LG Electronics RNC2 LG XBOOM Speaker

Product's Documents

Below are documents related to this product, you can read online or download:
RNC2 photo

Owner’s Manual English

This is the main product document for model RNC2.

The file format is pdf, 29 pages, you can download this manual here .

background
OWNER’S MANUAL
HIGH POWER SPEAKER
SYSTEM
Please read this manual carefully before operating your set and retain it for future
reference.
Model
RNC2
2405_Rev01
www.lg.com
Copyright © 2024 LG Electronics Inc. All Rights Reserved.
background
2
HIGH POWER SPEAKER SYSTEM
Quick Guide
Connecting and Using the Speaker
a
c
b
A
B
A Remote sensor
B Woofer lighting
HIGH POWER SPEAKER SYSTEM Quick Guide
background
3
a Plug the power cord before use.
b Playing Music from the USB ([ See “Connecting the product to
a USB storage device” on page 14.)
A Plug the USB storage device into the USB terminal.
B Press the Power
button to turn on the product.
C Press the Function
button repeatedly until “USB” appears on the status display.
D Press the Play/Pause
button to enjoy the music.
c Connecting the Speaker to a Smartphone Using Bluetooth ([
See “Connecting Smartphone to the Speaker via Bluetooth” on
page 11.)
A Press the Power button to turn on the product.
B Press the Function
button repeatedly to select the BT function. After a moment, you will see “READY
on the status display.
C Tap the Settings
button on your smartphone and select Bluetooth. Turn on the Bluetooth function. (
Off > On)
D From the list of smartphone devices, find and tap on “LG-RNC2.
E Once the smartphone is connected to the product via Bluetooth, you can see the status display change from
PAIRED[BT. Play a desired track in the music app on your smartphone.
background
4
Table of Contents
HIGH POWER SPEAKER SYSTEM
Quick Guide
2 Connecting and Using the Speaker
Exploring the Product
5 Top
7 Front / Rear
8 Exploring Remote Control
Connecting to Bluetooth
11 Connecting Smartphone to the Speaker via
Bluetooth
Connecting to USB
14 Connecting the product to a USB storage
device
Sound adjustment
16 Setting the sound mode
Additional Function
17 Auto power down
Safety Precautions
18 Safety and Regulatory
20 Prevention of product misuse
Things to Check before Reporting
Malfunction
24 Troubleshooting
Appendix
26 Product Specifications
27 Registered Trademarks and Licenses
28 Handling the Product
background
5
Exploring the Product
Top
a dc
e f
b
MIC
VOL
MIC
VOL
MIC
ECHO
MIC
ECHO
BASS
EQ
VOL
a
Power
It turns on/off the product.
b
USB port
Plug in a USB storage device to enjoy music with the product.
c
Status display
Options such as input mode and volume are displayed in text.
d
Function
Press the button repeatedly to select the desired input mode or function.
• BT : It connects the product via Bluetooth.
• USB : It connects the product to a USB storage device.
• Press and hold the Function
button for 2 seconds or longer and connect the Bluetooth device. ([
See “Connecting Smartphone to the Speaker via Bluetooth” on page 11.)
Exploring the Product
background
6
e
MIC VOL (Microphone Volume)
When you connect your microphone to the MIC jack, you can adjust an microphone volume.
Range: 0(MIN) to 15(MAX)
MIC ECHO (Microphone Echo)
When you connect your microphone to the MIC jack, you can adjust an echo effect to the sound from the
microphones.
Range: 0(MIN) to 9(MAX)
BASS
You can adjust the bass sound level as your preference. Adjust the bass sound level.
Range: -5(MIN) to +5(MAX)
EQ
Chooses sound impressions.
f
Lighting
Press the button repeatedly to select the desired Woofer lighting.
You can customise the Woofer Lighting mode as you want by pressing the button repeatedly.
• Lighting Mode: Party / Water / Forest / Off
Skip/Search
• Moving to the next music: Press the button once.
• Moving to the previous music: Press the
button twice quickly.
• While playing a file on a USB storage device, press and hold the
button. The search begins. At this
time, if you release your hand from the desired part, it will play from that part.
Stop
Stops playback.
VOL (Volume)
It controls the volume level.
Range: 0(MIN) to 40(MAX)
Play/Pause
Starts or pauses playback.
> CAUTION
• Place the speaker at a safe distance from the child’s reach. Otherwise it may result in the speaker falling down
and causing personal injury and/or property damage.
• Be careful that the speaker does not fall down. Otherwise it may result in the speaker malfunctioning and
causing personal injury and/ or property damage.
background
7
Front / Rear
a
b
c
a
Remote sensor
This receives wireless signals from the remote control.
b
Woofer Lighting
Enjoy a colourful light show to the beat of the music.
c
MIC (Microphone) 1/2
Connect a microphone.
> CAUTION
• Be careful not to expose the product to sunlight for a long time to prevent discolouration.
• It is not good for the eyes to see the lens while the LED is running, do not see it directly.
• If a microphone is not connected, “INSERT MIC” appears in the display window.
background
8
Exploring Remote Control
You can use the remote to control all functions of the product, from turning the power on/off to enabling
cinematic sound.
a
b
c
Replacement of Battery
(R03)
(R03)
Use AAA 1.5V batteries. Replace the two batteries by inserting them into the remote control in accordance with
the directions indicated.
A Open the battery cover on the back of the remote control.
B Insert the batteries with the + and ends corresponding to the markings.
C Close the battery cover.
Risk of fire or explosion if the battery is replaced by an incorrect type.
background
9
a
Power
It turns on/off the product.
Mute
Mutes the sound. To cancel it, press on the remote control again or change the volume level.
VOL (Volume)
It controls the volume level.
Range: 0(MIN) to 40(MAX)
Function
Press the button repeatedly to select the desired input mode or function.
• BT : It connects the product via Bluetooth.
• USB : It connects the product to a USB storage device.
• Press and hold the Function
button for 2 seconds or longer and connect the Bluetooth device. ([
See “Connecting Smartphone to the Speaker via Bluetooth” on page 11.)
Lighting
Press the button to select the Woofer lighting.
BASS
You can adjust the bass sound level as your preference. Adjust the bass sound level.
Range: -5(MIN) to +5(MAX)
PARTY
PAR T Y
Selects PARTY lighting mode.
WATER
WATER
Selects WATER lighting mode.
FOREST
FOREST
Selects FOREST lighting mode.
background
10
b
EQ
EQ
Chooses sound impressions.
Skip/Search
• Moving to the next music: Press the button once.
• Moving to the previous music: Press the
button twice quickly.
• While playing a file on a USB storage device, press and hold the
button. The search begins. At this
time, if you release your hand from the desired part, it will play from that part.
Play/Pause
Starts or pauses playback.
Stop
Stops playback.
c
MIC (Microphone)
When you connect your microphone to the MIC jack, you can adjust an microphone volume.
Range: 0(MIN) to 15(MAX)
REPEAT
In USB mode, listens to your files repeatedly or randomly.
In USB mode, press the button on the remote control repeatedly. Repeat/Random playback operates as
follows.
• OFF : Plays songs in order and stops the playback.
• ONE
: Plays a same song repeatedly.
• ALL
: Plays all the songs on repeatedly.
• RANDOM
: Plays all the songs randomly and repeatedly.
This button is not available.
ECHO
When you connect your microphone to the MIC jack, you can adjust an echo effect to the sound from the
microphones.
Range: 0(MIN) to 9(MAX)
background
11
Connecting to Bluetooth
Connecting Smartphone to the Speaker via Bluetooth
You can play music files stored on a Bluetooth device, or run music apps to enjoy the music with this product.
Please check the following first.
• The following are the Bluetooth specifications of the product.
- Bluetooth version: 4.2
- Codec: SBC
• How to connect the device to the product may differ depending on the type and model of the
Bluetooth device. For information on how to connect the product, refer to the user manual of the
Bluetooth device to be connected.
Select the [Bluetooth] menu on the smartphone's Settings screen.
The menu access method may differ depending on the smartphone manufacturer and model.
a Press the Power
button of the speaker and turn it on. Press the Function button repeatedly to select
the BT function. After a moment, you will see “READY” appears on the status display.
MIC
VOL
MIC
VOL
MIC
ECHO
MIC
ECHO
BASS
EQ
VOL
READY
b Tap the Setting ( / ) button on your smartphone and select Bluetooth.
(Android Phone)
Connecting to Bluetooth
background
12
(iPhone)
c Turn on the Bluetooth function. ( Off > On)
d You will see a list of connectable devices on the smartphone screen. Find and tap the name “LG-RNC2”.
LG-RNC2
Bluetooth devices
LG Smart Phone
Bluetooth devices
AVAILABLE DEVICES
Bluetooth
LG-RNC2
Bluetooth devices
Bluetooth devices
On
AVAILABLE DEVICES
e When the speaker is connected to the smartphone via Bluetooth, you will see the status display change
from “PAIRED”(Connected) [BT” (Ready to use).
f If "LG-RNC2" does not appear on the list, tap on the Refresh
icon on an Android phone or restart
Bluetooth on an iPhone.
(Android Phone)
Not Connected
LG Speaeker1
Not Connected
Not Connected
Not Connected
Settings
LG Speaeker2
LG Speaeker3
LG Speaeker4
MY DEVICES
Now discoverable as “iPhone”
Bluetooth
Bluetooth
(iPhone)
background
13
g Select and play a track on the smartphone.
Note
• The closer the Bluetooth device is to the speaker, the better connection you will get.
• If the Bluetooth device is not connected, “READY” appears on the display window. Connect the product again.
• When using Bluetooth, adjust the volume of the Bluetooth device to an appropriate level.
• When entering the BT function, this unit automatically connects to the last connected Bluetooth device or
the device which played back last. (Auto connection may not be supported depending on the connected device
specifications.)
background
14
Connecting to USB
Connecting the product to a USB storage device
You can enjoy sound by connecting a USB storage device with music files to the speaker.
a Plug the USB storage into the USB terminal of the speaker.
• The speaker cannot play any devices connected with a USB storage device hub or a USB storage device cable.
• The speaker cannot be connected to a USB storage device, USB type MP3 player or card reader that requires
a separate device drive to be installed.
MIC
VOL
MIC
VOL
MIC
ECHO
MIC
ECHO
BASS
EQ
VOL
b Press the Power button to the turn on the speaker.
c Press the Function
button repeatedly until “USB” appears on the status display.
MIC
VOL
MIC
VOL
MIC
ECHO
MIC
ECHO
BASS
EQ
VOL
USB
d Press the Play/Pause button to enjoy the music.
Connecting to USB
background
15
Note
• USB devices with large storage volume can take several minutes or more to browse files.
• LG Electronics is not responsible for any data loss. Please always back up the data to minimise damage caused
by data loss.
• Only FAT16/FAT32 formats are supported. exFAT/NTFS format is not supported.
• Use the USB port of this product only for playing a media file. You cannot charge external devices with the USB
port.
USB storage devices supported
• USB flash device
• USB 2.0 or USB 1.1
This product may not recognise some USB storage devices.
Playable file specifications
File extension Sampling frequency / Bitrate
MP3 32 kHz - 48 kHz / 32 kbps - 320 kbps
• Number of playable files: 999 or less
• Maximum number of directories: 99 or less
• The product cannot play the files protected by DRM (Digital Rights Management).
• The product cannot play video files in a USB storage device.
background
16
Sound adjustment
Setting the sound mode
This system has a number of pre-set equalizers. The displayed items for the equalizer may be different depending
on sound sources and effects.
You can select a desired sound mode by using EQ
EQ
.
On Display Description
BASS (BASS BLAST)
or
BASS+ (BASS BLAST+)
Reinforces the bass and powerful sound.
STANDARD You can enjoy optimised sound.
Sound adjustment
background
17
Additional Function
Auto power down
This unit will turn itself off to save electricity in the case were the unit is not connected to an external device and
is not used for 15 minutes.
Additional Function
background
18
Safety Precautions
Safety and Regulatory
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK) NO USER-
SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This lightning flash with arrowhead symbol within an equilateral triangle is intended to
alert the user to the presence of uninsulated dangerous voltage within the product’s
enclosure that may be of sufficient magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the literature
accompanying the product.
WARNING:
• TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
• Do not install this equipment in a confined space such as a book case or similar unit.
CAUTION:
• Do not use high voltage products around this product. (ex. Electrical swatter) This product may malfunction due
to electrical shock.
• No naked flame sources, such as lighted candles, should be placed on the apparatus.
• Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Slots and
openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to
protect it from over heating. The openings should never be blocked by placing the product on a bed, sofa, rug or
other similar surface. This product shall not be placed in a built-in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s instruction has been adhered to.
• The apparatus should not be exposed to water (dripping or splashing) and no objects filled with liquids, such as
vases, should be placed on the apparatus.
• For safety marking information including product identification and supply ratings, please refer to the main
label on the bottom or the other surface of the product.
• Be careful to make sure children do not put their hands or any objects into the *speaker duct.
- * speaker duct: A hole for plentiful bass sound on speaker cabinet. (enclosure)
Safety Precautions
background
19
CAUTION concerning the Power Cord
The Power Plug is the disconnecting device. In case of an emergency, the Power Plug must remain readily
accessible.
Check the specification page of this owner’s manual to be certain of the current requirements.
Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords, frayed power
cords, or damaged or cracked wire insulation are dangerous. Any of these conditions could result in electric shock
or fire. Periodically examine the cord of your device, and if its appearance indicates damage or deterioration, unplug
it, discontinue use of the device, and have the cord replaced with an exact replacement part by an authorised
service centre.
Protect the power cord from physical or mechanical abuse, such as being twisted, kinked, pinched, closed in a door,
or walked upon. Pay particular attention to plugs, wall outlets, and the point where the cord exits the device.
For models using a battery
This device is equipped with a portable battery or accumulator.
CAUTION: Risk of fire or explosion if the battery is replaced by an incorrect type.
For models using a built-in battery
Do not store or transport at pressures lower than 11.6 kPa and at above 15,000 m altitude.
• replacement of a battery with an incorrect type that can defeat a safeguard (for example, in the case of some
lithium battery types);
• disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery, that can result in
an explosion;
• leaving a battery in an extremely high temperature surrounding environment that can result in an explosion or
the leakage of flammable liquid or gas; and
• a battery subjected to extremely low air pressure that may result in an explosion or the leakage of flammable
liquid or gas.
Symbols
: Alternating current (AC).
0 : Direct current (DC).
: This is a class II equipment.
1 : Standby power state.
! : The power is turned on.
: Danger voltage.
background
20
Prevention of product misuse
To prevent misuse of the product, please be sure to check the contents below.
Precautions for installing the product
• Do not install the product in an unstable or vibrating place, such as on a shaking shelf or inclined surface. Install
the product on a firm and level surface.
- Otherwise, the product may fall or tip over and cause injury.
- If you install the product on an unstable surface, the product may not work properly.
• If you install the product on a piece of furniture or shelf, make sure that the bottom front of the product does
not protrude. Always use a piece of furniture or shelf that fits the product size.
- Otherwise, the product may lose its balance and fall, causing injury or product damage.
• Install the product in a safe place. Otherwise, a child may bump into an edge of the product and get injured.
• Install the product in a place free from electromagnetic interference for proper operation.
• If you install the product in a place that does not meet the general use conditions, an unexpected quality
problem may arise. So, make sure that you contact the service centre first before installing the product in such
a place.
• Do not keep the product in a place where the temperature is too high (above 35 °C) or too low (below 5 °C) or
a place with too much humidity.
• Avoid places exposed to direct sunlight or heat, e.g., near a heater. Do not use or keep flammable sprays or
substances near the product.
- Otherwise, there is a risk of explosion or fire.
• Do not install the product in a place with too much moisture, dust or soot.
- Otherwise, it may cause a fire or electric shock.
• Do not install the product in a narrow space, such as inside a bookshelf, that does not ventilate well. Do not
cover the product with a table cover or curtain.
- Otherwise, it may increase the product temperature, causing a breakdown or fire.
• Connect the power plug of the product to a power outlet that is easily accessible.
- When a fire or other problem occurs in the product, you must be able to remove the power plug quickly.
• Do not connect multiple products to one power outlet at the same time.
- Otherwise, it may cause overheating, resulting in a fire.
background
21
Precautions for using the product
• Do not lift or move the product while it is operating.
- Otherwise, it may cause a breakdown.
• When moving the product, pull out the power cord and all cables connected to the product.
- Otherwise, it may cause a fire or electric shock.
• Stop using the product immediately if you notice smoke or a strange odor. In this case, turn off the power
immediately, disconnect the power plug, and contact the service centre.
- Using the product in this state may result in a fire or electric shock.
• Do not insert metal objects such as coins and hairpins or flammable objects such as paper and matchsticks into
the product. Make sure that you tell any children not to do so.
- Otherwise, it may cause a breakdown.
• If a foreign substance is inserted into the product, disconnect the power plug and contact the service centre.
• Do not put a heavy object on top of the product.
- Otherwise, it may tip over or fall, causing injury.
• Make sure that a child does not hang on the product or get on it.
- Otherwise, the product may tip over or fall, causing injury. Make sure that you tell any children not to do so.
• Remove the power plug during thunderstorms.
- Otherwise, it may cause a fire.
• Do not place vessels with liquid, such as a vase, pot, cosmetics, or medicine, on top of the product.
- Otherwise, it may result in a fire, electric shock, or injury due to its fall, etc.
• Make sure that you connect the power plug firmly. Do not use voltage other than the rated voltage indicated on
the product.
- An insecure connection may result in a fire.
• Do not insert a conductor, such as chopsticks, into the groove on the other side of the product while the power
plug is connected to an outlet. Do not touch the power plug immediately after unplugging it from the outlet.
- Otherwise, it may cause electric shock.
• Hold the power plug with dry hands.
- Otherwise, it may cause electric shock.
• Do not move or push the product while holding a product cable such as a power cord.
- The cable may get damaged and cause a breakdown or result in a fire or electric shock.
• When removing a cable plugged into the product, make sure that you hold the connector at the end of the
cable. Do not hold the cable line.
- Otherwise, it may result in an injury or the product may fall and cause a breakdown.
• Do not keep the product in a place exposed to heat, e.g., near a heater.
- Otherwise, it may cause a fire or malfunction.
• Do not disassemble, repair, or modify the product.
- Otherwise, it may cause a breakdown, resulting in a fire, electric shock, or injury.
• Keep plastic wraps out of reach of toddlers.
- Otherwise, toddlers may choke on the plastic wraps.
• Do not drop an object on the product or make an impact on it. Keep the product away from places with severe
vibrations or magnets.
• Do not damage, modify, bend, twist, or heat a power cord.
- Otherwise, it can damage the power cord, resulting in a fire or electric shock.
background
22
• When you are not using the product for a prolonged period, such as when you are away from home, unplug the
power cord from the power outlet.
- If dust accumulates, it can cause heat, resulting in electric shock or fire due to a short circuit.
• Do not dispose of waste batteries together with regular waste. Dispose of them separately.
- Otherwise, there is a risk of explosion or fire.
• Do not use high voltage products around this product. (ex. Electrical swatter)
- This product may malfunction due to electrical shock.
• Do not touch the power plug immediately after unplugging it from the outlet.
- Otherwise, it may cause electric shock.
• Connect the power plug to a grounded outlet or extension cord. (This does not apply to products without a
ground.)
- Otherwise, it may cause a breakdown or electric shock due to a short circuit.
• In the case of a product with a vent, keeping the product turned on for a prolonged period can result in the vent
getting hot. Do not touch the vent when it is hot. The heat is not a fault of the product and does not cause any
malfunction. So, you may use the product without worry.
• Do not damage the power cable, AC adapter, or power plug. Do not place a heavy object on top of the power
cable or AC adapter.
- Otherwise, it may cause a fire or electric shock.
• If dust, dirt, etc. is found on the power plug pins, an AC adapter, or a power outlet, wipe it completely.
- Otherwise, it may cause a fire.
• In the case of a product with a power cord or AC adapter, use only genuine power cords and AC adapters
provided by LG Electronics.
- Otherwise, it may cause a fire or electric shock.
• If you are using headphones or earphones, do not turn on the volume too loudly or use them for a prolonged
period. [This only applies to models that support headphones or earphones]
- Otherwise, it may negatively affect your hearing ability.
background
23
The following only applies to models with a remote control
• Do not let children use the remote control. Keep the remote control out of reach of toddlers.
• Do not let children put the remote control in their mouth. Make sure that children don’t swallow the remote
control cover or a battery. If a child swallowed one, consult a physician immediately.
• Beware that children may step on the remote control cover and get injured.
• Remove obstacles between the product and the remote control for the smooth operation of the remote
control.
The following only applies to models that use optical discs
• Do not insert your hand into a disc drive or pull it out forcefully.
• Make sure that children do not insert their hands into the disc drive.
The following only applies to models that able to watch video
• Refrain from watching a 3D video if you didn't have enough sleep or after drinking alcohol.
- Some 3D videos may surprise or excite people.
• If any of the following symptoms occur while watching a video, stop watching it immediately and take a rest.
- If any of the symptoms continue, consult a physician. Vertigo, burning sensation of eyes or face, unconscious
motion, spasm, clouded consciousness, confusion, disorientation, nausea.
• You may suffer a symptom such as a seizure when you watch a certain image in a video or game or a video with
a certain pattern or flashing lights. If you or any of your relatives have a history of epilepsy or seizures, consult a
physician before watching.
• When you watch a 3D video, remove objects that are fragile or can cause injury from your surroundings.
- If you mistake a 3D video as real or move your body with surprise, you or your nearby relatives may get
injured or objects near you may get damaged.
Precautions for cleaning the product
• Do not spray water directly onto the product when cleaning it.
- Otherwise, it may cause a fire or electric shock.
• When cleaning the product, make sure that you pull out the power cord first and wipe the surface of the
product lightly with a dry cloth. Do not use chemicals or detergents when cleaning the product. They may
deteriorate the product surface or peel off the paint from the product (benzene, alcohol, etc.).
background
24
Things to Check before Reporting
Malfunction
Troubleshooting
If you experience the following symptoms while using the product, please check them again. They may not be
malfunctions.
Symptom Cause and Solution
Power is not
supplied.
• Plug the power cord into the wall outlet securely.
• Check whether electricity failed.
• Check the condition by operating electronic devices using the same AC outlet
There is no
sound or
the sound is
distorted.
• The volume of product or the connected Bluetooth device may be set to the
minimum. Adjust the volume of product or the connected Bluetooth device to the
appropriate level.
• Using an external device with the maximised sound may distort the sound. Lower the
volume of the external device to use.
• Is the mute function activated?
- If “MUTE” appears on the status display, the mute function is on. Press the Mute
button on the remote control to unmute.
The USB
storage
device is not
recognised.
• The product may not support the file system of the USB storage device. Format the
USB storage device and reconnect it. When formatting, check the supported USB
storage device format available on the product and select an appropriate file system.
([ See “Connecting the product to a USB storage device” on page 14.)
Bluetooth
connection
failed.
• Check if the Bluetooth setting is enabled.
• Turn off the Bluetooth setting and on again on the Bluetooth device.
• Make sure there are no obstacles between product and the Bluetooth device.
• Bluetooth pairing (connecting) may fail depending on the Bluetooth device type and
the surrounding environment.
Things to Check before Reporting Malfunction
background
25
The product
does not
operate
normally.
• Please beware that previous product settings may be lost.
The remote
control does not
work properly.
• When using the remote control, point it at the front of the product.
• Use the remote control within a 7-m radius of the product.
• Replace the batteries with new ones as needed.
background
26
Appendix
Product Specifications
General
Power requirements Refer to the main label.
Power consumption Refer to the main label.
Dimensions (W x H x D) Approx. 300 mm x 390 mm x 320 mm
Operating Temperature 5 °C - 35 °C
Operating Humidity 5 % - 80 % RH
Input
USB
5 V 0 500 mA
Microphone (MIC 1/2) Sensitivity 20 mV (1 kHz), 6.3 mm jack x 2
• Design and specifications are subject to change without notice.
Appendix
background
27
Registered Trademarks and Licenses
All trademarks and trade names are owned by their respective owners.
The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of
such marks by LG Electronics is under license.
Other trademarks and trade names are those of their respective owners.
background
28
Handling the Product
When shipping the Product
Please save the original shipping carton and packing materials. If you need to ship the product, for maximum
protection, re-pack the product as it was originally packed at the factory.
Keeping the exterior surfaces clean
• Do not use volatile liquids such as insecticide spray near the product.
• Wiping with strong pressure may damage the surface.
• Do not leave rubber or plastic products in contact with the product for a long period of time.
Cleaning the product
To clean the product, use a soft, dry cloth. If the surfaces are extremely dirty, use a soft cloth lightly moistened
with a mild detergent solution. Do not use strong solvents such as alcohol, benzine, or thinner, as these might
damage the surface of the product.
background

Specifications

LG Electronics RNC2 Questions and Answers
