instructions for
rollcabs 6-10 drawer
model no’s: aP2406, aP2408, aP2410
Thank you for purchasing a sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. saFeTY
warNING! ensure Health & safety, local authority, and general workshop practice regulations are adhered to when using this product.
8 do NoT open more than one drawer at a time.
8 do NoT step on the drawers.
8 do NoT let children play with the roll cab.
9 ensure all drawers are fully closed and the self locking catches are activated, before moving the toolbox.
9 secure the brakes when rollcab is in the desired position.
9 Keep the work area clean, uncluttered and ensure there is adequate lighting.
8 do NoT use in damp work areas.
warNING! the warnings, cautions and instructions referred to in this instruction manual cannot cover all possible conditions and
situations that may occur. it must be understood that common sense and caution are factors which cannot be built into this product, but
must be applied by the operator.
2. INTroducTIoN
Heavy gauge steel with double wall construction for extra strength and durability. Ball bearing drawer runners provide superior performance and
carry heavier loads. Each drawer tted with catch to prevent accidental opening when being transported around the workshop. Added security
provided by side mounted cylinder lock, supplied with two keys. rubber grip side handles for comfort and ease when manoeuvring. rust and
solvent resistant powder coat paint nish. Fitted with anti-shock protection on all four corners to prevent accidental damage. Features two
Ø125mm swivel castors with large toe locks and two xed wheels. Tough composite top for tting and securing top box or can be used as a
workstation. Unique design tted with perforated side panels for hanging tools and accessories.
3. sPecIFIcaTIoN
Original Language Version
© Jack sealey limited
refer to
instruction
manual
model no AP2406 AP2408 AP2410
overall size
Width 765mm 765mm 765mm
depth 465mm 465mm 465mm
Height 960mm 960mm 960mm
drawers (Qty)
medium 3 6 10
large 2 2
X - Large 1
drawer Width 535mm 535mm 535mm
drawer depth 390mm 390mm 390mm
drawer Height (medium) 60mm 60mm 60mm
drawer Height (large) 130mm 130mm
Drawer Height (X - Large) 195mm
AP2406, AP2408, AP2410 Issue:4(F) 23/04/18
4. accessorIes
5. oPeraTIoN
5.1. each drawer is fitted with a catch mechanism on the right hand side, underneath the handle. to open drawer push the catch to the left to
release it and pull the drawer open (fig.1).
warNING! only open one drawer at a time and do NoT overload the drawers, fig.2 shows the maximum weight per drawer size.
5.2. When moving the rollcab, ensure that the drawers are closed and locked (fig.3) to prevent accidental opening, release the brakes as
shown in fig.4 and move the rollcab using the handles to maintain full control. When the rollcab has been moved to the required location,
lock the brakes.
warNING! do NoT move across slopes of more than 5° as the rollcab may tilt over.
Original Language Version
© Jack sealey limited
sealey Group, Kempson way, suffolk business Park, bury st edmunds, suffolk. IP32 7ar
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
Note: it is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: no liability is accepted for incorrect use of this product.
warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
eNvIroNMeNT ProTecTIoN
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Parts support is available for this product. Please email sales@sealey.co.uk or telephone 01284 757500
AP2406, AP2408, AP2410 Issue:4(F) 23/04/18
Optional Accessories
model no description
AP24ACC1 Perforated Storage Panel
AP24ACC2 Side Shelf with Paper Roll Holder
AP24ACC3 document Holder
AP24ACC4 Waste Bin
AP24ACC5 can and Bottle Holder
AP24ACC6 Drawer Divider 3 x 395 x 58mm
AP24ACC7 Drawer Divider 3 x 395 x 120mm
AP24ACC9 Short Hook Set x 10pcs
AP24ACC10 Medium Hook Set x 10pcs
Fig.1
Fig.2
Fig.3
Fig.4
