Dishwasher / User ManualEN
ADW5002X/1 - ADW5002W/1
ADW5002B
EN - 2
Thank you for choosing this product.
This user manual contains important information on safety and instructions intended to
assist you in the operation and maintenance of your appliance.
Please take the time to read this user manual before using your appliance and keep this
book for future reference.
Icon Type Meaning
WARNING Serious injury or death risk
RISK OF ELECTRIC SHOCK Dangerous voltage risk
FIRE Warning; Risk of re / ammable materials
CAUTION Injury or property damage risk
IMPORTANT Operating the system correctly
EN - 3
CONTENTS
1 SAFETY INSTRUCTIONS .............................................................................. 4
1.1 General Safety Warnings ..............................................................................................4
1.2 Inallation Warnings .....................................................................................................5
1.3 During Usage..................................................................................................................6
2 INSTALLATION ................................................................................................ 9
2.1 Machine Positioning .......................................................................................................9
2.2 Water Connection ..........................................................................................................9
2.3 Water Inlet Hose ............................................................................................................9
2.4 Drain Hose (Model Depending) ....................................................................................10
2.5 Electrical Connection ...................................................................................................10
2.6 Fitting The Machine Undercounter ...............................................................................11
3 TECHNICAL SPECIFICATIONS ................................................................... 12
3.1 General Sppearance ....................................................................................................12
3.2 Technical Specications ...............................................................................................12
4 BEFORE USING THE APPLIANCE ............................................................. 14
4.1 Preparing Your Dishwasher For Fir Use ....................................................................14
4.2 Salt Usage (IF AVAILABLE) ..........................................................................................14
4.3 Fill The Salt (IF AVAILABLE) ........................................................................................14
4.4 Te Strip .......................................................................................................................15
4.5 Water Hardness Table ..................................................................................................15
4.6 Water Softener Syem .................................................................................................15
4.7 Setting ..........................................................................................................................15
4.8 Detergent Usage ..........................................................................................................15
4.9 Filling The Detergent ....................................................................................................16
4.10 Using Combined Detergents ......................................................................................16
4.11 Rinse-aid usage ..........................................................................................................16
4.12 Filling The Rinse-aid And Setting ...............................................................................16
5 LOADING YOUR DISHWASHER .................................................................. 18
5.1 Recommendations .......................................................................................................18
5.2 Alternative Basket Loads .............................................................................................21
6 PROGRAMME TABLE ................................................................................... 22
7 THE CONTROL PANEL ................................................................................. 23
8 CLEANING AND MAINTENANCE ................................................................ 26
8.1 Filters ............................................................................................................................26
8.2 Spray Arms ...................................................................................................................26
8.3 Drain Pump...................................................................................................................27
9 TROUBLESHOOTING .................................................................................. 28
EN - 4
1 SAFETY INSTRUCTIONS
1.1 General Safety Warnings
• Read these instructions carefully before using your
appliance and keep this manual for future reference.
Please check the packaging of your machine
before installation and the outer surface of the
machine once the packaging has been removed. Do
not operate the machine if it appears damaged or if
the packaging has been opened.
• Packaging materials protect your machine from any
damage that might occur during transportation. The
packaging materials are environmentally friendly
as they are recyclable. Use of recycled material
reduces raw material consumption and decreases
waste production.
This appliance can be used by children aged from
8 years and above, and by persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning the use of the
appliance in a safe way and understand hazards
involved. Children should not be allowed to play with
the appliance.
Remove packaging and keep it out of reach of
children.
Keep children away from detergents and rinse
aids.
EN - 5
There may be some residue left in the machine
after washing. Keep children away from the machine
when it is open.
1.2 Installation Warnings
• Choose a suitable and safe place to install your
machine.
• Only original spare parts should be used with the
machine.
Unplug the machine before installation.
Your machine must only be installed by an
authorised service agent. Installation by anyone other
than an authorised agent may cause your warranty to
be void.
Check that the indoor electrical fuse system is
connected in line with safety regulations.
All electrical connections must match the values on
the plate.
Ensure the machine does not stand on the
electrical supply cable.
Never use an extension cord or a multiple socket
connection.
The plug should be accessible after the machine is
installed.
• After installation, run your machine unloaded for the
rst time.
The machine must not be plugged in during
positioning.
EN - 6
Always use the coated plug supplied with your
machine.
If the electrical cable is damaged, it should only
be replaced by a qualied electrician.
• Connect the hose directly to the water inlet tap. The
pressure supplied by the tap should be a minimum
of 0.03 MPa and a maximum of 1 MPa. If the
pressure exceeds 1 MPa, a pressure relief valve
must be tted between the connection.
1.3 During Usage
• This machine is for domestic use only; do not use
it for other purposes. Commercial use will void the
guarantee.
Do not stand, sit or place loads on the open door
the dishwasher.
Only use detergents and rinse aids produced
specically for dishwashers. Our company is not
responsible for any damage that may occur due to
misuse.
Do not drink water from the machine.
Due to the danger of explosion, do not place any
chemical dissolving agents into the machine’s washing
section.
• Check the heat-resistance of plastic items before
washing them in the machine.
Only put items in the machine which are suitable for
dishwashing, and take care not to overll the baskets.
EN - 7
Do not open the door while the machine is in
operation, hot water may spill out. Safety devices
ensure the machine stops if the door is opened.
The machine door should not be left open. It may
cause accidents.
Place knives and other sharp objects in the cutlery
basket in a blade-down position.
For models with the automatic door-opening
system, when the EnergySave option is active, the
door will open at the end of a program. To prevent
damage to your dishwasher, do not attempt to close
the door for one minute after it has opened. For
eective drying, keep the door open for 30 minutes
after a programme has ended. Do not stand in front of
the door after the auto-open signal sounds.
In the case of a malfunction, repair should only
be performed by an authorised service company,
otherwise the warranty will be void.
Before repair work, the machine should be
disconnected from the mains. Do not pull the cable to
unplug the machine. Switch o the water tap.
Operation at a low voltage will cause a decline in
performance levels.
For safety, disconnect the plug once a program has
nished.
To avoid an electric shock, do not unplug the
machine with wet hands.
EN - 8
Pull the plug to disconnect the machine from the
mains, never pull on the cord.
EN - 9
2 INSTALLATION
2.1 Machine Positioning
When positioning the machine, place it in
an area where dishes can be easily loaded
and unloaded. Do not put the machine in
an area where the ambient temperature
falls below 0°C.
Read all warnings located on the packaging
before removing the packaging and
positioning the machine.
Place the machine close to a water tap
and drain. Take into consideration that the
connections will not be altered once the
machine is in position.
Do not hold the machine by its door or
panel.
Leave an adequate distance around the
machine to allow ease of movement when
cleaning.
Ensure the water inlet and outlet
hoses are not squeezed or trapped
and that the machine does not stand on the
electrical cable while positioning.
Adjust the feet so the machine is level and
balanced. The machine should be placed
on at ground otherwise it will be unstable
and the door of the machine will not close
properly.
2.2 Water Connection
We recommend tting a lter to your water
inlet supply in order to prevent damage to
your machine due to contamination (sand,
rust, etc.) from indoor plumbing. This will
also help prevent yellowing and deposit
formation after washing.
Note printing on the water inlet hose!
If models are marked with 25°, the water
temperature may be max. 25 °C (cold
water).
For all other models:
Cold water preferred; hot water max.
temperature 60 °C.
2.3 Water Inlet Hose
WARNING: Use the new water inlet
hose supplied with your machine, do not
use an old machine’s hose.
WARNING: Run water through the
new hose before connecting.
WARNING: Connect the hose
directly to the water inlet tap. The pressure
supplied by the tap should be a minimum
of 0.03 MPa and a maximum of 1 MPa. If
the pressure exceeds 1 MPa, a pressure
relief valve must be tted between the
connection.
WARNING: After the connections are
made, turn the tap on fully and check
for water leaks. Always turn o the water
inlet tap after a wash program has nished.
An Aquastop water spout is available
with some models. Do not damage it
or allow it to become kinked or twisted.
EN - 10
2.4 Drain Hose (Model Depending)
Connect the water drain hose directly to
water drain hole or to the sink outlet spigot.
This connection should be minimum 50
cm and maximum 110 cm from oor that
dishwasher is placed.
IMPORTANT: Items will not wash
properly if a drain hose longer than 4 m
is used.
2.5 Electrical Connection
WARNING: Your machine is set to
operate at 220-240 V. If the mains voltage
supply to your machine is 110 V, connect
a transformer of 110/220 V and 3000 W
between the electrical connection.
Connect the product to a
grounded outlet protected by a fuse
complying with the values in the
“Technical Specications” table”.
The earthed plug of the
machine must be connected
to an earthed outlet supplied by
suitable voltage and current.
In the absence of earthing
installation, an authorised
electrician should carry out an earthing
installation. In the case of use without
earthing installed, we will not be
responsible for any loss of use that may
occur.
The plug on this appliance
may incorporate 13A fuse depending on
the target country. (For Example UK,
Saudi Arabia)
EN - 11
2.6 Fitting The Machine Undercounter
If you wish to t your machine
undercounter, there must be sucient
space to do so and the wiring-plumbing
must be suitable to do so (1). If the space
under the countertop is suitable for tting
your machine, remove the worktop as
shown in the illustration (2).
WARNING: The countertop, which
the machine will be placed under, must be
stable in order to prevent imbalance.
The top panel of the dishwasher must
be removed to t the machine under the
countertop.
To remove the top panel, remove the
screws that hold it on, located at the rear
of the machine. Then, push the panel 1 cm
from the front towards the rear and lift it.
Adjust the machine feet according to the
slope of the oor (3).
Fit your machine by pushing it under the
counter taking care not to crush or bend the
hoses (4).
WARNING: After removing the top
panel of your dishwasher, the machine
should be placed in a space of the
dimensions shown in the gure below.
H1: min A
H2: min B1
H3: min B2
60 cm
A B
All
Products
B
1
B
2
Product’s Height
(±2 mm) 820 mm 830 mm 835 mm
A: If there is no felt on the top of the
product; you should take into account this
product’s height.
B1: If there is felt on the top of the product
with 2nd basket; you should take into
account this product’s height.
B2: If there is felt on the top of the product
with 3rd basket; you should take into
account this product’s height.
EN - 12
3 TECHNICAL SPECIFICATIONS
13
3.1 General Sppearance
1. Worktop
2. Upper basket with racks
3. Upper spray arm
4. Lower basket
5. Lower spray arm
6. Filters
7. Rating plate
8. Control panel
9. Detergent and rinse-aid dispenser
10. Cutlery basket
11. Salt dispenser
12. Upper basket track latch
13. Mini Active Drying Unit: This system
provides better drying performance your
dishes.
3.2 Technical Specications
Capacity
13 place
settings
Dimensions
Height
Width
Depth
850(mm)
598(mm)
598(mm)
Net weight
41 kg
Operating
voltage /
frequency
220-240V
50 Hz
Total current 10(A)
Total power 1900(W)
Water supply
pressure
Maximum:
1 (Mpa)
Minimum:
0.03 (Mpa)
EN - 13
RECYCLING
• Some machine components and
packaging consist of recyclable
materials.
• Plastics are marked with the
international abbreviations:(>PE<,
>PP<, etc. )
• The cardboard parts consist of recycled
paper. They can be put into waste
paper containers for recycling.
• Material unsuitable for domestic waste
must be disposed of at recycling
centres.
• Contact a relevant recycling centre to
obtain information about disposal of
different materials.
PACKAGING AND THE ENVIRONMENT
• Packaging materials protect your
machine from damage that may occur
during transportation. The packaging
materials are environmentally friendly
as they are recyclable. The use of
recycled material reduces raw material
consumption and therefore decreases
waste production.
CE Declaration of Conformity
We declare that our products meet the
applicable European Directives, Decisions
and Regulations and the requirements
listed in the standards referenced.
Disposal of Your Old Machine
The symbol on the product or
on its packaging indicates that
this product may not be treated
as household waste. Instead, it
shall be taken to the applicable
collection point for the recycling
of electrical and electronic
equipment. By ensuring
this product is disposed of correctly,
you will help prevent potential negative
consequences for the environment and
human health, which could otherwise be
caused by inappropriate waste handling of
this product. For more detailed information
about recycling this product, please contact
your local city office, your household waste
disposal service or the shop where the
product was purchased.
EN - 14
4 BEFORE USING THE
APPLIANCE
4.1 Preparing Your Dishwasher For First
Use
• Make sure the electricity and supply
water specications match the values
indicated in the installation instructions
for the machine.
• Remove all packaging material inside the
machine.
• Set the water softener level.
• Fill the rinse aid compartment..
4.2 Salt Usage (IF AVAILABLE)
For a good washing function, the
dishwasher needs soft, i.e. less calcareous
water. Otherwise, White lime residues
will remain on the dishes and the interior
equipment. This will negatively aect your
machine’s washing, drying and shining
performance. When water ows through
the softener system, the ions forming the
hardness are removed from the water and
the water reaches the softness required to
obtain the best washing result. Depending
on the level of hardness of the inowing
water, these ions that harden the water
accumulate rapidly inside the softener
system. Therefore, the softener system
has to be refreshed so that it operates with
the same performance also during the next
wash. For this purpose, dishwasher salt is
used.
Machine can only be used by special
dishwasher salt to soften the water. Do not
use any small grained or powdered type
of salts which can easily soluble. Using
any other type of salt can damage your
machine.
4.3 Fill The Salt (IF AVAILABLE)
To add softener salt, open the salt
compartment cap by turning it counter
clockwise. (1) (2) At rst use, ll the
compartment with 1 kg salt and water (3)
until it is almost overowing. If available,
using a funnel (4) will make lling easier.
Replace the cap and close it. After every
20-30 Cycles add salt into your machine
until it lls up (approx. 1 kg).
3 4
1 2
SALT
Only add water to the salt compartment
on rst use.
Use softener salt specically produced for
use in dishwashers.
When you start your dishwasher, the salt
compartment is lled with water, therefore
put the softener salt in prior to starting your
machine.
If the softener salt has overowed and you
do not start the machine immediately, run
a short washing program to protect your
machine against corrosion.
EN - 15
4.4 Test Strip
Run water
through the
tap (1min.)
Keep the
strip in the
water (1sec)
Shake the
strip.
Wait
(1min.)
Set the hardness level of
your machine.
1
2
3
4
5
6
NOTE: The level is set to 3 as default. If the water is well water or has a hardness level
above 90 dF, we recommend that you use lter and renement devices.
4.5 Water Hardness Table
Level German dH
French
dF
British
dE
Indicator
1 0-5 0-9 0-6 L1 is shown on the display.
2 6-11 10-20 7-14 L2 is shown on the display.
3 12-17 21-30 15-21 L3 is shown on the display.
4 18-22 31-40 22-28 L4 is shown on the display.
5 23-34 41-60 29-42 L5 is shown on the display.
6 35-50 61-90 43-63 L6 is shown on the display.
4.6 Water Softener System
The dishwasher is equipped with a water softener which reduces the hardness in the
mains water supply. To nd out the hardness level of your tap water, contact your water
company or use a test strip (if available).
4.7 Setting
• Open the door of the machine.
• Turn on the machine, and press the Programme button as soon as the machine is turned
on.
• Hold down the Programme button until “SL” disappears.
• The machine will display the last setting.
• Set the level by pressing the Programme button.
• Turn o the machine to save the setting.
4.8 Detergent Usage
Only use detergents specically designed for domestic dishwashers. Keep your detergents
in cool, dry places out of reach of children.
EN - 16
Add the proper detergent for the selected
program to ensure the best performance.
The amount of detergent needed depends
on the cycle, load size, and soil level of
dishes.
Do not ll detergent into the detergent
compartment more than required; otherwise
you can see whitish streaks or bluish layers
on glass and dishes and may cause glass
corrosion. Continued use of too much
detergent may cause machine damage.
Using little detergent can result in poor
cleaning and you can see whitish streaksin
hard water.
See the detergent manufacturer’s
instructions for a further information.
4.9 Filling The Detergent
Push the latch to open the dispenser and
pour in the detergent.
Close the lid and press it until it locks in
place. The dispenser should be relled just
before the start of each programme. If the
dishes are heavily soiled, place additional
detergent in the pre-wash detergent
chamber.
DETERGENT
4.10 Using Combined Detergents
These products should be used according
to the manufacturer’s instructions.
Never put combined detergents into the
interior section or the cutlery basket.
Combined detergents contain not only
the detergent but also rinse-aid, salt
replacement substances and additional
components depending on the combination.
We recommend you do not use combined
detergents in short programmes.
Please use powder detergents in such
programmes.
If you encounter problems when using
combined detergents, please contact the
detergent manufacturer.
When you stop using combined detergents,
make sure that water hardness and rinse
aid settings are set to the correct level.
4.11 Rinse-aid usage
The rinse aid helps to dry the dishes
without streaks and stains. Rinse-aid is
required for stain-free utensils and clear
glasses. The rinse aid is automatically
released during the hot rinse phase. If
rinse aid dosage setting set too low, whitish
stains remains on dishes and dishes do not
dry and washed clean.
If rinse aid dosage setting set too height,
you can see bluish layers on glass and
dishes.
4.12 Filling The Rinse-aid And Setting
To ll the rinse aid compartment, open
the rinse-aid compartment cap. Fill the
compartment with rinse aid to the MAX
level and then close the cap. Be careful not
to overll the rinse aid compartment and
wipe up any spills.
In order to change the rinse aid level,
follow the below steps before turning on
the machine:
• Open the door of the machine.
• ·Turn on the machine, and press the
Programme button as soon as the
machine is turned on.
• Hold down the Programme button until
“rA” disappears. Rinse aid setting follows
water hardness setting.
• The machine will display the last setting.
• Change the level by pressing the
programme button.
• Turn o the machine to save the setting.
The factory setting is “4”.
If the dishes are not drying properly or are
spotted, increase the level. If blue stains
form on your dishes, decrease the level.
EN - 17
Level Brightener Dose Indicator
1 Rinse-aid not
dispensed
r1 is shown on the
display.
2 1 dose is
dispensed
r2 is shown on the
display.
3 2 doses are
dispensed
r3 is shown on the
display.
4 3 doses are
dispensed
r4 is shown on the
display.
5 4 doses are
dispensed
r5 is shown on the
display.
EN - 18
5 LOADING YOUR DISHWASHER
For best results, follow these loading
guidelines.
Loading the household dishwasher up to the
capacity indicated by the manufacturer will
contribute to energy and water savings.
Manual pre-rinsing of tableware items leads
to increased water and energy consumption
and is not recommended You can place
cups, glasses, stemware, small plates,
bowls, etc. in upper basket. Do not lean long
glasses against one another or they cannot
remain steady and may receive damage.
When placing long stem glasses and
goblets, lean them against the basket edge
or rack and not against other items.
Place all containers such as cups, glasses
and pots into the dishwasher with the
opening facing downwards otherwise water
can collect on items.
If there is cutlery basket in machine, you
are recommended to use the cutlery grid
in order to obtain the best result. Place all
large (pots, pans, lids, plates, bowls etc.)
and very dirty items in the lower rack.
Dishes and cutlery should not be placed
above each other.
WARNING: Take care not to obstruct
the rotation of spray arms.
WARNING:Make sure after loading
the dishes do not prevent opening the
detergent dispenser.
5.1 Recommendations
Remove any coarse residue on dishes
before placing the dishes in the machine.
Start the machine with full load.
Do not overload the drawers or place
dishes in the wrong basket.
WARNING: To avoid any possible
injuries, place long-handle and sharp-
pointed knives with their sharp points facing
down or horizontally on the baskets.
EN - 19
Four Folding Racks
The folding racks are designed so that
large items, such as pots and pans, can
be easily placed in the dishwasher. Each
section can be folded separately. The
racks can be folded down or raised up, as
shown in the images below.
a
c
d
b
1
2
Upper Basket
Height Adjustment
Turn the Rail Stop Clips, at the ends of the
rails, to the sides to open them (as shown
in the image below), then pull out and
remove the basket. Change the position
of the wheels, then reinstall the basket
to the rail, making sure to close the Rail
Stop Clips.When the upper basket is in the
higher position, large items such as pans
can be placed on the lower basket.
EN - 20
Height Adjustable Rack (peg type)
The foldable racks in the upper basket
enable the placement of large items such
as pots and pans. Each section can be
folded separately. The foldable racks can
be either raised up or folded down.
Upper Basket Spoon Rack
The spoon rack has been designed for the
placement of long-stemmed utensils as
well as cutlery.
aa
The spoon rack has 4 different positions.
Set the spoon rack to position 1 or 2
depending on the position of items in the
upper basket. Position 1 allows for the
placement of cutlery.
Set the rack to position 3 or 4 if you do not
want to use the spoon rack.
1
2
3
4
A
Z
B
5.2 Alternative Basket Loads
Lower Basket
Upper Basket
Incorrect Loads
Incorrect loading can cause poor washing
and drying performance. Please follow the
manufacturer’s recommendations for a
good performans result.
Unsuitable Items For Dishwashing
• Cigarette ashes, candle leftovers, polish,
paint, chemical substances, iron-alloy
materials.
• Forks, spoons and knives with wooden,
bone, ivory or nacrecoated handles;
glued items, items soiled with abrasive,
acidic or base chemicals.
• Temperature-sensitive plastics, copper or
tincoated containers.
• Aluminium and silver objects.
• Some delicate glasses, ornamental
printed porcelains; some crystal items,
adhered cutlery, lead crystal glasses,
cutting boards, synthetic bred items.
• Absorbent items such as sponges or
kitchen rugs.
IMPORTANT: In future, purchase
dishwasher-proof kitchenware.
Important Note for Test Laboratories
For detailed information required for tests
according to EN normatives and a softcopy
of the manual, please send the model name
and serial number to the following address:
EN - 21
6 PROGRAMME TABLE
Programme
Duration
(min)
Description
Quick 30’ 30 Suitable for lightly soiled dishes and quick wash.
Delicate 40°C 74 Suitable for lightly soiled delicate dishes.
Eco 50°C
143
Standard program for normally soiled daily using dishes with reduced energy and
water consumptions.
Super 50’ 50 Suitable for normally soiled daily dishes with faster program.
Intensive 65°C 117 Suitable for heavily soiled dishes
NOTE: PROGRAMME DURATION MAY CHANGE ACCORDING TO THE AMOUNT
OF DISHES, TAP WATER, AMBIENT TEMPERATURE AND SELECTED ADDITIONAL
FUNCTIONS.
• Only use powder detergent in short programmes.
• Short programmes do not include a drying step.
• To assist drying, we recommend partially opening the door after the programme has
finished.
EN - 22
EN - 23
7 THE CONTROL PANEL
9
10
You can press the On/O button (4)
to switch on the product. On/o lights will
be lit as long as the machine is on. Press
the program button (5) to set the required
program.
Press the Start/Pause button (6) to start
the program. Once the selected program
has started, the washing light will be on
and the program duration will be displayed.
If you open the door of the machine whilst
the program is continuing, program number
and program duration will be displayed
alternately (7).
You can follow the program ow with the
washing, rinsing, drying and end lights (8)
on the control panel. Once the drying light
has switched on, the machine will remain
silent for 40 to 50 minutes.
NOTE: If you press the option button
(3) once, half load option will be activated.
This option will shorten the durations of
the selected programs to reduce power
and water consumption. If you are using
combined detergents that contain salt, rinse
aid and extra features, press the option
button for the second time and activate
the tablet function. You can use the extra
button (1) to add the following functions to
the compatible washing program.
If you want to change the delay time, press
the Start/Pause button rst, and then press
the Delay (2) button to select the new delay
time. Press Start/Pause button to activate
the new delay time. To cancel the delay,
press the Delay button until the delay time
is 0h.
When the hygiene function is active,
you can make the washing process
more hygienic by changing the washing
temperature and durations of the current
program.
If you select the extra rinsing function,
the extra rinsing light will switch on and
additional rinses will be added to the
selected program, making your dishes
cleaner and shinier.
If you select the extra drying function, the
extra drying light will switch on and the
drying duration of the selected program will
extend, making your dishes drier.
IMPORTANT: Hygiene and Drying
functions cannot be selected at the same
time since they are incompatible with each
other.
If you have used any extra function in the
washing program, the function will still
be active in the next washing program. If
you want to cancel that function for the
newly selected program, press and hold
the button of the relevant function until the
corresponding lights go o, or press the
On/O button (4) to switch o the machine.
If you want to use an extra function for the
newly selected program, select the desired
functions.
NOTE: If you switch o the machine
after selecting the delay time and starting
the program, the delay time will be
cancelled.
EN - 24
NOTE: You can press the delay button
(2) before the program starts to delay the
program start time for 1 to 19 hours.
NOTE: Power On indicator (10) will be
on during the machine is energized.
NOTE: Rinse aid refill indicator (10)
will light if rinse aid is missing/insufficient.
In this case, please fill the rinse aid
compartment.
Using the Child Lock
Press “Extra” and “Option” keys
simultaneously for 3 seconds to activate
Child Lock. At that time, on the remaining
time indicator, “CL” is displayed for 2
seconds. To deactivate this function, again,
press “Extra” and “Option” keys at the
same time for 3 seconds. “CL” will flash
twice.
7.1 Changing the Program
When you want to change the program
whilst a wash cycle is in progress.
Press Start/Pause button.
Once the program has stopped,
use the program selection button to
select the desired program.
Press the Start/Pause button to
start the newly selected program.
The newly selected program
will continue in the place of the
previous program.
7.2 Cancelling the Program
When you want to cancel the program
while a washing cycle is in progress.
Press and hold the Start/Pause
button for 3 seconds.
End light will flash during the cancelling
process. The machine will drain the
water inside for about 30 seconds.
After the End light has lit, press
the On/Off button
to switch off the machine.
Unplug the appliance. Turn
off the water tap.
NOTE: Do not open the door until the
program finishes.
NOTE: At the end of the washing pro-
gram, you can leave the door of the machine
ajar to speed up the drying process.
NOTE: If you open the door of the ma-
chine or if power gets cut during the washing
cycle, the program will resume once the door
has been closed or the power has recovered.
EN - 25
8 CLEANING AND
MAINTENANCE
Cleaning your dishwasher is important to
maintain the machine’s service life
Make sure that the water softening setting
(If available) is done correctly and correct
amount of detergent is used to prevent
limescale accumulation. Rell the salt
compartment when the salt sensor light
comes on.Oil and limescale may build up in
your Dishwasher over time. If this occurs:
• Fill the detergent compartment
but do not load any dishes. Select
a programme which runs at high
temperature and run the Dishwasher
empty. If this does not clean your
Dishwasher sufficiently, use a
cleaning agent designed for use with
dishwashers.
• To extend the life of your dishwasher,
clean the appliance regularly on each
month
• Wipe the door seals regularly with a
damp cloth to remove any accumulated
residue or foreign objects.
8.1 Filters
Clean the lters and spray arms at least
once a week. If any food waste remains
or foreign objects on the coarse and
ne lters, remove them and clean them
thoroughly with water.
a) Micro Filter b)
Coarse Filter
c) Metal Filter
3 4
1 2
a
c
b
To remove and clean the lter combination,
turn it counter clockwise and remove it by
lifting it upwards (1).Pull the coarse lter out
of the micro lter (2).Then pull and remove
the metal lter (3).Rinse the lter with lots of
water until it is free of residue. Reassemble
the lters. Replace the lter insert, and
rotate it clockwise (4).
• Never use your dishwasher without a
filter.
• Incorrect fitting of the filter will reduce
the washing effectiveness.
• Clean filters are necessary for proper
running of the machine.
8.2 Spray Arms
Make sure that the spray holes are not
clogged and that no food waste or foreign
object is stuck to the spray arms. If there is
any clogging,remove the spray arms and
clean them under water. To remove the
upper spray arm undo the nut holding it in
position by turning it clockwise and pulling
it downwards. Make sure that the nut is
properly tightened when retting the upper
spray arm.
EN - 26
8.3 Drain Pump
Large food residues or foreign objects
which were not captured by the filters may
block the waste water pump. The rinsing
water will then be above the filter.
Warning Risk of cuts!
When cleaning the waste water pump,
ensure that you do not injure yourself on p
ieces of broken glass or pointed
implements.
In this case:
1. First always disconnect the appliance
from the power supply.
2. Take out baskets.
3. Remove the filters.
4. Scoop out water, use a sponge if requi-
red.
5.Check the area and remove any foreign
objects.
6. Install filters.
7. Re-insert baskets.
EN - 27
EN - 28
9 TROUBLESHOOTING
FAULT POSSIBLE CAUSE TROUBLESHOOTING
The programme does
not start.
Your Dishwasher is not plugged in. Plug your Dishwasher in.
Your Dishwasher is not switched on.
Switch your Dishwasher on by pressing the
On/O button.
Fuse blown. Check your indoor fuses.
Water inlet tap is closed. Turn on the water inlet tap.
Your Dishwasher door is open. Close the Dishwasher door.
Water inlet hose and machine lters
are clogged.
Check the water inlet hose and machine
lters and make sure they are not clogged.
Water remains inside
the machine.
Water drain hose is clogged or
twisted.
Check the drain hose, then either clean or
untwist it.
The lters are clogged. Clean the lters.
The programme is not nished yet. Wait until the programme is nished.
Machine stops during
washing.
Power failure. Check mains power.
Water inlet failure. Check water tap.
Shaking and hitting
noises are heard during
a wash operation.
The spray arm is hitting the dishes in
the lower basket.
Move or remove items blocking the spray
arm.
Partial food wastes
remain on the dishes.
Dishes placed incorrectly, sprayed
water not reaching aected dishes.
Do not overload baskets.
Dishes leaning each another.
Place dishes as instructed in the section on
loading your dishwasher.
Not enough detergent used.
Use the correct amount of detergent, as
instructed in the programme table.
Wrong wash programme selected.
Use the information in the programme table
to select the most appropriate programme.
Spray arms clogged with food waste.
Clean the holes in the spray arms with thin
objects.
Filters or water drain pump clogged
or lter misplaced.
Check the drain hose and lters are
correctly tted.
EN - 29
FAULT POSSIBLE CAUSE TROUBLESHOOTING
Whitish stains remains
on dishes.
Not enough detergent used.
Use the correct amount of detergent, as
instructed in the programme table.
Rinse aid dosage and/or water
softener setting set too low.
Increase rinse aid and/or water softener
level.
High water hardness level. Increase water softerner level and add salt.
Salt compartment cap not closed
properly.
Check that the salt compartment cap is
closed properly.
Dishes do not dry.
Drying option is not selected. Select a programme with a drying option.
Rinse aid dosage set too low. Increase rinse aid dosage setting.
Rust stains form on the
dishes.
Stainless-steel quality of the dishes
is insucient.
Use only dishwasher-proof sets.
High level of salt in wash water.
Adjust the water hardness level using water
hardness table.
Salt compartment cap not closed
properly.
Check that the salt compartment cap is
closed properly.
Too much salt spilled in the
Dishwasher while lling it with salt.
Use funnel while lling salt to the
compartment to avoid spillage.
A poor mains grounding. Consult a qualied electrician immediately.
Detergent remains in the
detergent compartment.
Detergent was added when the
detergent compartment was wet.
Make sure detergent compartment is dry
before use.
EN - 30
AUTOMATIC FAULT WARNINGS AND WHAT TO DO
TROUBLE
CODE
POSSIBLE FAULT WHAT TO DO
F5
Insucient water
Make sure the water inlet tap is open and water is owing
Separate the inlet hose from the tap and clean the lter of
the hose.
Contact for service if the error continues.
F3
Continuous water input
Close the tap and contact for service.
F2
Inability to discharge water
Water discharge hose and lters may be clogged.
Cancel the program.
If the error continues, contact for service.
F8
Heater error
Contact for service.
F1 Overow
Unplug the machine and close the tap.
Contact for service.
FE Faulty electronic card Contact for service.
F7 Overheating Contact for service.
F9 Divisor position error Contact for service.
F6 Faulty heater sensor Contact for service.
The installation and repairing procedures should always carried out by the Authorised
Service Agent in order to avoid possible risks. The manufacturer shall not be held liable
for damages that may arise from procedures carried out by unauthorised persons. Repairs
may be carried out by technicians only. If a component has to be replaced, ensure that only
original spare parts are used.
Improper repairs or use of non-original spare parts may cause considerable damage and
put the user at considerable risk.
Contact information for your customer service can be found on the back of this document.
Function-relevant genuine spare parts according to the corresponding Ecodesign order can
be obtained from Customer Service for a period of at least 10 years from the date on which
your appliance was placed on the market within the European Economic Area.
EN - 31
XXXXXXXXXXX
