Steam Station Iron
Model No. SDA1589
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
2
Steam Station Iron
Model No. SDA1589
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions
should always be followed.
Only use the product as described in this user manual. Any other
use is considered improper and may result in damage to
property or persons.
The manufacturer or vendor cannot be held liable for damages
or injury incurred through improper or incorrect use.
• Read and familiarise yourself with all operating
instructions before using this Steam Station Iron.
• Before plugging your steam station iron into the mains,
visually check that the steam iron is intact and has not
suffered any transit damage.
• Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
• Close supervision is required when using this appliance
near children.
• Never leave this appliance within reach of children.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory
and mental capabilities or lack of experience or
knowledge if they have been given supervision or
instruction concerning use if the appliance in a safe way
and understand the hazards involved.
• Children shall not play with the appliance.
• Cleaning and user maintenance shall not be made by
3
Steam Station Iron
Model No. SDA1589
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
children unless they are older than 8 and supervised.
• Keep the appliance and its cord out of reach of children
aged less than 8 years.
• DO NOT leave the appliance unattended during use.
• DO NOT leave the appliance unattended whilst
connected to the mains supply.
• Always use this appliance on a solid, level, non-
flammable surface.
• DO NOT use this appliance outdoors.
• It is imperative to unplug the power cord after the
appliance has been used, before it is cleaned and whilst
being repaired.
• If the power cable is damaged, it should only be replaced
by suitable qualified personnel in order to avoid a hazard.
• Repairs to electrical appliances should only be performed
by qualified personnel. Improper repairs may place user
at serious risk.
• DO NOT operate this appliance with a damaged plug or
cord, after a malfunction or after being dropped or
damaged in any way.
• Regular, periodic checks should be carried out on the
mains cable to ensure no damage is evident. Should there
be any signs of damage the appliance should not be used.
• DO NOT allow the mains cable to hang over sharp edges
or come in contact with hot surfaces.
• DO NOT run the mains cable under carpets, rugs, etc.
• Allow the unit to cool before storage.
• Never place the appliance near to flammable material or
high pressure containers.
• This appliance is intended for household use only and
should not be used for industrial purposes.
• DO NOT use any accessories or attachments with this
appliance other than those supplied or recommended by
supplier.
• DO NOT immerse the appliance, base or its cord in water
4
Steam Station Iron
Model No. SDA1589
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
or any other liquids.
• DO NOT use this appliance for anything other than its
intended use.
• DO NOT push objects into any openings as damage to the
appliance and/or electric shock may occur.
• Ensure appliance is situated in an open area, do not allow
it to come in contact with or place beneath cupboards,
curtains, wall coverings, clothing or other flammable
materials.
• Unplug after each use. Grasp the plug, not the cord.
• DO NOT cover this appliance.
• CAUTION: The soleplate of the steam iron will get
hot during use.
THIS APPLIANCE MUST BE EARTHED
5
Steam Station Iron
Model No. SDA1589
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
You should now recycle your waste electrical goods and in
doing so help the environment. This symbol means waste
electrical products at the end of their useful life should not be
disposed of with normal household waste and not sent to
landfill. Please ensure it is taken to a suitable facility for
disposal. Check with your Local Authority or retailer for
recycling advice or visit www.recycle-more.co.uk, enter your
postcode to find out your nearest recycling site.
This symbol provides useful additional information on the
use of this product.
This symbol indicates that the supply uses an alternating current
mains supply.
This symbol indicates that the surface gets hot and care must be
taken
Before the First Use of Your Steam Station Iron
1. Remove all packing materials, including the plastic protective cover from the
soleplate and discard responsibly.
2. Ensure all parts are present (if applicable) see Description of Parts below.
3. Wipe the soleplate of the steam iron using a soft, clean damp cloth and dry
thoroughly.
4. DO NOT Immerse the steam station iron in water or any other liquid.
This designates a hazard with moderate risk, which may result
in severe injury if not adhered to.
6
Steam Station Iron
Model No. SDA1589
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Whilst using for the first time, a little smoke or odour may be emitted, this is
normal and will soon pass.
Description of Parts
To keep the base smooth and scratch free do not run the iron over metal
objects such as zips, buttons etc.
Dry Ironing
1. Place the Steam Station Base Unit (1) on a solid level, heat resistant surface at
a comfortable height for the user.
2. Refer to the ironing instructions on the garment to be ironed.
3. If the garment doesn’t have any ironing instructions but you know the type of
fabric used in the garment, use the chart below.
4. Fabrics with special finishes such as polishing, pleats etc. should be ironed at
the lowest temperature setting.
5. With mixed fibres always select the lowest applicable temperature.
6. Group items with similar fibres together, as the iron heats up faster than it
cools, start ironing items requiring the lowest temperature first.
7. Turn the Temperature Control (5) to the required setting according to the
guide below:
2
3
4
1
1. Water Tank/Base Unit
2. Base Unit Lock
3. Heating Indicator
4. Manual Steam Control
5. Temperature Control
6. Handle
7. Mains Cable/Water
Monotube
5
6
7
●Position for Nylon/Silk/Synthetics (Low temperature)
●●Position for Wool, Silk or mixtures (Medium temperature)
●●●Position for Cotton or Linen (Steam & High temperature)
7
Steam Station Iron
Model No. SDA1589
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
8. Insert the mains plug into the nearest socket, the
Heating Indicator (3) will illuminate showing the iron is
warming up. Once the Heating Indicator (3) goes out,
the iron is ready for ironing.
The Heating Indicator (3) will go on and off during
use, this is quite normal.
Steam Ironing
1. Do not insert the mains plug into the mains socket at
this stage.
2. Place the Steam Station Base Unit (1) on a solid, level
heat resistant surface at a comfortable height for the
user.
3. Fill the Water Tank (1) with cold water to the MAX
level.
4. Set the Temperature Control (5) to the MAX setting.
5. Insert the mains plug into the nearest socket, the
Heating Indicator (3) will illuminate showing the iron
is warming up. Once the Heating Indicator (3) goes
out, the iron is ready for steam ironing.
6. For continuous steam, press the Manual Steam Control (4) which will
continuously release steam through the soleplate.
If you live in a hard water area it is advised to use only distilled or
demineralised water to reduce Limescale build up and maintain the
performance of the steam station and extend the lifetime of the unit.
To remove limescale deposits use a 75% water 25% vinegar solution.
Do not store the iron with water in the water tank.
WARNING! Do not use chemically de-limed or perfumed water.
Care and Maintenance
• Before carrying out any cleaning or maintenance, ensure that the steam station
iron is unplugged from the mains power supply and has fully cooled.
• Wipe the soleplate with a soft damp cloth and dry thoroughly, after pouring off
any remaining water. The body of the iron can also be wiped down with a soft
damp cloth, do not use harsh or abrasive cleaning products.
8
Steam Station Iron
Model No. SDA1589
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Technical Data
Model No.
SDA1589
Rated Voltage
220-240V AC 50-60Hz
Rated Power
2200-2400W
Protection Class
I (This Appliance must be Earthed)
Disposal of the packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken to
a suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk, enter
your postcode to find out your nearest recycling site.
Troubleshooting Guide
Problem
Possible Cause
Possible Fix
Unit not powering up.
Mains plug not in socket
Check that the mains plug is
inserted into the socket and is
switched on.
Temperature Control is
not set to the correct
setting.
Rotate the Temperature Control
clockwise to the required heat
setting.
Fuse has blown in the
mains plug.
Check by substitution.
Unit does not steam.
The water reservoir may
be empty.
Unplug the iron and fill as per the
instructions.
White substance is
appearing around
spray outlet and
soleplate.
Calcium deposits.
Use distilled or demineralised water
9
Steam Station Iron
Model No. SDA1589
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
10
Steam Station Iron
Model No. SDA1589
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under license by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
