Sealey MLB80SB Mini Light Bar Single Bolt Fixing 50W User Manual

SMD LED MINI LIGHT BAR 12/24V 50W -

MAGNETIC BASE, SINGLE POINT FIXING

MODEL NO: MLB80MB, MLB80SB

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these

instructions, and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. SAFETY

9  Familiariseyourselfwiththisproduct’sapplicationandlimitations,aswellasanyspecicpotentialhazardspeculiartothebeacon.

9  Replaceorrepairdamagedparts.Userecommendedpartsonly.Nonauthorisedpartsmaybedangerousandwillinvalidatethe 

 warranty.

8 DO NOTusethebeaconforanypurposeotherthanforwhichitisdesigned.

8 DO NOTallowchildrentooperatethebeacon.

8 DO NOToperatethebeaconifanypartsaremissingordamagedasthismaycausefailureorpossiblepersonalinjury.

9  Whennotinuseswitchthebeacono󰀨andwhereappropriateremoveplugfrompowersupply.

2. INTRODUCTION

Extremelybright50WamberSMDLEDhighintensityminilightbarttedwithmagnetsonthebase.10Modulesttedwith8LEDs,creatinga

360°light.Fittedwitha3mcableand12Vvehicleaccessorysocket.Plugincludestwoswitches,on/o󰀨andamomentaryswitch,givingyouthe

optionof10di󰀨erentashpatterns.Built-inmemoryrecallslastpatternselected.ECER65andR10Approvedforhighwayuse.CEApproved

andE-Marked.IP66rated.Singleboltversionavailable(ModelNo.MLB80SB).

3. SPECIFICATION

Model No:............................................MLB80MB,MLB80SB

CurrentDrawinAmps:........................ (12V)2.5A/(24V)1.2A

Dimensions:.......................... (WxDxH)279x165x61mm

IPRating:........................................................................IP66

Power:.............................................................................50W

Supply:................................................................. 12-24VDC

Temperature Range:......................................-30°Cto+50°C

4. OPERATION

4.1. WIRING

4.1.1.  Blackwireshouldbewiredtoasuitableearth.

4.1.2. Redwireshouldbewiredviaaswitchtoasuitablefused12V

 livesupplyttedwitha5ampfuse.

4.1.3. Yellowwireshouldbewiredtoearthviaamomentary

 switch(negativeearth).

4.2. ATTACHING THE LIGHT TO YOUR VEHICLE

4.2.1. Therearetwostrongmagnetsonthereverseoftheunit.

 (g.1)

4.3. ATTACHING THE LIGHT BAR VIA THE SCREW FITTING

4.3.1. Thescrewcanberemovedfromtheundersideofthelight

 barbyremovingthexingplate.(g.1)

4.3.2. Underthexingplatethereisarecessfortheheadof

 thesetscrewtositin.Thiswillstopthesetscrewfrom

 turningwhentighteningthenut.(g.2)

4.4. SWITCHING ON AND CHANGING THE LIGHT

PATTERN

4.4.1. Therearetwobuttonsontheincaradaptor.Oneswitch

 (withLEDindicatorlight)switchesthelightonando󰀨.

The otherswitchswitcheslightpatterns.(g.3)

MLB80MB,MLB80SBIssue3(H23)02/05/23

Original Language Version

©JackSealeyLimited

Refer To

Instructions

g.1

g.2

Warning! Do Not

LookDirectlyInto

Light.

Warning!Hot

Surfaces

4.5. LIGHT PATTERNS

1 ECER65SlowFlash

2 Fast Flash

3 SAEDoubleFlash

4 Quad Flash

5 Splitash+FastFlash

6 QuadFlash+SplitFlash

7 SlowFlash+DoubleFlash

8 SlowFlash+6QuickFlashes

9 DoubleFlash+QuadFlash

10 DoubleFlash+QuadFlash+6QuickFlashes

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR

01284 757500 sales@sealey.co.uk www.sealey.co.uk

ENVIRONMENT PROTECTION

Recycleunwantedmaterialsinsteadofdisposingofthemaswaste.Alltools,accessoriesandpackagingshouldbesorted,

takentoarecyclingcentreanddisposedofinamannerwhichiscompatiblewiththeenvironment.Whentheproduct

becomescompletelyunserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersand

disposeoftheproductandfluidsaccordingtolocalregulations.

WEEE REGULATIONS

DisposeofthisproductattheendofitsworkinglifeincompliancewiththeEUDirectiveonWasteElectricalandElectronicEquipment

(WEEE).Whentheproductisnolongerrequired,itmustbedisposedofinanenvironmentallyprotectiveway.Contactyourlocalsolid

wasteauthorityforrecyclinginformation.

Note:Itisourpolicytocontinuallyimproveproductsandassuchwereservetherighttoalterdata,specificationsandcomponentpartswithoutprior

notice.

Important:NoLiabilityisacceptedforincorrectuseofthisproduct.

Warranty:Guaranteeis12monthsfrompurchasedate,proofofwhichisrequiredforanyclaim.

Original Language Version

g.3

MLB80MB,MLB80SBIssue3(H23)02/05/23
