrene foam
(buffer) and polyethylene (bags, protective
foam sheet).
Your DVD player consists of materials
which can be recycled and reused if
disassembled by a specialised company.
Please observe the local regulations
regarding the disposal of packaging
materials, exhausted batteries and old
equipment.
Important Note:
Due to the numerous versions of new
CD-Audio copy protection or
enhanced CD-Audio protection
recently available on certain discs,
Philips is unable to guarantee that
this DVD Player is fully compatible
with such new discs. Should you have
difficulty playing any such CD-Audio
discs, kindly refer them to your CD-
Audio disc retailer.
DivX, DivX Certified, and
associated logos are
trademarks of
DivXNetworks, Inc and
are used under license.
01-36 DVP630_EU_051 18/03/2004, 10:04 AM4
/05_8239 210 98393
5
Introduction
Supplied accessories ....................................... 6
Care and safety information .......................... 6
Connections
Connecting TV .............................................. 7-9
Using RGB jack ............................................... 7
Using Composite Video jacks (CVBS)........ 7
Using S-Video jack .......................................... 8
Using Component Video jacks (Pr Pb Y) ... 8
Using an accessory RF modulator .............. 9
Connecting the power cord.......................... 9
Optional : Connecting to an Audio System .
........................................................................... 10
Stereo system has Dolby Pro Logic or Right
/ Left Audio In jack ....................................... 10
Optional: Connecting Digital AV Receiver ...
........................................................................... 10
Receiver has a PCM, Dolby Digital, or
MPEG2 decoder............................................ 10
Functional Overview
Front and Rear Panels .................................. 11
Remote Control ............................................ 12
Getting Started
Step 1: Inserting batteries into the
Remote Control ............................................ 13
Using the Remote Control to operate the
Player ............................................................... 13
Step 2: Setting up the TV ........................ 13-14
To deactivate Progressive manually ... 13-14
Selecting the colour system that
corresponds to your TV.............................. 14
Step 3: Setting language preference ........... 15
Setting the OSD Language.......................... 15
Setting the Audio, Subtitle and Disc menu
language .......................................................... 15
Disc Operations
Playable Discs ................................................. 16
Region Codes .................................................16
Playing discs ..................................................... 17
Using the Disc Menu..................................... 17
Basic playback controls........................... 17-19
Pausing playback ............................................ 17
Selecting track/chapter ................................ 17
Mute ................................................................ 18
Resuming playback from the last stopped
point ................................................................ 18
Zoom .............................................................. 18
Repeat ............................................................. 18
Repeat A-B ..................................................... 18
Display ............................................................. 19
Slow Motion .................................................. 19
Searching......................................................... 19
Programme playback .................................... 19
Special DVD features .................................... 20
Playing a Title ................................................. 20
Camera Angle ................................................ 20
Changing the Audio Language .................... 20
Subtitles .......................................................... 20
Special VCD & SVCD Features ............. 20-21
Playback Control (PBC) .............................. 20
Preview .................................................... 20-21
Playing MP3/DivX/MPEG-4/JPEG ......... 21-22
General Operation ................................ 21-22
Playback selection ......................................... 22
Special MP3/JPEG/DivX features ................ 22
Preview Function (JPEG) ............................. 22
Zoom picture (JPEG) ................................... 22
Playback with multi-angles (JPEG) ............. 22
Scan Effect (JPEG) ......................................... 22
Playback speed control (MP3) ................... 22
JPEG and MP3 simultaneous playback ...... 22
DVD Menu Options
Basic Operations ........................................... 23
General Setup menu ...............................23-25
Screen Saver .................................................. 23
Smart Power .................................................. 23
Disc Lock........................................................ 24
Program .......................................................... 24
Program ................................................... 24-25
Audio Setup Menu ................................... 25-27
DOWNMIX ................................................... 25
Digital Output ............................................... 25
LPCM Output ................................................ 26
Sound Mode ................................................... 26
Reverb Mode ................................................. 26
DRC................................................................. 27
Video Setup Menu ................................... 27-29
TV Display ...................................................... 27
Close Caption ............................................... 28
Video Out ...................................................... 28
Progressive ............................................... 28-29
Smart Picture ................................................. 29
Preference Setup Menu .......................... 29-31
Parental ........................................................... 30
Password ..................................................30-31
Default............................................................. 31
MP3/JPEG Nav ............................................... 31
Troubleshooting ......................... 32–33
Specifications ...................................... 34
Glossary ...................................................................... 35
Contents
01-36 DVP630_EU_051 18/03/2004, 10:04 AM5
/05_8239 210 98393
6
Supplied accessories
Introduction
Care and safety information
● Power consumption
– When the system is switched to
Standby mode, it is still consuming power.
To disconnect the system from the power
supply completely, remove the AC power
plug from the wall jack.
● Avoid high temperatures, moisture,
water and dust
– Do not expose the player, batteries or
discs to humidity, rain, sand or excessive
heat (caused by heating equipment or
direct sunlight.)
● Avoid condensation problem
– The lens may cloud over when the
player is suddenly moved from cold to
warm surroundings, making it impossible
to play a disc. Leave the player in the
warm environment until the moisture
evaporates.
● Do not block the vents
– Do not operate the DVD Player in an
enclosed cabinet, allow about 10 cm (4
inches) of free space all around the player
for adequate ventilation.
10 cm
(4 inches)
10 cm
(4 inches)
10 cm
(4 inches)
DVD Home Cinema System
PHILIPS
● Care of the cabinet
– Use a soft cloth slightly moistened with
a mild detergent solution. Do not use a
solution containing alcohol, spirits,
ammonia or abrasives.
● Finding a suitable location
– Place the player on a flat, hard, and
stable surface.
● Disc handling
–To clean a CD, wipe it in a
straight line from the center
towards the edge using a soft,
lint-free cloth. A cleaning
agent may damage the disc!
– Write only on the printed side of a
CDR(W) and only with a soft felt-tipped pen.
– Handle the disc by its edge, do not
touch the surface.
Remote Control
and
two AA batteries
PREVIEW
PREVIEW
MUTE
MUTE
01-36 DVP630_EU_051 18/03/2004, 10:04 AM6
/05_8239 210 98393
7
Connections
Connecting TV
L
R
AUDIO OUT
VIDEO
OUT
S-VIDEO
OUT
PrPb
Y
DIGITAL OUT
COAXIAL OPTICAL
RGB
AUDIO
OUT
S-VIDEO
IN
VIDEO IN
SCART/RGB IN
AUDIO
IN
S-VIDEO
IN
VIDEO IN
SCART/RGB IN
1
IMPORTANT!
–You only need to make
one video
connection from the following
options, depending on the
capabilities of your TV system.
– Connect the DVD system directly
to the TV.
– RGB connection will let you use
the features of both the Audio and
Video in the DVD Player.
Using RGB jack
● Use the RGB cable (black) to connect the
DVD Player’s RGB jack (TV OUT) to the
corresponding Scart input jacks on the TV
(cable not supplied).
Helpful Hint:
– Ensure that the “TV” indication on
RGB cable is connected to the TV set
and “DVD” indication on RGB cable is
connected to the DVD Player.
L
R
AUDIO OUT
VIDEO
OUT
S-VIDEO
OUT
PrPb
Y
DIGITAL OUT
COAXIAL OPTICAL
RGB
AUDIO
IN
V (Pr/Cr)
U (Pb/Cb)
Y
S-VIDEO
IN
VIDEO IN
COMPONENT
VIDEO IN
AUDIO
OUT
V (Pr/Cr)
U (Pb/Cb)
Y
S-VIDEO
IN
VIDEO IN
COMPONENT
VIDEO IN
2
1
Using Composite Video jacks
(CVBS)
1 Use the composite video cable (yellow) to
connect the DVD Player’s CVBS (VIDEO)
jack to the video input jack (or labeled as
A/V In, Video In, Composite or Baseband)
on the TV (cable not supplied).
2 To hear the sound of this DVD Player
through your TV, use the audio cables
(white/red) to connect AUDIO OUT (L/
R) jacks of the DVD Player to the
corresponding AUDIO IN jacks on the TV
(cable not supplied).
01-36 DVP630_EU_051 18/03/2004, 10:04 AM7
/05_8239 210 98393
8
Connections
L
R
AUDIO OUT
VIDEO
OUT
S-VIDEO
OUT
Pr
Pb
Y
DIGITAL OUT
COAXIAL OPTICAL
AUDIO
IN
V (Pr/Cr)
U (Pb/Cb)
Y
S-VIDEO
IN
VIDEO IN
COMPONENT
VIDEO IN
AUDIO
OUT
Pr/Cr
Pb/Cb
Y
S-VIDEO
IN
VIDEO IN
COMPONENT
VIDEO IN
2
1
IMPORTANT!
– Component Video connection
provides higher picture quality. This
option must be available on your TV.
– The progressive scan video
quality is only possible through
Component Video (Y Pb Pr) output.
Using Component Video jacks
(Y Pb Pr)
1 Use the component video cables (red/
blue/green) to connect the DVD system’s
Y Pb Pr jacks to the corresponding
Component video input jacks (or labeled
as Pr/Cr Pb/Cb Y) on the TV (cable not
supplied).
2 To hear the sound of this DVD Player
through your TV, use the audio cables
(white/red) to connect AUDIO OUT (L/
R) jacks of the DVD Player to the
corresponding AUDIO IN jacks on the TV
(cable not supplied).
L
R
AUDIO OUT
VIDEO
OUT
S-VIDEO
OUT
PrPb
Y
DIGITAL OUT
COAXIAL OPTICAL
RGB
AUDIO
IN
V (Pr/Cr)
U (Pb/Cb)
Y
S-VIDEO
IN
VIDEO IN
COMPONENT
VIDEO IN
AUDIO
OUT
Pr/Cr
Pb/Cb
Y
S-VIDEO
IN
VIDEO IN
COMPONENT
VIDEO IN
2 1
IMPORTANT!
– S-Video connection provides
better picture quality. This option
must be available on your TV.
Using S-Video jack
1 Use the S-video cable to connect the
DVD system’s S-VIDEO OUT jack to
the S-Video input jack (or labeled as Y/C
or S-VHS) on the TV (cable not supplied).
2 To hear the sound of this DVD Player
through your TV, use the audio cables
(white/red) to connect AUDIO OUT (L/
R) jacks of the DVD Player to the
corresponding AUDIO IN jacks on the TV
(cable not supplied).
01-36 DVP630_EU_051 18/03/2004, 10:04 AM8
/05_8239 210 98393
9
Connections
IMPORTANT!
–If your TV only has a single
Antenna In jack (or labeled as 75
ohm or RF In,) you will need an RF
modulator in order to view the DVD
playback on the TV. See your
electronics retailer or contact
Philips for details on RF modulator
availability and operations.
Using an accessory RF modulator
1 Use the composite video cable (yellow) to
connect the DVD Player’s CVBS jack to
the video input jack on the RF modulator.
2 Use the RF coaxial cable (not supplied) to
connect the RF modulator to your TV’s
RF jack.
L
R
AUDIO OUT
VIDEO
OUT
S-VIDEO
OUT
PrPb
Y
DIGITAL OUT
COAXIAL OPTICAL
RGB
AUDIO IN
R L
VIDEO
IN
TO TVINT IN
CH3 CH4
2
1
RF coaxial cable to TV
Back of RF Modulator
(example only)
Antenna or
Cable TV signal
L
R
AUDIO OUT
VIDEO
OUT
S
~ AC MAINS
AUDIO
OUT
V (Pr/Cr)
U (Pb/Cb)
Y
S-VIDEO
IN
VIDEO IN
COMPONENT
VIDEO IN
After everything is connected
properly, plug in the AC power cord
to the power outlet.
Never make or change any connections
with the power switched on.
When no disc is loaded, press
STANDBY ON on the DVD Player
front panel,
“NO DISC” may appear on the
display panel.
OPEN/CLOSE
STOP PLAY/PAUSE
Connecting the power cord
NO DISC
01-36 DVP630_EU_051 18/03/2004, 10:04 AM9
/05_8239 210 98393
10
Stereo system has Dolby Pro Logic
or Right / Left Audio In jack
1 Select one of the video connections
(CVBS VIDEO IN or RGB jack (TV
OUT) depending on the options available
on your TV.
2 Use the audio cables (white/red) to
connect AUDIO OUT (L/R) jacks of
the DVD Player to the corresponding
AUDIO IN jacks on the stereo system
(cable not supplied).
3 Set the DVD Player’s Downmix to
‘STEREO’ for simple Right/Left AUDIO IN
or ‘LT/RT’ for Dolby Pro Logic decoding
(see page 25 “Downmix”).
Connections
L
R
AUDIO OUT
VIDEO
OUT
S-VIDEO
OUT
Pr
Pb
Y
DIGITAL OUT
COAXIAL OPTICAL
AUDIO
IN
STEREO
DIGITAL
OPTICAL
Optional: Connecting to an
Audio System
Optional: Connecting Digital AV
Receiver
L
R
AUDIO OUT
VIDEO
OUT
S-VIDEO
OUT
Pr
Pb
Y
DIGITAL OUT
COAXIAL OPTICAL
AUDIO
IN
DIGITAL
OPTICAL
AV Receiver
OR
Receiver has a PCM, Dolby Digital,
or MPEG2 decoder
1 Select one of the video connections
(CVBS VIDEO IN or RGB jack (TV
OUT) depending on the options available
on your TV.
2 Connect the COAXIAL or OPTICAL jack
of the DVD Player to the corresponding
Digital Audio In jack on your Receiver
(cable not supplied).
3 Set the DVD Player’s Digital Output to
PCM-ONLY or ALL depending on the
capabilities of your Receiver (see page 25
“Digital Output”).
Helpful Hint:
– If the audio format of the Digital Output
does not match the capabilities of your
receiver, the receiver will produce a strong,
distorted sound or no sound at all.
01-36 DVP630_EU_051 18/03/2004, 10:04 AM10
/05_8239 210 98393
11
Functional Overview
Front and Rear Panels
RGB
– Connect to RGB input of a TV
OPTICAL (Digital audio out)
– Connect to optical AUDIO input of a
digital audio equipment
COAXIAL (Digital audio out)
– Connect to coaxial AUDIO input of a
digital audio equipment
YPbPr
– Connect to YPbPr input of a TV
STANDBY-ON OPEN/CLOSE
STOP PLAY/PAUSE
STANDBY-ON B
–To switch the DVD Player to Standby
mode or ON
Disc tray
OPEN/CLOSE /
– Open/Close the disc tray
2; PLAY/PAUSE
– To start or interrupt playback
9 STOP
– To stop playback
IR Sensor
– Point the remote control towards this
sensor
Display
– Shows the current status of the DVD
Player
L
R
AUDIO OUT
VIDEO
OUT
S-VIDEO
OUT
PrPb
Y
DIGITAL OUT
COAXIAL OPTICAL
RGB
Mains (AC Power Cord)
– Connect to a standard AC outlet
Audio Out (Left/Right)
– Connect to AUDIO inputs of an amplifier,
receiver or stereo system
S-Video Out
– Connect to S-Video input of a TV
CVBS (VIDEO Out)
– Connect to CVBS Video input of a TV
Caution: Do not touch the inner pins of the jacks on the rear panel.
Electrostatic discharge may cause permanent damage to the unit.
01-36 DVP630_EU_051 18/03/2004, 10:04 AM11
/05_8239 210 98393
12
Functional Overview
Remote Control
PREVIEW MUTE
MUTE
RETURN / TITLE
– To go back to previous menu /
show title menu
DISC MENU
– Enters the disc contents menu
– Switches on or off the playback
control mode (for VCD version
2.0 only)
1 2 3 4
– Selects an item in the menu/
fast forward/backward, slow forward/
backward
OK
– Acknowledge menu selection
S
– To search or select previous
chapter or track
STOP ( 9 )
– To stop playback
PLAY ( B )
– To start playback
PAUSE ( ; )
– To pause playback temporarily /
frame-by-frame playback
REPEAT
– Selects various repeat modes
REPEAT (A-B)
– Repeats playback a specific section
on a disc
PREVIEW
– To preview the content of a track
or whole disc
MUTE
– Disables or enables sound output
POWER B
–To switch the DVD player to
standby mode or ON
0-9 numerical key pad
– Selects numbered items in a
menu
DISPLAY
– Displays information on TV
screen during playback
SYSTEM MENU
– Access or exit DVD Player’s
system menu
T
–To search or select next chapter
or track
SUBTITLE
–To access subtitle language
system menu
ANGLE
– Selects a DVD camera angle
ZOOM
– Enlarge a picture on the TV
screen
AUDIO
–To access audio language system
menu
Helpful Hint:
Press “STOP” for about 2 seconds to
OPEN or CLOSE disc tray.
01-36 DVP630_EU_051 18/03/2004, 10:04 AM12
/05_8239 210 98393
13
Getting Started
Step 1: Inserting batteries into
the Remote Control
1
3
2
1 Open the battery compartment.
2 Insert two batteries type R06 or AA,
following the indications (+-) inside
the compartment.
3 Close the cover.
Using the Remote Control to
operate the Player
1 Aim the Remote
Control directly at the
remote sensor (iR) on
the front panel.
2 Do not put any objects
between the Remote
Control and the DVD
Player while operating
the DVD Player.
CAUTION!
– Remove batteries if they are
exhausted or if the Remote Control
is not being used for a long time.
– Do not use old and new or
different types of batteries in
combination.
– Batteries contain chemical
substances, so they should be
disposed properly.
Step 2: Setting up the TV
IMPORTANT!
Make sure you have completed all
the necessary connections. (See
pages 7-8 “Connecting TV”).
1 Turn on the TV and set to the correct
video-in channel. You should see the blue
Philips DVD background screen on the
TV.
➜Usually these channels are between the
lowest and highest channels and may be
called FRONT, A/V IN, or VIDEO. See your
TV manual for more details.
➜Or, you may go to channel 1 on your
TV, then press the Channel down button
repeatedly until you see the Video In
channel.
➜Or, the TV Remote Control may have a
button or switch that chooses different
video modes.
➜Or, set the TV to channel 3 or 4 if you
are using an RF modulator.
2 If you are using external equipment, (eg.
audio system or receiver), turn it on and
select the appropriate input source for
the DVD Player output. Refer to the
equipment owner’s manual for detail.
To deactivate Progressive manually
The progressive scan display present 60
complete frames per seconds, rather than
30 frames per second of interlaced
scanning (ordinary normal TV system).
With nearly double the number of line,
progressive scan offers higher picture
resolution and eliminates bothersome
motion artifacts those jagged edge on
moving objects.
To enjoy the full quality potential offered
by progressive scan feature, a progressive
scan TV is required. To activate
progressive function, refer to ‘Progressive
on pages 28-29.
STOP P
L
PREVIEW
PREVIEW
MUTE
MUTE
01-36 DVP630_EU_051 18/03/2004, 10:04 AM13
/05_8239 210 98393
14
Selecting the colour system that
corresponds to your TV
This DVD Player is compatible with both
NTSC and PAL. In order for a DVD disc
to play on this Player, the colour system of
the Disc, the TV and the DVD Player
should match.
1 Press SYSTEM MENU.
2 Press 4 3 to select ‘Video Setup Page’.
3 Enter its submenu by pressing OK.
4 Use the 1 2 3 4 keys on the Remote
Control to navigate in the menu.
Move to ‘TV Standard’ and press B.
Getting Started
- - VIDEO SETUP PAGE - -
TV STANDARD
TV DISPLAY
CLOSED CAPTIONS
VIDEO OUTPUT
PROGRESSIVE
SMART PICTURE
MULTI
NTSC
PAL
MAIN PAGE
To deactivate Progressive manually
- cont’d
If the progressive function is activated, but
your TV does not support progressive
function or YPbPr cable is not connected
accordingly, there will be a blank screen.
You can deactivated progressive function
as below:
1 Press STANDBY ON on the front panel
to switch on the DVD player.
2 Press OPEN/CLOSE on the front panel
to open the disc tray.
3 Press numerical key pad ‘1’.
➜The blue Philips DVD background
appears on the TV screen.
PAL – Select this if the connected TV is
PAL system. It will change the video signal
of a NTSC disc and output in PAL format.
NTSC – Select this if the connected TV
is NTSC system. It will change the video
signal of a PAL disc (VCD only) and
output in NTSC format.
Multi – Select this if the connected TV is
compatible with both NTSC and PAL
(multi-system). The output format will be
in accordance with the video signal of the
disc.
Helpful Hints:
– Before changing the current TV
Standard setting, ensure that your TV
supports the ‘selected TV Standard’
system.
– If there is no proper picture on
your TV, wait for 15 seconds for auto
recovery.
- - REFER TO THE OWNER'S MANUAL - -
Changing MULTI to PAL
1. Ensure your TV supports PAL
2. If there is a blank screen on normal TV
wait 15 seconds for auto recover
CANCEL
OK
1 2 - Move OK - Select
- - REFER TO THE OWNER'S MANUAL - -
Confirm again to use PAL
If picture is good, press OK button on remote control
CANCEL
OK
1 2
- Move OK - Select
TO GO BACK TO MULTI
1. Open tray,
2. Press '3' Key
.
To exit from the menu
Press SYSTEM MENU.
01-36 DVP630_EU_051 18/03/2004, 10:04 AM14
/05_8239 210 98393
15
Step 3: Setting language
preference
You can select your own preferred
language settings.This DVD system will
automatically switch to the language for
you whenever you load a disc. If the
language selected is not available on the
disc, the disc’s default language will be
used instead. The OSD language in the
system menu, will remain once selected.
Setting the OSD Language
- - GENERAL SETUP PAGE - -
SCREEN SAVER
SMART POWER
DISC LOCK
PROGRAM
ENGLISH
FRENCH
GERMAN
ITALIAN
SPANISH
DUTCH
SWEDISH
PORTUGUESE
MAIN PAGE
OSD LANGUAGE
DivX(R) VOD
1 Press SYSTEM MENU.
2 Press 4 3 to select ‘General Setup’ page.
3 Enter its submenu by pressing OK.
4 Use the 1 2 3 4 keys on the Remote
Control to navigate in the menu.
Move to ‘OSD Language’ and press B.
5 Select a language and press OK.
To exit from the menu
Press SYSTEM MENU.
Getting Started
Setting the Audio, Subtitle and Disc
menu language
- - Preference Setup Page - -
SUBTITLE
DISC MENU
PARENTAL
PASSWORD
ENGLISH
FRENCH
GERMAN
ITALIAN
SPANISH
DUTCH
SWEDISH
PORTUGUESE
DEFAULT
AUDIO
MP3/JPEG NAV
MAIN PAGE
1 Press STOP twice then, press SYSTEM
MENU.
2 Press 4 3 to select ‘Preference Page’.
3 Enter its submenu by pressing OK.
4 Press 3 4 to highlight the following in the
Preference Page.
–‘Audio’ (disc’s soundtrack)
– ‘Subtitle’ (disc’s subtitles)
– ‘Disc Menu’ (disc’s menu)
5 Enter its submenu by pressing B.
6 Select a language and press OK.
7 Repeat steps 4~6 for other language
settings.
To exit from the menu
Press SYSTEM MENU.
01-36 DVP630_EU_051 18/03/2004, 10:05 AM15
/05_8239 210 98393
16
Disc Operations
IMPORTANT!
– Depending on the DVD or VIDEO
CD, some operations may be
different or restricted.
– Do not push on the disc tray or
put any objects other than disc on
the disc tray. Doing so may cause
the disc player malfunction.
Playable Discs
Your DVD Player will play:
● Discs:
– Digital Video Discs (DVDs)
– Video CDs (VCDs)
– Super Video CDs (SVCDs)
– Digital Video Discs +Recordable(DVD+R)
– Digital Video Discs + Rewritable(DVD+RW)
– Compact Discs (CDs)
– MP3 disc on CD-R(W):
–Maximum 30 characters display.
–Supported sampling frequencies :
32 kHz, 44.1 kHz, 48 kHz (MPEG-1)
16 kHz, 22.05 kHz, 24 kHz (MPEG-2)
–Supported Bit-rates : 32~256 kbps
(MPEG-1), 8~160 kbps (MPEG-2)
variable bitrates
– Picture files on CD-R(W):
–JPEG picture.
– MPEG-4 disc on CD-R(W):
– Simple profile
–Advanced simple profile (640-480)
– DivX
®
disc on CD-R(W):
–DivX 3.11, 4.x and 5.x
–GMC (Global Motion Compensation)
and Q-Pel (Quarter Pixel) not
supported
Helpful Hint:
– If you are having trouble playing a
certain disc, remove the disc and try a
different one. Improper formatted disc will
not play on this DVD Player.
This DVD Player can play DivX, MPEG-4,
MP3, JPEG, VCD & SVCD files on a
personally recorded CD-R/RW disc or
commercial CD.
● Maximum files programmable is 24.
● MP3: Maximum supported bitrate is
320kbps or 48KHz.
● DivX: DivX 3.11, 4.x and 5.x comply with
this standard, except GMC (Global
Motion Compensation) and QP (Quarter
Pixel) features.
● MPEG-4: All video codecs that comply
with specifications of ISO-MPEG4.
● JPEG: For baseline JPEG, maximum
resolution is 5120 x 3840 (beyond this
picture will be cropped). For progressive
JPEG, maximum resolution is 2048 x 1536
(beyond this, picture will not be
displayed).
Region Codes
DVD discs must be labeled for ALL
regions or Region 2 in order to play on
this Player.
You cannot play Discs that are labeled for
other regions.
Look for symbols on your DVD discs.
2
ALL
01-36 DVP630_EU_051 18/03/2004, 10:05 AM16
/05_8239 210 98393
17
IMPORTANT!
If the inhibit icon appears on the
TV screen when a button is
pressed, it means the function is
not available on the current disc
or at the current time.
Playing discs
1 Connect the power cords of the DVD
Player and TV (and any optional stereo or
AV receiver) to a power outlet.
2 Turn on the TV power and set to the
correct Video In channel. (See page 13
“Setting up the TV”).
3 Press STANDBY-ON on the DVD Player
front panel.
➜You should see the blue Philips DVD
background screen on the TV.
4 Press OPEN•CLOSE 0 button to open
the disc tray and load in a disc, then press
the same button again to close the disc
tray.
➜Make sure the label side is facing up.
For double-sided discs, load the side you
want to play facing up.
5 Playback will start automatically
(depending on the disc type).
➜If a disc menu appears on the TV, see
“Using the Disc Menu”.
➜If the disc is locked by parental control,
you must enter your four-digit password.
(See pages 30-31).
6 At any time, simply press STOP to stop
playback.
Disc Operations
Using the Disc Menu
Depending on the disc, a menu may
appear on the TV screen once you load
the disc.
To select a playback feature or item
● Use the 1 2 3 4 or numeric keypad
(0-9) on the Remote Control, then press
PLAY B to start playback.
To access to the menu
● Press DISC MENU on the Remote
Control.
Basic playback controls
Unless otherwise stated, all operations
described are based on Remote Control
use.
Pausing playback
(DVD/VCD/CD)
1 During playback, press PAUSE ;.
➜Playback will pause and sound will be
muted.
2 During pause mode, press 1 2 to select
the previous or next picture frame.
3 To r e turn to normal playback, press
PLAY B.
Selecting track/chapter
(DVD/VCD/CD)
● Press S / T or use the numeric
keypad (0-9) to key in a track/chapter
number, then press PLAY B to start
playback.
01-36 DVP630_EU_051 18/03/2004, 10:05 AM17
/05_8239 210 98393
18
Repeat (DVD/VCD/CD/MP3)
You can play a chapter, track, title or
entire disc repeatedly.
● Press REPEAT continuously to choose a
Repeat mode during playback.
➜ DVD
‘
CHAPTER REPEAT ON/TITLE REPEAT ON/
REPEAT OFF’ appears on the TV screen.
➜ VCD / CD
‘
REP-ONE/REP-ALL/REPEAT OFF’ appears on
the TV screen.
For VCD2.0, SVCD discs:
– Not available during Playback Control
‘ON’ (PBC On).
➜ MP3
If MP3/JPEG Nav setting is ‘WITH MENU’:
‘
REP-ONE/FOLDER REPEAT/REP-ALL/REPEAT
OFF
’ appears on the TV screen.
If MP3/JPEG Nav setting is ‘NO MENU’:
‘
REP-ONE/REP-ALL/REPEAT OFF’ appears on
the TV screen.
Helpful Hint:
– Repeat option may not be available on
some discs.
Repeat A-B (DVD/VCD/CD)
You can play only a specific portion of a
Title or Track repeatedly.
1 During playback, press REPEAT A-B as
your chosen starting point.
➜‘A TO B SET A’ appears on the TV
screen.
2 When the disc reaches your selected
ending point, press REPEAT A-B again.
➜‘A TO B SET B’ appears on the TV
screen, and the repeat sequence begins.
3 To resume regular playback, press
REPEAT A-B again.
➜‘A TO B CANCELLED’ appears on the TV
screen.
Disc Operations
Mute
(DVD/VCD/CD/MP3/DivX/MPEG4/
JPEG)
● Press MUTE repeatedly to disable and
enable the sound output.
Resuming playback from the last
stopped point (DVD/VCD/CD)
Resume playback of the last 5 discs ia
possible, even if the disc was ejected.
● Load one of the last 5 discs.
➜ “LOADING” appears.
● Press PLAY B and the disc will be played
back from the last point.
To cancel resume mode
● In stop mode, press STOP 9 again.
Helpful Hint:
– Resume option may not be available on
some discs.
Zoom (DVD/VCD)
Zooming allows you to enlarge the video
image during playback.
1 Press ZOOM during playback to select
the zoom factor.
2 Press 1 2 3 4 to pan across the TV
screen.
3 Press ZOOM repeatedly to increase and
decrease the zoom factor.
➜Playback will continue.
01-36 DVP630_EU_051 18/03/2004, 10:05 AM18
/05_8239 210 98393
19
Disc Operations
Searching
(DVD/VCD/SVCD/CD/MP3)
Press 1 or 2 to select fast reverse (FR)
search or fast forward (FF) search
respectively.
➜ DVD / MP3
FRx2 → FRx4 → FRx6 → FRx8 → PLAY
FFx2 → FFx4 → FFx6 → FFx8 → PLAY
➜ VCD / SVCD / CD
FRx1 → FRx2 → FRx3 → FRx4 → PLAY
FFx1 → FFx2 → FFx3 → FFx4 → PLAY
Programme Playback
(DVD/VCD/CD)
1 In Stop mode, press SYSTEM MENU
and press 4 3 to select ‘General Setup
Page’.
2 Select ‘Program’ and set it to ON, then
press OK.
➜ The ‘Program’ menu appears.
3 Use the 1 2 3 4 keys and numeric
keypad (0-9) on the Remote Control to
select a preferred programme.
4 Press PLAY to start playback.
➜ For DVD, the maximum programmable
title or chapter is 16.
➜ For VCD/CD, the maximum
programmable track is 24.
● To erase a selection in Program,
Use the 1 2 3 4 keys to select the
programmed item(s), press OK to delete.
● To list out the programmed item(s),
In Stop mode, press SYSTEM MENU to
select ‘Program’ to ON and then press
OK.
Display (DVD/VCD)
The Display function allows you to start
playback at any chosen time on the disc.
1 During playback, press DISPLAY.
➜ The time edit box appears.
2 Press DISPLAY once, use 1 2 to
highlight one of the option and use
numeric key pad (0-9) to enter the
number of the desired title (track) /
chapter.
3 Press DISPLAY twice, use 2 to highlight
the time option and use numeric key pad
(0-9) to enter hours, minutes and
seconds from left to right in the time edit
box.
4 Press OK to confirm selection.
➜Playback starts from the selected time
on the disc.
● Highlight ‘TIME’, then press 3 4 to view
the status of the playing disc.
For DVD
➜‘
TITLE ELAPSED/ TITLE REMAIN/ CHP
ELAPSED
/ CHP REMAIN’ appears.
For VCD
➜‘
SINGLE ELAPSED/ SINGLE REMAIN/ TOTAL
ELAPSED
/ TOTAL REMAIN’ appears.
Slow Motion (DVD/VCD/SVCD)
During playback, press 3 or 4 to select
slow reverse (SR) and slow forward (SF)
respectively.
➜ DVD
● Press 3 or 4 to select the slow reverse
and slow forward speed:
SFx2 → SFx4 → SFx8 → PLAY
SRx2 → SRx4 → SRx8 → PLAY
➜ VCD / SVCD
● Press 3 to select the slow forward
speed:
SFx1 → SFx2 → SFx3 → PLAY
Helpful Hint:
– Slow Reverse is not available in VCD/
SVCDs.
01-36 DVP630_EU_051 18/03/2004, 10:05 AM19
/05_8239 210 98393
20
Disc Operations
Special DVD Features
Playing a Title
1 Press RETURN/TITLE.
➜The disc title menu appears on the TV
screen.
2 Use 341 2 keys or numeric keypad
(0-9) to select a play option.
3 Press OK key to confirm.
Camera Angle
● Press ANGLE repeatedly to select
different desired angle.
Changing the Audio Language
For DVD
● Press AUDIO repeatedly to select
different audio languages.
Changing the Audio Channel
For VCD
● Press AUDIO to select the available
audio channels provided by the disc (LEFT
VOCAL, RIGHT VOCAL, LEFT MONO,
RIGHT MONO, STEREO).
Subtitles
● Press SUBTITLE repeatedly to select
different subtitle languages.
Special VCD & SVCD Features
Playback Control (PBC)
For VCD with Playback Control (PBC)
feature (version 2.0 only)
● Press DISC MENU to toggle between
‘PBC ON’ and ‘PBC OFF’.
➜If you select ‘PBC ON’, the disc menu
(if available) will appear on the TV.
➜Use the
S / T or the numeric
keypad (0-9) to select a play option, then
press PLAY B to start playback.
● During playback, pressing RETURN/
TITLE will return to the menu screen (if
PBC is on).
Preview (VCD/SVCD/CD)
For VCD/SVCD
● At stop mode, press PREVIEW on the
remote control.
➜The preview menu will be displayed.
1. INTRO
DVD player will playback every track for
few seconds with full screen to obtain a
summary of the disc content.
1 Press numerical key pad ‘1’.
2 Press STOP to quit previewing.
2. DISC
This function is used to divide a disc into
nine parts by regular intervals and display
them on one page to help you preview
the whole disc.
1 Press numerical key pad ‘2’.
➜The preview of 9 track with full screen
will appear.
2 To select other tracks beyond this page,
press S or T.
3 Press the numerical key pad to select
preferred track.
If you want to skip the index menu
and playback directly from the
beginning,
● Press DISC MENU key on the remote
control to switch to PBC off.
01-36 DVP630_EU_051 18/03/2004, 10:05 AM20
/05_8239 210 98393
21
Disc Operations
3. TRACK
This function is used to divide a single
track into nine parts by regular intervals
and display them on one page to help you
preview the selected track.
1 Press numerical key pad ‘3’.
➜The preview of one track with 9 parts
in a full screen will appear.
2 To select other tracks, press S or
T.
3 Press the numerical key pad to choose
the starting point.
4. EXIT
1 Press numerical key pad ‘4’.
For CD
● At stop mode, press PREVIEW on the
remote control.
➜Each track will be played for about 10
seconds.
➜For JPEG CD, press PREVIEW to
view 9 thumbnail pictures on the TV
screen (see page 23).
Playing MP3/DivX/MPEG-4/
JPEG/Kodak Picture CD
IMPORTANT!
You have to turn on your TV and set to
the correct Video In channel. (See page
13 “Setting up the TV”).
General Operation
1 Load an MP3/DivX/MPEG-4/JPEG disc.
➜The data disc menu appears on the TV
screen.
2 Use 3 4 to select the folder and press
OK to open the folder.
Root
3 Press 3 4 or use the numeric keypad
(0-9) to highlight an option.
4 Press OK to confirm.
➜The playback will start from the
selected file to the end of the folder.
● During MP3 playback, the selected track
name and current playing time will be
displayed on the ‘File Name’ column.
● Press DISC MENU on the remote
control to turn on/off the menu.
● If the ‘MP3/JPEG Nav’ setting is set to NO
MENU the DATA CD MENU will not
appear on the TV screen (see page 31).
Helpful Hint:
–For Kodak Picture CD, playback will start
automatically without a disc menu and press
STOP 9 to display thumbnails of 9 pictures.
01-36 DVP630_EU_051 18/03/2004, 10:05 AM21
/05_8239 210 98393
22
Disc Operations
Playback selection
During playback, you can;
● Press
S / T to select another file in
the current folder.
● Use
1 2 3 4 on the remote to rotate/flip
the picture files.
● Press
; to pause playback.
Special MP3/JPEG/DivX features
Preview Function
This function shows the content of the
current folder or the whole disc.
1 Press PREVIEW during playback.
➜Thumbnails of 9 pictures appears on
the TV screen.
(example for 9 thumbnail pictures display)
2 Press S / T to display the other
pictures on the previous/next page.
3 Use 1 2 3 4 to highlight one of the
picture and press OK to start playback.
For DivX
● Press AUDIO repeatedly to select
different audio languages.
● Press SUBTITLE repeatedly to select
different subtitle languages.
Zoom picture
For JPEG
● During playback, press ZOOM repeatedly
to switch ‘
ZOOM ON’ or ZOOM OFF’.
● Press
S / T to display the picture
with different scales.
● Use 1 2 3 4 to view the zoomed picture.
For DivX
● During playback, press ZOOM repeatedly
to select ‘zoom x 2’ or ‘zoom off’.
Scan Effect (JPEG)
● Press ANGLE repeatedly to choose
different scan effect.
➜Various scan effect appears on the top
left hand corner on the TV screen.
Playback speed control (MP3)
● Press
1 2 repeatedly to play backward/
forward at different speed.
● You can press
S / T to change the
tracks.
JPEG and MP3 simultaneous
playback
1 Select a MP3 track and press AUDIO.
➜‘Music Slide Show’ appears on the TV
screen.
2 Press 3 4 to select a picture file, then
press OK.
➜The picture will be played back in
sequence together with MP3 music.
3 To quit simultaneous playback, press
STOP.
➜The picture and MP3 music playback
will stop.
Helpful Hints:
– If the disc menu doesn’t appear on the
TV screen, switch ‘MP3/JPEG Navigator’ to
‘With Menu’ (see page 31).
– During Music slide show playback, all
buttons are disabled except PLAY, PAUSE,
STOP, OPEN/CLOSE and POWER.
Playback with multi-angles (JPEG)
● During playback, press
3 4 1 2 to rotate
the picture on the TV screen.
3: flip the picture vertically
4: flip the picture horizontally
1: rotate the picture anti-clockwise
2: rotate the picture clockwise
01-36 DVP630_EU_051 18/03/2004, 10:05 AM22
/05_8239 210 98393
23
Basic Operations
1 Press SYSTEM MENU in the STOP
mode to enter the Setup Menu.
2 Press OK to enter the next level
submenu or confirm your selection.
3 Press 1 2 to enter the submenu or
return to the previous menu.
4 Press 34 to highlight the desired menu.
5 Press SYSTEM MENU to quit the setup
menu.
➜The settings will be stored in the
player’s memory even if the player is
switched off.
General Setup menu
The options included in General Setup
menu are: ‘OSD Language’, ‘Screen Saver’,
‘Smart Power’, ‘Disc Lock’, ‘Program’ and
‘DivX(R) VOD’.
Follow the steps below:
SET UP MENU - - MAIN PAGE
AUDIO SETUP
VIDEO SETUP
PREFERENCES
EXIT MENU
GENERAL SETUP
1 Press SYSTEM MENU to enter the
setup menu.
2 Press 3 4 to select the ‘General Setup’
page.
3 Press OK to confirm.
DVD Menu Options
NOTE:
Some of the features in the DVD
Menu Options are described in
“Getting Started”.
Screen Saver
- - GENERAL SETUP PAGE - -
SCREEN SAVER
SMART POWER
DISC LOCK
PROGRAM
OFF
ON
MAIN PAGE
OSD LANGUAGE
DivX(R) VOD
1 Press 34 to highlight ‘Screen Saver’.
2 Enter its submenu by pressing 2.
3 Move the cursor by pressing 34 to
highlight the selected item.
➜Off: Screen saver is disabled.
➜
On: In STOP or No DISC mode, if no
actions are performed within 5 minutes,
the screen saver will be activated.
4 Press OK, then press 1 to return to
General Setup Page.
Smart Power
When in ‘Stop’ or ‘No Disc’ mode, the
DVD Player will switch to standby mode
after 15 minutes of inactivity for energy
saving.
- - GENERAL SETUP PAGE - -
SCREEN SAVER
SMART POWER
DISC LOCK
PROGRAM
OFF
ON
MAIN PAGE
OSD LANGUAGE
DivX(R) VOD
1 Press 34 to highlight ‘Smart Power’.
2 Enter its submenu by pressing 2.
3 Move the cursor by pressing 34 to
highlight the selected item.
➜Off: Smart Power is disabled.
➜
On: In STOP or No DISC mode, if no
actions are performed for 15 minutes, the
smart power will be activated.
4 Press OK, then press 1 to return to
General Setup Page.
01-36 DVP630_EU_051 18/03/2004, 10:05 AM23
/05_8239 210 98393
24
DVD Menu Options
Disc Lock (DVD/VCD/CD)
- - GENERAL SETUP PAGE - -
SCREEN SAVER
SMART POWER
DISC LOCK
PROGRAM
LOCK
UNLOCK
MAIN PAGE
OSD LANGUAGE
DivX(R) VOD
1 Press 34 to highlight ‘Disc Lock’.
2 Enter its submenu by pressing 2.
3 Move the cursor by pressing 34 to
highlight the selected item.
➜Lock: Select this option and the player
will lock the current playing disc.
➜
Unlock: Select this option and the
player will unlock the current playing disc.
● You will need to input the password to
confirm unlock selection. The initial
password is 1234 (see ‘Password’ on
pages 30-31).
4 Press OK, then press 1 to return to
General Setup Page.
Helpful Hint:
– When a specific locked disc is loaded, a
prompt menu will appear.
Program
- - GENERAL SETUP PAGE - -
SCREEN SAVER
SMART POWER
DISC LOCK
PROGRAM
ON
MAIN PAGE
OSD LANGUAGE
DivX(R) VOD
1 Press 34 to highlight ‘Program’.
2 Enter its submenu by pressing 2.
➜
On: Select this option to activate
program function.
3 Press OK to enter to ‘Program’ menu
(see ‘Program Playback’ on page 19).
For VCD / CD
PROGRAM
01
02
03
04
05
06
07
08
PRESS PLAY TO START
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
For DVD
PROGRAM
T I T L E 0 1 / 2 6 C H A P T E R 0 0 1 / 0 01
NO. TT CH NO. TT CH
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
PRESS PLAY TO START
DivX(R) VOD
Philips provide you the DivX
®
VOD
(Video On Demand) registration code
that allows you to rent and purchase
videos using the DivX
®
VOD service.
For more information, visit
www.divx.com/vod.
- - GENERAL SETUP PAGE - -
SCREEN SAVER
SMART POWER
PROGRAM
MAIN PAGE
OSD LANGUAGE
DivX(R) VOD
DISC LOCK
1 Press 34 to highlight ‘DivX(R) VOD’.
2 Press OK on the remote control.
➜The registration code will appear.
01-36 DVP630_EU_051 18/03/2004, 10:05 AM24
/05_8239 210 98393
25
DVD Menu Options
Audio Setup Menu
The options included in Audio Setup
menu are: ‘Downmix’, ‘Digital Output’,
‘LPCM Output’, ‘Sound Mode’, ‘Reverb
Mode’ and ‘D.R.C’.
1 Press SYSTEM MENU.
2 Press 3 4 to select the ‘Audio Setup’ page.
3 Press OK to confirm.
Downmix
- - AUDIO SETUP PAGE - -
DIGITAL OUTPUT
LPCM OUTPUT
SOUND MODE
REVERB MODE
LT/RT
STEREO
MAIN PAGE
DOWNMIX
D.R.C
1 Press the 34 keys to highlight ‘Downmix’.
2 Enter its submenu by pressing 2.
Digital Output
Set the Digital output according to your
optional audio equipment connection.
- - AUDIO SETUP PAGE - -
DIGITAL OUTPUT
LPCM OUTPUT
SOUND MODE
REVERB MODE
ALL
PCM ONLY
MAIN PAGE
DOWNMIX
D.R.C
1 Press 34 to highlight ‘Digital Output’.
2 Enter its submenu by pressing 2.
3 Move the cursor by pressing 34 to
highlight the selected item.
➜All: If you have connected your
DIGITAL AUDIO OUT to a multi-channel
decoder/receiver.
➜
PCM Only: Only if your receiver is
not capable of decoding multi-channel
audio.
4 Press OK, then press 1 to return to
Audio Setup Page.
Helpful Hint:
– If DIGITAL OUTPUT is set to ‘All’, all
audio settings except MUTE are invalid.
- - DivX(R) REGISTRATION - -
DONE
Your registration code is : YDLAILYF
Please use this code to register this player with
the DivX(R) Video On Demand service.
This will allow you to rent and purchase videos
using the DivX(R) Video On Demand format.
To learn more go to www.divx.com/vod
3 Use the registration code to purchase or
rent the videos from DivX
®
VOD service
at www.divx.com/vod.
Follow the instrucitons and download the
video onto a CD-R for playback on this
DVD player.
Helpful Hint:
– All the downloaded videos from DivX
®
VOD can only be played back on this DVD
player.
3 Move the cursor by pressing the 34 keys
to highlight the selected item.
➜
LT/RT: Select this option if your DVD
Player is connected to a Dolby Prologic
decoder.
➜
Stereo: Select this option when output
delivers sound from only the two front
speakers.
4 Press OK, then press 1 to return to
Audio Setup Page.
01-36 DVP630_EU_051 18/03/2004, 10:05 AM25
/05_8239 210 98393
26
DVD Menu Options
Sound Mode
The digital sound effect allows you to
select from various pre-set modes that
control the frequency bands of sound
optimise certain musical styles. It
enhances the excitement and enjoyment
of your favourite music.
- - AUDIO SETUP PAGE - -
DIGITAL OUTPUT
LPCM OUTPUT
SOUND MODE
REVERB MODE
NONE
ROCK
MAIN PAGE
DOWNMIX
D.R.C
POP
BALLAD
DANCE
CLASSIC
1 Press 34 to highlight ‘Sound Mode’.
2 Enter its submenu by pressing 2.
3 Move the cursor by pressing 34 to
highlight the selected item.
➜None, Rock, Pop, Ballad, Dance,
Classic
4 Press OK, then press 1 to return to
Audio Setup Page.
Reverb Mode
Reverb mode provides a virtual surround
sound experience using just two speakers.
- - AUDIO SETUP PAGE - -
DIGITAL OUTPUT
LPCM OUTPUT
SOUND MODE
REVERB MODE
OFF
STUDIO
MAIN PAGE
DOWNMIX
D.R.C
MOVIE
STADIUM
CHURCH
CLUB
1 Press 34 to highlight ‘Reverb Mode’.
2 Enter its submenu by pressing 2.
3 Move the cursor by pressing 34 to
highlight the selected item.
➜Off, Studio, Movie, Stadium,
Church, Club
4 Press OK, then press 1 to return to
Audio Setup Page.
LPCM Output
If you connect the DVD Player to a PCM
compatible receiver via the digital
terminals, such as coaxial or optical etc,
you may need to adjust ‘LPCM Output’.
Discs are recorded at a certain sampling
rate. The higher the sampling rate, the
better the sound quality.
- - AUDIO SETUP PAGE - -
DIGITAL OUTPUT
LPCM OUTPUT
SOUND MODE
REVERB MODE
96K
48K
MAIN PAGE
DOWNMIX
D.R.C
1 Press 34 to highlight ‘LPCM Output’.
2 Enter its submenu by pressing 2.
3 Move the cursor by pressing 34 to
highlight the selected item.
➜48K: Playback a disc recorded at the
sampling rate of 48kHz.
➜
96K: Playback a disc recorded at the
sampling rate of 96kHz.
4 Press OK, then press 1 to return to
Audio Setup Page.
Helpful Hints:
– Most discs are recorded at the sampling
rate of 48kHz.
– If ‘96K’ is selected, ensure that receiver
or amplifier supports 96kHz digital signals.
01-36 DVP630_EU_051 18/03/2004, 10:05 AM26
/05_8239 210 98393
27
DVD Menu Options
Video Setup Menu
The options included in Video Setup menu
are: ‘TV Standard’, ‘TV Display’, ‘Closed
Captions’, ‘Video Output’, ‘Progressive’
and ‘Smart Picture’.
1 Press SYSTEM MENU.
2 Press 3 4 to select the ‘Video Setup’
page.
3 Press OK to confirm.
D.R.C. (Dynamic Range Control)
High volume outputs are softened,
enabling you to watch your favourite
action movie without disturbing others at
night.
- - AUDIO SETUP PAGE - -
DIGITAL OUTPUT
LPCM OUTPUT
SOUND MODE
REVERB MODE
ON
OFF
MAIN PAGE
DOWNMIX
D.R.C
1 Press 34 to highlight ‘D.R.C’.
2 Enter its submenu by pressing 2.
3 Move the cursor by pressing 34 to
highlight the selected item.
➜
Off: Audio with uncompressed dynamic
range.
➜
On: Audio with fully compressed
dynamic range.
4 Press OK, then press 1 to return to
Audio Setup Page.
TV Display
Set the aspect ratio of the DVD Player
according to the TV you have connected.
- - VIDEO SETUP PAGE - -
TV STANDARD
TV DISPLAY
CLOSED CAPTIONS
VIDEO OUTPUT
PROGRESSIVE
SMART PICTURE
MAIN PAGE
4:3 PS
4:3 LB
16:9
1 Press 34 to highlight ‘TV Display’.
2 Enter its submenu by pressing 2.
3 Move the cursor by pressing 34 to
highlight the selected item.
16:9
4:3
Letter Box
4:3
Pan Scan
16:9
➜If you have a wide-screen TV.
4:3 Letter Box
➜If you have a normal TV. In this case, a
wide picture with black bands on the
upper and lower portions of the TV
screen will be displayed.
4:3 Pan Scan
➜If you have a normal TV and want both
sides of the picture to be trimmed or
formatted to fit your TV screen.
4 Press OK, then press 1 to return to
Video Setup Page.
01-36 DVP630_EU_051 18/03/2004, 10:05 AM27
/05_8239 210 98393
28
DVD Menu Options
Video Output
Video Output selection enables you to
choose the type of video output suitable
for your DVD player.
- - VIDEO SETUP PAGE - -
TV STANDARD
TV DISPLAY
CLOSED CAPTIONS
VIDEO OUTPUT
PROGRESSIVE
SMART PICTURE
MAIN PAGE
S-VIDEO
YPbPr
RGB
Progressive
To select this item you must set ‘Video
Output’ to YPbPr and ensure that your TV
has progressive scan.
- - VIDEO SETUP PAGE - -
TV STANDARD
TV DISPLAY
CLOSED CAPTIONS
VIDEO OUTPUT
PROGRESSIVE
SMART PICTURE
ON
OFF
MAIN PAGE
1 Press 34 to highlight ‘Progressive’.
2 Enter its submenu by pressing 2.
3 Move the cursor by pressing 34 to
highlight the selected item.
➜On: Enable Progressive.
➜Off: Disable Progressive.
4 Press OK, then press 1 to return to
Video Setup Page.
Closed Captions
Closed captions are data that are hidden
in the video signal on specific discs,
invisible without a special decoder. The
difference between subtitles and closed
captions is that subtitles are intended for
hearing persons and closed captions are
for the hearing impaired. For example,
closed captions show sound effects (e.g.,
“phone ringing” and “footsteps”), while
subtitles don’t.
Before you select this function, please
ensure that the disc contains closed
captions information and your TV set also
has this function.
- - VIDEO SETUP PAGE - -
TV STANDARD
TV DISPLAY
CLOSED CAPTIONS
VIDEO OUTPUT
PROGRESSIVE
SMART PICTURE
MAIN PAGE
ON
OFF
1 Press 34 to highlight ‘Closed Captions’.
2 Enter its submenu by pressing 2.
3 Move the cursor by pressing 34 to
highlight the selected item.
➜On: Enable Closed Captions.
➜Off: Disable Closed Captions.
4 Press OK, then press 1 to return to
Video Setup Page.
1 Press 34 to highlight ‘Video Output’.
2 Enter its submenu by pressing 2.
3 Move the cursor by pressing 34 to
highlight the selected item.
➜RGB: If you connected the video
output to a TV using RGB jack.
➜
S-Video: If you have connected the S-
Video output to a TV.
➜
YPbPr: If you have connected the
YPbPr output to a TV.
4 Press OK, then press 1 to return to
Video Setup Page.
01-36 DVP630_EU_051 18/03/2004, 10:05 AM28
/05_8239 210 98393
29
Smart Picture
In this menu, you can choose a picture
setting from a fixed set of ideal predefined
picture settings.
- - VIDEO SETUP PAGE - -
TV STANDARD
TV DISPLAY
CLOSED CAPTIONS
VIDEO OUTPUT
PROGRESSIVE
SMART PICTURE
MAIN PAGE
STANDARD
BRIGHT
SOFT
PERSONAL
1 Press 34 to highlight ‘Smart Picture’.
2 Enter its submenu by pressing 2.
3 Move the cursor by pressing 34 to
highlight the selected item.
➜
Standard: select the standard picture
setting.
➜
Bright: make the TV picture brighter.
➜
Soft: make the TV picture softer.
➜
Personal: achieve the colour effect set
in the ‘Brightness’, ‘Contrast’, ‘Hue’ and
‘Saturation’ menu.
4 Press OK, then press 1 to return to
Video Setup Page.
DVD Menu Options
Brightness
You can personalise your picture colour
by adjusting brightness,contrast, hue and
saturation.
1 Press 1 2 to highlight ‘Brightness’.
2 Press 4 to open the level bar.
3 Press 1 2 to decrease or increase the
brightness level.
4 Press OK to exit.
● Repeat steps
1 - 4 for adjusting the
contrast, hue and saturation feature.
Preference Setup Menu
The options included in Preference Setup
menu are: ‘Audio’, ‘Subtitle’, ‘Disc Menu’,
‘Parental’, ‘Password’, ‘Default’ and ‘MP3/
JPEG Nav’.
1 Press STOP twice.
2 Press SYSTEM MENU to enter the
setup menu.
3 Press 3 4 to select the ‘Preference’ page.
4 Press OK to confirm.
Helpful Hints:
– If a blank/distorted TV screen appears,
wait for 15 seconds for auto recover.
–To deactivate the progressive function,
refer to the hint menu displayed on the TV
screen or see pages 13 and 14.
CANCEL
- - REFER TO THE OWNER'S MANUAL - -
Confirm again to use progressive scan
If picture is good, press OK button on remote control
OK
2 3 - Move OK - Select
To deactivate progressive:
1. Open tray,
2. Press '1' Key.
- - REFER TO THE OWNER'S MANUAL - -
ACTIVATING PROGRESSIVE:
1. Ensure your TV has progressive
2. Connect with YPbPr (GBR) video
3. If there is a blank screen on normal
wait 15 seconds for auto recover
CANCEL
OK
2 3 - Move OK - Select
01-36 DVP630_EU_051 18/03/2004, 10:05 AM29
/05_8239 210 98393
30
DVD Menu Options
Parental
Some DVDs may have a parental level
assigned to the complete disc or to
certain scenes on the disc. This feature
lets you set a playback limitation level.
The rating levels are from 1 to 8 and are
country dependent. You can prohibit the
playing of certain discs that are not
suitable for your children or have certain
discs played with alternative scenes.
● VCD, SVCD, CD have no level indication,
so parental control function has no effect
on these type of discs. This applies to
most illegal DVD discs.
- - PREFERENCE SETUP PAGE - -
SUBTITLE
DISC MENU
PARENTAL
PASSWORD
I KID SAFE
2 G
3 PG
4 PG 13
5 PGR
6 R
7 NC 17
8 ADULT
DEFAULT
AUDIO
MP3/JPEG NAV
1 Press 34 to highlight ‘Parental’.
2 Enter its submenu by pressing 2.
3 Use 34 to highlight a rating level for the
disc inserted.
➜DVDs that are rated above the level
you selected will not play unless you enter
your four-digit password and choose a
higher level rating.
➜To disable Parental controls and have
all Discs play, choose ‘No Parental’.
4 Press OK, then press 1 to return to
Preference Setup Page.
Helpful Hint:
– Some DVDs are not encoded with a
rating though the movie rating may be
printed on the Disc cover. The rating level
feature does not work for such Discs.
Password
This feature is used for Parental Control.
Enter your four digit password when a
hint is displayed on the screen. The default
password is 1234.
- - PREFERENCE SETUP PAGE - -
SUBTITLE
DISC MENU
PARENTAL
PASSWO R D
CHANGE
DEFAULT
AUDIO
MP3/JPEG NAV
1 Press 34 to highlight ‘Password’.
2 Enter its submenu by pressing 2.
3 Press OK to open the password ‘Change’
page.
Rating explanations
1-2 G
– General Audience; recommended as acceptable
for viewers of all ages.
3 PG
– Parental Guidance suggested.
4 PG13
– Material is unsuitable for children under age 13.
5-6 PG-R
– Parental Guidance - Restricted; recommended
that parents restrict children under 17 from
viewing or allow to view only when supervised by
a parent or adult guardian.
7 NC-17
– No children under age 17; not recommended
viewing for children under age 17.
8 ADULT
– Mature material; should be viewed only by
adults due to graphic sexual material, violence or
language.
NO PARENTAL
– It will play all discs.
01-36 DVP630_EU_051 18/03/2004, 10:05 AM30
/05_8239 210 98393
31
Default
Setting the ‘Default’ function will reset all
options and your personal settings to the
factory defaults and all your personal
settings will be erased.
- - PREFERENCE SETUP PAGE - -
SUBTITLE
DISC MENU
PARENTAL
PASSWOR D
RESET
DEFAULT
AUDIO
MP3/JPEG NAV
1 Press 34 to highlight ‘Default’.
2 Highlight RESET by pressing 2.
3 Press OK, then press 1 to return to
Preference Setup Page.
DVD Menu Options
MP3/JPEG Navigator
This feature allows you to select alternate
settings when you playback picture CD
(JPEG/DivX) and MP3 CD.
- - PREFERENCE SETUP PAGE - -
SUBTITLE
DISC MENU
PARENTAL
PASSWORD
NO MENU
DEFAULT
AUDIO
MP3/JPEG NAV
WITH MENU
1 Press 34 to highlight ‘MP3/JPEG Nav’.
2 Enter its submenu by pressing 2.
3 Move the cursor by pressing 34 to
highlight the selected item.
➜No Menu: playback all pictures (JPEG/
DivX) or MP3 music in sequence
automatically without menu.
➜
With Menu: playback pictures (JPEG/
DivX) or MP3 music in the selected
folder with menu.
4 Press OK, then press 1 to return to
Preference Setup Page.
Helpful Hint:
– MP3/JPEG Nav can be set only in disc
recorded with menu and may not be
available on some discs eventhough it is set
to ‘WITH MENU’.
- - PASSWORD CHANGE PAGE - -
OLD PASSWORD
NEW PASSWORD
CONFIRM PASSWORD
PRESS OK TO CONFIRM
4 Enter the existing 4 digit code.
5 Enter the new 4-digit code.
6 Enter the new 4-digit code a second time
to confirm.
➜ The new 4 digit code will now take
effect.
7 Press OK, then press 1 to return to
Preference Setup Page.
Helpful Hints:
– If the password has been changed, the
parental and disc lock code will also be
changed. The default password won’t take
effect.
–To reset the password to the default
settings (1234), press STOP key four times.
Caution!
– When this function is activated, all
settings will be reset to factory
defaults except ‘Parental’ and
‘Password’.
01-36 DVP630_EU_051 18/03/2004, 10:05 AM31
/05_8239 210 98393
32
TV STANDARD (PAL/50Hz) (NTSC/60Hz)
Number of lines 625 525
Playback Multistandard (PAL/NTSC)
VIDEO PERFORMANCE
CVBS 1Vpp — 75 ohm
YPbPr 0.7 Vpp — 75 ohm
RGB (SCART) 0.7 Vpp — 75 ohm
VIDEO FORMAT
Digital Compression MPEG 2 for DVD,SVCD
MPEG 1 for VCD
MPEG-4
DVD 50Hz 60Hz
Horiz. resolution 720 pixels 720 pixels
Vertical resolution 576 lines 480 lines
VCD 50Hz 60Hz
Horiz. resolution 352 pixels 352 pixels
Vertical resolution 288 lines 240 lines
AUDIO FORMAT
Digital Mpeg/ AC-3/ compressed Digital
PCM 16, 20, 24 bits
fs, 44.1, 48, 96 kHz
MP3(ISO 9660) 96, 112, 128, 256
kbps & variable
bit rate fs, 32, 44.1,
48 kHz
Analog Sound Stereo
Dolby Surround compatible downmix from Dolby Digital
multi-channel sound
Specifications
AUDIO PERFORMANCE
DA Converter 24 bit
DVD fs 96 kHz 4Hz- 44kHz
fs 48 kHz 4Hz- 22kHz
SVCD fs 48 kHz 4Hz- 22kHz
fs 44.1kHz 4Hz- 20kHz
CD/VCD fs 44.1kHz 4Hz- 20kHz
Signal-Noise (1kHz) 105 dB
Dynamic range(1kHz) 100 dB
Crosstalk (1kHz) 105 dB
Distortion/noise (1kHz) 90 dB
MPEG MP3 MPEG Audio L3
CONNECTIONS
Scart Output Euroconnector
YPbPr Output Cinch 3x
Video Output Cinch (yellow)
Audio Output(L+R) Cinch (white/red)
Digital Output 1 coaxial, 1 optical
IEC60958 for CDDA / LPCM
IEC61937 for MPEG 1/2,
Dolby Digital
CABINET
Dimensions (w x h x d) 435 x 43 x 248 mm
Weight Approximately 2.0 kg
POWER CONSUMPTION
Power Supply Rating 220 – 240 V; 50 Hz
Power consumption in Standby mode < 0.8W
Specifications subject to change without prior notice
01-36 DVP630_EU_051 18/03/2004, 10:05 AM32
/05_8239 210 98393
33
WARNING
Under no circumstances should you try to repair the system yourself, as this will
invalidate the warranty. Do not open the system as there is a risk of electric shock.
If a fault occurs, first check the points listed below before taking the system for repair. If
you are unable to remedy a problem by following these hints, consult your dealer or
Philips for help.
Problem Solution
No power – Check if the AC power cord is properly connected.
– Press the STANDBY ON on the front of the DVD
system to turn on the power.
No picture – Refer to your TV’s manual for correct Video In
channel selection. Change the TV channel until you
see the DVD screen.
– Check if the TV is switched on.
Distorted picture – Sometimes a small amount of picture distortion may
appear depending on the disc being played back. This
is not a malfunction.
Completely distorted picture or – Connect DVD Player directly to the TV.
black/white picture with DVD – Make sure the disc is compatible with the DVD/
Player.
– Ensure that the DVD Player’s TV Standard is set to
match that of the Disc and your TV.
No sound or distorted sound – Adjust the volume.
– Check that the speakers are connected correctly.
No audio at digital output – Check the digital connections.
– Check if your receiver can decode MPEG-2 or DTS
and if not, please make sure the digital output is set
to PCM.
– Check if the audio format of the selected audio
language matches your receiver capabilities.
No sound and picture – Check that the RGB/SCART cable is connected to
the correct device (See Connecting TV).
Disc can’t be played – The DVD+R/CD-R must be finalised.
– Ensure the disc label is facing up.
– Check if the disc is defective by trying another disc.
– If you have recorded a Picture CD or MP3 CD
yourself, ensure that your disc contains at least 10
pictures or 5 MP3 tracks.
– Region code incorrect.
Picture freezes momentarily – Check the disc for fingerprints/scratches and
during playback clean with a soft cloth wiping from centre to edge.
No return to start-up screen when – Reset the unit by switching the player off, then on
disc is removed again.
Troubleshooting
01-36 DVP630_EU_051 18/03/2004, 10:05 AM33
/05_8239 210 98393
34
Problem Solution
The player does not respond to –Aim the Remote Control directly at the sensor
the Remote Control on the front of the player.
– Reduce the distance to the player.
– Replace the batteries in the Remote Control.
– Re-insert the batteries with their polarities (+/–
signs) as indicated.
Buttons do not work –To completely reset the player, unplug the AC
cord from the AC outlet for 5-10 seconds.
Player does not respond to some – Operations may not be permitted by the disc.
operating commands during playback. Refer to the instructions of the disc jacket.
DVD Player cannot read – Use a commonly available cleaning CD/DVD to
CDs/DVDs clean the lens before sending the DVD Player for
repair.
Menu items cannot be selected – Press STOP twice before selecting System Menu.
– Depending on the disc availability, some menu items
cannot be selected.
Unable to play DivX movies – Check that the DivX file is encoded in ‘Home
Theater’ mode with DivX 5.x encoder.
If you are unable to remedy a problem by following these hints, consult your dealer
or service center (HOTLINE).
Troubleshooting
01-36 DVP630_EU_051 18/03/2004, 10:05 AM34
/05_8239 210 98393
35
Analog: Sound that has not been turned into
numbers. Analog sound varies, while digital sound has
specific numerical values. These jacks send audio
through two channels, the left and right.
Aspect ratio: The ratio of vertical and horizontal
sizes of a displayed image. The horizontal vs. vertical
ratio of conventional TVs. is 4:3, and that of wide-
screens is 16:9.
AUDIO OUT Jacks: Jacks on the back of the DVD
System that send audio to another system (TV, Stereo,
etc.).
Bit Rate: The amount of data used to hold a given
length of music; measured in kilobits per seconds, or
kbps. Or, the speed at which you record. Generally,
the higher the bit rate, or the higher the recording
speed, the better the sound quality. However, higher
bit rates use more space on a Disc.
Chapter: Sections of a picture or a music piece on a
DVD that are smaller than titles. A title is composed
of several chapters. Each chapter is assigned a chapter
number enabling you to locate the chapter you want.
Component Video Out Jacks: Jacks on the back of
the DVD System that send high-quality video to a TV
that has Component Video In jacks (R/G/B, Y/Pb/Pr,
etc.).
Disc menu: A screen display prepared for allowing
selection of images, sounds, subtitles, multi-angles, etc
recorded on a DVD.
Digital: Sound that has been converted into
numerical values. Digital sound is available when you
use the DIGITAL AUDIO OUT COAXIAL or
OPTICAL jacks. These jacks send audio through
multiple channels, instead of just two channels as
analog does.
DivX 3.11/4.x/5.x: The DivX codec is a patent-
pending, MPEG-4 based video compression
technology, developed by DivXNetworks, Inc., that can
shrink digital video to sizes small enough to be
transported over the internet, while maintaining high
visual quality.
Dolby Digital: A surround sound system developed
by Dolby Laboratories containing up to six channels
of digital audio (front left and right, surround left and
right, center and subwoofer).
JPEG: A very common digital still picture format. A
still-picture data compression system proposed by the
Joint Photographic Expert Group, which features small
decrease in image quality in spite of its high
compression ratio.
MP3: A file format with a sound data compression
system. “MP3” is the abbreviation of Motion Picture
Experts Group 1 (or MPEG-1) Audio Layer 3. By using
MP3 format. one CD-R or CD-RW can contain about
10 times as much data volume as a regular CD can.
Multichannel: DVD is specified to have each sound
track constitute one sound field. Multichannel refers
to a structure of sound tracks having three or more
channels.
Parental Control: A function of the DVD to limit
playback of the disc by the age of the users according
to the limitation level in each country. The limitation
varies from disc to disc; when it is activated, playback
will be prohibited if the software’s level is higher than
the user-set level.
PCM (Pulse Code Modulation): A system for
converting analog sound signal to digital signal for
later processing, with no data compression used in
conversion.
Playback control (PBC): Refers to the signal
recorded on video CDs or SVCDs for controlling
reproduction. By using menu screens recorded on a
Video CD or SVCD that supports PBC, you can enjoy
interactive-type software as well as software having a
search function.
Progressive Scan: It displays all the horizontal lines
of a picture at one time, as a signal frame. This system
can convert the interlaced video from DVD into
progressive format for connection to a progressive
display. It dramatically increases the vertical
resolution.
Region code: A system for allowing discs to be
played back only in the region designated beforehand.
This unit will only play discs that have compatible
region codes. You can find the region code of your
unit by looking on the product label. Some discs are
compatible with more than one region (or ALL
regions).
S-Video: Produces a clear picture by sending
separate signals for the luminance and the color. You
can use S-Video only if your TV has S- video In jack.
Title: The longest section of a picture or music
feature on DVD, music, etc., in video software, or the
entire album in audio software. Each title is assigned a
title number enabling you to locate the title you want.
VIDEO OUT jack: Jack on the back of the DVD
System that sends video to a TV.
Glossary
01-36 DVP630_EU_051 18/03/2004, 10:05 AM35
/05_8239 210 98393
36
The products and services described herein are not
necessarily available in all countries
Due to continuous product improvements this document
is subject to change without notice.
PHILIPS NORGE AS
Sandstuveien 70,
PO Box 1, Manglerud
N-0612 Oslo
NORWAY
Phone: 2274 8250
OY PHILIPS AB
Sinikalliontie 3,
02630 Espo
Helsinki
FINLAND
puh. 09 615 80 250
PHILIPS KUNDTJÄNST
Kollbygatan 7,
Akalla,
16485 Stockholm
SWEDEN
Phone: 08-598 52 250
PHILIPS POLSKA
AL. Jerozolimskie 195B
02-222 Warszawa
POLSKA
Tel.: (022)-571-0-571
PHILIPS SERVICE
V Mezihori 2
180 00 Prage
CZECH REPUBLIC
Phone: (02)-3309 9240
PHILIPS Iberia, S.A.
C/Martinez Villergas, 49
28027 MADRID
SPAIN
Phone: 902-11 33 84
25GR LAQSIOT 15
177 78 SATQOR
AHGMA
Sgk. 00800 3122 1280
PHILIPS
Österreichische Philips Industrie
GmbH
Triesterstrasse 64
1101 Wien
AUSTRIA
Tel: 0810 001 203
PHILIPS INFO CENTER
Alexanderstrasse 1
20099 Hamburg
GERMANY
Tel: 0180-53 56 767
SERVICE
CONSOMMATEURS PHILIPS
BP 0101
75622 Paris Cédex 13
FRANCE
Phone: 0825-889 789
PHILIPS ELECTRONICS
IRELAND LIMITED
Consumer Information Center
Newstead, Clonskeagh
DUBLIN 14
Phone: 01-7640292
PHILIPS CONSUMER
ELECTRONICS
Servizio Consumatori
Via Casati 23
20052 Monza - Milano
ITALY
Phone: 800 820026
PHILIPS MÁRKASZERVIZ
Kinizsi U 30 - 36
Budapest 1092
HUNGARY
Phone: (01)-2164428
PHILIPS PORTUGUESA,
S.A.
Consumer Information Center
Rua Dr. António Loureiro Borge,
nr.5
Arquiparque, Miraflores
P-2795 L-A-VEHLA
PORTUGAL
Phone: 021-4163063
PHILIPS CE, The Philips
Centre,
420 - 430 London Road,
Croydon, Surrey
CR9 3QR
UNITED KINGDOM
Phone: 0208-665-6350
CONSUMER SERVICES
Prags Boulevard 80. PO Box
1919,
DK-2300 Copenhagen S
DANMARK
TIf: 32 88 32 00
PHILIPS
REPRESENTATION OFFICE
Ul. Usacheva 35a
119048 MOSCOW
RUSSIA
Phone: 095-937 9300
PHILIPS INFO CENTER
Fegistrasse 5
8957 Spreitenbach
SUISSE
Tel.: 0844-800 544
PHILIPS CUSTOMER CARE
CENTER
Tw ee Stationsstraat 80/
80 Rue des Deux Gares
1070 BURSSEL/BRUXELLES
BELGIUM (for BENELUX)
Tel: 070-222303
Meet Philips at the Internet
http://www.philips.com
Printed in China
/05_8239 210 98393
Sgp-SL-0412/05-1
HOTLINE
CLASS 1
LASER PRODUCT
01-36 DVP630_EU_051 18/03/2004, 10:05 AM36
