POWER TOOL STORAGE RACK - 2 BAY
MODEL NO: PTSR2
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure Health & Safety, and local authority regulations are adhered to when assembling and using this tool rack.
9 Locate tool rack in a suitable area where it will not be an obstruction.
9 Keep the general area clean, uncluttered and ensure there is adequate lighting.
WARNING! Mount tool rack on a at and solid wall such as breeze block that is strong enough to hold fully laden tool rack.
9 The tool rack should be rmly secured to the wall in a suitable location with xings provided.
8 DO NOT attempt to wall mount the tool rack on your own. Obtain assistance or use manual handling equipment.
9 Wall mount the tool rack at such a height that minimises the risk of injury when used.
9 Keep children and unauthorised persons away from the storage area.
8 DO NOT use the tool rack for any purpose other than that for which it is designed.
8 DO NOT site the tool rack out of doors.
8 DO NOT get the tool rack wet or use in damp or wet locations or areas where there is condensation.
8 DO NOT clean the tool rack with any solvents or abrasives which may damage the coated surface.
8 DO NOT overload the tool rack when wall mounted.
8 Ensure that the tool rack is properly and rmly assembled and installed before loading it.
2. INTRODUCTION
Wall mountable rack specically designed for the storage of power tools.
Stores up to two power tools. Shelf space for power tool battery and chargers.
Open fronted bays make tools easily accessible. Supplied at-packed.
3. SPECIFICATION
Model no .....................................................................PTSR2
Dimensions (W x D x H) .......................... 246 x 230 x 300mm
Power tool storage bays....................................................... 2
4. CONTENTS
1 Nut x9 2 Bolt x9 3 Self tapping screw x4 4 Drywall anchor x4
5. ASSEMBLY
Refer to
instruction
manual
PTSR2 Issue:1 05/02/21
Original Language Version
© Jack Sealey Limited
Wear protective
gloves
Attach the two side panels to the bottom shelf
using 2x nuts and 2x bolts per side.
Attach two side panels to the top shelf using
2x bolts per side. Note: the ange on the
top shelf should face downwards with the
centre hole on the side of the ange facing
forwards.
Position the support bar so the slot passes
through the tab on the bottom shelf with the
power toll slots. Secure the bar by lining up
the hole at the top of the support bar with the
corresponding hole on the top shelf.
The support bar should be positioned behind the
front edge of the top shelf. Secure using bolt and
nut.
6. INSTALLATION
6.1. Rack can be installed onto a peg board (using nuts and bolts) or a wall.
6.2. If installing into a wall, ensure wall (and xings) are able to support the weight
of the rack and any tools stored upon it.
6.3. Hold rack in place to mark and then pre-drill holes.
6.4. Use xings appropriate to the wall being used to x the rack to.
7. MAINTENANCE
7.1. Regularly check xings and mountings are rmly tted and that the rigidity and
security of the rack is not compromised.
7.2. Wipe clean with damp cloth.
8 DO NOT use chemical or abrasive cleaners as this may result in damage to the
surface.
.
Original Language Version
© Jack Sealey Limited
PTSR2 Issue:1 05/02/21
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
