Installation Guide
5/6-Port 10/100Mbps Desktop PoE/PoE+ Switch
LED Explanation
Power
On: Power on
O: Power o
Note:
1. PoE ports can also connect to non-PoE devices, but only transmit data.
2. TL-SF1005LP can supply up to 15.4 W for each PoE port and 41 W for all PoE ports.
3. TL-SF1005P/TL-SF1006P can supply up to 30 W for each PoE port and 67 W for all PoE
ports.
Power
PoE MAX
PoE Max
TL-SF1005LP
On: 34 W≤Total power supply < 41 W
Flashing: Total power supply ≥ 41 W
O: Total power supply < 34 W
TL-SF1005P/TL-SF1006P
On: 60 W≤Total power supply < 67 W
Flashing: Total power supply ≥ 67 W
O: Total power supply < 60 W
DC Power Adapter
AC Power Cord
Router
LAN Port
WAN Port
Internet
Ethernet Ports (1-5)
PoE Ports (1-4)
IP Camera AP IP Phone
PoE Devices
Link/Act and PoE Status
On: Link present but no
activity
Flashing: Transmitting/
receiving data
O: No link
On: Providing PoE power
Flashing: Current-overload/
Short-circuit
O: Not providing PoE power
Note: For simplicity, we will take TL-SF1005P for example throughout the Guide.
O: Port 1–4 run at 10/100 Mbps and support PoE power
supply up to 100 m away.
On: Port 1–4 run at 10 Mbps and support PoE power supply
up to 250 m away.
Extend
O: All the ports transmit data in the same priority.
On: Port 1 and 2 transmit data in a higher priority than other
ports. When congestion occurs, packets which are transmit-
ted by the ports with higher priority occupy the whole
bandwidth.
Priority
Switch Explanation
Note: The numbers in brackets indicate the ports where the feature takes eect. For example, when Extend(1-4) is toggled to On, the Extend mode will be enabled for ports 1-4.
Recovery (for TL-SF1005P/TL-SF1006P)
O: The PoE Auto Recovery function is disabled.
On: The switch will constantly detect the working status of a
PoE powered device (PD). When the switch nds that the PD
works abnormally, the switch will reboot it.
