Thermal & Opcal Bi-spectrum PTZ Network
Camera
User Manual
Legal Informaon
©2023 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
About this Manual
The Manual includes instrucons for using and managing the Product. Pictures, charts, images and
all other informaon hereinaer are for descripon and explanaon only. The informaon
contained in the Manual is subject to change, without noce, due to rmware updates or other
reasons. Please nd the latest version of this Manual at the Hikvision website ( hps://
www.hikvision.com/ ).
Please use this Manual with the guidance and assistance of professionals trained in supporng the
Product.
Trademarks
and other Hikvision's trademarks and logos are the properes of
Hikvision in various jurisdicons.
Other trademarks and logos menoned are the properes of their respecve owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS IS" AND "WITH
ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR
PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION
BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY,
OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
i
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED
TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN
RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATTER
PREVAILS.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
ii
Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger
Indicates a hazardous situaon which, if not avoided, will or could
result in death or serious injury.
Cauon
Indicates a potenally hazardous situaon which, if not avoided, could
result in equipment damage, data loss, performance degradaon, or
unexpected results.
Note
Provides addional informaon to emphasize or supplement
important points of the main text.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
iii
Safety Instrucon
These instrucons are intended to ensure that user can use the product correctly to avoid danger
or property loss.
Laws and Regulaons
●
In the use of the product, you must be in strict compliance with the electrical safety regulaons
of the naon and region.
Transportaon
●
Keep the device in original or similar packaging while transporng it.
●
Keep all wrappers aer unpacking them for future use. In case of any failure occurred, you need
to return the device to the factory with the original wrapper. Transportaon without the original
wrapper may result in damage on the device and the company shall not take any responsibilies.
●
Do not drop the product or subject it to physical shock. Keep the device away from magnec
interference.
Power Supply
●
Please purchase the charger by yourself. Input voltage should meet the Limited Power Source
(24 VDC, or 24 VAC) according to the IEC62368 standard. Please refer to technical specicaons
for detailed informaon.
●
Make sure the plug is properly connected to the power socket.
●
The socket-outlet shall be installed near the equipment and shall be easily accessible.
●
DO NOT connect mulple devices to one power adapter, to avoid over-heang or re hazards
caused by overload.
●
DO NOT touch the bare metal contacts of the inlets aer the circuit breaker is turned o.
Electricity sll exists.
●
+ idenes the posive terminal(s) of equipment which is used with, or generates direct current.
- idenes the negave terminal(s) of equipment which is used with, or generates direct current.
●
Ensure correct wiring of the terminals for connecon to an AC mains supply.
Baery
●
Risk of explosion if the baery is replaced by an incorrect type. Dispose of used baeries
according to the instrucons. Il y a risque d'explosion si la baerie est remplacée par une
baerie de type incorrect. Mere au rebut les baeries usagées conformément aux instrucons.
●
The built-in baery cannot be dismantled. Please contact the manufacture for repair if
necessary.
●
For long-term storage of the baery, make sure it is fully charged every half year to ensure the
baery quality. Otherwise, damage may occur.
●
This equipment is not suitable for use in locaons where children are likely to be present.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
iv
●
Improper replacement of the baery with an incorrect type may defeat a safeguard (for
example, in the case of some lithium baery types).
●
DO NOT dispose of the baery into re or a hot oven, or mechanically crush or cut the baery,
which may result in an explosion.
●
DO NOT leave the baery in an extremely high temperature surrounding environment, which
may result in an explosion or the leakage of ammable liquid or gas.
●
DO NOT subject the baery to extremely low air pressure, which may result in an explosion or
the leakage of ammable liquid or gas.
Installaon
●
Never place the equipment in an unstable locaon. The equipment may fall, causing serious
personal injury or death.
●
This equipment is for use only with corresponding brackets. Use with other (carts, stands, or
carriers) may result in instability causing injury.
System Security
●
You acknowledge that the nature of Internet provides for inherent security risks, and our
company shall not take any responsibilies for abnormal operaon, privacy leakage or other
damages resulng from cyber aack, hacker aack, however, our company will provide mely
technical support if required.
●
Please enforce the protecon for the personal informaon and the data security as the device
may be confronted with the network security problems when it is connected to the Internet.
Please contact us when the device might exist network security risks.
●
Please understand that you have the responsibility to congure all the passwords and other
security sengs about the device, and keep your user name and password.
Maintenance
●
If the product does not work properly, please contact your dealer or the nearest service center.
We shall not assume any responsibility for problems caused by unauthorized repair or
maintenance.
●
A few device components (e.g., electrolyc capacitor) require regular replacement. The average
lifespan varies, so periodic checking is recommended. Contact your dealer for details.
●
Wipe the device gently with a clean cloth and a small quanty of ethanol, if necessary.
●
If the equipment is used in a manner not specied by the manufacturer, the protecon provided
by the device may be impaired.
●
To reduce the risk of re, replace only with the same type and rang of fuse.
●
The serial port of the equipment is used for debugging only.
●
Disconnect the power source during servicing.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
v
Using Environment
●
Make sure the running environment meets the requirement of the device. The operang
temperature shall be -40°C to 60°C (-40°F to 140°F), and the operang humidity shall be 95% or
less, no condensing.
●
DO NOT expose the device to high electromagnec radiaon or dusty environments.
●
DO NOT aim the lens at the sun or any other bright light.
●
The equipment shall not be exposed to dripping or splashing and that no objects lled with
liquids, such as vases, shall be placed on the equipment.
●
No naked ame sources, such as lighted candles, should be placed on the equipment.
●
Provide a surge suppressor at the inlet opening of the equipment under special condions such
as the mountain top, iron tower, and forest.
●
Burned ngers when handling the parts with symbol . Wait one-half hour aer switching o
before handling the parts.
Emergency
●
If smoke, odor, or noise arises from the device, immediately turn o the power, unplug the
power cable, and contact the service center.
COMPLIANCE NOTICE: The thermal series products might be subject to export controls in various
countries or regions, including without limitaon, the United States, European Union, United
Kingdom and/or other member countries of the Wassenaar Arrangement. Please consult your
professional legal or compliance expert or local government authories for any necessary export
license requirements if you intend to transfer, export, re-export the thermal series products
between dierent countries.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
vi
Contents
Chapter 1 Overview .................................................................................................................... 1
1.1 Brief Descripon .................................................................................................................... 1
1.2 Funcon ................................................................................................................................. 1
Chapter 2 Device Acvaon and Accessing ................................................................................. 2
2.1 Acvate the Device via SADP ................................................................................................. 2
2.2 Acvate the Device via Browser ............................................................................................. 2
2.3 Login ...................................................................................................................................... 3
2.3.1 Plug-in Installaon ........................................................................................................ 3
2.3.2 Illegal Login Lock ........................................................................................................... 4
Chapter 3 Temperature Measurement ........................................................................................ 5
3.1 Noce ..................................................................................................................................... 5
3.2 Thermography Conguraon Flow Chart ............................................................................... 5
3.3 Automac Thermography ...................................................................................................... 7
3.3.1 Set Thermography Parameters ..................................................................................... 7
3.3.2 Set Normal Mode .......................................................................................................... 9
3.3.3 Set Expert Mode ........................................................................................................... 9
3.3.4 Set Thermography Rule ............................................................................................... 10
3.4 Manual Thermography ........................................................................................................ 12
3.5 Search History Temperature ................................................................................................ 12
Chapter 4 Fire and Smoke Detecon ......................................................................................... 14
4.1 Fire and Smoke Detecon Flow Chart .................................................................................. 14
4.2 Recommended Scene .......................................................................................................... 15
4.3 Detecon Mode and Applicaon Scene ............................................................................... 16
4.4 Set the Presets ..................................................................................................................... 16
4.5 Set Fire Detecon Parameters ............................................................................................. 18
4.5.1 Set Fire Source Shielded Region .................................................................................. 20
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
vii
4.6 Set Smoke Detecon Parameters ......................................................................................... 21
Chapter 5 Perimeter Protecon ................................................................................................ 23
5.1 Flow Chart of Perimeter Protecon ..................................................................................... 23
5.2 Set VCA Parameters ............................................................................................................. 24
5.3 Congure the Perimeter Protecon ..................................................................................... 24
5.3.1 Set Detecon Scenes and Tracking ............................................................................. 25
5.3.2 Set Rules ..................................................................................................................... 25
5.3.3 Set the Scene Auto-Switch .......................................................................................... 27
5.3.4 Set Polling Plan ............................................................................................................ 27
5.4 Advanced Conguraon ....................................................................................................... 28
Chapter 6 Event and Alarm ....................................................................................................... 30
6.1 Set Moon Detecon ........................................................................................................... 30
6.1.1 Normal Mode .............................................................................................................. 30
6.1.2 Expert Mode ............................................................................................................... 31
6.2 Set Video Tampering Alarm ................................................................................................. 32
6.3 Set Alarm Input .................................................................................................................... 33
6.4 Set Excepon Alarm ............................................................................................................. 34
6.5 Set Burning-Prevenon ........................................................................................................ 34
6.6 Detect Audio Excepon ........................................................................................................ 35
Chapter 7 Arming Schedule and Alarm Linkage ......................................................................... 36
7.1 Set Arming Schedule ............................................................................................................ 36
7.2 Linkage Method Sengs ...................................................................................................... 36
7.2.1 Trigger Alarm Output .................................................................................................. 36
7.2.2 FTP/NAS/Memory Card Uploading ............................................................................. 38
7.2.3 Send Email .................................................................................................................. 38
7.2.4 Nofy Surveillance Center .......................................................................................... 39
7.2.5 Trigger Recording ........................................................................................................ 39
Chapter 8 PTZ ........................................................................................................................... 40
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
viii
8.1 PTZ Control .......................................................................................................................... 40
8.2 Set Preset ............................................................................................................................. 42
8.2.1 Special Presets ............................................................................................................ 42
8.3 Set Patrol Scan ..................................................................................................................... 43
8.3.1 Set One-Touch Patrol .................................................................................................. 44
8.4 Set Paern Scan ................................................................................................................... 44
8.5 Set Linear Scan ..................................................................................................................... 45
8.6 Set Limit ............................................................................................................................... 46
8.7 Set Inial Posion ................................................................................................................ 46
8.8 Set Park Acon ..................................................................................................................... 47
8.9 Set Privacy Mask .................................................................................................................. 47
8.10 Set Scheduled Tasks ........................................................................................................... 48
8.11 Set Combined Path ............................................................................................................ 48
8.12 Set Device Posion ............................................................................................................. 49
8.12.1 Set Manual Compass ................................................................................................. 50
8.12.2 Set Auto Compass ..................................................................................................... 50
8.13 Set Power O Memory ...................................................................................................... 50
8.14 Set PTZ Priority ................................................................................................................... 51
Chapter 9 Live View .................................................................................................................. 52
9.1 Live View Parameters ........................................................................................................... 52
9.1.1 Window Division ......................................................................................................... 52
9.1.2 Live View Stream Type ................................................................................................ 52
9.1.3 Enable and Disable Live View ...................................................................................... 52
9.1.4 View Previous/Next Page ............................................................................................ 52
9.1.5 Full Screen ................................................................................................................... 52
9.1.6 Conduct Regional Focus .............................................................................................. 53
9.1.7 Light ............................................................................................................................ 53
9.1.8 Wiper .......................................................................................................................... 53
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
ix
9.1.9 Lens Inializaon ........................................................................................................ 53
9.1.10 Track Manually .......................................................................................................... 53
9.1.11 Auxiliary Focus .......................................................................................................... 54
9.1.12 Quick Set Live View ................................................................................................... 54
9.1.13 Lens Parameters Adjustment .................................................................................... 54
9.1.14 Conduct 3D Posioning ............................................................................................. 55
9.1.15 De-icing ..................................................................................................................... 55
9.1.16 Synchronize FOV ....................................................................................................... 55
9.2 Set Transmission Parameters ............................................................................................... 55
Chapter 10 Video and Audio ..................................................................................................... 57
10.1 Video Sengs .................................................................................................................... 57
10.1.1 Stream Type .............................................................................................................. 57
10.1.2 Video Type ................................................................................................................ 57
10.1.3 Resoluon ................................................................................................................. 57
10.1.4 Bitrate Type and Max. Bitrate ................................................................................... 58
10.1.5 Video Quality ............................................................................................................ 58
10.1.6 Frame Rate ................................................................................................................ 58
10.1.7 Video Encoding ......................................................................................................... 58
10.1.8 Smoothing ................................................................................................................. 59
10.1.9 Display VCA Info ........................................................................................................ 60
10.2 Audio Sengs .................................................................................................................... 60
10.2.1 Audio Input ............................................................................................................... 60
10.2.2 Two-way Audio .......................................................................................................... 60
10.3 Set ROI ............................................................................................................................... 61
10.4 Metadata ........................................................................................................................... 62
10.5 Display Sengs .................................................................................................................. 62
10.5.1 Scene Mode .............................................................................................................. 62
10.5.2 Image Adjustment ..................................................................................................... 62
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
x
10.5.3 Image Adjustment (Thermal Channel) ...................................................................... 63
10.5.4 Exposure Sengs ...................................................................................................... 63
10.5.5 Day/Night Switch ...................................................................................................... 64
10.5.6 Set Supplement Light ................................................................................................ 64
10.5.7 BLC ............................................................................................................................ 65
10.5.8 WDR .......................................................................................................................... 65
10.5.9 White Balance ........................................................................................................... 65
10.5.10 DNR ......................................................................................................................... 65
10.5.11 Smart Noise Reducon ........................................................................................... 66
10.5.12 Defog ....................................................................................................................... 66
10.5.13 Set Palee ............................................................................................................... 67
10.5.14 Set Palee Range .................................................................................................... 67
10.5.15 DDE ......................................................................................................................... 67
10.5.16 Brightness Sudden Change ..................................................................................... 67
10.5.17 Target Enhancement ............................................................................................... 68
10.5.18 Contrast Enhancement ........................................................................................... 68
10.5.19 Enhance Regional Image ......................................................................................... 68
10.5.20 Mirror ...................................................................................................................... 68
10.5.21 Video Standard ....................................................................................................... 68
10.5.22 Digital Zoom ............................................................................................................ 68
10.5.23 Zoom Limit .............................................................................................................. 69
10.5.24 Local Video Output ................................................................................................. 69
10.6 OSD .................................................................................................................................... 69
10.7 Overlay Picture ................................................................................................................... 69
10.8 Set Manual DPC (Defecve Pixel Correcon) ..................................................................... 70
10.9 Set Picture in Picture .......................................................................................................... 70
10.10 VCA Rule Display Sengs ................................................................................................ 71
Chapter 11 Video Recording and Picture Capture ...................................................................... 72
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
xi
11.1 Storage Sengs ................................................................................................................. 72
11.1.1 Set Memory Card ...................................................................................................... 72
11.1.2 Set NAS ..................................................................................................................... 72
11.1.3 Set FTP ...................................................................................................................... 73
11.1.4 Set Cloud Storage ...................................................................................................... 73
11.2 Video Recording ................................................................................................................. 74
11.2.1 Record Automacally ................................................................................................ 74
11.2.2 Record Manually ....................................................................................................... 76
11.2.3 Playback and Download Video .................................................................................. 76
11.3 Capture Conguraon ........................................................................................................ 76
11.3.1 Capture Automacally .............................................................................................. 77
11.3.2 Capture Manually ..................................................................................................... 77
11.3.3 View and Download Picture ...................................................................................... 77
Chapter 12 Network Sengs .................................................................................................... 79
12.1 TCP/IP ................................................................................................................................. 79
12.1.1 Mulcast Discovery ................................................................................................... 80
12.2 Port .................................................................................................................................... 80
12.3 Port Mapping ..................................................................................................................... 81
12.3.1 Set Auto Port Mapping .............................................................................................. 81
12.3.2 Set Manual Port Mapping ......................................................................................... 82
12.4 Mulcast ............................................................................................................................ 82
12.5 SNMP ................................................................................................................................. 82
12.6 Access to Device via Domain Name ................................................................................... 83
12.7 Access to Device via PPPoE Dial Up Connecon ................................................................ 83
12.8 Accessing via Mobile Client ................................................................................................ 84
12.8.1 Enable Hik-Connect Service on Camera .................................................................... 84
12.8.2 Set Up Hik-Connect ................................................................................................... 85
12.8.3 Add Camera to Hik-Connect ...................................................................................... 86
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
xii
12.9 Set ISUP .............................................................................................................................. 86
12.10 Set Open Network Video Interface .................................................................................. 87
12.11 Set Alarm Server .............................................................................................................. 87
12.12 Set Network Service ......................................................................................................... 88
12.13 Set SRTP ........................................................................................................................... 88
Chapter 13 System and Security ................................................................................................ 89
13.1 View Device Informaon .................................................................................................... 89
13.2 Search and Manage Log ..................................................................................................... 89
13.3 Import and Export Conguraon File ................................................................................ 89
13.4 Export Diagnose Informaon ............................................................................................. 90
13.5 Reboot ............................................................................................................................... 90
13.6 Restore and Default ........................................................................................................... 90
13.7 Upgrade ............................................................................................................................. 90
13.8 Set Electric Current Limit ................................................................................................... 91
13.9 View Open Source Soware License .................................................................................. 91
13.10 Time and Date .................................................................................................................. 91
13.10.1 Synchronize Time Manually .................................................................................... 91
13.10.2 Set NTP Server ........................................................................................................ 91
13.10.3 Set DST .................................................................................................................... 92
13.11 Set RS-232 ........................................................................................................................ 92
13.12 Set RS-485 ........................................................................................................................ 92
13.13 Set Same Unit .................................................................................................................. 93
13.14 Set Visible Light Parameters ............................................................................................. 93
13.15 Security ............................................................................................................................ 94
13.15.1 Authencaon ........................................................................................................ 94
13.15.2 Security Audit Log ................................................................................................... 94
13.15.3 Set IP Address Filter ................................................................................................ 95
13.15.4 Cercate Management ......................................................................................... 96
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
xiii
13.15.5 Set SSH .................................................................................................................... 98
13.15.6 Set HTTPS ................................................................................................................ 98
13.15.7 Set QoS .................................................................................................................... 99
13.15.8 Set IEEE 802.1X ....................................................................................................... 99
13.16 User and Account ........................................................................................................... 100
13.16.1 Set User Account and Permission ......................................................................... 100
13.16.2 Online Users .......................................................................................................... 100
Chapter 14 Appendix .............................................................................................................. 101
14.1 Common Material Emissivity Reference .......................................................................... 101
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
xiv
Chapter 1 Overview
1.1 Brief Descripon
Thermal & Opcal Bi-spectrum PTZ network camera integrates the funcon of the decoder,
thermal camera, and the high-denion zoom camera. It performs temperature measurement,
dynamic re source detecon and other smart detecons in the remote video security of the
power system, metallurgy system, petrochemical engineering, and so on. It is equipped with high-
sensivity IR detector and high-performance sensor. The device is able to measure object's
temperature at a high accuracy in real me. The pre-alarm system helps you discover unexpected
events immediately and protects your property.
1.2 Funcon
This secon introduces main funcons of the device.
Fire and Smoke Detecon
Device can detect re source and smoke in the scene and output pre-alarm and alarm to protect
the property.
Temperature Measurement
Device can measure the actual temperature of the spot being monitored. The device alarms when
temperature exceeds the temperature threshold value.
VCA
Device can do perimeter protecon. Mulple rules can be congured for dierent requirements.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
1
Chapter 2 Device Acvaon and Accessing
To protect the security and privacy of the user account and data, you should set a login password
to acvate the device when access the device via network.
Note
Refer to the user manual of the soware client for the detailed informaon about the client
soware acvaon.
2.1 Acvate the Device via SADP
Search and acvate the online devices via SADP soware.
Before You Start
Access www.hikvision.com to get SADP soware to install.
Steps
1.
Connect your computer to the same Wi-Fi network that the device is in.
2.
Run SADP soware to search the online devices of the LAN.
3.
Check Device Status from the device list, and select Inacve device.
4.
Create and input the new password in the password eld, and conrm the password.
Cauon
We highly recommend you create a strong password of your own choosing (using a minimum of
8 characters, including upper case leers, lower case leers, numbers, and special characters) in
order to increase the security of your product. And we recommend you reset your password
regularly, especially in the high security system, reseng the password monthly or weekly can
beer protect your product.
5.
Click OK.
Device Status changes into Acve.
6.
Oponal: Change the network parameters of the device in Modify Network Parameters.
2.2 Acvate the Device via Browser
You can access and acvate the device via the browser.
Steps
1.
Connect the device to the PC using the network cables.
2.
Change the IP address of the PC and device to the same segment.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
2
Note
The default IP address of the device is 192.168.1.64. You can set the IP address of the PC from
192.168.1.2 to 192.168.1.253 (except 192.168.1.64). For example, you can set the IP address of
the PC to 192.168.1.100.
3.
Input 192.168.1.64 in the browser.
4.
Set device acvaon password.
Cauon
We highly recommend you create a strong password of your own choosing (using a minimum of
8 characters, including at least three of the following categories: upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
5.
Click OK.
6.
Input the acvaon password to log in to the device.
7.
Oponal: Go to Conguraon → Network → Basic → TCP/IP to change the IP address of the
device to the same segment of your network.
2.3 Login
Log in to the device via Web browser.
2.3.1 Plug-in Installaon
Certain operaon systems and web browser may restrict the display and operaon of the device
funcon. You should install plug-in or complete certain sengs to ensure normal display and
operaon. For detailed restricted funcon, refer to the actual device.
Operang System Web Browser Operaon
Windows Internet Explorer 10+ Follow pop-up prompts to
complete plug-in installaon.
Google Chrome 57+
Mozilla Firefox 52+
Click
to
download and install plug-in.
Go to Conguraon →
Network → Advanced Sengs
→ Network Service to enable
WebSocket or WebSockets for
normal view if plug-in
installaon is not required.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
3
Operang System Web Browser Operaon
Display and operaon of
certain funcons are restricted.
For example, Playback and
Picture are not available. For
detailed restricted funcon,
refer to the actual device.
Mac OS 10.13+ Mac Safari 12+ Plug-in installaon is not
required.
Go to Conguraon →
Network → Advanced Sengs
→ Network Service to enable
WebSocket or WebSockets for
normal view. Display and
operaon of certain funcons
are restricted. For example,
Playback and Picture are not
available. For detailed
restricted funcon, refer to the
actual device.
Note
The device only supports Windows and Mac OS system and does not support Linux system.
2.3.2 Illegal Login Lock
It helps to improve the security when accessing the device via Internet.
Go to Conguraon → System → Security → Security Service , and enable Enable Illegal Login
Lock, Illegal Login Aempts and Locking Duraon are congurable.
Illegal Login Aempts
When your login aempts with the wrong password reach the set mes, the device is locked.
Locking Duraon
The device releases the lock aer the seng duraon.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
4
Chapter 3 Temperature Measurement
When you enable this funcon, the device measures the actual temperature of the scene. It alarms
when temperature exceeds the temperature threshold value.
3.1 Noce
This part introduces the noces of conguring temperature measurement funcon.
●
The target surface should be as vercal to the opcal axis as possible. It is recommended that
the angle of oblique image plane should be less than 45°.
●
The target image pixels should be more than 5 × 5.
●
If mulple presets will be taken for temperature measurement, it is recommended to set the
patrol me above 20 s.
●
Please select line thermography or area thermography for a certain area temperature
measurement. The point thermography is not recommended in case of deviaon occurred
during device movement to aect the accuracy of temperature measurement.
3.2 Thermography Conguraon Flow Chart
This part introduces the process of conguring temperature measurement.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
5
Figure 3-1 Thermography Conguraon Flow Chart
Note
Please refer to the Quick Start Guide for detailed informaon of Installaon part in the ow chart.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
6
3.3 Automac Thermography
Congure the temperature measurement parameters and temperature measurement rules. The
device can measure the actual temperature and output alarms when temperature exceeds the
alarm threshold value.
3.3.1 Set Thermography Parameters
Congure the parameters of temperature measurement.
Steps
1.
Go to Conguraon → Local , enable Display Temperature Info.
Display Temperature Info.
Select Yes to display temperature informaon on live view.
Enable Rules to display the rules informaon on live view.
2.
Click Save.
3.
Go to Conguraon → Temperature Measurement → Basic Sengs to congure parameters.
Enable Temperature Measurement
Check to enable temperature measurement funcon.
Enable Color-Temperature
Check to display Temperature-Color Ruler in live view.
Display Temperature Info. on Stream
Check to display temperature informaon on the stream.
Display Temperature in Opcal Channel
Check to display thermal channel temperature informaon in the opcal channel.
Display Max./Min./Average Temperature
Check to display maximum/minimum/average temperature informaon on liveview when the
temperature measurement rule is line or area.
Posion of Thermometry Info
Select the posion of temperature informaon showed on the live view.
●
Near Target: display the informaon beside the temperature measurement rule.
●
Top Le: display the informaon on the top le of screen.
Add Original Data on Capture
Check to add data on alarm triggered capture of thermal channel.
Add Original Data on Stream
Check to add original data on thermal view.
Data Refresh Interval
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
7
It means the refresh interval of temperature informaon.
Unit
Display temperature with Degree Celsius (°C)/Degree Fahrenheit (°F)/Degree Kelvin (K).
Temperature Range
Select the temperature measurement range. The device can adjust the temperature range
automacally if you select Auto.
Atmospheric Temperature
Set the atmospheric temperature.
Atmospheric Humidity
Set the atmospheric humidity.
Atmospheric Transmissivity
Set the atmospheric transmissivity from 0 to 1.
Distance Mode
Select the distance mode for temperature measurement. Fixed Distance and Self-Adapon
are selectable.
Version
View the version of current algorithm.
Calibraon File Version
View the version of calibraon le.
Alarm Interval
Set the alarm interval between two alarms.
Reect Light Filter
Enable these funcons if there is strong reected light from sun, or it may cause false alarm.
The lter sensivity can be adjusted.
Check Display Filtering Status, and an OSD will be displayed when the funcon is enabled.
Click Restart to restart the algorithm library of reect light lter.
Forkli Filter
Enable these funcons if there is forkli in the scene, or it may cause false alarm. The lter
level can be adjuested.
Check Display Filtering Status, and an OSD will be displayed when the funcon is enabled.
Click Restart to restart algorithm library of forkli lter.
Note
●
The sengs vary according to dierent camera models.
●
Reect Light Filter & Forkli Filter are mutually exclusive with VCA funcons.
●
The ltering status will be displayed on the lower right of the interface.
4.
Click Save.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
8
3.3.2 Set Normal Mode
This funcon is used to measure the temperature of the whole scene and alarm.
Steps
1.
Go to Conguraon → Temperature Measurement → Basic Sengs , and check Enable
Temperature Measurement.
2.
Refer to Set Thermography Parameters to set the parameters.
3.
Go to Conguraon → Temperature Measurement → Advanced Sengs , and select Normal.
4.
Congure the parameters of normal mode.
Emissivity
Set the emissivity of your target. The emissivity of each object is dierent.
Distance
The distance between the target and the device.
Pre-Alarm Threshold
When the temperature of target exceeds the pre-alarm threshold, and this status keeps more
than Filtering Time, it triggers pre-alarm.
Alarm Threshold
When the temperature of target exceeds the alarm threshold, and this status keeps more
than Filtering Time, it triggers alarm.
Pre-Alarm Output and Alarm Output
Check Pre-Alarm Output and Alarm Output to link the pre-alarm or alarm with the
connected alarm device.
5.
Refer to Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage method.
6.
Click Save.
The maximum and minimum temperature will be displayed on the live view.
Note
Go to Image → VCA Rules Display to adjust the font size and the temperature color of normal,
alarm and pre-alarm.
3.3.3 Set Expert Mode
Select the temperature measurement rules from Point, Line, or Area and congure parameters,
the device alarms if the alarm rules are met.
Steps
1.
Go to Conguraon → Temperature Measurement → Basic Sengs , check Enable
Temperature Measurement.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
9
2.
Refer to Set Thermography Parameters to set the parameters.
3.
Go to Conguraon → Temperature Measurement → Advanced Sengs , select Expert.
4.
Refer to Set Preset to set a preset.
5.
Select and enable the temperature measurement rules. Please refer to Set Thermography Rule
for seng the rule.
6.
Oponal: Click Area's Temperature Comparison to set the alarm rules and the temperature.
7.
Refer to Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage method.
8.
Click Save.
The maximum temperature and thermography rules will be displayed on the live view.
Note
Go to Image → VCA Rules Display to adjust the font size and the temperature color of normal,
alarm and pre-alarm.
9.
Oponal: Call the preset and check if the rules are ecient.
10.
Enable the scan funcon of device, such as linear scan to monitor the scene.
3.3.4 Set Thermography Rule
Steps
1.
Customize the rule name.
2.
Select the rule type to Point, Line, or Area. Then draw a point, line, or area on the interface
where the posion to be measured.
Point Please refer to
Point Thermography for detailed conguraon.
Line Please refer to
Line Thermography for detailed conguraon.
Area Please refer to
Area Thermography for detailed conguraon.
3.
Congure the temperature measurement parameters.
Emissivity
Set the emissivity of the target. The emissivity of the surface of a material is its eecveness
in eming energy as thermal radiaon. Dierent objects have dierent emissivity. Refer to
Common Material Emissivity Reference to search for the target emissivity.
Distance
The distance between the target and the device.
Reecve Temperature
If there is any object with high emissivity in the scene, check and set the reecve
temperature to correct the temperature. The reecve temperature should be set the same
as the temperature of the high emissivity object.
4.
Click and set the Alarm Rule.
Alarm Temperature and Pre-Alarm Temperature
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
10
Set the alarm temperature and pre-alarm temperature. E.g., select Alarm Rule as Above
(Average Temperature), set the Pre-Alarm Temperature to 50 °C, and set the Alarm
Temperature to 55 °C. The device pre-alarms when its average temperature is higher than
50 °C and alarms when its average temperature is higher than 55 °C.
Filtering Time
It refers to the duraon me aer the target temperature reaches or exceeds the pre-alarm
temperature/alarm temperature.
Tolerance Temperature
Set the tolerance temperature to prevent the constant temperature change to aect the
alarm. E.g., set tolerance temperature as 3 °C, set alarm temperature as 55 °C, and set pre-
alarm temperature as 50 °C. The device sends pre-alarm when its temperature reaches 50 °C
and it alarms when its temperature reaches 55 °C and only when the device temperature is
lower than 52 °C will the alarm be cancelled.
Pre-Alarm Output and Alarm Output
When the temperature of target exceeds the pre-alarm or alarm threshold, it triggers the pre-
alarm or alarm output of the connected device.
Area's Temperature Comparison
Select two areas and set the comparison rule, and set the temperature dierence threshold.
The device alarms when the temperature dierence meets the seng value.
5.
Click Save.
Click Live View, and select thermal channel to view the temperature and rules informaon on
live view.
Point Thermography
Congure the temperature measurement rule and click any point in live view to monitor the
temperature.
Steps
1.
Click in the live view and a cross cursor shows on the interface.
2.
Drag the cross cursor to desired posion.
Go to Live View interface to view the temperature and rule of the point in thermal channel.
Line Thermography
Congure the temperature measurement rule and monitor the maximum temperature of the line.
Steps
1.
Click and drag the mouse to draw a line in the live view interface.
2.
Click and move the line to adjust the posion.
3.
Click and drag the ends of the line to adjust the length.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
11
Go to Live View interface to view the maximum temperature and rule of the line in thermal
channel.
Area Thermography
Congure the temperature measurement rule and monitor the maximum temperature of the area.
Steps
1.
Click and drag the mouse in the live view to draw the area and right click to nish drawing.
2.
Click and move the area to adjust the posion.
3.
Drag the corners of the area to adjust the size and shape.
Go to Live View interface to view the maximum temperature and rule of the area in thermal
channel.
3.4 Manual Thermography
Aer enable the manual thermography funcon of the device, you can click any posion on the
live view to show the real temperature.
Steps
1.
Go to Conguraon → Local and select Display Temperature Info. as Yes.
2.
Go to Conguraon → Temperature Measurement → Basic Sengs .
3.
Check Enable Temperature Measurement.
4.
Click Save.
5.
Go to live view interface and select thermal channel, click
. Click any posion on the interface
to show the real temperature.
3.5 Search History Temperature
You can search the history temperature and generate the temperature/me graphic.
Before You Start
Refer to Set Memory Card and Set NAS to set the storage rst.
Steps
1.
Go to Conguraon → Temperature Measurement → Search History Temperature .
2.
Set the search parameters.
Preset
You can search the highest temperature informaon in normal mode. Or you can search the
temperature informaon of special presets in expert mode.
Rule
Select a rule of the special preset.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
12
Start Time
Set the searching start me.
Display Time Interval
Display the temperature informaon for every seng me interval.
3.
Click Search to generate the graphic.
4.
Click Export to download the graphic.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
13
Chapter 4 Fire and Smoke Detecon
The device will trigger and upload alarm when detect the re source or smoke.
Fire and smoke detecon is applied to re-prevenon purposes in scenic region, forest, tunnel and
so on. You can congure the re source detecon parameters and smoke detecon parameters.
When re source or smoke is detected, the alarm acons will be triggered.
Note
Not all models support the smoke detecon funcon, take the actual product for reference.
4.1 Fire and Smoke Detecon Flow Chart
Introduce the process of conguring re and smoke detecon.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
14
Figure 4-1 Fire and Smoke Detecon Flow Chart
Note
Please refer to the Quick Start Guide for detail informaon of Installaon part in the ow chart.
Obtain the informaon of longitude, altude, direcon and so on by device aer installaon.
4.2 Recommended Scene
This part introduces the recommended scenes of re source detecon and helps you select the
appropriate scene.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
15
Fire source detecon can be applied to indoor and outdoor monitoring with a large detecon
radius. To achieve the best monitoring eect, please set the installaon place as requirements
below.
●
The installaon place should be the highest posion within the detecon area. The lens should
not be covered during movement to detect the maximum area.
●
It is beer to choose the installaon place with convenient trac, well-equipped power and
internet facilies (e.g., communicaon tower, watchtower and high-rise roof).
4.3 Detecon Mode and Applicaon Scene
Fire and Smoke Detecon Mode
Fire or Smoke
The system alarms when device is either triggered by re source detecon or smoke detecon.
Fire and Smoke
The system holds when device is triggered by re source detecon or smoke detecon. When
target is detected by both rules, the system sends two alarms, otherwise, the system sends
single alarm.
Double Conrm
The system alarms when device is both triggered by re source detecon and smoke detecon.
Specied Fire Source
The system alarms when device is triggered by re source detecon.
Specied Smoke
The system alarms when device is triggered by smoke.
Applicaon Scene
In Applicaon Scene, Short Distance and Long Distance are selectable. Select the scene according
to the actual distance.
4.4 Set the Presets
Please set the presets according to steps below to improve the accuracy of re detecon.
Steps
1.
If the presets located in dierent areas, you can set 6 presets in two areas as the example
showed below.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
16
Figure 4-2 Set the Presets for re detecon
2.
Divide the scan area into three parts and set a preset every 120°. The black numbers are presets,
and the red numbers are scan areas.
3.
Set the presets according to the sequence of patrol path: 1->2->3->1->4->5->6->4.
Note
●
When set the presets, you should adjust the zoom rao to view the image of both opcal
channel and thermal channel clearly.
●
The recommended zoom rao of opcal channel and patrol speed shows in the table below.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
17
16.7-1000
(focus
distance)
12.5-775
(focus
distance)
15.6-500
(focus
distance)
6.7-330 (focus
distance)
10-320
(focus
distance)
6-240 (focus
distance)
The le column is opcal rao, the right columns are speed level.
15
km
15 4 20 4 / / / / / / / /
10
km
10 5 15 4 12 4 / / / / / /
5 km 7 6 10 5 8 5 20 4 13 4 / /
3 to 5
km
5 6 7 6 6 6 13 4 9 5 15 4
4.5 Set Fire Detecon Parameters
To avoid the potenal re damage, you should congure the re detecon funcon for certain
areas. The detail conguraon steps show as below.
Before You Start
●
The re detecon funcon can locate the re source area quickly together with patrol or linear
scan. Please refer to
Set Patrol Scan for conguring patrol. Please refer to Set the Presets for
presets seng.
●
Please refer to Set Device Posion for locang the re source posion.
●
Go to Conguraon → Local , set the re point parameters.
Locate Highest Temperature Point
Click and save to show the posion of the highest temperature on the interface.
Frame Fire Point
Click and save to frame the detected re source.
Steps
1.
Go to Conguraon → Event → Smart Event , select Fire and Smoke Detecon.
2.
Check Enable Fire and Smoke Detecon.
3.
Refer to
Detecon Mode and Applicaon Scene for seng the re detecon mode.
4.
Check Display Fire Source Frame on Stream to display a red frame around the re source on
stream when re occurs.
5.
Seng the parameters of re detecon.
Detecon Mode
by Single Frame
It can quickly detect re while moving, but have a high false posive rate.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
18
Adjust Sensivity during Patrol. The bigger the value is, the more easily the re source can
be detected, and the false rate is higher.
by Mulple Frame
The system stops to check the doubul re source aer rst detecon. It alarms with high
accuracy aer double checking the re source on mulple frames, thus the detecon speed
is slow.
As to the detecon sensivity of this mode, adjust the Sensivity during Patrol for the rst
detecon and Vericaon Sensivity for the double check.
In this detecon mode, Smoke Auxiliary Detecon can also be used to help verify the re
source.
Check Cancel Repeated Alarm and the device alarms only one me if re source detected in
the same place during one day.
Smoke Auxiliary Detecon
The device conducts smoke detecon to verify the re source. It can be congured when the
detecon mode is selected as by Mulple Frame.
Cancel Repeated Alarm
Alarm only one me if re source detected in the same place. It can be congured when the
detecon mode is selected as by Mulple Frame.
Sensivity
The sensivity of re detecon. The bigger the value is, more easily the re source can be
detected, and the false rate is higher.
Hold-and-Alarm Mode
Auto and Manual are selectable. The system will stop when it detects the re source. You can
set the duraon while it keeps sll.
Auto
You can set the dwell me. During the dwell me the camera stays sll where it detects the
re source when performing auto scan, patrol, paern, scheduled task, and park acon.
Manual
The device stays sll where it detects the re source, unl you manually
Fire Source Zoom Rao
Auto
The opcal channel changes its zoom rao unl the thermal channel has the same eld of
view.
Manual
You can set the opcal zoom rao.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
19
Note
The sengs vary according to dierent models.
6.
Oponal: You can shield certain areas from being detected in re source detecon. Refer to Set
Fire Source Shielded Region for details.
7.
Refer to Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage method.
8.
Click Save.
4.5.1 Set Fire Source Shielded Region
Steps
1.
Go to Conguraon → Local , and enable Display Shield Area.
2.
Go to Conguraon → Event → Smart Event → Fire Source Region Shield .
3.
Check Enable Fire Source Detecon Shield.
4.
Select Drawing Mode, and draw the area you want to shield.
In FOV Select this mode if the shielded area is in the current scene.
a. Click the PTZ control buons to nd the area you want to shield from the
re detecon.
b. Click Draw Area, and drag the mouse in the live view to draw the area.
c. You can drag the corners of the red rectangle area to change its shape and
size.
d. Click Stop Drawing to nish drawing, or click Clear All to clear all of the
areas you set without saving them.
Out FOV Select this mode if the shielded area exceeds the current scene.
a. Click Draw Area, and a red cursor displays in live view.
b. Select Vertex NO. 1, and adjust the live view image by clicking the PTZ
control buons.
c. When one corner of the shielded area is on the red cursor, click Set Vertex.
d. Repeat steps b-c to set other three vertexes.
e. Click Stop Drawing to nish drawing, or click Clear All to clear all of the
vertexes you set.
In
Panorama
Map
Select this mode if you want to view the whole scene.
a. Click Draw Area and drag the mouse in the live video window to draw the
area.
b. Drag the corners of the red rectangle area to change its shape and size.
c. Click Stop Drawing to nish drawing or click Clear All to clear all of the areas
you set without saving them.
d. Click
to regenerate the panorama map.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
20
Note
●
Set vertexes clockwise or anclockwise in sequence.
●
The pan angle of set area should be from 2 to 80 degrees, and lt angle should be from 1 to
45 degrees.
●
Draw four vertexes again if you want to change the shielded area.
●
When you select In Panorama Map from the drop-down list but the generaon of panorama
map failed, click Regenerang Panorama Map... to regenerate it.
●
In the In Panorama Map mode, the pan angle and lt angle of the set area should be within
± 60°.
5.
Check Display Shield Area to show the shield area on the live view.
6.
Click Add to save the re detecon shield, and it will be listed in the Fire Source Detecon
Shield List area; you can select a region and click Delete to delete it from the list; you can also
dene the color of the regions.
7.
Click Save.
Note
This funcon varies according to dierent camera models.
4.6 Set Smoke Detecon Parameters
To avoid the potenal smoke damage, you should congure the smoke detecon funcon for
certain areas. The detail conguraon steps show as below.
Steps
1.
Go to Conguraon → Event → Smart Event , select Fire and Smoke Detecon.
2.
Check Enable Fire and Smoke Detecon.
3.
Refer to
Detecon Mode and Applicaon Scene for seng the smoke detecon mode.
4.
Check Display Smoke Info on Stream to display the smoke informaon on stream.
5.
Check Cancel Repeated Alarm to alarm only one me if smoke detected in the same place.
6.
Set the Sensivity during Patrol and Vericaon Sensivity of smoke detecon. The higher the
value is, the more easily the smoke can be detected, and the false alarm rate is higher.
7.
Oponal: you can shield certain areas from being detected in smoke detecon.
1) Go to Conguraon → Event → Smart Event → Smoke Detecon Shield .
2) Check Enable Smoke Detecon Shield .
3) Click Draw Area and drag the mouse in the live view to draw the area. Release the mouse to
nish drawing.
4) You can drag the corners of the red rectangle area to change its shape and size. Or drag the
rectangle to the posion on your demand.
5) Click Stop Drawing.
6) Click Clear All to clear all of the seng areas.
7) Set the value of Acve Zoom Rao on your demand, and then the shield will only appear
when the zoom rao is greater than the predened value
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
21
8) Click Add to save the smoke detecon shield, and it will be listed in the Smoke Detecon
Shield List area. You can select a region and click Delete to delete it from the list. You can also
dene the color of the regions.
9) Check Display Shield Region to show the shielded area in live view.
8.
Refer to Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage method.
9.
Click Save.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
22
Chapter 5 Perimeter Protecon
The perimeter protecon funcon is used to detect whether there is any target break the VCA
rules. The opcal camera will track the target or the device will alarm when the VCA rule is
triggered.
5.1 Flow Chart of Perimeter Protecon
The process of conguring the perimeter protecon funcon is described below.
Figure 5-1 Flow Chart of Perimeter Protecon Conguraon
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
23
5.2 Set VCA Parameters
Steps
1.
Go to Conguraon → Local .
Rules
Enable it to display rules informaon on live view.
Display Rules Info. on Capture
Select Yes to display rules informaon on the capture.
2.
Go to Conguraon → VCA .
3.
Select the camera channel.
4.
Go to Basic Sengs to congure VCA parameters for the channel.
Display VCA Info. on Stream
Select to display target info and rule on stream, the informaon will be added to the video
stream, and the overlay will be displayed if you get live view or play back by the VS Player.
Display Target Info. on Alarm Picture
Select to display the target informaon on the alarm picture.
Display Rule Info. on Alarm Picture
Select to display the rule informaon on the alarm picture.
Snapshot Sengs
Select to upload the picture to the surveillance center when the VCA alarm occurs. You can
also set the quality of the picture.
5.
Click Save.
5.3 Congure the Perimeter Protecon
This secon is the detailed instrucon of conguring the perimeter protecon rules.
Steps
1.
Go to Conguraon → VCA , and select a camera channel to start conguraon.
2.
Refer to
Set Detecon Scenes and Tracking for detecon scene and tracking sengs.
3.
Refer to Set Rules to set the scene rules.
4.
Refer to Set the Scene Auto-Switch for seng scene patrol.
5.
Go to Conguraon → VCA → Camera 02 → Basic Sengs , enable Intelligent Analysis.
6.
Click Save.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
24
5.3.1 Set Detecon Scenes and Tracking
Mulple detecon scenes are supported for both channels. You can create scenes and set the
tracking parameters for beer target monitoring performance.
Steps
1.
Go to Conguraon → VCA , and select a camera channel.
2.
Click Scene Conguraon and New Scene to create one or more scenes.
3.
Select a numbered scene from the navigaon bar on the le and enter a Scene Name.
Note
If you want to show the name on the image, check Display Scene Name.
4.
Select the type of the scene.
Note
The congured rules in current scene will be cleared if you modify the type.
5.
Check Track to enable the target tracking funcon for the scene.
6.
Oponal: Check Limited Tracking and set the auto tracking range.
The camera channel tracks a target only within the set auto tracking range.
1) Control the PTZ buons to a desired scene and click Set Up Limit to save the posion as the
scene's upper boundary.
2) Repeat to set the le, right and lower boundaries of the scene.
7.
Set other tracking parameters.
Tracking Duraon
Set the duraon of tracking. If the value is selected as 0, the tracking duraon will not be
limited.
Zooming Rao
It is the zoomed-in level when the camera channel is tracking a target.
Go to Conguraon → VCA → Zooming Rao , select a scene from the drop-down list, and
control the zoom in/out buons to get a desired zooming level, and save the sengs.
Post-tracking
Set the duraon of automac tracking of the target aer it stops.
Go to Conguraon → VCA → Advanced Conguraon , and set parameter.
8.
Click Save.
5.3.2 Set Rules
The device can detect whether there is any target breaking the VCA rules. The opcal camera will
track the target or the device will alarm when the VCA rule is triggered.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
25
Steps
1.
Go to Conguraon → VCA → Scene Conguraon → Scene x → Rule .
2.
Click to add a new rule.
3.
Enter the rule name, and click the drop down menu to select Rule Type.
Note
Each scene can be congured with dierent rule types. Up to 8 rules can be set for one scene.
Line Crossing
If any target move across the seng line, the alarm will be triggered. You can set the crossing
direcon.
Intrusion
If any target intrude into the pre-dened region longer than the set duraon, the alarm will
be triggered.
Region Entrance
If any target enters the pre-dened region, the alarm will be triggered.
Region Exing
If any target exits the pre-dened region, the alarm will be triggered.
4.
Set parameters of the rule.
-
Sensivity
The higher the value is, the more easily the alarm can be triggered.
Target Detecon
You are recommended to select the target as Human & Vehicle. In distant view, the device
cannot classify the target with pixels less than 10*10. The target will be recognized as
human directly. So the selecon of this item will not trigger false alarm or missing alarm.
Background Interference Suppression
Eliminate the environment interference to reduce the false alarm. For example, the wind
blows grass.
5.
Draw the rules.
-
When the rule type is selected as Line Crossing, click
to draw a line in the live view. You can
drag end points of the line to adjust the posion and length.
Line Crossing
You can set the crossing direcon. Bidireconal, A-to-B, or B-to-A are selectable.
-
When the rule type is selected as Intrusion, Region Entrance, Region Entrance, click
to
draw an area in the live view. Right click the mouse to nish drawing.
Duraon
The device performs perimeter protecon when the target stays in the detecon area for
more than set value.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
26
Note
Draw three segments of the rule from near to far to cover all of the detecon area.
6.
Check to enable Filter by Pixel. Then Draw max size and min size rectangles to lter the target
among human, vehicle, animal, and others. Only the target whose size is between the Max. Size
and Min. Size value will trigger the alarm.
Note
●
You can draw the max. size and min. size rectangles according to the real target in the scene.
The recommended size is 1.2 mes of the target.
●
The height of the rectangle is a more important factor as it is the main dierence to tell apart
a human and an animal.
●
Click to copy the same sengs to other rules.
7.
Click Save.
8.
Refer to Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage method.
5.3.3 Set the Scene Auto-Switch
The device support patrol tracking for mulple important scenes. The alarm will be triggered if the
rule is broken during patrol sequence.
Before You Start
Finish scene sengs in advance. See
Set Detecon Scenes and Tracking for conguraon
instrucons.
Steps
1.
Go to VCA → Scene Auto-Switch to congure this funcon.
2.
Set the scene patrol sequence.
Scene Name
Select a scene name from the drop down list.
Duraon
Set the dwell me of the scene when doing patrol tracking.
3.
Click the up, down arrow to adjust the patrol sequence.
4.
Click Save.
5.3.4 Set Polling Plan
Both the opcal channel and the thermal channels support the perimeter protecon. Set the
working shi for each channel.
Before You Start
The detecon scenes and rules should be congured in advance for both channels.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
27
Steps
1.
Go to Conguraon → VCA → Camera 01/Camera 02 → Basic Sengs → Polling Plan .
2.
Select a polling mode.
Auto The device automacally acvates the opcal channel for perimeter protecon in
dayme and the thermal channel at night.
Manual You can manually set the working shis for the channels.
a. Select the Polling Mode as Manual.
b. Select Opcal Channel or Thermal Channel for the drop-down list.
c. Drag to draw me bars on the schedule. Click on the drawn bar to adjust the
me and the channel.
Note
The schedule for the channels cannot overlap.
3.
Click Save.
5.4 Advanced Conguraon
Go to Conguraon → VCA → Advanced Conguraon and congure the parameters.
Detecon Parameters
Single Alarm
The system only sends alarm once for one target triggering. Otherwise, the alarm will be
triggered connuously unl the target disappears.
Scene Modes
The scene mode is set to be General by default. Select Distant View when you are far from the
targets. Select Leaves Interfered View when there are shaking targets in the scene, such as
leaves.
Tracking Parameters
Post-tracking
Set the duraon of automac tracking of the target aer it stops. E.g., set post-tracking duraon
to 10s, the camera tracks the target unl that it stop and has been sll for over 10s.
Back to Scene Time
Set the duraon of the camera moving back to original scene aer perimeter protecon is
started.
Restore Parameters
Restore Default
Click Restore to restore the parameters to the default.
Restart VCA
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
28
Click Restart to restart the VCA funcon.
Note
The sengs vary according to dierent models.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
29
Chapter 6 Event and Alarm
This part introduces the conguraon of events. The device takes certain response to triggered
alarm. Certain events may not be supported by certain device models.
6.1 Set Moon Detecon
It helps to detect the moving objects in the detecon region and trigger the linkage acons.
Steps
1.
Go to Conguraon → Event → Basic Event → Moon Detecon .
2.
Select the channel No.
3.
Check Enable Moon Detecon.
4.
Oponal: Highlight to display the moving object in the image in green.
1) Check Enable Dynamic Analysis for Moon.
2) Go to Conguraon → Local .
3) Set Rules to Enable.
5.
Select Conguraon Mode, and set rule region and rule parameters.
-
For the informaon about normal mode, see
Normal Mode .
-
For the informaon about expert mode, see
Expert Mode .
6.
Set the arming schedule and linkage methods. For the informaon about arming schedule
sengs, see Set Arming Schedule . For the informaon about linkage methods, see Linkage
Method Sengs .
7.
Click Save.
6.1.1 Normal Mode
You can set moon detecon parameters according to the device default parameters.
Steps
1.
Select normal mode in Conguraon.
2.
Set the sensivity of normal mode. The higher the value of sensivity is, the more sensive the
moon detecon is. If the sensivity is set to 0, moon detecon and dynamic analysis do not
take eect.
3.
Click Draw Area. Click and drag the mouse on the live video, then release the mouse to nsh
drawing one area.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
30
Figure 6-1 Set Rules
Stop Drawing Stop drawing one area.
Clear All Clear all the areas.
4.
Oponal: You can set the parameters of mulple areas by repeang the above steps.
6.1.2 Expert Mode
You can congure the moon detecon parameters of day/night switch according to the actual
needs.
Steps
1.
Select expert mode in Conguraon.
2.
Set parameters of expert mode.
Day/Night Switch
OFF: Day/Night switch is disabled.
Day/Night Auto-Switch: The system switches day/night mode automacally according to
environment. It displays colored image at day and black and white image at night.
Day/Night Scheduled-Switch: The system switches day/night mode according to the schedule.
It switches to day mode during the set periods and switches to night mode during the other
periods.
Note
This funcon is not supported in the expert mode of thermal channel.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
31
Sensivity
The higher the value of sensivity is, the more sensive the moon detecon is. If the
sensivity is set to 0, moon detecon and dynamic analysis do not take eect.
3.
Select an Area and click Draw Area. Click and drag the mouse on the live video, then release the
mouse to nish drawing one area.
Figure 6-2 Set Rules
Stop Drawing Finish drawing one area.
Clear All Delete all the areas.
4.
Oponal: Repeat the above steps to set mulple areas.
6.2 Set Video Tampering Alarm
When the congured area is covered and cannot be monitored normally, the alarm is triggered and
the device takes certain alarm response acons.
Steps
1.
Go to Conguraon → Event → Basic Event → Video Tampering .
2.
Select the channel number.
3.
Check Enable.
4.
Set the Sensivity. The higher the value is, the easier to detect the area covering.
5.
Click Draw Area and drag the mouse in the live view to draw the area.
Stop Drawing Finish drawing.
Clear All Delete all the drawn areas.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
32
Figure 6-3 Set Video Tampering Area
6.
Refer to Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage method.
7.
Click Save.
6.3 Set Alarm Input
Alarm signal from the external device triggers the corresponding acons of the current device.
Before You Start
Note
This funcon is only supported by certain models.
Make sure the external alarm device is connected. See Quick Start Guide for cable connecon.
Steps
1.
Go to Conguraon → Event → Basic Event → Alarm Input .
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
33
2.
Check Enable Alarm Input Handling.
3.
Select Alarm Input NO. and Alarm Type from the dropdown list. Edit the Alarm Name.
4.
Refer to Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage method.
5.
Click Copy to... to copy the sengs to other alarm input channels.
6.
Click Save.
6.4 Set Excepon Alarm
Excepon such as network disconnecon can trigger the device to take corresponding acon.
Steps
1.
Go to Conguraon → Event → Basic Event → Excepon .
2.
Select Excepon Type.
HDD Full The HDD storage is full.
HDD Error Error occurs in HDD.
Network Disconnected The device is oine.
IP Address Conicted The IP address of current device is same as that of other device in
the network.
Illegal Login Incorrect user name or password is entered.
Voltage Instable The power supply voltage is uctuang.
PT Locking The panning and lng movements are stuck.
3.
Refer to
Linkage Method Sengs for seng linkage method.
4.
Click Save.
6.5 Set Burning-Prevenon
This funcon is used to close the shuer to prevent the lens from high temperature damage.
Steps
1.
Go to Conguraon → Event → Basic Event → Burning-Prevenon .
2.
Check Enable.
3.
Select burning-prevenon mode.
Lens Movement
The lens move automacally to avoid high temperature damage.
4.
Set the protecon duraon and protecon delay.
5.
Click Save.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
34
6.6 Detect Audio Excepon
Audio excepon detecon funcon detects the abnormal sound in the scene, such as the sudden
increase/decrease of the sound intensity, and some certain acons can be taken as response.
Steps
1.
Go to Conguraon → Event → Smart Event → Audio Excepon Detecon .
2.
Select one or several audio excepon detecon types.
Audio Loss Detecon
Detect sudden loss of audio track.
Sudden Increase of Sound Intensity Detecon
Detect sudden increase of sound intensity. Sensivity and Sound Intensity Threshold are
congurable.
Note
●
The lower the sensivity is, the more signicant the change should be to trigger the
detecon.
●
The sound intensity threshold refers to the sound intensity reference for the detecon. It is
recommended to set as the average sound intensity in the environment. The louder the
environment sound, the higher the value should be. You can adjust it according to the real
environment.
Sudden Decrease of Sound Intensity Detecon
Detect sudden decrease of sound intensity. Sensivity is congurable.
3.
Refer to Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage methods.
4.
Click Save.
Note
The funcon varies according to dierent models.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
35
Chapter 7 Arming Schedule and Alarm Linkage
Arming schedule is a customized me period in which the device performs certain tasks. Alarm
linkage is the response to the detected certain incident or target during the scheduled me.
7.1 Set Arming Schedule
Set the valid me of the device tasks.
Steps
1.
Click Arming Schedule.
2.
Drag the me bar to draw desired valid me.
Note
Up to 8 periods can be congured for one day.
3.
Adjust the me period.
-
Click on the selected me period, and enter the desired value. Click Save.
-
Click on the selected me period. Drag the both ends to adjust the me period.
-
Click on the selected me period, and drag it on the me bar.
4.
Oponal: Click Copy to... to copy the same sengs to other days.
5.
Click Save.
7.2 Linkage Method Sengs
You can enable the linkage funcons when an event or alarm occurs.
7.2.1 Trigger Alarm Output
If the device has been connected to an alarm output device, and the alarm output No. has been
congured, the device sends alarm informaon to the connected alarm output device when an
alarm is triggered.
Steps
Note
This funcon is only supported by certain models.
1.
Go to Conguraon → Event → Basic Event → Alarm Output .
2.
Set alarm output parameters.
Automac Alarm For the informaon about the conguraon, see
Automac Alarm .
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
36
Manual Alarm For the informaon about the conguraon, see Manual Alarm .
3.
Click Save.
Manual Alarm
You can trigger an alarm output manually.
Steps
1.
Set the manual alarm parameters.
Alarm Output No.
Select the alarm output No. according to the alarm interface connected to the external alarm
device.
Alarm Name
Edit a name for the alarm output.
Delay
Select Manual.
2.
Click Manual Alarm to enable manual alarm output.
3.
Oponal: Click Clear Alarm to disable manual alarm output.
Automac Alarm
Set the automac alarm parameters, then the device triggers an alarm output automacally in the
set arming schedule.
Steps
1.
Set automac alarm parameters.
Alarm Output No.
Select the alarm output No. according to the alarm interface connected to the external alarm
device.
Alarm Name
Custom a name for the alarm output.
Delay
It refers to the me duraon that the alarm output remains aer an alarm occurs.
2.
Set the alarming schedule. For the informaon about the sengs, see
Set Arming Schedule .
3.
Click Copy to… to copy the parameters to other alarm output channels.
4.
Click Save.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
37
7.2.2 FTP/NAS/Memory Card Uploading
If you have enabled and congured the FTP/NAS/memory card uploading, the device sends the
alarm informaon to the FTP server, network aached storage and memory card when an alarm is
triggered.
Refer to Set FTP to set the FTP server.
Refer to Set NAS for NAS conguraon.
Refer to Set Memory Card for memory card storage conguraon.
7.2.3 Send Email
Check Send Email, and the device sends an email to the designated addresses with alarm
informaon when an alarm event is detected.
For email sengs, refer to Set Email .
Set Email
When the email is congured and Send Email is enabled as a linkage method, the device sends an
email nocaon to all designated receivers if an alarm event is detected.
Before You Start
Set the DNS server before using the Email funcon. Go to Conguraon → Network → Basic
Sengs → TCP/IP for DNS sengs.
Steps
1.
Go to email sengs page: Conguraon → Network → Advanced Sengs → Email .
2.
Set email parameters.
1) Input the sender's email informaon, including the Sender's Address, SMTP Server, and
SMTP Port.
2) Oponal: If your email server requires authencaon, check Authencaon and input your
user name and password to log in to the server.
3) Set the E-mail Encrypon.
●
When you select SSL or TLS, and disable STARTTLS, emails are sent aer encrypted by SSL or
TLS. The SMTP port should be set as 465.
●
When you select SSL or TLS and Enable STARTTLS, emails are sent aer encrypted by
STARTTLS, and the SMTP port should be set as 25.
Note
If you want to use STARTTLS, make sure that the protocol is supported by your email server.
If you check the Enable STARTTLS while the protocol is not supported by your email sever,
your email is sent with no encrypon.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
38
4) Oponal: If you want to receive nocaon with alarm pictures, check Aached Image. The
nocaon email has 3 aached alarm pictures about the event with congurable image
capturing interval.
5) Input the receiver's informaon, including the receiver's name and address.
6) Click Test to see if the funcon is well congured.
3.
Click Save.
7.2.4 Nofy Surveillance Center
Check Nofy Surveillance Center, the alarm informaon is uploaded to the surveillance center
when an alarm event is detected.
7.2.5 Trigger Recording
Check Trigger Recording, and the device records the video about the detected alarm event.
For device with more than one camera channels, you can set one or more channels to take
recordings if needed.
For recording sengs, refer to Video Recording and Picture Capture .
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
39
Chapter 8 PTZ
PTZ is an abbreviaon for pan, lt, and zoom. It means the movement opons of the camera.
8.1 PTZ Control
In live view interface, you can use the PTZ control buons to control the device panning, lng,
and zooming.
PTZ Control Panel
Click and hold the direconal buon to pan/lt
the device.
Note
●
You can set Keyboard Control Speed in
Conguraon → PTZ → Basic Sengs . The
speed of pan/lt movement in live view is
based on this speed level.
●
You can set Max. Tilt-angle in Conguraon
→ PTZ → Basic Sengs to limit lt
movement range.
Click the buon, then the device keeps panning.
Note
You can set Auto Scan Speed in Conguraon
→ PTZ → Basic Sengs . The higher the value
you set, the faster the device pans.
Drag the slider to adjust the speed of pan/lt
movement.
Note
●
You can set Manual Control Speed in Conguraon → PTZ → Basic Sengs .
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
40
Compable The control speed is same as Keyboard Control
Speed.
Pedestrian Choose Pedestrian when you monitor the
pedestrians.
Non-motor Vehicle Choose Non-motor Vehicle when you monitor
the non-motor vehicles.
Motor Vehicle Choose Motor Vehicle when you monitor the
motor vehicles.
Auto You are recommended to set it as Auto when
the applicaon scene of the speed dome is
complicated.
●
To avoid blurred image resulted from fast zoom, you can check Enable Proporonal Pan in
Conguraon → PTZ → Basic Sengs . If you enable this funcon, the pan/lt speed change
according to the amount of zoom. When there is a large amount of zoom, the pan/lt speed will
be slower for keeping the image from moving too fast on the live view image.
Zoom in/out
Click the buon, and the lens zooms in.
Click the buon, and the lens zooms out.
Note
●
You can set Zooming Speed in Conguraon → PTZ → Basic Sengs . The higher the value is,
the faster the zooming speed is.
●
You can set Zoom Limit in Conguraon → Image → Display Sengs → Other to limit the
maximum value of the total zoom (digital zoom and opcal zoom).
●
You can set Synchronized Zoom in Conguraon → PTZ → Basic Sengs to synchronize the
zoom sengs in the opcal channel and the thermal channel.
Focus
Click the buon, then the lens focuses near and
the object nearby gets clear.
Click the buon, then the lens focuses far and
the object far away gets clear.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
41
Iris
When the image is too dark, click the buon to
enlarge the iris.
When the image is too bright, click the buon
to stop down the iris.
8.2 Set Preset
A preset is a predened image posion. For the dened preset, you can call the preset No. to view
the posion.
Steps
1.
Click to show the seng panel, and click .
2.
Use the PTZ control buons to move the lens to the desired posion.
3.
Select a preset number from the preset list, and click to nish the seng.
Note
Some presets are predened with special command. You can only call them but not congure
them.
4.
Repeat the steps above to set mulple presets.
Click the buon to call the preset.
Click the buon to delete the preset.
Note
You can delete all presets in Conguraon → PTZ → Clear Cong . Click Clear All Presets, and
click Save.
What to do next
Go to Conguraon → PTZ → Basic Sengs to set preset freezing and preset speed.
Aer enabling preset freezing, the live image switches directly from one preset to another, without
showing the areas between these two scenes. It also guarantees the masked area will not be seen
when the device is moving.
8.2.1 Special Presets
You can call the following presets with special demands to enable corresponding funcons.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
42
Preset No. Funcon Preset No. Funcon
33 Auto Flip 92 Set manual limits
34 Back to origin 93 Save manual limits
35 Call patrol 1 94 Remote restart
36 Call patrol 2 95 Call OSD menu
37 Call patrol 3 96 Stop a scan
38 Call patrol 4 97 Start random scan
39 Day mode 98 Start frame scan
40 Night mode 99 Start auto scan
41 Call paern 1 100 Start lt scan
42 Call paern 2 101 Start panorama scan
43 Call paern 3 102 Call patrol 5
44 Call paern 4 103 Call patrol 6
45 One-touch patrol 104 Call patrol 7
46 Call area scan 105 Call patrol 8
47 Call area scan 1
Note
Not all models support the presets above. Please take the actual product for reference.
8.3 Set Patrol Scan
Patrol scan is a funcon to automacally move among mulple presets.
Before You Start
Note
This funcon is only supported by certain models.
Make sure that you have dened more than one presets. See Set Preset for detailed conguraon.
Steps
1.
Click
to show the seng panel, and click to enter patrol seng interface.
2.
Select a patrol number from the list and click .
3.
Click to add presets.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
43
Preset
Select predened preset.
Speed
Set the speed of moving from one preset to another.
Time
It is the duraon staying on one patrol point.
Delete the presets in patrol.
Adjust the preset order.
Note
A patrol can be congured with 32 presets at most, and 2 presets at least.
4.
Click OK to nish a patrol seng.
5.
Repeat the steps above to congure mulple patrols.
6.
Operate patrols.
Call the patrol.
Stop patroling.
Delete the patrol.
Set the patrol.
Note
You can delete all patrols in Conguraon → PTZ → Clear Cong . Click Clear All Patrols, and
click Save.
8.3.1 Set One-Touch Patrol
The device automacally adds presets to one patrol path and starts patrol scan.
Steps
1.
Set two or more presets except special presets. For seng presets, refer to Set Preset .
The device will automacally add presets to patrol path No.8.
2.
Choose one of the following methods to enable the funcon.
-
Click
.
-
Call patrol path No.8.
-
Select and call preset No.45.
8.4 Set Paern Scan
The device can move as the recorded paern.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
44
Steps
Note
This funcon is only supported by certain models.
1.
Click to show the PTZ control panel, and click .
2.
Select one paern scan path that needs to be set.
3.
Click to start recording paern scan.
4.
Click PTZ control buons as demands.
Note
Recording stops when the space for paern scan is 0%.
5.
Click to complete one paern scan path sengs.
6.
Click to call paern scan.
Stop paern scan.
Reset paern scan path.
Delete the selected paern scan.
Note
If you need to delete all the paern scans, go to Conguraon → PTZ → Clear Cong , and
check Clear All Paerns, and click Save.
8.5 Set Linear Scan
The device can perform auto scan in seng area for re source detecon.
Steps
1.
Go to Conguraon → PTZ → Linear Scan .
2.
Select the camera channel.
3.
Zoom in and zoom out the camera to the appropriate zoom rao, and click Save Rao.
Note
Click Enable Saved Rao to set the camera to the saved zoom rao.
4.
Check Enter Area Sengs.
5.
Set the le/right/up/down limits with the PTZ control panel, and click
to conrm sengs.
6.
Oponal: Click Clear to delete the saved scan area.
7.
Click Save.
8.
Click Call Linear Scan to start linear scan, and click Stop Linear Scan to stop linear scan.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
45
Note
When seng the linear scan area, make sure the target area is both included in the opcal
channel and the thermal channel.
8.6 Set Limit
The device can only move within the limited range.
Steps
1.
Go to Conguraon → PTZ → Limit .
2.
Select Limit Type.
Manual Stops
It refers to the movement range limit when you control the device manually.
Scan Stops
It refers to the movement range limit when the device scans automacally.
Note
Scan limit is only supported by the device that has scan funcon.
3.
Click Set and set limits according to the prompt on the live image.
4.
Oponal: Click Clear to clear the limit sengs of the selected mode.
5.
Click Save.
6.
Check Enable Limit.
Note
If you need to cancel all the set patrol paths, go to Conguraon → PTZ → Clear Cong , select
Clear All PTZ Limited, and click Save.
Result
The device can only move within the set region aer saving the sengs.
8.7 Set Inial Posion
Inial posion refers to the relave inial posion of the device azimuth. You can set the inial
posion if you need to select one point in the scene as the base point.
Steps
1.
Go to Conguraon → PTZ → Inial Posion .
2.
Move the device to the needed posion by manually controlling the PTZ control buons.
3.
Click Set to save the informaon of inial posion.
Call The device moves to the set inial posion.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
46
Clear Clear the set inial posion.
8.8 Set Park Acon
You can set the device to perform an acon (for example, preset or patrol) or return to a posion
aer a period of inacvity (park me).
Before You Start
Set the acon type rst. For example, if you want to select patrol as park acon, you should set the
patrol. See Set Patrol Scan for details.
Steps
1.
Go to Conguraon → PTZ → Park Acon .
2.
Check Enable Park Acon.
3.
Set Park Time: the inacve me before the device starts park acon.
4.
Select Acon Type according to your needs.
Note
The VCA Type varies according to dierent acon types.
5.
Select an Acon Type ID, if you select patrol or preset as acon type.
When the acon type is patrol, acon type ID stands for patrol No. When the acon type is
preset, acon type ID stands for preset No.
6.
Click Save.
8.9 Set Privacy Mask
Privacy masks cover certain areas on the live image to protect personal privacy from being live
viewed and recorded.
Steps
1.
Go to Conguraon → PTZ → Privacy Mask .
2.
Select a channel.
3.
Adjust the live image to the target scene via PTZ control buons.
4.
Draw the area.
Draw Area Click Draw Area, and click on the live view
image to determine the boundary of the mask.
Stop Drawing Click Stop Drawing aer drawing the mask.
5.
Click Add.
It is listed in Privacy Mask List.
6.
Edit Name, Type, and Acve Zoom Rao on your demand.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
47
Acve Zoom Rao
When the actual zoom rao is less than the set acve zoom rao, the set area cannot be
covered. When the actual zoom rao is greater than the set acve zoom rao, the privacy
mask is valid. The maximum value of acve zoom rao depends on the camera module.
Note
Acve zoom rao is only supported for the PTZ channel.
7.
Repeat the steps above to set other privacy masks.
8.
Check Enable Privacy Masks.
8.10 Set Scheduled Tasks
You can set the device to perform a certain task during a certain period.
Steps
1.
Go to Conguraon → PTZ → Scheduled Tasks .
2.
Check Enable Scheduled Task.
3.
Select the task type from the drop-down list and draw a me bar on the schedule table.
4.
Click the set me bar and set the acon ID and smart event or VCA type.
Note
Not all task types support the sengs of acon ID and smart event or VCA funcon. Please take
the actual product for reference.
5.
Repeat step 3 and step 4 to set more than one scheduled tasks.
6.
Set Park Time. During the set task period, if you operate the device manually, the scheduled task
will be suspended. When the manual operaon is over, the device will connue to perform the
scheduled task aer the set park me.
Note
Up to 30 me periods can be congured per day.
7.
Click Save.
Note
If you want to clear all scheduled tasks, go to Conguraon → PTZ → Clear Cong , check Clear
All Scheduled Tasks, and click Save.
8.11 Set Combined Path
It oers the opon to add mulple types of VCA scanning tasks to one combinaon path. Seng
the combined path as a scheduled task or a park acon is convenient to manage mulple VCA
funcons in dierent circumstances.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
48
Before You Start
Note
This funcon is only supported by certain models.
Finish seng the desired acons (Linear Scan and Patrol are available) and VCA funcons (Fire
Detecon is available). See Set Linear Scan , Set Patrol Scan , and Fire and Smoke Detecon for
conguraon instrucons.
Steps
1.
Go to Conguraon → PTZ → Combined Path .
2.
Select a channel.
3.
Select a path number from the drop-down list.
Up to 4 paths are available.
4.
Click Add, and set the acon type, acon No. and VCA type for the added acon.
Up to 10 acons can be added to one path.
You can click ON to manually call the path and OFF to stop it.
5.
Click Save.
What to do next
Set the combined path in park acon (see Set Park Acon ) or scheduled task (see Set Scheduled
Tasks ).
8.12 Set Device Posion
Before You Start
Go to Conguraon → PTZ → Basic Sengs → PTZ OSD to enable PT Status display.
Steps
1.
Go to the seng page: Conguraon → PTZ → Posion Sengs .
2.
Select a PT Mode.
Manual Use a direcon indicang device to determine the North at the device locaon, and
set the North for the device. For details, see
Set Manual Compass .
Auto For the device that has built-in e-compass, the compass can automacally tell the
north direcon for the device. For details, see
Set Auto Compass .
3.
Oponal: Check Display Posion Diagram to display the posion diagram on the live view.
4.
Set Vandal-proof alarm.
Aer enabling the funcon, the device triggers alarms once its posion changes because of
shock or vandalism.
Sensivity
The higher the value is, the easier the alarm will be triggered.
Upload Vandal-proof Alarm
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
49
The device uploads the alarm informaon when the alarm is triggered.
5.
Get the device locaon informaon in advance, and input the longitude and latude of the
device manually.
6.
Click Save.
What to do next
If you lost direcon when operang the device, you can click Point to North to call the north
posion that is saved in the device.
8.12.1 Set Manual Compass
Use a direcon indicang device to determine the North at the device locaon, and set the North
for the device.
Before You Start
Use a direcon indicang device to determine the north at the device locaon.
Steps
1.
Select the PT Mode as Manual.
2.
Adjust the lt posion of the device to 0 by controlling the up arrow and down arrow on the PTZ
panel.
3.
Adjust the pan posion to show the live view of the north direcon by controlling the le arrow
and right arrow on the PTZ panel.
4.
Click Set as North.
8.12.2 Set Auto Compass
For the device that has built-in e-compass, the compass can automacally tell the north direcon
for the device.
Before You Start
Electromagnec interference may aect the accuracy of the e-compass. Use manual compass if
electromagnec interference occurs in the device installaon environment.
Steps
1.
Select the PT Mode as Auto.
2.
Click Calibrate to synchronize the north of the device with that of the e-compass.
8.13 Set Power O Memory
This funcon can resume the previous PTZ status of device aer it restarng from a power-o.
Steps
1.
Go to Conguraon → PTZ → Basic Sengs .
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
50
2.
Select Resume Time Point. When the device stays at one posion for the set resume me point
or more, the posion is saved as a memory point. The device returns to the last memory point
when it restarts.
3.
Click Save.
8.14 Set PTZ Priority
The funcon can set the PTZ priority of dierent signals.
Steps
1.
Go to Conguraon → PTZ → Priorize PTZ .
2.
Set the priority signal and delayed me.
Network
The network signal controls the device with priority.
RS-485
The RS-485 signal controls the device with priority.
Delay
It refers to the me interval of PTZ operaon controlled by dierent signals. When the
operaon with high priority is nished, the low priority signal controls the device aer the
seng interval.
3.
Click Save.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
51
Chapter 9 Live View
It introduces the live view parameters, funcon icons and transmission parameters sengs.
9.1 Live View Parameters
The supported funcons vary depending on the model.
Note
For mulchannel devices, select the desired channel rst before live view sengs.
9.1.1 Window Division
●
refers to 1 × 1 window division.
●
refers to 2 × 2 window division.
●
refers to 3 × 3 window division.
●
refers to 4 × 4 window division.
9.1.2 Live View Stream Type
Select the live view stream type according to your needs. For the detailed informaon about the
stream type selecon, refer to Stream Type .
9.1.3 Enable and Disable Live View
This funcon is used to quickly enable or disable live view of all channels.
●
Click to start live view of all channels.
●
Click to stop live view of all channels.
9.1.4 View Previous/Next Page
When the number of channels surpasses that of live view window division, this funcon can switch
live view among mulple channels.
Click to switch live view among mulple channels.
9.1.5 Full Screen
This funcon is used to view the image in full screen mode.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
52
Click to start full screen mode and press ESC buon to exit.
9.1.6 Conduct Regional Focus
You can enable the funcon to focus on certain area.
Steps
1.
Click to enable regional focus.
2.
Drag the mouse on the live view to draw a rectangle as the desired focus area.
3.
Click to disable this funcon.
9.1.7 Light
Click to turn on or turn o the illuminator.
9.1.8 Wiper
For the device that has a wiper, you can control the wiper via web browser.
Steps
1.
Click on live view page.
The wiper wipes the window one me.
9.1.9 Lens Inializaon
Lens inializaon is used on the device equipped with motorized lens. The funcon can reset lens
when long me zoom or focus results in blurred image. This funcon varies according to dierent
models.
Manual Lens Inializaon
Click
to operate lens inializaon.
Auto Lens Inializaon
Go to Conguraon → System → Maintenance → Lens Correcon to enable this funcon. You
can set the arming schedule, and the device will correct lens automacally during the
congured me periods.
9.1.10 Track Manually
In live view, manually select a target for the device to track.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
53
Note
The funcon may not be supported by certain device models.
Steps
1.
Click on the toolbar of the live view page.
2.
Click a moving object in the live image.
The device tracks the target and keeps it in the center of live view image.
9.1.11 Auxiliary Focus
Click to realize automac focus. This funcon is subject to the actual device model.
9.1.12 Quick Set Live View
It oers a quick setup of PTZ, display sengs, OSD, and video/audio sengs on live view page.
Steps
1.
Click to show quick setup page.
2.
Set PTZ, display sengs, OSD, and video/audio parameters.
-
For PTZ sengs, see
Lens Parameters Adjustment .
-
For display sengs, see
Display Sengs .
-
For OSD sengs, see
OSD .
-
For audio and video sengs, see
Video and Audio .
Note
The funcon is only supported by certain models.
9.1.13 Lens Parameters Adjustment
It is used to adjust the lens focus, zoom and iris.
Zoom
●
Click , and the lens zooms in.
●
Click , and the lens zooms out.
Focus
●
Click , then the lens focuses far and the distant object gets clear.
●
Click , then the lens focuses near and the nearby object gets clear.
PTZ Speed
●
Slide to adjust the speed of the pan/lt movement.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
54
Iris
●
When the image is too dark, click to enlarge the iris.
●
When the image is too bright, click to stop down the iris.
9.1.14 Conduct 3D Posioning
3D posioning is to relocate the selected area to the image center.
Steps
1.
Click to enable the funcon.
2.
Select a target area in live image.
-
Le click on a point on live image: the point is relocated to the center of the live image. With
no zooming in or out eect.
-
Hold and drag the mouse to a lower right posion to frame an area on the live: the framed
area is zoomed in and relocated to the center of the live image.
-
Hold and drag the mouse to an upper le posion to frame an area on the live: the framed
area is zoomed out and relocated to the center of the live image.
3.
Click the buon again to turn o the funcon.
9.1.15 De-icing
Click
to perform manual de-Icing of the device.
9.1.16 Synchronize FOV
Click to synchronize the FOV of opcal lens and thermal lens.
9.2 Set Transmission Parameters
The live view image may be displayed abnormally according to the network condions. In dierent
network environments, you can adjust the transmission parameters to solve the problem.
Steps
1.
Go to Conguraon → Local .
2.
Set the transmission parameters as required.
Protocol
TCP
TCP ensures complete delivery of streaming data and beer video quality, yet the real-me
transmission will be aected. It is suitable for the stable network environment.
UDP
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
55
UDP is suitable for the unstable network environment that does not demand high video
uency.
MULTICAST
MULTICAST is suitable for the situaon that there are mulple clients. You should set the
mulcast address for them before selecon.
Note
For detailed informaon about mulcast, refer to Mulcast .
HTTP
HTTP is suitable for the situaon that the third-party needs to get the stream from the
device.
Play Performance
Shortest Delay
The device takes the real-me video image as the priority over the video uency.
Balanced
The device ensures both the real-me video image and the uency.
Fluent
The device takes the video uency as the priority over teal-me. In poor network
environment, the device cannot ensures video uency even the uency is enabled.
Custom
You can set the frame rate manually. In poor network environment, you can reduce the
frame rate to get a uent live view. But the rule informaon may cannot display.
Auto Start Live View
●
Yes means the live view is started automacally. It requires a high performance monitoring
device and a stable network environment.
●
No means the live view should be started manually.
3.
Click OK.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
56
Chapter 10 Video and Audio
This part introduces the conguraon of video and audio related parameters.
10.1 Video Sengs
This part introduces the sengs of video parameters, such as, stream type, video encoding, and
resoluon.
Go to seng page: Conguraon → Video/Audio → Video .
Note
For device with mulple camera channels, select a channel before other sengs.
10.1.1 Stream Type
For device supports more than one stream, you can specify parameters for each stream type.
Main Stream
The stream stands for the best stream performance the device supports. It usually oers the
best resoluon and frame rate the device can do. But high resoluon and frame rate usually
mean larger storage space and higher bandwidth requirements in transmission.
Sub Stream
The stream usually oers comparavely low resoluon opons, which consumes less bandwidth
and storage space.
10.1.2 Video Type
Select the content (video and audio) that should be contained in the stream.
Video
Only video content is contained in the stream.
Video & Audio
Video content and audio content are contained in the composite stream.
10.1.3 Resoluon
Select video resoluon according to actual needs. Higher resoluon requires higher bandwidth and
storage.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
57
10.1.4 Bitrate Type and Max. Bitrate
Constant Bitrate
It means that the stream is compressed and transmied at a comparavely xed bitrate. The
compression speed is fast, but mosaic may occur on the image.
Variable Bitrate
It means that the device automacally adjust the bitrate under the set Max. Bitrate. The
compression speed is slower than that of the constant bitrate. But it guarantees the image
quality of complex scenes.
10.1.5 Video Quality
When Bitrate Type is set as Variable, video quality is congurable. Select a video quality according
to actual needs. Note that higher video quality requires higher bandwidth.
10.1.6 Frame Rate
The frame rate is to describe the frequency at which the video stream is updated and it is
measured by frames per second (fps).
A higher frame rate is advantageous when there is movement in the video stream, as it maintains
image quality throughout. Note that higher frame rate requires higher bandwidth and larger
storage space.
10.1.7 Video Encoding
It stands for the compression standard the device adopts for video encoding.
Note
Available compression standards vary according to device models.
H.264
H.264, also known as MPEG-4 Part 10, Advanced Video Coding, is a compression standard. Without
compressing image quality, it increases compression rao and reduces the size of video le than
MJPEG or MPEG-4 Part 2.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
58
H.265
H.265, also known as High Eciency Video Coding (HEVC) and MPEG-H Part 2, is a compression
standard. In comparison to H.264, it oers beer video compression at the same resoluon, frame
rate and image quality.
Prole
This funcon means that under the same bitrate, the more complex the prole is, the higher the
quality of the image is, and the requirement for network bandwidth is also higher.
I-Frame Interval
I-frame interval denes the number of frames between 2 I-frames.
In H.264 and H.265, an I-frame, or intra frame, is a self-contained frame that can be independently
decoded without any reference to other images. An I-frame consumes more bits than other
frames. Thus, video with more I-frames, in other words, smaller I-frame interval, generates more
steady and reliable data bits while requiring more storage space.
SVC
Scalable Video Coding (SVC) is the name for the Annex G extension of the H.264 or H.265 video
compression standard.
The objecve of the SVC standardizaon has been to enable the encoding of a high-quality video
bitstream that contains one or more subset bitstreams that can themselves be decoded with a
complexity and reconstrucon quality similar to that achieved using the exisng H.264 or H.265
design with the same quanty of data as in the subset bitstream. The subset bitstream is derived
by dropping packets from the larger bitstream.
SVC enables forward compability for older hardware: the same bitstream can be consumed by
basic hardware which can only decode a low-resoluon subset, while more advanced hardware
will be able decode high quality video stream.
10.1.8 Smoothing
It refers to the smoothness of the stream. The higher value of the smoothing is, the beer uency
of the stream will be, though, the video quality may not be so sasfactory. The lower value of the
smoothing is, the higher quality of the stream will be, though it may appear not uent.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
59
10.1.9 Display VCA Info
VCA informaon can be displayed by Player and Video.
Player
Player means the VCA info can be displayed by the dedicated player provided by the
manufacturer.
Video
Video means the VCA info can be displayed by any general video player.
10.2 Audio Sengs
It is a funcon to set audio parameters such as audio encoding, environment noise ltering.
Go to the audio sengs page: Conguraon → Video/Audio → Audio .
10.2.1 Audio Input
If a built-in microphone or an external audio pick-up device is available, audio encoding, audio
input mode and input volume are congurable.
Audio Encoding
The device oers several compression standard. Select according to your need.
Audio Input
Select MicIn for the built-in microphone, and LineIn for external audio pick-up device.
Note
MicIn is only supported by certain models.
Input Volume
Adjust the volume of the audio input.
Environmental Noise Filter
Set it as OFF or ON. When the funcon is enabled, the noise in the environment can be ltered
to some extent.
10.2.2 Two-way Audio
It is used to realize the two-way audio funcon between the monitoring center and the target in
the monitoring screen.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
60
Before You Start
●
Make sure the audio input device (pick-up or microphone) and audio output device (speaker)
connected to the device is working properly. Refer to specicaons of audio input and output
devices for device connecon.
●
If the device has built-in microphone and speaker, two-way audio funcon can be enabled
directly.
Steps
1.
Click Live View.
2.
Click on the toolbar to enable two-way audio funcon of the camera.
3.
Click and select , move the slider to adjust the volume.
4.
Click , disable the two-way audio funcon.
10.3 Set ROI
ROI (Region of Interest) encoding helps to assign more encoding resource to the region of interest,
thus to increase the quality of the ROI whereas the background informaon is less focused.
Before You Start
Please check the video coding type. ROI is supported when the video coding type is H.264 or H.
265.
Steps
1.
Go to Conguraon → Video/Audio → ROI .
2.
Check Enable.
3.
Select the channel No. according to your need.
4.
Select Stream Type.
5.
Select Region No. in Fixed Region to draw ROI region.
1) Click Draw Area.
2) Click and drag the mouse on the view screen to draw the xed region.
3) Click Stop Drawing.
Note
Select the xed region that needs to be adjusted and drag the mouse to adjust its posion.
6.
Input the Region Name and ROI Level.
7.
Click Save.
Note
The higher the ROI level is, the clearer the image of the detected region is.
8.
Oponal: Select other region No. and repeat the above steps if you need to draw mulple xed
regions.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
61
10.4 Metadata
Metadata is the raw data that the device collects before algorithm processing. It is oen used for
the third party integraon.
Go to Conguraon → Video/Audio → Metadata Sengs to enable metadata uploading of the
desired funcon for the camera channels.
10.5 Display Sengs
It oers the parameter sengs to adjust image features.
Go to Conguraon → Image → Display Sengs .
For device that supports mulple channels, display sengs of each channel is required. The
sengs for dierent channels may be dierent. This part introduces all possible parameters among
the channels.
Click Default to restore sengs.
10.5.1 Scene Mode
There are several sets of image parameters predened for dierent installaon environments.
Select a scene according to the actual installaon environment to speed up the display sengs.
10.5.2 Image Adjustment
By adjusng the Brightness, Saturaon, Hue, Contrast and Sharpness, the image can be best
displayed.
Figure 10-1 Saturaon
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
62
10.5.3 Image Adjustment (Thermal Channel)
You can opmize the image display eect of thermal channel by seng background correcon and
manual correcon.
Background Correcon
Fully cover the lens with an object of uniform temperature in front of the lens, such as foam
board or paperboard. When you click DPC (Defecve Pixel Correcon), the device will take the
uniform object as the standard and opmize the image once.
Manual Correcon
Click DPC (Defecve Pixel Correcon) to opmize the image once.
Note
It is a normal phenomenon that short video freezing might occur during the process of Background
Correcon and Manual Correcon.
Thermal AGC Mode
Choose the AGC mode according to dierent scenes to balance and improve the image quality.
●
Histogram: Choose for scene with obvious WDR and high temperature dierence, can
improve image contrast and enhance image (e.g., the scene contains both indoor and
outdoor scenes).
●
Linear: Choose for scene with low temperature dierence and the target is not obvious, can
improve image contrast and enhance image (e.g., the bird in forest).
●
Self-Adapve: Choose AGC mode automacally according to current scene.
10.5.4 Exposure Sengs
Exposure is controlled by the combinaon of iris, shuer, and gain. You can adjust image eect by
seng exposure parameters.
Exposure Mode
Auto
The iris, shuer, and gain values are adjusted automacally.
You can limit the changing ranges of iris, shuer and gain by seng Max. Iris Limit, Min. Iris
Limit, Max. Shuer Limit, Min. Shuer Limit and Limit Gain for beer exposure eect.
Iris Priority
The value of iris needs to be adjusted manually. The shuer and gain values are adjusted
automacally according to the brightness of the environment.
You can limit the changing ranges of the shuer and gain by seng Max. Shuer Limit, Min.
Shuer Limit and Limit Gain for beer exposure eect.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
63
Shuer Priority
The value of shuer needs to be adjusted manually. The iris and gain values are adjusted
automacally according to the brightness of the environment.
You can limit the changing ranges of the iris by seng Max. Iris Limit, Min. Iris Limit and
Limit Gain for beer exposure eect.
Manual
You need to set Iris, Shuer, and Gain manually.
Slow Shuer
The higher the slow shuer level is, the slower the shuer speed is. It ensures full exposure in
underexposure condion.
10.5.5 Day/Night Switch
Day/Night Switch funcon can provide color images in the day mode and turn on ll light in the
night mode. Switch mode is congurable.
Day
The image is always in color.
Night
The image is black/white or colorful and the supplement light will be enabled to ensure clear
live view image at night.
Auto
The camera switches between the day mode and the night mode according to the illuminaon
automacally.
Scheduled-Switch
Set the Start Time and the End Time to dene the duraon for day mode.
Note
●
Day/Night Switch funcon varies according to models.
●
You can turn on the smart supplement light in auto, night, and schedule-switch modes for beer
image eect.
10.5.6 Set Supplement Light
Steps
1.
Go to Conguraon → Maintenance → System Service .
2.
Check Enable Supplement Light.
3.
Click Save.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
64
10.5.7 BLC
If you focus on an object against strong backlight, the object will be too dark to be seen clearly. BLC
(backlight compensaon) compensates light to the object in the front to make it clear. If BLC mode
is set as Custom, you can draw a red rectangle on the live view image as the BLC area.
10.5.8 WDR
The WDR (Wide Dynamic Range) funcon helps the camera provide clear images in environment
with strong illuminaon dierences.
When there are both very bright and very dark areas simultaneously in the eld of view, you can
enable the WDR funcon and set the level. WDR automacally balances the brightness level of the
whole image and provides clear images with more details.
Note
When WDR is enabled, some other funcons may be not supported. Refer to the actual interface
for details.
10.5.9 White Balance
White balance is the white rendion funcon of the camera. It is used to adjust the color
temperature according to the environment.
10.5.10 DNR
Digital Noise Reducon is used to reduce the image noise and improve the image quality. Normal
and Expert modes are selectable.
Normal
Set the DNR level to control the noise reducon degree. The higher level means stronger
reducon degree.
Expert
Set the DNR level for both space DNR and me DNR to control the noise reducon degree. The
higher level means stronger reducon degree.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
65
Figure 10-2 DNR
10.5.11 Smart Noise Reducon
Smart Noise Reducon is a funcon that uses intelligent algorithms to automacally remove noise,
resulng in high-quality images.
Select the Smart Noise Reducon as ON and conrm to restart the device to complete the
conguraon.
Note
The funcon varies depending on dierent camera models.
10.5.12 Defog
You can enable the defog funcon when the environment is foggy and the image is misty. It
enhances the subtle details so that the image appears clearer.
Figure 10-3 Defog
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
66
10.5.13 Set Palee
You can select the palee mode to display the thermal grayscale image to colored image.
Steps
1.
Go to Conguraon → Image → Display Sengs .
2.
Select the thermal channel.
3.
Select a palee mode in Image Enhancement according to your need.
Result
The live view displays the image with palee.
10.5.14 Set Palee Range
The live view can display the palees eect of the specied temperature range.
Select Manual or Auto from By Temp. Range drop down list.
Auto
The device detects the max. temperature and min. temperature of the scene automacally and
display image of the whole scene with palees.
Manual
In this mode, you can enter the temperature upper limit and lower limit manually. And the live
view shows the palees eect of the desired temperature secon more detailed.
10.5.15 DDE
Digital Detail Enhancement is used to adjust the details of the image. OFF and Normal modes are
selectable.
OFF
Disable this funcon.
Normal
Set the DDE level to control the details of the image. The higher the level is, the more details
shows, but the higher the noise is.
10.5.16 Brightness Sudden Change
When the brightness of target and the background is hugely dierent (the temperature dierence
of target and background is huge), the system reduces the dierence for viewing.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
67
10.5.17 Target Enhancement
Enable this funcon to view the target clearer in environment of low temperature dierence.
10.5.18 Contrast Enhancement
This funcon can improve the palees contract between high temperature and low temperature
areas, avoiding overexposure and over darkness of the image. OFF and On modes are selectable.
10.5.19 Enhance Regional Image
You can select the desired area of image to improve the coding quality. The regional image will be
more detailed and clear.
Steps
1.
Go to Conguraon → Image → Display Sengs → Image Enhancement .
2.
Select the area of regional image enhancement. You can select OFF to disable this funcon, or
select Custom Area to draw a desired area.
A red rectangle shows on the display, in which the image quality is improved.
10.5.20 Mirror
When the live view image is the reverse of the actual scene, this funcon helps to display the
image normally.
Select the mirror mode as needed.
Note
The video recording will be shortly interrupted when the funcon is enabled.
10.5.21 Video Standard
Video standard is an ability of a video card or video display device that denes the amount of
colors that are shown and the resoluon. The two most common video standard used are NTSC
and PAL. In NTSC, 30 frames are transmied each second. Each frame is made up of 525 individual
scan lines. In PAL, 25 frames are transmied each second. Each frame is made up of 625 individual
scan lines. Select video signal standard according to the video system in your country/region.
10.5.22 Digital Zoom
You can zoom in the image. The larger the zoom size is, the more blurred the image is.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
68
10.5.23 Zoom Limit
You can set a certain value to limit the maximum value of zooming.
10.5.24 Local Video Output
If the device is equipped with video output interfaces, such as BNC, CVBS, HDMI, and SDI, you can
preview the live image directly by connecng the device to a monitor screen.
Select the output mode as ON/OFF to control the output.
10.6 OSD
You can customize OSD (On-screen Display) informaon such as device name, me/date, font,
color, and text overlay displayed on video stream.
Go to OSD seng page: Conguraon → Image → OSD Sengs .
Select a channel.
Set the corresponding parameters, and click Save to take eect.
Character Set
Select character set for displayed informaon. If Korean is required to display on screen, select
EUC-KR. Otherwise, select GBK.
Displayed Informaon
Set camera name, date, week, and their related display format.
Text Overlay
Set customized overlay text on image.
OSD Parameters
Set OSD parameters, such as Display Mode, OSD Size, Font Color, and Alignment.
10.7 Overlay Picture
Overlay a customized picture on live view.
Before You Start
The picture to overlay has to be in BMP format with 24-bit, and the maximum picture size is 128 ×
128 pixel.
Steps
1.
Go to picture overlay seng page: Conguraon → Image → Picture Overlay .
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
69
2.
Select a channel to overlay picture.
3.
Click Browse to select a picture, and click Upload.
The picture with a red rectangle will appear in live view aer successfully uploading.
4.
Check Enable Picture Overlay.
5.
Drag the picture to adjust its posion.
6.
Click Save.
10.8 Set Manual DPC (Defecve Pixel Correcon)
If the amount of defecve pixels in the image is comparavely small and accurate correcon is
needed, you can correct these pixels manually.
Steps
1.
Go to Conguraon → Image → DPC .
2.
Select the thermal channel.
3.
Select manual mode.
4.
Click the defecve pixel on the image, then a cursor shows on the live view.
5.
Click Up, Down, Le, Right to adjust the cursor posion to the defecve pixel posion.
6.
Click , then click to correct defecve pixel.
Note
If mulple defecve pixels need to be corrected, click aer locang a defecve pixel. Then
aer locang other pixels, click to correct them simultaneously.
7.
Oponal: Click to cancel defecve pixel correcon.
10.9 Set Picture in Picture
You can overlay the images of two channels and view the image of two channels at the same me.
Steps
1.
Select a channel number.
2.
Select the picture in picture mode.
Overlap Mode Paral image of thermal channel is displayed on the full screen of opcal
channel. This mode is only supported in opcal channel.
Details Overlay
Mode
The device displays the details of opcal channel on thermal channel. This
mode is only supported in thermal channel.
3.
In Details Overlay Mode, set the Fusion Distance of the target. It is recommended to use the
default value.
4.
Click Save.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
70
Note
Not all models support this funcon, take the actual product for reference.
10.10 VCA Rule Display Sengs
The VCA rule display refers to the funcon that you can customize the displayed overlay
informaon of the VCA rule, which includes the font size and line and frame color.
You can go to Conguraon → Image → VCA Rule Display to select the desired font size, and set
the line and frame color.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
71
Chapter 11 Video Recording and Picture Capture
This part introduces the operaons of capturing video clips and snapshots, playback, and
downloading captured les.
11.1 Storage Sengs
This part introduces the conguraon of several common storage paths.
11.1.1 Set Memory Card
If you choose to store the les to memory card, make sure you insert and format the memory card
in advance.
Before You Start
Insert the memory card to the camera. For detailed installaon, refer to Quick Start Guide of the
camera.
Steps
1.
Go to storage management seng page: Conguraon → Storage → Storage Management →
HDD Management .
2.
Select the memory card, and click Format to start inializing the memory card.
The Status of memory card turns to Normal from Uninialized, which means the memory card
can be used normally.
3.
Oponal: Dene the Quota of the memory card. Input the quota percentage for dierent
contents according to your need.
4.
Oponal: Check to enable POS Informaon Storage, then the device will record the POS
informaon of reect light lter and forkli lter.
Note
The funcon is supported when your memory card capacity is 32 GB or above. Formang the
memory card manually is required to reserve 16 GB for POS informaon.
5.
Click Save.
11.1.2 Set NAS
Take network server as network disk to store the record les, captured images, etc.
Before You Start
Get the IP address of the network disk rst.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
72
Steps
1.
Go to NAS seng page: Conguraon → Storage → Storage Management → Net HDD .
2.
Click HDD No. Select Mounng Type and set parameters for the disk.
Server Address
The IP address of the network disk.
File Path
The saving path of network disk les.
User Name and Password
The user name and password of the net HDD.
3.
Click Test to check whether the network disk is available.
4.
Click Save.
11.1.3 Set FTP
You can congure the FTP server to save images which are captured by events or a med snapshot
task.
Before You Start
Get the FTP server address rst.
Steps
1.
Go to Conguraon → Network → Advanced Sengs → FTP .
2.
Congure FTP sengs.
Server Address and Port
The FTP server address and corresponding port.
User Name and Password
The FTP user should have the permission to upload pictures.
If the FTP server supports picture uploading by anonymous users, you can check Anonymous
to hide your device informaon during uploading.
Directory Structure
The saving path of snapshots in the FTP server.
3.
Click Upload Picture to enable uploading snapshots to the FTP server.
4.
Click Test to verify the FTP server.
5.
Click Save.
11.1.4 Set Cloud Storage
It helps to upload the captured pictures and data to the cloud. The plaorm requests picture
directly from the cloud for picture and analysis. The funcon is only supported by certain models.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
73
Steps
Cauon
If cloud storage is enabled, the pictures are stored in the cloud video manager preferenally.
1.
Go to Conguraon → Storage → Storage Management → Cloud Storage .
2.
Check Enable Cloud Storage.
3.
Set basic parameters.
Protocol Version The protocol version of the cloud video manager.
Server IP The IP address of the cloud video manager. It supports IPv4 address.
Serve Port The port of the cloud video manager. 6001 is the default port and you
are not recommended to edit it.
AccessKey The key to log in to the cloud video manager.
SecretKey The key to encrypt the data stored in the cloud video manager.
User Name and
Password
The user name and password of the cloud video manager.
Picture Storage
Pool ID
The ID of the picture storage region in the cloud video manager. Make
sure storage pool ID and the storage region ID are the same.
4.
Click Test to test the congured sengs.
5.
Click Save.
11.2 Video Recording
This part introduces the operaons of manual and scheduled recording, playback, and
downloading recorded les.
11.2.1 Record Automacally
This funcon can record video automacally during congured me periods.
Before You Start
Select Trigger Recording in event sengs for each record type except Connuous. See
Event and
Alarm for details.
Steps
Note
The funcon varies according to dierent models.
1.
Go to Conguraon → Storage → Schedule Sengs → Record Schedule .
2.
Select channel No.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
74
3.
Check Enable.
4.
Select a record type.
Note
The record type is vary according to dierent models.
Connuous
The video will be recorded connuously according to the schedule.
Moon
When moon detecon is enabled and trigger recording is selected as linkage method, object
movement is recorded.
Alarm
When alarm input is enabled and trigger recording is selected as linkage method, the video is
recorded aer receiving alarm signal from external alarm input device.
Moon | Alarm
Video is recorded when moon is detected or alarm signal is received from the external
alarm input device.
Moon & Alarm
Video is recorded only when moon is detected and alarm signal is received from the
external alarm input device.
Event
The video is recorded when congured event is detected.
5.
Set schedule for the selected record type. Refer to Set Arming Schedule for the seng
operaon.
6.
Click Advanced to set the advanced sengs.
Overwrite
Enable Overwrite to overwrite the video records when the storage space is full. Otherwise
the camera cannot record new videos.
Pre-record
The me period you set to record before the scheduled me.
Post-record
The me period you set to stop recording aer the scheduled me.
Stream Type
Select the stream type for recording.
Note
When you select the stream type with higher bitrate, the actual me of the pre-record and
post-record may be less than the set value.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
75
Recording Expiraon
The recordings are deleted when they exceed the expired me. The expired me is
congurable. Note that once the recordings are deleted, they can not be recovered.
7.
Click Save.
11.2.2 Record Manually
Steps
1.
Go to Conguraon → Local .
2.
Set the Record File Size and saving path to for recorded les.
3.
Click Save.
4.
Click in the live view interface to start recording. Click to stop recording.
11.2.3 Playback and Download Video
You can search, playback and download the videos stored in the local storage or network storage.
Steps
1.
Click Playback.
2.
Select channel No.
3.
Set search condion and click Search.
The matched video les showed on the ming bar.
4.
Click
to play the video les.
-
Click
to clip video les.
-
Click
to play video les in full screen. Press ESC to exit full screen.
Note
Go to Conguraon → Local , click Save clips to to change the saving path of clipped video les.
5.
Click on the playback interface to download les.
1) Set search condion and click Search.
2) Select the video les and then click Download.
Note
Go to Conguraon → Local , click Save downloaded les to to change the saving path of
downloaded video les.
11.3 Capture Conguraon
The device can capture the pictures manually or automacally and save them in congured saving
path. You can view and download the snapshots.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
76
11.3.1 Capture Automacally
This funcon can capture pictures automacally during congured me periods.
Before You Start
If event-triggered capture is required, you should congure related linkage methods in event
sengs. Refer to Event and Alarm for event sengs.
Steps
1.
Go to Conguraon → Storage → Schedule Sengs → Capture → Capture Parameters .
2.
Set the capture type.
Timing
Capture a picture at the congured me interval.
Event-Triggered
Capture a picture when an event is triggered.
3.
Set the Format, Resoluon, Quality, Interval, and Capture Number.
4.
Refer to Set Arming Schedule for conguring schedule me.
5.
Click Save.
11.3.2 Capture Manually
Steps
1.
Go to Conguraon → Local .
2.
Set the Image Format and saving path to for snapshots.
JPEG
The picture size of this format is comparavely small, which is beer for network
transmission.
BMP
The picture is compressed with good quality.
3.
Click Save.
4.
Click near the live view or play back window to capture a picture manually.
11.3.3 View and Download Picture
You can search, view and download the pictures stored in the local storage or network storage.
Steps
1.
Click Picture.
2.
Select channel No.
3.
Set search condion and click Search.
The matched pictures showed in the le list.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
77
4.
Select the pictures then click Download to download them.
Note
Go to Conguraon → Local , click Save snapshots when playback to change the saving path of
pictures.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
78
Chapter 12 Network Sengs
12.1 TCP/IP
TCP/IP sengs must be properly congured before you operate the device over network. IPv4 and
IPv6 are both supported. Both versions can be congured simultaneously without conicng to
each other.
Go to Conguraon → Basic Conguraon → Network → TCP/IP for parameter sengs.
NIC Type
Select a NIC (Network Interface Card) type according to your network condion.
IPv4
Two IPv4 modes are available.
DHCP
The device automacally gets the IPv4 parameters from the network if you check DHCP. The
device IP address is changed aer enabling the funcon. You can use SADP to get the device IP
address.
Note
The network that the device is connected to should support DHCP (Dynamic Host
Conguraon Protocol).
Manual
You can set the device IPv4 parameters manually. Input IPv4 Address, IPv4 Subnet Mask, and
IPv4 Default Gateway, and click Test to see if the IP address is available.
IPv6
Three IPv6 modes are available.
Route Adversement
The IPv6 address is generated by combining the route adversement and the device Mac
address.
Note
Route adversement mode requires the support from the router that the device is connected
to.
DHCP
The IPv6 address is assigned by the server, router or gateway.
Manual
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
79
Input IPv6 Address, IPv6 Subnet, IPv6 Default Gateway. Consult the network administrator for
required informaon.
MTU
It stands for maximum transmission unit. It is the size of the largest protocol data unit that can
be communicated in a single network layer transacon.
The valid value range of MTU is 1280 to 1500.
DNS
It stands for domain name server. It is required if you need to visit the device with domain
name. And it is also required for some applicaons (e.g., sending email). Set Preferred DNS
Server and Alternate DNS server properly if needed.
12.1.1 Mulcast Discovery
Check the Enable Mulcast Discovery, and then the online network camera can be automacally
detected by client soware via private mulcast protocol in the LAN.
12.2 Port
The device port can be modied when the device cannot access the network due to port conicts.
Cauon
Do not modify the default port parameters at will, otherwise the device may be inaccessible.
Go to Conguraon → Network → Basic Sengs → Port for port sengs.
HTTP Port
It refers to the port through which the browser accesses the device. For example, when the
HTTP Port is modied to 81, you need to enter hp://192.168.1.64:81 in the browser for login.
HTTPS Port
It refers to the port through which the browser accesses the device with cercate. Cercate
vericaon is required to ensure the secure access.
RTSP Port
It refers to the port of real-me streaming protocol.
SRTP Port
It refers to the port of secure real-me transport protocol.
Server Port
It refers to the port through which the client adds the device.
WebSocket Port
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
80
TCP-based full-duplex communicaon protocol port for plug-in free preview.
WebSockets Port
TCP-based full-duplex communicaon protocol port for plug-in free preview. Cercate
vericaon is required to ensure the secure access.
Note
●
Enhanced SDK Service Port, WebSocket Port, and WebSockets Port are only supported by certain
models.
●
For device models that support that funcon, go to Conguraon → Network → Advanced
Sengs → Network Service to enable it.
12.3 Port Mapping
By seng port mapping, you can access devices through the specied port.
Before You Start
When the ports in the device are the same as those of other devices in the network, refer to Port
to modify the device ports.
Steps
1.
Go to Conguraon → Network → Basic Sengs → NAT .
2.
Select the port mapping mode.
Auto Port Mapping Refer to
Set Auto Port Mapping for detailed informaon.
Manual Port Mapping Refer to
Set Manual Port Mapping for detailed informaon.
3.
Click Save.
12.3.1 Set Auto Port Mapping
Steps
1.
Check Enable UPnP™, and choose a friendly name for the camera, or you can use the default
name.
2.
Select the port mapping mode to Auto.
3.
Click Save.
Note
UPnP™ funcon on the router should be enabled at the same me.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
81
12.3.2 Set Manual Port Mapping
Steps
1.
Check Enable UPnP™, and choose a friendly name for the device, or you can use the default
name.
2.
Select the port mapping mode to Manual, and set the external port to be the same as the
internal port.
3.
Click Save.
What to do next
Go to the router port mapping sengs interface and set the port number and IP address to be the
same as those on the device. For more informaon, refer to the router user manual.
12.4 Mulcast
Mulcast is group communicaon where data transmission is addressed to a group of desnaon
devices simultaneously.
Go to Conguraon → Network → Basic Sengs → Mulcast for the mulcast sengs.
For a device with more than one channel, mulcast can be set independently for each channel.
IP Address
It stands for the address of mulcast host.
Stream Type
The stream type as the mulcast source.
Video Port
The video port of the selected stream.
Audio Port
The audio port of the selected stream.
12.5 SNMP
You can set the SNMP network management protocol to get the alarm event and excepon
messages in network transmission.
Before You Start
Before seng the SNMP, you should download the SNMP soware and manage to receive the
device informaon via SNMP port.
Steps
1.
Go to the sengs page: Conguraon → Network → Advanced Sengs → SNMP .
2.
Check Enable SNMPv1, Enable SNMP v2c or Enable SNMPv3.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
82
Note
The SNMP version you select should be the same as that of the SNMP soware.
And you also need to use the dierent version according to the security level required. SNMP v1
is not secure and SNMP v2 requires password for access. And SNMP v3 provides encrypon and
if you use the third version, HTTPS protocol must be enabled.
3.
Congure the SNMP sengs.
4.
Click Save.
12.6 Access to Device via Domain Name
You can use the Dynamic DNS (DDNS) for network access. The dynamic IP address of the device can
be mapped to a domain name resoluon server to realize the network access via domain name.
Before You Start
Registraon on the DDNS server is required before conguring the DDNS sengs of the device.
Steps
1.
Refer to TCP/IP to set DNS parameters.
2.
Go to the DDNS sengs page: Conguraon → Network → Basic Sengs → DDNS .
3.
Check Enable DDNS and select DDNS type.
DynDNS
Dynamic DNS server is used for domain name resoluon.
NO-IP
NO-IP server is used for domain name resoluon.
4.
Input the domain name informaon, and click Save.
5.
Check the device ports and complete port mapping. Refer to Port to check the device port , and
refer to Port Mapping for port mapping sengs.
6.
Access the device.
By Browsers Enter the domain name in the browser address bar to access the device.
By Client Soware Add domain name to the client soware. Refer to the client manual for
specic adding methods.
12.7 Access to Device via PPPoE Dial Up Connecon
This device supports the PPPoE auto dial-up funcon. The device gets a public IP address by ADSL
dial-up aer the device is connected to a modem. You need to congure the PPPoE parameters of
the device.
Steps
1.
Go to Conguraon → Network → Basic Sengs → PPPoE .
2.
Check Enable PPPoE.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
83
3.
Set the PPPoE parameters.
Dynamic IP
Aer successful dial-up, the dynamic IP address of the WAN is displayed.
User Name
User name for dial-up network access.
Password
Password for dial-up network access.
Conrm
Input your dial-up password again.
4.
Click Save.
5.
Access the device.
By Browsers Enter the WAN dynamic IP address in the browser address bar to access
the device.
By Client Soware Add the WAN dynamic IP address to the client soware. Refer to the
client manual for details.
Note
The obtained IP address is dynamically assigned via PPPoE, so the IP address always changes
aer restarng the camera. To solve the inconvenience of the dynamic IP, you need to get a
domain name from the DDNS provider (e.g., DynDns.com). Refer to Access to Device via Domain
Name for detail informaon.
12.8 Accessing via Mobile Client
Hik-Connect is an applicaon for mobile devices. Using the App, you can view live image, receive
alarm nocaon and so on.
Note
Hik-Connect service should be supported by the camera.
12.8.1 Enable Hik-Connect Service on Camera
Hik-Connect service should be enabled on your camera before using the service.
You can enable the service through SADP soware or Web browser.
Enable Hik-Connect Service via Web Browser
Follow the following steps to enable Hik-Connect Service via Web Browser.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
84
Before You Start
You need to acvate the camera before enabling the service.
Steps
1.
Access the camera via web browser.
2.
Enter plaorm access conguraon interface. Conguraon → Network → Advanced Sengs
→ Plaorm Access
3.
Select Hik-Connect as the Plaorm Access Mode.
4.
Check Enable.
5.
Click and read "Terms of Service" and "Privacy Policy" in pop-up window.
6.
Create a vericaon code or change the old vericaon code for the camera.
Note
The vericaon code is required when you add the camera to Hik-Connect service.
7.
Save the sengs.
Enable Hik-Connect Service via SADP Soware
This part introduce how to enable Hik-Connect service via SADP soware of an acvated camera.
Steps
1.
Run SADP soware.
2.
Select a camera and enter Modify Network Parameters page.
3.
Check Enable Hik-Connect.
4.
Create a vericaon code or change the old vericaon code.
Note
The vericaon code is required when you add the camera to Hik-Connect service.
5.
Click and read "Terms of Service" and "Privacy Policy".
6.
Conrm the sengs.
12.8.2 Set Up Hik-Connect
Steps
1.
Get and install Hik-Connect applicaon by vising hps://www.hikmicro.com/en/ . Then go to
Support → Download Center → Soware to down load the applicaon.
2.
Start the applicaon and register for a Hik-Connect user account.
3.
Log in aer registraon.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
85
12.8.3 Add Camera to Hik-Connect
Steps
1.
Connect your mobile device to a Wi-Fi.
2.
Log into the Hik-Connect app.
3.
In the home page, tap "+" on the upper-right corner to add a camera.
4.
Scan the QR code on camera body or on the Quick Start Guide cover.
Note
If the QR code is missing or too blur to be recognized, you can also add the camera by inpung
the camera's serial number.
5.
Input the vericaon code of your camera.
Note
●
The required vericaon code is the code you create or change when you enable Hik-Connect
service on the camera.
●
If you forget the vericaon code, you can check the current vericaon code on Plaorm
Access conguraon page via web browser.
6.
Tap Connect to a Network buon in the popup interface.
7.
Choose Wired Connecon or Wireless Connecon according to your camera funcon.
Wireless
Connecon
Input the Wi-Fi password that your mobile phone has connected to, and
tap Next to start the Wi-Fi connecon process. (Locate the camera within 3
meters from the router when seng up the Wi-Fi.)
Wired
Connecon
Connect the camera to the router with a network cable and tap Connected
in the result interface.
Note
The router should be the same one which your mobile phone has connected to.
8.
Tap Add in the next interface to nish adding.
For detailed informaon, refer to the user manual of the Hik-Connect app.
12.9 Set ISUP
When the device is registered on ISUP plaorm (formerly called Ehome), you can visit and manage
the device, transmit data, and forward alarm informaon over public network.
Steps
1.
Go to Conguraon → Network → Advanced Sengs → Plaorm Access .
2.
Select ISUP as the plaorm access mode.
3.
Select Enable.
4.
Select a protocol version and input related parameters.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
86
5.
Click Save.
Register status turns to Online when the funcon is correctly set.
12.10 Set Open Network Video Interface
If you need to access the device through Open Network Video Interface protocol, you can
congure the user sengs to enhance the network security.
Steps
1.
Go to Conguraon → Network → Advanced Sengs → Integraon Protocol .
2.
Check Enable Open Network Video Interface.
3.
Select an authencaon mode.
-
If you select Digest, the device only supports digest authencaon.
-
If you select Digest&ws-username token, the device supports digest authencaon or ws-
username token authencaon.
4.
Click Add to congure the Open Network Video Interface user.
Delete Delete the selected Open Network Video Interface user.
Modify Modify the selected Open Network Video Interface user.
5.
Click Save.
6.
Oponal: Repeat the steps above to add more Open Network Video Interface users.
12.11 Set Alarm Server
The device can send alarms to desnaon IP address or host name through HTTP, HTTPS, or ISUP
protocol. The desnaon IP address or host name should support HTTP, HTTP, or ISUP data
transmission.
Steps
1.
Go to Conguraon → Network → Advanced Sengs → Alarm Server .
2.
Enter Desnaon IP or Host Name, URL, and Port.
3.
Select Protocol.
Note
HTTP, HTTPS, and ISUP are selectable. It is recommended to use HTTPS, as it encrypts the data
transmission during communicaon.
4.
Click Test to check if the IP or host is available.
5.
Click Save.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
87
12.12 Set Network Service
You can control the ON/OFF status of certain protocol as desired.
Steps
Note
This funcon varies according to dierent models.
1.
Go to Conguraon → Network → Advanced Sengs → Network Service .
2.
Set network service.
WebSocket & WebSockets
WebSocket or WebSockets protocol should be enabled if you use Google Chrome 57 and its
above version or Mozilla Firefox 52 and its above version to visit the device. Otherwise, live
view, image capture, and digital zoom funcon cannot be used.
If the device uses HTTP, enable WebSocket.
If the device uses HTTPS, enable WebSockets.
TLS (Transport Layer Security)
The device oers TLS1.1 and TLS1.2. Enable one or more protocol versions according to your
need.
3.
Click Save.
12.13 Set SRTP
The Secure Real-me Transport Protocol (SRTP) is a Real-me Transport Protocol (RTP) internet
protocol, intended to provide encrypon, message authencaon and integrity, and replay aack
protecon to the RTP data in both unicast and mulcast applicaons.
Steps
1.
Go to Conguraon → Network → Advanced Sengs → SRTP .
2.
Select Server Cercate.
3.
Select Encrypted Algorithm.
4.
Click Save.
Note
Only certain device models support this funcon.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
88
Chapter 13 System and Security
It introduces system maintenance, system sengs and security management, and explains how to
congure relevant parameters.
13.1 View Device Informaon
You can view device informaon, such as Device No., Model, Serial No. and Firmware Version.
Enter Conguraon → System → System Sengs → Basic Informaon to view the device
informaon.
13.2 Search and Manage Log
Log helps locate and troubleshoot problems.
Steps
1.
Go to Conguraon → System → Maintenance → Log .
2.
Set search condions Major Type, Minor Type, Start Time, and End Time.
3.
Click Search.
The matched log les will be displayed on the log list.
4.
Oponal: Click Export to save the log les in your computer.
13.3 Import and Export Conguraon File
It helps speed up batch conguraon on other devices with the same parameters.
Steps
1.
Export conguraon le.
1) Go to Conguraon → System → Maintenance → Upgrade & Maintenance .
2) Click Device Parameters and input the encrypon password to export the current
conguraon le.
3) Set the saving path to save the conguraon le in local computer.
2.
Import conguraon le.
1) Access the device that needs to be congured via web browser.
2) Click Browse to select the saved conguraon le.
3) Input the encrypon password you have set when exporng the conguraon le.
4) Click Import.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
89
13.4 Export Diagnose Informaon
Diagnose informaon includes running log, system informaon, hardware informaon.
Go to Conguraon → System → Maintenance → Upgrade & Maintenance , and click Diagnose
Informaon to export diagnose informaon of the device.
13.5 Reboot
You can restart the device via browser.
Go to Conguraon → System → Maintenance → Upgrade & Maintenance , and click Reboot.
13.6 Restore and Default
Restore and Default helps restore the device parameters to the default sengs.
Steps
1.
Go to Conguraon → System → Maintenance → Upgrade & Maintenance .
2.
Click Restore or Default according to your needs.
Restore Reset device parameters, except user informaon, IP parameters and video format
to the default sengs.
Default Reset all the parameters to the factory default.
Note
Be careful when using this funcon. Aer reseng to the factory default, all the
parameters are reset to the default sengs.
13.7 Upgrade
Before You Start
You need to obtain the correct upgrade package.
Cauon
DO NOT disconnect power during the process, and the device restarts automacally aer upgrade.
Steps
1.
Go to Conguraon → System → Maintenance → Upgrade & Maintenance .
2.
Choose one method to upgrade.
Firmware Locate the exact path of the upgrade le.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
90
Firmware Directory Locate the directory which the upgrade le belongs to.
3.
Click Browse to select the upgrade le.
4.
Click Upgrade.
13.8 Set Electric Current Limit
This funcon can control the power supply current of the device.
Go to Conguraon → System → Maintenance → System Service , and select Electric Current
Limit type. You can limit the device current to 75% of full current or half the full current for power
saving control.
13.9 View Open Source Soware License
Go to Conguraon → System → System Sengs → About , and click View Licenses.
13.10 Time and Date
You can congure me and date of the device by conguring me zone, me synchronizaon and
Daylight Saving Time (DST).
13.10.1 Synchronize Time Manually
Steps
1.
Go to Conguraon → System → System Sengs → Time Sengs .
2.
Select Time Zone.
3.
Click Manual Time Sync..
4.
Choose one me synchronizaon method.
-
Select Set Time, and manually input or select date and me from the pop-up calendar.
-
Check Sync. with computer me to synchronize the me of the device with that of the local
PC.
5.
Click Save.
13.10.2 Set NTP Server
You can use NTP server when accurate and reliable me source is required.
Before You Start
Set up a NTP server or obtain NTP server informaon.
Steps
1.
Go to Conguraon → System → System Sengs → Time Sengs .
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
91
2.
Select Time Zone.
3.
Click NTP.
4.
Set Server Address, NTP Port and Interval.
Note
Server Address is NTP server IP address.
5.
Click Test to test server connecon.
6.
Click Save.
13.10.3 Set DST
If the region where the device is located adopts Daylight Saving Time (DST), you can set this
funcon.
Steps
1.
Go to Conguraon → System → System Sengs → DST .
2.
Check Enable DST.
3.
Select Start Time, End Time and DST Bias.
4.
Click Save.
13.11 Set RS-232
RS-232 can be used to debug device or access peripheral device. RS-232 can realize communicaon
between the device and computer or terminal when the communicaon distance is short.
Before You Start
Connect the device to computer or terminal with RS-232 cable.
Steps
1.
Go to Conguraon → System → System Sengs → RS-232 .
2.
Set RS-232 parameters to match the device with computer or terminal.
3.
Click Save.
13.12 Set RS-485
RS-485 is used to connect the device to external device. You can use RS-485 to transmit the data
between the device and the computer or terminal when the communicaon distance is too long.
Before You Start
Connect the device and computer or terminal with RS-485 cable.
Steps
1.
Go to Conguraon → System → System Sengs → RS-485 .
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
92
2.
Set the RS-485 parameters.
Note
You should keep the parameters of the device and the computer or terminal the same.
3.
Click Save.
Note
The sengs take eect only for the PTZ channel.
13.13 Set Same Unit
Set the same temperature unit and distance unit. When you enable this funcon, the unit cannot
be congured separately in other seng pages
Steps
1.
Go to Conguraon → System → System Sengs → Unit Sengs .
2.
Check Use Same Unit.
3.
Set the temperature unit and distance unit.
4.
Click Save.
13.14 Set Visible Light Parameters
When the FOVs (Field of View) of the opcal channel and thermal channel are not the same, adjust
the visible light opcal axis to make sure the FOVs in the two channels are the same.
Steps
1.
Go to Conguraon → System → Maintenance → System Service .
2.
Select Visible Light Opcal Axis Adjustment from the drop-down list.
3.
Check Enable Visible Light Opcal Axis Adjustment.
4.
Adjust the opcal zoom rao to the maximum value via PTZ control panel.
5.
Click the direcon buons to adjust the posion of the visible light opcal axis.
6.
Adjust the sensivity. The higher the value is, the faster the cursor moves.
7.
Click Save when the FOVs of the opcal channel and thermal channel are the same.
Note
●
If the FOVs of the opcal channel and thermal channel are not the same, funcons such as
reect light lter and smoke auxiliary detecon may be aected.
●
Please adjust the visible light opcal axis under professional assistance.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
93
13.15 Security
You can improve system security by seng security parameters.
13.15.1 Authencaon
You can improve network access security by seng RTSP and WEB authencaon.
Go to Conguraon → System → Security → Authencaon to choose authencaon protocol
and method according to your needs.
RTSP Authencaon
Digest and digest/basic are supported, which means authencaon informaon is needed when
RTSP request is sent to the device. If you select digest/basic, it means the device supports
digest or basic authencaon. If you select digest, the device only supports digest
authencaon.
WEB Authencaon
Digest and digest/basic are supported, which means authencaon informaon is needed when
WEB request is sent to the device. If you select digest/basic, it means the device supports digest
or basic authencaon. If you select digest, the device only supports digest authencaon.
Note
Refer to the specic content of protocol to view authencaon requirements.
13.15.2 Security Audit Log
The security audit logs refer to the security operaon logs. You can search and analyze the security
log les of the device so as to nd out the illegal intrusion and troubleshoot the security events.
Security audit logs can be saved on device internal storage. The log will be saved every half hour
aer device boong. Due to limited storage space, you can also save the logs on a log server.
Search Security Audit Logs
You can search and analyze the security log les of the device so as to nd out the illegal intrusion
and troubleshoot the security events.
Steps
Note
This funcon is only supported by certain camera models.
1.
Go to Conguraon → System → Maintenance → Security Audit Log .
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
94
2.
Select log types, Start Time, and End Time.
3.
Click Search.
The log les that match the search condions will be displayed on the Log List.
4.
Oponal: Click Export to save the log les to your computer.
Set Log Server
The log server should support syslog (RFC 3164) over TLS.
Before You Start
●
Install client and CA cercates before conguraon. Refer to Cercate Management for
detailed informaon.
●
Select cercates according to the requirement of the log server. If two-way authencaon is
required, select the CA cercate and the client cercate. If one-way authencaon is
required, select the CA cercate only.
Steps
1.
Check Enable Log Upload Server.
2.
Oponal: Check Enable Encrypted Transmission if you want the log data to be encrypted.
3.
Input Log Server IP and Log Server Port.
4.
Oponal: Select client cercate.
5.
Select CA cercate to the device.
6.
Click Test to test the sengs.
7.
Click Save.
Cercate Management
It helps to manage the server/client cercates and CA cercate, and to send an alarm if the
cercates are close to expiry date, or are expired/abnormal.
Note
The funcon is only supported by certain device models.
13.15.3 Set IP Address Filter
IP address lter is a tool for access control. You can enable the IP address lter to allow or forbid
the visits from the certain IP addresses.
IP address refers to IPv4.
Steps
1.
Go to Conguraon → System → Security → IP Address Filter .
2.
Check Enable IP Address Filter.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
95
3.
Select the type of IP address lter.
Forbidden IP addresses in the list cannot access the device.
Allowed Only IP addresses in the list can access the device.
4.
Edit the IP address lter list.
Add Add a new IP address or IP address range to the list.
Modify Modify the selected IP address or IP address range in the list.
Delete Delete the selected IP address or IP address range in the list.
5.
Click Save.
13.15.4 Cercate Management
It helps to manage the server/client cercates and CA cercate, and to send an alarm if the
cercates are close to expiry date, or are expired/abnormal.
Note
The funcon is only supported by certain device models.
Create Self-signed Cercate
Steps
1.
Click Create Self-signed Cercate.
2.
Follow the prompt to enter Cercate ID, Country/Region, Hostname/IP, Validity and other
parameters.
Note
The cercate ID should be digits or leers and be no more than 64 characters.
3.
Click OK.
4.
Oponal: Click Export to export the cercate, or click Delete to delete the cercate to
recreate a cercate, or click Cercate Properes to view the cercate details.
Create Cercate Request
Before You Start
Select a self-signed cercate.
Steps
1.
Click Create Cercate Request.
2.
Enter the related informaon.
3.
Click OK.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
96
Import Cercate
Steps
1.
Click Import.
2.
Click Create Cercate Request.
3.
Enter the Cercate ID.
4.
Click Browser to select the desired server/client cercate.
5.
Select the desired import method and enter the required informaon.
6.
Click OK.
7.
Oponal: Click Export to export the cercate, or click Delete to delete the cercate to
recreate a cercate, or click Cercate Properes to view the cercate details.
Note
●
Up to 16 cercates are allowed.
●
If certain funcons are using the cercate, it cannot be deleted.
●
You can view the funcons that are using the cercate in the funcons column.
●
You cannot create a cercate that has the same ID with that of the exisng cercate and
import a cercate that has the same content with that of the exisng cercate.
Server Cercate/Client Cercate
Note
The device has default self-signed server/client cercate installed. The cercate ID is default.
Install CA Cercate
Steps
1.
Click Import.
2.
Enter the Cercate ID.
3.
Click Browser to select the desired server/client cercate.
4.
Select the desired import method and enter the required informaon.
5.
Click OK.
Note
Up to 16 cercates are allowed.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
97
Enable Cercate Expiraon Alarm
Steps
1.
Check Enable Cercate Expiraon Alarm. If enabled, you will receive an email or the camera
links to the surveillance center that the cercate will expire soon, or is expired or abnormal.
2.
Set the Remind Me Before Expiraon (day), Alarm Frequency (day) and Detecon Time (hour).
Note
●
If you set the reminding day before expiraon to 1, then the camera will remind you the day
before the expiraon day. 1 to 30 days are available. Seven days is the default reminding days.
●
If you set the reminding day before expiraon to 1, and the detecon me to 10:00, and the
cercate will expire in 9:00 the next day, the camera will remind you in 10:00 the rst day.
3.
Click Save.
13.15.5 Set SSH
SSH is a protocol to ensure security of remote login. This seng is reserved for professional
maintenance personnel only.
Steps
1.
Go to Conguraon → System → Security → Security Service .
2.
Check Enable SSH.
3.
Click Save.
13.15.6 Set HTTPS
HTTPS is a network protocol that enables encrypted transmission and identy authencaon,
which improves the security of remote access.
Steps
1.
Go to Conguraon → Network → Advanced Sengs → HTTPS .
2.
Check Enable.
3.
Oponal: Check HTTPS Browsing to access the device only via HTTPS protocol.
4.
Select a server cercate.
Note
●
Complete cercate management before selecng server cercate. Refer to Cercate
Management for detailed informaon.
●
If the funcon is abnormal, check if the selected cercate is abnormal in Cercate
Management.
5.
Click Save.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
98
13.15.7 Set QoS
QoS (Quality of Service) can help improve the network delay and network congeson by seng
the priority of data sending.
Note
QoS needs support from network device such as router and switch.
Steps
1.
Go to Conguraon → Network → Advanced Conguraon → QoS .
2.
Set Video/Audio DSCP, Alarm DSCP and Management DSCP.
Note
Network can idenfy the priority of data transmission. The bigger the DSCP value is, the higher
the priority is. You need to set the same value in router while conguraon.
3.
Click Save.
13.15.8 Set IEEE 802.1X
IEEE 802.1x is a port-based network access control. It enhances the security level of the LAN/
WLAN. When devices connect to the network with IEEE 802.1x standard, the authencaon is
needed.
Go to Conguraon → Network → Advanced Sengs → 802.1X , and enable the funcon.
Set Protocol and EAPOL Version according to router informaon.
Protocol
EAP-TLS and EAP-MD5 are selectable
EAP-MD5
If you use EAP-MD5, the authencaon server must be congured. Register a user name and
password for 802.1X in the server in advance. Input the user name and password for
authencaon.
EAP-TLS
If you use EAP-TLS, input Idenfy, Private Key Password, and upload CA Cercate, User
Cercate and Private Key.
EAPOL Version
The EAPOL version must be idencal with that of the router or the switch.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
99
13.16 User and Account
13.16.1 Set User Account and Permission
The administrator can add, modify, or delete other accounts, and grant dierent permission to
dierent user levels.
Cauon
To increase security of using the device on the network, please change the password of your
account regularly. Changing the password every 3 months is recommended. If the device is used in
high-risk environment, it is recommended that the password should be changed every month or
week.
Steps
1.
Go to Conguraon → System → User Management → User Management .
2.
Click Add. Enter User Name, select Level, and enter Password. Assign remote permission to
users based on needs.
Administrator
The administrator has the authority to all operaons and can add users and operators and
assign permission.
User
Users can be assigned permission of viewing live video, seng PTZ parameters, and changing
their own passwords, but no permission for other operaons.
Operator
Operators can be assigned all permission except for operaons on the administrator and
creang accounts.
Modify Select a user and click Modify to change the password and permission.
Delete Select a user and click Delete.
Note
The administrator can add up to 31 user accounts.
3.
Click OK.
13.16.2 Online Users
The informaon of users logging into the device is shown.
Go to Conguraon → System → User Management → Online Users to view the list of online
users.
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
100
Chapter 14 Appendix
14.1 Common Material Emissivity Reference
Material Emissivity
Human Skin 0.98
Printed Circuit Board 0.91
Concrete 0.95
Ceramic 0.92
Rubber 0.95
Paint 0.93
Wood 0.85
Pitch 0.96
Brick 0.95
Sand 0.90
Soil 0.92
Cloth 0.98
Hard Paperboard 0.90
White Paper 0.90
Water 0.96
Thermal & Opcal Bi-spectrum PTZ Network Camera User Manual
101
UD33329B
