Connect sensor
04 /
Basic parameter
Name
Humidifier
Model AHU-600Z1
Rated voltage
120V
Rated frequency
60Hz
Rated power
600W
Rated capacity
4.22 Quart
Rated humidification capacity
20.3 ounce/h
Dimension
10.6in X10.6in X 16.15in
Executive standard
05 /
Working principle
Our specialized pump
draws water through our filter
and over our
specialized heating element,
creat ing
purified
steam that is mixed with
cold air, introducing clean warm
humidity throughout the room .
Our unit has additional
technology such as the plasma generator for a 2
nd
level of air purification a s well as our room -humidity sensor that
tells you how dry the air is in the
room.
06 /
Product features
1.
Three
ways to fill with water : 1)
from the water injection port on the top
of the unit
2) by removing the top
and filling
3)
by
taking removable bucket to your water source.
2.
Room Humid ity sensor
with indicating lights
visually identifying
how dry the air
is
in your room.
3.
Remote control giving you the ability to change from across the room. As well as a magnet
on side of unit
and on the
remote
for convenient
storage.
4.
The humidity function can be set
to
a humidity range of 40 -75%RH, depending on what level is most comfortable for you.
5.
High temperature
heating element cleans the water,
and the plasma generator sterilizes the air, creating clean and
healthy humidity
8.
Low water sensor
lets you know when you need to refill
9.
Lighted display lets your view from across the room
10.
360-degree vapor output lets you distribute the humidity even ly
throughout the room.
UL STD.998AND867.
07/
Safety instruction
Very important!
•
Please read this manual carefully, make sure it is used correctly.
•
To
ensure
a long life of your humidifier, you must follow the regular cleaning procedures.
Precautions before use
When using the humidifier for the first time, let the humidifier work continuously for a
good
two hours in a well -
ventilated
area, to remove the odor that sometimes accompanies new electrical appliances when turned on and
heated up . After a few hours, the odor will dissipate. This odor is normal and will disappear after use.
Read all safety instructions before using the humidifier.
1.
Please unplug the power plug when filling water and cleaning.
2.
Do not use wet hands to plug and unplug the power plug , nor pull at the cord, to avoid the risk of electric
shock.
3.
Please do not try and repair or modify this product without authorization , it will void the warranty
4.
The power cord shall not be knotted, damaged, squeezed by heavy objects. Using a damaged cord on
any electrical
device may
lead to electric shock, short circuit,
and fire.
5.
This machine is for indoor use only.
6.
Like any appliance, it is encouraged to un plug during thunderstorm or when not in use for a nextended period.
7.
Do not turn the machine over when it is powered on or there is water inside, to
avoid damaging
to
the
internal electronic components.
8.
Do not let children
operate the machine .
9.
This humidifier
dispenses hot steam
when creating the humidity, so please use away from body
parts that could get burned.
10.
If there is any abnormality in the use of the product, please unplug the power plug immediately and
cont act manufacturer list on side of unit.
！
Warning notice!
WARNING: Chemical Burn Hazard.Keep batteries away from children.This product contains a lithium button/coin
cell battery.If a new or used lithium button/coin cell battery is swallowed or enters the body,it can cause severe
internal burns and can lead to death in as little as 2 hours.Always completely secure the battery compartment.
If the battery compartment does not close securely,stop using the product,remove the batterides,and keep it away
from children.If you think batteries might have beenswallowed or placde inside any part of the body,seek immdeiate
medical attention.The cells shall be disposed of properly,including keeping them away from children.
Even used cells may cause injury.
08/
Instruction
1.
Check the water tank and
filter
Rotate the upper compartment and check weather the water tank and filter are installed
correctly.
It is recommended to use clean tap water or dislled w ter. There are 3 ways to add water:
1.
Place humidifier on a stable level surface and with lid on, pour water in top center port using the water
gauge on side to ensure you do not overfill. Avoid water going into slots on outer ring of top which is where
the mist comes out.
2.
Remove top of unit with a quarter turn and lay next to unit. Pour water directly into tank, ensure not to over
fill.
3.
Lif water bucket by handle and take to your water source. Ensure not to over fill.
Soleus Air
AIR PURIFING
HUMIDIFIER
AHU
-
600Z1
Operation Instruction
Thank you for purchasing this product! Please read this manual
carefully before using the product and keep it properly.
Implementation standard:. UL STD.998AND867.
3.
Connect the power supply:
Connect the power cord to the power interface on the back of humidifier, insert the power plug into the
power outlet
that meets the product requirements, turn on the power button , and unit automatically
goes into standby mode , listen for
"beep".
4. On/O ffConstant humidity function:
1)
Press the power button briefly, and the machine will start, and the digital screen will flash to display
CO
(CO is the continuous humidification mode ),
At this time, the humidity can be set. After the humidity
adjustment range is 40 -75%RH and the set humidity is selected in CO mode , the machine will display
the humidity of the current actual environment and compare it with the set humidity. If the current
environmental humidity is lower than the set humidity, the machine will start humidification, and stop
humidification when the current environmental humidity reaches the set humidity. It will maintain the
current humidity value.
2)
During the working process of the machine, the humidification level
can be adjusted at any time, the default
is set at
level 2 and can be adjusted from levels 1 through 4 depending you’re preference.
5. Timing function:
Press the timer button briefly, and then cycle and switch CO-> 01-> 02->-> up to
12 hours. When CO turns o ff
the timer function, the operation is stopped, the display screen flashes and the current state is determined, and
the machine starts to work. When the set time is reached, the machine stops working and enters the standby
mode.
6. Sterilization function:
Press the sterilization button briefly to start the sterilization function .
The plasma generator works,
and
the
plasma is emitted to start sterilization. Press the sterilization button again to turn o ffthe
sterilization function.
7. Sleep mode:
Press the sleep button briefly to enter sleep mode. In
sleep mode, the machine is humidified silently in
1st level
by default.
8. Light effect on/off:
Press the sleep button for 3 seconds to turn o ffthe humidity level
indicator light that illuminates 360
degrees. Press again
for 3 seconds to restart the humidity level indicator light .
The lighting color represents the current ambient humidity
in
the room .
1).
The humidity value is <40%RH, and the lighting display is reddish orange.
2).
40%Rh < humidity value < 60%RH, and the lighting is displayed as aqua blue.
3).
60%Rh < humidity value, and the lighting display is turquoise.
9. If you see Warning lights
flashing :
When a
warning light flashes, it means that the machine is not working, and the following situations
should
occur:
1)
Empty Bucket : when the machine is short of water, the warning light flashes and lights up. Currently ,
it is
in standby mode until you add more water. After water is added, press any key to return to
normal
operation .
2)
If the upper section of unit (top)
is disconnected or loose, machine stops working, until reconnected.
3)
Tilting of the machine: When the machine is not level or stable, it will stop working
until level again.
10. Remote control:
1)
When using the remote control, it is necessary to aim and have a clear s ight
of
the machine for the
infrared to work and make changes .
2)
The battery is 3V CR2025 button cell.
3)
The functions of the remote controller are the same as those on the machine panel, and the corresponding
buttons can be triggered for use.
09/ For Optimal Performance
1. Installation.
1)
Make sure it is plugged into a safe and dry location wear the cord will
not be walked
on or tripped over.
2)
Make sure all connections are tight-
Top is screw ed
on and power cord is tight.
2. Handling.
1)
When moving, be sure to unplug
power plug
and ensure top stays tight.
2)
When moving, empty the remaining water in the water tank as not to spill.
3. Placement
1)
When using the humidifier for the first time, make sure to let it run for a few hours to get rid of any NEW electrical
odor that can accompany new powered electronics.
2)
Ensure that your surface is
level and sturdy.
3)
Make sure you put it on a
clean waterproof surface away from anything that could get damaged if it gets
wet when filling up or in normal operation.
4)
Make sure you test your location first when warm vapor is coming out to make sure it is far enough away
from the wall and furniture to protect paint
and fabric from moisture. We recommend at least
3 feet.
5)
Place in a
location away from small children that could get burn ed with direct contact where the mist
comes out.
6)
When the unit is not in use for an extended period, make sure the tank is stored empty.
4.
Every day use
1)
In case of abnormal sound and odor after the initial burn of
odor when new, please stop using the product
immediately.
2)
Please use the machine carefully to avoid scalding, as it disperses
hot water vapor.
3)
Do not sit, lean,
or tilt the machine.
4)
Cleaning Heating element -
when cleaning the heating element , do not scrape the heating plate with sharp or hard
objects.
5.
Cleaning
It is recommended with daily use, that you clean your unit once a week . When cleaning, please unplug the power
plug to prevent water in the appliance .
Also make sure it is completely dry before you power back up.
10
/
Trouble analysis and troubleshooting
Trouble
Probable causes
Probable
solution
Does not
appeared to have
power
The plug is not completely in outlet or unit
The machine switch is not turned on
The power supply is not connected
Plug in the plug
Turn on the machine switch
Check the plug on the power supply
No mist is coming
out of unit
1.
Humidifier takes 3-5 minutes to get up to
full operation, so could take that long to see
mist
1.
Wait for 3 -5 minutes
Sensor lights do
not
work
1 ensure the top part of the unit is connected
2.
The contacts on the top and bottom
components have do not have built
up and
need to be cleaned
1.
Screw the top component together and make sure
they are
connected.
2.
Wipe and clean the contacts of any build up.
Warning lights
flashing
1.
Water tank is short of water
2.
The upper section is not rotated in
place
3.
The machine is not level
1.
Press any key after adding water to restore
2.
Check connection to make sure nothing is
in the way,
then rotate until you have a tight connection
3.
Move to a study and level location
Exception handing
Like any appliance, if you hear an abnormal noise or large amount of smoke that smells different
(different from when it was new and plugged in for the first time) unplug immediately and check the
unit for tight connections. If that does not work, call customer service .
11/
Maintenance
If using Daily
, cleaning once a week is recommended for optimal
performance.
1.
Before cleaning, shut down and unplug the power supply.
2.
Like other humidifiers, with frequent use and areas with mineral heavy water, a white build -up can
occur. This white build up is d ried mineral deposits and can be easily cleaned with warm water or white
vinegar or follow your
own de-scaling method. It
is recommended to clean once a week.
3.
Scale cleaning of mist outlet pipe: take out the water tank component, soak and remove any build-up
in
white
vinegar, and then rinse with clear water. It is recommended to clean it every 15 days.
4.
Scale cleaning of heating plate: Take out the water tank component. Pour citric acid solution (10g citric acid, 200mL
water) or 100mL white vinegar into the heating plate at the bottom. Once Clean return the clean water tank component
with 8 ounces (roughly 1 cut), and run for 20min, and then pour it out and rinse with clear water. It is recommended to
clean it every 7 days.
5.
Please keep the chrome contacts
on the top and bottom compartments
dry
during the cleaning process. The
contacts can be wiped clean with a clean, soft
cloth. It is recommended to clean them once
a
week.
Please pay attention to the protection of the contact pins of the upper component, and do not apply excessive
pressure
and
twist by hand.
12/
Warranty description
Soleus
Air
warranties this product to be free of defects in material and workmanship
for the applications
specified in its operation instruction for a period of 1 year from the date of original retail purchase in the
United States.
If the unit exhibits a defect in normal use, we
will, either repair or replace it, free of charge within a
reasonable time after the unit is returned during the warranty
period.
As a condition to any warranty service obligation, the consumer must present the product along with a copy
of the original purchase invoice.
THIS WARRANTY DOES NOT COVER:
•
Damage, accidental or otherwise, to the unit while in the possession of a consumer not caused by
a defect
in material or workmanship
•
Damage caused by consumer misuse, tampering, or failure to follow the care and special
handling provisions
in the instructions. This includes dents, accidental or otherwise, to the base
and head of the unit.
•
Damage to the finish of the housing, or other appearance parts caused by wear.
•
Damage caused by repairs or alterations of the unit.
•
Freight and Insurance cost for the warranty service.
ALL WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANT ABILITY ARE LIMITED TO
ONE-YEAR DURATION OF THIS EXPRESS LIMITED WARRANTY. WE
DISCLAIMS ANY LIABILITY FOR
CONSEQUENTIAL OR INCIDENTAL DAMAGES AND IN NO EVENT SHALL THE VALUE EXCEED THE
RETAIL VALUE OF THE UNIT FOR BREACH OF ANY WRITTEN OR IMPLIED WARRANTY WITH
RESPECT TO THIS UNIT.
This warranty covers only new products purchased from our authorized dealers or retailers. It does not
cover used, salvaged, or refurbished products.
As some states do not allow the limitation or exclusion of incidental or consequential damages, or do not
allow limitation on implied warranties, the above limitations and exclusions may not apply to you. This
warranty gives you specific legal rights, and you may also have other rights that vary from state to state.
For Technical Support & Warranty Service
Please Call (888) 876-5387
2
1
3
4
5
6
7
8
9
10
11
12
