HIKVISION UNAUTHORIZED DISTRIBUTORS POLICY
Hikvision USA and Hikvision Canada sells products only through
authorized distributors. We value our industry partners and are
proud of the relationships we have developed to help expand the
use of our innovative technology products and solutions. These
authorized distributors have committed to serve as a link in the
Hikvision USA and Hikvision Canada value chain by providing
excellent pre- and post-sale customer service, including full
rmware and sales engineering support.
Not every distributor advertising Hikvision products has
been authorized by Hikvision USA and Hikvision Canada to
advertise or sell those products. We warn potential customers
against purchasing these “gray market” products from
unauthorized distributors. Unauthorized distributors may be
selling counterfeit, used, or damaged product. Much of the
products sold by unauthorized distributors have been altered
with modied rmware. Since this means that it is no longer
in original factory condition, Hikvision warranty is void, per
company policy.
We warn potential customers against purchasing from
unauthorized distributors. Purchasing through authorized
Hikvision USA and Hikvision Canada distributors ensures
that you receive the benets of technical support, project
registration, dealer loyalty programs and advance replacement
of any camera, recorder, monitor, video server, or software,
in addition to Hikvision USA and Hikvision Canada’s full
warranty. Additionally, products purchased through authorized
distribution partners have additional features and capabilities
that distinguish the North American offering.
If you have any questions or concerns about the ofcial status
of your Hikvision distributor before your purchase, please
contact Hikvision USA and Hikvision Canada Customer Service
at csr[email protected] to conrm their authorized status.
Thank you for your continued support of our industry-leading
video surveillance products.
It started with cutting-edge technology: high-denition IP cameras,
digital video servers, hybrid and standalone DVRs, NVRs, speed domes,
encoders, and decoders.
Fortied by one of the largest R&D teams in the video surveillance industry, the innovation behind these products quickly
made Hikvision the #1 CCTV and video surveillance equipment provider in the world (2015 IHS Report). A total solution
provider, Hikvision manufactures a full suite of video surveillance products and solutions for a broad range of vertical
markets, including retail, education, and many others. Whatever the scope or requirements of the application, Hikvision has
a user-friendly, highly scalable product to meet those needs.
ABOUT HIKVISION
PROFESSIONAL
SOLUTIONS
Box Camera
Indoor/Outdoor Dome
Outdoor Bullet
Multi-Sensor
Counting Camera
Ultra-Wide Panoramic
Fisheye
Covert
Height Strip
Indoor/Outdoor PTZ
Specialty Dome and PTZ
NVR
VALUE
SOLUTIONS
Indoor Recessed Dome
Outdoor Dome
Outdoor Compact Dome
Outdoor Turret
Outdoor Bullet
Indoor Pinhole
Covert
Indoor Fisheye
Indoor PTeZ™
Indoor/Outdoor PTZ
Outdoor IR PTZ
Plug-and-Play NVR
VALUE PLUS
SOLUTIONS
Outdoor Dome
Outdoor Compact Dome
Outdoor Turret
Outdoor Bullet
WI-FI
SOLUTIONS
Outdoor Wi-Fi Dome
Compact Wi-Fi Dome
Wi-Fi Cube
Indoor Wi-Fi PTeZ™
Indoor PTZ
Wi-Fi NVR
TurboHD
™
3.0
ANALOG
SOLUTIONS_
3 MP + 2 MP
Outdoor Dome
Outdoor Bullet
Outdoor Turret
TurboHD™ 3.0 Tribrid DVR
06
16
18
23
24
TurboHD
™
ANALOG
SOLUTIONS_
720p + 1080p
Indoor Box
Indoor/Outdoor Dome
Outdoor Turret
Outdoor Bullet
Indoor/Outdoor Analog PTZ
TurboHD™ Tribrid DVR
Encoder
Decoder
BRACKETS
AND BRACKET
CHART
PTZ Brackets
Stainless Steel Brackets
Camera Housings
Box Camera Brackets
Universal Brackets for Pendant Caps
Sun/Rain Shield
DVR/NVR Bracket
Camera Brackets
ACCESSORIES
Monitors
HD-TVI Accessories
Keyboards
PoE Gigabit L2.5 Ethernet Switches
PoE Unmanaged Switches
Ethernet Over Coax
Megapixel Auto Iris Lenses
Storage Product
Storage Expansion
Hard Drives
DVD-RW
Micro SD Card
iVMS
CLIENT
SOFTWARE
iVMS-4200
iVMS-4500
REFERENCE
GUIDE
26
33
37
39
40
VERTICAL
MARKET FOCUS
TRANSPORTATION
Hikvision offers a wide assortment of solutions to
meet the needs of transport hubs, roads, highways, and
more. Effects of exhaust, sand, winter salt, snow, sleet,
and high winds are not an issue for Hikvision cameras,
which are highly rated and made to resist severe outdoor
conditions
HEALTHCARE
Patient monitoring, emergency rooms, pharmacies,
specialty departments, and restricted areas are all
critical zones that require reliable security equipment.
Just as we all depend on our physician for keeping us
well, we can depend on Hikvision’s solutions to ensure
the security of healthcare facilities.
GOVERNMENT
With strained budgets and changing priorities, safety
remains an important issue for government facilities.
Signicant upgrades to existing analog infrastructures
are possible using our TurboHD™ line of HD-TVI
solutions, which deliver HD analog video without the
high costs of networked systems.
SAFE CITIES
Hikvision is dedicated to helping solve public safety
issues by providing surveillance systems that address
emergency response, disaster management, and overall
public safety. A key responsibility of any city is to ensure
its citizens feel safe, which is why cities trust Hikvision.
RETAIL
Shop and restaurant owners have peace of mind
when using Hikvision’s high performing products,
which are aesthetically pleasing to boot. In each
camera category are compact bullet, turret, dome and
covert varieties, which provide discreet surveillance in
attractive packaging. POS integration, heat mapping,
and special counting cameras provide signicant
business management information. Data collected can
then be managed through Hikvision’s smart recording
equipment.
EDUCATION
Protection of your loved ones is one of Hikvision’s
highest priorities. Budget-minded school districts nd
Hikvision’s product selection unmatched in the industry.
High resolution cameras offer excellent image quality
with high value for a market-leading price. Image
enhancements, such as wide dynamic range and high
denition video, make our products well suited to capture
remarkable detail in exterior and interior settings.
CRITICAL
INFRASTRUCTURE
Hikvision’s Smart Series and Specialty cameras offer
performance and features that are ideal for critical
security installations. Resolutions of 12 MP, 8 MP
(4K), 6 MP and more deliver detailed video images.
DarkFighter and LightFighter solutions provide clear
images in any lighting condition. Stainless-steel, high
impact and weather-rated cameras withstand harsh
environments. Built-in smart analytics provide pre- and
post-event details. Data recording and storage products
keep records safe and ready for forensic research. Every
critical infrastructure setting has its own set of needs.
With Hikvision products, these needs are all met.
GREATER
PARTNERSHIPS
The company’s remarkable
accomplishments in North America
speak to more than just top-tier
products. Hikvision rmly believes
that a company’s success depends
on superior customer support.
From inside sales to engineering support, from
customer service to technical support, Hikvision goes
the extra mile to provide customers with all of the
elements they need for a rst-class security system.
Hikvision’s Dealer Partner program and A&E program
provide additional resources for dealers, architects,
and engineers to help promote business success
through knowledge and valuable tools. Hikvision is
committed to protecting and creating business value
for its customers.
To learn more about our Partner programs, please
contact us at
NETWORK CAMERAS - SMART SERIES
BOX CAMERA
Model
DS-2CD4012FWD-A DS-2CD6026FHWD-A
DS-2CD6026FHWD-
A3/A7/A11
DS-2CD4025FWD-A DS-2CD4032FWD-A DS-2CD4065F-A DS-2CD4085F-AP
Image Sensor
1/3” progressive scan CMOS
1/1.8” progressive scan
CMOS
1/1.8” progressive scan
CMOS
1/2.8” progressive scan
CMOS
1/3” progressive scan CMOS
1/1.8” progressive scan
CMOS
1/1.7” progressive scan
CMOS
Min. Illumination (lux)
Color: 0.01 @ ƒ/1.2
B/W: 0.001 @ ƒ/1.2
Color: 0.001 @ ƒ/1.2
B/W: 0.0001 @ ƒ/1.2
Color: 0.0016 @ ƒ/1.5
B/W: 0.00016 @ ƒ/1.5
Color: 0.005 @ ƒ/1.2
B/W: 0.0005 @ ƒ/1.2
Color: 0.1 @ ƒ/1.2
B/W: 0.01 @ ƒ/1.2
Color: 0.02 @ ƒ/1.2
B/W: 0.002 @ ƒ/1.2
Color: 0.01 @ ƒ/1.2
B/W: 0.001 @ ƒ/1.2
Lens
Auto back focus,
C/CS mount
Auto back focus,
C/CS mount
A3: 3.8 to 16 mm ƒ/1.5
A7: 7 to 33 mm ƒ/0.95
A11: 11 to 40 mm ƒ/1.5
Auto back focus,
C/CS mount
Auto back focus,
C/CS mount
Auto back focus,
C/CS mount
Auto back focus,
C/CS mount
Auto back focus,
C/CS mount
Horizontal Angle of
View
Lens dependent Lens dependent Lens dependent Lens dependent Lens dependent Lens dependent Lens dependent
Pan/Tilt/Rotation
--- --- --- --- --- --- ---
Day/Night
TRUE TRUE TRUE TRUE TRUE TRUE TRUE
BLC/WDR
Yes/120 dB Yes/120 dB Yes/120 dB Yes/140 dB Yes/120 dB Yes/Digital Yes/Digital
IR Range Max.
(meters)
--- --- --- --- --- --- ---
Video Compression
H.264+/H.264/MPEG4/
MJPEG
H.264+/H.264/MPEG4/
MJPEG
H.264+/H.264/MPEG4/
MJPEG
H.264+/H.264/MJPEG
H.264+/H.264/MPEG4/
MJPEG
H.264+/H.264/MJPEG H.264+/H.264/MJPEG
Maximum Image
Resolution (pixels)
1280x960 1920x1080 1920x1080 1920x1080 2048x1536 3072x2048 4096x2160
Frame Rate (fps)
30 @ 1280x960
(60 @ 1280x720
with WDR off)
30 @ 1920x1080,
1280x960, 1280x720
(60 @ 1920x1080, 1280x960,
1280x720 with WDR off)
30 @ 1920x1080,
1280x960, 1280x720
(60 @ 1920x1080, 1280x960,
1280x720 with WDR off)
30 @ 1920x1080,
1280x960, 1280x720
(60 @ 1920x1080
with WDR off)
30 @ 1920x1080, 1280x720
20 @ 2048x1536
24 @ 3072x2048
30 @ 2560×2048,
2560×1920, 2048x1536,
1920x1080, 1280x720
22 @ 4096x2160,
24 @ 3840x2160
30 @ 1920x1080, 1280x720
Multi-Streaming
Triple Triple Triple Triple Triple Triple Triple
Smart Features
Full Smart Suite
1
Full Smart Suite
1
except Counting
Full Smart Suite
1
except Counting
Full Smart Suite
1
Full Smart Suite
1
Full Smart Suite
1
Full Smart Suite
1
Motion Detection
Yes Yes Yes Yes Yes Yes Yes
Audio Input/Output
IN: 1 line/mic
OUT: 1 line
MIC: Built in
IN: 1 line/mic
OUT: 1 line
MIC: Built in
IN: 1 line/mic
OUT: 1 line
MIC: Built in
IN: 1 line/mic
OUT: 1 line
MIC: Built in
IN: 1 line/mic
OUT: 1 line
MIC: Built in
IN: 1 line/mic
OUT: 1 line
MIC: Built in
IN: 1 line/mic
OUT: 1 line
MIC: Built in
Alarm Input/Output
1/1 1/1 1/1 1/1 1/1 1/1 1/1
Local Storage
MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max.
Ratings
UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed
Operating
Temperature Range
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
Power Requirements
(max.)
24 VAC, 12 VDC,
PoE (802.3af), 8.5 W
24 VAC, 12 VDC,
PoE (802.3af), 12 W
24 VAC, 12 VDC,
PoE (802.3af), 12 W
24 VAC, 12 VDC,
PoE (802.3af), 8.5 W
24 VAC, 12 VDC,
PoE (802.3af), 10 W
24 VAC, 12 VDC,
PoE (802.3af), 8 W
24 VAC, 12 VDC,
PoE (802.3af), 8 W
Standards: Complies with ONVIF (Prole S and G), CGI ASAPI. Contact factory for details.
1
Full Smart Suite: Line Crossing, Intrusion, Region Entrance, Region Exiting, Unattended Baggage, Object Removal, Scene Change, Sudden Audio Increase/Decrease, Audio Loss, Defocus, Object Counting, Defog
OVERVIEW
Hikvision offers several
choices when it comes to
networked IP products.
Smart Pro IP Solutions
The Smart Pro IP solutions are an ideal option for
professional applications, as they bring intelligence,
efciency, and convenience to video surveillance.
The DarkFighter and LightFighter IP cameras provide
outstanding image quality in challenging lighting
environments. Camera styles vary from indoor
and outdoor domes, bullets, turrets, covert, sheye
models, and various PTZ options. Key features
include high resolution up to 12MP, 180˚ panoramic
viewing, smart analytics, and H.264+ compression.
With so many options, the Smart Pro Series can easily
meet the high performance and storage requirements
of enterprise projects.
Value Plus Series and Value Series
The Value Plus Series and Value Series provide similar
choices of high-quality video surveillance cameras
and recorders at conservative prices. Key Hikvision
features—such as WDR, 3DDNR, BLC, motorized
zoom lenses, and EXIR—are not compromised in
these sensible series. Value recording products offer
simplicity in installation with Plug and Play technology.
For recording efciency, Value items also support
H.264+ and H.265 video compression. Whatever the
application scope or requirements, Hikvision has a
user-friendly, highly scalable product to meet those
needs.
*Lens NOT included
*Lens NOT included *Lens NOT included *Lens NOT included *Lens NOT included *Lens NOT included
PROFESSIONAL SOLUTIONS
3 MP2 MP 2 MP 2 MP 4K1.3 MP 6 MP
6
DarkFighter
DarkFighter
LightFighter
NETWORK CAMERAS - SMART SERIES
INDOOR DOME OUTDOOR BULLET
Model
DS-2CD4112FWD-IZ DS-2CD4125FWD-IZ DS-2CD4132FWD-IZ DS-2CD4165F-IZ DS-2CD4185F-IZ DS-2CD41C5F-IZ DS-2CD4212FWD-IZH DS-2CD4212FWD-IZH8 DS-2CD4A24FWD-IZH DS-2CD4A25FWD-IZH DS-2CD4A25FWD-IZH8
Image Sensor
1/3” progressive scan
CMOS
1/2.8” progressive scan
CMOS
1/3” progressive scan
CMOS
1/1.8” progressive scan
CMOS
1/1.7” progressive scan
CMOS
1/1.7” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/2.8" progressive scan
CMOS
1/2.8” progressive scan
CMOS
1/2.8” progressive scan
CMOS
Min. Illumination (lux)
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.007 @ ƒ/1.4
B/W: 0 with IR
Color: 0.14 @ ƒ/1.4
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.014 lux @ ƒ/1.4
B/W: 0 lux with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.007 @ ƒ/1.4
Color: 0.014 lux @ ƒ/1.4
B/W: 0 lux with IR
Color: 0.014 lux @ ƒ/1.4
B/W: 0 lux with IR
Lens
2.8 to 12 mm @ ƒ/1.4,
motorized, autofocus
2.8 to 12 mm @ ƒ/1.4,
motorized, autofocus
2.8 to 12 mm @ ƒ/1.4,
motorized, autofocus
2.8 to 12 mm @ ƒ/1.4,
motorized, autofocus
2.8 to 12 mm @ ƒ/1.4,
motorized, autofocus
2.8 to 12 mm @ ƒ/1.4,
motorized, autofocus
2.8 to 12 mm @ ƒ/1.4,
motorized, autofocus
8 to 32 mm @ ƒ/1.4,
motorized, autofocus
4.7-94 mm @ F1.4
motorized, autofocus
2.8 to 12 mm @ ƒ/1.4,
motorized, autofocus
8 to 32 mm @ ƒ/1.4,
motorized, autofocus
Horizontal Angle of
View
98.4° to 30.2° 113° to 33.8° 91.2° to 28.3° 94.5° to 30.5° 96.0° to 32.6° 93.6° to 31.8° 98.4° to 30.2° 27.8° to 9.1° 53.8° to 3.1° 98.4° to 30.2° 27.8° to 9.1°
Pan/Tilt/Rotation
0° to 355°/
0° to 75°/0° to 355°
0° to 355°/
0° to 75°/0° to 355°
0° to 355°/
0° to 75°/0° to 355°
0° to 355°/
0° to 75°/0° to 355°
0° to 355°/
0° to 75°/0° to 355°
0° to 355°/
0° to 75°/0° to 355°
3-Axis Positioning 3-Axis Positioning 3-Axis Positioning 3-Axis Positioning 3-Axis Positioning
Day/Night TRUE TRUE TRUE TRUE TRUE TRUE TRUE TRUE TRUE TRUE TRUE
BLC/WDR Yes/120 dB Yes/140 dB Yes/120 dB Yes/Digital Yes/Digital Yes/Digital Yes/120 dB Yes/120 dB Yes/120 dB Yes/140 dB Yes/140 dB
IR Range Max. (meters) 30 30 30 30 30 30 30 80 120 50 100
Video Compression
H.264+/H.264/MPEG4/
MJPEG
H.264+/H.264/MPEG4/
MJPEG
H.264+/H.264/MPEG4/
MJPEG
H.264+/H.264/MJPEG H.264+/H.264/MJPEG H.264+/H.264/MJPEG
H.264+/H.264/MPEG4/
MJPEG
H.264+/H.264/MPEG4/
MJPEG
H.264+/H.264/MJPEG H.264+/H.264/MJPEG H.264+/H.264/MJPEG
Maximum Image
Resolution (pixels)
1280x960 1920x1080 2048x1536 3072x2048 4096x2160 4000x3000 1280x960 1280x960 1920x1080 1920x1080 1920x1080
Frame Rate (fps)
30 @ 1280x960
(60 @1280x720
with WDR off)
30 @ 1920x1080,
1280x960, 1280x720
(60 @ 1920x1080
with WDR off)
20 @ 2048x1536
30 @ 1920x1080,
1280x720
24 @ 3072x2048
30 @ 3072x1728,
2560x2048,
2560x1920, 2048x1536,
1920x1080, 1280x720
22 @ 4096x2160,
24 @ 3840x2160
30 @ 1920x1080,
1280x720
15 @ 4000x3000
22 @ 4096x2160
24 @ 3840x2160
30 @ 3072x1728,
2560x1440,
1920x1080, 1280x720
30 @ 1280x960
(60 @ 1280x720
with WDR off)
30 @ 1280x960
(60 @ 1280x720
with WDR off)
30 @ 1920x1080,
1280x960, 1280x720
(60 @ 1920x1080
with WDR off)
30 @ 1920x1080,
1280x960, 1280x720
(60 @ 1920x1080
with WDR off)
30 @ 1920x1080,
1280x960, 1280x720
(60 @ 1920x1080
with WDR off)
Multi-Streaming Triple Triple Triple Triple Triple Triple Triple Triple Triple Triple Triple
Smart Features Full Smart Suite
1
Full Smart Suite
1
Full Smart Suite
1
Full Smart Suite
1
Full Smart Suite
1
Full Smart Suite
1
Full Smart Suite
1
except
Audio feature
Full Smart Suite
1
except
Audio feature
Full Smart Suite
1
except
Audio feature
Full Smart Suite
1
except
Audio feature
Full Smart Suite
1
except
Audio feature
Motion Detection Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Audio Input/Output
IN: 1 line/mic
OUT: 1 line
IN: 1 line/mic
OUT: 1 line
IN: 1 line/mic
OUT: 1 line
IN: 1 line/mic
OUT: 1 line
IN: 1 line/mic
OUT: 1 line
IN: 1 line/mic
OUT: 1 line
--- --- --- --- ---
Alarm Input/Output 1/1 1/1 1/1 1/1 1/1 1/1 --- --- --- --- ---
Local Storage MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max.
Ratings IK10, UL/cUL Listed IK10, UL/cUL Listed IK10, UL/cUL Listed IK10, UL/cUL Listed IK10, UL/cUL Listed IK10, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP67, UL/cUL Listed IP67, UL/cUL Listed IP67, UL/cUL Listed
Operating Temperature
Range
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-40° C to 60° C
(-40° F to 140° F)
-40° C to 60° C
(-40° F to 140° F)
-40° C to 60° C
(-40° F to 140° F)
-40° C to 60° C
(-40° F to 140° F)
-40° C to 60° C
(-40° F to 140° F)
Power Requirements
(max.)
12 VDC,
PoE (802.3af), 10.5 W
12 VDC,
PoE (802.3af), 10 W
12 VDC,
PoE (802.3af), 11.5 W
12 VDC,
PoE (802.3af), 12.5 W
12 VDC,
PoE (802.3af), 13 W
12 VDC,
PoE (802.3af), 13 W
12 VDC,
PoE+ (802.3at), 12 W
12 VDC,
PoE+ (802.3at), 12 W
12 VDC,
PoE+ (802.3at), 15.5 W
12 VDC,
PoE+ (802.3at), 15.5 W
12 VDC,
PoE+ (802.3at), 15.5 W
Standards: Complies with ONVIF (Prole S and G), CGI ASAPI. Contact factory for details.
1
Full Smart Suite: Line Crossing, Intrusion, Region Entrance, Region Exiting, Unattended Baggage, Object Removal, Scene Change, Sudden Audio Increase/Decrease, Audio Loss, Defocus, Object Counting, Defog
3 MP2 MP 2 MP 2 MP 2 MP6 MP 4K 12 MP 1.3 MP1.3 MP 1.3 MP
PROFESSIONAL SOLUTIONS
7
LightFighter
EXIR
LightFighter
EXIRLightFighter EXIR
NETWORK CAMERAS - SMART SERIES
OUTDOOR BULLET OUTDOOR DOME
Model
DS-2CD4A26FWD-IZH DS-2CD4A26FWD-IZH8 DS-2CD4A35FWD-IZH DS-2CD4A35FWD-IZH8 DS-2CD4A65F-IZH DS-2CD4A85F-IZH DS-2CD4AC5F-IZH DS-2CD4312FWD-IZHS DS-2CD4312FWD-IZHS8 DS-2CD4324FWD-IZHS DS-2CD4324FWD-IZHS8
Image Sensor
1/1.8” progressive scan
CMOS
1/1.8” progressive scan
CMOS
1/2.8” progressive scan
CMOS
1/2.8” progressive scan
CMOS
1/1.8” progressive scan
CMOS
1/1.7” progressive scan
CMOS
1/1.7” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/2.8” progressive scan
CMOS
1/2.8” progressive scan
CMOS
Min. Illumination (lux)
Color: 0.0027 @ ƒ/1.4
B/W: 0 with IR
Color: 0.0027 @ ƒ/1.4
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Lens
2.8 to 12 mm @ ƒ/1.4,
motorized, autofocus
8 to 32 mm @ ƒ/1.4,
motorized, autofocus
2.8 to 12 mm @ ƒ/1.4,
motorized, autofocus
8 to 32 mm @ ƒ/1.4,
motorized, autofocus
2.8 to 12 mm @ ƒ/1.4,
motorized, autofocus
2.8 to 12 mm @ ƒ/1.4,
motorized, autofocus
2.8 to 12 mm @ ƒ/1.4,
motorized, autofocus
2.8 to 12 mm @ ƒ/1.4,
motorized, autofocus
8 to 32 mm @ ƒ/1.4,
motorized, autofocus
2.8 to 12 mm @ ƒ/1.4,
motorized, autofocus
8 to 32 mm @ ƒ/1.4,
motorized, autofocus
Horizontal Angle of View 92° to 32° 28° to 12° 105° to 32° 29.7° to 9.7° 94.5° to 30.5° 96.0° to 32.6° 93.6° to 31.8° 98.4° to 30.2° 27.8° to 9.1° 113° to 33.8° 31.2° to 10.2°
Pan/Tilt/Rotation 3-Axis Positioning 3-Axis Positioning 3-Axis Positioning 3-Axis Positioning 3-Axis Positioning 3-Axis Positioning 3-Axis Positioning
0° to 355°/
0° to 75°/0° to 355°
0° to 355°/
0° to 75°/0° to 355°
0° to 355°/
0° to 75°/0° to 355°
0° to 355°/
0° to 75°/0° to 355°
Day/Night TRUE TRUE TRUE TRUE TRUE TRUE TRUE TRUE TRUE TRUE TRUE
BLC/WDR Yes/120 dB Yes/120 dB Yes/120 dB Yes/120 dB Yes/Digital Yes/Digital Yes/Digital Yes/120 dB Yes/120 dB Yes/120 dB Yes/120 dB
IR Range Max. (meters) 50 100 50 100 50 50 50 30 50 30 50
Video Compression
H.264+/H.264/
MPEG4/MJPEG
H.264+/H.264/
MPEG4/MJPEG
H.264+/H.264/MJPEG H.264+/H.264/MJPEG H.264+/H.264/MJPEG H.264+/H.264/MJPEG H.264+/H.264/MJPEG
H.264+/H.264/
MPEG4/MJPEG
H.264+/H.264/
MPEG4/MJPEG
H.264+/H.264/
MPEG4/MJPEG
H.264+/H.264/
MPEG4/MJPEG
Maximum Image
Resolution (pixels)
1920x1080 1920x1080 2048x1536 2048x1536 3072x2048 4096x2160 4000x3000 1280x960 1280x960 1920x1080 1920x1080
Frame Rate (fps)
30 @ 1920x1080,
1280x960, 1280x720
(60 @1920x1080
with WDR off)
30 @ 1920x1080,
1280x960, 1280x720
(60 @1920x1080 with
WDR off)
30 @ 2048x1536
(45 @ 2048x1536,
60 @ 1920x1280
with WDR off)
30 @ 2048x1536
(45 @ 2048x1536,
60 @ 1920x1280
with WDR off)
24 @ 3072x2048,
30 @ 3072x1728,
2560x2048,
2560x1920, 2048x1536,
1920x1080, 1280x720
22 @ 4096x2160,
24 @ 3840x2160
30 @ 1920x1080,
1280x720
15 @ 4000x3000
22 @ 4096x2160
24 @ 3840x2160
30 @ 3072x1728,
2560x1440,
1920x1080, 1280x720
30 @ 1280x960
(60 @ 1280x720
with WDR off)
30 @ 1280x960
(60 @ 1280x720
with WDR off)
30 @ 1920x1080,
1280x960, 1280x720
(60 @ 1920x1080
with WDR off)
30 @ 1920x1080,
1280x960, 1280x720
(60 @ 1920x1080
with WDR off)
Multi-Streaming Triple Triple Triple Triple Triple Triple Triple Triple Triple Triple Triple
Smart Features
Full Smart Suite
1
except
Audio feature
Full Smart Suite
1
except
Audio feature
Full Smart Suite
1
except
Audio feature
Full Smart Suite
1
except
Audio feature
Full Smart Suite
1
except
Audio feature
Full Smart Suite
1
except
Audio feature
Full Smart Suite
1
except
Audio feature
Full Smart Suite
1
Full Smart Suite
1
Full Smart Suite
1
Full Smart Suite
1
Motion Detection Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Audio Input/Output --- --- --- --- --- --- ---
IN: 1 line
OUT: 1 line
IN: 1 line
OUT: 1 line
IN: 1 line
OUT: 1 line
IN: 1 line
OUT: 1 line
Alarm Input/Output --- --- --- --- --- --- --- 2/2 2/2 2/2 2/2
Local Storage MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max.
Ratings IP67, UL/cUL Listed IP67, UL/cUL Listed IP67, UL/cUL Listed IP67, UL/cUL Listed IP67, UL/cUL Listed IP67, UL/cUL Listed IP67, UL/cUL Listed
IP66, IK10,
UL/cUL Listed
IP66, IK10,
UL/cUL Listed
IP66, IK10,
UL/cUL Listed
IP66, IK10,
UL/cUL Listed
Operating Temperature
Range
-40° C to 60° C
(-40° F to 140° F)
-40° C to 60° C
(-40° F to 140° F)
-40° C to 60° C
(-40° F to 140° F)
-40° C to 60° C
(-40° F to 140° F)
-40° C to 60° C
(-40° F to 140° F)
-40° C to 60° C
(-40° F to 140° F)
-40° C to 60° C
(-40° F to 140° F)
-40° C to 60° C
(-40° F to 140° F)
-40° C to 60° C
(-40° F to 140° F)
-40° C to 60° C
(-40° F to 140° F)
-40° C to 60° C
(-40° F to 140° F)
Power Requirements
(max.)
12 VDC,
PoE+ (802.3at), 21 W
12 VDC,
PoE+ (802.3at), 21 W
12 VDC,
PoE+ (802.3at), 15.5 W
12 VDC,
PoE+ (802.3at), 15.5 W
12 VDC,
PoE+ (802.3at), 15.5 W
12 VDC,
PoE+ (802.3at), 15.5 W
12 VDC,
PoE+ (802.3at), 15.5 W
24 VAC,
PoE (802.3af), 13 W
24 VAC,
PoE (802.3af), 13 W
24 VAC,
PoE+ (802.3at), 14 W
24 VAC,
PoE+ (802.3at), 14 W
Standards: Complies with ONVIF (Prole S and G), CGI ASAPI. Contact factory for details.
1
Full Smart Suite: Line Crossing, Intrusion, Region Entrance, Region Exiting, Unattended Baggage, Object Removal, Scene Change, Sudden Audio Increase/Decrease, Audio Loss, Defocus, Object Counting, Defog
PROFESSIONAL SOLUTIONS
3 MP 3 MP2 MP 2 MP 2 MP 2 MP6 MP 4K 12 MP 1.3 MP1.3 MP
8
EXIR EXIR EXIR EXIR EXIR
DarkFighter
EXIR
DarkFighter
EXIR
NETWORK CAMERAS - SMART SERIES
OUTDOOR DOME MULTI-SENSOR COUNTING CAMERA
Model
DS-2CD4526FWD-IZH DS-2CD4332FWD-IZHS DS-2CD4332FWD-IZHS8 DS-2CD4535FWD-IZH DS-2CD4535FWD-IZH8 DS-2CD4565F-IZH DS-2CD4585F-IZH DS-2CD45C5F-IZH DS-2CD6986F-H iDS-2CD6412FWD/C
Image Sensor
1/1.8” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/2.8” progressive scan
CMOS
1/2.8” progressive scan
CMOS
1/1.8” progressive scan
CMOS
1/1.7” progressive scan
CMOS
1/1.7” progressive scan
CMOS
1/1.8’’ Progressive Scan
CMOS
1/3’’ Progressive Scan
CMOS
Min. Illumination (lux)
Color: 0.0027 @ ƒ/1.4
B/W: 0 with IR
Color: 0.14 @ ƒ/1.4
B/W: 0 with IR
Color: 0.14 @ ƒ/1.4
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.002 Lux @ (F2.2,
AGC ON)
Color: 0.028 Lux @ (F2.0,
AGC ON)
B/W: 0.0028 Lux @ (F2.0,
AGC ON)
Lens
2.8 to 12 mm @ ƒ/1.4,
motorized, autofocus
2.8 to 12 mm @ ƒ/1.4,
motorized, autofocus
8 to 32 mm @ ƒ/1.4,
motorized, autofocus
2.8 to 12 mm @ ƒ/1.4,
motorized, autofocus
8 to 32 mm @ ƒ/1.4,
motorized, autofocus
2.8 to 12 mm @ ƒ/1.4,
motorized, autofocus
2.8 to 12 mm @ ƒ/1.4,
motorized, autofocus
2.8 to 12 mm @ ƒ/1.4,
motorized, autofocus
5mm × 4, adjustable, Pan
180°, Tilt: 78.4°
2.1mm @ ƒ/2.2
2.8mm @ ƒ/2.0
Horizontal Angle of View 92° to 32° 91.2° to 28.3° 26° to 8.54° 105° to 32° 29.7° to 9.7° 94.5° to 30.5° 96.0° to 32.6° 93.6° to 31.8° 180° stiched image
115° (2.1mm)
92.5° (2.8mm)
Pan/Tilt/Rotation
0° to 355°/
0° to 75°/0° to 355°
0° to 355°/
0° to 75°/0° to 355°
0° to 355°/
0° to 75°/0° to 355°
0° to 355°/
0° to 75°/0° to 355°
0° to 355°/
0° to 75°/0° to 355°
0° to 355°/
0° to 75°/0° to 355°
0° to 355°/
0° to 75°/0° to 355°
0° to 355°/
0° to 75°/0° to 355°
Pan: 0° to 360°,
tilt: 45° to 90°
---
Day/Night TRUE TRUE TRUE TRUE TRUE TRUE TRUE TRUE TRUE Electronic
BLC/WDR Yes/120 dB Yes/120 dB Yes/120 dB Yes/120 dB Yes/120 dB Yes/Digital Yes/Digital Yes/Digital Yes/Digital Yes/120 dB
IR Range Max. (meters) 40 30 50 40 50 40 40 40 --- ---
Video Compression
H.264+/H.264/
MPEG4/MJPEG
H.264+/H.264/
MPEG4/MJPEG
H.264+/H.264/
MPEG4/MJPEG
H.264+/H.264/
MPEG4/MJPEG
H.264+/H.264/MJPEG H.264+/H.264/MJPEG H.264+/H.264/MJPEG H.264+/H.264/MJPEG H.264/MJPEG H.264/MJPEG/MPEG4
Maximum Image Resolution
(pixels)
1920x1080 2048x1536 2048x1536 2048x1536 2048x1536 3072x2048 4096x2160 4000x3000 4096 × 1800 1280x960
Frame Rate (fps)
30 @ 1920x1080, 1280x960,
1280x720
(60 @ 1920x1080
with WDR off)
20 @ 2048x1536
30 @ 1920x1080, 1280x720
20 @ 2048x1536
30 @ 1920x1080, 1280x720
30 @ 2048x1536
(45 @ 2048x1536,
60 @ 1920x1080
with WDR off)
30 @ 2048x1536
(45 @ 2048x1536,
60 @ 1920x1080
with WDR off)
24 @ 3072x2048
30 @ 3072x1728,
2560x2048, 2560x1920,
2048x1536, 1920x1080,
1280x720
22 @ 4096x2160,
24 @ 3840x2160,
30 @ 1920x1080,
1280x720
15 @ 4000x3000
22 @ 4096x2160
24 @ 3840x2160
30 @ 3072x1728,
2560x1440,
1920x1080, 1280x720
Mode 1:
30 @ 4096x1800,
3840x1680
Mode 2:
24 @ 2400x3840
30 @1200x1920
30 @ 1280x960,
1280x720
Multi-Streaming Triple Triple Triple Triple Triple Triple Triple Triple Double Triple
Smart Features Full Smart Suite
1
Full Smart Suite
1
Full Smart Suite
1
Full Smart Suite
1
Full Smart Suite
1
Full Smart Suite
1
Full Smart Suite
1
Full Smart Suite
1
--- Basic Smart Suite
2
Motion Detection Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Audio Input/Output
IN: 1 line
OUT: 1 line
IN: 1 line
OUT: 1 line
IN: 1 line
OUT: 1 line
IN: 1 line
OUT: 1 line
IN: 1 line
OUT: 1 line
IN: 1 line
OUT: 1 line
IN: 1 line
OUT: 1 line
IN: 1 line
OUT: 1 line
IN: 1 line/mic
OUT: 1 line
IN: 1 line/mic
OUT: 1 line
Alarm Input/Output 1/1 2/2 2/2 1/1 1/1 1/1 1/1 1/1 1/1 1/1
Local Storage MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max.
Ratings
IP66, IK10,
UL/cUL Listed
IP66, IK10,
UL/cUL Listed
IP66, IK10,
UL/cUL Listed
IP66, IK10,
UL/cUL Listed
IP66, IK10,
UL/cUL Listed
IP66, IK10,
UL/cUL Listed
IP66, IK10,
UL/cUL Listed
IP66, IK10,
UL/cUL Listed
IP66, IK10,
UL/cUL Listed
UL/cUL Listed
Operating Temperature
Range
-40° C to 60° C
(-40° F to 140° F)
-40° C to 60° C
(-40° F to 140° F)
-40° C to 60° C
(-40° F to 140° F)
-40° C to 60° C
(-40° F to 140° F)
-40° C to 60° C
(-40° F to 140° F)
-40° C to 60° C
(-40° F to 140° F)
-40° C to 60° C
(-40° F to 140° F)
-40° C to 60° C
(-40° F to 140° F)
-40° C to 60° C
(-40° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
Power Requirements (max.)
24 VAC, 12 VDC,
PoE+ (802.3at), 17.5 W
24 VAC,
PoE (802.3af), 13 W
24 VAC,
PoE (802.3af), 13 W
12 VDC, 24 VAC,
PoE+ (802.3at), 17.5 W
12 VDC, 24 VAC,
PoE+ (802.3at), 17.5 W
12 VDC, 24 VAC,
PoE+ (802.3at), 17.5 W
12 VDC, 24 VAC,
PoE+ (802.3at), 17.5 W
12 VDC, 24 VAC,
PoE+ (802.3at), 17 W
24 VAC,
PoE+ (802.3at), 22 W
12 VDC, 7.5 W
Standards: Complies with ONVIF (Prole S and G), CGI ASAPI. Contact factory for details.
1
Full Smart Suite: Line Crossing, Intrusion, Region Entrance, Region Exiting, Unattended Baggage, Object Removal, Scene Change, Sudden Audio Increase/Decrease, Audio Loss, Defocus, Object Counting, Defog
2
Basic Smart Suite: Counting, ROI, EIS, Defog
3 MP 3 MP 3 MP 3 MP2 MP 6 MP 4K 12 MP 8 MP 1.3 MP
PROFESSIONAL SOLUTIONS
9
DarkFighter DarkFighter
NETWORK CAMERAS - SMART SERIES
ULTRA-WIDE PANORAMIC FISHEYE
Model
DS-2CD6W32FWD-IVS DS-2CD6332FWD-I DS-2CD6332FWD-IV DS-2CD6362F-I DS-2CD6362F-IV DS-2CD63C2F-IV
Image Sensor 1/3" progressive scan CMOS 1/3” progressive scan CMOS 1/3” progressive scan CMOS 1/1.8” progressive scan CMOS 1/1.8” progressive scan CMOS 1/1.7” progressive scan CMOS
Min. Illumination (lux)
Color: 0.1 @ ƒ/1.2, AGC On
B/W: 0 with IR
Color: 0.28 @ ƒ/2.0
B/W: 0 with IR
Color: 0.28 @ ƒ/2.0
B/W: 0 with IR
Color: 0.3 @ ƒ/2.8
B/W: 0 with IR
Color: 0.3 @ ƒ/2.8
B/W: 0 with IR
Color: 0.04 @ ƒ/2.4
B/W: 0 with IR
Lens 2mm @ f/2.4 1.19 mm @ ƒ/2.0, Fisheye 1.19 mm @ ƒ/2.0, Fisheye 1.27 mm @ ƒ/2.8, Fisheye 1.27 mm @ ƒ/2.8, Fisheye 1.98 mm @ ƒ/2.4
Horizontal Angle of View 135°, 98° vertical (wall) 180°/360° (wall) 180°/360° (wall) 180°/360° (wall) 180°/360° (wall) 180°/360° (wall)
Day/Night TRUE TRUE TRUE TRUE TRUE TRUE
BLC/WDR Yes/120 dB No/120 dB No/120 dB No/Digital No/Digital No/Digital
IR Range Max. (meters) 15 15 15 15 15 15
Video Compression H.264 H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG
Maximum Image Resolution
(pixels)
2048x1536 2048x1536 2048x1536 3072x2048 3072x2048 4000x3072
Frame Rate (fps)
30 @ 2048x1536
Fisheye (FE): M: 1536x1536; S:
720x720
Panorama (P): M: 1600x1200; S:
704x480
ePTZ: M: 800x600
M1: 20 @ FE(M), 20 @ P(M),
20 @ ePTZ(M)×3
M2: 30 @ FE(M) OR 30 @
ePTZ(M)×4
M3: 30 @ FE(M), 30 @ FE(S),
15 @ePTZ(M)×3
M4: 30 @ P(M), 30 @ P(S)
Fisheye (FE): M: 1536x1536; S:
720x720
Panorama (P): M: 1600x1200; S:
704x480
ePTZ: M: 800x600
M1: 20 @ FE(M), 20 @ P(M),
20 @ ePTZ(M)×3
M2: 30 @ FE(M) OR 30 @
ePTZ(M)×4
M3: 30 @ FE(M), 30 @ FE(S),
15 @ ePTZ(M)×3
M4: 30 @ P(M), 30 @ P(S)
Fisheye (FE): M: 3072x2048; S:
720x720
Panorama (P): M: 2048x1536; S:
704x480
ePTZ: M: 1024x768
M1: 15 @ FE(M), 15 @ P(M),
15 @ 3XePTZ(M)
M2: 30 @ FE(M) OR 30 @
4XePTZ(M)
M3: 15 @ FE (M), 15 @ FE (S),
15 @ 3X ePTZ(M)
M4: 30 @ P(M), 30 @ P(S)
Fisheye (FE): M: 3072x2048; S:
720x720
Panorama (P): M: 2048x1536; S:
704x480
ePTZ: M: 1024x768
M1: 15 @ FE(M), 15 @ P(M),
15 @ 3XePTZ(M)
M2: 30 @ FE(M) OR 30 @
4XePTZ(M)
M3: 15 @ FE (M),15 @ FE (S),
15 @ 3X ePTZ(M)
M4: 30 @ P(M), 30 @ P(S)
Fisheye (FE): M: 4000x3072; S:
720x720.
Panorama (P): M: 3072x2304; S:
704x576.
ePTZ:M: 1600x1200.
M1: 10 @ FE(M), 10 @ FE(S),
10 @ 3XePTZ(M).
M2: 15 @ P(M), 15 @ P(S)
M3: 15 @ 4XePTZ(M)
M4: 20 @ FE(M), 25 @
FE(3072x3072), 15 @FE(S)
Multi-Streaming Dual
Multi-Channel Mode;
High Frame Rate Mode;
Mode 3; Mode 4
Multi-Channel Mode;
High Frame Rate Mode;
Mode 3; Mode 4
Multi-Channel Mode;
High Frame Rate Mode;
Mode 3; Mode 4
Multi-Channel Mode;
High Frame Rate Mode;
Mode 3; Mode 4
Multi-Channel Mode;
High Frame Rate Mode;
Mode 3; Mode 4
Smart Features Basic Smart Suite
2
, ROI
Intrusion Detection,
Line Crossing
Intrusion Detection,
Line Crossing
Intrusion Detection,
Line Crossing
Intrusion Detection,
Line Crossing
Intrusion Detection,
Line Crossing
Motion Detection Yes Yes Yes Yes Yes Yes
Audio Input/Output Built-in speaker and mic Built-in speaker and mic Built-in speaker and mic Built-in speaker and mic Built-in speaker and mic Built-in speaker and mic
Alarm Input/Output 1/1 --- --- --- --- ---
Local Storage MicroSD 64 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max.
Ratings IP66, IK10, UL/cUL Listed UL/cUL Listed IP67, IK10, UL/cUL Listed UL/cUL Listed IP67, IK10, UL/cUL Listed IP67, IK10, UL/cUL Listed
Operating Temperature Range
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
Power Requirements (max.)
12 VDC,
PoE (802.3af), 12 W
12 VDC,
PoE (802.3af), 12.5 W
12 VDC,
PoE (802.3af), 12.5 W
12 VDC,
PoE (802.3af), 12 W
12 VDC,
PoE (802.3af), 12 W
12 VDC/PoE (802.3af), 14.7 W
Standards: Complies with ONVIF (Prole S and G), CGI ASAPI. Contact factory for details.
3 MP3 MP 3 MP 6 MP 6 MP
12 MP
PROFESSIONAL SOLUTIONS
10
FEATURED PRODUCT
Multi-Sensor DarkFighter
Panoramic IP camera
PRODUCT DETAILS ON PREVIOUS PAGE
Hikvision’s new Multi-Sensor DarkFighter Panoramic
IP camera (
DS-2CD6986F-H, page 9) offers a
variety of features for outstanding 180° panoramic
performance. It includes up to 7.3 MP resolution (4096
× 1800) with PoE, defogging technology, 3D digital
noise reduction, and IP66 and IK10 protection ratings.
Its four 5mm lenses provide a horizontal 180° view,
eliminating blind spots and providing broad coverage
in enclosed spaces. From Hikvision’s DarkFighter
series and with the ability to capture high quality color
images in very dim environments (0.002 lux), this
camera is an ideal choice for low-light situations.
A close companion product is our new I-Series Value
NVRs, which is a reliable addition to IP security
systems that require ultra high performance at an
economic price. These NVRs support recording of
up to 12 MP camera resolution, Ultra High Denition
(UHD) output up to 4K, and up to 24 TB storage
capacity. The recorder offers up to four SATA
interfaces and one eSATA interface for recording
and backup. It features Hikvision’s unique optimized
H.264+ and H.265 compression, increasing storage
space by 50-70%.
NETWORK CAMERAS - SMART SERIES
COVERT HEIGHT STRIP
Model
DS-2CD6412FWD-C2
(Base Unit)
DS-2CD6412FWD-L10
(Lens/Sensor)
DS-2CD6412FWD-L20
(Lens/Sensor)
DS-2CD6412FWD-L30
(Lens/Sensor)
DS-2CD6424FWD-10 DS-2CD6424FWD-20 DS-2CD6424FWD-30
DS-2CD6424FWD-40/E1 DS-2CD6424FWD-40/E2 DS-2CD6424FWD-20/E
Image Sensor
Supports (2) L10, L20, or
L30 lenses/sensor units
(not included)
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/2.7" progressive scan
CMOS
1/2.7" progressive scan
CMOS
1/2.7" progressive scan
CMOS
1/2.7" progressive scan
CMOS
1/2.7" progressive scan
CMOS
1/2.7" progressive scan
CMOS
Min. Illumination (lux) --- Color: 0.04 @ ƒ/2.3 Color: 0.04 @ ƒ/2.3 Color: 0.04 @ ƒ/2.0
Color: 0.028 Lux @ f2.0,
AGC ON
Color: 0.028 Lux @ f2.0,
AGC ON
Color: 0.028 Lux @ f2.0,
AGC ON
Color: 0.028 Lux @ f2.0,
AGC ON
Color: 0.028 Lux @ f2.0,
AGC ON
Color: 0.028 Lux @ f2.0,
AGC ON
Lens --- Fixed, 3.7 mm @ ƒ/2.3 Fixed, 3.7 mm @ ƒ/2.3
Fixed, 2.8 mm,
4 mm @ ƒ/2.0
Fixed 3.7mm @ f2.5,
cylindrical pinhole
Fixed 3.7mm @ f2.5,
L-shaped, pinhole
Fixed 2.8mm @ f2.0,
Tube
Fixed 2.8mm @ f2.0,
Ball with Turret mount
Fixed 2.8mm @ f2.0,
Ball with In-ceiling mount
Fixed 3.7mm @f2.5,
L-shaped, pinhole
Horizontal Angle of View Lens dependent 57° 57° 92.5°, 73.1° 65° 65° 115° 109.4° 109.4° 78.5°
Day/Night --- Electronic Electronic Electronic TRUE TRUE TRUE TRUE TRUE TRUE
BLC/WDR --- No/120 dB No/120 dB No/120 dB Yes/120 dB Yes/120 dB Yes/120 dB Yes/120 dB Yes/120 dB Yes/120 dB
IR Range Max. (meters) --- --- --- --- --- --- --- --- --- ---
Video Compression H.264/MPEG4/MJPEG --- --- --- H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG ---
Maximum Image Resolution
(pixels)
--- 1280x960 1280x960 1280x960 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080
Frame Rate (fps) 30 @ 1280x960, 1280x720 --- --- ---
30 @ 1920x1080,
1280x960, 1280x720
30 @ 1920x1080,
1280x960, 1280x720
30 @ 1920x1080,
1280x960, 1280x720
30 @ 1920x1080,
1280x960, 1280x720
30 @ 1920x1080,
1280x960, 1280x720
30 @ 1920x1080,
1280x960, 1280x720
Multi-Streaming Triple Stream --- --- --- --- --- --- --- --- Triple
Smart Features Basic Smart Suite
2
--- --- --- Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
+
ROI, Defog
Motion Detection Yes --- --- --- Yes Yes Yes Yes Yes Yes
Audio Input/Output
IN: 1 line/mic
OUT: 1 line
--- --- ---
IN: 1 line/mic
OUT: 1 line
IN: 1 line/mic
OUT: 1 line
IN: 1 line/mic
OUT: 1 line
IN: 1 line/mic
OUT: 1 line
IN: 1 line/mic
OUT: 1 line
IN: 1 line/mic
OUT: 1 line
Alarm Input/Output 1/1 --- --- --- 1/1 1/1 1/1 1/1 1/1 1/1
Local Storage MicroSD, 128 GB max. --- --- --- MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max.
Ratings UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed
Operating Temperature
Range
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
Power Requirements (max.)
12 VDC,
PoE (802.3af), 8.5 W
Powered by Base Unit Powered by Base Unit Powered by Base Unit
12 VDC,
PoE (802.3af), 6.5 W
12 VDC,
PoE (802.3af), 6.5 W
12 VDC,
PoE (802.3af), 6.5 W
12 VDC,
PoE (802.3af), 6.5 W
12 VDC,
PoE (802.3af), 6.5 W
12 VDC,
PoE (802.3af), 6.5 W
Standards: Complies with ONVIF (Prole S and G), CGI ASAPI. Contact factory for details.
1
Full Smart Suite: Line Crossing, Intrusion, Region Entrance, Region Exiting, Unattended Baggage, Object Removal, Scene Change, Sudden Audio Increase/Decrease, Audio Loss, Defocus, Object Counting, Defog
2
Basic Smart Suite: Counting, ROI, EIS, Defog
1.3 MP 1.3 MP 1.3 MP 2 MP 2 MP 2 MP 2 MP 2 MP 2 MP
*Base unit ONLY
*Base unit
NOT included
*Base unit
NOT included
*Base unit
NOT included
PROFESSIONAL SOLUTIONS
11
NETWORK PTZ CAMERAS - SMART PRO SERIES
INDOOR OUTDOOR
Model
DS-2DF5276-AE3 DS-2DF5220S-DE4/W DS-2DF5286-AE3 DS-2DF5276-AEL DS-2DF5286-AEL DS-2DF6236-AEL
DS-2DF6236V-AEL DS-2DF6336V-AEL DS-2DF7276-AEL
Image Sensor
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/2.8” progressive scan
CMOS
1/3” progressive scan
CMOS
1/2.8” progressive scan
CMOS
1/1.9” progressive scan
CMOS
1/2.8” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3" progressive scan
CMOS
Min. Illumination (lux)
Color: 0.05 @ ƒ/1.6
B/W: 0.005 @ ƒ/1.6
Color: 0.3 @ ƒ/1.6
B/W: 0.02 @ ƒ/1.6
Color: 0.4 @ ƒ/1.6
B/W: 0.03 @ ƒ/1.6
Color: 0.05 @ ƒ/1.6
B/W: 0.005 @ ƒ/1.6
Color: 0.4 @ ƒ/1.6
B/W: 0.03 @ ƒ/1.6
Color: 0.002 @ ƒ/1.5
B/W: 0.0002 @ ƒ/1.5
Color: 0.05 @ ƒ/1.6
B/W: 0.01 @ ƒ/1.6
Color: 0.05 @ ƒ/1.6
B/W: 0.01 @ ƒ/1.6
Color: 0.05 @ ƒ/1.6
B/W: 0.005 @ ƒ/1.6,
0 with IR
Lens
4.3 to 129.0 mm,
motorized zoom, autofocus
4.7 to 94 mm,
motorized zoom, autofocus
4.3 to 129.0 mm,
motorized zoom, autofocus
4.3 to 129.0 mm,
motorized zoom, autofocus
4.3 to 129.0 mm,
motorized zoom, autofocus
5.7 to 205.2 mm,
motorized zoom, autofocus
4.5 to 162 mm,
motorized zoom, autofocus
4.5 to 162 mm,
motorized zoom, autofocus
4.3 to 129.0 mm,
motorized zoom, autofocus
Horizontal Angle of View 57.4° to 2.8° 58.3° to 3.2° 65.5° to 2.11° 57.4° to 2.8° 65.5° to 2.11° 58.7° to 2.0°
60.6° to 3.68° 60.6° to 3.68° 57.4° to 2.8°
Optical Zoom 30x 20x 30x 30x 30x 36x
36x 36x 30x
Pan Range 360° endless 360° endless 360° endless 360° endless 360° endless 360° endless
360° endless 360° endless 360° endless
Tilt Range -5° to 90° (auto ip) -30° to 90° (auto ip) -5° to 90° (auto ip) -5° to 90° (auto ip) -5° to 90° (auto ip) -15° to 90° (auto ip)
-15° to 90° (auto ip) -15° to 90° (auto ip) -2° to 90° (auto ip)
Pan & Tilt Speed (Manual)
Pan: 0.1° to 300°/sec.
Tilt: 0.1° to 240°/sec.
Pan: 0.1° to 150°/sec.
Tilt: 0.1° to 120°/sec.
Pan: 0.1° to 300°/sec.
Tilt: 0.1° to 240°/sec.
Pan: 0.1° to 300°/sec.
Tilt: 0.1° to 240°/sec.
Pan: 0.1° to 300°/sec.
Tilt: 0.1° to 240°/sec.
Pan: 0.1° to 300°/sec.
Tilt: 0.1° to 240°/sec.
Pan: 0.1° to 300°/sec.
Tilt: 0.1° to 240°/sec.
Pan: 0.1° to 300°/sec.
Tilt: 0.1° to 240°/sec.
Pan: 0.1° to 160°/sec.
Tilt: 0.1° to 120°/sec.
Pan & Tilt Speed (Preset)
Pan: 540°/sec.
Tilt: 400°/sec.
Pan: 270°/sec.
Tilt: 200°/sec.
Pan: 540°/sec.
Tilt: 400°/sec.
Pan: 540°/sec.
Tilt: 400°/sec.
Pan: 540°/sec.
Tilt: 400°/sec.
Pan: 540°/sec.
Tilt: 400°/sec.
Pan: 540°/sec.
Tilt: 400°/sec.
Pan: 540°/sec.
Tilt: 400°/sec.
Pan: 240°/sec.
Tilt: 200°/sec.
Day/Night TRUE TRUE TRUE TRUE TRUE TRUE
TRUE TRUE TRUE
BLC/WDR Yes/Digital Yes/Digital Yes/Digital Yes/Digital Yes/Digital Yes/120 dB
Yes/140 dB Yes/120 dB Yes/Digital
Electronic Image Stabilization Yes Yes Yes Yes Yes Yes
--- --- Yes
IR Range Max. (Meters) --- --- --- --- --- ---
--- --- 150
Smart Features/
Presets/Tours/Patterns
PTZ Suite
3
/
300/8/4
PTZ Suite
3
/
300/8/4
PTZ Suite
3
/
300/8/4
PTZ Suite
3
/
300/8/4
PTZ Suite
3
/
300/8/4
PTZ Suite
3
/
300/8/4
PTZ Suite
3
/
300/8/4
PTZ Suite
3
/
300/8/4
PTZ Suite
3
/
300/8/4
Video Compression H.264/MJPEG/MPEG4 H.264/MJPEG/MPEG4 H.264/MJPEG/MPEG4 H.264/MJPEG/MPEG4 H.264/MJPEG/MPEG4 H.264/MJPEG/MPEG4
H.264/MJPEG H.264/MJPEG H.264/MJPEG/MPEG4
Maximum Image Resolution
(pixels)
1280x960 1920x1080 1920x1080 1280x960 1920x1080 1920x1080
1920x1080 2048x1536 1280x960
Frame Rate (fps) 30 @ 1280x960, 1280x720
30 @ 1920x1080,
1280x960, 1280x720
30 @ 1920x1080,
1280x960, 1280x720
30 @ 1280x960, 1280x720
30 @ 1920x1080,
1280x960, 1280x720
30 @ 1920x1080,
1280x960, 1280×720
30 @ 1920x1080, 1280x960,
1280x720
(60 @ 1920x1080, 1280x960,
1280x720 with WDR off)
30 @ 2048x1536, 1920x1080,
1280x960, 1280x720
(60 @ 2048x1536,
1920x1080, 1280x960, 1280x720
with WDR off)
30 @ 1280x960, 1280x720
Local Storage MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max.
MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max.
Ratings IK9, UL/cUL Listed UL/cUL Listed IK9, UL/cUL Listed IP66, IK10, UL/cUL Listed IP66, IK10, UL/cUL Listed IP67, IK10, UL/cUL Listed
IP67, IK10, UL/cUL Listed IP67, IK10, UL/cUL Listed IP66, UL/cUL Listed
Operating Temperature Range
-10° C to 50° C
(14° F to 122° F)
-10° C to 50° C
(14° F to 122° F)
-10° C to 50° C
(14° F to 122° F)
24 VAC: -40° C to 65° C
(-40° F to 149° F);
Hi-PoE: -30° C to 65° C
(-22° F to 149° F)
24 VAC: -40° C to 65° C
(-40° F to 149° F);
Hi-PoE: -30° C to 65° C
(-22° F to 149° F)
-40° C to 65° C
(-40° F to 149° F)
-40° C to 65° C
(-40° F to 149° F)
-40° C to 65° C
(-40° F to 149° F)
24 VAC: -40° C to 65° C
(-40° F to 149° F);
Hi-PoE: -30° C to 65° C
(-22° F to 149° F)
Power Requirements (max.)
24 VAC, PoE+ (802.3at), 25 W,
PoE injector included
12 VDC, PoE+ (802.3at), 25 W,
PoE injector included
24 VAC, PoE+ (802.3at), 25 W,
PoE injector included
24 VAC, PoE+ (802.3at), 60 W,
PoE Injector Included
24 VAC, PoE+ (802.3at), 60 W,
PoE Injector Included
24 VAC, PoE+ (802.3at), 60 W,
PoE Injector Included
24 VAC, PoE+ (802.3at),
60 W, PoE Injector Included
24 VAC, PoE+ (802.3at),
60 W, PoE Injector Included
24 VAC, Hi-PoE (802.3at),
60 W, PoE Injector Included
Standards: Complies with ONVIF (Prole S and G), CGI ASAPI. Contact factory for details.; Command Protocols: Hikvision and Pelco D/P
3
PTZ Suite: Line Crossing, Intrusion, Region Entrance, Region Exiting, Sudden Audio Increase/Decrease, Audio Loss, Defog
1.3 MP 2 MP 2 MP 1.3 MP 2 MP 2 MP
PROFESSIONAL SOLUTIONS
2 MP 3 MP 1.3 MP
12
LightFighterDarkFighter
NETWORK PTZ CAMERAS - SMART PRO SERIES
OUTDOOR
Model
DS-2DF7286-AEL DS-2DF8236I-AEL DS-2DF8236IV-AEL DS-2DF8336IV-AEL
DS-2DF8336IV-AELW
DS-2DF8836IV-AEL DS-2DF8836IV-AELW
Image Sensor
1/2.8" progressive scan
CMOS
1/1.9" progressive scan
CMOS
1/2.8" progressive scan
CMOS
1/3" progressive scan
CMOS
1/3” progressive scan CMOS
1/1.9" progressive scan
CMOS
1/1.9" progressive scan
CMOS
Min. Illumination (lux)
Color: 0.4 @ ƒ/1.6
B/W: 0.03 @ ƒ/1.6,
0 with IR
Color: 0.002 @ ƒ/1.5
B/W: 0.0002 @ ƒ/1.5,
0 with IR
Color: 0.05 @ ƒ/1.6
B/W: 0.01,
0 with IR
Color: 0.05 @ ƒ/1.6
B/W: 0.01,
0 with IR
Color: 0.05 @ ƒ/1.6
B/W: 0.01,
0 with IR
Color: 0.02 @ ƒ/1.5
B/W: 0.002 @ ƒ/1.5 with IR
Color: 0.02 @ ƒ/1.5
B/W: 0.002 @ ƒ/1.5 with IR
Lens
4.3 to 129.0 mm,
motorized zoom, autofocus
5.7 to 205.2 mm,
motorized zoom, autofocus
5.7 to 205.2 mm,
motorized zoom, autofocus
5.7 to 205.2 mm,
motorized zoom, autofocus
5.7 to 205.2 mm,
motorized zoom, autofocus
5.7 to 205.2 mm,
motorized zoom, autofocus
5.7 to 205.2 mm,
motorized zoom, autofocus
Horizontal Angle of View
65.5° to 2.11° 58.7° to 2.0° 60.6° to 3.68° 60.6° to 3.68° 60.6° to 3.68° 56.8° to 2.02° 56.8° to 2.02°
Optical Zoom
30x 36x 36x 36x 36x 36x 36x
Pan Range
360° endless 360° endless 360° endless 360° endless 360° endless 360° endless 360° endless
Tilt Range
-2° to 90° (auto ip) -20° to 90° (auto ip) -20° to 90° (auto ip) -20° to 90° (auto ip) -20° to 90° (auto ip) -20° to 90° (auto ip) -20° to 90° (auto ip)
Pan & Tilt Speed (Manual)
Pan: 0.1° to 160°/sec.
Tilt: 0.1° to 120°/sec.
Pan: 0.1° to 160°/sec.
Tilt: 0.1° to 120°/sec.
Pan: 0.1° to 160°/sec.
Tilt: 0.1° to 120°/sec.
Pan: 0.1° to 160°/sec.
Tilt: 0.1° to 120°/sec.
Pan: 0.1° to 160°/sec.
Tilt: 0.1° to 120°/sec.
Pan: 0.1° to 160°/sec.
Tilt: 0.1° to 120°/sec.
Pan: 0.1° to 160°/sec.
Tilt: 0.1° to 120°/sec.
Pan & Tilt Speed (Preset)
Pan: 240°/sec.
Tilt: 200°/sec.
Pan: 240°/sec.
Tilt: 200°/sec.
Pan: 240°/sec.
Tilt: 200°/sec.
Pan: 240°/sec
Tilt: 200°/sec.
Pan: 240°/sec.
Tilt: 200°/sec.
Pan: 240°/sec.
Tilt: 200°/sec.
Pan: 240°/sec.
Tilt: 200°/sec.
Day/Night
TRUE TRUE TRUE TRUE TRUE TRUE TRUE
BLC/WDR
Yes/Digital Yes/120 dB Yes/140 dB Yes/120 dB Yes/120 dB Yes/Digital Yes/Digital
Electronic Image
Stabilization
Yes Yes --- --- --- ---
IR Range Max. (Meters)
150 200 200 200 200 200 200
Smart Features/
Presets/Tours/Patterns
PTZ Suite
3
/
300/8/4
PTZ Suite
3
/
300/8/4
PTZ Suite
3
/
300/8/4
PTZ Suite
3
/
300/8/4
PTZ Suite
3
/
300/8/4
PTZ Suite
3
/
300/8/4
PTZ Suite
3
/
300/8/4
Video Compression
H.264/MJPEG/MPEG4 H.264/MJPEG/MPEG4 H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG
Maximum Image Resolution
(pixels)
1920x1080 1920x1080 1920x1080 2048x1536 2048x1536 4096x2160 4096x2160
Frame Rate (fps)
30 @ 1920x1080,
1280x960, 1280x720
30 @ 1920x1080,
1280x960, 1280×720
30 @ 1920x1080, 1280x960,
1280x720
(60 @ 1920x1080, 1280x960,
1280x720 with WDR off)
30 @ 2048x1536, 1920x1080,
1280x960, 1280x720
(60 @ 2048x1536,
1920x1080, 1280x960,
1280x720 with WDR off)
30 @ 2048x1536, 1920x1080,
1280x960, 1280x720
(60 @ 2048x1536,
1920x1080, 1280x960,
1280x720 with WDR off)
24 @ 4096x2160
(30 @3840x2160, 3072x1728,
2560x1440, 1920x1080,
1280x720)
24 @ 4096x2160
(30 @3840x2160, 3072x1728,
2560x1440, 1920x1080,
1280x720)
Local Storage
MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max.
Ratings
IP66, UL/cUL Listed IP66, IK10, UL/cUL Listed IP66, IK10, UL/cUL Listed IP66, IK10, UL/cUL Listed IP66, IK10, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed
Operating Temperature
Range
24 VAC: -40° C to 65° C
(-40° F to 149° F);
Hi-PoE: -30° C to 65° C
(-22° F to 149° F)
-40° C to 65° C
(-40° F to 149° F)
-40° C to 65° C
(-40° F to 149° F)
-40° C to 65° C
(-40° F to 149° F)
-40° C to 65° C
-40° F to 149° F)
-40° C to 65° C
(-40° F to 149° F)
-40° C to 65° C
(-40° F to 149° F)
Power Requirements (max.)
24 VAC, Hi-PoE (802.3at),
60 W, PoE Injector Included
24 VAC, Hi-PoE (802.3at),
60 W, PoE Injector Included
24 VAC, Hi-PoE (802.3at),
60 W, PoE Injector Included
24 VAC, Hi-PoE (802.3at),
60 W, PoE Injector Included
24 VAC, Hi-PoE (802.3at),
60 W, PoE Injector Included
24 VAC, Hi-PoE (802.3at),
60 W, PoE Injector Included
24 VAC, Hi-PoE (802.3at),
60 W, PoE Injector Included
Standards: Complies with ONVIF (Prole S and G), CGI ASAPI. Contact factory for details.; Command Protocols: Hikvision and Pelco D/P
3
PTZ Suite: Line Crossing, Intrusion, Region Entrance, Region Exiting, Sudden Audio Increase/Decrease, Audio Loss, Defog
2 MP 2 MP 3 MP 3 MP 4K 4K2 MP
PROFESSIONAL SOLUTIONS
13
FEATURED PRODUCT
Ultra HD Smart PTZ
Camera
DS-2DF8836IV-AELW
As a winner of the 2016 ISC West New Product
Showcase, the
DS-2DF8836IV-AELW Ultra HD Smart
PTZ Camera provides an array of benets, including
Ultra HD 4K image detail in real time (30fps), true WDR,
a 36x optical zoom lens, and an IR range of 650 feet.
Using video content analysis, the camera determines
when line crossing, intrusion, and region entry and exit
events have occurred, and it immediately sends alerts
to the user. ROI encoding and Smart Tracking allow
for even more efcient video surveillance, making this
camera as useful as it is cutting-edge.
LightFighterDarkFighter Wiper Wiper
OUTDOOR PTZ
Model
DS-2DT6223-AELY DS-2DY5223IW-AE DS-2DY9188-A DS-2DY9188-AI2
Image Sensor 1/1.9” progressive scan CMOS 1/1.9” progressive scan CMOS 1/1.9” progressive scan CMOS 1/1.9” progressive scan CMOS
Min. Illumination (lux)
Color: 0.002 @ ƒ/1.5, AGC On
B/W: 0.0002 @ ƒ/1.5 AGC On
Color: 0.002 @ ƒ/1.5, AGC On
B/W: 0.0002 @ ƒ/1.5, AGC On
Color: 0.002 @ ƒ/1.5, AGC On
B/W: 0.0002 @ ƒ/1.5, AGC On
Color: 0.002 @ ƒ/1.5, AGC On
B/W: 0.0002 @ ƒ/1.5, AGC On
Lens
5.9 to 135.7 mm,
motorized zoom, autofocus
5.9 to 135.7 mm,
motorized zoom, autofocus
5.7 to 205.2 mm,
motorized zoom, autofocus
5.7 to 205.2 mm,
motorized zoom, autofocus
Horizontal Angle of View 59.8° to 3.0° 59.8° to 3.0° 58.7° to 2° 58.7° to 2°
Optical Zoom 23x 23x 36x 36x
Pan Range 360° endless 360° endless 360° endless 360° endless
Tilt Range -20° to 90° (auto ip) -90° to 90° -40° to 90° -40° to 90°
Pan & Tilt Speed (Manual)
Pan: 0.1° to 300°/sec.
Tilt: 0.1° to 240°/sec.
Pan: 0.1° to 200°/sec.
Tilt: 0.1° to 50°/sec.
Pan: 0.1° to 100°/sec.
Tilt: 0.1° to 40°/sec.
Pan: 0.1° to 100°/sec.
Tilt: 0.1° to 40°/sec.
Pan & Tilt Speed (Preset)
Pan: 540°/sec.
Tilt: 400°/sec.
Pan: 540°/sec.
Tilt: 400°/sec.
Pan: 540°/sec.
Tilt: 400°/sec.
Pan: 540°/sec.
Tilt: 400°/sec.
Day/Night TRUE TRUE TRUE TRUE
BLC/WDR Yes/120 dB Yes/120 dB Yes/120 dB Yes/120 dB
Electronic Image Stabilization Yes Yes Yes Yes
IR Range Max. (Meters) --- 150 --- 200
Smart Features/
Presets/Tours/Patterns
PTZ Suite
3
/
300/8/4
PTZ Suite
3
/
300/8/4
PTZ Suite
3
/
256/8/4
PTZ Suite
3
/
256/8/4
Video Compression H.264/MJPEG/MPEG4 H.264/MJPEG H.264/MJPEG H.264/MJPEG
Maximum Image Resolution
(pixels)
1920x1080 1920x1080 1920x1080 1920x1080
Frame Rate (fps)
30 @ 1920x1080,
1280x960, 1280×720
30 @ 1920x1080, 1280x720
30 @ 1920x1080,
1280x960, 1280×720
30 @ 1920x1080,
1280x960, 1280×720
Local Storage MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max.
Ratings
316L Stainless Steel, IP67,
IK10,UL/cUL Listed
IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed
Operating Temperature Range
-40° C to 65° C
(-40° F to 149° F)
-40° C to 65° C
(-40° F to 149° F)
-40° C to 65° C
(-40° F to 149° )
-40° C to 65° C
(-40° F to 149° F)
Power Requirements (max.)
24 VAC, Hi-PoE (802.3at),
60 W, PoE Injector Included
24 VAC, Hi-PoE (802.3at),
45 W, PoE Injector Included
24 VAC, 60 W 24 VAC, 60 W
Standards: Complies with ONVIF (Prole S and G), CGI ASAPI. Contact factory for details.; Command Protocols: Hikvision and Pelco D/P
3
PTZ Suite: Line Crossing Detection, Intrusion Detection, Region Entrance, Region Exiting, Sudden Audio Increase/Decrease Detection, Audio Loss Detection, Defog
OUTDOOR DOME
DS-2CD6626DS-IZHS
Model
Image Sensor 1/1.8” progressive scan CMOS
Min. Illumination (lux)
Color: 0.002 @ ƒ/1.2
B/W: 0 with IR
Lens
2.8 to 12 mm @ ƒ/1.4,
motorized, autofocus
Horizontal Angle of View 92° to 32°
Pan/Tilt/Rotation
0° to 355°/
0° to 75°/0° to 355°
Day/Night TRUE
BLC/WDR Yes/120 dB
IR Range Max. (Meters) 30
Video Compression H.264+/H.264/MPEG4/MJPEG
Maximum Image Resolution
(pixels)
1920x1080
Frame Rate (fps)
30 @ 1920x1080, 1280x960,
1280x720
(60 @ 1920x1080, 1280x960
1280x720 with WDR off)
Multi-Streaming Triple
Smart Features Full Smart Suite
1
Motion Detection Yes
Audio Input/Output
IN: 1 line/mic
OUT: 1 line
Alarm Input/Output 1/1
Local Storage MicroSD 128 GB max.
Ratings
316L Stainless Steel,
IP67, IK10, UL/cUL Listed,
Anti-corrosion,
NEMA 4X, WF2, C5-M
Operating Temperature Range
-40° C to 60° C
(-40° F to 140° F)
Power Requirements (max.)
24 VAC, 12 VDC,
PoE (802.3af), 16 W
1
Full Smart Suite: Line Crossing, Intrusion, Region Entrance, Region
Exiting, Unattended Baggage, Object Removal, Scene Change, Sudden
Audio Increase/Decrease, Audio Loss, Defocus, Object Counting, Defog
2 MP
2 MP 2 MP 2 MP 2 MP
PROFESSIONAL SOLUTIONS
SPECIALTY NETWORK DOME AND PTZ CAMERAS - SMART PRO SERIES
SS
Stainless Steel
14
OVERVIEW
Specialty Camera
Solutions
Part of our Smart/Pro series, Hikvision is proud to
introduce its rst line of Specialty Camera Solutions.
Intended to bring Hikvision’s advanced technology
capabilities to the North American market, these
specialized camera systems will add to Hikvision’s
wide selection of innovative solutions. This means
more options for end users and more business
opportunities for our customers.
Whether it is a coastline or food processing site,
airport or highway, solar farm or critical infrastructure,
Hikvision is committed to delivering solutions for
demanding applications. Our specialty line also
features advanced analytics and all of the smart
essentials Hikvision customers have come to expect.
We invite you to explore these new product offerings
and expand your business when you provide your
customers with more options. Talk to your Hikvision
representative, or visit our website for more
information.
Stainless Steel Cameras
Constructed of 316L stainless steel and designed to
anti-corrosion standards.
Upright PTZ Cameras
Featuring DarkFighter technology and Smart Suite
Analytics
Thermal Imaging Cameras
Industry leading dual sensor technology with
thermography as standard.
DarkFighter DarkFighter DarkFighter
DarkFighter
SS
DarkFighter
SS
NETWORK VIDEO RECORDERS
PRO SERIES
Model
DS-9616NI-ST DS-9632NI-ST DS-9664NI-ST DS-9632NI-I8 DS-9664NI-I8 DS-96128NI-F24/H
4
DS-96256NI-F24/H
4
Max. Recording Resolution 6 MP 6 MP 6 MP 12 MP 12 MP 4K 4K
Video Compression H.264, H.264+ H.264, H.264+ H.264, H.264+ H.264, H264+, H.265 H.264, H264+, H.265 H.264 H.264
HDMI/VGA Output
1920x1080/1920x1080,
independent output
1920x1080/1920x1080,
independent output
1920x1080/1920x1080,
independent output
3840x2160/1920x1080 (HDMI1/VGA1
Synchronous), 1920x1080/1920x1080
(HDMI2/VGA2 Synchronous),
HDMI1/HDMI2 Independent
3840x2160/1920x1080 (HDMI1/VGA1
Synchronous), 1920x1080/1920x1080
(HDMI2/VGA2 Synchronous),
HDMI1/HDMI2 Independent
14 HDMI and 1 VGA at 1920x1080
Resolution, HDMI1/VGA/LCD
Synchronous. HDMI2 to HDMI14 are
Independent
14 HDMI and 1 VGA at 1920x1080
Resolution, HDMI1/VGA/LCD
Synchronous. HDMI2 to HDMI14 are
Independent
IP Video Inputs 16 32 64 32 64 128 256
Alarm Input/Output 16/4 16/4 16/4 16/4 16/4 16/8 16/8
USB 3 USB 2.0 3 USB 2.0 3 USB 2.0 2 USB 2.0; 1 USB 3.0 2 USB 2.0; 1 USB 3.0 1 USB 2.0; 2 USB 3.0 1 USB 2.0; 2 USB 3.0
RAID Support RAID 0, RAID 1, RAID 5, RAID 10 RAID 0, RAID 1, RAID 5, RAID 10 RAID 0, RAID 1, RAID 5, RAID 10 RAID 0, RAID 1, RAID 5, RAID 10 RAID 0, RAID 1, RAID 5, RAID 10 RAID 0, RAID 1, RAID 5, RAID 10 RAID 0, RAID 1, RAID 5, RAID 10
Internal SATA
8 SATA interfaces
(up to 6 TB each)
8 SATA interfaces
(up to 6 TB each)
8 SATA interfaces
(up to 6 TB each)
8 SATA interfaces
(up to 6 TB each)
8 SATA interfaces
(up to 6 TB each)
24 SATA interfaces
(up to 6 TB each)
24 SATA interfaces
(up to 6 TB each)
Maximum Internal Storage 48 TB 48 TB 48 TB 48 TB 48 TB 144 TB 144 TB
eSATA Interface Yes Yes Yes Yes Yes --- ---
Support DVD-RW Yes, replaces 4x SATA Yes, replaces 4x SATA Yes, replaces 4x SATA Yes, replaces 4x SATA Yes, replaces 4x SATA --- ---
Max. Incoming Bandwidth (Mbps)
100
(100 with RAID)
200
(100 with RAID)
200
(100 with RAID)
320
(200 with RAID)
320
(200 with RAID)
400
640
(400 with RAID)
Maximum Outgoing Bandwidth (Mbps)
240
(100 with RAID)
160
(100 with RAID)
160
(100 with RAID)
256
(200 with RAID)
256
(200 with RAID)
400 400
Ratings UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed
Rack Units 2 2 2 2 2 4 4
Power Requirements 100 to 240 VAC, 50 to 60 Hz 100 to 240 VAC, 50 to 60 Hz 100 to 240 VAC, 50 to 60 Hz 100 to 240 VAC, 50 to 60 Hz 100 to 240 VAC, 50 to 60 Hz 100 to 240 VAC, 50 to 60 Hz 100 to 240 VAC, 50 to 60 Hz
Power Consumption ≤45 W without HDD ≤45 W without HDD ≤45 W without HDD ≤30 W without HDD or DVD-R/W ≤30 W without HDD or DVD-R/W ≤100 W without HDD or DVD-R/W ≤100 W without HDD or DVD-R/W
Standards: Complies with ONVIF (Prole S), CGI ASAPI. Contact factory for details.
4
Requires rack shelf (not included) to mount in a 19” equipment rack; it is not recommended to rack mount the unit using rack rails and rack ears (not included) due to the weight. Weight without HDD ≤15.86 Kg (31.79 lb)
PROFESSIONAL SOLUTIONS
15
NETWORK CAMERAS - VALUE PLUS SERIES
OUTDOOR DOME OUTDOOR COMPACT DOME OUTDOOR DOME
Model
DS-2CD2122FWD-IS* DS-2CD2142FWD-IS* DS-2CD2152F-IS DS-2CD2522FWD-IS* DS-2CD2542FWD-IS* DS-2CD2552F-IS DS-2CD2722FWD-IZS* DS-2CD2742FWD-IZS* DS-2CD2752F-IZS
Image Sensor
1/2.8” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan CMOS
1/2.8” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3" progressive scan CMOS
1/2.8” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
Min. Illumination (lux)
Color: 0.028 @ ƒ/2.0
B/W: 0 with IR
Color: 0.028 @ ƒ/2.0
B/W: 0 with IR
Color: 0.028 @ f/2.0
B/W: 0 with IR
Color: 0.028 @ ƒ/2.0
B/W: 0 with IR
Color: 0.028 @ ƒ/2.0
B/W: 0 with IR
Color: 0.028 @ f/2.0
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Lens
Fixed, 4mm @ ƒ/2.0
(2.8 mm, 6 mm option)
Fixed, 2.8 mm @ ƒ/2.0
(4 mm, 6 mm option)
Fixed, 4mm @ ƒ/2.0
(6 mm option)
Fixed 4mm @ ƒ/2.0
(2.8 mm, 6 mm option)
Fixed, 2.8 mm @ ƒ/2.0
(4 mm, 6 mm option)
Fixed, 4mm @ ƒ/2.0
(2.8 mm, 6 mm option)
2.8 to 12 mm @ ƒ/1.4,
motorized
2.8 to 12 mm @ ƒ/1.4,
motorized
2.8 to 12 mm @ ƒ/1.4,
motorized
Horizontal Angle of View
102° (2.8 mm),
85° (4 mm), 52 ° (6 mm)
106° (2.8 mm),
83° (4 mm), 56° (6 mm)
89° (4 mm), 54.7° (6 mm)
102° (2.8 mm),
85° (4 mm), 52 ° (6 mm)
106° (2.8 mm),
83° (4 mm), 56° (6 mm)
86° (2.8 mm),
89° (4 mm), 54.7° (6 mm)
106° to 35° 112° to 33.8° 91° to 28°
Pan/Tilt/Rotation
0° to 355°/
0° to 75°/0° to 355°
0° to 355°/
0° to 75°/0° to 355°
0° to 355°/
0° to 75°/0° to 355°
-30° to 30°/
0° to 75°/0° to 360°
-30° to 30°/
0° to 75°/0° to 360°
-30° to 30°/
0° to 75°/0° to 360°
0° to 355°/
0° to 75°/0° to 355°
0° to 355°/
0° to 75°/0° to 355°
0° to 355°/ 0° to 75°/
0° to 355°
Day/Night TRUE TRUE TRUE TRUE TRUE TRUE TRUE TRUE TRUE
BLC/WDR No/120 dB Yes/120 dB Yes/Digital Yes/120 dB Yes/120 dB Yes/Digital Yes/120 dB Yes/120 dB Yes/Digital
IR Range Max. (meters) 30 30 30 10 10 10 30 30 30
Video Compression H.264+/H.264/MJPEG H.264+/H.264/MJPEG H.264+/H.264/MJPEG H.264+/H.264/MJPEG H.264+/H.264/MJPEG H.264+/H.264/MJPEG H.264+/H.264/MJPEG H.264+/H.264/MJPEG H.264+/H.264/MJPEG
Maximum Image Resolution (pixels) 1920x1080 2688x1520 2560x1920 1920x1080 2688x1520 2560x1920 1920x1080 2688x1520 2688x1520
Frame Rate (fps)
30 @ 1920x1080,
1280x960, 1280x720
20 @ 2688x1520
30 @ 1920x1080,
1280x720
20 @ 2560×1920,
30 @ 2048x1536,
1920×1080, 1280×720
30 @ 1920x1080,
1280x960, 1280x720
20 @ 2688x1520
30 @ 1920x1080,
1280x720
20 @ 2560×1920,
30 @ 2048x1536,
1920×1080, 1280×720
30 @ 1920x1080,
1280x960, 1280x720
20 @ 2688x1520
30 @ 1920x1080,
1280x720
20 @ 2688x1520
30 @ 1920x1080,
1280x720
Multi-Streaming Dual Dual Dual Dual Dual Dual Dual Dual Dual
Motion Detection Yes Yes Yes Yes Yes Yes Yes Yes Yes
Audio Input/Output
IN: 1 line
OUT: 1 line
IN: 1 line
OUT: 1 line
IN: 1 line
OUT: 1 line
Mic: Built in
OUT: 1 line
Mic: Built in
OUT: 1 line
IN: 1 line
OUT: 1 line
IN: 1 line
OUT: 1 line
IN: 1 line
OUT: 1 line
IN: 1 line
OUT: 1 line
Alarm Input/Output 1/1 1/1 1/1 1/1 1/1 1/1 1/1 1/1 1/1
Local Storage MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max.
Smart Features Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Ratings IP67
5
, IK10, UL/cUL Listed IP67
5
, IK10, UL/cUL Listed IP66, IK10, UL/cUL Listed IP67, IK8, UL/cUL Listed IP67, IK8, UL/cUL Listed IP66, IK8, UL/cUL Listed IP67
5
, IK10, UL/cUL Listed IP67
5
, IK10, UL/cUL Listed IP67
5
, IK10, UL/cUL Listed
Operating Temperature Range
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
Power Requirements (max.)
12 VDC,
PoE (802.3af), 5 W
12 VDC,
PoE (802.3af), 5 W
12 VDC,
PoE (802.3af), 5 W
12 VDC,
PoE (802.3af), 5 W
12 VDC,
PoE (802.3af), 5 W
12 VDC,
PoE (802.3af), 5 W
12 VDC,
PoE (802.3af), 5.5 W
12 VDC,
PoE (802.3af), 5.5 W
12 VDC,
PoE (802.3af), 5.5 W
Standards: Complies with ONVIF (Prole S and G), CGI ASAPI. Contact factory for details.
2
Basic Smart Suite: Line Crossing Detection, Intrusion Detection
5
IP67: effective June 2016 production
5 MP 5 MP
VALUE PLUS SOLUTIONS
16
2 MP 4 MP5 MP4 MP2 MP 2 MP 4 MP
*Black model available
DS-2CD2122FWD-ISB
*Black model available
DS-2CD2142FWD-ISB
*Black model available
DS-2CD2522FWD-ISB
*Black model available
DS-2CD2542FWD-ISB
*Black model available
DS-2CD2722FWD-IZSB
*Black model available
DS-2CD2742FWD-IZSB
NETWORK CAMERAS - VALUE PLUS SERIES
OUTDOOR TURRET OUTDOOR BULLET
Model
DS-2CD2322WD-I DS-2CD2342WD-I DS-2CD2352-I DS-2CD2022WD-I DS-2CD2042WD-I DS-2CD2T22WD-I5 DS-2CD2T42WD-I5 DS-2CD2T52-I5 DS-2CD2622FWD-IZS DS-2CD2642FWD-IZS
Image Sensor
1/2.8” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/2.8” progressive scan
CMOS
1/3” progressive scan
CMOS
1/2.8” progressive scan
CMOS
1/3” progressive scan
CMOS
1/2.8” progressive scan
CMOS
1/2.8” progressive scan
CMOS
1/3” progressive scan
CMOS
Min. Illumination (lux)
Color: 0.028 @ ƒ/2.0
B/W: 0 with IR
Color: 0.028 @ ƒ/2.0
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.028 @ ƒ/2.0
B/W: 0 with IR
Color: 0.028 @ ƒ/2.0
B/W: 0 with IR
Color: 0.028 @ ƒ/2.0
B/W: 0 with IR
Color: 0.028 @ ƒ/2.0
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Lens
Fixed, 2.8 mm @ ƒ/2.0
(4 mm, 6 mm option)
Fixed, 2.8 mm @ ƒ/2.0
(4 mm, 6 mm option)
Fixed, 2.8 mm @ ƒ/2.0
(4 mm, 6 mm option)
Fixed, 4 mm @ ƒ/2.0
(6 mm option)
Fixed, 4 mm @ ƒ/2.0
(6 mm option)
Fixed, 4 mm @ ƒ/2.0
(6mm option)
Fixed, 4 mm @ ƒ/2.0
(6mm option)
Fixed, 4 mm @ ƒ/2.0
(6mm option)
2.8 to 12 mm @ ƒ/1.4,
motorized
2.8 to 12 mm @ ƒ/1.4,
motorized
Horizontal Angle of View
109° (2.8 mm),
90° (4 mm), 54° (6 mm)
106° (2.8 mm),
83° (4 mm), 56° (6 mm)
112° (2.8 mm),
89° (4 mm), 54.7° (6 mm)
85° (4 mm), 52° (6 mm) 82° (4 mm) , 55° (6 mm) 90° (4 mm), 54° (6 mm) 83° (4 mm), 56° (6 mm) 89° (4 mm), 54.7° (6 mm) 106° to 35° 112° to 33.8°
Pan/Tilt/Rotation
0° to 360°/
0° to 75°/0° to 360°
0° to 360°/
0° to 75°/0° to 360°
0° to 355°/
0° to 75°/0° to 355°
3-Axis Positioning 3-Axis Positioning 3-Axis Positioning 3-Axis Positioning 3-Axis Positioning 3-Axis Positioning 3-Axis Positioning
Day/Night TRUE TRUE TRUE TRUE TRUE TRUE TRUE TRUE TRUE TRUE
BLC/WDR Yes/120 dB Yes/120 dB Yes/Digital No/120 dB No/120 dB Yes/120 dB Yes/120 dB Yes/Digital Yes/120 dB Yes/120 dB
IR Range Max. (meters) 30 30 30 30 30 50 50 50 30 30
Video Compression H.264+/H.264/MJPEG H.264+/H.264/MJPEG H.264+/H.264/MJPEG H.264+/H.264/MJPEG H.264+/H.264/MJPEG H.264+/H.264/MJPEG H.264+/H.264/MJPEG H.264+/H.264/MJPEG H.264+/H.264/MJPEG H.264+/H.264/MJPEG
Maximum Image Resolution
(pixels)
1920x1080 2688x1520 2560x1920 1920x1080 2688x1520 1920x1080 2688x1520 2560x1920 1920x1080 2688x1520
Frame Rate (fps)
30 @ 1920x1080,
1280x960, 1280x720
20 @ 2688x1520
30 @ 1920x1080, 1280x720
20 @ 2560×1920,
30 @ 2048x1536,
1920×1080, 1280×720
30 @ 1920x1080,
1280x960, 1280x720
20 @ 2688x1520
30 @ 1920x1080, 1280x720
30 @ 1920x1080,
1280x960, 1280x720
20 @ 2688x1520
30 @ 1920x1080, 1280x720
20 @ 2560×1920,
30 @ 2048x1536,
1920×1080, 1280×720
30 @ 1920x1080,
1280x960, 1280x720
20 @ 2688x1520
30 @ 1920x1080, 1280x720
Multi-Streaming Dual Dual Dual Dual Dual Dual Dual Dual Dual Dual
Motion Detection Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Audio Input/Output --- --- --- -- -- -- --- --
IN: 1 line
OUT: 1 line
IN: 1 line
OUT: 1 line
Alarm Input/Output --- --- --- -- -- -- --- -- 1/1 1/1
Local Storage --- --- --- -- -- -- --- -- MicroSD, 128 GB max. MicroSD, 128 GB max.
Smart Features Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
4
Basic Smart Suite
2
Basic Smart Suite
4
Basic Smart Suite
4
Ratings IP67
5
, UL/cUL Listed IP67
5
, UL/cUL Listed IP66, UL/cUL Listed IP67
5
, UL/cUL Listed3 IP67
5
, UL/cUL Listed IP67
5
, UL/cUL Listed IP67
5
, UL/cUL Listed IP66, UL/cUL Listed IP67
5
, UL/cUL Listed IP67
5
, UL/cUL Listed
Operating Temperature
Range
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C (-22° F to
140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
Power Requirements (max.)
12 VDC,
PoE (802.3af), 7.5 W
12 VDC,
PoE (802.3af), 7.5 W
12 VDC,
PoE (802.3af), 5.5 W
12 VDC,
PoE (802.3af), 5 W
12 VDC,
PoE (802.3af), 5 W
12 VDC,
PoE (802.3af), 7.5 W
12 VDC,
PoE (802.3af), 7.5 W
12 VDC,
PoE (802.3af), 7.5 W
12 VDC,
PoE (802.3af), 7.5 W
12 VDC,
PoE (802.3af), 7.5 W
Standards: Complies with ONVIF (Prole S and G), CGI ASAPI. Contact factory for details.
4
Basic Smart Suite: Line Crossing, Intrusion
5
IP67: effective June 2016 production
5 MP 4 MP2 MP 2 MP 2 MP 2 MP4 MP 4 MP 5 MP 4 MP
VALUE PLUS SOLUTIONS
17
EXIR EXIR EXIR
EXIR EXIR EXIR
NETWORK CAMERAS - VALUE SERIES
INDOOR RECESSED DOME OUTDOOR DOME OUTDOOR COMPACT DOME OUTDOOR DOME
Model
DS-2CD2E10F DS-2CD2E20F DS-2CD2112F-I DS-2CD2132F-I DS-2CD2510F DS-2CD2512F-I DS-2CD2520F DS-2CD2532F-I DS-2CD2712F-I DS-2CD2732F-I
Image Sensor
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
Min. Illumination (lux)
Color: 0.028 @ ƒ/2.0
B/W: 0 with IR
Color: 0.028 @ ƒ/2.0
B/W: 0 with IR
Color: 0.028 @ ƒ/2.0
B/W: 0 with IR
Color: 0.19 @ ƒ/2.0
B/W: 0 with IR
Color: 0.028 @ ƒ/2.0
B/W: 0.0028 @ ƒ/2.0
Color: 0.028 @ ƒ/2.0
B/W: 0 with IR
Color: 0.028 @ ƒ/2.0
B/W: 0.0028 @ ƒ/2.0
Color: 0.19 @ ƒ/2.0
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.01 @ ƒ/1.4
B/W: 0 with IR
Lens
Fixed, 4 mm @ ƒ/2.0
(2.8 mm, 6 mm option)
Fixed, 4 mm @ ƒ/2.0
(2.8 mm, 6 mm option)
Fixed, 4 mm @ ƒ/2.0
(2.8 mm, 6 mm,
12 mm option)
Fixed, 4 mm @ ƒ/2.0
(2.8 mm, 6 mm,
12 mm option)
Fixed, 2 mm @ ƒ/2.0
Fixed, 4 mm @ ƒ/2.0
(2.8 mm, 6 mm option)
Fixed, 2 mm @ ƒ/2.0
Fixed, 4 mm @ ƒ/2.0
(2.8 mm, 6 mm option)
2.8 to 12 mm @ ƒ/1.4,
manual
2.8 to 12 mm @ ƒ/1.4,
manual
Horizontal Angle of View
92.5° (2.8 mm),
73.1° (4 mm) , 46° (6 mm)
106° (2.8 mm),
85° (4 mm), 52° (6 mm)
92.5° (2.8 mm),
73.1° (4 mm),
46° (6 mm), 22° (12 mm)
86° (2.8 mm), 70° (4 mm),
43.3 (6 mm), 20.6° (12 mm)
115° (2 mm)
92.5° (2.8 mm),
73.1° (4 mm), 46° (6 mm)
126° (2 mm)
86° (2.8 mm),
70° (4 mm), 43.3° (6 mm)
98.4° to 30.2° 91.2° to 28.3°
Pan/Tilt/Rotation 0° to 355°/0° to 80°/na 0° to 355°/0° to 80°/na
0° to 355°/
0° to 75°/0° to 355°
0° to 355°/
0° to 75°/0° to 355°
±15°/0° to 90°/±15° ±30°/0° to 75°/0° to 360° ±15°/0° to 90°/±15° ±30°/0° to 75°/0° to 360°
0° to 355°/
0° to 75°/0° to 355°
0° to 355°/
0° to 75°/0° to 355°
Day/Night Electronic Electronic TRUE TRUE Electronic TRUE Electronic TRUE TRUE TRUE
BLC/WDR Yes/Digital Yes/Digital Yes/Digital Yes/Digital Yes/Digital Yes/Digital Yes/Digital Yes/Digital Yes/Digital Yes/Digital
IR Range Max. (meters) --- --- 30 30 --- 10 --- 10 30 30
Video Compression H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/ MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG
Maximum Image Resolution
(pixels)
1280x960 1920x1080 1280x960 2048x1536 1280x960 1280x960 1920x1080 2048x1536 1280x960 2048x1536
Frame Rate (fps) 30 @ 1280x960, 1280x720
30 @ 1920x1080,
1280x960, 1280x720
30 @ 1280x960, 1280x720
20 @ 2048x1536,
30 @ 1920x1080, 1280x720
30 @ 1280x960,
1280x720, 704x576
30 @ 1280x960, 1280x720
30 @ 1920x1080,
1280x960, 1280x720
20 @ 2048x1536
30 @ 1920x1080, 1280x720
30 @ 1280x960, 1280x720
20 @ 2048x1536
30 @ 1920x1080, 1280x720
Multi-Streaming Dual Dual Dual Dual Dual Dual Dual Dual Dual Dual
Smart Features Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Motion Detection Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Audio Input/Output --- --- --- --- --- --- --- --- --- ---
Alarm Input/Output --- --- --- --- --- --- --- 1/1 --- ---
Local Storage MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max.
Ratings UL/cUL Listed UL/cUL Listed IP66, IK10, UL/cUL Listed IP66, IK10, UL/cUL Listed IP67, IK10, UL/cUL Listed IP66, IK8, UL/cUL Listed IP67, IK10, UL/cUL Listed IP66, IK8, UL/cUL Listed IP66, IK10, UL/cUL Listed IP66, IK10, UL/cUL Listed
Operating Temperature
Range
-10° C to 40° C
(14° F to 104° F)
-10° C to 40° C
(14° F to 104° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
Power Requirements (max.)
12 VDC,
PoE (802.3af), 4.2 W
12 VDC,
PoE (802.3af), 4.5 W
12 VDC,
PoE (802.3af), 5 W
12 VDC,
PoE (802.3af), 5 W
12 VDC,
PoE (802.3af), 4 W
12 VDC,
PoE (802.3af), 7 W
12 VDC,
PoE (802.3af), 4 W
12 VDC,
PoE (802.3af), 7 W
12 VDC,
PoE (802.3af), 7 W
12 VDC,
PoE (802.3af), 7 W
Standards: Complies with ONVIF (Prole S and G), CGI ASAPI. Contact factory for details.
2
Basic Smart Suite: Line Crossing, Intrusion
1.3 MP 1.3 MP 1.3 MP1.3 MP1.3 MP 3 MP 3 MP 3 MP2 MP 2 MP
VALUE SOLUTIONS
18
NETWORK CAMERAS - VALUE SERIES
OUTDOOR TURRET OUTDOOR BULLET INDOOR PINHOLE COVERT INDOOR FISHEYE
Model
DS-2CD2332-I DS-2CD2012-I DS-2CD2032-I DS-2CD2212-I5 DS-2CD2232-I5 DS-2CD2612F-I DS-2CD2632F-I DS-2CD2D14WD DS-2CD2D14WD/M DS-2CD2942F-IS
Image Sensor
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/4” progressive scan
CMOS
1/4” progressive scan
CMOS
1/3” progressive scan
CMOS
Min. Illumination (lux)
Color: 0.19 @ ƒ/2.0
B/W: 0 with IR
Color: 0.028 @ ƒ/2.0
B/W: 0 with IR
Color: 0.19 @ ƒ/2.0
B/W: 0 with IR
Color: 0.028 @ ƒ/2.0
B/W: 0 with IR
Color: 0.19 @ ƒ/2.0
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.1 @ ƒ/1.4
B/W: 0 with IR
Color: 0.028 @ ƒ/2.0 Color: 0.028 @ ƒ/2.0
Color: 0.018 @ ƒ/1.6
B/W: 0.0018 @ ƒ/1.6
0 with IR
Lens
Fixed 4 mm @ ƒ/2.0
(2.8 mm, 6 mm,
12 mm option)
Fixed 4 mm @ ƒ/2.0
(6 mm, 12 mm option)
Fixed 4 mm @ ƒ/2.0
(6 mm, 12 mm option)
Fixed 4 mm @ ƒ/2.0
(6 mm, 12 mm option)
Fixed 4 mm @ ƒ/2.0
(6 mm, 12 mm option)
2.8 to 12 mm @ ƒ/1.4,
manual
2.8 to 12 mm @ ƒ/1.4,
manual
Pinhole, 3.2 mm @ ƒ/2.5
2.8 mm @ ƒ/2.0 or
4.0 mm @ ƒ/2.0
Fisheye, 1.6 mm, ƒ/1.6
Horizontal Angle of View
86° (2.8 mm), 70° (4 mm),
43.3° (6 mm),
20.6° (12 mm)
73.1° (4 mm),
46° (6 mm), 22° (12 mm)
70° (4 mm),
43.3° (6 mm),
20.6° (12 mm)
73.1° (4 mm),
46° (6 mm), 22° (12 mm)
70° (4 mm),
43.3° (6 mm),
20.6° (12 mm)
98.4° to 30.2° 91.2° to 28.3° 65° (3.2 mm)
67.3° (2.8 mm),
53° (4.0 mm)
186° (horizontal),
106° (vertical)
Pan/Tilt/Rotation
0° to 360°/
0°to 75°/0° to 360°
3-Axis Positioning 3-Axis Positioning 3-Axis Positioning 3-Axis Positioning 3-Axis Positioning 3-Axis Positioning 0° to 360°/0° to 90°/na 0° to 360°/0° to 90°/na ---
Day/Night TRUE TRUE TRUE TRUE TRUE TRUE TRUE Electronic Electronic TRUE
BLC/WDR Yes/Digital Yes/Digital Yes/Digital Yes/Digital Yes/Digital Yes/Digital Yes/Digital No/100 dB No/100 dB Yes/Digital
IR Range Max. (meters) 30 30 30 50 50 30 30 --- --- 8
Video Compression H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG
Maximum Image Resolution
(pixels)
2048x1536 1280x960 2048x1536 1280x960 2048x1536 1280x960 2048x1536 1280x720 1280x720 2560x1440
Frame Rate (fps)
20 @ 2048x1536
30 @ 1920x1080, 1280x720
30 @ 1280x960, 1280x720
20 @ 2048x1536
30 @ 1920x1080, 1280x720
30 @ 1280x960, 1280x720
20 @ 2048x1536
30 @ 1920x1080, 1280x720
30 @ 1280x960, 1280x720
20 @ 2048x1536
30 @ 1920x1080, 1280x720
30 @ 1280x720,
704x576, 640x480
30 @ 1280x720,
704x576, 640x480
15 @ 2560x1440
30 @ 1920x1080, 1280x720
Multi-Streaming Dual Dual Dual Dual Dual Dual Dual Dual Dual Dual
Smart Features Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
+
tampering alarm, dynamic
analysis, motion detection
Basic Smart Suite
2
+
tampering alarm, dynamic
analysis, motion detection
---
Motion Detection Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Audio Input/Output --- --- --- --- --- --- --- --- ---
IN: 1 line
OUT: 1 line
Alarm Input/Output --- --- --- --- --- --- --- --- --- 1/1
Local Storage --- --- --- --- --- MicroSD, 128 GB max. MicroSD, 128 GB max. --- --- MicroSD, 128 GB max.
Ratings IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed
Operating Temperature
Range
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-10° C to 40° C
(14° F to 104° F)
Power Requirements (max.)
12 VDC,
PoE (802.3af), 7 W
12 VDC,
PoE (802.3af), 7 W
12 VDC,
PoE (802.3af), 7 W
12 VDC,
PoE (802.3af), 9 W
12 VDC,
PoE (802.3af), 9 W
12 VDC,
PoE (802.3af), 7 W
12 VDC,
PoE (802.3af), 7 W
12 VDC, 3 W 12 VDC, 3 W
12 VDC,
PoE (802.3af), 5.55 W
Standards: Complies with ONVIF (Prole S and G), CGI ASAPI. Contact factory for details.
2
Basic Smart Suite: Line Crossing, Intrusion
1.3 MP 3 MP 1.3 MP3 MP 1.3 MP 3 MP 1 MP 1 MP3 MP 4 MP
VALUE SOLUTIONS
19
EXIR EXIR EXIR
NETWORK PTZ CAMERAS - VALUE SERIES
INDOOR PTeZ™ INDOOR PTZ OUTDOOR PTZ
Model
DS-2DE2103-DE3/W DS-2DE2202I-DE3/W DS-2DE4220-AE3 DS-2DE5184-AE3 DS-2DE3304W-DE DS-2DE4220-AE
Image Sensor 1/3" progressive scan CMOS 1/3” progressive scan CMOS 1/2.8” progressive scan CMOS 1/2.8” progressive scan CMOS 1/2.8” progressive scan CMOS 1/2.8” progressive scan CMOS
Min. Illumination (lux)
Color: 0.05 @ ƒ/1.6
B/W: 0.01 @ ƒ/1.6
Color: 0.05 @ ƒ/2.0
B/W: 0.01 @ ƒ/2.0
Color: 0.05 @ ƒ/1.6
B/W: 0.01 @ ƒ/1.6
Color: 0.05 @ ƒ/1.6
B/W: 0.01 @ ƒ/1.6
Color: 0.05 @ ƒ/1.6
B/W: 0.01 @ ƒ/1.6
Color: 0.05 @ ƒ/1.6
B/W: 0.01 @ ƒ/1.6
Lens
3.6 to 11 mm,
3x (effective)
5
via PTeZ™
3.6 to 8.6 mm,
2x (effective)
5
via PTeZ™
4.7 to 94 mm,
motorized zoom, autofocus
4.7 to 94 mm,
motorized zoom, autofocus
2.8 to 12 mm,
motorized zoom, autofocus
4.7 to 94 mm,
motorized zoom, autofocus
Horizontal Angle of View 80° to 33° 80° to 64.5° 58.3° to 3.2° 58.3° to 3.2° 105° to 33.5° 58.3° to 3.2°
Optical Zoom 3x 2x 20x 20x 4x (16x Digital) 20x
Pan Range 0° to 350° 0° to 350° 360° endless 360° endless 0° to 350° 360° endless
Tilt Range 0° to 90° (auto ip) +5° to 90° +5° to 90° (auto ip) -5° to 90° (auto ip) +5° to 90° +5° to 90° (auto ip)
Pan & Tilt Speed (Manual)
Pan: 0.1° to 50°/sec.
Tilt: 0.1° to 40°/sec.
Pan: 0.1° to 60°/sec.
Tilt: 0.1° to 50°/sec.
Pan: 0.1° to 160°/sec.
Tilt: 0.1° to 120°/sec.
Pan: 0.1° to 250°/sec.
Tilt: 0.1° to 150°/sec.
Pan: 0.1° to 60°/sec.
Tilt: 0.1° to 50°/sec.
Pan: 0.1° to 160°/sec.
Tilt: 0.1° to 120°/sec.
Pan & Tilt Speed (Preset)
Pan: 50°/sec.
Tilt: 40°/sec.
Pan: 50°/sec.
Tilt: 50°/sec.
Pan: 160°/sec.
Tilt: 120°/sec.
Pan: 300°/sec.
Tilt: 200°/sec.
Pan: 50°/sec.
Tilt: 50°/sec.
Pan: 160°/sec.
Tilt: 120°/sec.
Day/Night TRUE TRUE TRUE TRUE TRUE TRUE
BLC/WDR Yes/Digital Yes/Digital Yes/Digital Yes/Digital Yes/Digital Yes/Digital
IR Range Max. (meters) --- 20 --- --- --- ---
Smart Features Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Presets/Tours/Patterns 300/0/0 300/0/0 300/8/4 300/8/4 300/8/4 300/8/4
Wireless IEEE 802.11b/g/n IEEE 802.11b/g/n --- --- --- ---
Video Compression H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG
Maximum Image Resolution
(pixels)
1280x720 1920x1080 1920x1080 1920x1080 2048x1536 1920x1080
Frame Rate (fps) 30 @ 1280x720 30 @ 1920x1080 30 @ 1920x1080, 1280x720 30 @ 1920x1080, 1280x720
30 @ 2048x1536, 1920x1080,
1280x960, 1280x720
30 @ 1920x1080, 1280x720
Local Storage MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max.
Ratings UL/cUL Listed UL/cUL Listed IK8, UL/cUL Listed IK9, UL/cUL Listed IP67, UL/cUL Listed IP66, IK8, UL/cUL Listed
Operating Temperature range
-10° C to 50° C
(14° F to 122° F)
-10° C to 50° C
(14° F to 122° F)
-10° C to 50° C
(14° F to 122° F)
-10° C to 50° C
(14° F to 122° F)
-30°C to 65° C
(-22°F to 149°F)
-30° C to 65° C
(-22° F to 149° F)
Power Requirements (max.)
12 VDC,
PoE (802.3af), 6 W
12 VDC,
PoE (802.3af), 9 W
24 VAC,
PoE (802.3af), 18 W
24 VAC,
PoE+ (802.3at), 18 W
12 VDC,
PoE (802.3af), 8 W
24 VAC,
PoE+ (802.3at), 18 W
Standards: Complies with ONVIF (Prole S and G), CGI ASAPI. Contact factory for details.; Command Protocols: Hikvision and Pelco D/P
2
Basic Smart Suite: Line Crossing, Intrusion Detection
5
PTeZ™ cameras have a sensor-based zoom
1 MP 2 MP 2 MP 2 MP 2 MP3 MP
VALUE SOLUTIONS
20
FEATURED PRODUCT
3 MP Mini PTZ
Repositionable IP Dome
Not only does the DS-2DE3304W-DE mini dome
camera deliver an incredible image during daytime
scenes, it also produces clear images down to 0.01
lux. The 2.8 to 12mm autofocus zoom lens yields 4x
optical zoom and presents the perfect solution for
limited areas, such as doorways, perimeter gates,
or guard booths. It is designed for installations that
do not require the 360° high speed positioning of
traditional PTZ cameras but that do need occasional
pan/tilt/zoom capabilities, including presets, patrols,
and patterns. Its IP66 and IK10 ratings along with its
RCM-4 recessed ceiling mount allow the camera to be
discreetly mounted in outdoor softs for unobtrusive,
compact installations.
NETWORK PTZ CAMERAS - VALUE SERIES
OUTDOOR PTZ OUTDOOR IR PTZ
Model
DS-2DE5174-AE DS-2DE5184-AE DS-2DE5130W-AE DS-2DE5230W-AE DS-2DE5220I-AE DS-2DE7174-AE DS-2DE7184-AE DS-2DE7130IW-AE DS-2DE7230IW-AE
Image Sensor
1/3” progressive scan
CMOS
1/2.8” progressive scan
CMOS
1/3” progressive scan
CMOS
1/2.8” progressive scan CMOS
1/2.8” progressive scan
CMOS
1/3” progressive scan
CMOS
1/2.8” progressive scan
CMOS
1/3” progressive scan CMOS
1/2.8” progressive scan
CMOS
Min. Illumination (lux)
Color: 0.05 @ ƒ/1.4
B/W: 0.01 @ ƒ/1.4
Color: 0.05 @ ƒ/1.6
B/W: 0.01 @ ƒ/1.6
Color: 0.05 @ ƒ/1.6
B/W: 0.01 @ ƒ/1.6
Color: 0.05 @ ƒ/1.6
B/W: 0.01 @ ƒ/1.6
Color: 0.05 @ ƒ/1.5
B/W: 0.01 @ ƒ/1.5
Color: 0.05 @ ƒ/1.4
B/W: 0.01 @ ƒ/1.4, 0 with IR
Color: 0.05 @ ƒ/1.6
B/W: 0.01 @ ƒ/1.6, 0 with IR
Color: 0.05 @ ƒ/1.6, AGC On
B/W: 0.01 @ ƒ/1.6, 0 with IR
Color: 0.05 @ ƒ/1.6, AGC On
B/W: 0.01 @ ƒ/1.6, 0 with IR
Lens
4.7 to 94 mm,
motorized zoom, autofocus
4.7 to 94 mm,
motorized zoom, autofocus
4.3 to 129 mm,
motorized zoom, autofocus
4.3 to 129 mm,
motorized zoom, autofocus
4.7 to 94 mm,
motorized zoom, autofocus
4.7 to 94 mm,
motorized zoom, autofocus
4.7 to 94 mm,
motorized zoom, autofocus
4.3 to 129 mm,
motorized zoom, autofocus
4.3 to 129 mm,
motorized zoom, autofocus
Horizontal Angle of View 58.3° to 3.2° 58.3° to 3.2° 57.4° to 2.8° 65.5° to 2.1° 58.3° to 3.2° 58.3° to 3.2° 58.3° to 3.2° 65.5° to 2.1° 65.5° to 2.1°
Optical Zoom 20x 20x 30x 30x 20x 20x 20x 30x 30x
Pan Range 360° endless 360° endless 360° endless 360° endless 360° endless 360° endless 360° endless 360° endless 360° endless
Tilt Range -5° to 90° (auto ip) -5° to 90° (auto ip) -5° to 90° (auto ip) -5° to 90° (auto ip) -15° to 90° (auto ip) -15° to 90° (auto ip) -15° to 90° (auto ip ) -15° to 90° (auto ip) -15° to 90° (auto ip)
Pan & Tilt Speed (Manual)
Pan: 0.1° to 250°/sec.
Tilt: 0.1° to 150°/sec.
Pan: 0.1° to 250°/sec.
Tilt: 0.1° to 150°/sec.
Pan: 0.1° to 250°/sec.
Tilt: 0.1° to 150°/sec.
Pan: 0.1° to 250°/sec.
Tilt: 0.1° to 150°/sec.
Pan: 0.1° to 400°/sec.
Tilt: 0.1° to 200°/sec.
Pan: 0.1° to 160°/sec.
Tilt: 0.1° to 120°/sec.
Pan: 0.1° to 160°/sec.
Tilt: 0.1° to 120°/sec.
Pan: 0.1° to 160°/sec.
Tilt: 0.1° to 120°/sec.
Pan: 0.1° to 160°/sec.
Tilt: 0.1° to 120°/sec.
Pan & Tilt Speed (Preset)
Pan: 300°/sec.
Tilt: 200°/sec.
Pan: 300°/sec.
Tilt: 200°/sec.
Pan: 300°/sec.
Tilt: 200°/sec.
Pan: 300°/sec.
Tilt: 200°/sec.
Pan: 400°/sec.
Tilt: 200°/sec.
Pan: 240°/sec.
Tilt: 200°/sec.
Pan: 240°/sec.
Tilt: 200°/sec.
Pan: 240°/sec.
Tilt: 200°/sec.
Pan: 240°/sec.
Tilt: 200°/sec.
Day/Night TRUE TRUE TRUE TRUE TRUE TRUE TRUE TRUE TRUE
BLC/WDR Yes/Digital Yes/Digital Yes/Digital Yes/Digital Yes/Digital Yes/Digital Yes/Digital Yes/Digital Yes/Digital
IR Range Max. (meters) --- --- --- --- 150 150 150 150 150
Smart Features Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Basic Smart Suite
2
Presets/Tours/Patterns 300/8/4 300/8/4 300/8/4 300/8/4 300/8/4 300/8/4 300/8/4 300/8/4 300/8/4
Wireless --- --- --- --- --- --- --- --- ---
Video Compression H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG
Maximum Image Resolution
(pixels)
1280x960 1920x1080 1280x960 1920x1080 1920x1080 1280x960 1920x1080 1280x960 1920x1080
Frame Rate (fps) 30 @ 1280x960, 1280x720
30 @ 1920x1080,
1280x960, 1280x720
30 @ 1280x960, 1280x720
30 @ 1920x1080,
1280x960, 1280x720
30 @ 1920x1080, 1280x720 30 @ 1280x960, 1280x720
30 @ 1920x1080,
1280x960, 1280x720
30 @ 1280x960, 1280x720
30 @ 1920x1080,
1280x960, 1280x720
Local Storage MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max. MicroSD, 128 GB max.
Ratings IP66, IK10, UL/cUL Listed IP66, IK10, UL/cUL Listed IP66, IK10, UL/cUL Listed IP66, IK10, UL/cUL Listed IP66, IK10, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed
Operating Temperature range
-30° C to 65° C
(-22° F to 149° F)
-30° C to 65° C
(-22° F to 149° F)
-30° C to 65° C
(-22° F to 149° F)
-30° C to 65° C
(-22° F to 149° F)
-30° C to 65° C
(-22° F to 149° F)
-30° C to 65° C
(-22° F to 149° F)
-30° C to 65° C
(-22° F to 149° F)
-30° C to 65° C
(-22° F to 149° F)
-30° C to 65° C
(-22° F to 149° F)
Power Requirements (max.)
24 VAC,
PoE+ (802.3at), 18 W
24 VAC,
PoE+ (802.3at), 18 W
24 VAC,
PoE+ (802.3at), 18 W
24 VAC,
PoE+ (802.3at), 18 W
24 VAC,
Hi-PoE (802.3at), 32 W
24 VAC,
Hi-PoE (802.3at), 40 W
24 VAC,
Hi-PoE (802.3at), 40 W
24 VAC,
Hi-PoE (802.3at), 40 W
24 VAC,
Hi-PoE (802.3at), 40 W
Standards: Complies with ONVIF (Prole S and G), CGI ASAPI. Contact factory for details; Command Protocols: Hikvision and Pelco D/P
2
Basic Smart Suite: Line Crossing, Intrusion
1.3 MP 1.3 MP1.3 MP 1.3 MP2 MP2 MP 2 MP2 MP 2 MP
VALUE SOLUTIONS
21
NETWORK VIDEO RECORDERS
PLUG-AND-PLAY
Model
DS-7604NI-E1/4P DS-7608NI-E2/8P DS-7608NI-I2/8P DS-7616NI-E2/16P DS-7616NI-I2/16P DS-7716NI-SP/16 DS-7716NI-I4/16P
Max. Recording Resolution 6 MP 6 MP 12 MP 6 MP 12 MP 6 MP 12 MP
Video Compression H.264, H.264+ H.264, H.264+ H.264, H.264+, H.265 H.264, H.264+ H.264, H.264+, H.265 H.264, H.264+ H.264, H.264+, H.265
HDMI/VGA Output
1920x1080/1920x1080,
synchronized output
1920x1080/1920x1080,
synchronized output
3840x2160/1920x1080,
1920x1080/1920x1080,
independent output
1920x1080/1920x1080,
synchronized output
3840x2160/1920x1080,
1920x1080/1920x1080,
independent output
1920x1080/1920x1080,
independent output
3840x2160/1920x1080,
1920x1080/1920x1080,
independent output
IP Video Input
4-ch IPC with integrated
4-port 802.3af/at PoE switch
8-ch IPC with integrated
8-port 802.3af/at PoE switch
8-ch IPC with integrated
8-port 802.3af/at PoE switch
16-ch IPC with integrated
16-port 802.3af/at PoE switch
16-ch IPC with integrated
16-port 802.3af/at PoE switch
16-ch IPC with integrated
16-port 802.3af/at PoE switch
16-ch IPC with integrated
16-port 802.3af/at PoE switch
Audio Input/Output 1 line in/1 line out 1 line in/1 line out 1 line in/1 line out 1 line in/1 line out 1 line in/1 line out 1 line in/1 line out 1 line in/1 line out
Alarm Input/Output 4 ch/1 ch 4 ch/1 ch 4 ch/1 ch 4 ch/1 ch 4 ch/1 ch 16 ch/4 ch 16 ch/4 ch
USB 1 USB 2.0; 1 USB 3.0 1 USB 2.0; 1 USB 3.0 1 USB 2.0; 1 USB 3.0 1 USB 2.0; 1 USB 3.0 1 USB 2.0; 1 USB 3.0 3 USB 2.0 3 USB 2.0
Internal SATA
1 SATA interface
(up to 6 TB each)
2 SATA interfaces
(up to 6 TB each)
2 SATA interfaces
(up to 6 TB each)
2 SATA interfaces
(up to 6 TB each)
2 SATA interfaces
(up to 6 TB each)
4 SATA interfaces
(up to 6 TB each)
4 SATA interfaces
(up to 6 TB each)
eSATA Interface --- --- --- --- --- Yes Yes
Max. Internal Storage 6 TB 12 TB 12 TB 12 TB 12 TB 24 TB 24 TB
Support DVD-RW --- --- --- --- --- Yes, replaces 2x SATA Yes, replaces 2x SATA
Max. Incoming Bandwidth (Mbps) 40 80 80 160 160 100 160
Maximum Outgoing Bandwidth (Mbps) 80 80 256 80 256 240 256
Max. Remote Connections 128 128 128 128 128 128 128
Rack Units 1 1 1 1 1 1.5 1.5
Ratings UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed
PoE Budget 50 W 120 W 180 W 200 W 280 W 200 W 300 W
Power Requirements 48VDC, ≤10W without HDD 100 to 240 VAC, ≤10W without HDD 100 to 240 VAC, ≤15W without HDD 100 to 240 VAC, ≤15W without HDD 100 to 240 VAC, ≤15W without HDD 100 to 240 VAC, ≤40 W without HDD 100 to 240 VAC, ≤20W without HDD
Standards: Complies with ONVIF (Prole S), CGI ASAPI. Contact factory for detais; Command Protocols: Hikvision and Pelco D/P
VALUE SOLUTIONS
22
NETWORK CAMERAS - VALUE SERIES
OUTDOOR WI-FI DOME WI-FI COMPACT DOME WI-FI CUBE INDOOR WI-FI PTeZ
TM
INDOOR PTZ
Model
DS-2CD2112F-IWS DS-2CD2132F-IWS DS-2CD2522FWD-IWS DS-2CD2542FWD-IWS DS-2CD2412F-IW DS-2CD2432F-IW DS-2DE2103-DE3/W DS-2DE2202I-DE3/W DS-2DF5220S-DE4/W
Image Sensor
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/2.8” progressive
scan CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
Min. Illumination (lux)
Color: 0.028 @ ƒ/2.0
B/W: 0 with IR
Color: 0.19 @ ƒ/2.0
B/W: 0 with IR
Color: 0.028 @ ƒ/2.0
B/W: 0 with IR
Color: 0.028 @ ƒ/2.0
B/W: 0 with IR
Color: 0.028 @ ƒ/2.0
B/W: 0 with IR
Color: 0.28 @ ƒ/2.0
B/W: 0 with IR
Color: 0.05 @ ƒ/1.6
B/W: 0.01 @ ƒ/1.6
Color: 0.1 @ ƒ/2.0
B/W: 0.01 @ ƒ/2.0
Color: 0.3 @ ƒ/1.6
B/W: 0.02 @ ƒ/1.6
Lens
Fixed, 4 mm @ ƒ/2.0
(2.8 mm, 6 mm option)
Fixed, 4 mm @ ƒ/2.0
(2.8 mm, 6 mm option)
Fixed, 4 mm @ ƒ/2.0
(6 mm option)
Fixed, 4 mm @ ƒ/2.0
(2.8 mm, 6 mm option)
Fixed, 4 mm @ ƒ/2.0
(2.8 mm option)
Fixed, 4 mm @ ƒ/2.0
(2.8 mm option)
3.6 to 11 mm,
3x (effective)
5
via PTeZ™
3.6 to 8.6 mm,
2x (effective)
5
via PTeZ™
4.7 to 94 mm,
motorized zoom,
autofocus, 20x
Horizontal Angle of
View
92.5° (2.8 mm),
73.1° (4 mm),
46° (6 mm)
98.5° (2.8 mm),
79° (4 mm) ,
49° (6 mm)
85° (4 mm),
52° (6 mm)
106° (2.8 mm),
83° (4 mm),
56° (6 mm)
92.5° (2.8 mm),
73.1° (4 mm)
86° (2.8 mm),
79° (4 mm)
80° to 33° 80° to 64.5° 58.3° to 3.2°
Pan/Tilt/Rotation
0° to 355°/
0° to 75°/ 0° to 355°
0° to 355°/
0° to 75°/ 0° to 355°
-30° to 30°/
0° to 75°/ 0° to 360°
-30° to 30°/
0° to 75°/ 0° to 360°
3-Axis Positioning 3-Axis Positioning
Pan: 0.1° to 50°/sec.
Tilt: 0.1° to 40°/sec.
0° to 350°/
0° to 90°/NA
360° endless/
-30° to 90°
(auto ip)/NA
Day/Night TRUE TRUE TRUE TRUE TRUE TRUE TRUE TRUE TRUE
BLC/WDR Yes/Digital Yes/Digital No/120 dB No/120 dB Yes/Digital Yes/Digital Yes/Digital Yes/Digital Yes/Digital
IR Range Max. (meters) 30 30 10 10 10 10 --- 20 ---
Video Compression H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG H.264/MJPEG
Maximum Image
Resolution (pixels)
1280x960 2048x1536 1920x1080 2688x1520 1280x960 2048x1536 1280x720 1920x1080 1920x1080
Frame Rate (fps)
30 @ 1280x960,
1280x720
20 @ 2048x1536,
30 @ 1920 x 1080,
1280x720
30 @ 1920x1080,
1280x960, 1280x720
20 @ 2688x1520
30 @ 1920x1080,
1280x720
30 @ 1280x960,
1280x720
20 @ 2048x1536
30 @ 1920x1080
30 @ 1280x720 30 @ 1920x1080
30 @ 1920x1080,
1280x960, 1280x720
Multi-Streaming Dual Dual Dual Dual Dual Dual Dual Dual Dual
Motion Detection Yes Yes Yes Yes Yes Yes Yes Yes Yes
Wireless IEEE 802.11b/g/n IEEE 802.11b/g/n IEEE 802.11b/g/n IEEE 802.11b/g/n IEEE 802.11b/g/n IEEE 802.11b/g/n IEEE 802.11b/g/n IEEE 802.11b/g/n IEEE 802.11b/g/n
Audio Input/Output
IN: 1 line
OUT: 1 line
IN: 1 line
OUT: 1 line
OUT: 1 line
Mic: Built in
OUT: 1 line
Mic: Built in
Built-in mic
and speaker
Built-in mic
and speaker
OUT: 1 line
Mic: Built in
OUT: 1 line
Mic: Built in
IN: 1 line
OUT: 1 line
Alarm Input/Output 1/1 1/1 1/1 1/1 1/1 1/1 1/1 1/1 1/1
Local Storage
MicroSD,
128 GB max.
MicroSD,
128 GB max.
MicroSD,
128 GB max.
MicroSD,
128 GB max.
MicroSD,
128 GB max.
MicroSD,
128 GB max.
MicroSD,
128 GB max.
MicroSD,
128 GB max.
MicroSD,
128 GB max.
Ratings
IP66, IK10, UL/cUL
Listed
IP66, IK10, UL/cUL
Listed
IP67, IK8, UL/cUL
Listed
IP67, IK8, UL/cUL
Listed
UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed
Operating Temperature
Range
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
0° C to 40° C
(-22° F to 104° F)
0° C to 40° C
(-22° F to 104° F)
-10° C to 50° C
(14° F to 122° F)
-10° C to 50° C
(14° F to 122° F)
-10° C to 50° C
(14° F to 122° F)
Power Requirements
(max.)
12 VDC,
PoE (802.3af), 5 W,
PSU included
12 VDC,
PoE (802.3af), 5 W,
PSU included
12 VDC,
PoE (802.3af), 5 W,
PSU included
12 VDC,
PoE (802.3af), 5 W,
PSU included
12 VDC,
PoE (802.3af), 5 W,
PSU included
12 VDC,
PoE (802.3af), 5 W,
PSU included
12 VDC,
PoE (802.3af), 5.5 W,
PSU included
12 VDC,
PoE (802.3af), 9 W,
PSU included
12 VDC,
PoE+ (802.3at), 24 W
Standards: Complies with ONVIF (Prole S and G), CGI ASAPI. Contact factory for details.
5
PTeZ™ cameras have a sensor-based zoom
NETWORK VIDEO RECORDERS
WI-FI NVR
Model
DS-7104NI-SL/W
DS-7108NI-E1/V/W/1T
(with 1 TB HDD)
Video Compression H.264 H.264
HDMI/VGA Output
1920x1080/
1920x1080
1920x1080 /-
IP Video Input 4-ch 8-ch
Network Interface 1 LAN 1 WAN, 3 LAN
Wireless IEEE 802.11b/g/n IEEE 802.11b/g/n
Audio Input/Output 1 / 1 -/ 1 (HDMI)
USB 2 USB 2.0 1 USB 3.0
Internal SATA 1 (up to 4 TB) 1 (1 TB HDD included)
Max. Incoming
Bandwidth (Mbps)
25 Mbps 50 Mbps
Maximum Outgoing
Bandwidth (Mbps)
40 Mbps 80 Mbps
Max. Remote
Connections
128 128
Ratings UL/cUL Listed UL/cUL Listed
Power Requirements
12 VDC,
PSU included
12 VDC,
PSU included
Max. Total Power w/
full HDD load
16 W 12 W
Standards: Complies with ONVIF (Prole S), PSIA, CGI ASAPI. Contact factory
for details; Command Protocols: Hikvision and Pelco D/P protocols
1.3 MP1.3 MP 1 MP 2 MP2 MP2 MP 3 MP3 MP 4 MP
WI-FI SOLUTIONS
23
TurboHD™ 3.0 ANALOG CAMERAS - 2 MP AND 3 MP
OUTDOOR DOME OUTDOOR BULLET OUTDOOR TURRET OUTDOOR BULLET OUTDOOR TURRET OUTDOOR BULLET OUTDOOR TURRET
Model
DS-2CE56D7T-VPIT DS-2CE16D7T-IT DS-2CE56D7T-ITM DS-2CE16D7T-IT5 DS-2CE56D7T-IT3 DS-2CE16D7T–AIT3Z DS-2CE56D7T-IT3Z
Video Out HD-TVI HD-TVI HD-TVI HD-TVI HD-TVI HD-TVI HD-TVI
Image Sensor
1/2.7" progressive scan
CMOS
1/2.7" progressive scan
CMOS
1/2.7" progressive scan
CMOS
1/2.7" progressive scan
CMOS
1/2.7" progressive scan
CMOS
1/2.7" progressive scan
CMOS
1/2.7" progressive scan
CMOS
HD-TVI Resolution 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080
CVBS Resolution --- --- --- --- --- --- ---
Min. Illumination (lux)
Color: 0.034 @ ƒ/2.0
B/W: 0 with IR
Color: 0.034 @ ƒ/2.0
B/W: 0 with IR
Color: 0.034 @ ƒ/2.0
B/W: 0 with IR
Color: 0.034 @ ƒ/2.0
B/W: 0 with IR
Color: 0.034 @ ƒ/2.0
B/W: 0 with IR
Color: 0.03 @ ƒ/1.4
B/W: 0 with IR
Color: 0.03 @ ƒ/1.4
B/W: 0 with IR
Lens
Fixed, 3.6 mm @ ƒ/2.5
(6 mm option)
Fixed, 3.6 mm @ ƒ/2.5
(2.8 mm, 6 mm option)
Fixed, 3.6 mm @ ƒ/2.5
(2.8 mm option)
Fixed, 3.6 mm @ ƒ/2.5
(6 mm, 12mm option)
Fixed, 2.8mm @ ƒ/2.5
(3.6mm, 6mm option)
2.8 -12mm,
motorized lens
2.8 -12mm,
motorized lens
Horizontal Angle of View 82.2° (3.6mm), 54° (6mm)
103° (2.8mm),
82.2° (3.6mm), 54° (6mm)
103° (2.8mm),
82.2° (3.6mm)
82.2°(3.6mm),
54°(6mm), 24.3°(12mm)
103° (2.8mm),
82.2° (3.6mm), 54° (6mm)
35.1° to 114.5° 35.1° to 114.5°
Pan/Tilt/Rotation
0° to 340°/
0° to 75°/0° to 355°
3-Axis Positioning
0° to 360°/
0° to 75°/0° to 360°
3-Axis Positioning
0° to 360°/
0° to 75°/0° to 360°
0° to 360°/
0° to 90°/0° to 360°
0° to 360°/
0° to 75°/0° to 360°
Day/Night TRUE TRUE TRUE TRUE TRUE TRUE TRUE
BLC/WDR Yes/120 dB Yes/120 dB Yes/120 dB Yes/120 dB Yes/120 dB Yes/120 dB Yes/120 dB
IR Range Max. (meters) 20 20 20 80 40 40 40
Vertical Synchronization Internal Internal Internal Internal Internal Internal Internal
OSD Menu via Up-the-Coax
(UTC)
Yes Yes Yes Yes Yes Yes Yes
Ratings IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed
Operating Temperature
Range
-40° C to 60° C
(-40 ° F to 140° F)
-40° C to 60° C
(-40 ° F to 140° F)
-40° C to 60° C
(-40 ° F to 140° F)
-40° C to 60° C
(-40 ° F to 140° F)
-40° C to 60° C
(-40 ° F to 140° F)
-40° C to 60° C
(-40 ° F to 140° F)
-40° C to 60° C
(-40 ° F to 140° F)
Power Requirements (max.) 12 VDC, 5 W 12 VDC, 5 W 12 VDC, 5 W 12 VDC, 5 W 12 VDC, 5 W
12 VDC, 6 W
24 VAC, 9 W
12 VDC, 6 W
2 MP 2 MP 2 MP 2 MP 2 MP 2 MP 2 MP
TurboHD™ | ANALOG MIGRATION SOLUTIONS
24
TurboHD Cameras Accessories: Video Balun DS-1H18. See page 33 for details.
OVERVIEW
Enjoy HD with existing
cabling
Based on HD-TVI technology, Hikvision’s TurboHD™
products provide high denition (HD) video over
coaxial cable at distances of up to 1500 feet. Specially
designed for analog users who want a high-denition
surveillance system, this line allows users to enjoy
HD without upgrading to IP or even replacing their
existing cabling structures. Providing impressive
image quality, the camera line offers incredibly
durable, vandal proof products with features such as
OSD menu via Up-the-Coax (UTC), EXIR illumination,
motorized zoom and focus, and 120 dB WDR.
The TurboHD™ Plug and Play DVR products offer
several models scaled for small to medium businesses
with 4 to 32 channels. All TurboHD DVRs are tribrid—a
true revolution in the professional surveillance
market—supporting traditional analog (CVBS), HD-TVI,
and IP cameras. Thanks to autosensing technology,
installation is a breeze. These DVR products also
provide H.264 and Hikvision’s unique H.264+ video
compression, and up to 48TB of recording space.
EXIR EXIR EXIR EXIR EXIR EXIR EXIR
TurboHD™ 3.0 ANALOG CAMERAS - 2 MP AND 3 MP
INDOOR DOME OUTDOOR DOME OUTDOOR BULLET OUTDOOR TURRET OUTDOOR BULLET OUTDOOR TURRET OUTDOOR BULLET OUTDOOR TURRET INDOOR DOME OUTDOOR DOME
Model
DS-2CE56D7T-AITZ DS-2CE56D7T–AVPIT3Z DS-2CE56F7T-VPIT DS-2CE16F7T-IT DS-2CE56F7T-ITM DS-2CE16F7T-IT5 DS-2CE56F7T-IT3 DS-2CE16F7T–AIT3Z DS-2CE56F7T-IT3Z DS-2CE56F7T-AITZ DS-2CE56F7T–AVPIT3Z
Video Out HD-TVI HD-TVI HD-TVI HD-TVI HD-TVI HD-TVI HD-TVI HD-TVI HD-TVI HD-TVI HD-TVI
Image Sensor
1/2.7" progressive scan
CMOS
1/2.7" progressive scan
CMOS
1/3" progressive scan
CMOS
1/3" progressive scan
CMOS
1/3" progressive scan
CMOS
1/3" progressive scan
CMOS
1/3" progressive scan
CMOS
1/3" progressive scan
CMOS
1/3" progressive scan
CMOS
1/3" progressive scan
CMOS
1/3" progressive scan
CMOS
HD-TVI Resolution 1920x1080 1920x1080 1920x1536 1920x1536 1920x1536 1920x1536 1920x1536 1920x1536 1920x1536 1920x1536 1920x1536
CVBS Resolution --- --- --- --- --- --- --- --- --- --- ---
Min. Illumination (lux)
Color: 0.03 @ ƒ/1.4
B/W: 0 with IR
Color: 0.03 @ ƒ/1.4
B/W: 0 with IR
Color: 0.045 @ ƒ/2.0
B/W: 0 with IR
Color: 0.045 @ ƒ/2.0
B/W: 0 with IR
Color: 0.045 @ ƒ/2.0
B/W: 0 with IR
Color: 0.045 @ ƒ/2.0
B/W: 0 with IR
Color: 0.045 @ ƒ/2.0
B/W: 0 with IR
Color: 0.038 @ ƒ/1.4
B/W: 0 with IR
Color: 0.038 @ ƒ/1.4
B/W: 0 with IR
Color: 0.038 @ ƒ/1.4
B/W: 0 with IR
Color: 0.038 @ ƒ/1.4
B/W: 0 with IR
Lens
2.8 -12 mm,
motorized lens
2.8 -12 mm,
motorized lens
Fixed, 3.6 mm @ ƒ/2.5
(2.8 mm, 6 mm option)
Fixed, 3.6 mm @ ƒ/2.5
(2.8 mm, 6 mm option)
Fixed, 3.6 mm @ ƒ/2.5
(2.8 mm option)
Fixed, 3.6 mm @ ƒ/2.5 (6
mm option)
Fixed, 3.6 mm @ ƒ/2.5
(2.8 mm, 6 mm option)
2.8 -12mm,
motorized lens
2.8 -12mm,
motorized lens
2.8 -12mm,
motorized lens
2.8 -12mm,
motorized lens
Horizontal Angle of View 35.1° to 114.5° 35.1° to 114.5°
84° (2.8 mm),
67.8° (3.6 mm),
44.6 (6 mm)
84° (2.8 mm),
67.8° (3.6 mm),
44.6 (6 mm)
84° (2.8 mm),
67.8° (3.6 mm)
67.8° (3.6 mm),
44.6 (6 mm)
84° (2.8 mm),
67.8° (3.6 mm),
44.6 (6 mm)
26.8° to 83° 26.8° to 83° 26.8° to 83° 26.8° to 83°
Pan/Tilt/Rotation
0° to 355°/
0° to 75°/0° to 355°
0° to 340°/
0° to 75°/0° to 355°
0° to 340°/
0° to 75°/0° to 355°
3-Axis Positioning
0° to 360°/
0° to 75°/0° to 360°
3-Axis Positioning
0° to 360°/
0° to 75°/0° to 360°
3-Axis Positioning
0° to 360°/
0° to 75°/0° to 360°
0° to 355°/
0° to 75°/0° to 355°
0° to 355°/
0° to 75°/0° to 355°
Day/Night TRUE TRUE TRUE TRUE TRUE TRUE TRUE TRUE TRUE TRUE TRUE
BLC/WDR Yes/120 dB Yes/120 dB Yes/120 dB Yes/120 dB Yes/120 dB Yes/120 dB Yes/120 dB Yes/120 dB Yes/120 dB Yes/120 dB Yes/120 dB
IR Range Max. (meters) 30 40 20 20 20 80 40 40 40 30 40
Vertical Synchronization Internal Internal Internal Internal Internal Internal Internal Internal Internal Internal Internal
OSD Menu via Up-the-
Coax (UTC)
Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Ratings UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed UL/cUL Listed IP66, UL/cUL Listed
Operating Temperature
Range
-40° C to 60° C
(-40 ° F to 140° F)
-40° C to 60° C
(-40 ° F to 140° F)
-40° C to 60° C
(-40 ° F to 140° F)
-40° C to 60° C
(-40 ° F to 140° F)
-40° C to 60° C
(-40 ° F to 140° F)
-40° C to 60° C
(-40 ° F to 140° F)
-40° C to 60° C
(-40 ° F to 140° F)
-40° C to 60° C
(-40 ° F to 140° F)
-40° C to 60° C
(-40 ° F to 140° F)
-40° C to 60° C
(-40 ° F to 140° F)
-40° C to 60° C
(-40 ° F to 140° F)
Power Requirements
(max.)
12 VDC, 4.5 W
24 VAC, 6.5 W
12 VDC, 4.5 W
24 VAC, 6.5 W
12 VDC, 5 W 12 VDC, 5 W 12 VDC, 5 W 12 VDC, 5 W 12 VDC, 5 W
12 VDC, 6W
24 VAC, 9W
12 VDC, 6W
12 VDC, 4.5W
24 VAC, 6.5W
12 VDC, 4.5W
24 VAC, 6.5W
2 MP 2 MP 3 MP 3 MP 3 MP 3 MP 3 MP 3 MP 3 MP 3 MP 3 MP
TurboHD™ | ANALOG MIGRATION SOLUTIONS
25
TurboHD Cameras Accessories: Video Balun DS-1H18. See page 33 for details.
EXIR EXIR EXIR EXIR EXIR EXIR EXIR EXIR EXIR EXIR EXIR
TurboHD™ ANALOG CAMERAS - 720p AND 1080p
INDOOR BOX INDOOR DOME OUTDOOR DOME
Model
DS-2CC12D9T-A DS-2CE56C5T-AVFIR DS-2CE56D5T-AVFIR* DS-2CE56D5T-AIRZ DS-2CE56D1T-AVFIR* DS-2CE56D1T-VPIR* DS-2CE56C5T-AVPIR3 DS-2CE56D1T-AVPIR3* DS-2CE56D5T-AVPIR3* DS-2CE56D5T-AVPIR3ZH
Video Out
HD-TVI/CVBS
(Dual)
HD-TVI/CVBS
(selectable)
HD-TVI/CVBS
(Dual)
HD-TVI/CVBS
(Dual)
HD-TVI HD-TVI
HD-TVI/CVBS
(selectable)
HD-TVI
HD-TVI/CVBS
(Dual)
HD-TVI/CVBS
(Dual)
Image Sensor
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/2.7” progressive scan
CMOS
1/2.7” progressive scan
CMOS
1/3” progressive scan
CMOS (only 2.8 mm)
1/3” progressive scan
CMOS
1/2.7” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
HD-TVI Resolution 1920x1080 1280x720 1920x1080 1920x1080 1920x1080 1920x1080 1280x720 1920x1080 1920x1080 1920x1080
CVBS Resolution 600TVL 720TVL 600TVL 600TVL --- --- 720TVL --- 600TVL 600TVL
Min. Illumination (lux)
Color: 0.1 @ ƒ/1.2
B/W: 0.0001 @ ƒ/1.2
Color: 0.0014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.0014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.0014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.034 @ ƒ/2.5
B/W: 0 with IR
Color: 0.0014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.14 @ ƒ/1.4, B/W:
0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Lens C/CS mount
2.8 to 12 mm @ ƒ/1.4,
manual
2.8 to 12 mm @ ƒ/1.4,
manual
2.8 to 12 mm @ ƒ/1.4,
motorized
2.8 to 12 mm @ ƒ/1.4,
manual
Fixed, 3.6 mm @ ƒ/2.5
(2.8 mm, 6 mm option)
2.8 to 12 mm @ ƒ/1.4,
manual
2.8 to 12 mm @ ƒ/1.4,
manual
2.8 to 12 mm @ ƒ/1.4,
manual
2.8 to 12 mm @ ƒ/1.4,
motorized
Horizontal Angle of View Dependent on lens 78° to 28° 92° to 32° 103° to 32.1° 105.2° to 32.8°
90° (2.8 mm),
80° (3.6 mm),
55.4° (6 mm)
78° to 28° 105.2° to 32.8° 92° to 32° 103° to 32.1°
Pan/Tilt/Rotation ---
0° to 355°/
0° to 75°/0° to 355°
0° to 355°/
0° to 75°/0° to 355°
0° to 355°/
0° to 75°/0° to 355°
0° to 355°/
0° to 75°/0° to 355°
0° to 355°/
0° to 75°/0° to 355°
0° to 355°/
0° to 75°/0° to 355°
0° to 355°/
0° to 75°/0° to 355°
0° to 355°/
0° to 75°/0° to 355°
0° to 355°/
0° to 75°/0° to 355°
Day/Night TRUE TRUE TRUE TRUE TRUE TRUE TRUE TRUE TRUE TRUE
BLC/WDR Yes/120 dB No/Digital Yes/120 dB Yes/120 dB Yes/No Yes/No No/Digital Yes/No Yes/120 dB Yes/120 dB
IR Range Max. (meters) --- 30 30 30 30 20 40 40 40 40
Vertical Synchronization Internal Internal Internal Internal Internal Internal Internal Internal Internal Internal
OSD Menu via Up-the-Coax
(UTC)
Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Ratings UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed IP66, IK10, UL/cUL Listed IP66, IK10, UL/cUL Listed IP66, IK10, UL/cUL Listed IP66, IK10, UL/cUL Listed IP66, IK10, UL/cUL Listed
Operating Temperature Range
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-20° C to 45° C
(-4° F to -113° F)
-20° C to 45° C
(-4° F to 113° F)
-40° C to 60° C
(-40 ° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-40° C to 60° C
(-40 ° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-40° C to 60° C
(-40 ° F to 140° F)
Power Requirements (max.)
12 VDC,
24 VAC, 4.5 W
12 VDC, 3.5 W
24 VAC, 5 W
12 VDC, 4.5 W
24 VAC, 6.5 W
12 VDC, 6 W
24 VAC, 6 W
12 VDC, 3 W 12 VDC, 3 W
12 VDC, 3.5 W
24 VAC, 5 W
12 VDC, 24 VAC, 4 W
12 VDC, 4.5 W
24 VAC, 6.5 W
12 VDC, 9 W
24 VAC, 9 W
1080p1080p 720p 720p 1080p
*Lens NOT included
TurboHD™ | ANALOG MIGRATION SOLUTIONS
TurboHD Cameras Accessories: Video Balun DS-1H18. See page 33 for details.
26
1080p
1080p
1080p 1080p 1080p
*Black model available
DS-2CE56D5T-AVFIRB
*Black model available
DS-2CE56D1T-AVFIRB
*Black model available
DS-2CE56D1T-VPIRB
*Black model available
DS-2CE56D1T-AVPIR3B
*Black model available
DS-2CE56D5T-AVPIR3B
TurboHD™ ANALOG CAMERAS - 720p AND 1080p
OUTDOOR TURRET
Model
DS-2CE56C2T-IRM DS-2CE56D1T-IRM* DS-2CE56D1T-IT1 DS-2CE56C5T-IT1 DS-2CE56D5T-IT3* DS-2CE56C5T-VFIT3 DS-2CE56D5T-VFIT3 DS-2CE56D5T-IR3Z
Video Out HD-TVI HD-TVI HD-TVI
HD-TVI/CVBS
(selectable)
HDTVI/CVBS
(Dual)
HD-TVI/CVBS
(selectable)
HD-TVI/CVBS
(Dual)
HD-TVI/CVBS
(Dual)
Image Sensor
1/3” progressive scan
CMOS
1/2.7” progressive scan
CMOS
1/2.7” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
HD-TVI Resolution 1280x720 1920x1080 1920x1080 1280x720 1920x1080 1280x720 1920x1080 1920x1080
CVBS Resolution --- --- --- 720TVL 600TVL 720TVL 600TVL 600TVL
Min. Illumination (lux)
Color: 0.043 @ ƒ/2.5
B/W: 0 with IR
Color: 0.034 @ ƒ/2.5
B/W: 0 with IR
Color: 0.034 @ ƒ/2.5
B/W: 0 with IR
Color: 0.043 @ ƒ/2.5
B/W: 0 with IR
Color: 0.043 @ ƒ/2.5
B/W: 0 with IR
Color: 0.0014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Lens
Fixed, 3.6 mm @ ƒ/2.5
(2.8 mm, 6 mm option)
Fixed, 3.6 mm @ ƒ/2.5
(2.8 mm, 6 mm option)
Fixed, 3.6 mm @ ƒ/2.5
(2.8 mm, 6 mm option)
Fixed, 3.6 mm @ ƒ/2.5
(2.8 mm, 6 mm, 8 mm option)
Fixed, 3.6 mm @ ƒ/2.5
(2.8 mm, 6 mm, 12 mm, option)
2.8 to 12 mm @ ƒ/1.4, manual 2.8 to 12 mm @ ƒ/1.4, manual
2.8 to 12 mm @ ƒ/1.4,
motorized
Horizontal Angle of View
76.88° (3.6 mm),
99.73° (2.8 mm), 50.1° (6 mm)
105° (2.8 mm),
84.3° (3.6 mm), 55.4° (6 mm)
105° (2.8 mm),
84.3° (3.6 mm), 55.4° (6 mm)
71.43° (3.6 mm), 92.45° (2.8 mm),
46.9° (6 mm), 34.5° (8 mm)
80° (3.6 mm), 103.5° (2.8 mm),
54.3° (6 mm), 24.3° (12 mm)
78° to 28° 92° to 32° 103° to 32.1°
Pan/Tilt/Rotation
0° to 355°/
0° to 75°/ 0° to 355°
0° to 355°/
0° to 75°/ 0° to 355°
0° to 355°/
0° to 75°/ 0° to 355°
0° to 355°/
0° to 75°/ 0° to 355°
0° to 355°/
0° to 75°/ 0° to 355°
0° to 355°/
0° to 75°/ 0° to 355°
0° to 355°/
0° to 75°/ 0° to 355°
0° to 355°/
0° to 75°/ 0° to 355°
Day/Night TRUE TRUE TRUE TRUE TRUE TRUE TRUE TRUE
BLC/WDR No/No Yes/No Yes/No No/Digital Yes/120 dB No/Digital Yes/120 dB Yes/120 dB
IR Range Max. (meters) 20 20 20 20 40 50 50 40
Vertical Synchronization Internal Internal Internal Internal Internal Internal Internal Internal
OSD Menu via Up-the-Coax (UTC) No Yes Yes Yes Yes Yes Yes Yes
Ratings IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed
Operating Temperature Range
-40° C to 60° C
(-40 ° F to 140° F)
-40° C to 60° C
(-40 ° F to 140° F)
-40° C to 60° C
(-40 ° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
Power Requirements (max.) 12 VDC, 3.5 W 12 VDC, 3 W 12 VDC, 3 W 12 VDC, 3 W 12 VDC, 5 W 12 VDC, 6 W 12 VDC, 7 W 12 VDC, 6 W
720p 720p 1080p720p 1080p
TurboHD Cameras Accessories: Video Balun DS-1H18. See page 33 for details.
TurboHD™ | ANALOG MIGRATION SOLUTIONS
27
EXIREXIR
EXIR
EXIR EXIR
1080p 1080p 1080p
*Black model available
DS-2CE56D1T-IRMB
*Black model available
DS-2CE56D5T-IT3B
TurboHD™ ANALOG CAMERAS - 720p AND 1080p
OUTDOOR BULLET
Model
DS-2CE16C2T-IR DS-2CE16D1T-IR DS-2CE16D1T-IT1 DS-2CE16C5T-IT1 DS-2CE16D5T-IT3 DS-2CE16C5T-VFIR3 DS-2CE16D1T-AVFIR3 DS-2CE16D5T-AVFIT3 DS-2CE16D5T-AIR3ZH DS-2CE16D9T-AIRAZH
Video Out HD-TVI HD-TVI HD-TVI
HD-TVI/CVBS
(selectable)
HD-TVI/CVBS
(Dual)
HD-TVI/CVBS
(selectable)
HD-TVI
HD-TVI/CVBS
(Dual)
HD-TVI/CVBS
(Dual)
HD-TVI/CVBS
(Dual)
Image Sensor
1/3” progressive scan
CMOS
1/2.7” progressive scan
CMOS
1/3” progressive scan
CMOS (only 2.8 mm)
1/2.7” progressive scan
CMOS
1/3” progressive scan
CMOS (only 2.8 mm)
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/2.7” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
HD-TVI Resolution 1280x720 1920x1080 1920x1080 1280x720 1920x1080 1280x720 1920x1080 1920x1080 1920x1080 1920x1080
CVBS Resolution --- --- --- 720TVL 600TVL 720TVL --- 600TVL 600TVL 600TVL
Min. Illumination (lux)
Color: 0.043 @ ƒ/2.5
B/W: 0 with IR
Color: 0.034 @ ƒ/2.5
B/W: 0 with IR
Color: 0.034 @ ƒ/2.5
B/W: 0 with IR
Color: 0.043 @ ƒ/2.5
B/W: 0 with IR
Color: 0.043 @ ƒ/2.5
B/W: 0 with IR
Color: 0.0014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.14 @ ƒ/1.4
0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.014 @ ƒ/1.4
B/W: 0 with IR
Color: 0.028 @ ƒ/2.0
B/W: 0 with IR
Lens
Fixed, 3.6 mm @ ƒ/2.5
(2.8 mm, 6 mm option)
Fixed, 3.6 mm @ ƒ/2.5
(2.8 mm, 6 mm option)
Fixed, 3.6 mm @ ƒ/2.5
(2.8 mm, 6 mm option)
Fixed, 3.6 mm @ ƒ/2.5
(2.8 mm, 6 mm,
8 mm option)
Fixed, 3.6 mm @ ƒ/2.5
(2.8 mm, 6 mm,
12 mm option)
2.8 to 12 mm @ ƒ/1.4,
manual
2.8 to 12 mm @ ƒ/1.4,
manual
2.8 to 12 mm @ ƒ/1.4,
manual
2.8 to 12 mm @ ƒ/1.4,
motorized
5 to 50 mm @ ƒ/2.0
motorized
Horizontal Angle of View
76.88° (3.6 mm),
99.73°, (2.8 mm),
50.1° (6 mm)
90° (2.8 mm),
80° (3.6 mm),
55.4° (6 mm)
90° (2.8 mm),
80° (3.6 mm),
55.4° (6 mm)
71.43° (3.6 mm),
92.45° (2.8 mm),
46.9° (6 mm),
34.5° (8 mm)
80° (3.6 mm),
103.5° (2.8 mm),
54.3° (6 mm),
24.3° (12 mm)
78° to 28° 102° to 35° 92° to 32° 103° to 32.1° 59.8° to 6.2°
Pan/Tilt/Rotation 3-Axis Positioning 3-Axis Positioning 3-Axis Positioning 3-Axis Positioning 3-Axis Positioning 3-Axis Positioning 3-Axis Positioning 3-Axis Positioning 3-Axis Positioning 3-Axis Positioning
Day/Night TRUE TRUE TRUE TRUE TRUE TRUE TRUE TRUE TRUE TRUE
BLC/WDR No/No Yes/No Yes/No No/Digital Yes/120 dB No/Digital Yes/No Yes/120 dB Yes/120 dB Yes/120 dB
IR Range Max. (meters) 20 20 20 20 40 40 40 50 40 100
Vertical Synchronization Internal Internal Internal Internal Internal Internal Internal Internal Internal Internal
OSD Menu
via Up-the-Coax (UTC)
No Yes Yes Yes Yes Yes Yes Yes Yes Yes
Ratings IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed
Operating Temperature
Range
-40° C to 60° C
(-40 ° F to 140° F)
-40° C to 60° C
(-40 ° F to 140° F)
-40° C to 60° C
(-40 ° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-40° C to 60° C
(-40 ° F to 140° F)
-30° C to 60° C
(-22° F to 140° F)
-40° C to 60° C
(-40 ° F to 140° F)
-40° C to 60° C
(-40 ° F to 140° F)
Power Requirements
(max.)
12 VDC, 3.5 W 12 VDC, 3 W 12 VDC, 3 W 12 VDC, 3 W 12 VDC, 5 W 12 VDC, 4 W 12 VDC, 24 VAC, 6 W
12 VDC, 7 W
24 VAC, 10 W
12 VDC, 12 W
24 VAC, 12 W
12 VDC, 20 W
24 VAC, 20 W
1080p 1080p 1080p 1080p 1080p1080p 720p 720p720p 1080p
TurboHD™ | ANALOG MIGRATION SOLUTIONS
TurboHD Cameras Accessories: Video Balun DS-1H18. See page 33 for details.
28
EXIREXIR EXIR EXIR
TurboHD™ ANALOG PTZ CAMERAS - 720p AND 1080p
INDOOR OUTDOOR INDOOR OUTDOOR OUTDOOR IR
Model
DS-2AE4223T-A3 DS-2AE4223T-A DS-2AE5230T-A3 DS-2AE5123T-A DS-2AE5230T-A DS-2AE5123TI-A DS-2AE7230TI-A
Video Out
HD-TVI/CVBS,
UTC menu
HD-TVI/CVBS,
UTC menu
HD-TVI/CVBS,
UTC menu
HD-TVI/CVBS,
UTC menu
HD-TVI/CVBS,
UTC menu
HD-TVI/CVBS,
UTC menu
HD-TVI/CVBS,
UTC menu
Image Sensor
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
1/3” progressive scan
CMOS
Min. Illumination (lux)
Color: 0.05 @ ƒ/1.6
B/W: 0.01 @ ƒ/1.6
Color: 0.05 @ ƒ/1.6
B/W: 0.01 @ ƒ/1.6
Color: 0.02 @ ƒ/1.6
B/W: 0.002 @ ƒ/1.6
Color: 0.02 @ ƒ/1.6
B/W: 0.002 @ ƒ/1.6
Color: 0.02 @ ƒ/1.6
B/W: 0.002 @ ƒ/1.6
Color: 0.05 @ ƒ/1.4
B/W: 0.005 @ ƒ/1.4, 0 with IR
Color: 0.02 @ ƒ/1.6
B/W: 0.002 @ ƒ/1.6, 0 with IR
HD-TVI Resolution 1920x1080 1920x1080 1920x1080 1280x720 1920x1080 1280x720 1920x1080
CVBS Resolution 600TVL 600TVL 600TVL 600TVL 600TVL 600TVL 600TVL
Lens
4 to 92 mm, motorized zoom,
autofocus
4 to 92 mm, motorized zoom,
autofocus
4 to 120 mm, motorized zoom,
autofocus
4 to 92 mm, motorized zoom,
autofocus
4 to 120 mm, motorized zoom,
autofocus
4 to 92 mm, motorized zoom,
autofocus
4 to 120 mm, motorized zoom,
autofocus
Horizontal Angle of View 49° to 2.2° 49° to 2.2° 58° to 1.7° 49° to 2.2° 58° to 1.7° 49° to 2.2° 58° to 1.7°
Optical Zoom 23x 23x 30x 23x 30x 23x 30x
Pan Range 360° endless 360° endless 360° endless 360° endless 360° endless 360° endless 360° endless
Tilt Range -5° to 90° (auto ip) -5° to 90° (auto ip) -5° to 90° (auto ip) -15° to 90° (auto ip) -5° to 90° (auto ip) -15° to 90° (auto ip) -15° to 90° (auto ip)
Pan & Tilt Speed (Manual)
Pan: 0.1° to 160°/sec.
Tilt: 0.1° to 120°/sec.
Pan: 0.1° to 160°/sec.
Tilt: 0.1° to 120°/sec.
Pan: 0.1° to 250°/sec.
Tilt: 0.1° to 150°/sec.
Pan: 0.1° to 250°/sec.
Tilt: 0.1° to 150°/sec.
Pan: 0.1° to 250°/sec.
Tilt: 0.1° to 150°/sec.
Pan: 0.1° to 400°/sec.
Tilt: 0.1° to 120°/sec.
Pan: 0.1° to 160°/sec.
Tilt: 0.1° to 120°/sec.
Pan & Tilt Speed (Preset)
Pan: 160°/sec.
Tilt: 120°/sec.
Pan: 160°/sec.
Tilt: 120°/sec.
Pan: 300°/sec.
Tilt: 200°/sec.
Pan: 300°/sec.
Tilt: 200°/sec.
Pan: 300°/sec.
Tilt: 200°/sec.
Pan: 400°/sec.
Tilt: 200°/sec.
Pan: 240°/sec.
Tilt: 200°/sec.
Day/Night TRUE TRUE TRUE TRUE TRUE TRUE TRUE
BLC/WDR Yes/Digital Yes/Digital Yes/Digital Yes/Digital Yes/Digital Yes/Digital No/Digital
IR Range Max. (meters) --- --- --- --- --- 150 120
Presets/Tours/Patterns 256/8/4 256/8/4 256/8/4 256/8/4 256/8/4 256/8/4 256/8/4
Up-the Coax Control Hikvision-C Hikvision-C Hikvision-C Hikvision-C Hikvision-C Hikvision-C Hikvision-C
RS485 Control Hikvision, Pelco D/P Hikvision, Pelco D/P Hikvision, Pelco D/P Hikvision, Pelco D/P Hikvision, Pelco D/P Hikvision, Pelco D/P Hikvision, Pelco D/P
Ratings UL/cUL Listed IP66, UL/cUL Listed UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed IP66, UL/cUL Listed
Operating Temperature Range
-10° C to 50° C
(14° F to 122° F)
-30° C to 65° C
(-22° F to 149° F)
-10° C to 50° C
(14° F to 122° F)
-30° C to 65° C
(-22° F to 149° F)
-30° C to 65° C
(-22° F to 149° F)
-30° C to 65° C
(-22° F to 149° F)
-30° C to 65° C
(-22° F to 149° F)
Power Requirements (max.) 24 VAC, 12 W
24 VAC, 18 W/12 W
(heater on/off)
24 VAC, 12 W
24 VAC, 20 W/12 W
(heater on/off)
24 VAC, 20 W/12 W
(heater on/off)
24 VAC, 20 W/12 W
(heater on/off)
24 VAC, 40 W
1080p 1080p1080p 1080p 1080p 720p720p
TurboHD Cameras Accessories: Video Balun DS-1H18. See page 33 for details.
TurboHD™ | ANALOG MIGRATION SOLUTIONS
29
TRIBRID DIGITAL VIDEO RECORDERS
TurboHD™ TRIBRID DVR - VALUE SERIES TurboHD™ 3.0 TRIBRID DVR - VALUE SERIES
Model
DS-7204HGHI-SH DS-7208HGHI-SH DS-7216HGHI-SH DS-7204HUHI-F1/N DS-7208HUHI-F2/N
Max. Recording Resolution 1080p 1080p 1080p 3MP 3MP
Video Compression H.264 H.264 H.264 H.264+ H.264+
HDMI/VGA Output
1920x1080/1920x1080,
syncronous output
1920x1080/1920x1080,
syncronous output
1920x1080/1920x1080,
syncronous output
1920x1080/1920x1080,
syncronous output
1920 × 1080, VGA 3840 × 2160, HDMI,
synchronous output
Spot Monitor Output (BNC) --- --- --- Yes Yes
Analog Input 4-Ch 1.0 Vp-p, 75 Ω 8-Ch 1.0 Vp-p 75 Ω 16-Ch 1.0 Vp-p 75 Ω 4-Ch 1.0 Vp-p, 75 Ω 8-Ch 1.0 Vp-p, 75 Ω
Video Standard HD-TVI/CVBS (auto-detect) HD-TVI/CVBS (auto-detect) HD-TVI/CVBS (auto-detect) HD-TVI/CVBS (auto-detect) HD-TVI/CVBS (auto-detect)
Audio Input/Output 1-ch/1-ch 1-ch/1-ch 1-ch/1-ch 4-ch/1-ch 4-ch/1-ch
Alarm Input/Output 4 /1 8/4 16/4 4 /1 8/4
USB 2.0 2 2 2 2
Front panel: 1 × USB 2.0,
Rear panel: 1 × USB 3.0
RAID Support ---- ---- ---- ---- ----
Internal SATA 1 (up to 6 TB each) 2 (up to 6 TB each) 2 (up to 6 TB each) 1 (up to 6 TB each) 2 (up to 6 TB each)
Max. Internal Storage 6 TB 12 TB 12 TB 6 TB 12 TB
Support DVD-RW --- --- --- --- ---
Max. fps 720p/1080p/3 MP HD-TVI 30/12 30/12 30/12 30/30/15 30/30/15
Max. Analog (CVBS) Resolution WD1 (960H) WD1 (960H) WD1 (960H) WD1 (960H) WD1 (960H)
Disable Turbo/CVBS Channel/Add IPC --- --- --- Yes Yes
Hikvision IP Camera Support 1 up to 1080p 2 up to 1080p 2 up to 1080p 2 up to 4MP 2 up to 4MP
Front Panel Control --- --- --- Yes Yes
OSD Menu–Up-the-Coax Yes Yes Yes Yes Yes
eSATA Interface --- --- --- --- ---
Turbo Channel VCA
(Video Content Analysis)
6
Up to 1 channel support Up to 1 channel support Up to 1 channel support Up to 2 channel support Up to 2 channel support
Smart Play Yes Yes Yes Yes Yes
Max. Incoming/Outgoing Bandwidth
(Mbps)
60 96 128 60 128
Max. Network Streams 128 128 128 128 128
User Names 32 32 32 32 32
Remote User Logins 128 128 128 128 128
Ratings UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed
Rack Units 1 1 1 1 1
Power Requirements
12 VDC,
≤15 W without HDD
12 VDC,
≤20 W without HDD
12 VDC,
≤20 W without HDD
12 VDC,
≤15 W without HDD
12 VDC,
≤20 W without HDD
Standards: Complies with ONVIF (Prole S), CGI ASAPI. Contact factory for details.; Command Protocols: Hikvision and Pelco D/P protocols
6
Tribrid Smart Suite: Line Crossing, Intrusion Detection. Turbo channels; VCA supported from Hikvision IP cameras.
TurboHD™ | ANALOG MIGRATION SOLUTIONS
30
+
FEATURED PRODUCT
Tribrid DVRs detect
CVBS, TVI, and IP
cameras
The new DS-7200HUHI series of TurboHD DVRs
supports all the new 3 MP TurboHD cameras in
models with 4, 8, and 16 channel inputs. Now, razor
sharp images at 1920x1536 resolution can be
displayed and recorded with HD quality. These tribrid
DVRs can auto-detect a standard analog (CVBS),
TVI camera, and an IP camera input of up to 4 MP.
They also support Hikvision’s unique H.264+ video
compression, and they include great features ranging
from front panel controls to real-time recording and a
24TB internal recording capability.
TRIBRID DIGITAL VIDEO RECORDERS
TurboHD™
3.0 TRIBRID DVR - VALUE SERIES
TurboHD™
TRIBRID DVR - PRO SERIES
Model
DS-7216HUHI-F2/N DS-7308HQHI-SH DS-7316HQHI-SH DS-7332HGHI-SH DS-9008HQHI-SH DS-9016HQHI-SH
Max. Recording Resolution 3MP 1080p 1080p 1080p 1080p 1080p
Video Compression H.264+ H.264 H.264 H.264 H.264 H.264
HDMI/VGA Output
1920 × 1080, VGA 3840 × 2160, HDMI,
synchronous output
1920x1080/1920x1080,
independent output
1920x1080/1920x1080,
independent output
1920x1080/1920x1080,
syncronous output
1920x1080/1920x1080,
independent output
1920x1080/1920x1080,
independent output
Spot Monitor Output (BNC) Yes Yes Yes --- Yes Yes
Analog Input 16-Ch 1.0 Vp-p, 75 Ω 8-Ch 1.0 Vp-p 75 Ω 16-Ch 1.0 Vp-p 75 Ω 32-Ch 1.0 Vp-p 75 Ω 8-Ch 1.0 Vp-p 75 Ω 16-Ch 1.0 Vp-p 75 Ω
Video Standard HD-TVI/CVBS (auto-detect) HD-TVI/CVBS (auto-detect) HD-TVI/CVBS (auto-detect) HD-TVI/CVBS (auto-detect) HD-TVI/CVBS (auto-detect) HD-TVI/CVBS (auto-detect)
Audio Input/Output 4-ch/1-ch 4-ch/2-ch 4-ch/2-ch 4-ch/1-ch 8-ch/2-ch 16-ch/2-ch
Alarm Input/Output 16/4 16/4 16/4 16/4 16/4 16/4
USB 2.0
Front panel: 1 × USB 2.0,
Rear panel: 1 × USB 3.0
3 3 3 3 3
RAID Support ---- ---- ---- ----
RAID 0, RAID 1, RAID 5,
RAID 10 (up to 16TB)
RAID 0, RAID 1, RAID 5,
RAID 10 (up to 16TB)
Internal SATA 2 (up to 6 TB each) 4 (up to 6 TB each) 4 (up to 6 TB each) 4 (up to 6 TB each) 8 (up to 6 TB each) 8 (up to 6 TB each)
Max. Internal Storage 12 TB 24 TB 24 TB 24 TB 48 TB 48 TB
Support DVD-RW --- Yes, replaces 2x SATA Yes, replaces 2x SATA Yes, replaces 2x SATA Yes, replaces 4x SATA Yes, replaces 4x SATA
Max. fps 720p/1080p/3 MP HD-TVI 30/30/15 30/30 30/30 30/12 30/30 30/30
Max. Analog (CVBS) Resolution WD1 (960H) WD1 (960H) WD1 (960H) WD1 (960H) WD1 (960H) WD1 (960H)
Disable Turbo/CVBS Channel/Add IPC Yes Yes Yes Yes Yes Yes
Hikvision IP Camera Support 2 up to 4MP
2 up to 1080p
(up to 10 ch if HD-TVI
channels disabled)
2 up to 1080p
(up to 18 ch if HD-TVI
channels disabled)
8 up to 1080p
(up to 32 ch if HD-TVI
channels disabled)
10 up to 6 MP
(up to 18 if HD-TVI
channels disabled)
18 up to 6 MP
(up to 32 if HD-TVI
channels disabled)
Front Panel Control Yes Yes Yes Yes Yes Yes
OSD Menu–Up-the-Coax Yes Yes Yes Yes Yes Yes
eSATA Interface --- Yes Yes Yes Yes Yes
Turbo Channel VCA
(Video Content Analysis)
6
Up to 2 channel support Up to 2 channel support Up to 2 channel support Up to 1 channel support Up to 2 channel support Up to 2 channel support
Smart Play Yes Yes Yes Yes Yes Yes
Max. Incoming/Outgoing Bandwidth (Mbps) 128 200 200 200
160
(160 with RAID)
260
(260 with RAID)
Max. Network Streams 128 128 128 128 128 128
User Names 32 32 32 32 32 32
Remote User Logins 128 128 128 128 128 128
Ratings UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed
Rack Units 1 1.5 1.5 1.5 2 2
Power Requirements
12 VDC,
≤20 W without HDD
100 to 240 VAC, 50 to 60 Hz,
≤40 W without HDD
100 to 240 VAC, 50 to 60 Hz,
≤55 W without HDD
100 to 240 VAC, 50 to 60 Hz,
≤65 W without HDD
100 to 240 VAC, 47 to 63 Hz,
≤45 W without HDD
100 to 240 VAC, 47 to 63 Hz,
≤65 W without HDD
Standards: Complies with ONVIF (Prole S), CGI ASAPI. Contact factory for details.; Command Protocols: Hikvision and Pelco D/P protocols
6
Tribrid Smart Suite: Line Crossing, Intrusion Detection. Turbo channels; VCA supported from Hikvision IP cameras.
TurboHD™ | ANALOG MIGRATION SOLUTIONS
31
+
ENCODERS AND DECODERS
ENCODER DECODER
Model
DS-6701HWI DS-6704HWI DS-6708HWI DS-6716HWI DS-6708HQHI-SATA DS-6716HQHI-SATA DS-6401HDI-T DS-6404HDI-T DS-6408HDI-T
Frame Rate (fps) 30 30 30 30 30 30 Per video input Per video input Per video input
Multi-Streaming Yes Yes Yes Yes Yes Yes 1 video output 4 video outputs 8 video outputs
Video Input
1-ch, BNC
(1.0 Vp-p, 75 Ω)
4-ch, BNC
(1.0 Vp-p, 75 Ω)
8-ch, BNC
(1.0 Vp-p, 75 Ω)
16-ch, BNC
(1.0 Vp-p, 75 Ω)
8-ch, BNC
(1.0 Vp-p, 75 Ω)
16-ch, BNC
(1.0 Vp-p, 75 Ω)
H.264/MPEG4 TCP/IP H.264/MPEG4 TCP/IP H.264/MPEG4 TCP/IP
Video Output H.264/MPEG4 TCP/IP H.264/MPEG4 TCP/IP H.264/MPEG4 TCP/IP H.264/MPEG4 TCP/IP H.264/MPEG4 TCP/IP H.264/MPEG4 TCP/IP 1 HDMI, 1 VGA, 1 BNC
4 HDMI, 4 VGA, 2 BNC
(via DB-15 connector)
8 HDMI, 8 VGA, 4 BNC
(via DB-15 connector)
Network Interface
1 RJ-45 10/100 Mbps Ethernet
(PoE)
1 RJ-45 10/100 Mbps Ethernet
(PoE)
1 RJ-45 10/100/1000 Mbps
Ethernet
1 RJ-45 10/100/1000 Mbps
Ethernet
1 RJ-45 10/100/1000 Mbps
Ethernet
1 RJ-45 10/100/1000 Mbps
Ethernet
1 10/100/1000 Mbps
Ethernet
1 10/100/1000 Mbps
Ethernet
1 10/100/1000 Mbps
Ethernet
Storage --- --- --- ---
2 SATA interfaces
(up to 6 TB each)
2 SATA interfaces
(up to 6 TB each)
--- --- ---
Audio Input/Output 1 line in/1 line out 4 line in/1 line out 8 line in/1 line out 16 line in/1 line out 4 line in/1 line out 4 line in/1 line out 1 line in/1 line out 4 line in/4 line out 8 line in/8 line out
Voice Talk Input 1-ch 1-ch 1-ch 1-ch --- --- 1-ch 1-ch 1-ch
Alarm Input/Output 1/1 4/2 8/4 16/4 8/4 16/4 4/4 4/4 4/4
RS-232 --- Yes Yes Yes --- --- Yes Yes Yes
RS-485 Yes Yes Yes Yes Yes Yes Yes Yes Yes
Resolution In
WD1
(960H)/4CIF/2CIF/CIF/qCIF
WD1
(960H)/4CIF/2CIF/CIF/qCIF
WD1
(960H)/4CIF/2CIF/CIF/qCIF
WD1
(960H)/4CIF/2CIF/CIF/qCIF
HD-TVI: 8-ch
30fps @ 1080p and 720p
HD-TVI: 16-ch
30fps @ 1080p and 720p
--- --- ---
Resolution Out --- --- --- --- --- ---
5 MP: 2-ch, 1080p: 4-ch 720p:
8-ch, 4CIF: 16-ch
5 MP: 4-ch, 1080p: 8-ch 720p:
16-ch, 4CIF: 32-ch
5 MP: 8-ch, 1080p: 16-ch 720p:
32-ch, 4CIF: 64-ch
Ratings UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed UL/cUL Listed
Power Requirements 12 VDC, ≤5 W 12 VDC,≤7 W 12 VDC ≤10 W 12 VDC ≤22 W 12 VDC ≤30 W without HDD 12 VDC ≤45 W without HDD 12 VDC ≤15 W 100 to 240 VAC ≤70 W 100 to 240 VAC ≤70 W
Standards: Complies with ONVIF (Prole S), CGI ASAPI contact for factory details: Command Protocols: Hikvision and Pelco D/P protocols
TurboHD™ | ANALOG MIGRATION SOLUTIONS
32
MONITORS
Model
DS-D5042FL DS-D5032FL DS-D5021FC
Bezel Material Metal Metal Plastic
Working Time 7x24 h 7x24 h 7x24 h
Display Type LED-Backlit TFT LCD LED-Backlit TFT LCD LED-Backlit TFT LCD
Screen Size 42” 32” 20.7”
Pixel Pitch (H×V) 0.807 mm × 0.807 mm 0.807 mm × 0.807 mm 0.2385 mm × 0.2385 mm
Max. Resolution 1920×1080p 1920×1080p 1920×1080p
Brightness 400cd/m
2
(Typical) 400cd/m
2
(Typical) 200cd/m
2
(Typical)
Contrast 4000:1 4000:1 600:1
Response Time 8 ms 8 ms 3.5 ms
Color 16.7 M 16.7 M 16.7 M
Viewing Angle
Horizontal 178°,
Vertical 178°
Horizontal 178°,
Vertical 178°
Horizontal 170°,
Vertical 160°
Inputs 1x HDMI, VGA, DVI, BNC, USB 1x HDMI, VGA, DVI, BNC, USB 1x HDMI, VGA, BNC
Audio input 1, 3.5 mm mini-jack 1, 3.5 mm mini-jack 1, 3.5 mm mini-jack
Audio Out 1, 3.5 mm mini-jack 1, 3.5 mm mini-jack ---
Speaker 3 W x 2 3 W x 2 2 W x 2
Ratings CE, FCC CE, FCC CE, FCC
Power Supply 100-220 VAC, 50/60 Hz 100-220 VAC, 50/60 Hz 100-220 VAC, 50/60 Hz
Power Consumption
140 W (Normal working),
1 W (Standby)
75 W (Normal working),
1 W (Standby)
30 W (Normal working),
5 W (Standby)
Operation Temperature 0° C to 40° C 0° C to 40° C 0° C to 40° C
Operating Humidity
10% to 85%
(No Condensation)
10% to 85%
(No Condensation)
10% to 85%
(No Condensation)
Storage Temperature -20° C to 55° C -20° C to 55° C -20° C to 60° C
VESA Mount
Not VESA compliant
394 mm x 307 mm
200 mm x 200 mm 100 mm x 100 mm
Table Mount 190109090 190109088 Included
Wall Mount 190108462 190112360 190112560
Dimension (W×H×D)
962.2 × 570.5 × 71.55 mm
(37.9" x 22.5" x 2.8")
737.4 × 452.5 × 70.65 mm
(29" x 17.8" x 2.78")
491.55 × 301.12 × 53.54 mm
(19.35 x 11.86" x 2.1")
Weight 28 Kg (62 lbs) 19 Kg (42 lbs) 4.0 Kg (9 lbs)
KEYBOARDS
Model
DS-1003KI DS-1005KI DS-1100KI
RS-485 Yes No Yes
USB No Yes Yes
Interface Port RS-485 USB 2.0 RS-232, RS-485, RJ-45, USB 2.0
Control Serial Serial TCP/IP
Audio N/A N/A
IN: 1 line
OUT: 1 line
Decoding N/A N/A 1-ch @ 1080p
LCD Screen 5” x 2.5” N/A
7” TFT touchscreen at
800 x 480 resolution
Joystick 3–Axis 3–Axis 3–Axis
Resolution N/A N/A 1920x1080
Network N/A N/A Yes
Power Requirements 12 VDC (<10 W) 5 VDC via USB (≤5 W) 12 VDC (<15 W)
HD-TVI JOYSTICK HD-TVI MONITOR HD-TVI CONVERTER BALUN
Model
DS-1045 DS-TT-X41T DS-1H33 DS-1H18
Description HD-TVI Joystick Controller
Multifunction Video
Tester, test a variety of
video signals, including
TurboHD, HDMI, CVBS,
and VGA.
Converter from HD-TVI
video signal to HDMI
signal
Unshielded twisted pair
(UTP) Baluns
ACCESSORIES
ACCESSORIES
33
ACCESSORIES
PoE GIGABIT L2.5 ETHERNET SWITCHES PoE UNMANAGED SWITCHES
Model
DS-3D2208P DS-3D2228P DS-3E0105P-E DS-3E0109P-E DS-3E0318P-E DS-3E0326P-E
Ports
8p 10/100 Base-T,
2p 10/100/1000 Base-T,
2p 1000Mbps SFP,
1p console
24p 10/100 Base-T,
4p 10/100/1000 Base-T,
4p 1000Mbps SFP,
1p console
4p 10/100 Base-T,
1 uplink 10/100
8p 10/100 Base-T,
1uplink 10/100
16p 10/100 Base-T,
2 uplinks10/100/1000
24p 10/100 Base-T,
2 uplinks 10/100/1000
Forwarding 4.2 Mpps 9.6 Mpps 0.74Mpps 1.34Mpps 5.36Mpps 6.55Mpps
Backplane 5.6 Gbps 12.8 Gbps 1Gbps 1.8Gbps 7.2Gbps 8.8Gbps
PoE Budget
170 W
(8 PoE or 4 PoE+)
400 W
(24 PoE or 12 PoE+)
58W 123W 230W 370W
PoE Support
8 ports 802.3af (up to 15.4 W/port)
or 5 ports 802.3at (up to 30 W/port)
24 ports 802.3af (up to 15.4 W/port)
or 12 ports 802.3at (up to 30 W/port)
4 ports 802.3af (up to 15.4 W/port)
or 2 ports 802.3at (up to 30 W/port)
8 ports 802.3af (up to 15.4 W/port)
or 4 ports 802.3at (up to 30 W/port)
16 ports 802.3af (up to 15.4 W/port)
or 8 ports 802.3at (up to 30 W/port)
24 ports 802.3af (up to 15.4 W/port)
or 12 ports 802.3at (up to 30 W/port)
Standards
STP (IEEE 802.1D), RSTP (IEEE802.1w),
MSTP (802.1S), VLAN (802.1Q), QinQ, GVRP,
MULTICAST (IGMP SNOOPING V1/V2/V3),LACP,
SNMP (V1/V2), RMON (GROUP 1/2/3/9) TELNET,
SNTP, QOS.
1EEE802.1X, ACL
(IP/MAC/VLAN), DHCP SNOOPING, DAI, ARP
PREVENTION (STATIC/DYNAMIC), RADIUS, SSH.
STP (IEEE 802.1D), RSTP (IEEE802.1w),
MSTP (802.1S), VLAN (802.1Q), QinQ, GVRP,
MULTICAST (IGMP SNOOPING V1/V2/V3),LACP,
SNMP (V1/V2), RMON (GROUP 1/2/3/9) TELNET,
SNTP, QOS.
1EEE802.1X, ACL
(IP/MAC/VLAN), DHCP SNOOPING, DAI, ARP
PREVENTION (STATIC/DYNAMIC), RADIUS, SSH.
Unmanaged,
Plug-and-play installation
IEEE802.3x full duplex,
Optimized packet buffering (2.75M)
Optional 250m extended transmission mode
(PoE bandwidth reduced to
10Mbps per port by activating)
Unmanaged,
Plug-and-play installation
IEEE802.3x full duplex
Optimized packet buffering (2.75M)
Priority Queue on ports 1-2
(if switch is over capacity,
94 of 100 packets will route rst here)
Unmanaged,
Plug-and-play installation
IEEE802.3x full duplex
Optimized packet buffering (2.75M)
Priority Queue on ports 1-4(if switch is over
capacity, 94of100 packets will route rst here)
Optional 250m extended transmission mode
(PoE bandwidth reduced to
10Mbps per port by activating)
Unmanaged,
Plug-and-play installation
IEEE802.3x full duplex
Optimized packet buffering (2.75M)
Priority Queue on ports 1-4(if switch is over
capacity, 94of100 packets will route rst here)
Optional 250m extended transmission mode
(PoE bandwidth reduced to
10Mbps per port by activating)
Operating Temperature Range 0° C to 50° Cw 0° C to 50° C 0° C to 40° C 0° C to 40° C 0° C to 40° C 0° C to 40° C
Power Requirements 110 to 240 VAC, 170 W 110 to 240 VAC, 400 W 110 to 240 VAC, 170 W 110 to 240 VAC, 400 W 110 to 240 VAC, 170 W 110 to 240 VAC, 400 W
MEGAPIXEL AUTO IRIS LENSES
Model
TV0515D-MPIR
YV2.8x2.8SR4A-
SA2
YV3.3x15SR4A-
SA2L
DV4x12.5SR4A-SA1 TV2712D-MPIR TV0550D-MPIR
Specications
1.3 MP, 1/3" imager
size, IR, auto iris,
5 to 15 mm, ƒ/1.4,
manual zoom,
CS mount
3.0 MP, 1/2.7"
imager size, auto
iris, 2.8 to 8 mm,
ƒ/1.3, manual zoom,
CS mount
3.0 MP, 1/2.7"
imager size, auto
iris, 15 to 50 mm,
ƒ/1.5, manual zoom,
CS mount
5.0 MP, 1/1.8”
imager size, auto
iris, 12.5 to 50 mm,
ƒ/ 1.6, manual zoom,
C mount
3.0 MP, 1/2.7"
imager ,2.7 to 12
mm, ƒ/1.2, manual
zoom, CS mount
3.0 MP, 1/2.7
imager, 5 to 50 mm,
ƒ/1.7, manual zoom,
CS mount
Model
DV3.8x4SR4A-SA1 DV4X12.5SR4A-SA1L HV0733D-6MP HV1140D-8MPIR HV3816D-8MPIR
Specications
3.0 MP, 1/1.8 sensor,
auto iris, IR, 4 to 15.2
mm, ƒ/1.5, manual zoom,
C mount
5.0 MP, 1/1.8 sensor,
auto iris, IR, 12.5 to 50
mm, ƒ/1.6, manual zoom,
C mount
Lens, 6 MP 1/1.8 sensor,
auto iris, 7-33mm, ƒ/0.95,
manual zoom,
CS Mount
4K, 1/1.8" sensor, auto
iris, 11 to 40 mm, ƒ/1.5,
IR, manual zoom,
CS mount
4K, 1/1.8" sensor, 3.8 to
16 mm, ƒ/1.5, IR, manual
zoom, CS mount
ETHERNET OVER COAX
Model
DS-1H05-T DS-1H05-R DS-1H05-8R DS-1H05-16R
Input Interface RJ-45 interface and BNC BNC 8 - BNC 16 - BNC
Output Interface BNC RJ-45 Interface and BNC 4 - RJ-45 Interface 4 - RJ-45 Interface
Maximum
Bandwidth (Mbps)
36 (downstream) 11 (upstream) 11 (upstream) 11 (upstream)
Distance
Up to 1,500 feet
with RG6/U cable
Up to 1,500 feet
with RG6/U cable
Up to 1,500 feet
with RG6/U cable
Up to 1,500 feet
with RG6/U cable
Dimensions 80 x 96 x 27 mm 80 x 96 x 27 mm
440 x 44.5 x
195 mm
440 x 44.5 x
195 mm
Operating Conditions (max.) -10° C to +55° C -10° C to +55° C -10° C to +55° C -10° C to +55° C
Power Requirements (max.)
12 VDC, PSU included, 5 W
(does not power camera)
12 VDC, PSU included, 5 W
(does not power camera)
12 VDC, PSU included, 5 W
(does not power camera)
12 VDC, PSU included, 5 W
(does not power camera)
ACCESSORIES
34
STORAGE PRODUCTS
Model
DS-A81016S DS-A82024D
Controller/Processor Single, 64-bitmulti-core processor Double, 64-bitmulti-core processor
High-speed buffer 4 GB (expandable to 8G) 4 GB (expandable to 8G)
Video Input/Output IPSAN: 180-ch (2 Mbps) CVR:320-ch (2 Mbps) IPSAN: 256-ch (2 Mbps) CVR:448-ch (2 Mbps)
Operating system Windows, Linux, Solaris, HP-UX, AIX, MacOS Windows, Linux, Solaris, HP-UX, AIX, MacOS
HDD slot 16 24
HDD interface SATA /1 TB, 2 TB, 3 TB, 4 TB SAS/1 TB, 2 TB 3 TB 4 TB, (SSD is optional)
Hot-swap disk Supported Supported
RAID level RAID 0, 1, 3, 5, 6,10,50, JBOD, Hot-Spare RAID 0, 1, 3, 5, 6,10,50, JBOD, Hot-Spare
Disk management
S.M.A.R.T. (Self-Monitoring, Analysis and
Reporting Technology)
S.M.A.R.T. (Self-Monitoring, Analysis and
Reporting Technology)
LUN management iSCSI Volume, Record Volume iSCSI Volume, Record Volume
Data protection
Real-time backup of system information,
LUN clone
Real-time backup of system information,
LUN clone
Recording type
Continuous/Manual / Main and Sub Stream/
Motion /Sensor, etc.
Continuous/Manual / Main and Sub Stream/
Motion /Sensor, etc.
Recording backup Localbackup; Remote backup Localbackup; Remote backup
Recording protection
Lock key video le for protection, N+1 hot spare
system, ANR,video loss alarm
Lock key video le for protection, N+1 hot spare
system, ANR,video loss alarm
Search mode By time / type By time / type
Download mode
Quick download, batch download,
segment download, merging download
Quick download, batch download,
segment download, merging download
Device Management
method
Web-based GUI, CLI serial port,
integrated management of multiple units
Web-based GUI, CLI serial port,
integrated management of multiple units
Alarm type
Sound, Flash LED, Email, SMS,
Warning on device management page
Sound, Flash LED, Email, SMS,
Warning on device management page
Log download
Auto-download by USB ash drive,
Remotebackup via web browsing
Auto-download by USB ash drive,
Remotebackup via web browsing
Network Protocol RTSP / ONVIF / PSIA / iSCSI iSCSI/ NFS/ CIFS/ FTP/ HTTP/ AFP/ FCP
External data port 6×1000M self-adaptive Ethernet interface 4×1000M self-adaptive Ethernet interface
Management port 1×100Mself-adaptive Ethernet interface 1×100Mself-adaptive Ethernet interface
SAS expansion port 1 (6 Gbps) 1 (6 Gbps)
VGA output 1 1
COM interface
2 (1 for hyper terminal
and 1 for mobile phone alarm/UPS)
2 (1 for hyper terminal
and 1 for mobile phone alarm/UPS)
USB interface 2 2
Power Supply Redundant (1+1); single power available Redundant (1+1); single power available
Power consumption
Max. 460 W (with HDD, redundant power);
Max. 400 W (with HDD, single power)
Working Consumption: ≤ 380
(with HDD or DVD/RW
Rating Power Consumption: ≤1050W
Temperature Operating: 5°-40°; Storage: -20°-70° Operating 5 ºC~40 ºC Storing: -20 ºC~70 ºC
STORAGE EXPANSION
Model
DS-AJ6816S DS-AJ6824D
Controller Single Controller Double Controller
SAS Interface
(Upper-level)
1 (6 Gbps) 2( 6 Gbps)
SAS Interface
(Lower-level)
1 (6 Gbps) 1 (6 Gbps)
HDD Interfaces 16 24
HDD Interface
Type
SAS SAS
Hot Swap HDD Supported Supported
Power Redundant (1+1) Redundant (1+1)
Applicable
Models
DS-A81016S DS-A82024D
Power
Consumption
≤ 550 W (with HDD's) ≤ 550 W (with HDD's)
Working
Temperature
5°C ~ 40°C (41°F ~ 104°F) 5°C ~ 40°C (41°F ~ 104°F)
SURVEILLANCE GRADE HARD DRIVES ENTERPRISE HARD DRIVES
Model
HK-HDD1T HK-HDD2T HK-HDD3T HK-HDD4T HK-HDD6T HK-HDD1T-E HK-HDD2T-E HK-HDD3T-E HK-HDD4T-E
Capacity 1 TB 2 TB 3 TB 4 TB 6 TB 1 TB 2 TB 3 TB 4 TB
Interface SATA SATA SATA SATA SATA SATA 6 Gb/sec. SATA 6 Gb/sec. SATA 6 Gb/sec. SATA 6 Gb/sec.
Classication Audio/Video Audio/Video Audio/Video Audio/Video Audio/Video Audio/Video Audio/Video Audio/Video Audio/Video
Operation 24/7 continuous 24/7 continuous 24/7 continuous 24/7 continuous 24/7 continuous 24/7 continuous 24/7 continuous 24/7 continuous 24/7 continuous
HDD FOR STORAGE PRODUCTS DVD-RW MICRO SD CARD
Model
HDD-SAS4T HIK-DVDRW DS-UTF32GI-H1 DS-UTF64GI-H1
Description
HDD for DS-A81016S, DS-A82024D, DS-
AJ6816S, DS-AJ6824D
DVD-RW option for NVR and DVR 32 GB uSD 64 GB uSD
ACCESSORIES
ACCESSORIES
35
PTZ BRACKETS STAINLESS STEEL BRACKETS
Model
WMP-S WMP-L CMP PMP JBP-W PMPL CMPL CPM-S CPM-L CPMPE RPM WBPT-S WBPT WMP-SS CPM-SS WMS-SS JBM-SS
Description
Short wall
mount for 4"
PTZ
Wall Mount
PTZ-Long
Corner Mount
for WMP-L and
WMP-S
Pole Mount for
WMP-L and
WMP-S
PTZ Junction
box with wall
bracket
Pole Mount
Large
(for JBP-W)
Corner Mount
Large
(for JBP-W)
Ceiling Pendant
Mount-Short
Ceiling Pendant
Mount-Long
Ceiling Pendant
Mount,
extension pipe
1.5" diameter
Roof Parapet
Mount
Wall Mount for
DS-2DY5223IW-
AE Upright PTZ
Wall Mount for
DS-2DY9xxx
Series Upright
PTZs
Pendant Wall
Mount for
DS-2DT6223-
AELY
Pendant Ceiling
Mount for DS-
2DT6223-AELY
Pendant Wall
Mount for
DS-2CD6626DS-
IZHS
Medium
Junction Box
*PTZ brackets are for series; DS-2AE5xxx; DS-2AE7xxx; DS-2DE4xxx; DS-2DE5xxx; DS-2DE6xxx; DS-2DE7xxx; DS-2DF5xxx; DS-2DF6xxx; DS-2DF8xxx
CAMERA HOUSING BOX CAMERA BRACKETS UNIVERSAL BRACKET FOR PENDANT CAPS
Model
CHB CHB-HBW CHB-HB WBS WBL CPM CPME WMS* WML RPM PM CM
Description
Camera Housing with
Bracket
Camera Housing with
Bracket, Heater, Blower,
Wiper
Camera Housing with
Bracket, Heater, Blower
Suitable for box camera,
wall Mount
Suitable for box camera
and housing, wall mount
Camera Ceiling Pendant
Mount
Camera Ceiling Pendant
Mount, Extension Pipe
1" diameter
Short Wall Mount,
junction box
Long Wall Mount,
junction box
Roof Parapet Mount Pole Mount Adapter Corner Mount Adapter
ACCESSORIES
ACCESSORIES
CAMERA BRACKETS
Model
CB-FE CBM CBS* CBXS* CBT-1 AB110* AB135* AB165 AB-FE AB-FE2 AB-FE45* ABS* ABM RCM-1* RCM-2* RCM-3* RCM-4 WM-C WM110* GP100
Description
Conduit
base for
Fisheye
Conduit
Base
Conduit
Base
Conduit
Base
Conduit
Base
Angled Base Angled Base Angled Base
Angled Base
for Fisheye
Angled Base
for Fisheye
45
˚
Angled
Wall Mount
for Fisheye
ABS
Angled Base
Angled Base
Recessed
ceiling
mount
Recessed
ceiling
mount
Recessed
ceiling
mount
Recessed
ceiling
mount*
Wall Mount
Compact
Plastic Wall
Mount
Single Gang
Plate
*Recessed ceiling mount for DS-2DE3304W-DE
36
SUN/RAIN SHIELD DVR/NVR CAMERA BRACKETS
Model
SRS SRSM SRSL WMR* PC110* PC110T* PC120* PC130* PC130T* PC135* PC140* PC140PT PC160 PC165 PC210 PC-FE CB110* CB-130 CB135* CB140PT CB165
Description
Wall mount
dome rain
and sun
protection
Medium
for outdoor
dome rain
and sun
protection
Large for
outdoor
dome rain
and sun
protection
Wall
Mounted
Bracket for
DVR/NVR
110 mm
Pendant
Cap
110TRS
Pendant
Cap
120 mm
Pendant
Cap
130 mm
Pendant
Cap
130TRL
Pendant
Cap
135 mm
Pendant
Cap
140 mm
Pendant
Cap
140 mm
Pendant
Cap for DS-
2DE3304W-
DE
160 mm
Pendant
Cap
165 mm
Pendant
Cap
210mm
Pendant
Cap for
DS-
2CD6986F-H
Pendant Cap
for sheye
Conduit Base Conduit Base Conduit Base
Conduit
Base for DS-
2DE3304W-
DE
Conduit
Base
Compatible with WMS and WML Compatible with WML
*Wall Mounted Bracket for DVR/NVR is compatible with DS-7608NI-E2/8P and DS-7616NI-E2/16P
*Black model
PC110B
*Black model
SRSB
*Black model
PC110TB
*Black model
PC120B
*Black model
RCM-1B
*Black model
ABSB
*Black model
RCM-2B
*Black model
RCM-3B
*Black model
WM110B
*Black model
WMSB
*Black model
PC130B
*Black model
PC130TB
*Black model
PC135B
*Black model
PC140B
*Black model
CB110B
*Black model
CB135B
*Black model
AB110B
*Black model
AB135B
*Black model
CBSXB
*Black model
CBSB
PENDANT CAP CONDUIT BASE ANGLED BASE
RECESSED
CEILING MOUNT
WALL
MOUNT
SUN/RAIN
SHADE
GP
Camera Model
PC110
PC110T
PC120
PC130
PC130T
PC135
PC140
PC140PT
PC160
PC210
PC-FE
PC165
CB110
CB130
CB135
CB140PT
CB165
CB-FE
CBM
CBS
CBXS
C B T- 1
AB110
AB135
AB165
AB-FE
AB-FE2
AB-FE45
ABM
ABS
RCM-1
RCM-2
RCM-3
RCM-4
WM-C
WM110
SRS
SRSL
SRSM
GP100
PROFESSIONAL SOLUTIONS
DS-2CD41xxFxx-IZ
DS-2CD42xxFxx-IZHx*
DS-2CD43xxFWD-IZHSx
DS-2CD45xxFxx-IZHx
DS-2CD4AxxFxx-IZHx*
DS-2CD63xxFxx-Ix
DS-2CD6W32FWD-IVS
DS-2CD6986F-H
BRACKET CHART
ACCESSORIES
VALUE PLUS SOLUTIONS
DS-2CD20xxWD-I
DS-2CD21xxFWD-IS
DS-2CD23x2WD-I
DS-2CD25x2FWD-IS
DS-2CD26x2FWD-IZS*
DS-2CD27x2FWD-IZS
DS-2CD2Tx2WD-I
VALUE SOLUTIONS
DS-2CD20xx-I
DS-2CD21x2F-I
DS-2CD22x2-I5
DS-2CD23x2-I
DS-2CD25xxF-xx
DS-2CD26x2F-I*
DS-2CD27x2F-I
DS-2CD2942F-IS
PTZ CAMERA
DS-2DE2103-DE3/W
DS-2DE2202I-DE3/W
DS-2DE3304W-DE
Wi-Fi SOLUTIONS
DS-2CD21x2F-IWS
DS-2DE2103-DE3/W
DS-2DE2202I-DE3/W
DS-2CD25x2FWD-IWS
PC110
PC110T
PC120
PC130
PC130T
PC135
PC140
PC140PT
PC160
PC210
PC-FE
PC165
CB110
CB130
CB135
CB140PT
CB165
CB-FE
CBM
CBS
CBXS
C B T- 1
AB110
AB135
AB165
AB-FE
AB-FE2
AB-FE45
ABM
ABS
RCM-1
RCM-2
RCM-3
RCM-4
WM-C
WM110
SRS
SRSL
SRSM
GP100
*Includes CB130 conduit base
GP = Gang Plate
37
PENDANT CAP CONDUIT BASE ANGLED BASE
RECESSED
CEILING MOUNT
WALL
MOUNT
SUN/RAIN
SHADE
GP
Camera Model
PC110
PC110T
PC120
PC130
PC130T
PC135
PC140
PC140PT
PC160
PC210
PC-FE
PC165
CB110
CB130
CB135
CB140PT
CB165
CB-FE
CBM
CBS
CBXS
C B T- 1
AB110
AB135
AB165
AB-FE
AB-FE2
AB-FE45
ABM
ABS
RCM-1
RCM-2
RCM-3
RCM-4
WM-C
WM110
SRS
SRSL
SRSM
GP100
TurboHD™ | ANALOG MIGRATION SOLUTIONS
DS-2CE16C2T-IR
DS-2CE16C5T-IT1
DS-2CE16C5T-VFIR3
DS-2CE16xxT-xxxxxx
DS-2CE16D1T-IT1
DS-2CE16D1T-IR
DS-2CE16D5T-IT3
DS-2CE16D9T-AIRAZH
DS-2CE56C2T-IRM
DS-2CE56C5T-AVFIR
DS-2CE56C5T-AVPIR3
DS-2CE56C5T-IT1
DS-2CE56C5T-VFIT3
DS-2CE56D1T-AVFIR
DS-2CE56D1T-AVPIR3
DS-2CE56D1T-IT1
DS-2CE56D1T-IRM
DS-2CE56D1T-VPIR
DS-2CE56D5T-AIRZ
DS-2CE56D5T-AVFIR
DS-2CE56D5T-AVPIR3
DS-2CE56D5T-AVPIR3ZH
DS-2CE56D5T-IR3Z
DS-2CE56D5T-IT3
DS-2CE56D5T-VFIT3
PC110
PC110T
PC120
PC130
PC130T
PC135
PC140
PC140PT
PC160
PC210
PC-FE
PC165
CB110
CB130
CB135
CB140PT
CB165
CB-FE
CBM
CBS
CBXS
C B T- 1
AB110
AB135
AB165
AB-FE
AB-FE2
AB-FE45
ABM
ABS
RCM-1
RCM-2
RCM-3
RCM-4
WM-C
WM110
SRS
SRSL
SRSM
GP100
ACCESSORIES
GP = Gang Plate
BRACKET CHART
38
VIDEO MANAGEMENT CLIENT SOFTWARE - iVMS-4200 AND iVMS-4500
Standard Software is included in the compatible product packages only. No-fee policy applies to license, channel, software support agreement, and technical support access of Standard Software only. Customized software may incur additional fee.
Apple, iPhone, iPad and iTunes are registered trademarks of Apple Inc.® Android™ is a registerd trademark of Google Inc.® Windows Mobile is a registered trademark of Microsoft Corp.® All other trademarks are property of their respective owners.
iVMS-4200 CLIENT SOFTWARE (WINDOWS AND MAC COMPATIBLE) – NO LICENSING FEE!
Live View Support up to 4 output screens, recommend maximum of 32 live views
Encoding Device Up to 256 encoded devices
Decoding Device Up o 64 decoding devices
Imported Camera Up to 1024 imported cameras
Camera Group Up to 256 camera groups, with 64 maximum cameras in one group
Storage Server Up to 16 storage servers, each server's recording performance is 64*2 Mbps
Stream Media Server
Up to 16 stream media servers,, each server is with incoming connections of 64*2 Mbps
and outgoing connections of 200*2 Mbps
Playback 16 channel playback. For best performance, 1 to 4 cameras at a time are recommended for remote playback
Download Up to 16 simultaneous download tasks
User Up to 51 users
System Log Congurable, 1 to 6 months
Map Supports PNG, BMP, and JPEG images. Nested maps supported.
PTZ Control, presets, patrols, patterns supported
Device Search Supports Search Activated Device Protocol (SADP)
Device Conguration Supports remote programming and conguration of any connected device. Features Add Device Wizard.
Minimum Server System
Requirements
Windows 2003/Windows 7/ Windows 8/ Windows 8.1 /
Windows Server 2008 (32-bit or 64-bit), Windows Server 2008 R2 /
Windows Server 2012 (64-bit)
iVMS-4500 MOBILE CLIENT APPLICATION FOR SMARTPHONES AND TABLETS
Mobile client software can be used to monitor the live video remotely from embedded hybrid DVR, NVR, DVR recorders, IP camera, IP speed dome or DVS/encoder via
wireless network.
Number of Devices 100 device addresses
Live View iPhone/Android Phone: 16 cameras
Remote Playback iPhone/Android Phone/Windows Phone: 1-ch playback; iPad/Android Tablet: up to 4-ch
Congurable Image
Quality
Clear, balanced, uent, and customized
Frame Rate Up to 25/30 fps (dependant on device and network)
Resolution Up to 1080p
Stream Type Video and audio
PTZ Control Pan, tilt, zoom
Snapshot Snapshot and video recording in Live View
Compatible Devices
Apple iOS (iPhone/iPad)
1
Android (1.6 or higher)
2
Windows Mobile
3
1
iPhone/iPad app must be acquired from the iTunes App Store.
2
Android app can be obtained at the Android Market or www.hikvision.com.
3
Windows Phone 8 app must be acquired from the Windows Store.
VIDEO MANAGEMENT CLIENT SOFTWARE
39
PROFESSIONAL SOLUTIONS VALUE PLUS SOLUTIONS VALUE SOLUTIONS TurboHD™ | ANALOG MIGRATION SOLUTIONSWI-FI SOLUTIONS ACCESSORIES
QUICK REFERENCE GUIDE - SORTED ALPHABETICALLY
AB-FE
36
AB-FE2
36
AB-FE45
36
AB110
36
AB135
36
AB165
36
ABM
36
ABS
36
CB-130
36
CB-FE
36
CB110
36
CB135
36
CB140PT
36
CB165
36
CBM
36
CBS
36
CBT-1
36
CBXS
36
CHB
36
CHB-HB
36
CHB-HBW
36
CM
36
CMP
36
CMPL
36
CPM
36
CPM-L
36
CPM-S
36
CPM-SS
36
CPME
36
CPMPE
36
DS-1003KI
33
DS-1003KI
33
DS-1005KI
33
DS-1045
33
DS-1100KI
33
DS-1H05-16R
34
DS-1H05-8R
34
DS-1H05-R
34
DS-1H05-T
34
DS-1H18
33
DS-1H33
33
DS-2AE4223T-A
29
DS-2AE4223T-A3
29
DS-2AE5123T-A
29
DS-2AE5123TI-A
29
DS-2AE5230T-A
29
DS-2AE5230T-A3
29
DS-2AE7230TI-A
29
DS-2CC12D9T-A
26
DS-2CD2012-I
19
DS-2CD2022WD-I
17
DS-2CD2032-I
19
DS-2CD2042WD-I
17
DS-2CD2112F-I
18
DS-2CD2112F-IWS
23
DS-2CD2122FWD-IS/B
16
DS-2CD2132F-I
18
DS-2CD2132F-IWS
23
DS-2CD2142FWD-IS/B
16
DS-2CD2152F-I
16
DS-2CD2212-I5
19
DS-2CD2232-I5
19
DS-2CD2322WD-I
17
DS-2CD2332-I
19
DS-2CD2342WD-I
17
DS-2CD2352-I
17
DS-2CD2412F-IW
23
DS-2CD2432F-IW
23
DS-2CD2510F
18
DS-2CD2512F-I
18
DS-2CD2520F
18
DS-2CD2522FWD-IS/B
16
DS-2CD2522FWD-IWS
23
DS-2CD2532F-I
18
DS-2CD2542FWD-IS/B
16
DS-2CD2542FWD-IWS
23
DS-2CD2552F-I
16
DS-2CD2612F-I
19
DS-2CD2622FWD-IZS
17
DS-2CD2632F-I
19
DS-2CD2642FWD-IZS
17
DS-2CD2712F-I
18
DS-2CD2722FWD-IZS/B
16
DS-2CD2732F-I
18
DS-2CD2742FWD-IZS/B
16
DS-2CD2752F-IZS
16
DS-2CD2942F-IS
19
DS-2CD2D14WD
19
DS-2CD2D14WD/M
19
DS-2CD2E10F
18
DS-2CD2E20F
18
DS-2CD2T22WD-I5
17
DS-2CD2T42WD-I5
17
DS-2CD2T52-I5
17
DS-2CD4012FWD-A
6
DS-2CD4025FWD-A
6
DS-2CD4032FWD-A
6
DS-2CD4065F-A
6
DS-2CD4085F-AP
6
DS-2CD4112FWD-IZ
7
DS-2CD4125FWD-IZ
7
DS-2CD4132FWD-IZ
7
DS-2CD4165F-IZ
7
DS-2CD4185F-IZ
7
DS-2CD41C5F-IZ
7
DS-2CD4212FWD-IZH
7
DS-2CD4212FWD-IZH8
7
DS-2CD4312FWD-IZHS
8
DS-2CD4312FWD-IZHS8
8
DS-2CD4324FWD-IZHS
8
DS-2CD4324FWD-IZHS8
8
DS-2CD4332FWD-IZHS
9
DS-2CD4332FWD-IZHS8
9
DS-2CD4526FWD-IZH
9
DS-2CD4535FWD-IZH
9
DS-2CD4535FWD-IZH8
9
DS-2CD4565F-IZH
9
DS-2CD4585F-IZH
9
DS-2CD45C5F-IZH
9
DS-2CD4A24FWD-IZH
7
DS-2CD4A25FWD-IZH
7
DS-2CD4A25FWD-IZH8
7
DS-2CD4A26FWD-IZH
8
DS-2CD4A26FWD-IZH8
8
DS-2CD4A35FWD-IZH
8
DS-2CD4A35FWD-IZH8
8
DS-2CD4A65F-IZH
8
DS-2CD4A85F-IZH
8
DS-2CD4AC5F-IZH
8
DS-2CD6026FHWD-A
6
DS-2CD6026FHWD-A3/A7/A11
6
DS-2CD6332FWD-I
10
DS-2CD6332FWD-IV
10
DS-2CD6362F-I
10
DS-2CD6362F-IV
10
DS-2CD63C2F-IV
10
DS-2CD6412FWD-C2
11
DS-2CD6412FWD-L10
11
DS-2CD6412FWD-L20
11
DS-2CD6412FWD-L30
11
DS-2CD6424FWD-10
11
DS-2CD6424FWD-20
11
DS-2CD6424FWD-20/E
11
DS-2CD6424FWD-30
11
DS-2CD6424FWD-40/E1
11
DS-2CD6424FWD-40/E2
11
DS-2CD6626DS-IZHS
14
DS-2CD6986F-H
9
DS-2CD6W32FWD-IVS
10
DS-2CE16C2T-IR
28
DS-2CE16C5T-IT1
28
DS-2CE16C5T-VFIR3
28
DS-2CE16D1T-AVFIR3
28
DS-2CE16D1T-IR
28
DS-2CE16D1T-IT1
28
DS-2CE16D5T-AIR3ZH
28
DS-2CE16D5T-AVFIT3
28
DS-2CE16D5T-IT3
28
DS-2CE16D7T-IT
24
DS-2CE16D7T-IT5
24
DS-2CE16D7T–AIT3Z
24
DS-2CE16D9T-AIRAZH
28
DS-2CE16F7T-IT
25
DS-2CE16F7T-IT5
25
DS-2CE16F7T–AIT3Z
25
DS-2CE56C2T-IRM
27
DS-2CE56C5T-AVFIR
26
DS-2CE56C5T-AVPIR3
26
DS-2CE56C5T-IT1
27
DS-2CE56C5T-VFIT3
27
DS-2CE56D1T-AVFIR/B
26
DS-2CE56D1T-AVPIR3/B
26
DS-2CE56D1T-IRM/B
27
DS-2CE56D1T-IT1
27
DS-2CE56D1T-VPIR/B
26
DS-2CE56D5T-AIRZ
26
DS-2CE56D5T-AVFIR/B
26
DS-2CE56D5T-AVPIR3/B
26
DS-2CE56D5T-AVPIR3ZH
26
DS-2CE56D5T-IR3Z
27
DS-2CE56D5T-IT3/B
27
DS-2CE56D5T-VFIT3
27
DS-2CE56D7T-AITZ
25
DS-2CE56D7T-IT3
24
DS-2CE56D7T-IT3Z
24
DS-2CE56D7T-ITM
24
DS-2CE56D7T-VPIT
24
DS-2CE56D7T–AVPIT3Z
25
DS-2CE56F7T-AITZ
25
DS-2CE56F7T-IT3
25
DS-2CE56F7T-IT3Z
25
DS-2CE56F7T-ITM
25
DS-2CE56F7T-VPIT
25
DS-2CE56F7T–AVPIT3Z
25
DS-2DE2103-DE3/W
20
DS-2DE2103-DE3/W
23
DS-2DE2202I-DE3/W
20
DS-2DE2202I-DE3/W
23
DS-2DE3304W-DE
20
DS-2DE4220-AE
20
DS-2DE4220-AE3
20
DS-2DE5130W-AE
21
DS-2DE5174-AE
21
DS-2DE5184-AE
21
DS-2DE5184-AE3
20
DS-2DE5220I-AE
21
DS-2DE5230W-AE
21
DS-2DE7130IW-AE
21
DS-2DE7174-AE
21
DS-2DE7184-AE
21
DS-2DE7230IW-AE
21
DS-2DF5220S-DE4/W
23
DS-2DF5220S-DE4/W
12
DS-2DF5276-AE3
12
DS-2DF5276-AEL
12
DS-2DF5286-AE3
12
DS-2DF5286-AEL
12
DS-2DF6236-AEL
12
DS-2DF6236V-AEL
12
DS-2DF6336V-AEL
12
DS-2DF7276-AEL
12
DS-2DF7286-AEL
13
DS-2DF8236I-AEL
13
DS-2DF8236IV-AEL
13
DS-2DF8336IV-AEL
13
DS-2DF8336IV-AELW
13
DS-2DF8836IV-AEL
13
DS-2DF8836IV-AELW
13
DS-2DT6223-AELY
14
DS-2DY5223IW-AE
14
DS-2DY9188-A
14
DS-2DY9188-AI2
14
DS-3D2208P
34
DS-3D2228P
34
DS-3E0105P-E
34
DS-3E0109P-E
34
DS-3E0318P-E
34
DS-3E0326P-E
34
DS-6401HDI-T
32
DS-6404HDI-T
32
DS-6408HDI-T
32
DS-6701HWI
32
DS-6704HWI
32
DS-6708HQHI-SATA
32
DS-6708HWI
32
DS-6716HQHI-SATA
32
DS-6716HWI
32
DS-7104NI-SL/W
23
DS-7108NI-E1/V/W/1T
23
DS-7204HGHI-SH
30
DS-7204HUHI-F1/N
30
DS-7208HGHI-SH
30
DS-7208HUHI-F2/N
30
DS-7216HGHI-SH
30
DS-7216HUHI-F2/N
30
DS-7308HQHI-SH
31
DS-7316HQHI-SH
31
DS-7332HGHI-SH
31
DS-7604NI-E1/4P
22
DS-7608NI-E2/8P
22
DS-7608NI-I2/8P
22
DS-7616NI-E2/16P
22
DS-7616NI-I2/16P
22
DS-7716NI-I4/16P
22
DS-7716NI-SP/16
22
DS-9008HQHI-SH
31
DS-9016HQHI-SH
31
DS-96128NI-F24/H
15
DS-9616NI-ST
15
DS-96256NI-F24/H
15
DS-9632NI-I8
15
DS-9632NI-ST
15
DS-9664NI-I8
15
DS-9664NI-ST
15
DS-A81016S
35
DS-A82024D
35
DS-AJ6816S
35
DS-AJ6824D
35
DS-D5021FC
33
DS-D5032FC
33
DS-D5042FL
33
DS-TT-X41T
33
DS-UTF32GI-H1
35
DS-UTF64GI-H1
35
DV3.8x4SR4A-SA1
34
DV4x12.5SR4A-SA1
34
DV4X12.5SR4A-SA1L
34
GP100
36
HDD-SAS4T
35
HIK-DVDRW
35
HK-HDD1T
35
HK-HDD1T-E
35
HK-HDD2T
35
HK-HDD2T-E
35
HK-HDD3T
35
HK-HDD3T-E
35
HK-HDD4T
35
HK-HDD4T-E
35
HK-HDD6T
35
HV0733D-6MP
34
HV1140D-8MPIR
34
HV3816D-8MPIR
34
iDS-2CD6412FWD/C
9
JBM-SS
36
JBPW
36
PC-FE
36
PC110
36
PC110T
36
PC120
36
PC130
36
PC130T
36
PC135
36
PC140
36
PC140PT
36
PC160
36
PC165
36
PC210
36
PM
36
PMP
36
PMPL
36
RCM-1
36
RCM-2
36
RCM-3
36
RCM-4
36
RPM
36
RPM
36
SRS
36
SRSL
36
SRSM
36
TV0515D-MPIR
34
TV0550D-MPIR
34
TV2712D-MPIR
34
WBL
36
WBPT
36
WBPT-S
36
WBS
36
WM-C
36
WM110
36
WML
36
WMP-L
36
WMP-S
36
WMP-SS
36
WMR
36
WMS
36
WMS-SS
36
YV2.8x2.8SR4A-SA2
34
YV3.3x15SR4A-SA2L
34
PRODUCT NOTES
SUPPORT
Hikvision Technical Support
Hikvision strives to provide industry-leading support to our customer base
and we work continuously to innovate video surveillance technology. From
product installation questions to technical troubleshooting to rmware
upgrades, dedicated telephone support guides you to the solution.
Hikvision USA and Hikvision Canada Technical Support:
Toll-free: +1-866-200-6690 (U.S. and Canada)
Phone: +1-909-895-0400
Email: techsuppor[email protected]
Hikvision Learning & Development
Hikvision Learning & Development was created to familiarize designers,
integrators, installers, and end-users with the rapidly changing technical
challenges that a proper video security installation demands, using
state-of-the-art products. From essential understanding of terminology
to comprehensive networking analysis using diverse industry-tested
theoretical and hands-on training in a supportive environment, Hikvision
Learning & Development provides the best training program in the industry.
For more information visit us at www.hikvisionlearning.com
Hikvision Partner Program:
FOSTERING PARTNER EXCELLENCE
The Hikvision Dealer Partner program rewards partner loyalty with exciting
relationship-based advantages and recognition. Through this program,
Hikvision extends exclusive access to products, business assistance, and
priority service to key industry partners. In April 2016, Hikvision launched
a new category of the Partner Program: Diamond. This tier is designed
to meet the needs of enterprise-level partners with built-in incentives for
enhanced protability and enriched training certication and support.
For more information about joining our partner network as a Silver, Gold,
Platinum, or Diamond level member, contact
Hikvision USA Inc.
18639 Railroad Street
City of Industry, CA 91748
Email: [email protected]
Hikvision Canada Inc.
4485 Dobrin Street
St. Laurent, QC H4R 2L8
Email: [email protected]
Contact Information
Toll-Free: +1 866-200-6690 (U.S. and Canada)
Phone: +1 909-895-0400
www.hikvision.com
Connect with us:
©2016-2017 Hikvision USA Inc. and Hikvision Canada Inc. All rights reserved. Hikvision is a registered trademark of Hikvision Digital Technology Co., Ltd. in the US, Canada and other countries. All other trademarks, service
marks, and product or service names are trademarks or registered trademarks of their respective owners. Product specications and availability are subject to change without notice.
