80PK-26
SureGrip
TM
Tapered
Temperature Probe
Instruction Sheet
XWWarning
To avoid electrical shock, do not use this
probe when voltages exceeding 24 V ac rms
or 60 V dc are present. The probe tip is
electronically connected to the output
terminals.
Introduction
The 80PK-26 SureGrip
TM
Tapered Temperature Probe is
essentially a bead probe with a handle that can be used
as a surface probe. The stainless steel sheath allows the
bead to measure temperatures higher than bead probes
with flexible leads. The handle also allows you to apply
more focused surface pressure without having your hand
in close proximity to the source. The 40-inch (1-meter)
cable is terminated with a Type K miniature thermocouple
connector with 0.792-mm (.312-in) pin spacing. The
80PK-26 can be used with any temperature-measuring
instrument that is designed to accept Type K
thermocouples and has miniature connector input.
Specifications
Type
K Standard Grade Ni-Cr vs Ni-Al (Chromel vs Alumel)
Measurement Range
-40 °C to 816 °C (-40 °F to 1500 °F)
Accuracy
(With respect to ANSI MC96.1-1982-Standard Limits of
Error):
Note
All error calculations should be done in
°
C, then
scaled to
°
F.
Range
Accuracy
(% of reading)
-40 °C to 293 °C
(-40 °F to 559.4 °F)
±2.2 °C
293 °C to 816 °C
(559.4 °F to 1500 °F)
±0.75 %
November 2004 Rev.2, 9/09
© 2004-2009 Fluke Corporation. All rights reserved.
All product names are trademarks of their respective companies
