LG Electronics LUU249HV 24000 BTU Single Zone Ducted System Outdoor Unit with GoldFin, Inverter - Use Manual - Use Guide PDF.
Documents: Go to download!
User Manual
User manual of LG Electronics LUU249HV (83 pages)
See other models: LS120HXV2 LS180HEV2 LS120HEV2 LH248HV4 GS-D600PLC
Documents: Go to download!
User Manual
User manual of LG Electronics LUU249HV (83 pages)
See other models: LS120HXV2 LS180HEV2 LS120HEV2 LH248HV4 GS-D600PLC
LG Electronics LUU249HV | Pages: 83 | Created on: 2024-04-26 | File type: PDF | Filename: 53811755_lh248hv4.pdf | Size: 8.34 MB | Language: English | Other documents: 2 files.
Download User Manual
Download User Manual
Specs Sheet
- Width: 37 13/32 Inch
- Depth: 13 Inch
- Height: 32 27/32 Inch
- Net Weight: 130 Lbs.
- Shipping Weight: 143.3 Lbs.
- Heating Capacity: 27,000 BTU
- Min Connectable Capacity: 1 BTU
- Max Connectable Capacity: 1 BTU
- Liquid Line Outer Diameter: 3/8 Inch
- Suction Line Outer Diameter: 5/8 Inch
- Piping Length: 24.6 Ft.
- Max. Line Length Total: 164 Ft.
- Max. Height Diff. btwn. Indoor and Outdoor Units: 98.4 Ft.
- Operation: Cooling with Heat Pump
- Compressor Noise Level Cooling: 48 dB
- Compressor Noise Level Heating: 52 dB
- Drain Line Outer Diameter: 1 1/4 Inch
- Drain Line Inner Diameter: 4 Inch
- Outside Temperature Range for Cooling Min.: 5 °F
- Outside Temperature Range for Cooling Max.: 118 °F
- Outside Temperature Range for Heating Min.: 4 °F
- Outside Temperature Range for Heating Max.: 64 °F
- Parts Warranty: 5 Year
- Min No. of Connectible Indoor Units: 1
- Max No. of Connectible Indoor Units: 1
- Power Input Cooling Min.: 720 Watts
- Power Input Cooling Rated: 2,980 Watts
- Power Input Cooling Max.: 4,000 Watts
- Power Input Heating Min.: 580 Watts
- Power Input Heating Rated: 2,080 Watts
- Power Input Heating Max.: 3,100 Watts
- Rated Amps: 13.5 Amps
- Power and Communication Cable No.: 4
- Power and Communication Cable AWG: 14
- Power Supply Cable No. x AWG: 3C x 12
- Refrigerant Charge: 4.41 Ft.
- Voltage: 230/208 Volts
- Refrigerant Control: EEV
