RECHARGEABLE 360° INSPECTION LIGHT 8W &
1W SMD LED
MODELS: LED3604, LED3604G, LED3604R, LED3604UV
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9 Inspect the cable and connector for wear and damage to ensure items are safe before connecting to the power supply. If worn or
damaged DO NOT use.
9 Ensure the torch is fully charged before initial use.
8 DO NOT charge in damp conditions.
8 DO NOT turn the torch on when it is being charged.
8 DO NOT shine directly into your, another person’s or an animal’s eyes.
8 DO NOT allow children to use the torch.
8 DO NOT handle or move the torch whilst it is being charged.
8 DO NOT use the torch if you suspect that the battery or the torch casing is damaged.
8 DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery, subsequently
recharge the battery at least once every six months of non-use.
8 DO NOT attempt to open, disassemble, modify or service the battery pack.
8 DO NOT crush, puncture, short external contacts or dispose of in re or water.
9 Replace only with the battery pack designated for this product.
9 Recycle or dispose of used battery as stipulated by local regulation.
9 If the electrolyte in the cells gets on your skin, thoroughly wash with soap and water. If it gets in your eyes, rinse thoroughly with cool
water and seek immediate medical attention.
2. INTRODUCTION
Unique and innovative 360° swivel and tilt function enables the light source to be positioned in any direction. Exclusive patented design owned
by and registered to Sealey. Features super bright SMD LEDs providing up to 600 lumens through the adjustable rotary switch and a 1W LED
directional torch. Slimline design with minimum thickness of 9mm. Features a single hanging hook, magnetic base allowing hands-free operation
and battery level indicator. High quality 3.7V 2.6Ah lithium-ion battery for longer life, no memory effect and a much slower discharge than
traditional Ni-MH batteries. Supplied with a high quality braided USB lead.
3. SPECIFICATION
Model No .....LED3604, LED3604G, LED3604R, LED3604UV
Battery ...............................................3.7V 2.6Ah Lithium-ion
Charging Time: .................................................................. 4hr
IP Rating: ........................................................................IP54
LED Type: .............................................. 8W & 1W SMD LED
Lumen Output: ..............Side(High/Low)/Top; (600/50)/120lm
Maximum Length ........................................................400mm
Minimum Length .........................................................390mm
Operating Time: ................Side(High/Low)/Top; (1.5/16)/10hr
Wavelength UV: ..................................................390-405mm
IMPORTANT WARRANTY INFORMATION
The battery tted to this lamp is considered to be a consumable item and its ability to accept a charge will reduce over time. We will provide
warranty against mechanical and electrical defect for a period of one year - this does not cover fair wear and tear. If the battery is not properly
charged before rst use, or regularly conditioned, its capacity will diminish. Under these circumstances we will not replace the battery regardless
of whether the battery less than one year old.
4. OPERATION
4.1. CHARGING
4.1.1. Remove USB socket cover from the side of the lamp.
4.1.2. Connect the USB lead to the port on the side of the lamp and a USB power socket. Turn on the power supply.
4.1.3. The battery charge level LED on the side of the lamp will ash green and show the level of charge.
LED3604, G, R, UV Issue 2 (2,3) 25/04/23
Original Language Version
© Jack Sealey Limited
Refer to
instructions
4.1.4. When the battery has fully charged all the LED’s will turn GREEN.
4.1.5. Switch off power supply, remove charging lead and replace socket cover.
4.2. OPERATION
4.2.1. The lamp has a magnetic base to x to ferrous materials and a hook to hang the lamp.
4.2.2. By pulling the base from the main body the 360°, tilt function can be used enabling the lamp to be positioned in any direction.
4.2.3. To turn on the lamp rotate the red switch clockwise on the back of the lamp. Further rotation will increase the brightness of the lamp.
Rotate anti-clockwise to switch off.
4.2.4. To turn on the torch press the red button on the back of the unit, press again to turn off.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice. Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
REGISTER YOUR
PURCHASE HERE
Original Language Version
© Jack Sealey Limited
LED3604, G, R, UV Issue 2 (2,3) 25/04/23
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd’s Batteries Producer Registration Number (BPRN) is BPRN00705.
