EN
DETAILED
INSTRUCTIONS FOR USE
OF UPRIGHT FREEZER
2
805159
We thank you for the confidence you have shown by purchasing
our appliance which is designed to simplify your life. To make the use of the
product easier, we have supplied detailed instructions for use, and installation
instructions supplied on a separate sheet. The instructions should allow you to
learn about your new appliance as quickly as possible.
We wish you find a lot of pleasure in its use.
The appliance is intended solely for household use.
The freezer is intended for freezing fresh food and for long-term storage of
frozen food (up to one year, depending on the type of food).
Link to the EU EPREL database
The QR code on the energy label supplied with the appliance provides a web
link to the registration of this appliance in the EU EPREL database. Keep
the energy label for reference together with the user manual and all other
documents provided with this appliance.
It is possible to find information related to the performance of the product
in the EU EPREL database using the link https://eprel.ec.europa.eu and the
model name and product number that you can find on the rating plate of the
appliance.
For more detailed information about the energy label, visit www.theenergylabel.eu.
Important safety warning
General information and tips
i
Protecting the environment
!
Do not wash in the dishwasher
3
CONTENTS
805159
INTRODUCTION
APPLIANCE
DESCRIPTION
DEFROSTING
AND CLEANING
THE APPLIANCE
4 IMPORTANT NOTES AND PRECAUTIONS
4 BEFORE USING THE APPLIANCE FOR THE FIRST TIME
5 IMPORTANT SAFETY INSTRUCTIONS
8 IMPORTANT INFORMATION ON THE USE OF APPLIANCE
9 ENVIRONMENT PROTECTION
10 ADVICE FOR SAVING POWER WITH REFRIGERATION
APPLIANCES
11 INSTALLATION AND CONNECTION
13 APPLIANCE DESCRIPTION
14 OPERATING THE APPLIANCE
16 FREEZING AND STORING FROZEN FOOD
16 Freezing procedure
17 Important warnings on freezing
17 Avoid contamination of food
17 Storing industrially frozen food
18 Frozen food storage time
18 Defrosting frozen food
19 DEFROSTING THE APPLIANCE
20 CLEANING THE APPLIANCE
21 TROUBLESHOOTING
22 INFORMATION ABOUT APPLIANCE NOISE
MISCELLANEOUS
STORING AND
FREEZING FOOD
4
IMPORTANT NOTES AND
PRECAUTIONS
805159
Before connecting the appliance to the power mains,
please read carefully the instructions for use which
describe the appliance and its correct and safe use.
The instructions apply to several appliance types/
models; thus, settings or equipment may be described
herein which is not available in your appliance. We
recommend saving this instruction manual for future
reference and attach it to the appliance if it is sold in
the future.
The instruction manual includes the NO FROST
version/model of the freezer which is fitted with a fan
and in which the defrosting process is automatic (only
with some models).
Check for any damage or irregularities on your
appliance. If you find your appliance is damaged,
notify the retailer from which you have purchased the
appliance.
Before connecting the appliance to the power mains,
let the appliance rest in a vertical position for a
minimum of 2 hours. This will reduce the possibility of
operation faults due to the effect of transport on the
cooling system.
BEFORE USING THE APPLIANCE FOR
THE FIRST TIME
i
5
805159
IMPORTANT SAFETY INSTRUCTIONS
!
The appliance must be connected to the power
mains and grounded in compliance with the effective
standards and regulations.
WARNING! Do not locate multiple portable socket-
outlets or portable power supplies at the rear of the
appliance.
Before cleaning the appliance, unplug it from the power
mains (unplug the power cord from the wall outlet).
WARNING! If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
WARNING! When positioning the appliance, ensure the
supply cord is not trapped or damaged.
If LED lighting does not work, call a service technician.
Do not attempt a repair of the LED lighting yourself, as
there is danger of contact with high voltage!
WARNING! Do not use any electric devices inside
the appliance, except for those allowed by the
manufacturer of this refrigeration appliance.
WARNING! Do not use mechanical devices or other
means to accelerate the defrosting process, other
than those recommended by the manufacturer.
WARNING! To avoid any hazard resulting from poor
stability of the appliance, make sure it is installed as
instructed.
!
!
!
WARNING! Risk of fire/flammable materials.
6
805159
Danger of frostbite
Never put frozen food in your mouth and avoid
touching frozen food as this may cause frostnip or
frostbite.
Safety of children and vulnerable persons
The appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety.
Children should be supervised to ensure that they do
not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
Remove the packaging intended to protect the
appliance or particular parts during transport and keep
it outside the reach of children.
It presents danger of injury or suffocation.
When removing a used appliance, disconnect the
power cord, remove the door, and leave the shelves in
the appliance. This will prevent children from locking
themselves in the appliance.
For European markets only
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
7
805159
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
Children aged from 3 to 8 years are allowed to load
and unload refrigerating appliances.
Warning regarding the refrigerant
The appliance contains a small amount of an
environmentally friendly yet flammable gas R600a.
Make sure that no parts of the cooling system
are damaged. A gas leak is not hazardous to the
environment, but it could cause eye injury or fire.
In case of a gas leak, ventilate the room thoroughly,
disconnect the appliance from the power mains, and
call a service technician.
8
805159
The appliance may not be used outdoors and it may
not be exposed to rain.
Do not store explosive substances such as aerosol cans
with a flammable propellant in this appliance.
If the appliance will be out of use for an extended
period of time, switch it off using the relevant button,
and unplug it from the power mains. Empty the
appliance, defrost it, clean it, and leave the door ajar.
In case of an error or power supply failure do not
open the freezer compartment unless the freezer has
not operated for over 16 hours. After this period, use
the frozen food or provide sufficient cooling (e.g. a
replacement appliance).
WARNING! Keep ventilation openings, in the
appliance enclosure or in the built-in structure, clear
of obstruction.
i
IMPORTANT INFORMATION ON THE USE
OF APPLIANCE
WARNING! This appliance is intended to be used in
household and similar applications such as:
– staff kitchen areas in shops, offices and other working
environments;
– farm houses and by clients in hotels, motels and other
residential type environments;
– bed and breakfast type environments;
– catering and similar non-retail applications.
9
805159
The symbol on the product or its packaging indicates that the product
should not be treated as normal household waste. The product should be
taken to an authorized collection centre for waste electric and electronic
equipment processing. Correct disposal of the product will help prevent
any negative effects on the environment and health of people which could
occur in case of incorrect product removal. For detailed information on
removal and processing of the product, please contact the relevant municipal
body in charge of waste management, your waste disposal service, or the
store where you bought the product.
Packaging is made of environmentally friendly materials
that can be recycled, disposed of, or destroyed without
any hazard to the environment.
!
Removing an obsolete appliance
To protect the environment, take the obsolete
appliance to an authorized home appliance collection
centre.
Before doing so, do the following:
• disconnect the appliance from the power mains;
• do not allow children to play with the appliance.
ENVIRONMENT PROTECTION
WARNING! Do not damage the refrigerant circuit.
This will also prevent pollution.
i
Technical information on the appliance
Rating plate can be found in the appliance interior. It
indicates data on voltage, gross and net volume, type
and amount of refrigerant, and information on the
climate classes.
If the language on the rating plate is not the language
of your choice or the language of your country, replace
it with the one supplied.
10
ADVICE FOR SAVING POWER
WITH REFRIGERATION
APPLIANCES
805159
• Install the appliance as specified in the instruction manual.
• Do not open the door more often than necessary.
• Occasionally make sure air circulation underneath the appliance is
unobstructed.
• Condenser unit on the rear wall should be kept clean (see chapter Cleaning the
appliance).
• If the gasket is damaged or does not provide a perfect seal for any reason,
have it replaced as soon as possible.
• Store the food in tightly sealed containers or appropriate packaging.
• Before placing the food in the refrigerator, allow it to cool down to room
temperature.
• Defrost frozen food in the refrigerator compartment.
• To make use of the entire freezer compartment interior volume, remove
some of the drawers as described in the instruction manual.
• Defrost your conventional freezer when an approximately 3–5 millimetre
layer of frost or ice has built up on the refrigerated surfaces.
• Make sure the layout of shelves in the compartment is uniform and that
the food is placed so that the air can freely circulate in the appliance
interior (observe the recommended placement of food as described in the
instructions).
• In appliances with a fan, do not block the fan slots or vents.
• If you do not need the fan or the ionizer, switch them off to reduce power
consumption.
11
805159
• Do not place an appliance in a room where temperature can drop to
below 5 °C as this may cause abnormal appliance operation or failure!
i
INSTALLATION AND CONNECTION
SELECTING THE ROOM
• Install the appliance in a dry and well ventilated room. The appliance will operate
correctly if the environment temperature is in the interval specifi ed in the table. The
appliance class is indicated on the rating plate / label with the basic information on
the appliance.
Description Class Ambient temperature
range °C
Relative humidity
Extended temperate SN +10 to +32
75%
Temperate N +16 to +32
Subtropical ST +16 to +38
Tropical T +16 to +43
• After the installation, the appliance mains plug should be accessible!
• Do not place the appliance near appliances or devices radiating heat, such as
a cooker, a stove, a radiator, water heater etc., and do not expose it to direct
sunlight. The appliance should stand at least 3 cm away from an electric or gas
cooker or at least 30 cm away from an oil or solid fuel stove. If the distance
between such source of heat and the appliance is smaller, use an insulating
panel.
Note: Place the appliance in a su ciently large room. There should be at least 1
m
3
of space per 8 grams of refrigerant. Amount of refrigerant is indicated on the
rating plate in the appliance interior.
• At the base of the kitchen unit intended for building in the integrated
appliance, there should be at least 200 cm
2
free space, for adequate air
circulation.
On the upper part of the appliance the air is coming out, so try not to cover
the opening for the outfl ow air.
Ignoring this caution may result in damage to the appliance.
Note:
When installing the appliance side-by-side into kitchen cabinets, each appliance
should be integrated into a separate cabinet.
An anti-condensation service kit should be purchased, complete with a power
cord for connecting the kit to the power mains. An additional power socket is
required for connecting the anti-condensation service kit.
For safety reasons, the service kit may only be installed by an authorized
service technician!
12
805159
The process of changing the appliance door opening and integrating the
appliance into a cabinet is described on the separate installation instructions
supplied in the bag with the instruction manual.
CONNECTING THE APPLIANCE
• Connect the appliance to the power
mains using the power cord. The wall
outlet should be fi tted with a ground
contact (safety socket). Nominal
voltage and frequency are indicated
on the rating plate/label with basic
information on the appliance.
• The appliance must be connected
to the power mains and grounded
in compliance with the e ective
standards and regulations. The
appliance will withstand short-term
deviations from the nominal voltage,
but not more than +/- 6%.
CHANGING THE DOOR OPENING DIRECTION AND
INTEGRATING THE APPLIANCE INTO A CABINET
13
APPLIANCE DESCRIPTION
805159
1 Control unit
2 LED lighting
3 NO FROST freezing
unit (cooler, fan ...)
4 Storage compartment
with door
5 Freezing and storage
drawers
1
3
2
4
5
Best location for
freezing fresh food.
This product contains a light source of energy efficiency class (F).
14
OPERATING THE APPLIANCE
805159
Switching on: To switch on: rotate the
A dial clockwise.
Switching off: Rotate the A dial in
the counter-clockwise direction until
the arrow is aligned with the symbol
. (Warning: appliance will remain
powered, i.e. there will still be electric
current in the appliance.)
SWITCHING THE APPLIANCE ON/OFF
A Temperature setting and on/o dial
Use the dial to switch the appliance on or o , set the temperature, and control
the ECO and intensive freezing (freezer boost) function.
B Temperature display
B
A
15
805159
ADJUSTING THE TEMPERATURE IN THE APPLIANCE
• To set the desired temperature,
rotate the A dial in clockwise
direction.
• Recommended setting of the A dial
is on the eco position.
• With this setting, the temperature
in the freezer compartment
temperature will be around –18 °C.
• A change in the environment
temperature will a ect the
temperature in the appliance. Adjust
the setting with the A dial accordingly.
Positions towards the mean a lower
temperature in the appliance (cooler).
Settings towards the mean a higher
temperature (warmer).
i
• After the appliance is switched on, it may take several hours for the set
temperature to be reached. Do not place any food into the freezer before
the temperature drops to the selected setting.
INTENSIVE FREEZING
We recommend using this setting before
cleaning the appliance or 24 hours before
inserting a large amount of food. Activating
this function will make sure the food is
cooled or frozen faster to retain vitamins,
minerals, nutrients, and fl avour, and to
extend its freshness.
• Switching on the intensive freezing: Rotate the A dial to position .
• When the intensive freezing function is active, the B display indicates FF.
• When the intensive freezing function is activated, the appliance will operate
with maximum power. During this time, operation may be somewhat louder.
• After the end of the intensive freezing cycle, rotate the A dial back to the desired
setting.
If the function is not deactivated manually, it will be deactivated automatically
after approximately two days. The temperature returns to the most recently set
value (the most recent setting appears on the display B, but the knob remains in
the position .
16
FREEZING AND STORING
FROZEN FOOD
805159
i
Maximum amount of fresh food that may be inserted
at once is specified on the appliance rating plate. If
the amount of food to be frozen exceeds the indicated
amount, the quality of freezing will be inferior; in addition,
the quality of the food already frozen will deteriorate.
• To make use of the entire freezer volume, remove all drawers. Place the food
directly on the shelves and on the freezer bottom.
• Activate the super freeze function 24 hours before freezing fresh food:
- rotate the A dial to position
.
After this period of time, distribute the food evenly across the drawers intended
for freezing. A maximum of 4 kg may be loaded into each drawer.
Make sure the fresh food is not in contact with the food that is already frozen.
• When freezing smaller amounts of food (1-2 kilograms), activating the super
freeze function is not required.
• After 24 hours, the food can be moved to other freezer compartments and the
freezing process can be repeated as necessary.
FREEZING PROCEDURE
17
805159
i
Only use the freezer to freeze food appropriate for freezing.
Always use quality and fresh food.
Select the most suitable packaging for the food and use the
packaging correctly.
Make sure the packaging is air and water tight so that the
food does not dry out and loose its vitamins.
Indicate the type of food, amount, and date of freezing on
the packaging.
It is important that the food freezes quickly. Therefore,
smaller packages are recommended. Refrigerate the food
before freezing.
IMPORTANT WARNINGS ON FREEZING
STORING INDUSTRIALLY FROZEN FOOD
• When storing and using frozen food, observe the manufacturer's instructions.
Temperature and expiry date are indicated on the packaging.
• Only choose food with undamaged packaging, stored in freezers at
temperatures of –18 °C or lower.
• Do not purchase food covered in frost as this indicates it has been partly
thawed several times and that it is of inferior quality.
• Protect the food from thawing during transport. In case of an increase in
temperature, storage time will be shorter and quality will deteriorate.
AVOID CONTAMINATION OF FOOD
To avoid contamination of food, please respect the following instructions:
• Opening the door for long periods can cause a signifi cant increase of the
temperature in the compartments of the appliance.
• Regularly clean surfaces that can come in contact with food and accessible
drainage systems.
• If the refrigerating appliance is left empty for long periods, switch o , defrost,
clean, dry, and leave the door open to prevent mould developing within the
appliance.
18
805159
FROZEN FOOD STORAGE TIME
RECOMMENDED STORAGE TIME IN THE FREEZER
Type of food Time
fruit, beef from 10 to 12 months
vegetables, veal, poultry from 8 to 10 months
Venison from 6 to 8 months
Pork from 4 to 6 months
finely chopped or ground meat 4 months
bread, pastry, cooked meals, lean fish 3 months
entrails 2 months
smoked sausage, fatty fish 1 month
DEFROSTING FROZEN FOOD
Freezing the food does not kill the microorganisms. After the food is defrosted
or thawed, bacteria are re-activated and the food spoils quickly. Use the
partially or completely defrosted food as soon as possible.
Partial thawing decreases the nutritive value of the food, particularly fruit,
vegetables, and ready-to-eat food.
19
DEFROSTING THE APPLIANCE
805159
DEFROSTING A NO FROST FREEZER
• The NO FROST freezer will defrost automatically. Occasional frost that may
appear on the walls will disappear automatically.
• Build-up of ice or frost in the freezer compartment can be a result of abnormal
use of appliance (door opened too frequently and/or too long, door not
properly closed etc.). In this case, unplug the appliance, remove the food
from the freezer and protect them from defrosting. Clean and dry the freezer
interior. Before returning the frozen food into the freezer, switch on the
appliance and select the desired setting.
20
CLEANING THE APPLIANCE
805159
• Use a soft cloth to clean all surfaces. Cleaners that contain abrasive
substances, acids, or solvents are not suitable for cleaning as they may
damage the surface.
Clean the appliance exterior with water or a mild solution of suds.
Lacquer-coated and aluminium surfaces may be cleaned with lukewarm water
to which you have added a mild detergent. Use of cleaners with low alcohol
content is allowed (e.g. window cleaners). Do not use cleaners containing
alcohol for cleaning plastic materials.
• The condenser unit mounted on the
(exterior) back wall should always be
kept clean, free of dust or deposits
resulting from kitchen smoke or
fumes. Occasionally clean the dust
using a soft non-metal brush or a
vacuum cleaner.
• After cleaning, switch the appliance
back on and insert the food.
Appliance interior can be cleaned with lukewarm water to which you
can add some vinegar.
Before cleaning, unplug the appliance from the power mains – switch off the
appliance (see chapter Switching the Appliance On/Off) and unplug the power
cord from the wall outlet.
!
• Do not wash the parts of appliance interior equipment in a dishwasher as
they may be damaged.
21
TROUBLESHOOTING
Problem: Cause or remedy:
Appliance is connected
to the power mains but
it does not work.
• Make sure there is voltage in the power outlet and
that the appliance is switched on.
Cooling system
operates continuously
for a long period of
time:
• Too high environment temperature.
• Door opened too frequently or too long.
• Door not closed correctly (possible impurities on
the seal, misaligned door, damaged seal etc.).
• Too much fresh food inserted at once.
• Insufficient compressor and condenser unit
cooling. Check for sufficient air circulation behind
the appliance and clean the condenser unit.
Build-up of ice or frost
in the freezer interior
may be a result of the
following:
• Door opened too frequently or too long.
• Door not properly closed.
• Poor door sealing.
• If the seal is dirty or damaged, clean or replace it.
Door is difficult to open: • If you are trying to open the freezer door after
just having closed it, this could be difficult to do.
As you open the door, some cool air escapes from
the appliance and it is replaced by warm air from
the environment. When this air is cooled, negative
pressure is generated which results in problems as
you try to open the door. After a few minutes, the
condition is normalized and the door can be easily
opened again.
LED lighting does not
work:
• If LED lighting does not work, call a service
technician.
• Do not attempt a repair of the LED lighting
yourself, as there is danger of contact with high
voltage!
If the above tips do not resolve your problem, call the nearest authorized service
centre and state the type, model, and serial number indicated on the appliance
rating plate or label located in the appliance interior.
805159
22
INFORMATION ABOUT
APPLIANCE NOISE
805159
Cooling in refrigerator freezers is made possible by a cooling system that also
includes a compressor (and a fan with some appliances), which generates some
noise. The level of noise depends on installation, proper use, and age of the
appliance.
• After connecting the appliance to the power mains, compressor operation,
or the sound of fl owing liquid, may be somewhat louder. This is not a sign
of malfunction and it will not a ect the useful life of the appliance. In time,
appliance operation and this noise will become quieter.
• Sometimes, unusual or loud noises may appear during appliance operation;
these are mostly the result of improper installation:
- The appliance must stand level and stable on a solid base.
- The appliance may not be in contact with a wall or adjacent furniture.
- Make sure the interior equipment sits firmly in its place and that the noise is
not caused by rattling cans, bottles or other containers placed next to each
other.
• Due to the higher workload on the cooling system when the door is opened
more frequently or for a longer time, when a large amount of fresh food is
introduced or when intensive freezing or cooling functions are activated, the
appliance can temporarily generate more noise.
WE RESERVE THE RIGHT TO CHANGES THAT DO NOT AFFECT THE
APPLIANCE FUNCTIONALITY.
FREEZER BI540 ADV HSN en (05-24)
