CV-PHS
Portable Hand-Wash Sink
Quick-start Instructions
Do not connect water heater to electricity unless it is
full of water!!
Start-up:
Fill the fresh water tanks with cold, potable water and insert
the siphon (intake) hose from the pump into one of the fresh water
tanks. Make sure the hose is all the way to the bottom of the tank.
Make sure the drain hose(s) are inserted into the waste water tank.
Plug the long power cord into a dedicated electrical outlet.
Connect the water pump cord to the electrical outlet inside the cart,
the pump will run. Open the cold water faucet until water flows
freely with no air bubbles. Open the hot water faucet until water
flows freely with no air bubbles (this may take a minute if the heater
is empty).
Operation:
When the faucets are turned off the pump will automatically
shut off and turn back on when the faucet(s) are opened, unless:
there are air bubbles in the water lines. To correct this, simply run
more water until the air bubbles are out. Note: when the fresh water
tank is empty, the pump will draw air bubbles into the system, and
the fresh water tank must be exchanged or refilled. Disconnect the
pump from the electrical outlet until the fresh water tank can be
exchanged or refilled.
Do not let the pump run dry for more than 2 minutes; damage
to the pump may result.
Do not let the waste water tank overflow. Dispose of waste
water in a sanitary drain only.
Drain hoses must be inserted into the waste water tanks at all
times. (unless connected to a sanitary drain)
You can connect the sink cart to direct city water supply via the
garden hose coupling located immediately downstream of the
pump outlet.
The sink drain(s) may be connected to a sanitary drain via the
garden hose fittings located directly below each sink bowl.
NO POWER?? Check the reset button on the GFCI electrical
outlet located in the cart.
