MECHANICS UTILITY SEAT
MODEL NO: SCR9.V3
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this seat.
9 Locate seat in a suitable working area.
WARNING! Use seat on level and solid ground, preferably concrete.
9 Keep the seat clean and tidy in accordance with good workshop practice.
8 DO NOT use the seat for any purpose other than that for which it is designed.
8 DO NOT stand on the seat.
8 DO NOT use the seat outdoors.
8 DO NOT get the seat wet or use in damp or wet locations or areas where there is condensation.
8 DO NOT clean the seat with any solvents which may damage the paint surface or the protective coating on the padded seat base.
8 DO NOT exceed maximum capacity of 110kg.
2. INTRODUCTION
Steel framework with powder coated nish. Extra thick cushioned padding for added comfort when seated. Easy-rolling Ø63mm rubber
castors with ball bearing swivel. Composite storage tray for tools and components.
3. SPECIFICATION
Model No ................................................................ SCR9.V3
Max. Capacity ...............................................................110kg
Overall Size (W x D x H) .........................355 x 360 x 385mm
4. ASSEMBLY
4.1. Start by placing the tray on the base frame. Slot the
castors through the frame from the underside and
secure to the tray with the cap nuts, washers and split
washers.
4.2. Attach the two seat support frames to the base frame
with the four bolts, cap nuts and washers.
4.3. Place the seat cushion upside down, place the two
support bars on the underside of the cushion. Turn the
framework upside down and place on top of the cushion
and support bars, secure using the four screws and
washers.
4.4. Turn the seat upright, the product is now ready to use.
Refer to
instructions
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
SCR9.V3 Issue 1 27/09/21
Original Language Version
© Jack Sealey Limited
Base frame
Seat
support
frames
Seat cushion
Tray
