When using electrical appliances, basic safety precautions should
always be followed. These instructions should be saved for future
reference:
• Read and familiarise yourself with all operating instructions before
using this Kettle.
• Before plugging your kettle into the mains, visually check that the
kettle is intact and has not suered any transit damage.
• Check that the voltage indicated on the data plate corresponds with
that of the local network before connecting the appliance to the mains
power supply.
• Do not immerse the appliance, base or its cord in water or any other
liquids.
• Close supervision is required when using this appliance near children.
• Never leave this appliance within reach of children.
• This appliance can be used by children aged from 8 years
and above if they have been given supervision or instruction
concerning use of the appliance in a safe way and if they understand
the hazards involved. Cleaning and user maintenance shall not be
made by children unless they are older than 8 and supervised. Keep
the appliance and its cord out of the reach of children aged less
than 8 years.
• Appliances can be used by persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved.
• Children shall not play with the appliance.
• Do not leave the appliance unattended during use.
• Do not leave the appliance unattended whilst connected to the mains
supply.
• Always use this appliance on a solid, level, non-ammable surface.
• Do not use this appliance outdoors.
• It is imperative to unplug the power cord after the appliance has been
used, before it is cleaned and whilst being repaired.
Important Safeguards
Kensington 3kW Kettle
SDA1685
User Manual
• If the supply cord is damaged, it must be replaced by the
manufacturer, service agent or similarly qualied person in order to
avoid a hazard.
• Do not operate this appliance after a malfunction or after being
dropped or damaged in any way.
• Do not allow the mains cable to hang over sharp edges or come in
contact with hot surfaces.
• Do not run the mains cable under carpets, rugs, etc.
• Allow the unit to cool before storage.
• Never place the appliance near to ammable material or high
pressure containers.
• This appliance is intended for household use only and should not be
used for industrial purposes.
• Do not use any accessories or attachments with this appliance other
than those supplied or recommended by the supplier – only use the
base provided with this kettle.
• Do not use this appliance for anything other than its intended use.
• Do not push objects into any openings as damage to the appliance
and/or electric shock may occur.
• Ensure appliance is situated in an open area, do not allow it to come
in contact with cupboards, curtains, wall coverings, clothing or other
ammable materials.
• Unplug after each use. Grasp the plug, not the cord.
• Do not cover this appliance.
• Never place this appliance on an electric, gas, or any other type of
hob.
• WARNING: Do not open the lid while the water is boing. Never ll
the kettle more than its capacity, if the kettle is overlled, boiling
water may be ejected – ensure the water level is between the min
and max marks.
• Always close the lid during use.
• CAUTION: The outside surface of the kettle will get hot during
use.
• Ensure the kettle is switched o before removing it from the base.
Kensington 3kW Kettle
SDA1685
User Manual
A. Spout
B. Filter (inside kettle)
C. Lid
D. Lid release button
E. Handle
F. On/O Switch
G. Base
H. Water level indicator
Description of parts
Before the rst time you use your kettle
B
C
E
D
A
F
G
• Please read these operating instructions thoroughly and keep
them in a safe place for future reference.
• Remove all packaging materials and discard responsibly.
• Before using the kettle for the rst time, ll to the max mark and
allow it to boil.
• Pour away the boiled water and then repeat the process. If a slight
taste or odour remains repeat the above process once more.
• Do not immerse the kettle or its base in water.
H
Kensington 3kW Kettle
SDA1685
User Manual
Instructions for use
• Place the kettle base on a at, level, non-ammable surface.
• Press the Lid Release button (D) and ll the kettle with water to
the desired level ensuring that it is above the MIN mark and below
the MAX mark.
• Replace the lid on the kettle by pushing it closed and place it onto
the base.
• Insert the mains plug (with dry hands) into the mains socket and
switch on if applicable.
• Push down the power on/o switch which will illuminate the Power
Indicator Light and the water will begin to boil.
• At the end of the boiling cycle the power on/o switch will
automatically switch o.
• Wait until the water has nished boiling before removing it from the
base unit.
• Ensure the lid is correctly closed before pouring boiling water –
beware of scalding.
Cleaning your kettle
• Do not clean your kettle in a dishwasher.
• Always disconnect the kettle from the mains power supply before
cleaning.
• Wipe clean the outside of the kettle with a soft damp cloth. Never
clean any part of the kettle with harsh or abrasive cleaners.
• Do not submerge any part of the base, mains cable or kettle in
water or any other liquids.
Decalcication of your kettle
• The frequency of the decalcication depends on the hardness of
the water in your area and how often the appliance is used
• If the kettle switches o before it boils or has a white deposit
building up inside then it probably needs to be decalcied.
Kensington 3kW Kettle
SDA1685
User Manual
Electrical Connections
This appliance is tted with a fused three-pin plug to BS 1363. If the plug
has to be removed, it should be cut o and carefully disposed of
immediately. To avoid a possible shock hazard, do not insert the
discarded plug into a mains socket.
Fitting a new plug
If for any reason you need to t a new plug, the exible mains lead must
be connected as shown below. The wires in the mains lead tted to this
appliance are coloured in accordance with the following code:
Connect Green &
Yellow to Earth (E)
Connect Blue to
Neutral (N)
Connect Brown to
Live (L)
Ensure the outer sheath of the mains lead
is securely held by the cable clamp
• The Blue wire must be connected to the terminal marked N or
coloured Black.
• The Brown wire must be connected to the terminal marked L or
coloured Red.
• The Green and Yellow wire must be connected to the terminal marked
E or coloured Green.
• Check that there are no cut or stray strands of wire inside the plug.
• Use a 13 Amp BS 1362 fuse, only use BSI or ASTA approved fuses.
• If you are in any way unsure which plug or fuse to use, always refer to
a qualied electrician.
• After replacing or changing a fuse on a moulded plug, the cover must
be retted to the plug; the appliance must not be used without a fuse
cover.
Kensington 3kW Kettle
SDA1685
User Manual
Technical Data
Voltage 220-240V AC 50/60Hz
Rated power 3000W
Capacity 1.7Litre
Model Number SDA1685
Customer Support
Should you require any product information,
replacement parts or accessories, please contact our
customer care team at [email protected] or
call 0161 831 7879.
• Replacement parts and accessories are guaranteed
for 1 year from the date of purchase.
• It is important to note that your warranty becomes
invalid should non Daewoo parts or accessories be used
with this appliance
Waste electrical products should not be disposed of with
household waste. Please recycle where facilities exist. Check with
your Local Authority or retailer for recycling advice.
Kensington 3kW Kettle
SDA1685
User Manual
Thank you for purchasing your Daewoo product.
As part of our commitment to quality we are offering you an extra 2 years warranty in addition to your
1 year guarantee.
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof of purchase or
receipt. If any defects should arise due to faulty workmanship or material, your faulty product should be returned
to the place of purchase, replacement or refund is at the discretion of the retailer.
The guarantee is subject to the following provisions:
• The product must be correctly installed and operated in accordance with the requirements contained
in the instruction manual.
• The product must be used solely for domestic purposes.
• It does not cover general wear and tear, damage, misuse or any consumable parts.
• The Guarantee is rendered invalid if the product has been resold or has been damaged through
inexpert repair.
• The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your individual product upon
registration. (Note: products must be registered individually and covers the main body and housing) If you do not
register your product within 28 days of the original purchase date, your product will only be guaranteed for 1
year.
To validate your extended 2 year warranty* please register your purchase online within 28 days of the original
purchase date by registering at
www.daewoowarrantyregistration.com/warranty-registration
*Your extended warranty is only valid with proof of purchase receipt and
subject to the conditions outlined above.
Daewoo® is a registered trademark.
Produced and imported under licence by ESG Ltd
ESG Ltd
Manchester M3 1JS
www.esgltd.com
WARRANTY
