USER’S MANUAL
Model: VTM5000S
5” SLIM MONITOR
1. BILL OF MATERIAL
Monitor Manual
2. SPECIFICATION
• Screen Type: 5” Digital TFT LCD
• 2 Video Input
• Display Format: 16:9
• Power: 3W+
• Power supply: 12VDC
• Reverse trigger wire
• PAL/ NTSC auto switch
• Pixel: 800x480
• Slim and Sleek Design
• Contrast: 350:1
3. WIRING
Video Input
Red Plug
For technical support contact 888-941-3060 or email [email protected]om
WWW.VISIONTECHAMERICA.COM
Power Wire Windshield Mount Bracket Sunshade
g
g
g
g
Camera Input
Red lead: 12VDC
Black lead: Ground
• Dimension: 4.125” (W) x 3.75” (H) x 0.5” (D)
/+
/-
V/O
Power
Up
Menu
Down
Mode
Blue wire: Reverse Light 12VDC
