BAUMR-AG LDRSCFBMRAA18 450kg Mobile Scaffold High Work User Manual

Height Adjustable

Mobile Scaffold

Safety

Maximum load capacity = 450kg (1000lbs). Never exceed the load capacity.

Electrocution / shock hazard - The equipment is electrically conductive. Do not use where the equipment or user

may contact live electrical circuits. Contacting live electrical circuits may cause serious injury or death.

Always lock the castors before using the scaffold. • Always ensure that all locking pins are fully engaged and the

retaining clips are in place. • Use the scaffold on flat and level surfaces only. Do NOT jack or adjust the scaffold to

suit uneven surfaces. • Do NOT attempt to stack scaffolds on top of one another. • Where possible, guard rails and

stabilizers should be used. • Always position the scaffold so that the work area can be reached without leaning or

hanging off the scaffold. • Manufactured to ANSI standards.

Parts Identification

Assembly

No.

Description

Qty

1 Horizontal Support Beam 2

2 Vertical Scaffold 2

3 Platform 1

4 Locking Pin 8

5 Castor 4

1. Attach the horizontal support beams to the vertical

scaffolds. Ensure that the beams are positioned at

the same height and that the spring-loaded pins are

fully engaged with the vertical scaffolds.

2. Insert the casters fully into the bottom ends of the

vertical scaffolds, then secure them with locking

pins. Ensure that the retaining clip for all locking pins

is in place.

3. Place the platform (wood side on top) on to the top

of the horizontal support beams, then secure it with

the spring-loaded clamps.

Usage Guide

To adjust platform height, pull and hold the spring-loaded pins for the horizontal support beams in the

unlocked position, then move the beams to the required height. Release the pins and ensure that they are

fully engaged with the vertical scaffolds and are at the same height.

Place the scaffold as close to the work area as possible, then lock all castors (step on the locking lever at

each castor). To unlock the castors, step on the smaller unlocking lever.

Use caution when mounting and dismounting the scaffold to prevent movement, tilting etc.

If any items or load is placed on the platform, attempt to spread it as evenly as possible to help prevent tilting

or unbalancing the scaffold.

[Revision 1.0 January 2017]

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Some experts believe that the incorrect or prolonged use of almost any product may

cause serious injury or death. To help reduce your risk of serious injury or death, refer

to the information below. For more information, see www.datastreamserver.com/safety



Consult all documentation, packaging and

product labelling before use. Note that

some products feature documentation

available online. It is recommended to print

and retain the documentation.



Before each use, check the product for

loose/broken/damaged/missing parts, wear

or leaks (if applicable). Never use a

product with

loose/broken/damaged/missing parts, wear

or leaks.



Products must be inspected and serviced

(if applicable) by a qualified technician

every 6 months. This is based on average

residential use by persons of average size

and strength, and on a property of average

metropolitan size. Use beyond these

recommendations may require more

frequent inspections/servicing.



Ensure that all users of the product have

completed a suitable industry recognised

training course before being allowed

access to the product.



The product has been supplied by a general merchandise

retailer that may not be familiar with your specific

application or description of application. Be sure to attain

third-party approval from a qualified specialist for your

application before use, regardless of any assurances from

the retailer or its representatives.



This product is not intended for use where fail-safe

operation is required. As with any product (for example,

automobile, computer, toaster), there is the possibility of

technical issues that may require the repair or replacement

of parts, or the product itself. If the possibility of such failure

and the associated time it may take to rectify could in any

way inconvenience the user, business or employee, or

financially affect the user, business or employee, then the

product is not suitable for your requirements. This product is

not intended for use where incorrect operation or a failure of

any kind, including but not limited to, a condition requiring

product return, replacement, parts replacement or service

by a technician may cause financial loss, loss of employee

time or an inconvenience requiring compensation.



If this product has been purchased in error when

considering the information presented here, contact the

retailer directly for details of their returns policy, if required.

ideas, diagrams or images may be reproduced or transmitted in any form or by any means, electronic or

mechanical, including photocopying, scanning or recording, or any information storage and retrieval system,

without express permission or consent from the publisher.
