London
THIS MIXER TAP MUST BE INSTALLED BY A LICENSED PLUMBER IN
ACCORDANCE WITH LOCAL REGULATIONS.
This Oliveri tap is manufactured to standard AS/NZS 3718
.
This product complies with the Lead Free requirements of the National
Construction Code Volume 3.
MAX OPERATING PRESSURE: ................................................................................... 5 bar (500kPa)
RECOMMENDED OPERATION PRESSURE: ................................................................ . 1.5-5 bar (150-500kPa)
MAX HOT WATER TEMPERATURE: ........................................................................... 65°C
RECOMMENDED HOT WATER TEMPERATURE: ......................................................... 50°C
Where water pressure exceeds 500kPa, a pressure reducing device is required to be installed. Note that water
pressure overnight can reach 150% of the daytime pressure.
Note:
Installation of aerators containing flow regulators: Upon re-installation, the aerator should be tightened
with an aerator key to prevent removal by hand.
Note:
Ceramic Cartridges: Warranty claims will not be honoured where the ceramic cartridge has
malfunctioned due to the presence in the water supply of:
• Copper tube pieces, sand, dirt or stones
• Thread tape
• Other objects not normally present in potable water supplies.
Do not remove the cartridge from the body as it has been pressure tested and tightened to a
specific torque.
Before attempting any work involving mains water supply lines, ensure the water supply is shut off.
Stop valves (preferably with filters) must be used when installing your Oliveri mixer to allow isolation (not
supplied with mixer). Failure to do so where required will void warranty.
This mixer tap is already pre-assembled and tested. Do not disassemble, as this may void the warranty.
This mixer tap must be installed in accordance with these instructions.
Oliveri Solutions Pty Ltd ABN 12 007 551 886
51 Naweena Rd, Regency Park SA 5010 P 08 8348 6444 E sales@oliveri.com.au
Issue Date 28/11/2023 Revision Number: V2.0
Single Lever Mixer
LON580FCR / LON58
0FMB / LON580FBN
CARE & MAINTENANCE
Clean with a soft cloth and warm soapy water as necessary - rinse and dry after cleaning. Under no
circumstances should abrasive or acid based cleaning products be used.
WARRANTY
PRODUCT
COMPONENT
DOMESTIC USE
COMMERCIAL USE
Kitchen Tapware
London
Cartridge
10 years replacement parts,
1 year labour
7 years replacement parts,
1 year labour
Body
7 years replacement parts,
1 year labour
1 years replacement parts,
& labour
Finish (chrome) LON580FCR
7 years replacement parts,
1 year labour
1 year replacement parts
& labour
Finish (Other) LON580FBN,
LON580FMB
5
years
replacement
parts,
1 year labour
1 year replacement
parts
& labour
Subject to
the terms contained in the full warranty information available at https://oliveri.com.au/service-and-
warranty, where a genuine manufacturing defect arises within the warranty period Oliveri will, at its election,
repair the defect or replace the product.
This warranty does not cover against normal wea
r and will be voided if the product is misused
or not installed in accordance with these instructions. Note: Fitting spout-attached devices, including
water filters, to this mixer will void warranty.
Our goods co
me w
ith guarantees that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to
be of acceptable quality and the failure does not amount to a major failure.
SERVICE
If the problem represents a danger, or damage to property may occur, immediately shut off the
water supply. If the mixer tap requires servicing, please contact your plumber (preferably the one who
installed it). Most problems occur due to contaminated supply lines or water pressure exceeding 500kPa.
Unscrew and clean the spout aerator periodically - especially if you notice a drop in water pressure.
If the Plumber / Installer is satisfied that the problem is not due to poor installation, con
tact Oliveri’s nominated
Warranty Service Agent for assistance on:
Ph: (08) 8348 6444 (choose the after sales service & warranty option)
Email: warranty@oliveri.com.au
For full warranty information visit: https://oliveri.com.au/service-and-warranty
If a warranty service call finds that the spout does not have a genuine manufacturing fault, our
Warranty Service Agent reserves the right to pass on any call-out fee to the householder.
Installation
Instructions
Technical
Data
1.
Remove product from packaging and check for damage, if the product is damaged do
not install and return to store of purchase.
2.
T
he WELS compliant aerator has been pre-assembled into the mixer outlet. To comply with WELS
the flow regulator must remain in place.
3.
Ensure product is complete as per exploded drawing.
4.
A single 35mm hole is required in the mounting surface
.
5.
The maximum mounting surface thickness cannot exceed 37 mm.
6.
Ensure bench sealing washer (A) is in place on base of Mixer. Screw the Mixer Tails (C) into base of the
Mixer being careful to avoid damage to the o’ring seals, the Mixer Tails are colour coded,
red for hot
and blue for cold, the Mixer base inlet holes are stamped with ‘H’ for hot and ‘C’ for cold. Hand
tighten only.
7.
Screw Threaded Rod (D) into base of Mixer.
8. Feed the Mixer Tails (C) through the mounting surface, each end alternately and position the mixer
on the mounting surface ensuring the Sealing Washer (A) is positioned correctly .
9. Feed Mixer Tails, each alternately through Stabiliser Plate (D) if supplied.
10.
Slide Rubber Horse Shoe (E) onto Threaded Rod (D) followed by Metal Horse Shoe Plate (F).
N.B The Mixer Tails should be positioned towards the user and the Fixing Bolt to the back.
11. Using Lock Nut (G), tighten the Mixer to mounting surface with supplied tool (H).
12.
Connect Mixer tails to mains water 1/2" stop cock. Tighten to 10Nm, Do NOT overtighten.
13.
Ensure the Mixer Tails are not kinked, bent, stretched or twisted when assembling to
the
mains water supply. The Mixer Tail connection between the Mixer and the water
supply must have a natural curve (minimum bend radius 30 mm).
14.
Ensure Mixer tails are installed indoors, above-ground, and remain accessible - do not bury, submerge,
install behind a wall, floor or ceiling. Do not not expose to abrasions, corrosive agents or the like. Test
for leaks: lf a leak occurs, retighten slightly.
15.
It is recommended that In-Line Filters be installed to ensure a cleaner flow of water to the Mixer
.
TO THE CONSUMER
1. The Mixer is only to be cleaned with warm soapy water and a soft cloth.
2.
Issue Date 28/11/2023 Revision Number: V2.0
Under no circumstances should any abrasive, cream or acid-based cleaning agents be used, as these
types of cleaners can damage the finish, cartridge, seals and Mixer aerator.
Installation Instructions
C
D
E
F
G
Max 37
A
Braided flexible hoses
must be inspected
every 12 months for
warning signs of failure
including bulging, rust
spots, wear, moisture,
snapped threads,
kinking, water staining,
general corrosion or
discolouration.
Mixer tails showing any
signs of the above
mentioned warning
signs must be replaced
immediately.
H
B
Installation Instructions
INSTALLATION INSTRUCTIONS
General Note: This product is to be installed by a licenced plumber. Installation must comply with the
AS/NZS 3500 series of Standards, Plumbing Code of Australia and applicable plumbing codes and
regulations.
Pressures & Temperatures
Maximum Hydrostatic Pressure: 500kPa. Note: AS/NZS 3500.1 Subclause 3.3.4 (Maximum pressure
within buildings) states "The maximum static pressure at any outlet, other than a fire service outlet,
within a building shall not exceed 500kPa. Note: Pressures above 500kPa can cause damage from
water hammer, reduced life of appliances, taps and fittings, and cause excessive noise in the system."
Minimum Hydrostatic Pressure: 150kPa.Note: This Product may not be suitable for use with low
pressure/gravity feed water supplies or with some continuous flow/instantaneous hot water systems.
The maximum operating temperature for the Mixer Tap is 65°C. The recommended maximum delivery
temperature is 50°C.
Please ensure that the lines are flushed prior to installation as contaminates in the water can
damage the ceramic disc cartridge, flow regulator and affect the performance of the mixer.
1.
Remove product from packaging and check for damage, if the product is damaged do
not install and return to store of purchase.
2.
T
he WELS compliant aerator has been pre-assembled into the mixer outlet. To comply with WELS
the flow regulator must remain in place.
3.
Ensure product is complete as per exploded drawing.
4.
A single 35mm hole is required in the mounting surface
.
5.
The maximum mounting surface thickness cannot exceed 37 mm.
6.
Ensure bench sealing washer (A) is in place on base of Mixer. Screw the Mixer Tails (C) into base of the
Mixer being careful to avoid damage to the o’ring seals, the Mixer Tails are colour coded,
red for hot
and blue for cold, the Mixer base inlet holes are stamped with ‘H’ for hot and ‘C’ for cold. Hand
tighten only.
7.
Screw Threaded Rod (D) into base of Mixer.
8. Feed the Mixer Tails (C) through the mounting surface, each end alternately and position the mixer
on the mounting surface ensuring the Sealing Washer (A) is positioned correctly .
9. Feed Mixer Tails, each alternately through Stabiliser Plate (D) if supplied.
10.
Slide Rubber Horse Shoe (E) onto Threaded Rod (D) followed by Metal Horse Shoe Plate (F).
N.B The Mixer Tails should be positioned towards the user and the Fixing Bolt to the back.
11. Using Lock Nut (G), tighten the Mixer to mounting surface with supplied tool (H).
12.
Connect Mixer tails to mains water 1/2" stop cock. Tighten to 10Nm, Do NOT overtighten.
13.
Ensure the Mixer Tails are not kinked, bent, stretched or twisted when assembling to
the
mains water supply. The Mixer Tail connection between the Mixer and the water
supply must have a natural curve (minimum bend radius 30 mm).
14.
Ensure Mixer tails are installed indoors, above-ground, and remain accessible - do not bury, submerge,
install behind a wall, floor or ceiling. Do not not expose to abrasions, corrosive agents or the like. Test
for leaks: lf a leak occurs, retighten slightly.
15.
It is recommended that In-Line Filters be installed to ensure a cleaner flow of water to the Mixer
.
TO THE CONSUMER
1. The Mixer is only to be cleaned with warm soapy water and a soft cloth.
2.
Issue Date 28/11/2023 Revision Number: V2.0
Under no circumstances should any abrasive, cream or acid-based cleaning agents be used, as these
types of cleaners can damage the finish, cartridge, seals and Mixer aerator.
Installation Instructions
C
D
E
F
G
Max 37
A
Braided flexible hoses
must be inspected
every 12 months for
warning signs of failure
including bulging, rust
spots, wear, moisture,
snapped threads,
kinking, water staining,
general corrosion or
discolouration.
Mixer tails showing any
signs of the above
mentioned warning
signs must be replaced
immediately.
H
B
Installation Instructions
INSTALLATION INSTRUCTIONS
General Note: This product is to be installed by a licenced plumber. Installation must comply with the
AS/NZS 3500 series of Standards, Plumbing Code of Australia and applicable plumbing codes and
regulations.
Pressures & Temperatures
Maximum Hydrostatic Pressure: 500kPa. Note: AS/NZS 3500.1 Subclause 3.3.4 (Maximum pressure
within buildings) states "The maximum static pressure at any outlet, other than a fire service outlet,
within a building shall not exceed 500kPa. Note: Pressures above 500kPa can cause damage from
water hammer, reduced life of appliances, taps and fittings, and cause excessive noise in the system."
Minimum Hydrostatic Pressure: 150kPa.Note: This Product may not be suitable for use with low
pressure/gravity feed water supplies or with some continuous flow/instantaneous hot water systems.
The maximum operating temperature for the Mixer Tap is 65°C. The recommended maximum delivery
temperature is 50°C.
Please ensure that the lines are flushed prior to installation as contaminates in the water can
damage the ceramic disc cartridge, flow regulator and affect the performance of the mixer.
London
THIS MIXER TAP MUST BE INSTALLED BY A LICENSED PLUMBER IN
ACCORDANCE WITH LOCAL REGULATIONS.
This Oliveri tap is manufactured to standard AS/NZS 3718
.
This product complies with the Lead Free requirements of the National
Construction Code Volume 3.
MAX OPERATING PRESSURE: ................................................................................... 5 bar (500kPa)
RECOMMENDED OPERATION PRESSURE: ................................................................ . 1.5-5 bar (150-500kPa)
MAX HOT WATER TEMPERATURE: ........................................................................... 65°C
RECOMMENDED HOT WATER TEMPERATURE: ......................................................... 50°C
Where water pressure exceeds 500kPa, a pressure reducing device is required to be installed. Note that water
pressure overnight can reach 150% of the daytime pressure.
Note:
Installation of aerators containing flow regulators: Upon re-installation, the aerator should be tightened
with an aerator key to prevent removal by hand.
Note:
Ceramic Cartridges: Warranty claims will not be honoured where the ceramic cartridge has
malfunctioned due to the presence in the water supply of:
• Copper tube pieces, sand, dirt or stones
• Thread tape
• Other objects not normally present in potable water supplies.
Do not remove the cartridge from the body as it has been pressure tested and tightened to a
specific torque.
Before attempting any work involving mains water supply lines, ensure the water supply is shut off.
Stop valves (preferably with filters) must be used when installing your Oliveri mixer to allow isolation (not
supplied with mixer). Failure to do so where required will void warranty.
This mixer tap is already pre-assembled and tested. Do not disassemble, as this may void the warranty.
This mixer tap must be installed in accordance with these instructions.
Oliveri Solutions Pty Ltd ABN 12 007 551 886
51 Naweena Rd, Regency Park SA 5010 P 08 8348 6444 E sales@oliveri.com.au
Issue Date 28/11/2023 Revision Number: V2.0
Single Lever Mixer
LON580FCR / LON58
0FMB / LON580FBN
CARE & MAINTENANCE
Clean with a soft cloth and warm soapy water as necessary - rinse and dry after cleaning. Under no
circumstances should abrasive or acid based cleaning products be used.
WARRANTY
PRODUCT
COMPONENT
DOMESTIC USE
COMMERCIAL USE
Kitchen Tapware
London
Cartridge
10 years replacement parts,
1 year labour
7 years replacement parts,
1 year labour
Body
7 years replacement parts,
1 year labour
1 years replacement parts,
& labour
Finish (chrome) LON580FCR
7 years replacement parts,
1 year labour
1 year replacement parts
& labour
Finish (Other) LON580FBN,
LON580FMB
5
years
replacement
parts,
1 year labour
1 year replacement
parts
& labour
Subject to
the terms contained in the full warranty information available at https://oliveri.com.au/service-and-
warranty, where a genuine manufacturing defect arises within the warranty period Oliveri will, at its election,
repair the defect or replace the product.
This warranty does not cover against normal wea
r and will be voided if the product is misused
or not installed in accordance with these instructions. Note: Fitting spout-attached devices, including
water filters, to this mixer will void warranty.
Our goods co
me w
ith guarantees that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to
be of acceptable quality and the failure does not amount to a major failure.
SERVICE
If the problem represents a danger, or damage to property may occur, immediately shut off the
water supply. If the mixer tap requires servicing, please contact your plumber (preferably the one who
installed it). Most problems occur due to contaminated supply lines or water pressure exceeding 500kPa.
Unscrew and clean the spout aerator periodically - especially if you notice a drop in water pressure.
If the Plumber / Installer is satisfied that the problem is not due to poor installation, con
tact Oliveri’s nominated
Warranty Service Agent for assistance on:
Ph: (08) 8348 6444 (choose the after sales service & warranty option)
Email: warranty@oliveri.com.au
For full warranty information visit: https://oliveri.com.au/service-and-warranty
If a warranty service call finds that the spout does not have a genuine manufacturing fault, our
Warranty Service Agent reserves the right to pass on any call-out fee to the householder.
Installation
Instructions
Technical
Data
