1
Owner’s Manual
PRODUCT REGISTRATION
Register your product today for a
chance to win an ISOBAR
®
surge
protector in our monthly drawing!
Tripplite.Eaton.com/warranty
Purchased product
may differ from image.
Model:
DMSW1332STAA
Slat Wall Monitor Arm
CAUTION: DO NOT EXCEED MAXIMUM
LISTED WEIGHT CAPACITY. SERIOUS
INJURY OR PROPERTY DAMAGE MAY
OCCUR!
Maximum Load: Maximum Load:
10 kg (22 lb.)10 kg (22 lb.)
2
Safety Instructions
Warranty and Product Registration
WARNING
• Do not begin the installation until you have read and understood the instructions and warnings contained in this
manual. If you have any questions regarding any of the instructions or warnings, please visit
Tripplite.Eaton.com/support.
• ThismountwasdesignedtobeinstalledandutilizedONLYasspeciedinthismanual.Improperinstallationof
this product may cause damage or serious injury.
• This product should only be installed by someone of good mechanical ability, with basic building experience and a
full understanding of this instruction manual.
• Make sure the unit can safely support the combined load of the equipment and all attached hardware and
components.
• Always use an assistant or mechanical lifting equipment to safely lift and position equipment.
• This product is intended for indoor use only. Using this product outdoors could lead to product failure and
personal injury.
NOTE: Read the entire instruction manual before you start assembly and installation.
5-Year Limited Warranty
We warrant our products to be free from defects in materials and workmanship for a period of five (5) years from the date of initial
purchase. Our obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. Visit
Tripplite.Eaton.com/support/product-returns before sending any equipment back for repair. This warranty does not apply to
equipment which has been damaged by accident, negligence or misapplication or has been altered or modified in any way.
EXCEPT AS PROVIDED HEREIN, WE MAKE NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE. Some states do not permit limitation or exclusion of implied warranties; therefore, the
aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL WE BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, we
are not liable for any costs, such as lost profits or revenue, loss of equipment, loss of use of equipment, loss of software, loss of data,
costs of substitutes, claims by third parties, or otherwise.
Product Registration
Visit Tripplite.Eaton.com/warranty today to register your new product. You’ll be automatically entered into a drawing for a chance to
win a FREE Eaton Tripp Lite series product!*
* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.
Eaton has a policy of continuous improvement. Specifications are subject to change without notice.
3
Component Checklist
Assembly
IMPORTANT: Ensure you have received all parts according to the component checklist prior to installing. If
any parts are missing or faulty, visit Tripplite.Eaton.com/support for service.
A
x 1 M4x10
B
x 4
C
x 1
11
4
Eaton
1000 Eaton Boulevard
Cleveland, OH 44122
United States
Eaton.com
© 2024 Eaton
All Rights Reserved
Publication No. 23-12-027 / 93-4988_RevA
January 2024
Eaton is a registered trademark.
All trademarks are property
of their respective owners.
Assembly
Maintenance
• Check that the bracket is secure and safe to use at regular intervals (at least every three months).
• Please visit Tripplite.Eaton.com/support if you have any questions.
22
33
B
Note: Choose the appropriate screws,
washers and spacers (if needed) according
to the type of screen.
CAUTION:
Do not over-tighten screws.
Adjust torque if needed
using the included hex
wrench
C
.
100
LCD
75
C
