MR692B/MR692W
Installation Instructions
6” x 9” (152 x 229 mm) Marine
2-Way Full Range Speakers (1 Pair)
- 1 -
Thank you for purchasing a BOSS Audio Systems product. Please read through these
instructions carefully so you will know how to install this product properly.
Package contents
• 2x Speakers (with xed grill)
• 8x Mounting screws and clip nuts
• 2x EVA gaskets
• Cutout template and warranty
Specications
• 2-way speaker, full range
Woofer: 6” x 9” (152 x 229 mm),
polypropylene cone, resin treated cloth surround
Tweeter: 1” (25 mm), dome
• Output power: max 350 W
• Nominal impedance: 4 Ω
• Frequency response: 60 Hz-20 kHz
• System sensitivity: 92 dB (1 watt/1 meter)
• Outdoor use. Water resistant, but never
submerge.
Speaker dimensions
A
B
B
A
C
E
D
A. Overall diameter: 7.75” x 10.5” (197 x 267 mm)
B. Mounting hole diameter: 6.02” x 8.78” (153 x 223 mm)
C. Mounting depth: 3.38” (86 mm)
D. Grill protrusion: 1.375” (35 mm)
E. Outer motor diameter: 4.80” (122 mm)
