Hikvision DS-K1T331W Face Recognition Access Control User Manual

DS-K1T331 Series Face Recognion Terminal

User Manual

Legal Informaon

About this Manual

The Manual includes instrucons for using and managing the Product. Pictures, charts, images and

all other informaon hereinaer are for descripon and explanaon only. The informaon

contained in the Manual is subject to change, without noce, due to rmware updates or other

reasons. Please nd the latest version of this Manual at the Hikvision website ( hps://

www.hikvision.com/ ).

Please use this Manual with the guidance and assistance of professionals trained in

supporng the

Product.

Trademarks

and other Hikvision's trademarks and logos are the properes of

Hikvision in various jurisdicons.

Other trademarks and logos menoned are the properes of their respecve owners.

Disclaimer

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT

DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED “AS IS” AND “WITH

ALL FAULTS AND ERRORS”. HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING

WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR

PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION

BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,

INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS

INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,

WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY,

OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN

ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.

YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY

RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,

PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS

INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY

TECHNICAL SUPPORT IF REQUIRED.

YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE

SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.

ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT

INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF

PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.

YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE

DS-K1T331 Series Face Recognion Terminal User Manual

DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR

PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED

TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN

RIGHTS ABUSES.

IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER

PREVAILS.

Data Protecon

During the use of device, personal data will be collected, stored and processed. To protect data,

the development of Hikvision devices incorporates privacy by design principles. For example, for

device with facial recognion features, biometrics data is stored in your device with encrypon

method; for ngerprint device, only ngerprint template will be saved, which is impossible to

reconstruct a ngerprint image.

As data controller, you are advised to collect, store, process and transfer data in accordance with

the applicable data

protecon laws and regulaons, including without limitaon, conducng

security controls to safeguard personal data, such as, implemenng reasonable administrave and

physical security controls, conduct periodic reviews and assessments of the

eecveness of your

security controls.

DS-K1T331 Series Face Recognion Terminal User Manual

Symbol Convenons

The symbols that may be found in this document are dened as follows.

Symbol Descripon

Danger

Indicates a hazardous situaon which, if not avoided, will or could

result in death or serious injury.

Cauon

Indicates a potenally hazardous situaon which, if not avoided, could

result in equipment damage, data loss, performance degradaon, or

unexpected results.

Note

Provides addional informaon to emphasize or supplement

important points of the main text.

DS-K1T331 Series Face Recognion Terminal User Manual

iii

Regulatory Informaon

FCC Informaon

Please take aenon that changes or modicaon not expressly approved by the party responsible

for compliance could void the user’s authority to operate the equipment.

FCC compliance: This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable

protecon against harmful interference in a residenal installaon. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in accordance

with the

instrucons, may cause harmful interference to radio communicaons. However, there is

no guarantee that interference will not occur in a parcular installaon. If this equipment does

cause harmful interference to radio or television

recepon, which can be determined by turning

the equipment o and on, the user is encouraged to try to correct the interference by one or more

of the following measures:

—Reorient or relocate the receiving antenna.

—Increase the

separaon between the equipment and receiver.

—Connect the equipment into an outlet on a circuit

dierent from that to which the receiver is

connected.

—Consult the dealer or an experienced radio/TV technician for help

This equipment should be installed and operated with a minimum distance 20cm between the

radiator and your body.

FCC

Condions

This device complies with part 15 of the FCC Rules. Operaon is subject to the following two

condions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause

undesired

operaon.

EU Conformity Statement

This product and - if applicable - the supplied accessories too are marked with "CE"

and comply therefore with the applicable harmonized European standards listed

DS-K1T331 Series Face Recognion Terminal User Manual

under the EMC Direcve 2014/30/EU, RE Direcve 2014/53/EU,the RoHS Direcve

2011/65/EU

2012/19/EU (WEEE direcve): Products marked with this symbol cannot be disposed

of as unsorted municipal waste in the European Union. For proper recycling, return

this product to your local supplier upon the purchase of equivalent new equipment,

or dispose of it at designated

collecon points. For more informaon see:

www.recyclethis.info

2006/66/EC (baery direcve): This product contains a baery that cannot be

disposed of as unsorted municipal waste in the European Union. See the product

documentaon for specic baery informaon. The baery is marked with this

symbol, which may include

leering to indicate cadmium (Cd), lead (Pb), or mercury

(Hg). For proper recycling, return the

baery to your supplier or to a designated

collecon point. For more informaon see:www.recyclethis.info

DS-K1T331 Series Face Recognion Terminal User Manual

Safety Instrucon

These instrucons are intended to ensure that user can use the product correctly to avoid danger

or property loss.

The

precauon measure is divided into Dangers and Cauons:

Dangers: Neglecng any of the warnings may cause serious injury or death.

Cauons: Neglecng any of the cauons may cause injury or equipment damage.

Dangers: Follow these safeguards to prevent

serious injury or death.

Cauons: Follow these precauons to prevent

potenal injury or material damage.

Danger:

●

All the electronic operaon should be strictly compliance with the electrical safety regulaons,

re prevenon regulaons and other related regulaons in your local region.

●

Please use the power adapter, which is provided by normal company. The power consumpon

cannot be less than the required value.

●

Do not connect several devices to one power adapter as adapter overload may cause over-heat

re hazard.

●

Please make sure that the power has been disconnected before you wire, install or dismantle the

device.

●

When the product is installed on wall or ceiling, the device shall be

rmly xed.

●

If smoke, odors or noise rise from the device, turn

o the power at once and unplug the power

cable, and then please contact the service center.

●

1. Risk of explosion if the baery is replaced by an incorrect type

2. Improper replacement of the

baery with an incorrect type may defeat a safeguard (for

example, in the case of some lithium baery types).

3. This equipment is not suitable for use in

locaons where children are likely to be present.

4. Do not dispose of the baery into re or a hot oven, or mechanically crush or cut the baery,

which may result in an explosion.

5. Do not leave the baery in an extremely high temperature surrounding environment, which

may result in an explosion or the leakage of

ammable liquid or gas.

6. Do not subject the baery to extremely low air pressure, which may result in an explosion or

the leakage of ammable liquid or gas.

7. Dispose of used

baeries according to the instrucons

●

If the product does not work properly, please contact your dealer or the nearest service center.

Never

aempt to disassemble the device yourself. (We shall not assume any responsibility for

problems caused by unauthorized repair or maintenance.)

DS-K1T331 Series Face Recognion Terminal User Manual

Cauons:

●

Do not drop the device or subject it to physical shock, and do not expose it to high

electromagnesm radiaon. Avoid the equipment installaon on vibraons surface or places

subject to shock (ignorance can cause equipment damage).

●

Do not place the device in extremely hot (refer to the specicaon of the device for the detailed

operang temperature), cold, dusty or damp locaons, and do not expose it to high

electromagnec radiaon.

●

The device cover for indoor use shall be kept from rain and moisture.

●

Exposing the equipment to direct sun light, low venlaon or heat source such as heater or

radiator is forbidden (ignorance can cause re danger).

●

Do not aim the device at the sun or extra bright places. A blooming or smear may occur

otherwise (which is not a malfuncon however), and aecng the endurance of sensor at the

same me.

●

Please use the provided glove when open up the device cover, avoid direct contact with the

device cover, because the acidic sweat of the ngers may erode the surface coang of the device

cover.

●

Please use a so and dry cloth when clean inside and outside surfaces of the device cover, do

not use alkaline detergents.

●

Please keep all wrappers

aer unpack them for future use. In case of any failure occurred, you

need to return the device to the factory with the original wrapper. Transportaon without the

original wrapper may result in damage on the device and lead to addional costs.

●

Improper use or replacement of the

baery may result in hazard of explosion. Replace with the

same or equivalent type only. Dispose of used baeries according to the instrucons provided by

the

baery manufacturer.

●

Biometric recognion products are not completely applicable to an-spoong environments. If

you require a higher security level, use

mulple authencaon modes.

●

Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited Power

Source with 100~240 VAC or 12 VDC according to the IEC60950-1 standard. Please refer to

technical

specicaons for detailed informaon.

DS-K1T331 Series Face Recognion Terminal User Manual

vii

Available Models

Product Name Model

Face Recognion Terminal DS-K1T331

DS-K1T331W

Use only power supplies listed in the user instrucons:

Model Manufacturer Standard

ADS-26FSG-12 12018EPG Shenzhen Honor Electronic Co.,

Ltd.

ADS-26FSG-12 12018EPI-01 Shenzhen Honor Electronic Co.,

Ltd.

ADS-26FSG-12 12018EPCU Shenzhen Honor Electronic Co.,

Ltd.

PCU

ADS-26FSG-12 12018EPB Shenzhen Honor Electronic Co.,

Ltd.

MSA-C1500IC12.0-18P-BR MOSO Technology Co., Ltd. PBR

DS-K1T331 Series Face Recognion Terminal User Manual

viii

Contents

Chapter 1 Overview .................................................................................................................... 1

1.1 Overview ................................................................................................................................ 1

1.2 Features ................................................................................................................................. 1

Chapter 2 Appearance ................................................................................................................ 2

Chapter 3 Installaon ................................................................................................................. 3

3.1 Installaon Environment ........................................................................................................ 3

3.2 Base Mounng ....................................................................................................................... 3

3.3 Install with Gang Box ............................................................................................................. 4

Chapter 4 Wiring ...................................................................................................................... 10

4.1 Terminal

Descripon ............................................................................................................ 10

4.2 Wire Normal Device ............................................................................................................. 11

4.3 Wiring with Power Cable ..................................................................................................... 12

Chapter 5

Acvaon ................................................................................................................. 13

5.1 Acvate via Device ............................................................................................................... 13

5.2

Acvate via Web Browser .................................................................................................... 14

5.3 Acvate via SADP ................................................................................................................. 15

5.4 Acvate Device via Client Soware ...................................................................................... 16

Chapter 6 Quick

Operaon ....................................................................................................... 18

6.1 Select Language ................................................................................................................... 18

6.2 Set Password Change Type ................................................................................................... 18

6.3 Set

Applicaon Mode .......................................................................................................... 19

6.4 Set Network Parameters ...................................................................................................... 20

6.5 Access to Plaorm ............................................................................................................... 21

6.6 Privacy

Sengs .................................................................................................................... 23

6.7 Set Administrator ................................................................................................................. 24

Chapter 7 Basic Operaon ........................................................................................................ 26

DS-K1T331 Series Face Recognion Terminal User Manual

7.1 Login .................................................................................................................................... 26

7.1.1 Login by Administrator ................................................................................................ 26

7.1.2 Login by

Acvaon Password ...................................................................................... 27

7.2 Communicaon Sengs ...................................................................................................... 28

7.2.1 Set Wired Network Parameters .................................................................................. 28

7.2.2 Set Wi-Fi Parameters ................................................................................................... 30

7.2.3 Set RS-485 Parameters ................................................................................................ 32

7.3 User Management ............................................................................................................... 32

7.3.1 Add Administrator ....................................................................................................... 32

7.3.2 Add Face Picture ......................................................................................................... 33

7.3.3 Add Card ..................................................................................................................... 35

7.3.4 Add Password .............................................................................................................. 36

7.3.5 Set

Authencaon Mode ............................................................................................ 37

7.3.6 Search and Edit User ................................................................................................... 37

7.4 Data Management ............................................................................................................... 38

7.4.1 Delete Data ................................................................................................................. 38

7.4.2 Import Data ................................................................................................................. 38

7.4.3 Export Data ................................................................................................................. 39

7.5

Identy Authencaon ........................................................................................................ 39

7.5.1

Authencate via Face .................................................................................................. 39

7.5.2 Authencate via Mulple Credenal .......................................................................... 39

7.6 Basic Sengs ....................................................................................................................... 40

7.7 Set Biometric Parameters .................................................................................................... 41

7.8 Set Access Control Parameters ............................................................................................ 42

7.9 Time and

Aendance Status Sengs .................................................................................. 44

7.9.1 Disable

Aendance Mode via Device ......................................................................... 44

7.9.2 Set Manual Aendance via Device ............................................................................. 45

7.9.3 Set Auto

Aendance via Device .................................................................................. 46

DS-K1T331 Series Face Recognion Terminal User Manual

7.9.4 Set Manual and Auto Aendance via Device .............................................................. 48

7.10 System Maintenance .......................................................................................................... 49

Chapter 8

Operaon via Web Browser ...................................................................................... 51

8.1 Login .................................................................................................................................... 51

8.2 Live View .............................................................................................................................. 51

8.3 Person Management ............................................................................................................ 53

8.4 Search Event ........................................................................................................................ 54

8.5 Conguraon ....................................................................................................................... 54

8.5.1 Set Local Parameters ................................................................................................... 54

8.5.2 View Device Informaon ............................................................................................. 55

8.5.3 Set Time ...................................................................................................................... 55

8.5.4 Set DST ........................................................................................................................ 56

8.5.5 View Open Source

Soware License ........................................................................... 56

8.5.6 Upgrade and Maintenance ......................................................................................... 56

8.5.7 Log Query .................................................................................................................... 58

8.5.8 Security Mode

Sengs ............................................................................................... 58

8.5.9

Cercate Management ............................................................................................. 59

8.5.10 Change Administrator's Password ............................................................................. 60

8.5.11 View Device Arming/Disarming Informaon ............................................................ 60

8.5.12 Network

Sengs ....................................................................................................... 60

8.5.13 Set Video and Audio Parameters .............................................................................. 64

8.5.14 Customize Audio Content ......................................................................................... 65

8.5.15 Set Image Parameters ............................................................................................... 66

8.5.16 Set Supplement Light Brightness .............................................................................. 67

8.5.17 Time and

Aendance Sengs .................................................................................. 68

8.5.18 Access Control

Sengs ............................................................................................. 70

8.5.19 Set Biometric Parameters ......................................................................................... 76

8.5.20 Set

Noce Publicaon ............................................................................................... 79

DS-K1T331 Series Face Recognion Terminal User Manual

Chapter 9 Client Soware Conguraon ................................................................................... 80

9.1 Conguraon Flow of Client Soware ................................................................................. 80

9.2 Device Management ............................................................................................................ 80

9.2.1 Add Device .................................................................................................................. 81

9.2.2 Reset Device Password ................................................................................................ 89

9.3 Group Management ............................................................................................................. 90

9.3.1 Add Group ................................................................................................................... 90

9.3.2 Import Resources to Group ......................................................................................... 91

9.3.3 Edit Resource Parameters ........................................................................................... 91

9.3.4 Remove Resources from Group .................................................................................. 91

9.4 Person Management ............................................................................................................ 92

9.4.1 Add

Organizaon ........................................................................................................ 92

9.4.2

Congure Basic Informaon ....................................................................................... 93

9.4.3 Issue a Card by Local Mode ......................................................................................... 93

9.4.4 Upload a Face Photo from Local PC ............................................................................ 95

9.4.5 Take a Photo via Client ................................................................................................ 96

9.4.6 Collect Face via Access Control Device ....................................................................... 97

9.4.7

Congure Access Control Informaon ........................................................................ 98

9.4.8 Customize Person Informaon .................................................................................. 100

9.4.9

Congure Resident Informaon ................................................................................ 101

9.4.10 Congure Addional Informaon ........................................................................... 101

9.4.11 Import and Export Person Idenfy Informaon ...................................................... 102

9.4.12 Import Person

Informaon ..................................................................................... 102

9.4.13 Import Person Pictures ........................................................................................... 102

9.4.14 Export Person Informaon ...................................................................................... 103

9.4.15 Export Person Pictures ............................................................................................ 103

9.4.16 Delete Registered Pictures ...................................................................................... 104

9.4.17 Get Person

Informaon from Access Control Device .............................................. 104

DS-K1T331 Series Face Recognion Terminal User Manual

xii

9.4.18 Move Persons to Another Organizaon .................................................................. 105

9.4.19 Issue Cards to Persons in Batch ............................................................................... 105

9.4.20 Report Card Loss ..................................................................................................... 106

9.4.21 Set Card Issuing Parameters .................................................................................... 106

9.5

Congure Schedule and Template ..................................................................................... 107

9.5.1 Add Holiday ............................................................................................................... 107

9.5.2 Add Template ............................................................................................................ 108

9.6 Set Access Group to Assign Access Authorizaon to Persons ............................................ 110

9.7 Congure Advanced Funcons .......................................................................................... 112

9.7.1 Congure Device Parameters .................................................................................... 112

9.7.2 Congure Remaining Open/Closed ........................................................................... 117

9.7.3 Congure Mul-Factor Authencaon ..................................................................... 118

9.7.4

Congure Card Reader Authencaon Mode and Schedule .................................... 120

9.7.5

Congure First Person In ........................................................................................... 122

9.7.6 Congure An-Passback ........................................................................................... 123

9.7.7 Congure Device Parameters .................................................................................... 124

9.8

Congure Linkage Acons for Access Control .................................................................... 130

9.8.1 Congure Client Acons for Access Event ................................................................. 130

9.8.2 Congure Device Acons for Access Event ............................................................... 131

9.8.3

Congure Device Acons for Card Swiping ............................................................... 132

9.8.4 Congure Device Acons for Person ID .................................................................... 133

9.9 Door Control ...................................................................................................................... 134

9.9.1 Control Door Status ................................................................................................... 134

9.9.2 Check Real-Time Access Records .............................................................................. 136

9.10 Event Center .................................................................................................................... 136

9.10.1 Enable Receiving Event from Devices ..................................................................... 136

9.10.2 View Real-Time Events ............................................................................................ 137

9.10.3 Search Historical Events .......................................................................................... 139

DS-K1T331 Series Face Recognion Terminal User Manual

xiii

9.11 Time and Aendance ....................................................................................................... 142

9.11.1 Congure Aendance Parameters .......................................................................... 142

9.11.2 Add General Timetable ........................................................................................... 149

9.11.3 Add

Shi .................................................................................................................. 152

9.11.4 Manage Shi Schedule ........................................................................................... 155

9.11.5 Manually Correct Check-in/out Record ................................................................... 158

9.11.6 Add Leave and Business Trip ................................................................................... 159

9.11.7 Calculate Aendance Data ...................................................................................... 160

9.11.8 Aendance Stascs .............................................................................................. 162

9.12 System Conguraon ....................................................................................................... 165

9.12.1 Set General Parameters .......................................................................................... 165

9.12.2 Set Picture Storage .................................................................................................. 166

9.12.3 Set Alarm Sound ..................................................................................................... 167

9.12.4 Set Access Control and Video Intercom Parameters ............................................... 167

9.12.5 Set File Saving Path ................................................................................................. 168

9.12.6 Set Email Parameters .............................................................................................. 168

9.13

Operaon and Maintenance ............................................................................................ 169

Appendix A. Tips When Collecng/Comparing Face Picture .................................................... 170

Appendix B. Tips for Installaon Environment ........................................................................ 172

Appendix C. Dimension .......................................................................................................... 173

Appendix D.

Communicaon Matrix and Device Command .................................................... 174

DS-K1T331 Series Face Recognion Terminal User Manual

xiv

Chapter 1 Overview

1.1 Overview

Face recognion terminal is a kind of access control device for face recognion, which is mainly

applied in security access control systems, such as logisc centers, airports, university campuses,

alarm centrals, dwellings, etc.

1.2 Features

●

3.97-inch LCD touch screen

●

2 MP wide-angle dual-lens

●

Face

an-spoong

●

Face recognion distance: 0.3 m to 1.5 m

●

Suggested height for face

recognion: between 1.4 m and 1.9 m

●

Deep learning algorithm

●

1000 face capacity, 1500 card capacity (when

connecng external card reader), 150,000 event

capacity, and 20,000 captured pictures storage

●

Face

recognion duraon ＜ 0.2 s/User; face recognion accuracy rate ≥ 99%

●

Capture linkage and captured pictures storage

●

Transmits card and user data from or to the client

soware via TCP/IP protocol and saves the

data on the client soware

●

Imports pictures from the USB

ash drive to the device or export pictures, events, from the

device to the USB ash drive

●

Stand-alone operaon

●

Manage, search and set device data aer logging in the device locally

●

Connects to one external card reader via RS-485 protocol

●

Connects to secure door control unit via RS-485 protocol to avoid the door opening when the

device is destroyed

●

Audio prompt

●

Watchdog design and tamper

funcon

●

Support English, Spanish (South America), Arabic, Thai, Indonesian, Russian, Vietnamese,

Portuguese (Brazil)

DS-K1T331 Series Face Recognion Terminal User Manual

Chapter 2 Appearance

Refer to the following contents for detailed informaon of the face recognion terminal:

Figure 2-1 Face Recognion Terminal Diagram

Table 2-1 Descripon of Face Recognion Terminal

No. Name Descripon

1 Display Screen 3.97-inch LCD touch screen.

2 Supplement Light Supplement light camera.

3 Camera 1 Recording or capturing videos or pictures.

4 Camera 2 Recording or capturing videos or pictures.

5 microUSB Interface Connect to USB ash drive via a microUSB to

USB cable.

6 Tamper Aer installaon, if the device is disassembled,

a tamper alarm will be triggered.

7 Network Interface Connect to Ethernet.

8 Wiring Terminals Connect to other external devices, including RS-

485 card reader, door lock, etc.

9 Debugging Port The debug terminal is used for debugging only.

DS-K1T331 Series Face Recognion Terminal User Manual

Chapter 3 Installaon

3.1 Installaon Environment

●

Avoid backlight, direct sunlight, and indirect sunlight.

●

For

beer recognion, there should be light source in or near the installaon environment.

●

The minimum bearing weight of the wall or other places should be 3

mes heavier than the

device weight.

●

There shall be no strong

reecve objects (such as glass doors/walls, stainless steel objects,

acrylic and other glossy

plascs, lacquer, ceramic les, etc.) within 1 m of the eld of view of the

device.

●

Avoid device reecon.

●

Face recognion distance shall be greater than 30 cm.

●

Keep the camera clean.

Note

For details about installaon environment, see Tips for Installaon Environment.

3.2 Base Mounng

Place the device on the desk or other ats by using the mounng bracket.

Steps

Route the cables through the cable hole of the bracket, and connect the terminals with external

devices' cables.

Align the device two holes with the two buckles on the bracket.

Hang the device on the bracket and make sure the buckle in the middle of the bracket is inserted

in the groove on the device back.

DS-K1T331 Series Face Recognion Terminal User Manual

Figure 3-1 Base Mounng

Place the assembled device and bracket on the desk or other ats.

3.3 Install with Gang Box

Steps

According to the datum line on the mounng template, sck the mounng template on the wall

or other surface, 1.45 meters higher than the ground.

DS-K1T331 Series Face Recognion Terminal User Manual

Figure 3-2 Mounng Template

Drill holes on the wall or other surface according to the mounng template and install the gang

box.

DS-K1T331 Series Face Recognion Terminal User Manual

Figure 3-3 Install Gang Box

Use two supplied screws (SC-KM4x25-SUS or KA4×22-SUS) to secure the mounng plate on the

gang box.

DS-K1T331 Series Face Recognion Terminal User Manual

Figure 3-4 Install Mounng Plate

Route the cables through the cable hole of the mounng plate, and connect the terminals with

the external devices' cables.

Align the device with the

mounng plate and hang the device on the mounng plate.

DS-K1T331 Series Face Recognion Terminal User Manual

Figure 3-5 Install Device

Use one supplied screw to secure the device and the mounng plate.

DS-K1T331 Series Face Recognion Terminal User Manual

Figure 3-6 Secure Device

Note

●

The installaon height here is the recommended height. You can change it according to your

actual needs.

●

For easy installaon, drill holes on mounng surface according to the supplied mounng

template.

DS-K1T331 Series Face Recognion Terminal User Manual

Chapter 4 Wiring

●

If the device should connect with peripherals, it supports wiring with the RS-485 card reader, the

door lock, the exit

buon, and the power supply.

Note

If the cable size is 18 AWG, you should use a 12 V power supply. And the distance between the

power supply and the device should be no more than 80 m.

●

If the device has no peripherals to be wired, it supports wiring with the power supply by using

the supplied adaptor.

4.1 Terminal

Descripon

The terminals contains power input, RS-485, and door lock.

The terminal's diagram is as follows:

Figure 4-1 Terminal Diagram

The descripons of the terminals are as follows:

DS-K1T331 Series Face Recognion Terminal User Manual

Table 4-1 Terminal Descripons

Group No. Funcon Color Name Descripon

Group A A1 Power Input Red +12 V 12 VDC Power

Supply

A2 Black GND Ground

Group B B1 RS-485 Yellow 485+ RS-485 Wiring

B2 Blue 485-

B3 Black GND Ground

Group C C1 Door Lock Orange NC Lock Wiring

(NC)

C2 Green COM Common

C3 Grey NO Lock Wiring

(NO)

C4 White SENSOR Door Contact

(Sensor)

C5 Purple BTN Exit Door

Wiring

C6 Black GND Ground

C7 Black GND Ground

4.2 Wire Normal Device

You can connect the terminal with normal peripherals.

DS-K1T331 Series Face Recognion Terminal User Manual

Figure 4-2 Device Wiring

Note

●

The power input should be 12 VDC, 1.5 A, 18 W.

●

Do not wire the device to the electric supply directly.

4.3 Wiring with Power Cable

Wire the device with power supply directly by using the supplied power cable if the device has no

other peripherals to be wired.

The wiring diagram is shown below:

Figure 4-3 Wiring with Power Cable

DS-K1T331 Series Face Recognion Terminal User Manual

Chapter 5 Acvaon

You should acvate the device before the rst login. Aer powering on the device, the system will

switch to Device

Acvaon page.

Acvaon via the device, SADP tool and the client soware are supported.

The default values of the device are as follows:

●

The default IP address: 192.0.0.64

●

The default port No.: 8000

●

The default user name: admin

5.1

Acvate via Device

If the device is not acvated, you can acvate the device aer it is powered on.

On the Acvate Device page, create a password and conrm the password. Tap Acvate and the

device will acvated.

Figure 5-1 Acvaon Page

Cauon

The password strength of the device can be automacally checked. We highly recommend you

change the password of your own choosing (using a minimum of 8 characters, including at least

DS-K1T331 Series Face Recognion Terminal User Manual

three kinds of following categories: upper case leers, lower case leers, numbers, and special

characters) in order to increase the security of your product. And we recommend you change your

password regularly, especially in the high security system, changing the password monthly or

weekly can

beer protect your product.

Proper

conguraon of all passwords and other security sengs is the responsibility of the

installer and/or end-user.

Note

Characters containing admin and nimda are not supported to be set as acvaon password.

●

Aer acvaon, you should select a language according to your actual needs.

●

Aer acvaon, you should select an applicaon mode. For details, see Set Applicaon Mode .

●

Aer acvaon, if you need to add the device to the client soware or other plaorms, you

should edit the device IP address. For details, see

Set Network Parameters .

●

Aer acvaon, if you need to operate the device remotely via APP, you should scan the QR

code to link to the APP. For details, see .

●

Aer acvaon, if you need to add administrator to manage the device parameters, you should

set administrator. For details, see Add Administrator .

5.2

Acvate via Web Browser

You can acvate the device via the web browser.

Steps

Enter the device default IP address (192.0.0.64) in the address bar of the web browser, and press

Enter.

Note

Make sure the device IP address and the computer's should be in the same IP segment.

Create a new password (admin password) and conrm the password.

Cauon

STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of

your own choosing (using a minimum of 8 characters, including upper case leers, lower case

leers, numbers, and special characters) in order to increase the security of your product. And

we recommend you reset your password regularly, especially in the high security system,

reseng the password monthly or weekly can beer protect your product.

Note

Characters containing admin and nimda are not supported to be set as acvaon password.

Click Acvate.

DS-K1T331 Series Face Recognion Terminal User Manual

Edit the device IP address. You can edit the IP address via the SADP tool, the device, and the

client soware.

5.3 Acvate via SADP

SADP is a tool to detect, acvate and modify the IP address of the device over the LAN.

Before You Start

●

Get the SADP soware from the supplied disk or the ocial website hp://

www.hikvision.com/en/ , and install the SADP according to the prompts.

●

The device and the PC that runs the SADP tool should be within the same subnet.

The following steps show how to acvate a device and modify its IP address. For batch acvaon

and IP addresses modicaon, refer to User Manual of SADP for details.

Steps

Run the SADP

soware and search the online devices.

Find and select your device in online device list.

Input new password (admin password) and conrm the password.

Cauon

STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of

your own choosing (using a minimum of 8 characters, including upper case leers, lower case

leers, numbers, and special characters) in order to increase the security of your product. And

we recommend you reset your password regularly, especially in the high security system,

reseng the password monthly or weekly can beer protect your product.

Note

Characters containing admin and nimda are not supported to be set as acvaon password.

Click Acvate to start acvaon.

DS-K1T331 Series Face Recognion Terminal User Manual

Status of the device becomes Acve aer successful acvaon.

Modify IP address of the device.

1) Select the device.

2) Change the device IP address to the same subnet as your computer by either modifying the IP

address manually or checking Enable DHCP.

3) Input the admin password and click Modify to

acvate your IP address modicaon.

5.4

Acvate Device via Client Soware

For some devices, you are required to create the password to acvate them before they can be

added to the

soware and work properly.

Steps

Note

This funcon should be supported by the device.

Enter the Device Management page.

Click on the right of Device Management and select Device.

Click Online Device to show the online device area.

The searched online devices are displayed in the list.

Check the device status (shown on Security Level column) and select an

inacve device.

Click

Acvate to open the Acvaon dialog.

Create a password in the password eld, and conrm the password.

DS-K1T331 Series Face Recognion Terminal User Manual

Cauon

The password strength of the device can be automacally checked. We highly recommend you

change the password of your own choosing (using a minimum of 8 characters, including at least

three kinds of following categories: upper case leers, lower case leers, numbers, and special

characters) in order to increase the security of your product. And we recommend you change

your password regularly, especially in the high security system, changing the password monthly

or weekly can

beer protect your product.

Proper conguraon of all passwords and other security sengs is the responsibility of the

installer and/or end-user.

Note

Characters containing admin and nimda are not supported to be set as acvaon password.

Click OK to acvate the device.

DS-K1T331 Series Face Recognion Terminal User Manual

Chapter 6 Quick Operaon

6.1 Select Language

You can select a language for the device system.

Aer the device acvaon, you can select a language for the device system.

Figure 6-1 Select System Language

By default, the system language is English.

Note

Aer you change the system language, the device will reboot automacally.

6.2 Set Password Change Type

Aer acvang the device, you can set the password change type as reserved email address or

security

quesons. Once you forgot the device password, you can change the password via the

selected change type.

Change Password via Email Address

If you need to change password via reserved email, you can enter an email address, and tap Next.

DS-K1T331 Series Face Recognion Terminal User Manual

Figure 6-2 Password Change Page

Change via Security

Quesons

If you need to change password via security quesons, you can tap Change to Security Quesons

on the right corner. Select the security quesons and enter the answers. Click Next.

Note

You can only select one type to change password. If you need, you can enter the web page to set

both of the changing types.

6.3 Set Applicaon Mode

Aer acvang the device, you should select an applicaon mode for beer device applicaon.

Steps

On the Welcome page, select Indoor or Others from the drop-down list.

DS-K1T331 Series Face Recognion Terminal User Manual

Figure 6-3 Welcome Page

Tap OK to save.

Note

●

You can also change the sengs in System Sengs.

●

If you install the device indoors near the window or the face recognion funcon is not

working well, select Others.

●

If you do not

congure the applicaon mode and tap Next, the system will select Indoor by

default.

●

If you

acvate the device via other tools remotely, the system will select Indoor as the

applicaon mode by default.

6.4 Set Network Parameters

Aer acvaon and select applicaon mode, you can set the network for the device

Steps

When you enter the Select Network page, tap Wired Network or Wi-Fi for your actual needs.

DS-K1T331 Series Face Recognion Terminal User Manual

Figure 6-4 Select Network

Note

Disconnect the wired network before connecng a Wi-Fi.

Tap Next.

Wired Network

Note

Make sure the device has connected to a network.

If enable DHCP, the system will assign the IP address and other parameters automacally.

If disable DHCP, you should set the IP address, the subnet mask, and the gateway.

Wi-Fi

Select a Wi-Fi and enter the Wi-Fi's password to get connected.

Or tap Add Wi-Fi and enter the Wi-Fi's name and the password to get connected.

Oponal: Tap Skip to skip network sengs.

6.5 Access to

Plaorm

Enable the funcon and the device can communicate via Hik-Connect. You can add the device to

Hik-Connect modile client and so on.

DS-K1T331 Series Face Recognion Terminal User Manual

Steps

Enable Access to Hik-Connect, and set the server IP and vericaon code.

Figure 6-5 Access to Hik-Connect

Tap Next.

Oponal: Tap Skip to skip the step.

Oponal: Tap Previous to go to the previous page.

Note

If you tap Previous to return to the Wi-Fi conguraon page, you need to tap the connected Wi-

Fi or connect another Wi-Fi to enter the plaorm page again.

DS-K1T331 Series Face Recognion Terminal User Manual

6.6 Privacy Sengs

Aer acvaon, selecng applicaon mode, and selecng network, you should set the privacy

parameters, including the picture uploading and storage.

Select parameters according to your actual needs.

Figure 6-6 Privacy

Upload Captured Pic. When Auth. (Upload Captured Picture When Authencang)

Upload the pictures captured when authencang to the plaorm automacally.

Save Captured Pic. When Auth. (Save Captured Picture When Authencang)

If you enable this funcon, you can save the picture when Authencang to the device.

Save Registered Pic. (Save Registered Picture)

The registered face picture will be saved to the system if you enable the funcon.

Upload Pic. Aer Linked Capture (Upload Picture Aer Linked Capture)

Upload the pictures captured by linked camera to the plaorm automacally.

Save Pic. Aer Linked Capture (Save Pictures Aer Linked Capture)

If you enable this funcon, you can save the picture captured by linked camera to the device.

Tap Next to complete the sengs.

DS-K1T331 Series Face Recognion Terminal User Manual

6.7 Set Administrator

Aer device acvaon, you can add an administrator to manage the device parameters.

Before You Start

Acvate the device and select an applicaon mode.

Steps

Oponal: Tap Skip to skip adding administrator if required.

Enter the administrator's name

(oponal) and tap Next.

Figure 6-7 Add Administrator Page

Select a credenal to add.

Note

Up to one credenal should be added.

: Face forward at the camera. Make sure the face is in the face recognion area. Click to

capture and click to conrm.

: Enter the card No. or present card on the card presenng area. Click OK.

Click OK.

You will enter the authencaon page.

Status Icon

Descripon

DS-K1T331 Series Face Recognion Terminal User Manual

Device is armed/not armed.

Hik-Connect is enabled/disabled.

/ /

The device wired network is connected/not connected/connecng failed.

/ /

The device' Wi-Fi is enabled and connected/not connected/enabled but not connected.

Shortcut Keys

Descripon

Note

You can congure those shortcut keys displayed on the screen. For details, see Basic Sengs .

Scan QR code to authencate.

Note

The QR code can be obtained from the visitor terminal.

●

Enter the device room No. and tap OK to call.

●

Tap to call the center.

Note

The device should be added to the center, or the calling operaon will be failed.

Enter password to authencate.

DS-K1T331 Series Face Recognion Terminal User Manual

Chapter 7 Basic Operaon

7.1 Login

7.1.1 Login by Administrator

If you have added an administrator for the device, only the administrator can login the device for

device

operaon.

Steps

Long tap on the inial page for 3 s and slide to the le/right by following the gesture to enter

the admin login page.

Figure 7-1 Admin Login

Authencate the administrator's face to enter the home page.

DS-K1T331 Series Face Recognion Terminal User Manual

Figure 7-2 Home Page

Note

The device will be locked for 30 minutes aer 5 failed aempts.

Oponal: Tap and you can enter the device acvaon password for login.

Oponal: Tap and you can exit the admin login page.

7.1.2 Login by

Acvaon Password

You should login the system before other device operaons. If you do not congure an

administrator, you should follow the instrucons below to login.

Steps

Long tap on the inial page for 3 s and slide to the le/right by following the gesture to enter

password entering page.

Tap the Password

eld and enter the device acvaon password.

Tap OK to enter the home page.

Note

The device will be locked for 30 minutes aer 5 failed password aempts.

DS-K1T331 Series Face Recognion Terminal User Manual

Figure 7-3 Home Page

7.2

Communicaon Sengs

You can set the network parameters, the Wi-Fi parameter, and the RS-485 parameters on the

communicaon sengs page.

7.2.1 Set Wired Network Parameters

You can set the device wired network parameters, including the IP address, the subnet mask, the

gateway, and DNS parameters.

Steps

Tap Comm. (Communicaon Sengs) on the Home page to enter the Communicaon Sengs

page.

On the Communicaon Sengs page, tap Wired Network.

DS-K1T331 Series Face Recognion Terminal User Manual

Figure 7-4 Wired Network Sengs

Set IP Address, Subnet Mask, and Gateway.

Enable DHCP, and the system will assign IP address, subnet mask, and gateway automacally.

Disable DHCP, and you should set the IP address, subnet mask, and gateway manually.

Note

The device's IP address and the computer IP address should be in the same IP segment.

Set the DNS parameters. You can enable Auto Obtain DNS, set the preferred DNS server and the

alternate DNS server.

DS-K1T331 Series Face Recognion Terminal User Manual

7.2.2 Set Wi-Fi Parameters

You can enable the Wi-Fi funcon and set the Wi-Fi related parameters.

Steps

Note

The funcon should be supported by the device.

Tap Comm. (Communicaon Sengs) on the Home page to enter the Communicaon Sengs

page.

On the Communicaon Sengs page, tap.

DS-K1T331 Series Face Recognion Terminal User Manual

Figure 7-5 Wi-Fi Sengs

Enable the Wi-Fi funcon.

Congure the Wi-Fi parameters.

Select a Wi-Fi from the list, and enter the Wi-Fi's password. Tap OK.

If the target Wi-Fi is not in the list,tap Add Wi-Fi. Enter the Wi-Fi's name and password. And

tap OK.

Note

Only digits, leers, and special characters are allowed in the password.

Set the Wi-Fi's parameters.

By default, DHCP is enable. The system will allocate the IP address, the subnet mask, and the

gateway automacally.

DS-K1T331 Series Face Recognion Terminal User Manual

If disable DHCP, you should enter the IP address, the subnet mask, and the gateway manually.

Tap OK to save the sengs and go back to the Wi-Fi tab.

Tap to save the network parameters.

7.2.3 Set RS-485 Parameters

The face recognion terminal can connect secure door control unit or card reader via the RS-485

terminal.

Steps

Tap Comm. (Communicaon Sengs) on the Home page to enter the Communicaon Sengs

page.

On the Communicaon Sengs page, tap RS-485 to enter the RS-485 tab.

Figure 7-6 Set RS-485 Parameters

Select an peripheral type according to your actual needs.

Note

If you select Access Controller: If connect the device to a terminal via the RS-485 interface, set

the RS-485 address as 2.

Tap the back icon at the upper le corner and you should reboot the device if you change the

parameters.

7.3 User Management

On the user management interface, you can add, edit, delete and search the user.

7.3.1 Add Administrator

The administrator can login the device backend and congure the device parameters.

Steps

Long tap on the inial page and log in the backend.

Tap User → + to enter the Add User page.

Edit the employee ID.

DS-K1T331 Series Face Recognion Terminal User Manual

Note

●

The employee ID should be less than 32 characters. And it can be a combinaon of lower

leers, upper leers, and numbers.

●

The employee ID should not be duplicated.

Tap the Name eld and input the user name on the so keyboard.

Note

●

Numbers, upper case leers, lower case leers, and special characters are allowed in the user

name.

●

Up to 32 characters are allowed in the user name.

Oponal: Add a face picture, or cards for the administrator.

Note

●

For details about adding a face picture, see Add Face Picture .

●

For details about adding a card, see Add Card .

Oponal: Set the administrator's authencaon type.

Note

For details about seng the authencaon type, see Set Authencaon Mode .

Enable the Administrator Permission funcon.

Enable Administrator Permission

The user is the administrator. Except for the normal aendance funcon, the user can also

enter the Home page to operate aer authencang the permission.

Tap

to save the sengs.

7.3.2 Add Face Picture

Add user's face picture to the device. And the user can use the face picture to authencate.

Steps

Note

Up to 1000 face pictures can be added.

Long tap on the inial page for 3 s and slide to the le/right by following the gesture and log in

the backend.

Tap User → + to enter the Add User page.

Edit the employee ID.

DS-K1T331 Series Face Recognion Terminal User Manual

Note

●

The employee ID should be less than 32 characters. And it can be a combinaon of lower

leers, upper leers, and numbers.

●

The employee ID should not be duplicated.

Tap the Name eld and input the user name on the so keyboard.

Note

●

Numbers, upper case leers, lower case leers, and special characters are allowed in the user

name.

●

The suggested user name should be within 32 characters.

Tap the Face Picture eld to enter the face picture adding page.

Figure 7-7 Add Face Picture

Look at the camera.

Note

●

Make sure your face picture is in the face picture outline when adding the face picture.

●

Make sure the captured face picture is in good quality and is accurate.

●

For details about the instrucons of adding face pictures, see Tips When Collecng/

Comparing Face Picture .

Aer completely adding the face picture, a captured face picture will be displayed at the upper

right corner of the page.

Tap Save to save the face picture.

DS-K1T331 Series Face Recognion Terminal User Manual

Oponal: Tap Try Again and adjust your face posion to add the face picture again.

Set the user role.

Administrator

The user is the administrator. Except for the normal aendance funcon, the user can also

enter the Home page to operate aer authencang the permission.

Normal User

The User is the normal user. The user can only

authencate or take aendance on the inial

page.

10.

Tap

to save the sengs.

7.3.3 Add Card

Add a card for the user and the user can authencate via the added card.

Steps

Note

Up to 1500 cards can be added.

Long tap on the inial page for 3 s and slide to the le/right by following the gesture and log in

the backend.

Tap User → + to enter the Add User page.

Connect an external card reader according to the wiring diagram.

Tap the Employee ID.

eld and edit the employee ID.

Note

●

The employee ID should be less than 32 characters. And it can be a combinaon of lower

leers, upper leers, and numbers.

●

The employee ID should not be duplicated.

Tap the Name eld and input the user name on the so keyboard.

Note

●

Numbers, upper case leers, lower case leers, and special characters are allowed in the user

name.

●

The suggested user name should be within 32 characters.

Tap the Card eld and tap +.

Congure the card No.

Enter the card No. manually.

Present the card over the card

presenng area to get the card No.

DS-K1T331 Series Face Recognion Terminal User Manual

Note

●

The card No. cannot be empty.

●

Up to 20 characters are allowed in the card No.

●

The card No. cannot be duplicated.

Congure the card type.

Set the user role.

Administrator

The user is the administrator. Except for the normal

aendance funcon, the user can also

enter the Home page to operate aer authencang the permission.

Normal User

The User is the normal user. The user can only authencate or take aendance on the inial

page.

10.

Tap to save the sengs.

7.3.4 Add Password

Add a password for the user and the user can authencate via the password.

Steps

Long tap on the inial page for 3 s and slide to the le/right by following the gesture and log in

the backend.

Tap User → + to enter the Add User page.

Tap the Employee ID.

eld and edit the employee ID.

Note

●

The employee ID should be less than 32 characters. And it can be a combinaon of lower

leers, upper leers, and numbers.

●

The employee ID should not be duplicated.

Tap the Name eld and input the user name on the so keyboard.

Note

●

Numbers, upper case leers, lower case leers, and special characters are allowed in the user

name.

●

The suggested user name should be within 32 characters.

Tap the Password eld and create a password and conrm the password.

Note

●

Only numbers are allowed in the password.

●

4 to 8 digits are allowed in the password.

Set the user role.

DS-K1T331 Series Face Recognion Terminal User Manual

Administrator

The user is the administrator. Except for the normal aendance funcon, the user can also

enter the Home page to operate aer authencang the permission.

Normal User

The User is the normal user. The user can only authencate or take aendance on the inial

page.

Tap

to save the sengs.

7.3.5 Set Authencaon Mode

Aer adding the user's face picture, password, or other credenals, you should set the

authencaon mode and the user can authencate his/her identy via the congured

authencaon

mode.

Steps

Long tap on the inial page for 3 s and slide to the le/right by following the gesture and log in

the backend.

Tap User → Add User/Edit User →

Authencaon Mode .

Select Device or Custom as the authencaon mode.

Device

If you want to select device mode, you should set the terminal authencaon mode in Access

Control

Sengs page rst. For details see Seng Access Control Parameters.

Custom

You can combine dierent authencaon modes together according to your actual needs.

Tap to save the sengs.

7.3.6 Search and Edit User

Aer adding the user, you can search the user and edit it.

Search User

On the User Management page, Tap the search area to enter the Search User page. Tap Card on

the

le of the page and select a search type from the drop-down list. Enter the employee ID, card

No., or the user name for search. Tap to search.

Edit User

On the User Management page, select a user from the user list to enter the Edit User page. Follow

the steps in User Management to edit the user parameters. Tap to save the sengs.

DS-K1T331 Series Face Recognion Terminal User Manual

Note

The employee ID cannot be edited.

7.4 Data Management

You can delete data, import data, and export data.

7.4.1 Delete Data

Delete user data.

On the Home page, tap Data → Delete Data → User Data . All user data added in the device will be

deleted.

7.4.2 Import Data

Steps

Plug a USB

ash drive in the device.

On the Home page, tap Data → Import Data .

Tap User Data or Face Data.

Enter the created password when you exported the data. If you do not create a password when

you exported the data, leave a blank in the input box and tap OK immediately.

Note

●

If you want to transfer all user informaon from one device (Device A) to another (Device B),

you should export the informaon from Device A to the USB ash drive and then import from

the USB ash drive to Device B. In this case, you should import the user data before imporng

the prole photo.

●

The supported USB

ash drive format is FAT32.

●

The imported pictures should be saved in the folder (named enroll_pic) of the root directory

and the picture's name should be follow the rule below:

Card No._Name_Department_Employee ID_Gender.jpg

●

If the folder enroll_pic cannot save all imported pictures, you can create another folders,

named enroll_pic1, enroll_pic2, enroll_pic3, enroll_pic4, under the root directory.

●

The employee ID should be less than 32 characters. It can be a combinaon of lower leers,

upper leers, and numbers. It should not be duplicated, and should not start with 0.

●

Requirements of face picture should follow the rules below: It should be taken in full-face

view, directly facing the camera. Do not wear a hat or head covering when taking the face

picture. The format should be JPEG or JPG. The resoluon should be 640 × 480 pixel or more

than of 640 × 480 pixel. The picture size should be less than 2 M.

DS-K1T331 Series Face Recognion Terminal User Manual

7.4.3 Export Data

Steps

Plug a USB

ash drive in the device.

On the Home page, tap Data → Export Data .

Tap Event Data, User Data, or Face Data.

Oponal: Create a password for exporng. When you import those data to another device, you

should enter the password.

Note

●

The supported USB ash drive format is DB.

●

The system supports the USB ash drive with the storage of 1G to 32G. Make sure the free

space of the USB ash drive is more than 512M.

●

The exported user data is a DB

le, which cannot be edited.

7.5 Identy Authencaon

Aer network conguraon, system parameters conguraon and user conguraon, you can go

back to the

inial page for identy authencaon. The system will authencate person according

to the congured authencaon mode.

You can

authencate identy via 1:N matching.

1:N Matching

Compare the captured face picture or with all face pictures stored in the device.

7.5.1

Authencate via Face

If the authencaon mode is Face, posion the face looking at the camera to start face

authencaon.

If authencaon completed, a prompt "Authencated" will pop up.

7.5.2

Authencate via Mulple Credenal

Before You Start

Set the user

authencaon type before authencaon. For details, see Set Authencaon Mode .

Steps

If the authencaon mode is Password and Face, authencate face according to the instrucons

on the live view page.

Aer the previous credenal is authencated, connue authencate password.

DS-K1T331 Series Face Recognion Terminal User Manual

Note

For detailed informaon about authencang face, see Tips When Collecng/Comparing Face

Picture.

If authencaon succeeded, the prompt "Authencated" will pop up.

7.6 Basic Sengs

You can set the shortcut key, voice, me, select language, and the supplement light.

Long tap on the inial page for 3 s and slide to the le/right by following the gesture and login the

device home page. Tap Basic.

Figure 7-8 Basic Sengs Page

shortcut key, voice, me, community No., building No., and Unit No.

Shortcut Key

Choose the shortcut key that displayed on the authencaon page, including the call funcon,

and the password entering funcon.

Voice Sengs

You can enable/disable the voice prompt funcon and adjust the voice volume.

DS-K1T331 Series Face Recognion Terminal User Manual

Note

You can set the voice volume between 0 and 10.

Time Sengs

Set the me zone, the device me and the DST.

Select Language

Select the system language. Aer the language is changed, the system will reboot to take eect.

Supplement Light Sengs

Tap White Light and you can set the supplement light mode. You can select to enable or disable

the supplement light, or customize the supplement light's brightness, start me, and end me.

7.7 Set Biometric Parameters

You can customize the face parameters to improve the face recognion performance. The

congurable parameters includes applicaon mode, face liveness level, face recognion distance,

face recognion interval, wide dynamic, face 1:N security level, ECO sengs, and face with mask

detecon.

Long tap on the inial page for 3 s and login the home page. Tap Biometric.

Table 7-1 Face Picture Parameters

Parameter Descripon

Applicaon Mode Select either others or indoor according to actual environment.

Face Liveness Level Aer enabling face an-spoong funcon, you can set the matching

security level when performing live face authencaon.

Face Recognion

Distance

Set the valid distance between the user and the camera when

authencang.

Face Recognion

Interval

The me interval between two connuous face recognions when

authencang.

Note

You can input the number from 1 to 10.

Wide Dynamic It is suggested to enable the WDR funcon if installing the device

outdoors.

When there are both very bright and very dark areas simultaneously in

the view, you can enable the WDR

funcon to balance the brightness of

the whole image and provide clear images with details.

DS-K1T331 Series Face Recognion Terminal User Manual

Parameter Descripon

Face 1:N Security Level Set the matching threshold when authencang via 1:N matching mode.

The larger the value, the smaller the false accept rate and the larger the

false rejecon rate.

ECO Sengs Aer enabling the ECO mode, the device will use the IR camera to

authencate faces in the low light or dark environment. And you can set

the ECO mode threshold, ECO mode (1:N), and ECO mode (1:1).

ECO Threshold

When enabling the ECO mode, you can set the ECO mode’s threshold.

The larger the value, the easier the device entering the ECO mode.

ECO Mode (1:1)

Set the matching threshold when

authencang via ECO mode 1:1

matching mode. The larger the value, the smaller the false accept rate

and the larger the false

rejecon rate.

ECO Mode (1:N)

Set the matching threshold when authencang via ECO mode 1:N

matching mode. The larger the value, the smaller the false accept rate

and the larger the false rejecon rate

Face with Mask

Detecon

Aer enabling the face with mask detecon, the system will recognize

the captured face with mask picture. You can set face with mask & face

1:N level and the strategy.

Reminder of Wearing

If the person do not wear a face mask when authencang, the

device prompts a

nocaon and the door will open.

Must Wear

If the person do not wear a face mask when authencang, the

device prompts a nocaon and the door keeps closed.

7.8 Set Access Control Parameters

You can set the access control permissions, including the funcons of authencaon mode, enable

NFC card, door contact, and door open me.

On the Home page, tap ACS (Access Control Sengs) to enter the Access Control Sengs page.

Edit the access control parameters on this page.

DS-K1T331 Series Face Recognion Terminal User Manual

Figure 7-10 Access Control Parameters

The available parameters descripons are as follows:

Table 7-2 Access Control Parameters

Descripons

Parameter Descripon

Terminal Auth. Mode (Terminal

Authencaon Mode)

Select the face recognion terminal's authencaon mode. You

can also customize the authencaon mode.

Note

●

Biometric recognion products are not completely applicable

to an-spoong environments. If you require a higher

security level, use mulple authencaon modes.

●

If you adopt

mulple authencaon modes, you should

authencate other methods before authencang face.

Reader Auth. Mode (Card

Reader Authencaon Mode)

Select the card reader's authencaon mode.

Enable NFC Card Enable the funcon and you can present the NFC card to

authencate.

Door Contact You can select "Open (Remain Open)" or "Close (Remian

Closed)" according to your actual needs. By default, it is Close

(Remian Closed).

DS-K1T331 Series Face Recognion Terminal User Manual

Parameter Descripon

Open Duraon Set the door unlocking duraon. If the door is not opened for

the set me, the door will be locked. Available door locked me

range: 1 to 255s.

Authencaon Interval Set the device authencang interval. Available authencaon

interval range: 0 to 65535.

7.9 Time and Aendance Status Sengs

You can set the aendance mode as check in, check out, break out, break in, overme in, and

overme out according to your actual situaon.

Note

The funcon should be used cooperavely with me and aendance funcon on the client

soware.

7.9.1 Disable Aendance Mode via Device

Disable the aendance mode and the system will not display the aendance status on the inial

page.

Tap T&A Status to enter the T&A Status page.

DS-K1T331 Series Face Recognion Terminal User Manual

Figure 7-11 Disable Aendance Mode

Set the Aendance Mode as Disable.

You will not view or congure the aendance status on the inial page. And the system will follow

the

aendance rule that congured on the plaorm.

7.9.2 Set Manual

Aendance via Device

Set the aendance mode as manual, and you can select a status manually when you take

aendance.

Before You Start

Add at least one user, and set the user's authencaon mode. For details, see User Management.

Steps

Tap T&A Status to enter the T&A Status page.

Set the

Aendance Mode as Manual.

DS-K1T331 Series Face Recognion Terminal User Manual

Figure 7-12 Manual Aendance Mode

Enable the Aendance Status funcon.

Result

You should select the

aendance status manually aer authencaon.

Note

If you do not select a status, the authencaon will be failed and it will not be marked as a valid

aendance.

7.9.3 Set Auto Aendance via Device

Set the aendance mode as auto, and you can set the aendance status and its available schedule.

The system will automacally change the aendance status according to the congured

parameters.

Before You Start

Add at least one user, and set the user's authencaon mode. For details, see User Management.

Steps

Tap T&A Status to enter the T&A Status page.

Set the

Aendance Mode as Auto.

DS-K1T331 Series Face Recognion Terminal User Manual

Figure 7-13 Auto Aendance Mode

Select an aendance status and set its schedule.

1) Select Check In, Check Out, Break Out, Break In, Overme In, or Overme Out as the

aendance status.

2) Tap Schedule.

3) Select Monday, Tuesday, Wednesday, Thursday, Friday, Saturday, or Sunday.

4) Tap the select date and set the selected

aendance status's start me.

5) Tap Conrm.

6) Repeat step 1 to 5 according to your actual needs.

Note

The aendance status will be valid within the congured schedule.

Result

When you authencate on the inial page, the authencaon will be marked as the congured

aendance status according to the congured schedule.

Example

If set the Break Out Schedule as Monday 11:00, and Break In Schedule as Monday 12:00, the valid

user's

authencaon from Monday 11:00 to 12:00 will be marked as break.

DS-K1T331 Series Face Recognion Terminal User Manual

7.9.4 Set Manual and Auto Aendance via Device

Set the aendance mode as Manual and Auto, and the system will automacally change the

aendance status according to the congured parameters. At the same me you can manually

change the aendance status aer the authencaon.

Before You Start

Add at least one user, and set the user's authencaon mode. For details, see User Management.

Steps

Tap T&A Status to enter the T&A Status page.

Set the

Aendance Mode as Manual and Auto.

Figure 7-14 Manual and Auto Mode

Select an aendance status and set its schedule.

1) Select Check In, Check Out, Break Out, Break In, Overme In, or Overme Out as the

aendance status.

2) Tap Schedule.

3) Select Monday, Tuesday, Wednesday, Thursday, Friday, Saturday, or Sunday.

4) Tap the select date and set the selected

aendance status's start me.

5) Tap Conrm.

6) Repeat step 1 to 5 according to your actual needs.

Note

The aendance status will be valid within the congured schedule.

DS-K1T331 Series Face Recognion Terminal User Manual

Result

On the inial page and authencate. If you do not select a status, the authencaon will be

marked as the congured aendance status according to the schedule. If you tap Select Status and

select a status to take

aendance, the authencaon will be marked as the selected aendance

status.

Example

If set the Break Out Schedule as Monday 11:00, and Break In Schedule as Monday 12:00, the valid

user's

authencaon from Monday 11:00 to 12:00 will be marked as break.

7.10 System Maintenance

You can view the system

informaon and the capacity. You can also upgrade the device, restore to

factory sengs, restore to default sengs, and reboot the device.

Long tap on the

inial page for 3 s and slide to the le/right by following the gesture and login the

home page. Tap Maint..

Hold the ? on the upper-right corner of the page and enter the password to view the version of the

device.

Figure 7-15 Maintenance Page

System Informaon

DS-K1T331 Series Face Recognion Terminal User Manual

You can view the device model, serial No., versions, address, producon data, QR code, and

open source code license.

Note

The page may vary according to dierent device models. Refers to the actual page for details.

Capacity

You can view the number of, user, face picture, card, and event.

Device Upgrade

Plug the USB ash drive in the device USB interface. Tap Upgrade, and the device will read the

digicap.dav

le in the USB ash drive to start upgrading.

Unlink APP Account

Aer unlinking APP account, you cannot operate via APP.

Restore to Default Sengs

All parameters, except for the communicaon sengs, remotely imported user informaon, will

be restored to the default sengs. The system will reboot to take eect.

Restore to Factory Sengs

All parameters will be restored to the factory sengs. The system will reboot to take eect.

Reboot

Reboot the device.

DS-K1T331 Series Face Recognion Terminal User Manual

Chapter 8 Operaon via Web Browser

8.1 Login

You can login via the web browser or the remote conguraon of the client soware.

Note

Make sure the device is acvated. For detailed informaon about acvaon, see Acvaon .

Enter the device IP address in the address bar of the web browser and press Enter to enter the

Note

Make sure that the IP address starts with "Hps:".

Enter the device user name and the password. Click Login.

Conguraon of Client Soware

Download and open the client soware. Aer adding the device, click to enter the Conguraon

page.

8.2 Live View

You can view the live video of the device.

Aer logging in, you will enter the live view page. You can perform the live view, capture, video

recording, and other operaons.

DS-K1T331 Series Face Recognion Terminal User Manual

Figure 8-1 Live View Page

Funcon Descripons:

Select the image size when starng live view.

Set the volume when starng live view.

Note

If you adjust the volume when starng two-way audio, you may hear a repeated sounds.

You can capture image when starng live view.

Reserved funcon. You can zoom in the live view image.

Unlock the linked door.

Start or stop live view.

Start or stop video recording.

Select the streaming type when starng live view. You can select from the main stream and the

sub stream.

DS-K1T331 Series Face Recognion Terminal User Manual

Select the window division type when starng live view.

Full screen view.

8.3 Person Management

Click and add the person's informaon, including the basic informaon, card, authencaon mode,

and the picture.

Click OK to save the person.

Add Basic

Informaon

Click User → Add to enter the Add Person page.

Add the person's basic informaon, including the employee ID, the person's name, user level, oor

No., and room No.

Click OK to save the sengs.

Add Card

Click User → Add to enter the Add Person page.

Click Add Card and enter a card number.

Click OK to save the

sengs.

Add Face Picture

Click User → Add to enter the Add Person page.

Click + on the right to upload a face picture from the local PC.

Note

The picture format should be JPG, JPEG or PNG. The size should be less than 200K.

Click OK to save the sengs.

Set Permission Time

Click User → Add to enter the Add Person page.

Set Start Time and End Time.

Click OK to save the

sengs.

Set Access Control

Click User → Add to enter the Add Person page.

Aer check Adminstrator in Access Control, the added person can log in by authencang face.

Click OK to save the sengs.

Add

Authencaon Mode

Click User → Add to enter the Add Person page.

DS-K1T331 Series Face Recognion Terminal User Manual

Set the authencaon type.

Click OK to save the sengs.

8.4 Search Event

Click Search to enter the Search page.

Figure 8-2 Search Page

Enter the search condions, including the employee ID, the name, the card No., the start me, and

the end

me, and click Search.

The results will be displayed on the right panel.

8.5

Conguraon

8.5.1 Set Local Parameters

Set the live view parameters, record le saving path, and captured pictures saving path.

DS-K1T331 Series Face Recognion Terminal User Manual

Set Live View Parameters

Click Conguraon → Local to enter the Local page. Congure the stream type, the play

performance, auto start live view, and the image format and click Save.

Set Record File Saving Path

Click Conguraon → Local to enter the Local page. Select a record le size and select a saving

path from your local computer and click Save.

You can also click Open to open the

le folder to view details.

Set Captured Pictures Saving Path

Click

Conguraon → Local to enter the Local page. Select a saving path from your local computer

and click Save.

You can also click Open to open the

le folder to view details.

8.5.2 View Device

Informaon

View the device name, language, model, serial No., QR code, version, device capacity, etc.

Click

Conguraon → System → System Sengs → Basic Informaon to enter the conguraon

page.

You can view the device name, language, model, serial No., QR code, version, device capacity, etc.

8.5.3 Set Time

Set the device's me zone, synchronizaon mode, and the device me.

Click Conguraon → System → System Sengs → Time Sengs .

Figure 8-3 Time

Sengs

Click Save to save the sengs aer the conguraon.

Time Zone

Select the device located me zone from the drop-down list.

Time Sync.

NTP

DS-K1T331 Series Face Recognion Terminal User Manual

You should set the NTP server's IP address, port No., and interval.

Manual

By default, the device me should be synchronized manually. You can set the device me

manually or check Sync. with Computer Time to synchronize the device me with the

computer's

me.

8.5.4 Set DST

Steps

Click Conguraon → System → System Sengs → DST .

Figure 8-4 DST Page

Check Enable DST.

Set the DST start

me, end me and bias me.

Click Save to save the sengs.

8.5.5 View Open Source

Soware License

Go to Conguraon → System → System Sengs → About Device , and click View Licenses to

view the device license.

8.5.6 Upgrade and Maintenance

Reboot device, restore device parameters, and upgrade device version.

Reboot Device

Click Conguraon → System → Maintenance → Upgrade & Maintenance .

DS-K1T331 Series Face Recognion Terminal User Manual

Figure 8-5 Upgrade and Maintenance Page

Click Reboot to start reboot the device.

Restore Parameters

Click Conguraon → System → Maintenance → Upgrade & Maintenance .

Restore All

All parameters will be restored to the factory sengs. You should acvate the device before

usage.

Default

The device will restore to the default

sengs, except for the device IP address and the user

informaon.

Unlink APP Account

Unlink the Hik-Connect account from the plaorm.

Import and Export Parameters

Click Conguraon → System → Maintenance → Upgrade & Maintenance .

Export

Click Export to export the logs or device parameters.

Note

You can import the exported device parameters to another device.

Import

Click and select the le to import. Click Import to start import conguraon le.

DS-K1T331 Series Face Recognion Terminal User Manual

Upgrade

Click Conguraon → System → Maintenance → Upgrade & Maintenance .

Select an upgrade type from the drop-down list. Click and select the upgrade le from your

local PC. Click Upgrade to start upgrading.

Note

Do not power o during the upgrading.

8.5.7 Log Query

You can search and view the device logs.

Go to Conguraon → System → Maintenance → Log Query .

Set the major and minor type of the log type. Set the start

me and end me for searching, and

click Search.

The results will be displayed below, which including the No., me, the major type the minor type,

the channel No., the local/remote user

informaon, the remote host IP, etc.

8.5.8 Security Mode

Sengs

Set the security mode for logging in the client soware.

On the Device for Management page, click Conguraon → System → Security → Security

Service .

Select a security mode from the drop-down list, and click Save.

Security Mode

High security level for user

informaon vericaon when logging in the client soware.

Compable Mode

The user informaon vericaon is compable with the old client soware version when

logging in.

Enable SSH

To raise network security, disable SSH service. The

conguraon is only used to debug the

device for the professionals.

Enable HTTP

In order to increase the network security level when vising websites, you can enable HTTP to

acquire a more secure and encrypted network

communicaon environment. The

communicaon should authencated by identy and encrypon password aer enabling HTTP,

which is save.

DS-K1T331 Series Face Recognion Terminal User Manual

8.5.9 Cercate Management

It helps to manage the server/client cercates and CA cercate.

Note

The funcon is only supported by certain device models.

Create and Install Self-signed Cercate

Steps

Go to Conguraon → System → Security → Cercate Management .

In the

Cercate Files area, select a Cercate Type from the drop-down list.

Click Create.

Input

cercate informaon.

Click OK to save and install the cercate.

The created cercate is displayed in the Cercate Details area.

The

cercate will be saved automacally.

Download the cercate and save it to an asking le in the local computer.

Send the asking

le to a cercaon authority for signature.

Import the signed cercate.

1) Select a cercate type in the Import Passwords area, and select a cercate from the local,

and click Install.

2) Select a cercate type in the Import Communicaon Cercate area, and select a cercate

from the local, and click Install.

Install Other Authorized

Cercate

If you already has an authorized cercate (not created by the device), you can import it to the

device directly.

Steps

Go to Conguraon → System → Security → Cercate Management .

In the Import Passwords and Import Communicaon Cercate areas, select cercate type

and upload

cercate.

Click Install.

Install CA

Cercate

Before You Start

Prepare a CA cercate in advance.

DS-K1T331 Series Face Recognion Terminal User Manual

Steps

Go to Conguraon → System → Security → Cercate Management .

Create an ID in the Inport CA Cercate area.

Note

The input cercate ID cannot be the same as the exisng ones.

Upload a

cercate le from the local.

Click Install.

8.5.10 Change Administrator's Password

Steps

Click Conguraon → User Management .

Click

Enter the old password and create a new password.

Conrm the new password.

Click OK.

Cauon

The password strength of the device can be automacally checked. We highly recommend you

change the password of your own choosing (using a minimum of 8 characters, including at least

three kinds of following categories: upper case leers, lower case leers, numbers, and special

characters) in order to increase the security of your product. And we recommend you change

your password regularly, especially in the high security system, changing the password monthly

or weekly can

beer protect your product.

Proper conguraon of all passwords and other security sengs is the responsibility of the

installer and/or end-user.

8.5.11 View Device Arming/Disarming Informaon

View device arming type and arming IP address.

Go to Conguraon → Arming/Disarming Informaon .

You can view the device arming/disarming

informaon. Click Refresh to refresh the page.

8.5.12 Network

Sengs

Set TCP/IP and port parameters.

DS-K1T331 Series Face Recognion Terminal User Manual

Set Basic Network Parameters

Click Conguraon → Network → Basic Sengs → TCP/IP .

Figure 8-6 TCP/IP Sengs Page

Set the parameters and click Save to save the sengs.

DHCP

If uncheck the funcon, you should set the IPv4 address, IPv4 subnet mask, IPv4 default

gateway, MTU, and the device port.

If you check the

funcon, the system will allocate the IPv4 address, IPv4 subnet mask, and the

IPv4 default gateway automacally.

NIC Type

Select a NIC type from the drop-down list. By default, it is Auto.

DNS Server

Set the preferred DNS server and the Alternate DNS server according to your actual need.

Set Port Parameters

Set the HTTP, RTSP, HTTPS and Server port parmaeters.

Click

Conguraon → Network → Basic Sengs → Port .

HTTP

It refers to the port through which the browser accesses the device. For example, when the

HTTP Port is

modied to 81, you need to enter hp://192.0.0.65:81 in the browser for login.

RTSP

It refers to the port of real-me streaming protocol.

HTTPS

Set the HTTPS for accessing the browser. Cercate is required when accessing.

Server

DS-K1T331 Series Face Recognion Terminal User Manual

It refers to the port through which the client adds the device.

Set Wi-Fi Parameters

Set the Wi-Fi parameters for device wireless connecon.

Steps

Note

The funcon should be supported by the device.

Click Conguraon → Network → Basic Sengs → Wi-Fi .

Figure 8-7 Wi-Fi Sengs Page

Check Wi-Fi.

Select a Wi-Fi

Click of a Wi-Fi in the list and enter the Wi-Fi password.

Click Add and enter a Wi-Fi's name, password, and

encrypon type. Click Connect. When the

Wi-Fi is connected, click OK.

Oponal: Set the WLAN parameters.

1) Click TCP/IP

Sengs.

2) Set the IP address, subnet mask, and default gateway. Or check Enable DHCP and the system

will allocate the IP address, subnet mask, and default gateway

automacally.

Click Save.

Report Strategy

Sengs

You can set the center group for uploading the log via the ISUP protocol.

DS-K1T331 Series Face Recognion Terminal User Manual

Go to Conguraon → Network → Basic Sengs → Report Strategy .

You can set the center group and the system will transfer logs via ISUP protocol. Click Save to save

the sengs.

Center Group

Select a center group from the drop-down list.

Main Channel

The device will communicate with the center via the main channel.

Note

N1 refers to wired network.

Set ISUP Parameters

Set the ISUP parameters for accessing device via ISUP protocol.

Steps

Note

The funcon should be supported by the device.

Click Conguraon → Network → Advanced Sengs → Plaorm .

Select ISUP from the plaorm access mode drop-down list.

Check Enable.

Set the ISUP version, server address, device ID, and the ISUP status.

Note

If you select 5.0 as the version, you should set the ISUP key as well.

Click Save.

Plaorm

Access

Plaorm access provides you an opon to manage the devices via plaorm.

Steps

Click

Conguraon → Network → Advanced → Plaorm Access to enter the sengs page.

Check the checkbox of Enable to enable the funcon.

Select the Plaorm Access Mode.

Note

Hik-Connect is an applicaon for mobile devices. With the App, you can view live image of the

device, receive alarm nocaon and so on.

Create a Stream Encrypon/Encrypon Key for the device.

DS-K1T331 Series Face Recognion Terminal User Manual

Note

6 to 12 leers (a to z, A to Z) or numbers (0 to 9), case sensive. You are recommended to use a

combinaon of no less than 8 leers or numbers.

Click Save to enable the sengs.

Congure HTTP Listening

The device can send alarm informaon to the desnaon IP or host via HTTP protocol.

Before You Start

The

desnaon IP or host name should support the HTTP protocol to receive the alarm

informaon.

Note

The funcon should be supported by the device.

Steps

Click Conguraon → Network → Advanced → HTTP Listening .

Edit the

desnaon IP or host name, URL and port.

Oponal: Click Test to test whether the entered IP address or host name are valid.

Oponal: Click Default to reset the desnaon IP or host name.

Click Save.

8.5.13 Set Video and Audio Parameters

Set the image quality, resoluon, and the device volume.

Set Video Parameters

Click Conguraon → Video/Audio → Video .

Figure 8-8 Video

Sengs Page

DS-K1T331 Series Face Recognion Terminal User Manual

Set the stream type, the video type, the bitrate type, the frame rate, the Max. bitrate, video

encoding.

Click Save to save the sengs aer the conguraon.

Set Audio Parameters

Click Conguraon → Video/Audio → Audio .

Drag the block to adjust the device output volume.

Click Save to save the

sengs aer the conguraon.

8.5.14 Customize Audio Content

Customize the output audio content when authencaon succeeded and failed.

Steps

Click

Conguraon → Video/Audio → Audio Prompt .

Figure 8-9 Customize Audio Content

set the appellaon.

Enable the funcon.

Set the me duraon when authencaon succeeded.

1) Click Add.

DS-K1T331 Series Face Recognion Terminal User Manual

2) Set the me duraon and the language.

Note

If authencaon is succeeded in the congured me duraon, the device will broadcast the

congured content.

3) Enter the audio content.

Oponal: Repeat substep 1 to 3.

5) Oponal: Click to delete the congured me duraon.

Set the me duraon when authencaon failed.

1) Click Add.

2) Set the me duraon and the language.

Note

If authencaon is failed in the congured me duraon, the device will broadcast the

congured content.

3) Enter the audio content.

4) Oponal: Repeat substep 1 to 3.

Oponal: Click to delete the congured me duraon.

Click Save to save the sengs.

8.5.15 Set Image Parameters

Set the video standard, WDR, brightness, contrast, saturaon, and sharpness.

Steps

Click Conguraon → Image Adjustment .

Figure 8-10 Image Sengs Page

DS-K1T331 Series Face Recognion Terminal User Manual

Congure the parameters to adjust the image.

Video Standard

Set the video frame rate when performing live view remotely. Aer changing the standard,

you should reboot the device to take eect.

PAL

25 frames per second. Suitable for mainland China, Hong Kong (China), the Middle East

countries, Europe countries, etc.

NTSC

30 frames per second. Suitable for the USA, Canada, Japan, Taiwan (China), Korea, the

Philippines, etc.

WDR

Enable or disable the WDR

funcon.

When there are both very bright and very dark areas simultaneously in the view, WDR

balances the brightness level of the whole image and provide clear images with details.

Brightness/Contrast/Saturaon/Sharpness

Drag the block or enter the value to adjust the live video's brightness, contrast, saturaon,

and sharpness.

Start/end recording video.

Capture the image.

Click Default to restore the parameters to the default sengs.

8.5.16 Set Supplement Light Brightness

Set the device supplement light brightness.

Steps

Click Conguraon → Image → Supplement Light Parameters .

Figure 8-11 Supplement Light

Sengs Page

Select a supplement light type and mode from the drop-down list. If you select the mode as ON,

you should set the brightness.

DS-K1T331 Series Face Recognion Terminal User Manual

8.5.17 Time and Aendance Sengs

If you want to track and monitor when the persons start/stop work and monitor their working

hours and late arrivals, early departures,

me taken on breaks, and absenteeism, you can add the

person to the shi group and assign a shi schedule (a rule for the aendance dening how the

schedule repeats, the shi type, break sengs, and the card swiping rule.) to the shi group to

dene the aendance parameters for the persons in the shi group.

Disable Aendance Mode via Web

Disable the aendance mode and the system will not display the aendance status on the inial

page.

Steps

Click Conguraon → Aendance to enter the sengs page.

Set the

Aendance Mode as Disable.

Result

You will not view or congure the aendance status on the inial page. And the system will follow

the aendance rule that congured on the plaorm.

Time

Sengs

Steps

Click Conguraon → Time Sengs to enter the sengs page.

Select Status Type.

Oponal: Edit Schedule Name according to the actual needs.

Drag mouse to set the schedule.

Note

Set the schedule from Monday to Sunday according to the actual needs.

Oponal: Select a meline and click Delete. Or click Delete All to clear the sengs.

Click Save.

Set Manual

Aendance via Web

Set the aendance mode as manual, and you should select a status manually when you take

aendance.

Before You Start

Add at least one user, and set the user's authencaon mode. For details, see User Management.

DS-K1T331 Series Face Recognion Terminal User Manual

Steps

Click Conguraon → Aendance to enter the sengs page.

Set the Aendance Mode as Manual.

Enable the

Aendance Status Required and set the aendace status lasts duraon.

Enable a group of aendance status.

Note

The Aendance Property will not be changed.

Oponal: Select an status and change its name if required.

Result

You should select an aendance status manually aer authencaon.

Note

If you do not select a status, the authencaon will be failed and it will not be marked as a valid

aendance.

Set Auto Aendance via Web

Set the aendance mode as auto, and you can set the aendance status and its available schedule.

The system will automacally change the aendance status according to the congured schedule.

Before You Start

Add at least one user, and set the user's authencaon mode. For details, see User Management.

Steps

Click Conguraon → Aendance to enter the sengs page.

Set the

Aendance Mode as Auto.

Enable the Aendance Status funcon.

Enable a group of aendance status.

Note

The Aendance Property will not be changed.

Oponal: Select an status and change its name if required.

Set the status' schedule. Refers to Time Sengs for details.

Set Manual and Auto

Aendance via Web

Set the aendance mode as Manual and Auto, and the system will automacally change the

aendance status according to the congured schedule. At the same me you can manually

change the

aendance status aer the authencaon.

DS-K1T331 Series Face Recognion Terminal User Manual

Before You Start

Add at least one user, and set the user's authencaon mode. For details, see User Management.

Steps

Click

Conguraon → Aendance to enter the sengs page.

Set the Aendance Mode as Manual and Auto.

Enable the Aendance Status funcon.

Enable a group of aendance status.

Note

The Aendance Property will not be changed.

Oponal: Select an status and change its name if required.

Set the status' schedule. Refers to Time Sengs for details.

Result

On the inial page and authencate. The authencaon will be marked as the congured

aendance

status according to the schedule. If you tap the edit icon on the result tab, you can

select a status to take aendance manually, the authencaon will be marked as the edited

aendance status.

Example

If set the Break Out as Monday 11:00, and Break In as Monday 12:00, the valid user's

authencaon from Monday 11:00 to 12:00 will be marked as break.

8.5.18 Access Control

Sengs

Set Authencaon Parameters

Click Conguraon → Access Control → Authencaon Sengs .

Note

The funcons vary according to dierent models. Refers to the actual device for details.

Click Save to save the sengs aer the conguraon.

Device Type

Select Main Card Reader or Sub Card Reader from the drop-down list.

Main Card Reader

You can

congure the device card reader's parameters.

Sub Card Reader

You can congure the connected peripheral card reader's parameters.

If select Main Card Reader:

DS-K1T331 Series Face Recognion Terminal User Manual

Card Reader Type/Card Reader Descripon

Get card reader type and descripon. They are read-only.

Enable Card Reader

Enable the card reader's funcon.

Authencaon

Select an authencaon mode according to your actual needs from the drop-down list.

Display Authencaon Result

Check Face Picture, Name, or Employee ID. When authencaon is completed, the system will

display the selected contents in the result.

Recognion Interval

You can set the interval between 2 connuous recognion of a same person during the

authencaon. In the congured interval, Person A can only recognized once. If another person

(Person B) has recognized during the interval, Person A can recognized again.

Authencaon Interval

You can set the authencaon interval of the same person when authencang. The same

person can only

authencate once in the congured interval. A second authencaon will be

failed.

Alarm of Max. Failed Aempts

Enable to report alarm when the card reading aempts reach the set value.

Enable Tampering Detecon

Enable the an-tamper detecon for the card reader.

Enable Card No. Reversing

The read card No. will be in reverse sequence

aer enabling the funcon.

If select Sub Card Reader:

Card Reader Type/Card Reader Descripon

Get card reader type and descripon. They are read-only.

Enable Card Reader

Enable the card reader's funcon.

Authencaon

Select an authencaon mode according to your actual needs from the drop-down list.

Recognion Interval

If the interval between card presenng of the same card is less than the congured value, the

card

presenng is invalid.

Authencaon Interval

DS-K1T331 Series Face Recognion Terminal User Manual

You can set the authencaon interval of the same person when authencang. The same

person can only authencate once in the congured interval. A second authencaon will be

failed.

Alarm of Max. Failed Aempts

Enable to report alarm when the card reading aempts reach the set value.

Communicaon with Controller Every

When the access control device cannot connect with the card reader for longer than the set

me, the card reader will turn oine automacally.

Max. Interval When Entering Password

When you entering the password on the card reader, if the interval between pressing two digits

is longer than the set value, the digits you pressed before will be cleared automacally.

OK LED Polarity/Error LED Polarity

Set OK LED Polarity/Error LED Polarity of the access control device according to the card reader

parameters. Generally, adopts the default

sengs.

Enable Tampering Detecon

Enable the an-tamper detecon for the card reader.

Set Door Parameters

Click Conguraon → Access Control → Door Parameters .

Figure 8-12 Door Parameters Sengs Page

Click Save to save the sengs aer the conguraon.

Door No.

Select the device corresponded door No.

Name

You can create a name for the door.

Open Duraon

DS-K1T331 Series Face Recognion Terminal User Manual

Set the door unlocking duraon. If the door is not opened for the set me, the door will be

locked.

Door Open Timeout Alarm

An alarm will be triggered if the door has not been closed within the congured me duraon.

Door Contact

You can set the door contact as Remain Open or Remain Closed according to your actual needs.

By default, it is Remain Closed.

Exit

Buon Type

You can set the exit buon as Remain Open or Remain Closed according to your actual needs.

By default, it is Remain Open.

Door Lock Powering O Status

You can set the door lock status when the door lock is powering o. By default, it is Remain

Closed.

Extended Open Duraon

The door contact can be enabled with appropriate delay aer person with extended access

needs swipes her/his card.

Door Remain Open

Duraon with First Person

Set the door open duraon when rst person is in. Aer the rst person is authorized, it allows

mulple persons access the door or other authencaon acons.

Duress Code

The door can open by inpung the duress code when there is duress. At the same me, the

client can report the duress event.

Super Password

The

specic person can open the door by inpung the super password.

Note

The duress code and the super code should be dierent.

Set Card Security

Click Conguraon → Access Control → Card Security to enter the sengs page.

Set the parameters and click Save.

Enable NFC Card

In order to prevent the mobile phone from

geng the data of the access control, you can

enable NFC card to increase the security level of the data.

Enable M1 Card

Enable M1 card and

authencang by presenng M1 card is available.

DS-K1T331 Series Face Recognion Terminal User Manual

M1 Card Encrypon

Sector

M1 card encrypon can improve the security level of authencaon.

Enable the funcon and set the encrypon sector. By default, Sector 13 is encrypted. It is

recommended to encrypt sector 13.

Enable EM Card

Enable EM card and

authencang by presenng EM card is available.

Note

If the peripheral card reader supports presenng EM card, the funcon is also supported to

enable/disable the EM card funcon.

Set RS-485 Parameters

You can set the RS-485 parameters including the peripheral, address, baud rate, etc.

Click Conguraon → Access Control → RS-485 Sengs .

Click Save to save the

sengs aer the conguraon.

No.

Set the RS-485 No.

Peripheral Type

Select a peripheral from the drop-down list according the actual situaon. You can select from

Card Reader, Extension Module, Access Controller, or Disable.

Note

Aer the peripheral is changed and saved, the device will reboot automacally.

RS-485 Address

Set the RS-485 Address according to your actual needs.

Note

If you select Access Controller: If connect the device to a terminal via the RS-485 interface, set

the RS-485 address as 2. If you connect the device to a controller, set the RS-485 address

according to the door No.

Baud Rate

The baud rate when the devices are communicang via the RS-485 protocol.

DS-K1T331 Series Face Recognion Terminal User Manual

Set Privacy Parameters

Set the event storage type, picture upload and storage parameters, and the picture clearing

parameters.

Go to

Conguraon → Access Control → Privacy

Event Storage Sengs

Select a method to delete the event. You can select from Delete Old Events Periodically, Delete

Old Events by

Specied Time, or Overwring.

Delete Old Events Periodically

Drag the block or enter number to set the period for event deleng. All events will be deleted

according to the congured me duraon.

Delete Old Events by Specied Time

Set a me and all events will be deleted on the congured me.

Overwring

The earliest 5% events will be deleted when the system detects the stored events has been over

95% of the full space.

Picture Uploading and Storage

Upload Captured Picture When Authencang

Upload the pictures captured when authencang to the plaorm automacally.

Save Captured Picture When Authencang

If you enable this funcon, you can save the picture when authencang to the device.

Save Registered Picture

The registered face picture will be saved to the system if you enable the funcon.

Upload Picture Aer Linked Capture

Upload the pictures captured by linked camera to the plaorm automacally.

Save Pictures Aer Linked Capture

If you enable this funcon, you can save the picture captured by linked camera to the device.

Clear All Pictures in Device

Note

All pictures cannot be restored once they are deleted.

Clear Registered Face Pictures

All registered pictures in the device will be deleted.

Clear Captured Pictures

DS-K1T331 Series Face Recognion Terminal User Manual

All captured pictures in the device will be deleted.

Set Card Authencaon Parameters

Set the card reading content when authencate via card on the device.

Go to

Conguraon → Access Control → Card Authencaon Sengs .

Select a card authencaon mode and click Save.

Full Card No.

All card No. will be read.

Wiegand 26 (3 bytes)

The device will read card via Wiegand 26 protocol (read 3 bytes).

Wiegand 34 (4 bytes)

The device will read card via Wiegand 34 protocol (read 4 bytes).

8.5.19 Set Biometric Parameters

Set Basic Parameters

Click Conguraon → Smart → Smart .

DS-K1T331 Series Face Recognion Terminal User Manual

Figure 8-13 Smart Sengs Page

Click Save to save the sengs aer the conguraon.

Face An-spoong

Enable or disable the live face detecon funcon. If enabling the funcon, the device can

recognize whether the person is a live one or not.

Note

Biometric recognion products are not completely applicable to an-spoong environments. If

you require a higher security level, use mulple authencaon modes.

Live Face Detecon Security Level

Aer enabling the face an-spoong funcon, you can set the matching security level when

performing live face authencaon.

Recognion Distance

Select the distance between the authencang user and the device camera.

DS-K1T331 Series Face Recognion Terminal User Manual

Applicaon Mode

Select either others or indoor according to actual environment.

Face Recognion Mode

Normal Mode

Recognize face via the camera normally.

Deep Mode

The device can recognize a much wider people range than the normal mode. This mode is

applicable to a more complicated environment.

Connuous Face Recognion Interval

Set the me interval between two connuous face recognions when authencang.

Pitch Angle

The maximum pitch angle when starng face authencaon.

Yaw Angle

The maximum yaw angle when starng face authencaon.

Face Grading

Set the face grading according to your needs.

1:N Matching Threshold

Set the matching threshold when authencang via 1:N matching mode. The larger the value,

the smaller the false accept rate and the larger the false rejecon rate.

Face Recognion Timeout Value

Set the meout value when face recognizing. If the face recognion me is longer than the

congured value, the system will pop up a prompt.

ECO Mode

Aer enabling the ECO mode, the device will use the IR camera to authencate faces in the low

light or dark environment. And you can set the ECO mode threshold, ECO mode (1:N), and ECO

mode (1:1).

ECO Mode (1:N)

Set the matching threshold when

authencang via ECO mode 1:N matching mode. The larger

the value, the smaller the false accept rate and the larger the false rejecon rate

Set

Recognion Area

Click Conguraon → Smart → Area Conguraon .

Drag the yellow frame in the live video to adjust the recognion area. Only the face within the area

can be recognized by the system.

Click Save to save the

sengs.

Click or to record videos or capture pictures.

DS-K1T331 Series Face Recognion Terminal User Manual

8.5.20 Set Noce Publicaon

You can set the screen saver and the sleep me for the device.

Click

Conguraon → Noce Publicaon .

Figure 8-14 Noce Page

Sleep

Enable Sleep and the device will enter the sleep mode when no operaon within the congured

sleep me.

Theme Management

You can click + in the frame and upload the screen saver pictures from the local PC.

Note

By now, there is only one theme can be added.

Play Schedule

Aer you have created a theme, you can select the theme and draw a schedule on the me line.

Select the drawn schedule and you can edit the exact start and end

me.

Select the drawn schedule and you can click Delete or Delete All to delete the schedule.

Slide Show Interval

Drag the block or enter the number to set the slide show interval. The picture will be changed

according to the interval.

DS-K1T331 Series Face Recognion Terminal User Manual

Chapter 9 Client Soware Conguraon

9.1 Conguraon Flow of Client Soware

Follow the ow diagram below to congure on the client soware.

Figure 9-1 Flow Diagram of Conguraon on Client Soware

9.2 Device Management

The client supports managing access control devices and video intercom devices.

DS-K1T331 Series Face Recognion Terminal User Manual

Example

You can control entrance & exit and manage aendance aer adding access control devices to the

client; you can perform video intercom with the indoor staons and door staons.

9.2.1 Add Device

The client provides three device adding modes including by IP/domain, IP segment, and ISUP

protocol. The client also supports imporng mulple devices in a batch when there are large

amount of devices to be added.

Add Online Device

The acve online devices in the same local subnet with the client soware will be displayed on the

Online Device area. You can click Refresh Every 60s to refresh the informaon of the online

devices.

Add Single or

Mulple Online Devices

The client can detect online devices which are in the same network as the PC running the client.

You can select a detected online device displayed in the online device list and add it to the client.

For detected online devices sharing the same user name and password, you can add them to the

client in a batch.

Before You Start

●

The device(s) to be added are in the same network as the PC running the client.

●

The device(s) to be added have been

acvated.

Steps

Click Device Management → Device 。

Click Online Device to show the online device area.

The searched online devices are displayed in the list.

Figure 9-2 Online Device

DS-K1T331 Series Face Recognion Terminal User Manual

In the Online Device area, check one or more online device(s), and click Add to open the device

adding window.

Figure 9-3 Add Single Online Device

Figure 9-4 Add Mulple Online Devices

Enter the required informaon.

DS-K1T331 Series Face Recognion Terminal User Manual

Name

Enter a descripve name for the device.

IP Address

Enter the device's IP address. The IP address of the device is obtained automacally in this

adding mode.

Port

You can customize the port number. The port number of the device is obtained

automacally

in this adding mode.

User Name

By default, the user name is admin.

Password

Enter the device password.

Cauon

The password strength of the device can be automacally checked. We highly recommend

you change the password of your own choosing (using a minimum of 8 characters, including

at least three kinds of following categories: upper case leers, lower case leers, numbers,

and special characters) in order to increase the security of your product. And we recommend

you change your password regularly, especially in the high security system, changing the

password monthly or weekly can

beer protect your product.

Proper conguraon of all passwords and other security sengs is the responsibility of the

installer and/or end-user.

Oponal: Check Transmission Encrypon (TLS) to enable transmission encrypon using TLS

(Transport Layer Security) protocol for security purpose.

Note

●

This funcon should be supported by the device.

●

If you have enabled Cercate Vericaon, you should click Open Cercate Directory to

open the default folder, and copy the cercate le exported from the device to this default

directory to strengthen the security. See for details about enabling

cercate vericaon.

●

You can log into the device to get the

cercate le by web browser.

Check Synchronize Time to synchronize the device me with the PC running the client aer

adding the device to the client.

Oponal: Check Import to Group to create a group by the device name, and import all the

channels of the device to this group.

Example

For access control device, its access points, alarm inputs/outputs, and encoding channels (if

exist) will be imported to this group.

Click Add.

DS-K1T331 Series Face Recognion Terminal User Manual

Add Mulple Detected Online Devices

For detected online devices sharing the same user name and password, you can add them to the

client in a batch.

Before You Start

Make sure the to-be-added devices are online.

Steps

Enter the Device Management module.

Click Device tab on the top of the right panel.

Click Online Device to show the online device area at the

boom of the page.

The searched online devices are displayed in the list.

Select

mulple devices.

Note

For the inacve device, you need to create the password for it before you can add the device

properly. For details, refer to .

Click Add to open the device adding window.

Enter the required informaon.

User Name

By default, the user name is admin.

Password

Enter the device password.

Cauon

The password strength of the device can be automacally checked. We highly recommend

you change the password of your own choosing (using a minimum of 8 characters, including

at least three kinds of following categories: upper case leers, lower case leers, numbers,

and special characters) in order to increase the security of your product. And we recommend

you change your password regularly, especially in the high security system, changing the

password monthly or weekly can

beer protect your product.

Proper conguraon of all passwords and other security sengs is the responsibility of the

installer and/or end-user.

Oponal: Check Synchronize Time to synchronize the device me with the PC running the client

aer adding the device to the client.

Oponal: Check Import to Group to create a group by the device name, and import all the

channels of the device to this group.

Example

For access control device, its access points, alarm inputs/outputs, and encoding channels (if

exist) will be imported to this group.

DS-K1T331 Series Face Recognion Terminal User Manual

Click Add to add the devices.

Add Device by IP Address or Domain Name

If you know the IP address or domain name of the device to add, you can add devices to the client

by specifying the IP address (or domain name), user name, password, etc.

Steps

Enter Device Management module.

Click Device tab on the top of the right panel.

The added devices are displayed on the right panel.

Click Add to open the Add window, and then select IP/Domain as the adding mode.

Enter the required

informaon.

Name

Create a descripve name for the device. For example, you can use a nickname that can show

the

locaon or feature of the device.

Address

The IP address or domain name of the device.

Port

The devices to add share the same port number. The default value is 8000.

User Name

Enter the device user name. By default, the user name is admin.

Password

Enter the device password.

Cauon

The password strength of the device can be automacally checked. We highly recommend

you change the password of your own choosing (using a minimum of 8 characters, including

at least three kinds of following categories: upper case leers, lower case leers, numbers,

and special characters) in order to increase the security of your product. And we recommend

you change your password regularly, especially in the high security system, changing the

password monthly or weekly can

beer protect your product.

Proper conguraon of all passwords and other security sengs is the responsibility of the

installer and/or end-user.

Oponal: Check Transmission Encrypon (TLS) to enable transmission encrypon using TLS

(Transport Layer Security) protocol for security purpose.

DS-K1T331 Series Face Recognion Terminal User Manual

Note

●

This funcon should be supported by the device.

●

If you have enabled Cercate Vericaon, you should click Open Cercate Directory to

open the default folder, and copy the cercate le exported from the device to this default

directory to strengthen the security. See for details about enabling

cercate vericaon.

●

You can log into the device to get the

cercate le by web browser.

Check Synchronize Time to synchronize the device me with the PC running the client aer

adding the device to the client.

Oponal: Check Import to Group to create a group by the device name, and import all the

channels of the device to this group.

Example

For access control device, its access points, alarm inputs/outputs, and encoding channels (if

exist) will be imported to this group.

Finish adding the device.

Click Add to add the device and back to the device list page.

Click Add and New to save the sengs and connue to add other device.

Add Devices by IP Segment

If the devices share the same port No., user name and password, and their IP addresses ranges in

the same IP segment, you can add them to the client by specifying the start IP address and the end

IP address, port No., user name, password, etc of the devices.

Steps

Enter the Device Management module.

Click Device tab on the top of the right panel.

The added devices are displayed on the right panel.

Click Add to open the Add window.

Select IP Segment as the adding mode.

Enter the required

informaon.

Start IP

Enter a start IP address.

End IP

Enter an end IP address in the same network segment with the start IP.

Port

Enter the device port No. The default value is 8000.

User Name

By default, the user name is admin.

Password

DS-K1T331 Series Face Recognion Terminal User Manual

Enter the device password.

Cauon

The password strength of the device can be automacally checked. We highly recommend

you change the password of your own choosing (using a minimum of 8 characters, including

at least three kinds of following categories: upper case leers, lower case leers, numbers,

and special characters) in order to increase the security of your product. And we recommend

you change your password regularly, especially in the high security system, changing the

password monthly or weekly can

beer protect your product.

Proper conguraon of all passwords and other security sengs is the responsibility of the

installer and/or end-user.

Oponal: Check Transmission Encrypon (TLS) to enable transmission encrypon using TLS

(Transport Layer Security) protocol for security purpose .

Note

●

This funcon should be supported by the device.

●

If you have enabled Cercate Vericaon, you should click Open Cercate Folder to open

the default folder, and copy the cercate le exported from the device to this default

directory to strengthen the security. See for details about enabling

cercate vericaon.

●

You can log into the device to get the

cercate le by web browser.

Check Synchronize Time to synchronize the device me with the PC running the client aer

adding the device to the client.

Oponal: Check Import to Group to create a group by the device name, and import all the

channels of the device to the group.

Finish adding the device.

Click Add to add the device and back to the device list page.

Click Add and New to save the sengs and connue to add other device.

Add Device by ISUP Account

For access control devices supports ISUP 5.0 protocol, you can add them to the client by ISUP

protocol

aer entering device ID and key, if you have congured their server addresses, port No.,

and device IDs.

Before You Start

Make sure the devices have connected to the network properly.

Steps

Enter Device Management module.

The added devices are displayed on the right panel.

Click Add to open the Add window.

Select ISUP as the adding mode.

Enter the required

informaon.

DS-K1T331 Series Face Recognion Terminal User Manual

Device Account

Enter the account name registered on ISUP protocol.

ISUP Key

For ISUP 5.0 devices, enter the ISUP key if you have set it when conguring network center

parameter for the device.

Note

This funcon should be supported by the device.

Oponal: Check Synchronize Time to synchronize the device me with the PC running the client

aer adding the device to the client.

Oponal: Check Import to Group to create a group by the device name, and import all the

channels of the device to the group.

Finish adding the device.

Click Add to add the device and go back to the device list.

Click Add and New to save the sengs and connue to add other device.

Oponal: Perform the following operaon(s).

Device Status Click on Operaon column to view device status.

Edit Device

Informaon

Click on Operaon column to edit the device informaon, such as

device name, device account, and ISUP key.

Check Online User Click on Operaon column to check the online users who access the

device, such as user name, user type, user's IP address, and login me.

Refresh Click on Operaon column to get the latest device informaon.

Delete Device Select one or mulple devices and click Delete to delete the selected

device(s) from the client.

Import Devices in a Batch

You can add mulple devices to the client in a batch by entering the device parameters in a pre-

dened CSV le.

Steps

Enter the Device Management module.

Click Device tab on the top of the right panel.

Click Add to open the Add window, and then select Batch Import as the adding mode.

Click Export Template and then save the

pre-dened template (CSV le) on your PC.

Open the exported template le and enter the required informaon of the devices to be added

on the corresponding column.

Note

For detailed descripon of the required elds, refer to the introducons in the template.

DS-K1T331 Series Face Recognion Terminal User Manual

Adding Mode

Enter 0 or 1 or 2.

Address

Edit the address of the device.

Port

Enter the device port number. The default port number is 8000.

User Name

Enter the device user name. By default, the user name is admin.

Password

Enter the device password.

Cauon

The password strength of the device can be automacally checked. We highly recommend

you change the password of your own choosing (using a minimum of 8 characters, including

at least three kinds of following categories: upper case leers, lower case leers, numbers,

and special characters) in order to increase the security of your product. And we recommend

you change your password regularly, especially in the high security system, changing the

password monthly or weekly can

beer protect your product.

Proper conguraon of all passwords and other security sengs is the responsibility of the

installer and/or end-user.

Import to Group

Enter 1 to create a group by the device name. All the channels of the device will be imported

to the corresponding group by default. Enter 0 to disable this

funcon.

Click and select the template le.

Click Add to import the devices.

9.2.2 Reset Device Password

If you forgot the password of the detected online devices, you can reset the device password via

the client.

Steps

Enter Device Management page.

Click Online Device to show the online device area.

All the online devices sharing the same subnet will be displayed in the list.

Select the device from the list and click

on the Operaon column.

Reset the device password.

Click Generate to pop up the QR Code window and click Download to save the QR code to

your PC. You can also take a photo of the QR code to save it to your phone. Send the picture

to our technical support.

DS-K1T331 Series Face Recognion Terminal User Manual

Note

For the following operaons for reseng the password, contact our technical support.

Cauon

The password strength of the device can be automacally checked. We highly recommend you

change the password of your own choosing (using a minimum of 8 characters, including at least

three kinds of following categories: upper case leers, lower case leers, numbers, and special

characters) in order to increase the security of your product. And we recommend you change

your password regularly, especially in the high security system, changing the password monthly

or weekly can

beer protect your product.

Proper conguraon of all passwords and other security sengs is the responsibility of the

installer and/or end-user.

9.3 Group Management

The client provides groups to manage the added resources in

dierent groups. You can group the

resources into dierent groups according to the resources' locaons.

Example

For example, on the 1st

oor, there mounted 16 doors, 64 alarm inputs, and 16 alarm outputs. You

can organize these resources into one group (named 1st Floor) for convenient management. You

can control door status, and do some other

operaons of the devices aer managing the resources

by groups.

9.3.1 Add Group

You can add group to organize the added device for convenient management.

Steps

Enter the Device Management module.

Click Device Management → Group to enter the group management page.

Create a group.

Click Add Group and enter a group name as you want.

Click Create Group by Device Name and select an added device to create a new group by the

name of the selected device.

Note

The resources (such as alarm inputs/outputs, access points, etc.) of this device will be

imported to the group by default.

DS-K1T331 Series Face Recognion Terminal User Manual

9.3.2 Import Resources to Group

You can import the device resources (such as alarm inputs/outputs, access points, etc.) to the

added group in a batch.

Before You Start

Add a group for managing devices. Refer to

Add Group .

Steps

Enter the Device Management module.

Click Device Management → Group to enter the group management page.

Select a group from the group list and select the resource type as Access Point, Alarm Input,

Alarm Output, etc.

Click Import.

Select the thumbnails/names of the resources in the thumbnail/list view.

Note

You can click or to switch the resource display mode to thumbnail view or to list view.

Click Import to import the selected resources to the group.

9.3.3 Edit Resource Parameters

Aer imporng the resources to the group, you can edit the resource parameters. For access point,

you can edit the access point name. For alarm input, you can edit the alarm input name. Here we

take access point as an example.

Before You Start

Import the resources to group.

Steps

Enter the Device Management module.

Click Device Management → Group to enter the group management page.

All the added groups are displayed on the

le.

Select a group on the group list and click Access Point.

The access points imported to the group will display.

Click

in the Operaon column to open the Edit Resource window.

Edit the resource name.

Click OK to save the new

sengs.

9.3.4 Remove Resources from Group

You can remove the added resources from the group.

DS-K1T331 Series Face Recognion Terminal User Manual

Steps

Enter the Device Management module.

Click Device Management → Group to enter the group management page.

All the added groups are displayed on the

le.

Click a group to show the resources added to this group.

Select the resource(s) and click Delete to remove the resource(s) from the group.

9.4 Person Management

You can add person informaon to the system for further operaons such as access control, video

intercom,

me and aendance, etc. You can manage the added persons such as issuing cards to

them in a batch, imporng and exporng person informaon in a batch, etc.

9.4.1 Add

Organizaon

You can add an organizaon and import person informaon to the organizaon for eecve

management of the persons. You can also add a surbodinate organizaon for the added one.

Steps

Enter Person module.

Select a parent organizaon in the le column and click Add in the upper-le corner to add an

organizaon.

Create a name for the added organizaon.

Note

Up to 10 levels of organizaons can be added.

Oponal: Perform the following operaon(s).

Edit

Organizaon Hover the mouse on an added organizaon and click to edit its name.

Delete

Organizaon

Hover the mouse on an added organizaon and click to delete it.

Note

●

The lower-level organizaons will be deleted as well if you delete an

organizaon.

●

Make sure there is no person added under the organizaon, or the

organizaon cannot be deleted.

Show Persons in

Sub Organizaon

Check Show Persons in Sub Organizaon and select an organizaon to

show persons in its sub organizaons.

DS-K1T331 Series Face Recognion Terminal User Manual

9.4.2 Congure Basic Informaon

You can add person to the client one by one and congure the person's basic informaon such as

name, email, phone number, etc.

Steps

Enter Person module.

Note

For the rst me you enter Person module, a window pops up, and you can set the rules to

generate person ID (leers and numbers supported) when adding person. When geng person

informaon from device, if there are no person IDs, the person IDs will be generated according

to the rule.

Select an organizaon in the organizaon list to add the person.

Click Add to open the adding person window.

The Person ID will be generated

automacally.

Enter the basic informaon including person name, telephone number, email address, validity

period, etc.

Conrm to add the person.

Click Add to add the person and close the Add Person window.

Click Add and New to add the person and

connue to add other persons.

9.4.3 Issue a Card by Local Mode

If a card enrollment staon is available, you can issue a card by local mode. To read the card

number, you should connect the card enrollment staon to the PC running the client by USB

interface or COM, and place the card on the card enrollment staon.

Steps

Enter Person module.

Select an

organizaon in the organizaon list to add the person and click Add to enter Add

Person panel.

Note

Enter the person's basic informaon rst. For details about conguring person's basic

informaon, refer to Congure Basic Informaon .

In the Credenal → Card area, click +.

Click Sengs to enter the Sengs page.

Select Local as the card issuing mode.

DS-K1T331 Series Face Recognion Terminal User Manual

Figure 9-5 Issue a Card by Local Mode

Set other related parameters.

Card Enrollment

Staon

Select the model of the connected card enrollment staon.

Note

Currently, the supported card enrollment staon models include DS-K1F100-D8, DS-K1F100-

M, DS-K1F100-D8E, and DS-K1F180-D8E.

Card Type

This eld is only available when the model is DS-K1F100-D8E or DS-K1F180-D8E. Select the

card type as EM card or Mifare card according to the actual card type.

Buzzing

DS-K1T331 Series Face Recognion Terminal User Manual

Enable or disable the buzzing when the card number is read successfully.

Card No. Type

Select the type of the card number according to actual needs.

M1 Card Encrypon

This eld is only available when the model is DS-K1F100-D8, DS-K1F100-D8E, or DS-K1F180-

D8E. If the card is M1 card, then you can enable the M1 Card Encrypon funcon and select

the sector of the card to encrypt.

Click OK to

conrm the operaon.

Place the card on the card enrollment staon, and click Read to get the card number.

The card number will display in the Card No. eld automacally.

Click Add.

The card will be issued to the person.

9.4.4 Upload a Face Photo from Local PC

When adding person, you can upload a face photo stored in local PC to the client as the person's

prole.

Steps

Enter Person module.

Select an organizaon in the organizaon list to add the person and click Add.

Note

Enter the person's basic informaon rst. For details about conguring person's basic

informaon, refer to Congure Basic Informaon .

Click Add Face in the Basic Informaon panel.

Select Upload.

Select a picture from the PC running the client.

Note

The picture should be in JPG or JPEG format and smaller than 200 KB.

Oponal: Enable Verify by Device to check whether the facial recognion device managed in

the client can recognize the face in the photo.

Note

This funcon is hidden or shown according to the device capacity.

Conrm to add the person.

Click Add to add the person and close the Add Person window.

Click Add and New to add the person and

connue to add other persons .

DS-K1T331 Series Face Recognion Terminal User Manual

9.4.5 Take a Photo via Client

When adding a person, you can take a photo of the her/him via the client and set this photo as the

person's

prole.

Before You Start

Make sure PC running the client has a camera or you have connected other USB camera to the PC.

Steps

Enter Person module.

Select an organizaon in the organizaon list to add the person and click Add to enter Add

Person window.

Note

Enter the person's basic informaon rst. For details, refer to Congure Basic Informaon .

Click Add Face in the Basic Informaon area.

Select Take Photo to enter Take Photo window.

Oponal: Enable Verify by Device to check whether the captured face photo can meet the

uploading requirements.

Note

This funcon is hidden or shown according to the device capacity.

Take a photo.

1) Face to the camera and make sure your face is in the middle of the collecng window.

2) Click

to capture a face photo.

3) Oponal: Click to capture again.

4) Click OK to save the captured photo.

DS-K1T331 Series Face Recognion Terminal User Manual

Figure 9-6 Take a Photo via Client

Conrm to add the person.

Click Add to add the person and close the Add Person window.

Click Add and New to add the person and

connue to add other persons.

9.4.6 Collect Face via Access Control Device

When adding person, you can collect the person's face via access control device added to the client

which supports facial recognion funcon.

Steps

Enter Person module.

Select an

organizaon in the organizaon list to add the person and click Add.

Note

Enter the person's basic informaon rst. For details about conguring person's basic

informaon, refer to Congure Basic Informaon .

Click Add Face in the Basic Informaon panel.

Select Remote

Collecon.

Select an added access control device or the enrollment staon from the drop-down list.

DS-K1T331 Series Face Recognion Terminal User Manual

Note

If you select the enrollment staon, you should click Login to set related parameters of the

device including IP address, port No., user name, and password. Also, you can check Face An-

Spoong and select the liveness level as Low, Medium, or High.

Face An-Spoong

If you check this funcon, then the device can detect whether the face to be collected is an

authenc one.

Collect face.

1) Face to the camera of the selected access control device and make sure your face is in the

middle of the

collecng window.

2) Click to capture a photo.

3) Click OK to save the captured photo.

Conrm to add the person.

Click Add to add the person and close the Add Person window.

Click Add and New to add the person and

connue to add other persons .

9.4.7

Congure Access Control Informaon

When adding a person, you can set her/his access control informaon, such as binding an access

control group with the person,

conguring PIN code, seng the person as a visitor, a blocklist

person, or a super user, etc.

Steps

Enter Person module.

Select an

organizaon in the organizaon list to add the person and click Add.

In the Access Control area, click to select access group(s) for the person.

Note

For details, refer to Set Access Group to Assign Access Authorizaon to Persons .

DS-K1T331 Series Face Recognion Terminal User Manual

Figure 9-7 Congure Access Control Informaon

Set a unique PIN code for the person which can be used for access authencaon.

Manually enter a PIN code containing 4 to 8 digits.

Note

Persons' PIN codes cannot be repeated.

Click Generate to randomly generate an unrepeated PIN code of 6 digits.

Note

If there are repeated PIN codes, a prompt will pop up on the client. The admin can generate a

new PIN code to replace the repeated PIN code and nofy related persons.

Check the person's operaon permissions.

Super User

If the person is set as a super user, he/she will have

authorizaon to access all the doors/

oors and will be exempted from remaining closed restricons, all an-passback rules, and

rst person authorizaon.

Extended Door Open Time

Use this funcon for persons with reduced mobility. When accessing the door, the person will

have more me than others to pass through doors.

For details about seng the door's open duraon, refer to Congure Parameters for Door/

Elevator .

Add to Blocklist

Add the person to the blocklist and when the person tries to access doors/oors, an event

will be triggered and sent to the client to nofy the security personnel.

Mark as Visitor

If the person is a visitor, you should set the her/his valid mes for visit.

DS-K1T331 Series Face Recognion Terminal User Manual

Note

The valid mes for visit is between 1 and 100. You can also check No Limit, then there are no

limited mes for the visitor to access doors/oors.

Device Operator

For person with device operator role, he/she is authorized to operate on the access control

devices.

Note

The Super User, Extended Door Open Time, Add to Blocklist, and Mark as Visitor funcons

cannot be enabled concurrently. For example, if one person is set as super user, you cannot

enable extended door open me for her/him, add her/him to the blocklist, or set her/him as

visitor.

Conrm to add the person.

Click Add to add the person and close the Add Person window.

Click Add and New to add the person and

connue to add other persons.

9.4.8 Customize Person

Informaon

You can customize the person properes which are not pre-dened in the client according to actual

needs, e.g., place of birth. Aer customizing, when add a person, you can enter the custom

informaon to make the person informaon complete.

Steps

Enter Person module.

Set the elds of custom informaon.

1) Click Custom Property.

2) Click Add to add a new property.

3) Enter the property name.

4) Click OK.

Set the custom

informaon when adding a person.

1) Select an organizaon in the organizaon list to add the person and click Add.

Note

Enter the person's basic informaon rst. For details about conguring person's basic

informaon, refer to Congure Basic Informaon .

2) In the Custom Informaon panel, enter the person informaon.

3) Click Add to add the person and close the Add Person window, or click Add and New to add

the person and connue to add other persons.

DS-K1T331 Series Face Recognion Terminal User Manual

100

9.4.9 Congure Resident Informaon

If the person is resident, for video intercom purpose, you need to set the room number for

her/him and bind an indoor

staon. Aer bound, you can call this person by calling the indoor

staon and perform video intercom with her/him.

Steps

Enter Person module.

Select an

organizaon in the organizaon list to add the person and click Add.

Note

Enter the person's basic informaon rst. For details about conguring person's basic

informaon, refer to Congure Basic Informaon .

In the Resident Informaon panel, select the indoor staon to bind it to the person.

Note

If you select Analog Indoor Staon, the Door Staon eld will display and you are required to

select the door staon to communicate with the analog indoor staon.

Enter the oor No. and room No. of the person.

Conrm to add the person.

Click Add to add the person and close the Add Person window.

Click Add and New to add the person and

connue to add other persons.

9.4.10

Congure Addional Informaon

When adding person, you can congure the addional informaon for the person, such as person's

identy type, identy No., country, etc., according to actual needs.

Steps

Enter Person module.

Select an organizaon in the organizaon list to add the person and click Add.

Note

Enter the person's basic informaon rst. For details about conguring person's basic

informaon, refer to Congure Basic Informaon .

In the Addional Informaon panel, enter the addional informaon of the person, including

person's ID type, ID No., job tle, etc., according to actual needs.

Conrm to add the person.

Click Add to add the person and close the Add Person window.

Click Add and New to add the person and

connue to add other persons .

DS-K1T331 Series Face Recognion Terminal User Manual

101

9.4.11 Import and Export Person Idenfy Informaon

You can import the informaon and pictures of mulple persons to the client soware in a batch.

Meanwhile, you can also export the person

informaon and pictures and save them in your PC.

9.4.12 Import Person Informaon

You can enter the informaon of mulple persons in a predened template (CSV/Excel le) to

import the informaon to the client in a batch.

Steps

Enter the Person module.

Select an added

organizaon in the list, or click Add in the upper-le corner to add an

organizaon and then select it.

Click Import to open the Import panel.

Select Person

Informaon as the imporng mode.

Click Download Template for Imporng Person to download the template.

Enter the person informaon in the downloaded template.

Note

●

If the person has mulple cards, separate the card No. with semicolon.

●

Items with asterisk are required.

●

By default, the Hire Date is the current date.

Click to select the CSV/Excel le with person informaon from local PC.

Click Import to start imporng.

Note

●

If a person No. already exists in the client's database, delete the exisng informaon before

imporng.

●

You can import informaon of no more than 2,000 persons.

9.4.13 Import Person Pictures

Aer imporng face pictures for the added persons to the client, the persons in the pictures can be

idened by an added face recognion terminal. You can either import person pictures one by

one, or import

mulple pictures at a me according to your need.

Before You Start

Be sure to have imported person informaon to the client beforehand.

Steps

Enter the Person module.

DS-K1T331 Series Face Recognion Terminal User Manual

102

Select an added organizaon in the list, or click Add in the upper-le corner to add an

organizaon and then select it.

Click Import to open the Import panel and check Face.

Oponal: Enable Verify by Device to check whether face recognion device managed in the

client can recognize the face in the photo.

Click to select a face picture le.

Note

●

The (folder of) face pictures should be in ZIP format.

●

Each picture le should be in JPG format and should be no larger than 200 KB.

●

Each picture le should be named as "Person ID_Name". The Person ID should be the same

with that of the imported person

informaon.

Click Import to start imporng.

The imporng progress and result will be displayed.

9.4.14 Export Person

Informaon

You can export the added persons' informaon to local PC as a CSV/Excel le.

Before You Start

Make sure you have added persons to an

organizaon.

Steps

Enter the Person module.

Oponal: Select an organizaon in the list.

Note

All persons' informaon will be exported if you do not select any organizaon.

Click Export to open the Export panel.

Check Person

Informaon as the content to export.

Check desired items to export.

Click Export to save the exported

le in CSV/Excel le on your PC.

9.4.15 Export Person Pictures

You can export face picture le of the added persons and save in your PC.

Before You Start

Make sure you have added persons and their face pictures to an organizaon.

Steps

Enter the Person module.

Oponal: Select an organizaon in the list.

DS-K1T331 Series Face Recognion Terminal User Manual

103

Note

All persons' face pictures will be exported if you do not select any organizaon.

Click Export to open the Export panel and check Face as the content to export.

Click Export to start

exporng.

Note

●

The exported le is in ZIP format.

●

The exported face picture is named as "Person ID_Name_0" ("0" is for a full-frontal face).

9.4.16 Delete Registered Pictures

You can delete face picture le of the added persons automacally.

Before You Start

Make sure you have saved the structure data.

Steps

Enter the Person module.

Oponal: Select a person item in the list.

Click Delete Registered Picture to delete the registered picture.

9.4.17 Get Person

Informaon from Access Control Device

If the added access control device has been congured with person informaon (including person

details and issued card informaon), you can get the person informaon from the device and

import them to the client for further

operaons.

Steps

Note

●

If the person name stored in the device is empty, the person name will be lled with the issued

card No. aer imporng to the client.

●

If the card number or person ID (employee ID) stored on the device already exists in the client

database, the person with this card number or person ID will not be imported to the client.

Enter Person module.

Select an organizaon to import the persons.

Click Get from Device.

Select an added access control device or the enrollment

staon from the drop-down list.

DS-K1T331 Series Face Recognion Terminal User Manual

104

Note

If you select the enrollment staon, you should click Login, and set IP address, port No., user

name and password of the device.

Click Import to start imporng the person informaon to the client.

Note

Up to 2,000 persons and 5,000 cards can be imported.

The person informaon, including person details, and the linked cards (if congured), will be

imported to the selected organizaon.

9.4.18 Move Persons to Another

Organizaon

You can move the added persons to another organizaon if you need.

Before You Start

●

Make sure you have added at least two

organizaons.

●

Make sure you have imported person informaon.

Steps

Enter Person module.

Select an

organizaon in the le panel.

The persons under the organizaon will be displayed in the right panel.

Select the person to move.

Click Change

Organizaon.

Select the

organizaon to move persons to.

Click OK.

9.4.19 Issue Cards to Persons in Batch

The client provides a convenient way to issue cards to mulple persons in a batch.

Steps

Enter Person module.

Click Batch Issue Cards.

All the added persons with no card issued will be displayed in the right panel.

Oponal: Enter key words (name or person ID) in the input box to lter the person(s) that need

issuing cards.

Oponal: Click Sengs to set the card issuing parameters. For details, refer to Issue a Card by

Local Mode.

Click

Inialize to inialize the card enrollment staon or card reader to make it ready for issuing

cards.

Click the Card No. column and enter the card number.

DS-K1T331 Series Face Recognion Terminal User Manual

105

Place the card on the card enrollment staon.

Swipe the card on the card reader.

Manually enter the card number and press the Enter key.

The person(s) in the list will be issued with card(s).

9.4.20 Report Card Loss

If the person lost his/her card, you can report the card loss so that the card's related access

authorizaon will be inacve.

Steps

Enter Person module.

Select the person you want to report card loss for and click Edit to open the Edit Person window.

In the

Credenal → Card panel, click on the added card to set this card as lost card.

Aer reporng card loss, the access authorizaon of this card will be invalid and inacve. Other

person who gets this card cannot access the doors by swiping this lost card.

Oponal: If the lost card is found, you can click to cancel the loss.

Aer cancelling card loss, the access authorizaon of the person will be valid and acve.

If the lost card is added in one access group and the access group is applied to the device

already,

aer reporng card loss or cancelling card loss, a window will pop up to nofy you to

apply the changes to the device. Aer applying to device, these changes can take eect on the

device.

9.4.21 Set Card Issuing Parameters

The client provides two modes for reading a card's number: via card enrollment staon or via the

card reader of the access control device. If a card enrollment

staon is available, connect it to the

PC running the client by USB interface or COM, and place the card on the card enrollment to read

the card number. If not, you can also swipe the card on the card reader of the added access control

device to get the card number. As a result, before issuing a card to one person, you need to set the

card issuing parameters including the issuing mode and related parameters.

When adding a card to one person, click

Sengs to open the Card Issuing Sengs window.

Local Mode: Issue Card by Card Enrollment

Staon

Connect a card enrollment staon to the PC running the client. You can place the card on the card

enrollment staon to get the card number.

Card Enrollment

Staon

Select the model of the connected card enrollment staon

DS-K1T331 Series Face Recognion Terminal User Manual

106

Note

Currently, the supported card enrollment staon models include DS-K1F100-D8, DS-K1F100-M,

DS-K1F100-D8E, and DS-K1F180-D8E.

Card Type

This eld is only available when the model is DS-K1F100-D8E or DS-K1F180-D8E.

Select the card type as EM card or IC card according to the actual card type.

Serial Port

It is only available when the model is DS-K1F100-M.

Select the COM the card enrollment

staon connects to.

Buzzing

Enable or disable the buzzing when the card number is read successfully.

Card No. Type

Select the type of the card number according to actual needs.

M1 Card Encrypon

This eld is only available when the model is DS-K1F100-D8, DS-K1F100-D8E, or DS-K1F180-D8E.

If the card is M1 card, and if you need to enable the M1 Card

Encrypon funcon, you should

enable this funcon and select the sector of the card to encrypt.

Remote Mode: Issue Card by Card Reader

Select an access control device added in the client and swipe the card on its card reader to read

the card number.

9.5

Congure Schedule and Template

You can congure the template including holiday and week schedule. Aer seng the template,

you can adopt the

congured template to access groups when seng the access groups, so that

the access group will take eect in the me duraons of the template.

Note

For access group sengs, refer to Set Access Group to Assign Access Authorizaon to Persons .

9.5.1 Add Holiday

You can create holidays and set the days in the holidays, including start date, end date, and holiday

duraon in one day.

DS-K1T331 Series Face Recognion Terminal User Manual

107

Steps

Note

You can add up to 64 holidays in the soware system.

Click Access Control → Schedule → Holiday to enter the Holiday page.

Click Add on the le panel.

Create a name for the holiday.

Oponal: Enter the descripons or some nocaons of this holiday in the Remark box.

Add a holiday period to the holiday list and

congure the holiday duraon.

Note

Up to 16 holiday periods can be added to one holiday.

1) Click Add in the Holiday List eld.

2) Drag the cursor to draw the me duraon, which means in that duraon of me, the

congured access group is acvated.

Note

Up to 8 me duraons can be set to one holiday period.

3) Oponal: Perform the following operaons to edit the me duraons.

●

Move the cursor to the

me duraon and drag the me duraon on the meline bar to the

desired posion when the cursor turns to .

●

Click the

me duraon and directly edit the start/end me in the appeared dialog.

●

Move the cursor to the start or the end of me duraon and drag to lengthen or shorten

the me duraon when the cursor turns to .

Oponal: Select the me duraon(s) that need to be deleted, and then click in the

Operaon column to delete the selected me duraon(s).

5) Oponal: Click in the Operaon column to clear all the me duraon(s) in the me bar.

6) Oponal: Click in the Operaon column to delete this added holiday period from the

holiday list.

Click Save.

9.5.2 Add Template

Template includes week schedule and holiday. You can set week schedule and assign the me

duraon of access authorizaon for dierent person or group. You can also select the added

holiday(s) for the template.

Steps

Note

You can add up to 255 templates in the soware system.

DS-K1T331 Series Face Recognion Terminal User Manual

108

Click Access Control → Schedule → Template to enter the Template page.

Note

There are two default templates: All-Day Authorized and All-Day Denied, and they cannot be

edited or deleted.

All-Day Authorized

The access authorizaon is valid in each day of the week and it has no holiday.

All-Day Denied

The access authorizaon is invalid in each day of the week and it has no holiday.

Click Add on the le panel to create a new template.

Create a name for the template.

Enter the descripons or some nocaon of this template in the Remark box.

Edit the week schedule to apply it to the template.

1) Click Week Schedule tab on the lower panel.

2) Select a day of the week and draw

me duraon(s) on the meline bar.

Note

Up to 8 me duraon(s) can be set for each day in the week schedule.

3) Oponal: Perform the following operaons to edit the me duraons.

●

Move the cursor to the me duraon and drag the me duraon on the meline bar to the

desired

posion when the cursor turns to .

●

Click the me duraon and directly edit the start/end me in the appeared dialog.

●

Move the cursor to the start or the end of me duraon and drag to lengthen or shorten

the

me duraon when the cursor turns to .

4) Repeat the two steps above to draw more me duraons on the other days of the week.

Add a holiday to apply it to the template.

Note

Up to 4 holidays can be added to one template.

1) Click Holiday tab.

2) Select a holiday in the

le list and it will be added to the selected list on the right panel.

3) Oponal: Click Add to add a new holiday.

Note

For details about adding a holiday, refer to Add Holiday .

4) Oponal: Select a selected holiday in the right list and click to remove the selected one, or

click Clear to clear all the selected holiday(s) in the right list.

Click Save to save the

sengs and nish adding the template.

DS-K1T331 Series Face Recognion Terminal User Manual

109

9.6 Set Access Group to Assign Access Authorizaon to Persons

Aer adding the person and conguring the person's credenals, you can create the access groups

to dene which person(s) can get access to which door(s) and then apply the access group to the

access control device to take eect.

Steps

When the access group

sengs are changed, you need to apply the access groups to the devices

again to take eect. The access group changes include changes of template, access group sengs,

person's access group sengs, and related person details (including card number, face picture,

linkage between card number and linkage between card number and card password, card

eecve

period, etc).

Click Access Control →

Authorizaon → Access Group to enter the Access Group interface.

Click Add to open the Add window.

In the Name text eld, create a name for the access group as you want.

Select a template for the access group.

Note

You should congure the template before access group sengs. Refer to Congure Schedule

and Template for details.

In the le list of the Select Person eld, select person(s) to assign access authority.

In the

le list of the Select Access Point eld, select door(s), door staon(s) or oor(s) for the

selected persons to access.

Click Save.

You can view the selected person(s) and the selected access point(s) on the right side of the

interface.

DS-K1T331 Series Face Recognion Terminal User Manual

110

Figure 9-8 Display the Selected Person(s) and Access Point(s)

Aer adding the access groups, you need to apply them to the access control device to take

eect.

1) Select the access group(s) to apply to the access control device.

2) Click Apply All to Devices start applying all the selected access group(s) to the access control

device or door

staon.

3) Click Apply All to Devices or Apply Changes to Devices.

Apply All to Devices

This

operaon will clear all the existed access groups of the selected devices and then

apply the new access group to the device.

Apply Changes to Devices

This operaon will not clear the existed access groups of the selected devices and only

apply the changed part of the selected access group(s) to the device(s).

4) View the applying status in the Status column or click Applying Status to view all the applied

access group(s).

Note

You can check Display Failure Only to lter the applying results.

The selected persons in the applied access groups will have the authorizaon to enter/exit the

selected doors/door

staons with their linked card(s).

Oponal: Click to edit the access group if necessary.

DS-K1T331 Series Face Recognion Terminal User Manual

111

Note

If you change the persons' access informaon or other related informaon, you will view the

promptAccess Group to Be Applied on the right corner of the client.

You can click the prompt to apply the changed data to the device. You can select either Apply

Now or Apply Later.

Figure 9-10 Data Synchronizaon

9.7

Congure Advanced Funcons

You can congure the advanced funcons of access control to meet some special requirements in

dierent scene.

Note

●

For the card related funcons(the type of access control card), only the card(s) with access group

applied will be listed when adding cards.

●

The advanced funcons should be supported by the device.

●

Hover the cursor on the Advanced

Funcon, and then Click to customize the advanced

funcon(s) to be displayed.

9.7.1 Congure Device Parameters

Aer adding the access control device, you can congure the parameters of access control device,

access control points.

DS-K1T331 Series Face Recognion Terminal User Manual

112

Congure Parameters for Access Control Device

Aer adding the access control device, you can congure its parameters, including overlaying user

informaon on picture, uploading pictures aer capturing, saving captured pictures, etc.

Steps

Click Access Control → Advanced Funcon → Device Parameter .

Note

If you can nd Device Parameter in the Advanced Funcon list, Hover the cursor on the

Advanced Funcon, and then Click to select the Device Parameter to be displayed.

Select an access device to show its parameters on the right page.

Turn the switch to ON to enable the corresponding funcons.

Note

●

The displayed parameters may vary for dierent access control devices.

●

Some of the following parameters are not listed in the Basic Informaon page, click More to

edit the parameters.

Voice Prompt

If you enable this funcon, the voice prompt is enabled in the device. You can hear the voice

prompt when operang in the device.

Upload Pic. Aer Linked Capture

Upload the pictures captured by linked camera to the system automacally.

Save Pic. Aer Linked Capture

If you enable this funcon, you can save the picture captured by linked camera to the device.

Face Recognion Mode

Normal Mode

Recognize face via the camera normally.

Deep Mode

The device can recognize a much wider people range than the normal mode. This mode is

applicable to a more complicated environment.

Enable NFC Card

If enable the

funcon, the device can recognize the NFC card. You can present NFC card on

the device.

Enable M1 Card

If enable the

funcon, the device can recognize the M1 card. You can present M1 card on the

device.

Enable EM Card

DS-K1T331 Series Face Recognion Terminal User Manual

113

If enable the funcon, the device can recognize the EM card. You can present EM card on the

device.

Note

If the peripheral card reader supports presenng EM card, the funcon is also supported to

enable/disable the EM card funcon.

Click OK.

Oponal: Click Copy to, and then select the access control device(s) to copy the parameters in

the page to the selected device(s).

Congure Parameters for Door/Elevator

Aer adding the access control device, you can congure its access point (door) parameters.

Steps

Click Access Control → Advanced

Funcon → Device Parameter .

Select an access control device on the le panel, and then click to show the doors or oors of

the selected device.

Select a door or

oor to show its parameters on the right page.

Edit the door or oor parameters.

Note

●

The displayed parameters may vary for dierent access control devices.

●

Some of the following parameters are not listed in the Basic Informaon page, click Advanced

to edit the parameters.

Name

Edit the card reader name as desired.

Door Contact

You can set the door sensor as remaining closed or remaining open. Usually, it is remaining

closed.

Exit

Buon Type

You can set the exit buon as remaining closed or remaining open. Usually, it is remaining

open.

Open

Duraon

Aer swiping the normal card and relay acon, the mer for locking the door starts working.

Extended Open Duraon

The door contact can be enabled with appropriate delay aer person with extended access

needs swipes her/his card.

Door Le Open Timeout Alarm

DS-K1T331 Series Face Recognion Terminal User Manual

114

The alarm can be triggered if the door has not been closed in a congured me period. If it is

set as 0, no alarm will be triggered.

Duress Code

The door can open by inpung the duress code when there is duress. At the same me, the

client can report the duress event.

Super Password

The specic person can open the door by inpung the super password.

Note

●

The duress code and the super code should be dierent.

●

The duress code and the super password should be dierent from the authencaon

password.

●

The length of duress code and the super password is according the device, usually it should

contains 4 to 8 digits.

Click OK.

Oponal: Click Copy to , and then select the door to copy the parameters in the page to the

selected doors.

Note

The door's status duraon sengs will be copied to the selected door(s) as well.

Congure Parameters for Card Reader

Aer adding the access control device, you can congure its card reader parameters.

Steps

Click Access Control → Advanced Funcon → Device Parameter .

In the device list on the le, click to expand the door, select a card reader and you can edit the

card reader's parameters on the right.

Edit the card reader basic parameters in the Basic

Informaon page.

Note

●

The displayed parameters may vary for dierent access control devices. There are part of

parameters listed as follows. Refer to the user manual of the device for more details.

●

Some of the following parameters are not listed in the Basic Informaon page, click Advanced

to edit the parameters.

Basic Informaon

Name

Edit the card reader name as desired.

Minimum Card Swiping Interval

DS-K1T331 Series Face Recognion Terminal User Manual

115

If the interval between card swiping of the same card is less than the set value, the card

swiping is invalid. You can set it as 0 to 255.

Alarm of Max. Failed Aempts

Enable to report alarm when the card reading aempts reach the set value.

Card Reader Type/Card Reader Descripon

Get card reader type and descripon. They are read-only.

Advanced

Enable Card Reader

Enable the

funcon and e device can be used as an card reader.

OK LED Polarity/Error LED Polarity/Buzzer Polarity

Set OK LED Polarity/Error LED Polarity/Buzzer LED Polarity of main board according to the

card reader parameters. Generally, adopts the default sengs.

Max. Interval When Entering PWD

When you inpung the password on the card reader, if the interval between pressing two

digits is larger than the set value, the digits you pressed before will be cleared

automacally.

Tampering Detecon

Enable the an-tamper detecon for the card reader.

Communicaon with Controller Every

Set the max. failure aempts of reading card.

Face 1:N Matching Threshold

Set the matching threshold when authencang via 1:N matching mode. The larger the value,

the smaller the false accept rate and the larger the false rejecon rate when authencaon.

Face Recognion Interval

The me interval between two connuous face recognions when authencang. By default,

it is 2s.

Face An-Spoong

Enable or disable the live face detecon funcon. If enabling the funcon, the device can

recognize whether the person is a live one or not.

Applicaon Mode

You can select indoor or others applicaon modes according to actual environment.

Lock Authencaon Failed Face

Aer enabling the Live Face Detecon funcon, the system will lock the user's face for 5

minutes if the live face detecon is failed for more than the congured aempts. The same

user cannot

authencate via the fake face within 5 minutes. Within the 5 minutes, the user

can authencate via the real face twice connuously to unlock.

Liveness Level

DS-K1T331 Series Face Recognion Terminal User Manual

116

Aer enabling Face An-Spoong, you can set the matching security level when performing

live face authencaon.

Click OK.

Oponal: Click Copy to, and then select the card reader(s) to copy the parameters in the page to

the selected card reader(s).

9.7.2 Congure Remaining Open/Closed

You can set the status of the door as open or closed. For example, you can set the door remaining

closed in the holiday, and set the door remaining open in the

specied period of the work day.

Before You Start

Add the access control devices to the system.

Steps

Click Access Control → Advanced

Funcon → Remain Open/Closed to enter the Remain Open/

Closed page.

Select the door that need to be

congured on the le panel.

To set the door status during the work day, click the Week Schedule and perform the following

operaons.

1) Click Remain Open or Remain Closed.

2) Drag the cursor to draw the me duraon, which means in that duraon of me, the

congured access group is acvated.

Note

Up to 8 me duraons can be set to each day in the week schedule.

3) Oponal: Perform the following operaons to edit the me duraons.

●

Move the cursor to the me duraon and drag the me duraon on the meline bar to the

desired

posion when the cursor turns to .

●

Click the me duraon and directly edit the start/end me in the appeared dialog.

●

Move the cursor to the start or the end of

me duraon and drag to lengthen or shorten

the me duraon when the cursor turns to .

4) Click Save.

Operaons

Copy to Whole

Week

Select one duraon on the me bar, click Copy to Whole Week to copy all

the duraon sengs on this me bar to other week days.

Delete Selected Select one duraon on the me bar, click Delete Selected to delete this

duraon.

Clear Click Clear to clear all the duraon sengs in the week schedule.

To set the door status during the holiday, click the Holiday and perform the following operaons.

1) Click Remain Open or Remain Closed.

2) Click Add.

DS-K1T331 Series Face Recognion Terminal User Manual

117

3) Enter the start date and end date.

4) Drag the cursor to draw the me duraon, which means in that duraon of me, the

congured access group is acvated.

Note

Up to 8 me duraons can be set to one holiday period.

5) Perform the following operaons to edit the me duraons.

●

Move the cursor to the me duraon and drag the me duraon on the meline bar to the

desired posion when the cursor turns to .

●

Click the

me duraon and directly edit the start/end me in the appeared dialog.

●

Move the cursor to the start or the end of me duraon and drag to lengthen or shorten

the me duraon when the cursor turns to .

6) Oponal: Select the me duraon(s) that need to be deleted, and then click in the

Operaon column to delete the selected me duraon(s).

7) Oponal: Click in the Operaon column to clear all the me duraon(s) in the me bar.

Oponal: Click in the Operaon column to delete this added holiday period from the

holiday list.

9) Click Save.

Oponal: Click Copy to to copy the door status sengs of this door to other door(s).

9.7.3

Congure Mul-Factor Authencaon

You can manage the persons by group and set the authencaon for mulple persons of one

access control point (door).

Before You Start

Set access group and apply the access group to the access control device. For details, refer to

Set

Access Group to Assign Access Authorizaon to Persons .

Perform this task when you want to set

authencaons for mulple cards of one access control

point (door).

Steps

Click Access Control → Advanced Funcon → Mul-Factor Auth .

Select an access control device in device list on the

le panel.

Add a person/card group for the access control device.

1) Click Add on the right panel.

2) Create a name for the group as desired.

3) Specify the start

me and end me of the eecve period for the person/card group.

4) Select members(s) and card(s) in the Available list, and the selected member(s) and card(s)

will be added to the Selected list.

Note

Make sure you have issue card to the person.

DS-K1T331 Series Face Recognion Terminal User Manual

118

Make sure you have set access group and apply the access group to the access control device

successfully.

5) Click Save.

6) Oponal: Select the person/card group(s), and then click Delete to delete it(them).

7) Oponal: Select the person/card group(s), and then click Apply to re-apply access group that

failed to be applied previously to the access control device.

Select an access control point (door) of selected device on the

le panel.

Enter the maximum interval when entering password.

Add an

authencaon group for the selected access control point.

1) Click Add on the Authencaon Groups panel.

2) Select a

congured template as the authencaon template from the drop-down list.

Note

For seng the template, refer to Congure Schedule and Template .

3) Select the authencaon type as Local Authencaon, Local Authencaon and Remotely

Open Door, or Local

Authencaon and Super Password from the drop-down list.

Local Authencaon

Authencaon by the access control device.

Local Authencaon and Remotely Open Door

Authencaon by the access control device and by the client. When the person swipes the

card on the device, a window will pop up. You can unlock the door via the client.

Figure 9-11 Remotely Open Door

Note

You can check Oine Authencaon to enable the super password authencaon when

the access control device is disconnected with the client.

Local Authencaon and Super Password

Authencaon by the access control device and by the super password.

DS-K1T331 Series Face Recognion Terminal User Manual

119

4) Select the added person/card group in the le list below and it will be added to the Selected

list on the right as the authencaon group.

5) Click the added authencaon group in the right list to set authencaon mes in the Auth

Times column.

Note

●

The authencaon mes should be larger than 0 and smaller than the added personnel

quanty in the personnel group.

●

The maximum value of authencaon mes is 16.

6) Click Save.

Note

●

For each access control point (door), up to four authencaon groups can be added.

●

For the authencaon group of which authencaon type is Local Authencaon, up to 8

person/card groups can be added to the authencaon group.

●

For the

authencaon group of which authencaon type is Local Authencaon and Super

Password or Local

Authencaon and Remotely Open Door, up to 7 person/card groups can

be added to the

authencaon group.

Click Save.

9.7.4

Congure Card Reader Authencaon Mode and Schedule

You can set the passing rules for the card reader of the access control device according to your

actual needs.

Steps

Click Access Control → Advanced

Funcon → Authencaon to enter the authencaon mode

conguraon page.

Select a card reader on the

le to congure.

Set card reader authencaon mode.

1) Click Conguraon.

DS-K1T331 Series Face Recognion Terminal User Manual

120

Figure 9-12 Select Card Reader Authencaon Mode

Note

PIN refers to the PIN code set to open the door. Refer to Congure Access Control

Informaon .

2) Check the modes in the Available Mode list and they will be added to the selected modes list.

3) Click OK.

Aer selecng the modes, the selected modes will display as icons with dierent color.

Click the icon to select a card reader authencaon mode, and drag the cursor to draw a color

bar on the schedule, which means in that period of

me, the card reader authencaon is valid.

Repeat the above step to set other me periods.

DS-K1T331 Series Face Recognion Terminal User Manual

121

Figure 9-13 Set Authencaon Modes for Card Readers

Oponal: Select a congured day and click Copy to Week to copy the same sengs to the whole

week.

Oponal: Click Copy to to copy the sengs to other card readers.

Click Save.

9.7.5

Congure First Person In

You can set mulple rst persons for one access control point. Aer the rst person is authorized,

it allows mulple persons access the door or other authencaon acons.

Before You Start

Set the access group and apply the access group to the access control device. For details, refer to

Set Access Group to Assign Access Authorizaon to Persons .

Perform this task when you want to congure opening door with rst person.

Steps

Click Access Control → Advanced Funcon → First Person In to enter the First Person In page.

Select an access control device in the list on the

le panel.

Select the current mode as Enable Remaining Open aer First Person or Disable Remaining

Open aer First Person from the drop-down list for each access control point of the selected

device.

Enable Remaining Open

aer First Person

DS-K1T331 Series Face Recognion Terminal User Manual

122

The door remains open for the congured me duraon aer the rst person is authorized

unl the remain open duraon ends. If you select this mode, you should set the remain open

duraon.

Note

The remain open duraon should be between 0 and 1440 minutes. By default, the remain

open duraon is 10 minutes.

Disable Remaining Open aer First Person

Disable the funcon of rst person in, namely normal authencaon.

Note

You can authencate by the rst person again to disable the rst person mode.

Click Add on the First Person List panel.

Select person(s) in the le list and the person(s) will be add to the selected persons as the rst

person(s) of the doors.

The added rst person(s) will list in the First Person List

Oponal: Select a rst person from the list and click Delete to remove the person from the rst

person list.

Click Save.

9.7.6

Congure An-Passback

The an-passback feature is designed to minimizes the misuse or fraudulent use of access

credenals such as passing back card to an unauthorized person, or tailed access. The an-

passback

funcon establishes a specic sequence in which access credenals must be used in

order to grant access. You can set the sequence according to the actual path via the client and if

the person uses the

credenal in wrong sequence, you can also reset the an-password records.

Before You Start

Add access control device to the client, and enable the an-passing back funcon of the access

control device.

Steps

Note

Either the an-passing back or mul-door interlocking funcon can be congured for an access

control device at the same me. For the conguraon of mul-door interlocking, refer to .

Click Access Control → Advanced Funcon → An-Passback to enter the An-Passpack Sengs

page.

Select an access control device on the le panel.

Select a card reader as the beginning of the path in the First Card Reader

eld.

DS-K1T331 Series Face Recognion Terminal User Manual

123

Click of the selected rst card reader in the Card Reader Aerward column to open the select

card reader dialog.

Select the aerward card readers for the rst card reader.

Note

Up to four aerward card readers can be added as aerward card readers for one card reader.

Click OK in the dialog to save the

selecons.

Click Save in the An-Passback Sengs page to save the sengs and take eect.

Example

Set Card Swiping Path: If you select Reader In_01 as the beginning, and select Reader In_02,

Reader Out_04 as the linked card readers. Then you can only get through the access control

point by swiping the card in the order as Reader In_01, Reader In_02 and Reader Out_04.

Click Reset

An-Passback and select the person(s) to delete the related an-passback records

about the person(s) on the device.

Note

This funcon should be supported by the device.

9.7.7 Congure Device Parameters

Aer adding the access control device, you can set its parameters such as network parameters.

Set

Mulple NIC Parameters

If the device supports mulple network interfaces, you can set the network parameters of these

NICs via the client, such as IP address, MAC address, port number, etc.

Before You Start

Add access control device to the client, and make sure the device supports

mulple NICs.

Steps

Enter the Access Control module.

On the navigaon bar on the le, enter Advanced Funcon → More Parameters .

Select an access control device in the device list and click NIC to enter

Mulple NIC Sengs

page.

Select an NIC you want to congure from the drop-down list.

Set its network parameters such as IP address, default gateway, subnet mask, etc.

MAC Address

A media access control address (MAC address) is a unique

idener assigned to the network

interface for

communicaons on the physical network segment.

MTU

DS-K1T331 Series Face Recognion Terminal User Manual

124

The maximum transmission unit (MTU) of the network interface.

Click Save.

Set Network Parameters

Aer adding the access control device, you can set the device log uploading mode, and create ISUP

account via wired network.

Set Log Uploading Mode

You can set the mode for the device to upload logs via ISUP protocol.

Steps

Enter the Access Control module.

On the

navigaon bar on the le, enter Advanced Funcon → More Parameters .

Select an access control device in the device list and enter Network → Uploading Mode .

Select the center group from the drop-down list.

Check Enable to enable to set the uploading mode.

Select the uploading mode from the drop-down list.

Enable N1 or G1 for the main channel.

Select Close to disable the main channel.

Click Save.

Create ISUP Account in Wired

Communicaon Mode

You can set the account for ISUP protocol in wired communicaon mode. Then you can add

devices via ISUP protocol.

Steps

Note

This funcon should be supported by the device.

Enter the Access Control module.

On the navigaon bar on the le, enter Advanced Funcon → More Parameters .

Select an access control device in the device list and enter Network → Network Center .

Select the center group from the drop-down list.

Select the Address Type as IP Address or Domain Name.

Enter IP address or domain name according to the address type.

Enter the port number for the protocol.

DS-K1T331 Series Face Recognion Terminal User Manual

125

Note

The port number of the wireless network and wired network should be consistent with the port

number of ISUP.

Select the Protocol Type as ISUP.

Note

If set the ISUP version as 5.0, you should create an ISUP key for the ISUP account.

Set an account name for the network center.

10.

Click Save.

Set Device Capture Parameters

You can congure the capture parameters of the access control device, including manual capture

and event triggered capture.

Note

●

The capture funcon should be supported by the device.

●

Before seng the capture parameters, you should set the picture storage rst to dene where

the event triggered pictures are saved. For details, refer to Set Picture Storage in the user

manual of the client

soware. .

Set Triggered Capture Parameters

When an event occurs, the camera of the access control device can be triggered to capture

picture(s) to record what happens when the event occurs. You can view the captured pictures

when checking the event details in Event Center. Before that, you need to set the parameters for

the capture such as number of pictures captured for one

me.

Before You Start

Before

seng the capture parameters, you should set the picture storage rst to dene where the

captured pictures are saved. For details, refer to Set Picture Storage in the user manual of the

client soware.

Steps

Note

This funcon should be supported by the device

Enter the Access Control module.

On the

navigaon bar on the le, enter Advanced Funcon → More Parameters → Capture .

Select an access control device in the device list and select Linked Capture.

Set the picture size and quality.

DS-K1T331 Series Face Recognion Terminal User Manual

126

Set the capture mes once triggered which denes how many pictures will be captures for one

me.

If the capture mes is more than 1, set the interval for each capture.

Click Save.

Set Manual Capture Parameters

In Status Monitoring module, you can capture a picture manually the access control device's

camera by clicking a buon. Before that, you need to set the parameters for the capture such as

picture quality.

Before You Start

Before

seng the capture parameters, you should set the saving path rst to dene where the

captured pictures are saved. For details, refer to Set Picture Storage in the user manual of the

client

soware.

Steps

Note

This funcon should be supported by the device

Enter the Access Control module.

On the

navigaon bar on the le, enter Advanced Funcon → More Parameters → Capture .

Select an access control device in the device list and select Manual Capture.

Select the

resoluon of the captured pictures from the drop-down list.

Select the picture quality as High, Medium, or Low. The higher the picture quality is, the larger

size the picture will be.

Click Save.

Set Parameters for Face

Recognion Terminal

For face recognion terminal, you can set its parameters including face picture database, QR code

authencaon, etc.

Steps

Note

This funcon should be supported by the device.

Enter the Access Control module.

On the

navigaon bar on the le, enter Advanced Funcon → More Parameters .

Select an access control device in the device list and click Face Recognion Terminal.

Set the parameters.

DS-K1T331 Series Face Recognion Terminal User Manual

127

Note

These parameters displayed vary according to dierent device models.

Algorithm

Select Deep Learning as the face picture database.

Save Authencaon Picture

If enabled, the captured face picture when authencang will be saved on the device.

ECO Mode

Aer enabling the ECO mode, the device can authencate faces in the low light or dark

environment. And you can set he ECO mode threshold, ECO mode (1:N), and ECO mode (1:1).

ECO Mode (1:N)

Set the matching threshold when

authencang via ECO mode 1:N matching mode. The

larger the value, the smaller the false accept rate and the larger the false rejecon rate.

ECO Mode Threshold

When enabling the ECO mode, you can set the ECO mode's threshold. The larger the value,

the easier the device entering the ECO mode. Available range: 0 to 8.

Work Mode

Set the device work mode as Access Control Mode. The access control mode is the device

normal mode. You should

authencate your credenal for accessing.

Click Save.

Set RS-485 Parameters

You can set the access control device's RS-485 parameters including the baud rate, data bit, the

stop bit, parity type,

ow control type, communicaon mode, work mode, and connecon mode.

Steps

Note

The RS-485 Sengs should be supported by the device.

Enter the Access Control module.

On the navigaon bar on the le, enter Advanced Funcon → More Parameters .

Select an access control device in the device list and click RS-485 to enter the RS-485

Sengs

page.

Select the serial port number from the drop-down list to set the RS-485 parameters.

Set the serial number, external device,

authencaon center, baud rate, data bit, stop bit, parity

type, ow control type, communicaon mode, and working mode in the drop-down list.

Click Save.

DS-K1T331 Series Face Recognion Terminal User Manual

128

●

The congured parameters will be applied to the device automacally.

●

When you change the working mode or connecon mode, the device will reboot

automacally.

Enable M1 Card Encrypon

M1 card encrypon can improve the security level of authencaon.

Steps

Note

The funcon should be supported by the access control device and the card reader.

Enter the Access Control module.

On the navigaon bar on the le, enter Advanced Funcon → More Parameters .

Select an access control device in the device list and click M1 Card

Encrypon Vericaon to

enter the M1 Card Encrypon Vericaon page.

Set the switch to on to enable the M1 card

encrypon funcon.

Set the sector ID.

Note

●

The sector ID ranges from 1 to 100.

●

By default, Sector 13 is encrypted. It is recommended to encrypt sector 13.

Click Save to save the sengs.

Set Wiegand Parameters

You can set the access control device's Wiegand channel and the communicaon mode. Aer

seng the Wiegand parameters, the device can connect to Wiegand card reader via Wiegand

communicaon.

Before You Start

Add access control device to the client, and make sure the device supports Wiegand.

Steps

Enter the Access Control module.

On the

navigaon bar on the le, enter Advanced Funcon → More Parameters .

Select an access control device in the device list and click Wiegand to enter the Wiegand

Sengs page.

Set the switch to on to enable the Wiegand

funcon for the device.

Select the Wiegand channel No. and the communicaon mode from the drop-down list.

DS-K1T331 Series Face Recognion Terminal User Manual

129

Note

If you set Communicaon Direcon as Sending, you are required to set the Wiegand Mode as

Wiegand 26 or Wiegand 34.

Click Save.

●

The congured parameters will be applied to the device automacally.

●

Aer changing the communicaon direcon, the device will reboot automacally.

9.8 Congure Linkage Acons for Access Control

You can congure dierent linkage acons for the event detected by the access control device.

Aer that, linkage acons will be triggered once the event happens. This mechanism is used for

nofying the security personnel the event, or triggering automac access control in real me.

Two types of linkage acons are supported:

●

Client

Acons: When the event is detected, it will trigger the acons on the client, such as the

client making an audible warning..

●

Device

Acons: When the event is detected, it will trigger the acons of a specic device, such

as buzzing of a card reader and, opening/closing of a door, ..

9.8.1

Congure Client Acons for Access Event

Even if you are far away from an access point, you can sll know what happens and how urgent the

event is via the client by conguring client acons for the access event. Client acons here refer to

the

acons automacally executed by the client itself, such as making an audible warning and

sending an email. Once an event is triggered, the client will nofy the security personnel, so that

he/she can handle the event in

me.

Before You Start

Add access control device to the client.

Steps

Click Event

Conguraon → Access Control Event .

The added access control devices will display in the device list.

Select a resource (including device, alarm input, door, and card reader) from the device list.

The event types which the selected resource supports appear.

Select the event(s) and click Edit Priority to

dene the priority for the event(s), which can be

used to lter events in the Event Center.

Set the linkage

acons of the event.

1) Select the event(s) and click Edit Linkage to set the client acons when the event(s) are

triggered.

Audible Warning

DS-K1T331 Series Face Recognion Terminal User Manual

130

The client soware gives an audible warning when the event is triggered. You can select

alarm sound for the audible warning.

Note

For details about seng the alarm sound, refer to Set Alarm Sound in the user manual of

the client soware.

Send Email

Send an email

nocaon about the event to one or more receivers.

For details about

seng email parameters, refer to Set Email Parameters in the user

manual of the client

soware.

2) Click OK.

Enable the event so that when the event is detected, event will be sent to the client and the

linkage

acons will be triggered.

Oponal: Click Copy to to copy the event sengs to other access control device, alarm input,

door, or card reader.

9.8.2

Congure Device Acons for Access Event

You can set the access control device's linkage acons for the access control device's triggered

event. When the event is triggered, it can trigger the alarm output, host buzzer, and other acons

on the same device.

Steps

Note

It should be supported by the device.

Click Access Control → Linkage Conguraon .

Select the access control device from the list on the

le.

Click Add buon to add a new linkage.

Select the event source as Event Linkage.

select the event type and detailed event to set the linkage.

In the Linkage Target area, set the property target to enable this

acon.

Buzzer on Controller

The audible warning of access control device will be triggered.

Capture

The real-me capture will be triggered.

Access Point

The door status of open, close, remain open, and remain close will be triggered.

DS-K1T331 Series Face Recognion Terminal User Manual

131

Note

The target door and the source door cannot be the same one.

Click Save.

Oponal: Aer adding the device linkage, you can do one or more of the following:

Edit Linkage

Sengs

Select the congured linkage sengs in the device list and you can edit its

event source parameters, including event source and linkage target.

Delete Linkage

Sengs

Select the congured linkage sengs in the device list and click Delete to

delete it.

9.8.3 Congure Device Acons for Card Swiping

You can set the access control device's linkage acons for the specied card swiping. When you

swipe the

specied card, it can trigger the host buzzer, and other acons on the same device.

Steps

Note

It should be supported by the device.

Click Access Control → Linkage Conguraon .

Select the access control device from the list on the

le.

Click Add buon to add a new linkage.

Select the event source as Card Linkage.

Enter the card number or select the card from the drop-down list.

Select the card reader where the card swipes to trigger the linked

acons.

In the Linkage Target area, set the property target to enable this acon.

Buzzer on Controller

The audible warning of access control device will be triggered.

Capture

The

real-me capture will be triggered.

Access Point

The door status of open, close, remain open, or remain closed will be triggered.

Click Save.

When the card

(congured in Step 5) swipes on the card reader (congured in Step 6), it can

trigger the linked acons (congured in step 7).

Oponal: Aer adding the device linkage, you can do one or more of the following:

Delete Linkage

Sengs

Select the congured linkage sengs in the device list and click Delete to

delete it.

DS-K1T331 Series Face Recognion Terminal User Manual

132

Edit Linkage

Sengs

Select the congured linkage sengs in the device list and you can edit its

event source parameters, including event source and linkage target.

9.8.4 Congure Device Acons for Person ID

You can set the access control device's linkage acons for the specied person ID. When access

control device detects the

specied person ID, it can trigger the alarm output, buzzer on card

reader, and other acons, so as to implement special monitoring on the specied person.

Steps

Note

It should be supported by the device.

Click Access Control → Linkage Conguraon .

Select the access control device from the list on the

le.

Click Add to add a new linkage.

Select Person Linkage as the event source.

Enter the employee number or select the person from the drop-down list.

Select the card reader where the card swipes.

In the Linkage Target area, set the property target to enable this

acon.

Buzzer on Controller

The audible warning of access control device will be triggered.

Buzzer on Reader

The audible warning of card reader will be triggered.

Capture

An event-related picture will be captured when the selected event happens.

Recording

An event-related picture will be captured when the selected event happens.

Note

The device should support recording.

Alarm Output

The alarm output will be triggered for nocaon.

Alarm Input

Arm or disarm the alarm input.

Note

The device should support zone funcon.

DS-K1T331 Series Face Recognion Terminal User Manual

133

Access Point

The door status of open, close, remain open, or remain closed will be triggered.

Audio Play

The audio prompt will be triggered. And the select audio index related audio content will be

played according to the congured play mode.

Click Save.

Oponal: Aer adding the device linkage, you can do one or more of the followings:

Delete Linkage

Sengs

Select the congured linkage sengs in the device list and click Delete to

delete it.

Edit Linkage

Sengs

Select the congured linkage sengs in the device list and you can edit its

event source parameters, including event source and linkage target.

9.9 Door Control

In Monitoring module, you can view the real-me status of the doors managed by the added

access control device. You can also control the doors such as open/close the door, or remain the

door open/closed via the client remotely. The real-me access event are displayed in this module.

You can view the access details and person details.

Note

For the user with door control permission, the user can enter the Monitoring module and control

the door. Or the icons used for control will not show. For seng the user permission, refer to

Person Management .

9.9.1 Control Door Status

You can control the status for the door(s), including unlock door, locking door, remaining the door

unlock, remaining the door locked, remain all unlocked, etc.

Before You Start

●

Add person and assign access

authorizaon to designed person, and person will have the access

authorizaon to the access points (doors). For details, refer to Person Management and Set

Access Group to Assign Access Authorizaon to Persons .

●

Make sure the

operaon user has the permission of the access points (doors). For details, refer

to .

Steps

Click Monitoring to enter the status monitoring page.

Select an access point group on the upper-right corner.

DS-K1T331 Series Face Recognion Terminal User Manual

134

Note

For managing the access point group, refer to Group Management .

The doors in the selected access control group will display.

Click a door icon to select a door, or press Ctrl and select mulple doors.

Note

For Remain All Unlocked and Remain All Locked, ignore this step.

Click the following buons to control the door.

Unlock

When the door is locked, unlock it and it will be open for once. Aer the open duraon, the

door will be closed and locked again

automacally.

Lock

When the door is unlocked, lock it and it will be closed. The person who has the access

authorizaon can access the door with credenals.

Remain Unlocked

The door will be unlocked (no maer closed or open). All the persons can access the door

with no

credenals required.

Remain Locked

The door will be closed and locked. No person can access the door even if he/she has the

authorized credenals, except the super users.

Remain All Unlocked

All doors in the group will be unlocked (no maer closed or open). All the persons can access

the doors with no

credenals required.

Remain All Locked

All doors in the group will be closed and locked. No person can access the doors even if

he/she has the authorized credenals, except the super users.

Capture

Capture a picture manually.

Note

The Capture buon is available when the device supports capture funcon. The picture is

saved in the PC running the client. For seng the saving path, refer to Set File Saving Path in

the user manual of the client soware.

Result

The icon of the doors will change in real-me according to the operaon if the operaon is

succeeded.

DS-K1T331 Series Face Recognion Terminal User Manual

135

9.9.2 Check Real-Time Access Records

The access records will display in real me, including card swiping records, face recognions

records, comparison records, etc. You can view the person informaon and view the picture

captured during access.

Steps

Click Monitoring and select a group from the drop-down list on the upper-right corner.

The access records triggered at the doors in the selected group will display in real

me. You can

view the details of the records, including card No., person name, organizaon, event me, etc.

Oponal: Check the event type and event status so that these events will show in the list if the

events are detected. The events of unchecked type or status will not be displayed in the list.

Oponal: Check Show Latest Event and the latest access record will be selected and displayed at

the top of the record list.

Oponal: Click the event to view the accessed person details, including person pictures

(captured picture and prole), person No., person name, organizaon, phone, contact address,

etc.

Note

You can double click the captured picture to enlarge it to view the details.

Oponal: Right click on the column name of the access event table to show or hide the column

according to actual needs.

9.10 Event Center

The event informaon (for example, device oine) received by the client displays. In the Event

Center, you can check the detailed

informaon of the real-me and historical events, view the

event linked video, handle the events, and so on.

Before the client can receive the event

informaon from the device, you need to enable the events

of the resource and arm the device rst. For details, refer to Enable Receiving Event from Devices .

9.10.1 Enable Receiving Event from Devices

Before the client soware can receive event nocaons from the device, you need to arm the

device rst.

Steps

Click → Tool → Device Arming Control to open Device Arming Control page.

All the added devices appear on this page.

Oponal: If there are to many devices, enter the key words in Filter led to lter the device(s)

you want.

DS-K1T331 Series Face Recognion Terminal User Manual

136

Note

For the ltered devices, you can click Arm All or Disarm All to enable receiving event of these

devices.

In the Auto-Arming column, turn on the switch to enable auto-arming.

Figure 9-14 Arm Device

Aer turned on, the device(s) will be armed. And nocaons about the events triggered by the

armed device(s) will be automacally sent to the client soware in real-me.

9.10.2 View Real-Time Events

The real-me event informaon received by the client of the connected resources are displayed.

You can check the

real-me event informaon, including event source, event me, priority, etc.

Before You Start

Enable receiving events from devices before the client can receive event from the device, see

Enable Receiving Event from Devices for details.

Steps

Click Event Center → Real-me Event to enter the real-me event page and you can view the

real-me events received by the client.

Event Time

DS-K1T331 Series Face Recognion Terminal User Manual

137

For encoding device, event me is the client me when it receives the event. For other device

types, event me is the me when the event is triggered.

Priority

Priority represents the emergency degree of the event.

Filter the events.

Filter by Device Type and (or)

Priority

Select device type(s) and (or) priories to lter

events.

Filter by Keywords Enter the keywords to lter the events.

Oponal: Right-click the table header of the event list to customize the event related items to be

displayed in the event list.

Select an event in the event list to view the event details.

Oponal: Perform the following operaons if necessary.

Handle Single Event Click Handle to enter the processing suggeson, and then click OK.

Note

Aer an event is handled, the Handle buon will become Add

Remark. Click Add Remark to add more remarks for this handled

event.

Handle Events in a

Batch

Select events that need to be processed, and then click Handle in

Batch. Enter the processing suggeson, and then click OK.

Enable/Disable Alarm

Audio

Click Audio On/Mute to enable/disable the audio of the event.

Select the Latest

Event Automacally

Check Auto-Select Latest Event to select the latest event

automacally and the event informaon details is displayed.

Clear Events Click Clear to clear the all the events in the event list.

Send Email Select an event and then click Send Email, and the informaon

details of this event will be sent by email.

Note

You should congure the email parameters rst, see Set Email

Parameters in the user manual of the client soware for details.

Auto-Play Video Check Auto-Play Video to automacally play video when displaying

event details.

Enlarge Video or


●

Double click the video image to view video in a larger window.

●

Put the cursor on the picture, and click to view picture in a

larger window.

DS-K1T331 Series Face Recognion Terminal User Manual

138

Download Captured


Hover the cursor on the captured picture, and click the download

icon on the lower right corner of the picture to download it to the

local PC.

Download Event

Triggered Video

Hover the cursor on the recorded video, click to download the

video (30s before the event happens) triggered by the event.

9.10.3 Search Historical Events

You can search and view historical events by seng search condions such as me, device type,

and priority in the client. For the searched events, you can handle and export them.

Before You Start

Enable receiving events from devices before the client can receive event

informaon from the

device,see Enable Receiving Event from Devices for details.

Steps

Click Event Center → Event Search to enter the event search page.

Set the

lter condions to display the required events only.

Time

The me when the event starts.

Search by

Device

Search the events by device or the device's resource channels. If searched by device, you

need to set the followings:

●

Include Sub-Node: Search the events of the device and all resource channels.

●

Device Type: Select the device from which you want to search events.

Group

Search the events by resource channels in the group.

Note

●

For video intercom device, you need to select search scope: All and Locking Log.

●

For access control device, you can click Show More to set more condions: status, event

type, card reader type, person name, card No., and organizaon.

Priority

The priority including low, medium, high and uncategorized which indicates the emergency

degree of the event.

Event Type

Select one or more event types to be searched from the drop-down list.

DS-K1T331 Series Face Recognion Terminal User Manual

139

Note

You can enter a key word (supports fuzzy search) in the search box to search the target event

type(s).

Status

The handling status of the event.

Search by Keyword

Enter a key word (supports fuzzy search) to quickly search the target historical event(s). For

example, you can enter a person's name to search the events related with this person.

Click Search to search the events according the

condions you set.

Figure 9-15 Search Historical Events

Note

If you have selected Access Control as device type in Step 2, you can view extra informaon such

as card No., skin-surface temperature, and abnormal temperature (if device supports) in the

searched events.

DS-K1T331 Series Face Recognion Terminal User Manual

140

Figure 9-16 Search Historical Event

Oponal: Right click the table header of the event list to customize the event related items to be

displayed in the event list.

Select an event in the event list to view the event details.

Oponal: Perform one of the following operaons.

Handle Single

Event

Handle single event: Select one event that needs to be handled, and then

click Handle in the event informaon details page, and enter the handling

suggeson.

Note

Aer an event is handled, the Handle buon will become Add Remark,

click Add Remark to add more remarks for this handled event.

Batch Handle

Events

Handle events in a batch: Select the events which need to be handled,

and then click Handle in Batch, and enter the handling suggeson.

Note

Aer an event is handled, the Handle buon will become Add Remark,

click Add Remark to add more remarks for this handled event.

DS-K1T331 Series Face Recognion Terminal User Manual

141

Auto-Play Video Check Auto-Play Video to automacally play video when displaying event

details.

Enlarge Video or


●

Double click the video image to view video in a larger window.

●

Put the cursor on the picture, and click to view picture in a larger

window.

Send Email Select an event and then click Send Email, and the informaon details of

this event will be sent by email.

Note

You should congure the email parameters rst, see Set Email Parameters

in the user manual of the client soware for details.

Export Event

Informaon

Click Export to export the event log or event pictures to the local PC in

CSV/Excel le. You can set the saving path manually.

Download

Captured Picture

Hover the cursor on the captured picture, and click the download icon on

the lower right corner of the picture to download it to the local PC.

Download Event

Triggered Video

Hover the cursor on the recorded video, click to download the video

(30s before the event happens) triggered by the event.

9.11 Time and Aendance

The Time and Aendance module provides mulple funconalies to track and monitor when

employees start and stop work, and full control of employees working hours such as late arrivals,

early departures,

me taken on breaks and absenteeism.

Note

In this secon, we introduce the conguraons before you can geng the aendance reports. The

access records recorded aer these conguraons will be calculated in the stascs.

9.11.1 Congure Aendance Parameters

You can congure the aendance parameters, including the general rule, overme parameters,

aendance check point, holiday, leave type, etc.

Set Weekend

The days of weekends may vary in

dierent countries and regions. The client provides weekends

denion funcon. You can select one or more days as the weekends according to actual

requirements, and set dierent aendance rules for weekends from workdays.

DS-K1T331 Series Face Recognion Terminal User Manual

142

Steps

Note

The parameters congured here will be set as default for the newly added me period. It will not

aect the existed one(s).

Enter Time & Aendance module.

Click

Aendance Sengs → General Rule .

Select the day(s) as weekend, such as Saturday and Sunday.

Click Save.

Congure Overme Parameters

You can congure the overme parameters for workday and weekend, including overme level,

work hour rate, aendance status for overme, etc.

Steps

Click Time &

Aendance → Aendance Sengs → Overme .

Set required

informaon.

Overme

Level for Workday

When you work for a certain period aer end-work me on workday, you will reach dierent

overme level: overme level 1, overme level 2 and overme level 3. You can set dierent

work hour rate for three overme levels, respecvely.

Work Hour Rate

Work Hour Rate is used to calculate work hours by mulplying it by overme. When you work

for a certain period aer end-work me on workday, you will reach dierent overme level.

You can set

dierent work hour rates (1-10, can be a decimal) for three overme levels. For

example, your valid overme is one hour (in overme level 1), and the work hour rate of

overme level 1 is set as 2, then the work hours in the period will be calculated as 2 hours.

Overme Rule for Weekend

You can enable overme rule for weekend and set calculaon mode.

Click Save.

Congure

Aendance Check Point

You can set the card reader(s) of the access control device as the aendance check point(s), so that

the authencaon on the card readers will be recorded for aendance.

Before You Start

●

You have added access control device(s). For details, refer to Add Device .

●

You have enabled T&A Status. For details, refer to

Add General Timetable .

DS-K1T331 Series Face Recognion Terminal User Manual

143

By default, all card readers of the added access control devices are set as start/end-work check

points. If you need to edit check point funcon of card reader(s), you can perform the following

operaons.

Steps

Enter the Time & Aendance module.

Click Aendance Sengs → Aendance Check Point to enter the aendance check point

sengs page.

Set Set All Card Readers as Check Points switch to o.

Check the desired card reader(s) as aendance check point(s) in the list below.

Set check point funcon as Start/End-Work, Start-Work or End-Work.

Note

When selecng Start-Work or End-Work, the aendance status uploaded from the device will

be decided by the check point funcon you set here.

Start-Work

Aendance status uploaded from the device will all be calculated as Check-in.

End-Work

Aendance status uploaded from the device will all be calculated as Check-out.

Start/End-Work

Aendance status will be calculated as Check in/out according to the actual aendance

status on the device.

Click Set as Check Point.

The

congured aendance check point(s) are displayed on the right list.

Oponal: Aer seng aendance check points, and perform the following operaons.

Edit Check

Point

Check one aendance check point, click Edit to edit its informaon including

name, check point funcon, etc.

Check two or more aendance check points, click Edit to batch edit check

point

funcon, enter remark, etc.

Delete Check

Point

Check one or more check points, and click Delete to delete it/them.

Congure Holiday

You can add the holiday during which the check-in or check-out will not be recorded.

DS-K1T331 Series Face Recognion Terminal User Manual

144

Add Regular Holiday

You can congure a holiday which will take eect annually on regular days during the eecve

period, such as New Year's Day, Independence Day, Christmas Day, etc.

Steps

Enter the Time & Aendance module.

Click Aendance Sengs → Holiday to enter the Holiday Sengs page.

Check Regular Holiday as holiday type.

Custom a name for the holiday.

Set the

rst day of the holiday.

Enter the number of the holiday days.

Set the

aendance status if the employee works on holiday.

Oponal: Check Repeat Annually to make this holiday seng eecve every year.

Click OK.

The added holiday will display in the holiday list and calendar.

If the date is selected as

dierent holidays, it will be recorded as the rst-added holiday.

10.

Oponal: Aer adding the holiday, perform one of the following operaons.

Edit Holiday

Click to edit the holiday informaon.

Delete Holiday Select one or more added holidays, and click Delete to delete the

holiday(s) from the holiday list.

Add Irregular Holiday

You can congure a holiday which will take eect annually on irregular days during the eecve

period, such as Bank Holiday.

Steps

Enter the Time & Aendance module.

Click Aendance Sengs → Holiday to enter the Holiday Sengs page.

Click Add to open the Add Holiday page.

Check Irregular Holiday as holiday type.

Custom a name for the holiday.

Set the start date of the holiday.

Example

If you want to set the forth Thursday in November, 2019 as the Thanksgiving Day holiday, you

should select 2019, November, 4th, and Thursday from the four drop-down lists.

Enter the number of the holiday days.

Set the

aendance status if the employee works on holiday.

Oponal: Check Repeat Annually to make this holiday seng eecve every year

DS-K1T331 Series Face Recognion Terminal User Manual

145

10.

Click OK.

The added holiday will display in the holiday list and calendar.

If the date is selected as dierent holidays, it will be recorded as the rst-added holiday.

11.

Oponal: Aer adding the holiday, perform one of the following operaons.

Edit Holiday Click to edit the holiday informaon.

Delete Holiday Select one or more added holidays, and click Delete to delete the

holiday(s) from the holiday list.

Congure Leave Type

You can customize the leave type (major leave type and minor leave type) according to actual

needs. You can also edit or delete the leave type.

Steps

Enter the Time &

Aendance module.

Click

Aendance Sengs → Leave Type to enter the Leave Type Sengs page.

Click Add on the le to add a major leave type.

Oponal: Perform one of the following operaons for major leave type.

Edit

Move the cursor over the major leave type and click to edit the major leave type.

Delete Select one major leave type and click Delete on the le to delete the major leave

type.

Click Add on the right to add a minor leave type.

Oponal: Perform one of the following operaons for minor leave type.

Edit

Move the cursor over the minor leave type and click to edit the minor leave type.

Delete Select one or mulple major leave types and click Delete on the right to delete the

selected minor leave type(s).

Synchronize Authencaon Record to Third-Party Database

The aendance data recorded on the client can be used by other system for calculaon or some

other

operaons. You can enable synchronizaon funcon to apply the authencaon record from

the client to the third-party database automacally.

Steps

Enter Time & Aendance module.

Click

Aendance Sengs → Third-Party Database .

Set Apply to Database switch to on to enable synchronizaon funcon.

Select database Type as SQLServer or MySQL.

DS-K1T331 Series Face Recognion Terminal User Manual

146

Note

If you select MySQL, you should import the conguraon le (libmysql.dll) from local PC.

Set the other required parameters of the third-party database, including server IP address, port

No., database name, user name and password.

Note

The default port No. of the selected database type is displayed automacally. You can enter a

number ranging from 1 to 65535 to customize the port No if needed.

Set table parameters of database according to the actual conguraon.

1) Enter the table name of the third-party database.

2) Set the mapped table elds between the client and the third-party database.

Click Save to test whether database can be connected and save the sengs for the successful

connecon.

●

The aendance data will be wrien to the third-party database.

●

During

synchronizaon, if the client disconnects with the third-party database, the client will

start

reconnecon every 30 mins. Aer being reconnected, the client will synchronize the data

recorded during the disconnected me period to the third-party database.

Congure

Break Time

You can add break me and set start me, end me, duraon, calculaon mode and other

parameters for the break. The added break me can also be edited or deleted.

Steps

Click Time & Aendance → Timetable → Break Time .

The added break

me is displayed in the list.

Click Break Time Sengs to enter Break Time Sengs window.

Click Add.

Enter a name for the break

me.

Set related parameters for the break me.

Start Time / End Time

Set the me when the break starts and ends.

No Earlier Than / No Later Than

Set the earliest swiping me for starng break and the latest swiping me for ending break.

Break Duraon

The duraon from start me to end me of the break.

Calculaon

Auto Deduct

The break duraon will be calculated according to the me you set.

DS-K1T331 Series Face Recognion Terminal User Manual

147

Must Check

The break duraon will be calculated and excluded from work hours according to actual

check-in and check-out me.

Return from Break Early for

The actual check-in and check-out me does not exceed the break me, and can be

marked as normal work or work overme.

Return from Break Late for

The actual check-in and check-out me exceeds the break me, and can be marked as

late, absent or early leave.

Calculated by

Each Check in/out: Each check-in me and check-out me is valid and the sum of all

periods between adjacent check-in and check-out

me will be recorded as the break

me duraon.

First In & Last Out: The rst check-in me is recorded as start break me and the last

check-out

me is recorded as the end break me.

Enable T&A Status

Set Enable T&A Status switch to on to calculate the actual break me according to

aendance status on the device.

Note

This funcon should be supported by the device.

Valid Authencaon Interval

During the valid authencaon interval, person swiping card for several mes will only

be calculated as once when

calculang aendance data.

Click Save to save the sengs.

Oponal: Click Add to connue adding break me.

Congure

Report Display

You can congure display contents displayed in the aendance report, such as the company name,

logo, date format,

me format, and mark.

Steps

Enter Time & Aendance module.

Click Aendance Stascs → Report Display .

Set the display

sengs for aendance report.

Company Name

Enter a company name to display the name in the report.

Aendance Status Mark

DS-K1T331 Series Face Recognion Terminal User Manual

148

Enter the mark and select the color. The related elds of aendance status in the report will

display with the mark and color.

Weekend Mark

Enter the mark and select the color. The weekend elds in the report will display with the

mark and color.

Click Save.

9.11.2 Add General Timetable

On the

metable page, you can add general metable for employees, which requires the xed

start-work me and end-work me. Also, you can set valid check-in/out me, allowable metable

for being late and leaving early.

Steps

Click Time and

Aendance → Timetable to enter the metable sengs page.

Click Add to enter add metable page.

DS-K1T331 Series Face Recognion Terminal User Manual

149

Figure 9-17 Add Timetable

Create a name for the metable.

Note

You can click the color icon beside the name to customize the color for the valid metable on

the me bar in the Conguraon Result area.

Select the metable type as general.

Select calculaon method.

First In & Last Out

The

rst check-in me is recorded as start work me and the last check-out me is recorded

as the end-work me.

Each Check-In/Out

Each check-in me and check-out me is valid and the sum of all periods between adjacent

check-in and check-out

me will be recorded as the valid working duraon.

DS-K1T331 Series Face Recognion Terminal User Manual

150

You need to set Valid Authencaon Interval for this calculaon method. For example, if the

interval between card swiping of the same card is less than the set value, the card swiping is

invalid.

Oponal: Set Enable T&A Status switch to on to calculate according to aendance status of the

device.

Note

This funcon should be supported by the device.

Oponal: Enable Calculate Break Time into Aended Duraon.

Note

When enabled, break me will be calculated into the overall aendance duraon. That is, the

actual aendance duraon equals to the overall aendance duraon (includes break me).

Set the related aendance me parameters as the following:

Start/End-Work Time

Set the start-work

me and end-work-me.

Valid Check-in/out Time

On the me bar, adjust the yellow bar to set the metable during which the check-in or

check-out is valid.

Calculated as

Set the duraon calculated as the actual work duraon.

Late/Early Leave Allowable

Set the metable for late or early leave.

Set absence related parameters.

Check-In, Late for

You can set the late

me duraon for the employee who has checked in but is late for work. If

the employee exceeds the required

me period, his/her aendance data will be marked as

absent.

Check-Out, Early Leave for

You can set the early leave me duraon for the employee who checks out earlier than the

normal leave

me, and his/her aendance data will be marked as absent.

No Check-in

If the employee does not check in, his/her aendance data may be marked as absent or late.

No Check-Out

If the employee does not check out, his/her aendance data may be marked as absent or

early leave.

10.

Click Save to add the

metable.

11.

Oponal: Perform one or more following operaons aer adding metable.

Edit Timetable

Select a metable from the list to edit related informaon.

DS-K1T331 Series Face Recognion Terminal User Manual

151

Delete Timetable Select a metable from the list and click Delete to delete it.

9.11.3 Add Shi

You can add shi for employees including seng shi period (day, week, month) and the eecve

aendance

me. According to the actual requirements, you can adding mulple metables in one

shi for employees, which requires them to check in and check out for each metable.

Before You Start

Add a

metable rst. See Add General Timetable for details.

Steps

Click Time & Aendance → Shi to enter shi sengs page.

Click Add to enter Add

Shi page.

Enter the name for shi.

Select the shi period from the drop-down list.

Select the added

metable and click on the me bar to apply the metable.

DS-K1T331 Series Face Recognion Terminal User Manual

152

Figure 9-18 Add Shi

Note

You can select more than one metables. The start and end work me and the valid check-in

and out me in dierent me tables can not be overlapped.

DS-K1T331 Series Face Recognion Terminal User Manual

153

Figure 9-19 Add Mulple Timetables

Click Save.

The added shi lists on the le panel of the page. At most 64 shis can be added.

Oponal: Assign the shi to organizaon or person for a quick shi schedule.

1) Click Assign.

2) Select

Organizaon or Person tab and check the desired organizaon(s) or person(s) box.

The selected organizaons or persons will list on the right page.

3) Set the Expire Date for the shi schedule.

4) Set other parameters for the schedule.

Check-in Not Required

Persons in this schedule do not need to check-in when they come to work.

Check-out Not Required

Persons in this schedule do not need to check-out when they end work.

Scheduled on Holidays

DS-K1T331 Series Face Recognion Terminal User Manual

154

On the holidays, this schedule is sll eecve and the persons needs to go to work

according to the schedule.

Eecve for Overme

The persons' overme will be recorded for this schedule.

5) Click Save to save the quick shi schedule.

9.11.4 Manage Shi Schedule

Shi work is an employment pracce designed to make use of all 24 hours of the clock each day of

the week. The pracce typically sees the day divided into shis, set periods of me during which

dierent shis perform their dues.

You can set department schedule, person schedule, and temporary schedule.

Set Department Schedule

You can set the shi schedule for one department, and all the persons in the department will be

assigned with the

shi schedule.

Before You Start

In Time & Aendance module, the department list is the same with the organizaon. You should

add organizaon and persons in Person module rst. See Person Management for details.

Steps

Click Time & Aendance → Shi Schedule to enter the Shi Schedule Management page.

Click Department Schedule to enter Department Schedule page.

Select the department from the

organizaon list on the le.

Note

If Include Sub Organizaon is checked, when selecng the organizaon, its sub organizaons are

selected at the same me.

Select the shi from the drop-down list.

Oponal: Enable Mulple Shi Schedules and select the eecve me period(s) from the

added

metables for the persons.

Note

This is only available for shi with only one metable.

Mulple Shi Schedules

It contains more than one metables. The person can check in/out in any of the metables

and the aendance will be eecve.

DS-K1T331 Series Face Recognion Terminal User Manual

155

If the mulple shi schedules contains three metables: 00:00 to 07:00, 08:00 to 15:00 and

16:00 to 23:00. The aendance of the person adopng this mulple shi schedules will be

eecve in any of the three metables. If the person checks in at 07:50, it will apply the

nearest metable 08:00 to 15:00 to the person's aendance.

Set the start date and end date.

Set other parameters for the schedule.

Check-in Not Required

Persons in this schedule do not need to check-in when they come to work.

Check-out Not Required

Persons in this schedule do not need to check-out when they end work.

Scheduled on Holidays

On the holidays, this schedule is

sll eecve and the persons needs to go to work according

to the schedule.

Eecve for Overme

The persons' overme will be recorded for this schedule.

Flexible Shi Schedule on Weekend

The person's aendance on the weekend will be recorded as overme.

Click Save.

Set Person Schedule

You can assign the shi schedule to one or more persons. You can also view and edit the person

schedule details.

Before You Start

Add department and person in Person module. See

Person Management for details.

Steps

Note

The person schedule has the higher priority than department schedule.

Click Time & Aendance → Shi Schedule to enter the Shi Schedule page.

Click Person Schedule to enter Person Schedule page.

Select the

organizaon and select the person(s).

Select the shi from the drop-down list.

Oponal: Enable Mulple Shi Schedules and select the eecve me period(s) from the

added metables for the persons.

DS-K1T331 Series Face Recognion Terminal User Manual

156

Note

This is only available for shi with only one metable.

Mulple Shi Schedules

It contains more than one metables. The person can check in/out in any of the metables

and the aendance will be eecve.

If the mulple shi schedules contains three metables: 00:00 to 07:00, 08:00 to 15:00 and

16:00 to 23:00. The

aendance of the person adopng this mulple shi schedules will be

eecve in any of the three metables. If the person checks in at 07:50, it will apply the

nearest metable 08:00 to 15:00 to the person's aendance.

Set the start date and end date.

Set other parameters for the schedule.

Check-in Not Required

Persons in this schedule do not need to check-in when they come to work.

Check-out Not Required

Persons in this schedule do not need to check-out when they end work.

Scheduled on Holidays

On the holidays, this schedule is sll eecve and the persons needs to go to work according

to the schedule.

Eecve for Overme

The persons' overme will be recorded for this schedule.

Flexible Shi Schedule on Weekend

The person's aendance on the weekend will be recorded as overme.

Click Save.

Set Temporary Schedule

You can add a temporary schedule for the person and the person will be assigned with the shi

schedule temporarily. You can also view and edit the temporary schedule details.

Before You Start

Add department and person in Person module. See Person Management for details.

Steps

Note

The temporary schedule has higher priority than department schedule and person schedule.

Click Time & Aendance → Shi Schedule to enter the Shi Schedule Management page.

Click Temporary Schedule to enter Temporary Schedule page.

Select the

organizaon and select the person(s).

DS-K1T331 Series Face Recognion Terminal User Manual

157

Click one date or click and drag to select mulple dates for the temporary schedule.

Select Workday or Non-Workday from drop-down list.

If Non-Workday is selected, you need to set the following parameters.

Calculated as

Select normal or overme level to mark the aendance status for temporary schedule.

Timetable

Select a

metable from drop-down list.

Mulple Shi Schedule

It contains more than one metables. The person can check in/out in any of the metables

and the aendance will be eecve.

If the mulple shi schedules contains three metables: 00:00 to 07:00, 08:00 to 15:00 and

16:00 to 23:00. The aendance of the person adopng this mulple shi schedules will be

eecve in any of the three metables. If the person checks in at 07:50, it will apply the

nearest

metable 08:00 to 15:00 to the person's aendance.

Rule

Set other rule for the schedule, such as Check-in Not Required, andCheck-out Not Required.

Click Save.

Check

Shi Schedule

You can check the shi schedule in calendar or list mode. You ca also edit or delete the shi

schedule.

Steps

Click Time & Aendance → Shi Schedule to enter the Shi Schedule Management page.

Select the organizaon and corresponding person(s).

Click

or to view the shi schedule in calendar or list mode.

Calendar

In calendar mode, you can view the shi schedule for each day in one month. You can click

the temporary schedule for one day to edit or delete it.

List

In list mode, you can view the

shi schedule details about one person or organizaon, such as

shi name, type, eecve period and so on. Check the shi schedule(s), and click Delete to

delete the selected

shi schedule(s).

9.11.5 Manually Correct Check-in/out Record

If the aendance status is not correct, you can manually correct the check-in or check out record.

You can also edit, delete, and export the check-in or check-out record.

DS-K1T331 Series Face Recognion Terminal User Manual

158

Before You Start

●

You should add organizaons and persons in Person module. For details, refer to Person

Management .

●

The person's

aendance status is incorrect.

Steps

Click Time & Aendance → Aendance Handling to enter aendance handling page.

Click Correct Check-in/out to enter adding check-in/out

correcon page.

Select one or more persons from le list for correcon.

Select the correcon date.

Select the correcon type as Check-in, Check-out, Break-in, Break-out, etc,. and set the correct

me.

Note

You can click to add mulple correcon items. At most 8 check-in/out items can be added.

Oponal: Enter the remark informaon as desired.

Click Save to save the above sengs.

Oponal: Aer adding the check-in/out correcon, perform one of the following operaons.

View Click or to view the added aendance handling informaon in calendar or list

mode.

Edit

●

In calendar mode, click → Edit to edit the details.

●

In list mode, double-click the related eld in Date, Handling Type, Time, or Remark

column to edit the details.

Note

The edited check-in/out correcon will take aect.

Delete

●

In calendar mode, select one check-in/out correcon, and click Delete to delete

the selected item.

●

In list mode, check one or more check-in/out correcons, and click Delete to

delete the selected items.

Note

The deleted check-in/out correcon will no longer take aect.

Export In list mode, check one or more check-in/out correcons to export the aendance

handling details (CSV le) to local PC.

9.11.6 Add Leave and Business Trip

You can add leave and business trip when the employee want to ask for leave or go on a business

trip.

DS-K1T331 Series Face Recognion Terminal User Manual

159

Before You Start

You should add organizaons and persons in the Person module. For details, refer to Person

Management .

Steps

Click Time &

Aendance → Aendance Handling to enter aendance handling page.

Click Apply for Leave/Business Trip to enter adding the leave/business trip page.

Select person from

le list.

Set the date(s) for your leave or business trip.

Select the major leave type and minor leave type from the drop-down list.

Note

You can set the leave type in Aendance Sengs. For details, refer to Congure Leave Type .

Set the me for leave.

Oponal: Enter the remark informaon as desired.

Click Save.

Oponal: Aer adding the leave and business trip, perform one of the following operaons.

View Click or to view the added aendance handling informaon in calendar or list

mode.

Note

In calendar mode, you need to click Calculate to get the aendance status of the

person in one month.

Edit

●

In calendar mode, click the related label on date to edit the details.

●

In list mode, double-click the led in Date, Handling Type, Time, or Remark column

to edit the related informaon.

Delete Delete the selected items.

Export Export the aendance handling details to local PC.

Note

The exported details are saved in CSV format.

9.11.7 Calculate Aendance Data

You need to calculate the aendance data before searching and viewing the overview of the

aendance data, employees' detailed aendance data, employees' abnormal aendance data, the

employees'

overme working data, and card swiping log.

DS-K1T331 Series Face Recognion Terminal User Manual

160

Automacally Calculate Aendance Data

You can set a schedule so that the client can automacally calculate aendance data of the

previous day at the

me you congured every day.

Steps

Note

Enter the Time & Aendance module.

Click Aendance Sengs → General Rule .

In the Auto-Calculate

Aendance area, set the me that you want the client to calculate the

data.

Click Save.

The client will calculate the

aendance data of the previous day from the me you have

congured.

Manually Calculate

Aendance Data

You can manually calculate aendance data by seng condions including aendance me,

department, aendance status, etc.

Steps

Enter the Time & Aendance module.

Click Aendance Stascs → Calculaon .

Set the start

me and end me to dene the aendance data range.

Select the department from the drop-down list.

Oponal: Set other condions, including name and person ID.

Check aendance status (supports mul-selecon).

Click Calculate.

Note

Only the aendance data within three months can be calculated.

Oponal: Perform one of the following operaons.

Correct Check-

in/out

Select one person, click Correct Check-in/out to add check-in/out

correcon.

Select Items to

Display

Click on the upper right corner, or right click the table header of the

aendance data list to customize the items to be displayed in the list.

Adjust Items

Sequence

Click one item (except Person ID) and move the mouse to customize the

sequence of dierent items.

Generate Report Click Report to generate the aendance report.

DS-K1T331 Series Face Recognion Terminal User Manual

161

Note

The report items will be displayed in the sequence you have set.

Export Report Click Export to export aendance data (CSV le) to local PC.

Note

The report items will be displayed in the sequence you have set.

9.11.8 Aendance Stascs

You can check the original aendance record, generate and export the aendance report based on

the calculated aendance data.

Get an Overview of Employees'

Aendance Data

You can search and view the employee's aendance data on the client, including aendance me,

aendance status, check point, etc.

Before You Start

●

You should add organizaons and persons in Person module and the persons have swiped cards.

For details, refer to

Person Management .

●

Calculate the aendance data.

Note

○

The client will automacally calculate the previous day's aendance data at 1:00 am on the

next day.

○

Keep the client running at 1:00 am or it cannot calculate the previous day's aendance data

automacally. If not calculated automacally, you can calculate the aendance data manually.

For details, refer to

Manually Calculate Aendance Data .

Steps

Enter the Time & Aendance module.

Click

Aendance Stascs → Aendance Record .

Set the aendance start me and end me that you want to search.

Set other search

condions, including department, name, and person ID.

Select data source as All, Original Records on Device or Manually Handled Records.

Oponal: Click Get Events from Device to get the aendance data from the device.

DS-K1T331 Series Face Recognion Terminal User Manual

162

Note

There are two methods for geng aendance events from the device, including Online and

Import File. For more details about operaons, refer to Get Events from Device in the user

manual of the client soware.

Oponal: Click Reset to reset all the search condions and edit the search condions again.

Click Search.

Oponal: For the displayed search results, perform one of the following operaons.

Edit Aendance

Status

Select one incorrect record, double click the eld of Aendance Status

column and select from the drop-down list to edit single piece of

aendance status.

Check two or more incorrect records, click Edit

Aendance Status on the

upper

le corner and select from the drop-down list to batch edit mulple

pieces of aendance status.

Generate

Report

Click Report to generate the aendance report.

Export Report Click Export and select saving path to export the aendance report (CVS

le) to the local PC.

Custom Export Click Custom Report and set condions to export aendance records

according to actual needs. For details, refer to Custom Export Aendance

Records in the user manual of the client soware.

Generate Instant Report

It supports to generate the a series of aendance reports manually to view the employees'

aendance results.

Before You Start

Calculate the aendance data.

Note

You can calculate the aendance data manually, or set the schedule so that the client can calculate

the data automacally every day. For details, refer to Calculate Aendance Data .

Steps

Enter the Time &

Aendance module.

Click Aendance Stascs → Report .

Select a report type.

Select the department or person to view the

aendance report.

Set the start

me and end me during which the aendance data will be displayed in the report.

Click Report to generate the stascs report and open it.

DS-K1T331 Series Face Recognion Terminal User Manual

163

Send Report Regularly

The client supports mulple report types and you can pre-dene the report content and it can

send the report

automacally to the email address you congured.

Steps

Enter the Time & Aendance module.

Click Aendance Stascs → Regularly Send Report .

Click Add to enter the add custom report page.

Set the report content.

Report Name

Enter a name for the report.

Report Type

Select one report type and this report will be generated.

Report Time

The

me to be selected may vary for dierent report type.

Person

Select the added person(s) whose aendance records will be generated for the report.

Note

You can view the selected person(s) in the right side of the Person area.

Set the schedule to send the report to the email address(es) automacally.

Note

The Auto-Send Email funcon is enabled by default.

1) Set the Eecve Period during which the client will send the report on the selected sending

date(s).

2) Select the Sending Date(s) on which the client will send the report.

3) Set the Sending Time at which the client will send the report.

Example

If you set the

eecve period as 2018/3/10 to 2018/4/10, select Friday as the sending date,

and set the sending

me as 20:00:00, the client will send the report at 8 p.m. on Fridays

during 2018/3/10 to 2018/4/10.

Note

Make sure the aendance records are calculated before the sending me. You can calculate

the aendance data manually, or set the schedule so that the client can calculate the data

automacally every day. For details, refer to Calculate Aendance Data .

4) Enter the receiver email address(es).

DS-K1T331 Series Face Recognion Terminal User Manual

164

Note

Up to 5 email addresses can be added. You can click + to add a new email address.

5) Oponal: Click Preview to view the email details.

Click OK.

Oponal: Aer adding the custom report, you can do one or more of the followings:

Edit Report Select one added report and click Edit to edit its sengs.

Delete Report Select one added report and click Delete to delete it.

Generate Report Select one added report and click Report to generate the report instantly

and you can view the report details.

9.12 System Conguraon

9.12.1 Set General Parameters

You can congure the frequently-used parameters, including log expired me, network

performance, etc.

Steps

Enter the System

Conguraon module.

Click General tab to enter the General Sengs page.

Congure the general parameters.

Date Format / Time Format

The display style of date and

me on related pages.

Log Expiry Date

The me for keeping the log les. Once exceeded, the les will be deleted.

Maximum Mode

Select Maximize or Full Screen as the maximum mode. Maximize mode can maximize the

display and show the taskbar. Full Screen mode can display the client in full-screen mode.

Calendar Type

Select Gregorian Calendar or Nepali Calendar as the calendar type. If you select Nepali

Calendar, the calender will switch to Nepali language and calculated

me by Nepali calendar.

You need to restart the client

aer switching the calendar.

Network Performance

Set the network condions to Normal, Beer or Best.

Save Pictures in Structure Data Format

You can enable Save Pictures in Structure Data Format to save structure data and delete

registered picture.

DS-K1T331 Series Face Recognion Terminal User Manual

165

Save Event for

Set the event deleng cycle to delete the old event.

Detect New Soware Version

Aer enabled, the client can automacally detect the new soware version and remind the

user to upgrade the soware.

Automac Time Synchronizaon

Automacally

synchronize the me of the added devices with the me of the PC running the

client at a specied me point.

Auto-Upgrade Device

Set the upgrading mode aer the new version of device are detected.

Disable

Aer enabled, the client will not download the rmware package and upgrade even if the

client detects a new version of the client.

Prompt Me If Download and Upgrade

Aer the client detects a new version of the device, it will prompt the user whether to

download the rmware package and upgrade.

Download and Prompt Me If Upgrade

Aer the client detects the new version of the device, it will download the rmware

package automacally, and prompt the user whether to upgrade.

Download and Prompt Automacally

Aer the client detects the new version of the devices, it will download the rmware

package and upgrade the new version automacally.

You need to set a schedule in the Upgrade Time eld, during which the client upgrades the

new version automacally.

Click Save.

9.12.2 Set Picture Storage

The pictures, captured by the camera of video access control terminal, triggered by events, can be

saved in the PC running the iVMS-4200 Service. You can set the picture storage

locaon here

manually.

Steps

Enter the System Conguraon module.

Click Event Picture Storage.

Set the Store Pictures in Server switch to on.

All the disks of the PC running the iVMS-4200 service will show.

Select the disk to save the pictures.

DS-K1T331 Series Face Recognion Terminal User Manual

166

Note

The default saving path is: Disk/iVMS-4200alarmPicture

Click Save.

9.12.3 Set Alarm Sound

When the event is triggered, the client can give an audible warning to nofy the security

personnel. You can set the sound of the audible warning in this secon.

Steps

Open the System

Conguraon page.

Click Alarm Sound tab to enter the Alarm Sound Sengs page.

Oponal: Click and select the audio les from the local path for dierent events.

Oponal: Add customized alarm sound.

1) Click Add to add customized alarm sound.

2) Double click the Type

eld to customize the alarm sound name as desired.

3) Click and select the audio les from the local path for dierent alarms.

Oponal: Click for a tesng of the audio le.

Oponal: Click in the Operaon column to delete the custom sound.

Click Save.

Note

The format of the audio le can only be WAV.

9.12.4 Set Access Control and Video Intercom Parameters

You can congure the access control and video intercom parameters according to actual needs.

Steps

Open the System Conguraon page.

Click the Access Control & Video Intercom tab.

Input the required

informaon.

Ringtone

Click and select the audio le from the local path for the ringtone of indoor staon.

Oponally, you can click for a tesng of the audio le.

Max. Ring Duraon

Specify the seconds that the ring will last for at most. The maximum ring duraon can be set

from 15s to 60s.

Max. Speaking

Duraon with Indoor Staon

DS-K1T331 Series Face Recognion Terminal User Manual

167

Specify the seconds that the call with indoor staon will last for at most. The maximum

speaking duraon between indoor staon and the client can be set from 120s to 600s.

Max. Speaking Duraon with Door Staon

Specify the seconds that the call with door staon will last for at most. The maximum

speaking duraon between door staon and the client can be set from 90s to 120s.

Max. Speaking Duraon with Access Control Device

Specify the seconds that the call with access control device will last for at most. The

maximum speaking

duraon between access control device and the client can be set from

90s to 120s.

Click Save.

9.12.5 Set File Saving Path

The pictures captured in Status Monitoring module are stored on the local PC. The saving path of

these les can be set.

Steps

Open the System Conguraon page.

Click File tab to enter the File Saving Path

Sengs page.

Click and select a local path for the les.

Click Save.

9.12.6 Set Email Parameters

When an event is triggered, if you can set Send Email as linkage acon for this event, the client will

an email to the recipients for

nocaon. You need to set the email sengs and specify target

recipients in this secon.

Steps

Enter the System Conguraon module.

Click Email tab to enter the Email

Sengs interface.

Enter the required informaon.

STMP Server

The STMP server IP address of host name (e.g., smtp.263xmail.com)

Encrypon Type

You can check the radio to select Non-Encrypted, SSL, or STARTTLS .

Port

Enter the communicaon port used for SMTP. The port is 25 by default.

Sender Address

The email address of the sender.

DS-K1T331 Series Face Recognion Terminal User Manual

168

Security Cercate (Oponal)

If your email server requires authencaon, check this checkbox to use authencaon to log

into the server and enter the login user name and password of your email account.

User Name

Enter the user name of the sender email address if Server Authencaon is checked.

Password

Enter the password of the sender Email address if Server Authencaon is checked.

Receiver 1 to 3

Enter the email address of the receiver. Up to 3 receivers can be set.

Oponal: Click Send Test Email to send an email to the receiver for test.

Click Save.

9.13

Operaon and Maintenance

You can perform maintaining operaons in the menu to ensure a smooth and convenient usage of

the client.

In the upper-right corner of the client, click → File → System → Tool , and perform the

following

operaons.

Open Log File

You can open a log le saved in your local PC or log les of the client.

Import/Export

Conguraon File

You can import conguraon les from local PC to the client if needed, and vice versa.

Auto Backup

Select day and me to backup conguraon les and data in database, or restore the backed up

data.

Skin

Change the skin of the client, including bright-color series and black-color series.

Batch Time Sync

Synchronize selected devices' me with your PC me.

Message Queue

Aer conguring email linkage, the triggered event(s) will be displayed here. Select an event and

cancel sending the an email to the receiver.

DS-K1T331 Series Face Recognion Terminal User Manual

169

Appendix A. Tips When Collecng/Comparing Face


The

posion when collecng or comparing face picture is as below:

Posions (Recommended Distance: 0.5 m)

Expression

●

Keep your expression naturally when collecng or comparing face pictures, just like the

expression in the picture below.

●

Do not wear hat, sunglasses, or other accessories that can aect the facial recognion funcon.

●

Do not make your hair cover your eyes, ears, etc. and heavy makeup is not allowed.

Posture

In order to get a good quality and accurate face picture, posion your face looking at the camera

when collecng or comparing face pictures.

DS-K1T331 Series Face Recognion Terminal User Manual

170

Size

Make sure your face is in the middle of the collecng window.

DS-K1T331 Series Face Recognion Terminal User Manual

171

Appendix B. Tips for Installaon Environment

1. Light Source Illuminaon Reference Value

Candle: 10Lux

Bulb: 100~850Lux

Sunlight: More than 1200Lux

2. Install the device at least 2 meters away from the light, and at least 3 meters away from the

window or door.

3.Avoid backlight, direct and indirect sunlight

DS-K1T331 Series Face Recognion Terminal User Manual

172

Appendix C. Dimension

DS-K1T331 Series Face Recognion Terminal User Manual

173

Appendix D. Communicaon Matrix and Device

Command

Communicaon Matrix

Scan the following QR code to get the device communicaon matrix.

Note that the matrix contains all

communicaon ports of Hikvision access control and video

intercom devices.

Figure D-1 QR Code of Communicaon Matrix

Device Command

Scan the following QR code to get the device common serial port commands.

Note that the command list contains all commonly used serial ports commands for all Hikvision

access control and video intercom devices.

Figure D-2 Device Command

DS-K1T331 Series Face Recognion Terminal User Manual

174

UD15529B-C

Hikvision DS-K1T331W Face Recognition Access Control Terminal

Product's Documents

Hikvision DS-K1T331W User Manual

Specifications

Hikvision DS-K1T331W Questions and Answers
