3PC SMD LED STRIP LIGHTING
MODEL NO: LEDSTR03
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. GENERAL
8 DO NOT shine directly into your, another person’s or an animal’s eyes.
8 DO NOT allow children to use the strip light.
8 DO NOT use the strip light if you suspect that the battery case or any part of the strip light is damaged.
WARNING! Ensure Health and Safety, local authority and general workshop practice regulations are adhered to when using this light.
9 Inspect the cable and connector for wear and damage to ensure items are safe before connecting to the power supply. If worn or
damaged DO NOT use.
IMPORTANT: Check that the voltage marked on the charger plug is the same as the lamp when using your own plug adapter.
9 Uncoil the cable between charger and the lamp.
8 DO NOT use a USB cable or Plug adapter that exceeds 5V-2A, doing so will damage the product and void any warranty.
8 DO NOT pull the charger plug from the mains socket by the lead.
8 DO NOT get the charger wet, or use in wet, damp conditions (for indoor use only).
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or re:
8 DO NOT attempt to open, disassemble, modify or service the battery case.
8 DO NOT leave batteries in supplied battery case for long periods of inactivity.
8 DO NOT crush, puncture, short external contacts or dispose of in re or water.
8 DO NOT expose to temperatures above 60°C (140°F).
9 Replace only with the batteries designated for this product.
9 Recycle or dispose of used batteries as stipulated by local regulation.
9 If the electrolyte in the cells gets on your skin, thoroughly wash with soap and water. If it gets in your eyes, rinse thoroughly with cool
water and seek immediate medical attention.
2. INTRODUCTION
Linkable LED strip lights with PIR and CDS sensor. The sensor only works in dark (illuminance ≤10-20 LUX). The PIR and CDS sensor
can be set to two modes, 30 seconds and 1 minute before turning o. This allows you to leave the light on when not in use and it
will turn o after the set period when no movement is detected. Each strip features 6 SMD LED’s and can be linked to up to 5 strips.
Each pack includes 2 corner extensions, one cover for the end of the strip and 6 metal clips with option of using the included screws
or adhesive strips to attach to almost any surface. USB powered or can be used with the battery case supplied (4 x AAA batteries not
included) which can also be mounted using the bracket supplied, any 5V-1A/2A power bank or a 5V-1A/2A USB plug adaptor.
3. SPECIFICATION
4. OPERATION
4.1. SETTING UP
4.1.1. Connect the light tubes together by removing the end caps and slotting the tubes into each other.
4.1.2. Use the elbow pieces if you need to go around a corner or get the light further back into the cupboard.
4.1.3. Attach the metal clips to the light and stick the adhesive pads to the clips.
4.1.4. Place in desired location.
4.2. USE WITH SUPPLIED BATTERY UNIT
LEDSTR03 Issue 2 (3) 20/09/2023
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Indoor use only
MODEL NO: LEDSTR03
Battery: 4 x AAA (not included)
LED Type: 0.6W x 3 SMD
Length: 306 x 8.44 x 6.80 mm (L x W x D) Per Strip
Lumen Output: 150lm
Operating Time: 4hrs
4.2.1. Insert the batteries into the battery unit, and plug in using micro usb.
4.2.2. Switch unit “ON”.
4.2.3. Turn the switch to “30S” in the strip, when people move close to it in the dark, it will automatically light up. It will turn o
approximately 30 seconds after you leave.
4.2.4. Turn the switch to “1M” in the strip, when people move close to it in the dark, it will automatically light up. It will turn o
approximately 1 minute after you leave.
4.2.5. Switching the battery pack to “OFF” will stop the light from working.
4.3. USE WITH A POWER BANK OR ADAPTOR
4.3.1. Use a 5V-1A/2A power bank or a 5V-1A/2A USB plug adaptor.
Note: When you rst turn the battery to “ON” the lamp will light up, regardless of light conditions. After it turns o automatically, it will
only react in ‘dark’ light conditions (luminance < 20lux).
4.4. LOCATING THE LAMP
4.4.1. Put the sensor lamp inside your house, where you need some extra light.
4.4.2. The best hanging height of the sensor lamp is 1.2m - 1.5m.
4.4.3. Position the away from appliances such as refrigerator, stove, air conditioning etc, places where the temperature will change a lot.
8 DO NOT place on the other side of glass, curtains, or furniture, the lamp sensor will not work if obstructed.
8 DO NOT place the lamp so it is facing a window.
Note: The sensitivity of sensor largely relates to the direction of movement. The best sensitivity is when you move parallel to the
sensor. The lowest sensitivity is moving in radial direction. So it’s critical to seek the location of installation in order to up to the best
sensitivity and avoid the misinformation of infrared probe.
5. MAINTENANCE
5.1. Remove Batteries if storing or not using for long periods of time.
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd Batteries Producer Registration Number (BPRN) is BPRN00705.
LEDSTR03 Issue 2 (3) 20/09/2023
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic
Equipment (WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact
your local solid waste authority for recycling information.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts
without prior notice.
IMPORTANT: No Liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
