5M 32A TYPE 2 TO TYPE 2 MODE 3 EV
CHARGING CABLE
MODEL NO: EVCC2232
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9 Follow these instructions to avoid the risk of death or serious injury.
8 DO NOT use this product on rainy days.
9 Make sure chargers are used in a safe, secure place and well out of the reach of young children or pets.
8 DO NOT damage the products maliciously
8 DO NOT drop the connector or press heavy objects on its surface.
8 DO NOT disassemble or assemble the connector and change the internal parts
8 DO NOT clean the products using chemicals.
8 DO NOT charge while driving.
9 Make sure the connector is fully inserted into the socket.
2. INTRODUCTION
The mode 3 charging cable simply plugs into any public or home EV charging point. Supplied with storage case.
3. SPECIFICATION
Model ................................................................ EVCC2232
Plug Type: ................................................. Type 2 to Type 2
Current: ......................................................................... 32A
Voltage: .......................................................................230V
Cable Length: ................................................................. 5m
Cable Specication: ............. EN50620 - 3*6mm²+2*0.5mm²
IP Rating: ...................................................................... IP54
4. OPERATION
4.1. Remove protective caps from plugs.
4.2. The cable must be plugged into the charging unit before plugging into the car.
4.3. Replace protective caps on plugs after use.
Refer to
instructions
Electrical shock
hazard
EVCC2232 Issue 1 05/06/2020
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
