LFX6G7434BI
EN User Manual | Washing Machine
aeg.com\register
Welcome to AEG! Thank you for choosing our appliance.
Get usage advice, brochures, trouble shooter, service and repair information:
www.aeg.com/support
Subject to change without notice.
CONTENTS
1. SAFETY INFORMATION................................................................................ 2
2. SAFETY INSTRUCTIONS.............................................................................. 4
3. PRODUCT DESCRIPTION............................................................................. 6
4. TECHNICAL DATA......................................................................................... 7
5. INSTALLATION...............................................................................................7
6. CONTROL PANEL........................................................................................ 19
7. DIAL AND BUTTONS....................................................................................20
8. PROGRAMMES............................................................................................ 23
9. SETTINGS.................................................................................................... 26
10. BEFORE FIRST USE..................................................................................27
11. DAILY USE..................................................................................................27
12. HINTS AND TIPS........................................................................................ 31
13. CARE AND CLEANING.............................................................................. 33
14. TROUBLESHOOTING................................................................................ 39
15. CONSUMPTION VALUES.......................................................................... 42
16. ENVIRONMENTAL CONCERNS................................................................44
1. SAFETY INFORMATION
Before beginning the installation and use of this
appliance, carefully read the supplied instructions.
The manufacturer is not responsible for any injuries or
damage that are the result of incorrect installation or usage.
Always keep the instructions in a safe and accessible location
for future reference.
1.1 Children and vulnerable people safety
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved.
2 ENGLISH
• Children between 3 and 8 years of age and persons with
very extensive and complex disabilities shall be kept away
from the appliance unless continuously supervised.
• Children of less than 3 years of age should be kept away
from the appliance unless continuously supervised.
• Children should be supervised to ensure that they do not
play with the appliance.
• Keep all packaging away from children and dispose of it
appropriately.
• Keep detergents away from children.
• Keep children and pets away from the appliance when the
door is open.
• If the appliance has a child safety device, it should be
activated.
• Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
1.2 General Safety
• This appliance is for washing domestic-type, machine-
washable laundry only.
• This appliance is designed for single household domestic
use in an indoor environment.
• This appliance may be used in, offices, hotel guest rooms,
bed & breakfast guest rooms, farm guest houses and other
similar accommodation where such use does not exceed
(average) domestic usage levels.
• Do not change the specification of this appliance.
• The appliance maximum load is 7.0 kg. Do not exceed the
maximum load of each programme (refer to the
“Programmes” chapter).
• The operating water pressure at the water entry point from
the outlet connection must be between 0.5 bar (0.05 MPa)
and 10 bar (1.0 MPa).
• The ventilation opening in the base must not be covered by
a carpet, mat, or any floor covering.
ENGLISH 3
• The appliance must be connected to the water mains using
the new supplied hose sets, or other new hose sets
supplied by the Authorised Service Centre.
• Old hose sets must not be reused.
• If the mains power supply cable is damaged, it must be
replaced by the manufacturer, its Authorised Service Centre
or similarly qualified persons to avoid an electrical hazard.
• Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the socket.
• Do not use high pressure water sprays and/or steam to
clean the appliance.
• Clean the appliance with a moist cloth. Use only neutral
detergents. Do not use abrasive products, abrasive
cleaning pads, solvents or metal objects.
2. SAFETY INSTRUCTIONS
2.1 Installation
The installation must comply with
relevant national regulations.
• Remove all the packaging and the transit
bolts including rubber bush with plastic
spacer.
• Keep the transit bolts in a safe place. If the
appliance is to be moved in the future they
must be reattached to lock the drum to
prevent an internal damage.
• Always take care when moving the
appliance as it is heavy. Always use safety
gloves and enclosed footwear.
• Follow the installation instructions supplied
with the appliance.
• Do not use the appliance before installing
it in the built-in structure due to safety
manner.
• Do not install or use a damaged
appliance.
• Do not install or use the appliance where
the temperature can be less than 0°C or
where it is exposed to the weather.
• The floor area on which the appliance is to
be installed must be flat, stable, heat
resistant and clean.
• Make sure that there is air circulation
between the appliance and the floor.
• When the appliance is in its permanent
position, check if it is levelled correctly
with the aid of a spirit level. If it is not,
adjust the feet accordingly.
• Do not install the appliance directly above
a floor drain.
• Do not spray water on the appliance and
do not expose it to excessive humidity.
• Do not install the appliance where the
appliance door cannot be fully opened.
• Do not put a closed container to collect
possible water leakage under the
appliance. Contact the Authorised Service
Centre to ensure which accessories can
be used.
2.2 Electrical connection
WARNING!
Risk of fire and electric shock.
• WARNING: This appliance is designed to
be installed / connected to a grounding
connection in the building.
• Always use a correctly installed
shockproof socket.
4 ENGLISH
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug and to the mains cable. Should
the mains cable need to be replaced, this
must be carried out by our Authorised
Service Centre.
• Connect the mains plug to the mains
socket only at the end of the installation.
Make sure that there is access to the
mains plug after the installation.
• Do not touch the mains cable or the mains
plug with wet hands.
• Do not pull the mains cable to disconnect
the appliance. Always pull the mains plug.
• This appliance is fitted with a 13 A mains
plug. If it is necessary to change the mains
plug fuse, use only a 13 A ASTA (BS
1362) fuse (UK and Ireland only).
2.3 Water connection
• The inlet water shall not exceed 25 °C.
• Do not cause damage to the water hoses.
• Before connection to new pipes, pipes not
used for a long time, where repair work
has been carried out or new devices fitted
(water meters, etc.), let the water flow until
it is clean and clear.
• Ensure that there are no visible water
leaks during and after the first use of the
appliance.
• Do not use an extension hose if the inlet
hose is too short. Contact the Authorised
Service Centre for the replacement of the
inlet hose.
• When unpacking the appliance, It is
possible to see water flowing from the
drain hose. This is due to the testing of the
appliance with the use of water in the
factory.
• You can extend the drain hose to
maximum 400 cm. Contact the Authorised
Service Centre for the other drain hose
and the extension.
• Make sure that there is access to the tap
after the installation.
2.4 Use
WARNING!
Risk of injury, electric shock, fire, burns
or damage to the appliance.
• Follow the safety instructions on the
detergent packaging.
• Do not put flammable products or items
that are wet with flammable products in,
near or on the appliance.
• Do not wash fabrics which are heavily
soiled with oil, grease or other greasy
substances. It can damage rubber parts of
the washing machine. Prewash such
fabrics by hand before loading them into
the washing machine.
• Do not touch the glass door while a
programme operates. The glass can get
hot.
• Make sure that all metal objects are
removed from the laundry.
2.5 Service
• To repair the appliance contact the
Authorised Service Centre. Use original
spare parts only.
• Please note that self-repair or non-
professional repair can have safety
consequences and might void the
guarantee.
• The following spare parts are available for
at least 10 years after the model has been
discontinued: motor and motor brushes,
transmission between motor and drum,
pumps, shock absorbers and springs,
washing drum, drum spider and related
ball bearings, heaters and heating
elements, including heat pumps, piping
and related equipment including hoses,
valves, filters and aquastops, printed
circuit boards, electronic displays,
pressure switches, thermostats and
sensors, software and firmware including
reset software, door, door hinge and
seals, other seals, door locking assembly,
plastic peripherals such as detergent
dispensers. The duration may be longer in
your country. For further information,
please visit our website.
• Please note that some of these spare
parts are only available to professional
ENGLISH 5
repairers, and that not all spare parts are
relevant for all models.
• Concerning the lamp(s) inside this product
and spare part lamps sold separately:
These lamps are intended to withstand
extreme physical conditions in household
appliances, such as temperature,
vibration, humidity, or are intended to
signal information about the operational
status of the appliance. They are not
intended to be used in other applications
and are not suitable for household room
illumination.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the mains
electrical and water supplies.
• Cut off the mains electrical cable close to
the appliance and dispose of it.
• Remove the door catch to prevent children
or pets from becoming trapped in the
drum.
• Dispose of the appliance in accordance
with local requirements for the disposal of
Waste Electrical and Electronic Equipment
(WEEE).
3. PRODUCT DESCRIPTION
3.1 Appliance overview
10
11 12
13
21 3
4
7
8
9
5
6
1
Hinge supports
2
Detergent dispenser
3
Control panel
4
Magnetic plate
5
Door handle
6
Rating plate
7
Plate with rubber beater
8
Drain pump filter
9
Front feet for levelling the appliance
10
Drain hose
11
Mains cable
12
Inlet hose connection
13
Back feet for levelling the appliance
6 ENGLISH
00000000
00A
Mod.
xxxxxxxxx
000V ~ 00Hz 0000 W
910000000
00
A
B
C
Prod.No.
D
The rating plate reports the model name (A), product
number (B), electrical ratings (C) and serial number
(D).
4. TECHNICAL DATA
Dimension Width/ Height/ Total depth 59.6 cm /81.9 cm /55.3 cm
Electrical connection Voltage
Overall power
Fuse
Frequency
230-240 V
2100 W
13 A
50 Hz
Level of protection against ingress of solid particles and moisture ensured
by the protective cover, except where the low voltage equipment has no
protection against moisture
IPX4
Water supply pressure
1)
Minimum
Maximum
0.5 bar (0.05 MPa)
10 bar (1.0 MPa)
Water supply
2)
Cold water
Maximum Load Cotton 7.0 kg
Spin Speed Maximum spin speed 1351 rpm
1)
The appliance works correctly if the water pressure is not lower than 0.05 MPa (0.5 bar). If you cannot connect
the water inlet hose to the cold water tap of the primary hydraulic system, connect it to your domestic cold water
storage system. Make sure not to exceed a distance of 5.02 m (16.5 ft) between the appliance inlet hose and the
bottom of the water storage tank.
2)
Connect the water inlet hose to a water tap with a 3/4'' thread.
5. INSTALLATION
WARNING!
Refer to Safety chapters.
5.1 Be prepared for installation
It is recommended that installation is
carried out by two persons.
ENGLISH 7
5.2 The appliance is equipped
with ...
x1 x2
x1
E
x2
x1 x1
x2
x4 x1 x1
BA C D
F G H L
5.3 Unpacking
WARNING!
Use the gloves.
WARNING!
Remove all the packaging and the transit bolts before installing the appliance.
1. Put two polystyrene packaging elements
on the floor under the appliance.
WARNING!
It is strongly recommended that this
action is carries out by two persons.
2. Carefully put the appliance down on its
rear side.
Make sure not to damage the hoses.
8 ENGLISH
1
2
3. Remove the polystyrene protection from
the bottom.
1
2
4. Return the appliance in vertical position
and remove the socket polystyrene
protection.
5. Remove the power supply cable and the
drain hose from the hose holders.
It is possible to see water flowing from
the drain hose. This is due to the
testing with water of the appliance in
factory.
6. Remove the three bolts, the hose holders
and plastic spacers by using the spanner
supplied with the appliance.
ENGLISH 9
F
G
7. Close the holes with the plastic caps you
find in the user manual bag. Put the smallest
cap F in upper hole and the two bigger caps
G in lower holes.
We recommend that you keep the packaging and the transit bolts for any movement of the
appliance.
5.4 Installation on suspended
flooring
Suspended wooden floors are particularly
susceptible to vibration.
To limit vibration we recommend placing a
waterproof wooden panel, at least 15 mm
thick, under the appliance. It should be
screwed to at least 2 floor beams and should
extend beyond the front feet.
If possible, install the appliance where the
floor is more stable.
5.5 Positioning and levelling
x4
1. Install the appliance on a flat hard floor.
WARNING!
Make sure that carpets do not stop the air
circulation below the appliance.
Bring the appliance near the furniture
recess before levelling it. For more details,
refer to paragraph "Building in".
2. Loosen or tighten the feet to adjust the level.
A correct adjustment of the appliance level
prevents the vibration, noise and the
movement of the appliance when in
operation.
10 ENGLISH
The appliance must be level and stable.
CAUTION!
Do not put cardboard, wood or equivalent
materials below the appliance feet to
adjust the level.
5.6 Hose and cable connection
1100 mm 1450 mm
960 mm1230 mm
900 mm
1360 mm
max 1000 mm
min. 600 mm
max 1000 mm
min. 600 mm
The inlet hose
1. Remove the inlet hose from inside the drum.
2. To connect the water inlet hose towards the
proper direction and with the proper inclination,
check the position of the water tap before
connecting it to the back of the appliance.
Make sure the hose is nor kinked,
squashed but neither tensed.
ENGLISH 11
20
O
20
O
45
O
45
O
3. Connect the hose to the back of the appliance.
Do not turn the inlet hose downwards, but turn it
left or right depending on the position of your
water tap.
4. Loosen the ring nut to fix it in the correct
position.
5. Connect the water inlet hose to the cold water
tap with 3/4 thread.
WARNING!
The inlet water shall not exceed 25 °C.
WARNING!
Make sure that there are no leaks from the
couplings.
Use the hose supplied with appliance.
Do not use an extension hose if the inlet hose is too short. Contact the Authorised Service
Centre for an inlet hose replacement.
Water drainage
The drain hose can be connected:
Ø 40 mm
To a stand pipe with vent-hole
Directly into a drain pipe at a height of not less
than 60 cm (23.6”) and not more than 100 cm
(39.3”).
The end of the drain hose must always be
ventilated , i.e. the inner diameter of the drain pipe
(min. 40 mm - min. 1.6”) must be larger than the
external diameter of the drain hose.
12 ENGLISH
max.
600 mm
To a sink spigot
Put the drain hose in the spigot and tighten it with
the supplied cable tie L.
Make sure that the drain hose makes a loop to
prevent particles going into the appliance from the
sink.
L
To a wall-pipe
Directly to a built-in drain pipe in the room wall
and tighten it with the supplied cable tie L.
You can extend the drain hose to maximum 400 cm. Contact the service centre for the
other drain hose and the extension.
5.7 Building in
600 mm
min.
820 mm
min.
560 mm
16-22 mm
min.
This appliance has been designed to be built into
the kitchen furniture. See the minimum recess
dimensions in the drawings.
ENGLISH 13
553 mm
596 mm
140 mm
76 mm
50 mm
50 mm
819 mm
If hoses run behind the appliance, make
sure that nothing closes the small recess
indicated with the measures 50 x 50 mm.
The appliance is also equipped with an adhesive
sponge pad H that you can find inside the drum.
Attach it on the top of the appliance where
indicated in the drawing.
When levelling the appliance under the furniture,
DO NOT squeeze the sponge pad.
Before proceeding with appliance building in,
bring it near the recess and preposition the inlet
hose, the drain hose and the mains cable.
WARNING!
Make sure they are not kinked or
squashed.
5.8 Installing anti-tilting device
(Accessory)
Install this accessory in case of risk of appliance tilting only.
If the height of the counter is 820 mm or lower, you cannot install the anti-tilting device.
14 ENGLISH
1. Remove the screws of the top cover on the rear
of the appliance and install the anti-tilting device
as shown in the drawing.
~10mm
2. Adjust the anti-tilting device so that the distance
from the counter is 10mm. Loosen the nut
counterclockwise with a 3mm wrench. Adjust the
height and turn the nut clockwise to fix it.
5.9 Preparation and assembly of the cupboard door
The dimensions of the cupboard door should be:
• width min. 595 - max. 598 mm;
• thickness 16-22 mm.
Factory pre setting
The appliance is originally pre set for the
assembly of a cupboard door opening from right
to left.
The best solution would be to screw the
upper hinge to the upper hole of the top
plate and the lower hinge to the lower hole
of the bottom plate.
ENGLISH 15
Reversibility of the cupboard door
Carry out the cupboard door reversibility before
the appliance is built in completely.
M
N
O
If the cupboard door has to be opened from left to
right, invert the position of the hinge supports M
with the magnetic plate N and lower plate O.
M
N
O
Make sure that the plate with magnet is on
the upper position.
x
y
y
Cupboard door preparation
For countersinking the door, it is
recommended to call a professional.
Align the cupboard door to the furniture correctly.
Measure the distance X to fix the height of the
hole to countersink the upper hinge. The centre of
the hole Y should be at the same height of the
stroke on the hinge support.
16 ENGLISH
16-22 mm
22±1,5 mm
449
mm
595-598 mm
Ø 35 mm
12,5 - 14 mm
Set the position of the lower hole respecting
dimensions and distances shown in the drawing
(449 mm).
Countersink the holes.
A
Hinges
To mount the hinges it is necessary to drill two
holes (dia. 35 mm, depth 12.5 - 14 mm
depending on the depth of cupboard door) on the
inner side of the door.
The hinges will be fixed to the door by means of
the four supplied screws A.
max. 105°
To align the door perfectly, make sure that
the edge of cupboard door is parallel with
the appliance edge and to respect the
proper opening angle (max. 105 °).
Mounting the door
Fix the hinges to the hinge supports on the
appliance by means of the two supplied screws
B.
The hinges can be adjusted to
compensate for possible uneven thickness
of the door.
ENGLISH 17
2
N
1
E
D
C
Counter-magnet
The appliance is pre set for a magnetic closure.
For a correct closure:
1. Position the screw C and the counter-magnet
D on the magnetic plate N. Lean the
cupboard door against the screw until it
leaves a mark.
2. Open the cupboard door and screw the
counter-magnet D (steel disk + rubber ring E)
with the screw C in the inner side of the
cupboard door, where the screw left the mark
as described in the first step.
Flexible machine stopper
The supplied plastic stopper can be only
installed when the appliance installation is
complete, to avoid movement outward. Fix
it on the furniture, near the front panel
taking as reference height the middle of
the door, on the opposite side of the
hinges.
5.10 Electrical connection
At the end of installation you can connect the
mains plug to the mains socket.
The rating plate and the 'Technical Data'
chapter indicate the necessary electrical
ratings. Make sure that they are compatible
with the mains power supply.
Check that your domestic electrical
installation can take the maximum load
required, also taking into account any other
appliances may also be in use.
Connect the appliance to an earthed
socket.
The power supply cable must be easily
accessible after installing the appliance.
For any electrical work required to install this
appliance, contact our Authorised Service
Centre.
The manufacturer does not accept any
responsibility for damage or injury through
failure to comply with the above safety
precaution.
18 ENGLISH
6. CONTROL PANEL
6.1 Control panel description
1
10
7
6
8
9
11
5
2 3 4
The permanent options are set by
holding pressed the relative button for at
least 3 seconds.
1
Programme dial
2
Display
3
Delay Start touch button
4
Time Save touch button
5
Start/Pause touch button
6
Stains touch button and permanent Child
Lock option
7
Extra Rinse touch button
8
Prewash touch button
9
Spin reduction options touch button
• Rinse Hold option
• No spin option
• Night option
10
Temperature touch button
11
On/Off push button
6.2 Display
ENGLISH 19
Door locked indicator.
Delay start indicator.
The digital indicator can show:
• Reset position ( ).
• Programme duration (e. g. ).
• Delay time (e. g.
).
• Cycle end ( ).
• Warning code (e.g.
).
• Error indicator (
).
Time Save indicator.
Anti-stain indicator.
Extra Rinse indicator.
Add garments indicator. it lights at the beginning of the washing phase, when it is
still possible to pause the appliance and add more laundry.
Child safety lock indicator.
Machine clean indicator. This is a recommendation to perform the drum cleaning.
7. DIAL AND BUTTONS
7.1 Introduction
The options/functions are not available
with all washing programmes. Check the
compatibility between options/functions
and washing programmes in the
"Programme Chart". An option/function
can exclude another one, in this case the
appliance doesn't allow you to set
incompatible options/functions.
7.2 On/Off
Press this button for a few seconds to
activate or deactivate the appliance. Two
different tunes sound while switching the
appliance on or off.
As the Stand-by function automatically
deactivates the appliance after several
minutes to reduce the energy consumption,
you may need to activate the appliance
again.
For more details, refer to Stand-by paragraph
in Daily Use chapter.
7.3 Programme dial
For selecting the desired washing
programme. Refer to 'Programmes' chapter
for more details.
The position
is a "Reset" function, which
stops and resets the running programme. The
display shows empty dashes to indicate that
no programme was selected.
7.4 Temperature
When you select a washing programme, the
appliance automatically proposes a default
temperature.
The indicator Cold = cold water.
20 ENGLISH
The indicator of the set temperature comes
on.
7.5 Spin
When you set a programme, the appliance
automatically sets the default spin speed
allowed for each programme.
By means of this button, you can change
the default spin speed or set one of the
additional spin options:
• Rinse Hold . The related indicator
comes on.
The final spin is not performed. The water
of the last rinse is not drained out to
prevent the fabrics from creasing. The
washing programme ends with water in
the drum.
The door stays locked and the drum turns
regularly to reduce creasing. You must
drain the water to unlock the door.
If you touch the Start/Pause button,
the appliance performs the spinning phase
and drains the water.
• No spin . The related indicator comes
on.
Set this option to deactivate all spin
phases. The appliance performs only the
draining phase of the selected washing
programme. Set this option for very
delicate fabrics. The rinse phase uses
more water for some washing
programmes
• Night . The related indicator comes on.
The intermediate and the final spinning
phases are suppressed and the
programme ends with water in the drum.
This helps to reduce creasing. The door
stays locked. The drum turns regularly to
reduce creasing. You must drain the water
to unlock the door.
As the programme is very quiet, it is
suitable for use at night time when
cheaper electricity tariffs are available. In
some programmes the rinses are
performed with more water.
If you touch the Start/Pause button,
the appliance performs only the draining
phase.
The appliance empties the water out
automatically after approximately 18
hours.
7.6 Prewash
With this option you can add a prewash
phase to a washing programme.
The corresponding indicator above the touch
button illuminates.
• Use this option to add a pre-wash phase
at 30 °C before the washing phase.
This option is recommended for heavily
soiled laundry, especially if containing
sand, dust, mud and other solid particles.
The options can increase the programme
duration.
7.7 Permanent Extra Rinse
With this option you can add a few rinses
according to the selected washing
programme.
Use this option for people with allergies to
detergent residues and with sensitive skin.
This option increases the programme
duration.
The corresponding indicator above the touch
button illuminates and also stays permanently
on during next cycles until this option is
deactivated.
7.8 Stains
Touch this button to add the stain phase to a
programme.
The corresponding indicator above the touch
button illuminates.
Use this option for laundry with hard stains to
remove.
When you set this option, put the stain
remover into compartment
.
ENGLISH 21
This option increases the programme
duration.
This option is not available with a
temperature lower than 40 °C.
7.9 Child Lock
With this option you can prevent children from
playing with the control panel.
To activate/deactivate this option, hold the
Plus Steam button pressed until the indicator
comes on/goes off on the display.
When it is activated, the appliance will default
to this option after you switch it off or change/
reset the programme. If you press any button,
the indicator blinks to indicate that the
buttons are disabled.
The Child Lock function may not be available
for a few seconds after switching the
appliance on.
7.10 Delay Start
With this option you can delay the start of a
programme to a more convenient time.
Touch the button repeatedly to set the
required delay. The time increases in steps of
1 hour up to 20 hours.
The display shows the indicator and the
selected delay time. After touching the Start/
Pause button, the appliance begins the
countdown and the door is locked.
7.11 Time Save
With this option you can reduce the
programme duration depending on the load
size and the degree of soiling.
When you set a washing programme, the
display shows the default duration and
dashes.
Touch Time Save button to reduce the
programme duration according to your needs.
The display shows the new programme
duration and a number of dashes will
decrease accordingly:
suitable for a full load of normally soiled
garments.
a quick cycle for a full load of lightly
soiled garments.
very quick cycle for a smaller lightly
soiled load (max. half load recommended).
the shortest cycle to freshen up a small
amount of laundry.
The Time Save is available only with the
programmes in the table.
In some appliances the programme
duration is reduced without showing any
dashes.
7.12 Start/Pause
Touch the Start/Pause button to start,
pause the appliance or interrupt a running
programme.
22 ENGLISH
8. PROGRAMMES
8.1 Programme Chart
Programme
Default tempera‐
ture
Temperature
range
Reference
spin speed
(rpm)
Maxi‐
mum
load
Programme description
(Type of load and level of soiling)
Eco 40-60
40 °C
1)
1400 rpm
(1400- 800
rpm)
7.0 kg White cotton and fast-coloured cotton. Normally soiled
items. The energy consumption decreases and the time of the
washing programme is extended, ensuring good washing re‐
sults.
Cottons
40 °C
90 °C - Cold
1400 rpm 7.0 kg White cotton and coloured cotton. Normal and heavy soil.
Synthetics
40 °C
60 °C - Cold
1200 rpm 3.0 kg Synthetic items or mixed fabric items. Normally soiled
items.
Delicates
30 °C
40 °C - Cold
1200 rpm 2.0 kg Delicate fabrics such as acrylics, viscose and mixed fab‐
rics requiring gentler washing. Normally and lightly soiled
items.
Easy Iron
40 °C
60 °C - Cold
800 rpm 3.0 kg Synthetic items requiring a gentle wash. Normally and
lightly soiled items.
2)
Mixed
30 °C
40 °C - Cold
1200 rpm 3.0 kg Synthetic and mixed fabrics. Normally soiled items.
Spin/Drain
1400 rpm 7.0 kg All fabrics, except woollens and delicate fabrics. To spin
the laundry and to drain the water in the drum.
Rinse
1400 rpm 7.0 kg All fabrics, except woollens and very delicate fabrics.
Programme for rinsing and spinning the laundry. The default
spin speed is the one used for cotton programmes. Reduce
the spin speed according to the type of laundry. If necessary,
set the Extra Rinse option to add rinses. With a low spin
speed, the appliance performs delicate rinses and a short
spin.
ENGLISH 23
Programme
Default tempera‐
ture
Temperature
range
Reference
spin speed
(rpm)
Maxi‐
mum
load
Programme description
(Type of load and level of soiling)
Machine Clean
60 °C
1200 rpm - Maintenance cycle with hot water to clean and freshen the
drum and to remove residue that may cause odour. For the
best result use this cycle once a month. Before running this
cycle, remove all items from the drum. In the washing phase
compartment of the detergent dispenser, put the flap of the
compartment in upward position. Pour a cup of chlorine
bleach or a washing machine cleaner in the washing phase
compartment. DO NOT use both together.
After the drum cleaning, run a further rinse cy‐
cle with empty drum and no detergent to re‐
move any residue of bleach.
Duvet
40 °C
60 °C - Cold
800 rpm
3.0 kg
Single synthetic blanket, padded clothes, duvets, down
jackets and similar items.
20min 3kg
30 °C
40 °C - 30 °C
1200 rpm 3.0 kg Cotton and synthetic items lightly soiled or once worn.
Sport
30 °C
40 °C - Cold
1200 rpm 3.0 kg Mixed fabric sportswear. Lightly soiled items or items to re‐
fresh.
Denim
30 °C
40 °C - Cold
800 rpm 3.0 kg Special programme for Denim clothing with delicate
washing phase to minimize colour fading and marks. For
better care a reduced load size is recommended.
Wool/Silk
®
40 °C
40 °C - Cold
1200 rpm 1.5 kg Machine washable wool, hand washable wool and other
fabrics with «hand washing» care symbol
3)
.
1)
According to UK Ecodesign for Energy-Related Products and Energy Information Regulations and to the EU
Ecodesign Regulation 2019/2023 and the EU Energy Label Regulation 2019/2014, this programme at 40 °C is able
to clean normally soiled cotton laundry declared to be washable at 40 °C or 60 °C, together in the same cycle.
For the reached temperature in the laundry, the programme duration and other data, please refer to 'Con‐
sumption Values' chapter.
The most efficient programmes in terms of energy consumption are generally those that perform at lower tem‐
peratures and longer duration.
2)
To reduce creasing, this cycle regulates the water temperature and performs a soft wash and spin phase. The
appliance adds some rinses.
3)
During this cycle the drum rotates slowly to ensure a gentle wash. It can seem that the drum doesn't rotate or
doesn't rotate properly, but this is normal for this programme.
24 ENGLISH
Programme options compatibility
Programme
Spin
Rinse Hold
No spin
Night
Extra Rinse
Prewash
Stains
1)
Delay Start
Time Save
Eco 40-60
■ ■ ■
Cottons
■ ■ ■ ■ ■ ■ ■ ■ ■
Synthetics
■ ■ ■ ■ ■ ■ ■ ■ ■
Delicates
■ ■ ■ ■ ■ ■
Easy Iron
■ ■ ■ ■ ■ ■ ■
Mixed
■ ■ ■ ■ ■ ■ ■ ■
Spin/Drain
■
■
2)
■
Rinse
■ ■ ■ ■ ■
Machine Clean
■ ■
Duvet
■ ■
20min 3kg
■ ■ ■ ■
Sport
■ ■ ■ ■ ■ ■
Denim
■ ■ ■ ■ ■ ■ ■
Wool/Silk
®
■ ■ ■ ■
1)
This option is not available with temperature lower than 40 °C.
2)
When setting the No Spin option, the appliance performs drain only.
Suitable detergents for washing programmes
Programme Universal
powder
1)
Liquid Univer‐
sal
Liquid for col‐
oureds
Delicates
woollens
Special
Eco 40-60 ▲ ▲ ▲ -- --
Cottons ▲ ▲ ▲ -- --
Synthetics ▲ ▲ ▲ -- --
Delicates -- -- -- ▲ ▲
Easy Iron ▲ ▲ ▲ -- --
Mixed -- ▲ ▲ -- --
ENGLISH 25
Programme Universal
powder
1)
Liquid Univer‐
sal
Liquid for col‐
oureds
Delicates
woollens
Special
Duvet -- -- -- ▲ ▲
20min 3kg -- ▲ ▲ -- --
Sport -- ▲ ▲ -- ▲
Denim -- -- ▲ ▲ ▲
Wool/Silk -- -- -- ▲ ▲
1)
At temperature higher than 60 °C the use of powder detergent is recommended.
▲ = Recommended -- = Not recommended
8.2 Woolmark Wool Care - Blue
The wool wash cycle of this machine has been approved
by The Woolmark Company for the washing of wool gar‐
ments labelled as «hand wash» provided that the prod‐
ucts are washed according to the instructions on the gar‐
ment label and those issued by the manufacturer of this
washing machine. M1380
The Woolmark symbol is a Certification mark in many
countries.
9. SETTINGS
9.1 Acoustic signals
This appliance has different acoustic signals,
that operate when:
• You activate the appliance (special short
tune).
• You deactivate the appliance (special
short tune).
• You touch the buttons (click sound).
• You make an invalid selection (3 short
sounds).
• The programme is completed (sequence
of sounds for about 2 minutes).
• The appliance has a malfunction
(sequence of short sounds for about 5
minutes).
To activate/deactivate the acoustic signals
when the programme is completed, touch the
Temp. and the Spin buttons simultaneously
for about 2 seconds. The display shows On
or Off.
If you deactivate the acoustic signals,
they continue to operate when the
appliance has a malfunction.
26 ENGLISH
10. BEFORE FIRST USE
1. Make sure that the electrical power is
available and the water tap is open.
2. Pour 2 litres of water into the detergent
compartment marked by .
This action activates the drain system.
3. Pour a small quantity of detergent into the
compartment marked by .
4. Set and start a programme for cotton at
the highest temperature without any
laundry in the drum.
This removes all possible dirt from the drum
and the tub.
11. DAILY USE
WARNING!
Refer to Safety chapters.
11.1 Activating the appliance
1. Connect the mains plug to the mains
socket.
2. Open the water tap.
3. Press the On/Off button for a few
seconds to activate the appliance.
A short tune sounds.
11.2 Loading the laundry
1. Open the appliance door.
2. Empty the pockets and unfold the items
before you put them in the appliance.
3. Put the laundry in the drum, one item at a
time.
Do not put too much laundry in the drum.
4. Close the door firmly.
CAUTION!
Make sure that no laundry gets caught
between the seal and the door to avoid
risk of water leakage and damage to the
laundry.
Washing heavily oiled, greasy stains
could cause damage to rubber parts of
the washing machine.
11.3 Filling the detergent and
additives
- Compartment for prewash phase, soak pro‐
gramme or stain remover.
- Compartment for washing phase.
- Compartment for fabric softener and other liquid
treatments(fabric conditioner, starch).
- Maximum level for quantity of liquid additives.
ENGLISH 27
- Flap for powder or liquid detergent.
Always follow the instructions that you
find on the packaging of the detergent
products, but we recommend that you do
not exceed the maximum indicated level
( ). This quantity will however
guarantee the best washing results.
After a washing cycle, if necessary,
remove any detergent residue from the
detergent dispenser.
11.4 Check the position of the
detergent flap
1. Pull out the detergent dispenser until it
stops.
2. Press the lever down to remove the
dispenser.
3. To use powder detergent, turn the flap
up.
4. To use liquid detergent, turn the flap
down.
With the flap in the position DOWN:
• Do not use gelatinous or thick liquid
detergents.
• Do not exceed to liquid detergent dose
indicated on the flap.
• Do not set the prewash phase.
• Do not set the delay start function.
5. Measure out the detergent and the fabric
conditioner.
6. Carefully close the detergent dispenser.
Make sure that the flap does not cause a
blockage when you close the drawer.
11.5 Setting a programme
1. Turn the programme dial to select the
desired washing programme. The first
programme on the top right of the
programme dial is Eco 40-60, the
programme to which the information of
the energy label relates.
The indicator of the Start/Pause button
flashes.
The display shows an indicative programme
duration.
2. To change the temperature and/or the
spin speed, touch the related buttons.
3. If desired, set one or more options by
touching the related buttons. The related
indicators will light up and the given
information will change on the display
accordingly.
If a selection is not possible an acoustic
signal sounds and the display shows
.
28 ENGLISH
11.6 Starting a programme
Touch the Start/Pause button to start the
programme. It is not possible to start the
programme when the indicator of the button
is off and doesn't flash (e.g. programme dial
on a wrong position).
The related indicator stops flashing and stays
on.
The programme starts, the door is locked.
The display shows the indicator .
The drain pump can operate shortly
before the appliance fills water.
11.7 Starting a programme with the
delay start
1. Touch the Delay Start button repeatedly
until the display shows the desired delay
time. On the display the indicator shows
2. Touch the Start/Pause button. The
appliance door locks and starts the
countdown of the delay start. The display
shows the indicator .
When the countdown is completed, the
programme starts automatically.
Cancelling the delay start after the
countdown has started
To cancel the delay start:
1. Touch the Start/Pause button to
pause the appliance. The related
indicator flashes.
2. Touch the Delay Start button repeatedly
until the display shows and the
indicator goes off.
3. Touch the Start/Pause button again to
start the programme immediately.
Changing the delay start after the
countdown has started
To change the delay start:
1. Touch the Start/Pause button to
pause the appliance. The related
indicator flashes.
2. Touch the Delay Start button repeatedly
until the display shows the desired delay
time.
3. Touch the Start/Pause button again to
start the new countdown.
11.8 The ProSense System load
detection
The programme duration in the display is
referred to a medium/high load.
After touching the Start/Pause button, the
ProSense System starts the laundry load
detection:
1. The appliance detects the load in the first
30 seconds. In the programmes where
Time Save is available, during this phase
dot separating hours from minutes is
blinking and the drum rotates shortly.
2. The programme duration could be
adjusted accordingly and could increase
or decrease. After further 30 seconds, the
water filling starts.
About 20 minutes after the programme
start, the programme duration could be
adjusted again depending on the
capacity of water absorption of the
fabrics.
The ProSense detection is carried out
with complete washing programmes only
and if the programme duration has not
been reduced.
The ProSense System is not available
with all programmes such as :Wool/Silk,
Rinse, Spin and programmes with short
cycles.
ENGLISH 29
11.9 Interrupting a programme and
changing the options
When the programme is running, you can
change only some options:
1. Touch the Start/Pause button.
The related indicator flashes.
2. Change the options. The given
information in the display changes
accordingly.
3. Touch the button Start/Pause again.
The washing programme continues.
11.10 Cancelling a running
programme
1. Press the button On/Off to cancel the
programme and to deactivate the
appliance.
2. Press the button On/Off again to activate
the appliance.
If the ProSense System has completed
and the water filling has already started,
the new programme starts without
repeating the ProSense System. The
water and the detergent are not drained
out in order to avoid waste. The display
shows the maximum duration of the
programme, updating it about 20 minutes
after the starting of the new programme.
There is also an alternative way of cancelling:
1. Rotate the selector knob to the "Reset"
position .
2. Wait for 1 second. The display shows
.
Now, you can set a new washing programme.
11.11 Opening the door - Adding
garments
If the temperature and level of the water
in the drum are too high and/or the drum
is still rotating you should not open the
door.
While a programme or the delay start
operates, the appliance door is locked. The
display shows the indicator .
1. Touch the Start/Pause button.
In the display the related door lock indicator
goes off.
2. Open the appliance door. If necessary,
add or remove the items. Close the door
and touch the Start/Pause button.
The programme or the delay start continues.
11.12 End of the programme
When the programme has finished, the
appliance stops automatically. The acoustic
signals operate (if they are active). The
display shows
The indicator of the Start/Pause button
goes off.
The door unlocks and the indicator goes
off.
1. Press button On/Off to deactivate the
appliance.
After five minutes from the end of the
programme, the energy saving function
automatically deactivates the appliance.
When you activate the appliance again,
the display shows the end of the previous
programme. Turn the programme dial to
set a new cycle.
2. Remove the laundry from the appliance.
3. Make sure that the drum is empty.
4. Keep the door and the detergent
dispenser slightly ajar to prevent mildew
and odours.
11.13 Draining water out after end
of cycle
If you have chosen a programme or an option
that does not empty out the water of the last
rinse, the programme is completed, but:
• The time area shows and the
display shows the door locked .
• The indicator of the Start/Pause button
starts flashing.
• The drum still turns at regular intervals to
prevent creases in the laundry.
• The door stays locked.
30 ENGLISH
• You must drain the water to open the
door:
1. If necessary, touch the Spin button to
decrease the spin speed proposed by the
appliance.
2. Press the Start/Pause button: the
appliance drains the water and spins.
The option indicator Rinse Hold or
disappears.
If you have set Night and the spin
speed is not changed, when you press
the Start/Pause button, the appliance
only drains the water.
3. When the programme is completed and
the door locked indicator goes off,
you can open the door.
4. Press the On/Off button for a few
seconds to deactivate the appliance.
11.14 Stand-by function
The Stand-by function automatically
deactivates the appliance to reduce the
energy consumption when:
• You do not use the appliance for 5
minutes when no programme is running.
Press the button On/Off to activate the
appliance again.
• 5 minutes after the end of the washing
programme.
Press the On/Off button to activate the
appliance again.
The display shows the end of the last
programme.
Turn the programme dial to set a new
cycle.
If the dial is rotated to the "Reset" position ,
the appliance automatically turns off in 30
seconds.
If you set a programme or an option that
ends with water in the drum, the Stand-
by function doesn't deactivate the
appliance to remind you to drain the
water.
12. HINTS AND TIPS
WARNING!
Refer to Safety chapters.
12.1 The laundry load
• Divide the laundry into: white, coloured,
synthetics, delicates and wool.
• Follow the washing instructions on the
laundry care labels.
• Do not wash white and coloured items
together.
• Some coloured items can discolour with
the first wash. We recommend that you
wash them separately for the first couple
of times.
• Turn multilayered fabrics, wool and items
with printed illustrations inside out.
• Pre-treat stubborn stains.
• Wash stubborn stains with a special
detergent.
• Be careful with curtains. Remove the
hooks and put the curtains in a washing
bag or pillowcase.
• A very small load can cause balance
problems with the spin phase leading to
excessive vibration. If this occurs:
a. interrupt the programme and open the
door (refer to "Daily Use" chapter);
b. manually redistribute the load so that
the items are spaced evenly around
the tub;
c. press the Start/Pause button. The
spin phase continues.
• Button up pillowcases, close zippers,
hooks and poppers. Tie up belts, cords,
shoelaces, ribbons and any other loose
elements.
• Do not wash laundry without hems or with
cuts. Use a washing bag to wash small
and/or delicate items (e.g. underwired
ENGLISH 31
bras, belts, tights, shoelaces, ribbons,
etc. ).
• Empty pockets and unfold the items.
12.2 Stubborn stains
For some stains, water and detergent is not
sufficient.
We recommend that you pre-treat these
stains before you put the items in the
appliance.
Special stain removers are available. Use the
special stain remover that is applicable to the
type of stain and fabric.
Do not spray stain remover on garments near
the appliance as it is corrosive to the plastic
parts.
12.3 Detergent type and quantity
The choice of detergent and use of correct
quantities not only affects your wash
performance, but also helps to avoid waste
and protect the environment:
• Use only detergents and other treatments
specially made for washing machines.
First, follow these generic rules:
– powder detergents (also tablets and
single-dose detergents) for all types of
fabric, excluding delicate. Prefer
powder detergents containing bleach
for whites and laundry sanitization,
– liquid detergents (also single-dose
detergents) , preferably for low
temperature wash programmes (60 °C
max) for all types of fabric, or special
ones for woollens only.
• The choice and quantity of detergent will
depend on: type of fabric (delicates,
woollens, cottons, etc), the colour of
clothes, size of the load, degree of soiling,
wash temperature and hardness of the
water used.
• Follow the instructions that you find on
packaging of the detergents or other
treatments without exceeding the
indicated maximum level (
).
• Do not mix different types of detergents.
• Use less detergent if:
– you are washing a small load,
– the laundry is lightly soiled,
– there is large amounts of foam during
washing.
• When using detergent tabs or pods,
always put them inside the drum, not in
the detergent dispenser and follow the
manufacturer's recommendations .
Insufficient detergent may cause:
• unsatisfactory washing results,
• the wash load to turn grey,
• greasy clothes,
• mould in the appliance.
Excessive detergent may cause:
• sudsing,
• reduced washing effect,
• inadequate rinsing,
• a greater impact for the environment.
12.4 Ecological hints
To save water, energy and to help protect the
environment, we recommend that you follow
these tips:
• Normally soiled laundry may be washed
without prewash in order to save
detergent, water and time (the
environment is protected too!).
32 ENGLISH
• Loading the appliance to the maximum
capacity indicated for each
programmes helps to reduce energy
and water consumption.
• With adequate pre-treatment, stains and
limited soiling can be removed; the
laundry can then be washed at a lower
temperature.
• To use the correct quantity of detergent,
refer to the quantity suggested by the
detergent producer and check the water
hardness of you domestic system. Refer
to 'Water hardness'.
• Set the maximum possible spin speed
for the selected washing programme
before drying your laundry in a tumble
dryer. This will save energy during drying!
12.5 Water hardness
If the water hardness in your area is high or
moderate, we recommend that you use a
water softener for washing machines. In
areas where the water hardness is soft it is
not necessary to use a water softener.
To find out the water hardness in your area,
contact your local water authority.
Use the correct quantity of water softener.
Follow the instructions that you find on the
packaging of the product.
13. CARE AND CLEANING
WARNING!
Refer to Safety chapters.
13.1 Periodic cleaning schedule
Periodic cleaning helps to extend the life
of your appliance.
After each cycle, keep the door and the
detergent dispenser slightly ajar to get air
circulation and dry the humidity inside the
appliance: this will prevent mildew and
odours.
If the appliance is not used for a long time:
close the water tap and unplug the appliance.
Indicative periodic cleaning schedule:
Descaling Twice a year
Maintenance wash Once a month
Clean door seal Every two months
Clean drum Every two months
Clean detergent dispens‐
er
Every two months
Clean drain pump filter Twice a year
Clean the inlet hose and
the valve filter
Twice a year
The following paragraphs explain how you
should clean each part.
13.2 Removing foreign objects
Make sure that pockets are empty and all
loose elements are tied up before
running your cycle. Refer to "The laundry
load" in "Hints and tips".
Remove any foreign objects (such as metal
clip, buttons, coins, etc) that you may find in
the door seal, the filters and the drum. Refer
to "Door seal with double lip trap", "Cleaning
the drum", "Cleaning the drain pump" and
"Cleaning the inlet hose and the valve filter"
paragraphs. If necessary, please contact the
Authorised Service Centre.
13.3 External cleaning
Clean the appliance with mild soap and warm
water only. Fully dry all the surfaces. Do not
use a scouring pads or any scratching
material.
CAUTION!
Do not use alcohol, solvents or chemical
products.
CAUTION!
Do not clean the metal surfaces with
chlorine-based detergent.
ENGLISH 33
13.4 Descaling
If the water hardness in your area is high
or moderate, we recommend that you
use a water descaling product for
washing machines.
Regularly examine the drum to check for
limescale.
Regular detergents already contain water
softening agents, but we recommend to run a
cycle with an empty drum and a descaling
product.
Always follow the instructions that you
find on the packaging of the product.
13.5 Maintenance wash
The repeated and prolonged use of low
temperature programmes can cause
detergent deposits, fluff residues, bacterial
growth inside the drum and the tub. This
could generate bad odours and mildew. To
eliminate these deposits and clean the inner
part of the appliance, run a maintenance
wash regularly (at least once a month).
Refer to "Cleaning the drum" paragraph.
13.6 Door seal with double lip trap
This appliance is designed with a self
cleaning draining system, allowing light fluff
fibers that fall off the clothes to be drained out
with the water. Regularly examine the seal.
Coins, buttons, other small items can be
recovered at the end of the cycle.
Clean it when needed, using ammonia cream
cleanser agent without scratching the seal
surface.
Always obey the instructions that you find
on the packaging of the product.
Check and remove objects (if there are any)
that could be trapped in the fold.
Make sure that no laundry remains between
the seal and the door.
Use a moist cloth to wipe off any dirt or water
residue left behind in the door seal after
completion of program cycle.
13.7 Cleaning the drum
Regularly examine the drum to prevent
unwanted deposits.
Rust deposits in the drum may occur due to
rusting foreign body in the washing or tap
water containing iron
Clean the drum with special products for
stainless steel.
Always follow the instructions that you
find on the packaging of the product.
Do not clean the drum with acidic
descaling products, scouring products
containing chlorine or iron or steel wool.
For a thorough clean:
1. Remove all laundry from the drum.
2. Run the Machine Clean programme. For
more details, refer to washing programme
table.
3. Add a small quantity of powder detergent
into the empty drum, in order to rinse out
any left residues.
Occasionally, at the end of a cycle the
display may show the icon : this is a
recommendation to perform the “drum
cleaning”. Once the drum cleaning has
been performed, the icon disappears.
34 ENGLISH
13.8 Cleaning the detergent
dispenser
To prevent possible deposits of dried
detergent or clotted fabric softener and/or
formation of mould in the detergent dispenser
drawer, once in a while carry out the following
cleaning procedure:
1. Open the drawer. Press the catch
downwards as indicated in the picture
and pull it out.
2. Remove the top part of the additive
compartment to aid cleaning and flush it
out under running warm water, to remove
any traces of accumulated detergent.
After cleaning, put the top part back into
position.
3. Make sure that all detergent residue is
removed from the upper and lower part of
the recess. Use a small brush to clean
the recess.
4. Insert the detergent drawer into the guide
rails and close it. Run the rinsing
programme without any clothes in the
drum.
13.9 Cleaning the drain pump
WARNING!
Disconnect the mains plug from the
mains socket.
Regularly check the drain pump filter and
make sure that it is clean.
Clean the drain pump if:
• The appliance does not drain the water.
• The drum does not turn.
• The appliance makes an unusual noise
because of the blockage of the drain
pump.
• The display shows the alarm code .
ENGLISH 35
WARNING!
• Do not remove the filter while the
appliance operates.
• Do not clean the pump if the water in
the appliance is hot. Wait until the
water cools down
Proceed as follows to clean the pump:
1
2
1. Open the pump cover.
2. Place a suitable bowl below the drain pump
access to collect the water that flows out.
Always keep a rag nearby to dry up any water
spillages when removing the filter.
180˚
3. Turn the filter 180 degrees in anti-clockwise
direction to open it, without removing. Let the water
flow out.
4. When the bowl is full of water, turn the filter back
and empty the container.
5. Repeat the steps 3 and 4 until the water stops to
flow out.
36 ENGLISH
1
2
6. Turn the filter anti-clockwise to remove it
7. If it is necessary, remove fluff and objects from
the filter recess.
Make sure that the impeller of the pump can rotate.
If it does not rotate, contact the Authorised Service
Centre.
8. Clean the filter under the water tap.
2
1
9. Put the filter back into the special guides by
turning it clockwise. Make sure that you tighten the
filter correctly to prevent leakages.
ENGLISH 37
1
2
10. Close the pump cover.
When you drain the water with the emergency drain procedure, you must activate the drain system
again:
1. Put 2 litres of water in the main wash compartment of the detergent dispenser.
2. Start the programme to drain the water.
13.10 Cleaning the inlet hose and the valve filter
1
2
3
45°
20°
13.11 Emergency drain
If the appliance cannot drain the water, carry
out the same procedure, described in
'Cleaning the drain pump' paragraph. If
necessary, clean the pump.
When you drain the water with the
emergency drain procedure, you must
activate the drain system again:
1. Put 2 litres of water in the main wash
compartment of the detergent dispenser.
2. Start the programme to drain the water.
38 ENGLISH
13.12 Frost precautions
If the appliance is installed in an area where
the temperature can reach values around 0°
C or drop below, remove the remaining water
from the inlet hose and the drain pump.
1. Disconnect the mains plug from the
mains socket.
2. Close the water tap.
3. Put the two ends of the inlet hose in a
container and let the water flow out of the
hose.
4. Empty the drain pump. Refer to the
emergency drain procedure.
5. When the drain pump is empty, install the
inlet hose again.
WARNING!
Make sure that the temperature is higher
than 0 °C before you use the appliance
again.
The manufacturer is not responsible for
damages caused by low temperatures.
14. TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
14.1 Alarm Codes and Possible failures
The appliance does not start or it stops during operation. First try to find a solution to the problem
(refer to the tables).
WARNING!
Deactivate the appliance before carrying out any check.
With some problems, the display shows an alarm code and the Start/
Pause button may flash continuously:
If the appliance is overloaded, remove some items from the drum
and/or keep pressed the door while touching the Start/Pause
button until the indicator stops flashing (see the picture below).
ENGLISH 39
Problem Possible solution
The appliance does not fill
with water properly.
• Make sure that the water tap is open.
• Make sure that the pressure of the water supply is not too low. For this infor‐
mation, contact your local water authority.
• Make sure that the water tap is not clogged.
• Make sure that the inlet hose has no kinks, damages or bends.
• Make sure that the connection of the water inlet hose is correct.
• Make sure that the filter of the inlet hose and the filter of the valve are not clog‐
ged. Refer to 'Care and cleaning'.
The appliance does not
drain the water.
• Make sure that the sink spigot is not clogged.
• Make sure that the drain hose has no kinks or bends.
• Make sure that the drain filter is not clogged. Clean the filter, if necessary. Re‐
fer to "Care and cleaning".
• Make sure that the connection of the drain hose is correct.
• Set the drain programme if you set a programme without drain phase.
• Set the drain programme if you set an option which ends with water in the tub.
The appliance door is open
or not closed correctly.
• Make sure that the door is properly closed.
Internal fail. No communica‐
tion between electronic ele‐
ments of the appliance.
• The programme was not finished properly or the appliance stopped too early.
Switch the appliance off and on again.
• If the alarm code appears again, contact the Authorised Service Centre.
The mains supply is unsta‐
ble.
• Wait until mains supply is stable.
The anti-flood device is on.
• Disconnect the appliance and close the water tap. Contact the Authorised
Service Centre.
If the display shows other alarm codes, deactivate and activate the
appliance. If the problem continues, contact the Authorised Service Centre.
In case of different problem with the appliance check the table below for
possible solutions.
Problem Possible solution
The programme does not
start.
• Make sure that the mains plug is connected to the mains socket.
• Make sure that the appliance door is closed.
• Make sure that there is no damaged fuse in the fuse box.
• Make sure that the Start/Pause has been touched.
• If the delay start is set, cancel the setting or wait for the end of countdown.
• Deactivate the Child Lock function if it is on.
• Check the position of the knob on the selected programme.
The appliance fills with water
and drains immediately.
• Make sure that the drain hose is in the correct position. The hose may be posi‐
tioned too low. Refer to "Installation instruction".
40 ENGLISH
Problem Possible solution
The spin phase does not op‐
erate or the washing cycle
lasts longer than usual.
• Set the spin programme.
• Make sure that the drain filter is not clogged. Clean the filter, if necessary. Re‐
fer to "Care and cleaning".
• Adjust manually the items in the tub and start the spin phase again. This prob‐
lem may be caused by balance problems.
There is water on the floor.
• Make sure that the couplings of the water hoses are tight and there is not wa‐
ter leakages.
• Make sure that the water inlet hose and the drain hose have no damages.
• Make sure you use the correct detergent and the correct quantity of it.
You cannot open the appli‐
ance door.
• Make sure that a washing programme that ends with water in tub, has not
been selected.
• Make sure that the washing programme is finished.
• Set the drain or the spin programme if there is water in the drum.
• Make sure that the appliance receives electrical power.
• This problem may be caused by a failure of the appliance. Contact the Author‐
ised Service Centre.
If you need to open the door, please read carefully "Emergency door opening".
The appliance makes an un‐
usual noise and vibrates.
• Make sure the levelling of the appliance is correct. Refer to "Installation in‐
struction".
• Make sure that the packaging and/or the transit bolts are removed. Refer to
"Installation instruction".
• Add more laundry in the drum. The load may be too small.
The programme duration in‐
creases or decreases during
programme execution.
• The ProSense System is able to adjust the programme duration according to
the type and the laundry load size. Refer to "The ProSense System load de‐
tection" in "Daily Use" chapter.
The washing results are not
satisfactory.
• Increase the detergent quantity or use a different detergent.
• Use special products to remove the stubborn stains before you wash the laun‐
dry.
• Make sure that you set the correct temperature.
• Decrease the laundry load.
Too much foam in the drum
during the washing cycle.
• Reduce the quantity of detergent or the number of tablets or single-dose deter‐
gents.
After the washing cycle,
there are some detergent
residues in the dispenser
drawer.
• Make sure that the flap is in the correct position (UP for powder detergent -
DOWN for liquid detergent).
• Make sure you have used the detergent dispenser according the indications
given in this user manual.
After the check, activate the appliance. The programme continues from the
point of interruption.
If the problem occurs again, contact the Authorised Service Centre.
The necessary data for the service centre are on the rating plate.
ENGLISH 41
14.2 Emergency door opening
In case of power failure or functioning failure
the appliance door remains locked. The
washing programme continues when the
power is restored. If the door remains locked
in case of failure, it is possible to open it
using the emergency unlock function.
Before opening the door:
CAUTION!
Risk of burns! Make sure that the
water temperature is not too high and
the laundry is not hot. If necessary,
wait until they cool down.
CAUTION!
Risk of injury! Make sure that the
drum is not rotating. If necessary, wait
until the drum stops rotating.
Make sure that the water level inside
the drum is not too high. If necessary,
proceed with an emergency drain
(refer to «Emergency drain» in «Care
and cleaning» chapter).
To open the door, proceed as follows:
1. Press the On/Off button to switch the
appliance off.
2. Disconnect the mains plug from the
mains socket.
3. Pull the emergency unlock trigger
downward once. Pull it once again, keep
it tensed and, in the meanwhile, open the
appliance door. The emergency unlock
trigger is located where indicated by the
following picture.
4. Take out the laundry and then close the
appliance door.
15. CONSUMPTION VALUES
15.1 Introduction
See the web link www.theenergylabel.eu for detailed information
about Energy Label.
42 ENGLISH
The QR codes on the EU and UK energy labels supplied with the
appliance provide a web link to the information related to the
performance of the appliance. For the energy label with the EU
flag, it is also possible to find the information in the EU EPREL
database using the link https://eprel.ec.europa.eu and the model
name and product number that you find on the rating plate of the
appliance. Refer to 'Product description' chapter for the position of
the rating plate. Keep the energy labels for reference together with
the user manual and all other documents provided with this
appliance.
15.2 Legend
kg Laundry load. hh:mm Programme duration.
kWh Energy consumption. °C Temperature in the laundry.
Litres Water consumption. rpm Spin speed.
% Remaining moisture at the end of spinning phase. The higher is the spin speed, the higher is the
noise and the lower is the remaining moisture.
Values and programme duration may differ depending on different conditions (e.g. room
temperature, water temperature and pressure, load size and type of laundry, supply
voltage) and also if you change the default setting of a programme.
15.3 According to UK Ecodesign for
Energy-Related Products and
Energy Information Regulations and
to EU Ecodesign Regulation
2019/2023 and the EU Energy Label
Regulation 2019/2014
Eco 40-60 pro‐
gramme
kg kWh Litres hh:mm % °C
rpm
1)
Full load 7.0 0.720 53.0 03:15 53.00 38.0 1351
Half load 3.5 0.440 43.0 02:30 53.00 32.0 1351
Quarter load 2.0 0.300 33.0 02:20 54.00 31.0 1351
1)
Maximum spin speed.
ENGLISH 43
Power consumption in different modes
Off (W) Stand-by (W) Delay start (W)
0.50 0.50 4.00
Time to Off/Standby mode is 15 minutes maximum.
15.4 Common programmes
These values are indicative only.
Programme
kg kWh Litres hh:mm % °C
rpm
1)
Cottons
2)
90°C
7.0 2.220 80.0 04:00 52.00 85.0 1400
Cottons
60°C
7.0 1.300 75.0 03:25 52.00 55.0 1400
Cottons
3)
20°C
7.0 0.250 75.0 02:40 52.00 20.0 1400
Synthetics
40°C
3.0 0.650 75.0 02:25 35.00 40.0 1200
Delicates
4)
30°C
2.0 0.360 50.0 01:10 35.00 30.0 1200
Wool
30°C
1.5 0.200 55.0 01:05 30.00 30.0 1200
1)
Reference indicator of the spin speed.
2)
Suitable for washing heavily soiled textiles.
3)
Suitable for washing lightly soiled cottons, synthetic and mixed fabrics.
4)
It also performs as quick washing cycle for lightly soiled laundry.
16. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol . Put the
packaging in relevant containers to recycle it.
Help protect the environment and human
health by recycling waste of electrical and
electronic appliances. Do not dispose of
appliances marked with the symbol with
the household waste. Return the product to
your local recycling facility or contact your
municipal office.
44 ENGLISH
*
157079180-B-032024
