How to Use
This appliance is intended for household use only.
GETTING STARTED
Remove any labels, stickers, or tags attached to the body or soleplate of the iron.
Important: For optimum performance, let the iron stand for 90 seconds before beginning to iron.
Note: Use ordinary tap water for ironing. Do not use water processed through a home
softening system.
FILLING THE WATER TANK
1. Grasp the water-fill cover and pull it out to expose the water-fill opening.
2. Tilt the iron and use a clean measuring cup to pour water into opening until the water
reaches the "MAX" mark on the water tank. Do not overfill.
Important: Be careful not to overfi ll the iron. Do not add water beyond the "MAX" mark
on the water tank. This may cause water to spill out of the soleplate.
3. After filling, be sure to push the water-fill cover securely back into the water-fill opening.
4. Plug in the iron.
Tip: If you are unsure of a garment’s fiber, test a small area on an inside seam or hem)
before ironing.
INDICATOR LIGHT
The Indicator Light will illuminate when a temperature setting is selected. Once the soleplate has
reached the selected temperature, the Indicator Light will darken.
STEAM IRONING
1. Turn the fabric select dial to an appropriate setting (between 4 and 6) for your fabric.
Read garment’s label to help you determine fabric type. Be sure there is water in
the reservoir.
2. When finished ironing, turn the fabric select dial to "MIN" and unplug the iron.
Important: Always stand the iron on its heel rest when powered on but not in use.
Product may vary slightly from what is illustrated.
Please Read and Save this Use and Care Book.
IMPORTANT SAFEGUARDS
When using your iron, basic safety precautions should always be followed,
including the following:
❍ READ ALL INSTRUCTIONS BEFORE USING.
❍ Only use this iron for its intended use.
❍ To avoid the risk of electric shock, do not immerse the iron in water or other liquids.
❍ Always turn the iron off before plugging it into or unplugging it from an electrical
outlet. Never pull on the cord to disconnect the iron from the electrical outlet;
instead, grasp the plug and pull on the plug to disconnect the iron.
❍ Do not let the cord touch hot surfaces. Let the iron cool completely before putting
the iron away. Coil the cord loosely around the iron when storing.
❍ Always disconnect the iron from the electrical outlet before filling the iron with
water. Empty the water tank from the iron when the iron is not in use.
❍ Do not operate the iron with a damaged cord or in the event the iron has been
dropped or damged. To avoid the risk of electric shock, do not disassemble the iron.
Take it to a qualified serviceperson for examination and repair. Incorrect assembly
might result in a risk of electric shock when the iron is used after reassembly.
❍ Close supervision is necessary for any appliance used by or near children. Do not
leave the iron unattended while the iron is connected or on an ironing board.
❍ Burns can occur from touching hot metal parts, hot water or steam. Use caution
when you turn a steam iron upside down; there might be hot water in the reservoir.
❍ This appliance is not intended for use by people (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
❍ Children should be supervised to ensure that they do not play with the appliance.
❍ The iron must be used and rested on a stable surface.
- When placing the iron on its stand, ensure that the surface on which the stand
is placed is stable.
- The iron is not to be used if it has been dropped, if there are visible signs of
damage, or if it is leaking.
❍ The iron must not be left unattended while it is connected to the electrical outlet.
❍ The plug must be removed from the electrical outlet before the water reservoir is
filled with water.
❍ To avoid a circuit overload, do not operate an iron on the same circuit with another
high-wattage appliance.
❍ If an extension cord is absolutely necessary, a cord with an ampere rating equal to
or greater than the maximum rating of the iron should be used. A cord rated for
less amperage can result in a risk of fire or electric shock due to overheating. Care
shall be taken to arrange the cord so that it cannot be pulled or be tripped over.
SAVE THESE INSTRUCTIONS.
This product is for household use only.
POLARIZED PLUG (120V models only)
This appliance has a polarized plug (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended to fit
into a polarized outlet only one way. If the plug does not fit fully into
the outlet, reverse the plug. If it still does not fit, contact a qualified
electrician. Do not attempt to modify the plug in any way.
TAMPER-RESISTANT SCREW
Warning: This appliance is equipped with a tamper-resistant screw
to prevent removal of the outer cover. To reduce the risk of fire or
electric shock, do not attempt to remove the outer cover. There are
no user-serviceable parts inside. Repair should be done only by
authorized service personnel.
Note: If the power supply cord is damaged, it should be replaced by
qualified personnel; in Latin America, by an authorized service center.
1. Spray Nozzle
2. Water-Fill Opening
3. Steam Selector
4. Auto Clean Button
5. Spray Button
6. Steam Surge Button
7. Handle
8. Pivoting Cord
9. Heel Rest
10. Fabric And Temperature Dial
11. Water Tank
12. Ceramicglide
tm
Soleplate
13. Indicator Light
SPRAY
Use to dampen tough wrinkles at any setting.
1. Be sure the iron is filled with water.
2. On first use, pump the spray button a few times.
SURGE OF STEAM
Horizontal
Tip: Use to remove stubborn creases.
1. With the water tank filled to the "MAX" mark, set the fabric select dial to an appropriate
setting (between 4 and 6) for your fabric. Read garment’s label to help you determine
fabric type. Be sure there is water in the reservoir.
2. For best performance, use surge of steam at 5-second intervals.
3. When finished ironing, turn the fabric select dial to "MIN" and unplug the iron.
Important: Always stand the iron on its heel rest when powered on but not in use.
Vertical
Tip: Use for removing wrinkles from hanging clothes and drapes.
1. Be sure the water tank is filled to the "MAX" mark.
2. Hang the garment to be steamed on a clothes hanger (curtains or drapes can be steamed
once they are hung).
3. Set the fabric select dial to appropriate setting (between 5 and 6) for your fabric.
4. Hold the iron close to (but not touching) the fabric.
5. Pull the fabric tight in your free hand and press the button as you move the iron over
the fabric.
DRY IRONING
1. Turn the steam/dry selector to dry ( ).
2. Turn the fabric select dial to an appropriate setting for your fabric.
3. When you are finished ironing, make sure to unplug the iron.
EMPTYING THE WATER TANK
Note: It is not necessary to empty the water after each use.
1. Unplug the iron and let it cool.
2. If you want to empty the water, hold the iron over a sink with the tip pointing down.
Water will empty out of the water-fill opening.
Care and Cleaning
This product contains no user serviceable parts. Refer service to qualified service personnel.
CLEANING OUTSIDE SURFACES
1. Make sure iron is unplugged and has cooled completely.
2. Wipe the soleplate and outer surfaces with a soft cloth dampened with water and mild
household detergent.
3. Never use abrasives, heavy-duty cleansers, vinegar or scouring pads that may scratch or
discolor the iron.
4. After cleaning, steam iron over an old cloth to remove any residue from the steam vents.
AUTO-CLEAN™ SYSTEM
Tip: To keep the steam vents free of any buildup, follow these instructions about once
a month:
1. Fill the water tank well below the "MAX" line. Plug in the iron.
2. Turn the fabric select dial to 6 and stand the iron on its heel rest. Allow it to heat.
3. Turn fabric select dial to "MIN," unplug the iron, and hold the iron over a sink with the
soleplate facing downward.
4. Press and hold the AUTO-CLEAN™ button. Be careful, as hot water and steam will come
out of the steam vents. Continue to hold the AUTO-CLEAN™ button until all the water has
emptied. If necessary, rock iron side-to-side and front-to-back.
5. When finished, release the button, stand the iron on its heel rest and plug it in. Heat for
about 2 minutes to dry out any remaining water.
STORING YOUR IRON
1. Check that the fabric select dial is set to "MIN."
2. Unplug the iron and let it cool completely.
3. Store the iron on its heel rest. Storing iron on its soleplate can cause leaks or damage.
MINERAL GLIDE
MOONSTONE
MINERAL GLIDE
MOONSTONE
How to Use
This appliance is intended for household use only.
GETTING STARTED
Remove any labels, stickers, or tags attached to the body or soleplate of the iron.
Important: For optimum performance, let the iron stand for 90 seconds before beginning to iron.
Note: Use ordinary tap water for ironing. Do not use water processed through a home
softening system.
FILLING THE WATER TANK
1. Grasp the water-fill cover and pull it out to expose the water-fill opening.
2. Tilt the iron and use a clean measuring cup to pour water into opening until the water
reaches the "MAX" mark on the water tank. Do not overfill.
Important: Be careful not to overfi ll the iron. Do not add water beyond the "MAX" mark
on the water tank. This may cause water to spill out of the soleplate.
3. After filling, be sure to push the water-fill cover securely back into the water-fill opening.
4. Plug in the iron.
Tip: If you are unsure of a garment’s fiber, test a small area on an inside seam or hem)
before ironing.
INDICATOR LIGHT
The Indicator Light will illuminate when a temperature setting is selected. Once the soleplate has
reached the selected temperature, the Indicator Light will darken.
STEAM IRONING
1. Turn the fabric select dial to an appropriate setting (between 4 and 6) for your fabric.
Read garment’s label to help you determine fabric type. Be sure there is water in
the reservoir.
2. When finished ironing, turn the fabric select dial to "MIN" and unplug the iron.
Important: Always stand the iron on its heel rest when powered on but not in use.
Product may vary slightly from what is illustrated.
Please Read and Save this Use and Care Book.
IMPORTANT SAFEGUARDS
When using your iron, basic safety precautions should always be followed,
including the following:
❍ READ ALL INSTRUCTIONS BEFORE USING.
❍ Only use this iron for its intended use.
❍ To avoid the risk of electric shock, do not immerse the iron in water or other liquids.
❍ Always turn the iron off before plugging it into or unplugging it from an electrical
outlet. Never pull on the cord to disconnect the iron from the electrical outlet;
instead, grasp the plug and pull on the plug to disconnect the iron.
❍ Do not let the cord touch hot surfaces. Let the iron cool completely before putting
the iron away. Coil the cord loosely around the iron when storing.
❍ Always disconnect the iron from the electrical outlet before filling the iron with
water. Empty the water tank from the iron when the iron is not in use.
❍ Do not operate the iron with a damaged cord or in the event the iron has been
dropped or damged. To avoid the risk of electric shock, do not disassemble the iron.
Take it to a qualified serviceperson for examination and repair. Incorrect assembly
might result in a risk of electric shock when the iron is used after reassembly.
❍ Close supervision is necessary for any appliance used by or near children. Do not
leave the iron unattended while the iron is connected or on an ironing board.
❍ Burns can occur from touching hot metal parts, hot water or steam. Use caution
when you turn a steam iron upside down; there might be hot water in the reservoir.
❍ This appliance is not intended for use by people (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
❍ Children should be supervised to ensure that they do not play with the appliance.
❍ The iron must be used and rested on a stable surface.
- When placing the iron on its stand, ensure that the surface on which the stand
is placed is stable.
- The iron is not to be used if it has been dropped, if there are visible signs of
damage, or if it is leaking.
❍ The iron must not be left unattended while it is connected to the electrical outlet.
❍ The plug must be removed from the electrical outlet before the water reservoir is
filled with water.
❍ To avoid a circuit overload, do not operate an iron on the same circuit with another
high-wattage appliance.
❍ If an extension cord is absolutely necessary, a cord with an ampere rating equal to
or greater than the maximum rating of the iron should be used. A cord rated for
less amperage can result in a risk of fire or electric shock due to overheating. Care
shall be taken to arrange the cord so that it cannot be pulled or be tripped over.
SAVE THESE INSTRUCTIONS.
This product is for household use only.
POLARIZED PLUG (120V models only)
This appliance has a polarized plug (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended to fit
into a polarized outlet only one way. If the plug does not fit fully into
the outlet, reverse the plug. If it still does not fit, contact a qualified
electrician. Do not attempt to modify the plug in any way.
TAMPER-RESISTANT SCREW
Warning: This appliance is equipped with a tamper-resistant screw
to prevent removal of the outer cover. To reduce the risk of fire or
electric shock, do not attempt to remove the outer cover. There are
no user-serviceable parts inside. Repair should be done only by
authorized service personnel.
Note: If the power supply cord is damaged, it should be replaced by
qualified personnel; in Latin America, by an authorized service center.
1. Spray Nozzle
2. Water-Fill Opening
3. Steam Selector
4. Auto Clean Button
5. Spray Button
6. Steam Surge Button
7. Handle
8. Pivoting Cord
9. Heel Rest
10. Fabric And Temperature Dial
11. Water Tank
12. Ceramicglide
tm
Soleplate
13. Indicator Light
SPRAY
Use to dampen tough wrinkles at any setting.
1. Be sure the iron is filled with water.
2. On first use, pump the spray button a few times.
SURGE OF STEAM
Horizontal
Tip: Use to remove stubborn creases.
1. With the water tank filled to the "MAX" mark, set the fabric select dial to an appropriate
setting (between 4 and 6) for your fabric. Read garment’s label to help you determine
fabric type. Be sure there is water in the reservoir.
2. For best performance, use surge of steam at 5-second intervals.
3. When finished ironing, turn the fabric select dial to "MIN" and unplug the iron.
Important: Always stand the iron on its heel rest when powered on but not in use.
Vertical
Tip: Use for removing wrinkles from hanging clothes and drapes.
1. Be sure the water tank is filled to the "MAX" mark.
2. Hang the garment to be steamed on a clothes hanger (curtains or drapes can be steamed
once they are hung).
3. Set the fabric select dial to appropriate setting (between 5 and 6) for your fabric.
4. Hold the iron close to (but not touching) the fabric.
5. Pull the fabric tight in your free hand and press the button as you move the iron over
the fabric.
DRY IRONING
1. Turn the steam/dry selector to dry ( ).
2. Turn the fabric select dial to an appropriate setting for your fabric.
3. When you are finished ironing, make sure to unplug the iron.
EMPTYING THE WATER TANK
Note: It is not necessary to empty the water after each use.
1. Unplug the iron and let it cool.
2. If you want to empty the water, hold the iron over a sink with the tip pointing down.
Water will empty out of the water-fill opening.
Care and Cleaning
This product contains no user serviceable parts. Refer service to qualified service personnel.
CLEANING OUTSIDE SURFACES
1. Make sure iron is unplugged and has cooled completely.
2. Wipe the soleplate and outer surfaces with a soft cloth dampened with water and mild
household detergent.
3. Never use abrasives, heavy-duty cleansers, vinegar or scouring pads that may scratch or
discolor the iron.
4. After cleaning, steam iron over an old cloth to remove any residue from the steam vents.
AUTO-CLEAN™ SYSTEM
Tip: To keep the steam vents free of any buildup, follow these instructions about once
a month:
1. Fill the water tank well below the "MAX" line. Plug in the iron.
2. Turn the fabric select dial to 6 and stand the iron on its heel rest. Allow it to heat.
3. Turn fabric select dial to "MIN," unplug the iron, and hold the iron over a sink with the
soleplate facing downward.
4. Press and hold the AUTO-CLEAN™ button. Be careful, as hot water and steam will come
out of the steam vents. Continue to hold the AUTO-CLEAN™ button until all the water has
emptied. If necessary, rock iron side-to-side and front-to-back.
5. When finished, release the button, stand the iron on its heel rest and plug it in. Heat for
about 2 minutes to dry out any remaining water.
STORING YOUR IRON
1. Check that the fabric select dial is set to "MIN."
2. Unplug the iron and let it cool completely.
3. Store the iron on its heel rest. Storing iron on its soleplate can cause leaks or damage.
MINERAL GLIDE
MOONSTONE
MINERAL GLIDE
MOONSTONE
How to Use
This appliance is intended for household use only.
GETTING STARTED
Remove any labels, stickers, or tags attached to the body or soleplate of the iron.
Important: For optimum performance, let the iron stand for 90 seconds before beginning to iron.
Note: Use ordinary tap water for ironing. Do not use water processed through a home
softening system.
FILLING THE WATER TANK
1. Grasp the water-fill cover and pull it out to expose the water-fill opening.
2. Tilt the iron and use a clean measuring cup to pour water into opening until the water
reaches the "MAX" mark on the water tank. Do not overfill.
Important: Be careful not to overfi ll the iron. Do not add water beyond the "MAX" mark
on the water tank. This may cause water to spill out of the soleplate.
3. After filling, be sure to push the water-fill cover securely back into the water-fill opening.
4. Plug in the iron.
Tip: If you are unsure of a garment’s fiber, test a small area on an inside seam or hem)
before ironing.
INDICATOR LIGHT
The Indicator Light will illuminate when a temperature setting is selected. Once the soleplate has
reached the selected temperature, the Indicator Light will darken.
STEAM IRONING
1. Turn the fabric select dial to an appropriate setting (between 4 and 6) for your fabric.
Read garment’s label to help you determine fabric type. Be sure there is water in
the reservoir.
2. When finished ironing, turn the fabric select dial to "MIN" and unplug the iron.
Important: Always stand the iron on its heel rest when powered on but not in use.
Product may vary slightly from what is illustrated.
Please Read and Save this Use and Care Book.
IMPORTANT SAFEGUARDS
When using your iron, basic safety precautions should always be followed,
including the following:
❍ READ ALL INSTRUCTIONS BEFORE USING.
❍ Only use this iron for its intended use.
❍ To avoid the risk of electric shock, do not immerse the iron in water or other liquids.
❍ Always turn the iron off before plugging it into or unplugging it from an electrical
outlet. Never pull on the cord to disconnect the iron from the electrical outlet;
instead, grasp the plug and pull on the plug to disconnect the iron.
❍ Do not let the cord touch hot surfaces. Let the iron cool completely before putting
the iron away. Coil the cord loosely around the iron when storing.
❍ Always disconnect the iron from the electrical outlet before filling the iron with
water. Empty the water tank from the iron when the iron is not in use.
❍ Do not operate the iron with a damaged cord or in the event the iron has been
dropped or damged. To avoid the risk of electric shock, do not disassemble the iron.
Take it to a qualified serviceperson for examination and repair. Incorrect assembly
might result in a risk of electric shock when the iron is used after reassembly.
❍ Close supervision is necessary for any appliance used by or near children. Do not
leave the iron unattended while the iron is connected or on an ironing board.
❍ Burns can occur from touching hot metal parts, hot water or steam. Use caution
when you turn a steam iron upside down; there might be hot water in the reservoir.
❍ This appliance is not intended for use by people (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
❍ Children should be supervised to ensure that they do not play with the appliance.
❍ The iron must be used and rested on a stable surface.
- When placing the iron on its stand, ensure that the surface on which the stand
is placed is stable.
- The iron is not to be used if it has been dropped, if there are visible signs of
damage, or if it is leaking.
❍ The iron must not be left unattended while it is connected to the electrical outlet.
❍ The plug must be removed from the electrical outlet before the water reservoir is
filled with water.
❍ To avoid a circuit overload, do not operate an iron on the same circuit with another
high-wattage appliance.
❍ If an extension cord is absolutely necessary, a cord with an ampere rating equal to
or greater than the maximum rating of the iron should be used. A cord rated for
less amperage can result in a risk of fire or electric shock due to overheating. Care
shall be taken to arrange the cord so that it cannot be pulled or be tripped over.
SAVE THESE INSTRUCTIONS.
This product is for household use only.
POLARIZED PLUG (120V models only)
This appliance has a polarized plug (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended to fit
into a polarized outlet only one way. If the plug does not fit fully into
the outlet, reverse the plug. If it still does not fit, contact a qualified
electrician. Do not attempt to modify the plug in any way.
TAMPER-RESISTANT SCREW
Warning: This appliance is equipped with a tamper-resistant screw
to prevent removal of the outer cover. To reduce the risk of fire or
electric shock, do not attempt to remove the outer cover. There are
no user-serviceable parts inside. Repair should be done only by
authorized service personnel.
Note: If the power supply cord is damaged, it should be replaced by
qualified personnel; in Latin America, by an authorized service center.
1. Spray Nozzle
2. Water-Fill Opening
3. Steam Selector
4. Auto Clean Button
5. Spray Button
6. Steam Surge Button
7. Handle
8. Pivoting Cord
9. Heel Rest
10. Fabric And Temperature Dial
11. Water Tank
12. Ceramicglide
tm
Soleplate
13. Indicator Light
SPRAY
Use to dampen tough wrinkles at any setting.
1. Be sure the iron is filled with water.
2. On first use, pump the spray button a few times.
SURGE OF STEAM
Horizontal
Tip: Use to remove stubborn creases.
1. With the water tank filled to the "MAX" mark, set the fabric select dial to an appropriate
setting (between 4 and 6) for your fabric. Read garment’s label to help you determine
fabric type. Be sure there is water in the reservoir.
2. For best performance, use surge of steam at 5-second intervals.
3. When finished ironing, turn the fabric select dial to "MIN" and unplug the iron.
Important: Always stand the iron on its heel rest when powered on but not in use.
Vertical
Tip: Use for removing wrinkles from hanging clothes and drapes.
1. Be sure the water tank is filled to the "MAX" mark.
2. Hang the garment to be steamed on a clothes hanger (curtains or drapes can be steamed
once they are hung).
3. Set the fabric select dial to appropriate setting (between 5 and 6) for your fabric.
4. Hold the iron close to (but not touching) the fabric.
5. Pull the fabric tight in your free hand and press the button as you move the iron over
the fabric.
DRY IRONING
1. Turn the steam/dry selector to dry ( ).
2. Turn the fabric select dial to an appropriate setting for your fabric.
3. When you are finished ironing, make sure to unplug the iron.
EMPTYING THE WATER TANK
Note: It is not necessary to empty the water after each use.
1. Unplug the iron and let it cool.
2. If you want to empty the water, hold the iron over a sink with the tip pointing down.
Water will empty out of the water-fill opening.
Care and Cleaning
This product contains no user serviceable parts. Refer service to qualified service personnel.
CLEANING OUTSIDE SURFACES
1. Make sure iron is unplugged and has cooled completely.
2. Wipe the soleplate and outer surfaces with a soft cloth dampened with water and mild
household detergent.
3. Never use abrasives, heavy-duty cleansers, vinegar or scouring pads that may scratch or
discolor the iron.
4. After cleaning, steam iron over an old cloth to remove any residue from the steam vents.
AUTO-CLEAN™ SYSTEM
Tip: To keep the steam vents free of any buildup, follow these instructions about once
a month:
1. Fill the water tank well below the "MAX" line. Plug in the iron.
2. Turn the fabric select dial to 6 and stand the iron on its heel rest. Allow it to heat.
3. Turn fabric select dial to "MIN," unplug the iron, and hold the iron over a sink with the
soleplate facing downward.
4. Press and hold the AUTO-CLEAN™ button. Be careful, as hot water and steam will come
out of the steam vents. Continue to hold the AUTO-CLEAN™ button until all the water has
emptied. If necessary, rock iron side-to-side and front-to-back.
5. When finished, release the button, stand the iron on its heel rest and plug it in. Heat for
about 2 minutes to dry out any remaining water.
STORING YOUR IRON
1. Check that the fabric select dial is set to "MIN."
2. Unplug the iron and let it cool completely.
3. Store the iron on its heel rest. Storing iron on its soleplate can cause leaks or damage.
MINERAL GLIDE
MOONSTONE
MINERAL GLIDE
MOONSTONE
How to Use
This appliance is intended for household use only.
GETTING STARTED
Remove any labels, stickers, or tags attached to the body or soleplate of the iron.
Important: For optimum performance, let the iron stand for 90 seconds before beginning to iron.
Note: Use ordinary tap water for ironing. Do not use water processed through a home
softening system.
FILLING THE WATER TANK
1. Grasp the water-fill cover and pull it out to expose the water-fill opening.
2. Tilt the iron and use a clean measuring cup to pour water into opening until the water
reaches the "MAX" mark on the water tank. Do not overfill.
Important: Be careful not to overfi ll the iron. Do not add water beyond the "MAX" mark
on the water tank. This may cause water to spill out of the soleplate.
3. After filling, be sure to push the water-fill cover securely back into the water-fill opening.
4. Plug in the iron.
Tip: If you are unsure of a garment’s fiber, test a small area on an inside seam or hem)
before ironing.
INDICATOR LIGHT
The Indicator Light will illuminate when a temperature setting is selected. Once the soleplate has
reached the selected temperature, the Indicator Light will darken.
STEAM IRONING
1. Turn the fabric select dial to an appropriate setting (between 4 and 6) for your fabric.
Read garment’s label to help you determine fabric type. Be sure there is water in
the reservoir.
2. When finished ironing, turn the fabric select dial to "MIN" and unplug the iron.
Important: Always stand the iron on its heel rest when powered on but not in use.
Product may vary slightly from what is illustrated.
Please Read and Save this Use and Care Book.
IMPORTANT SAFEGUARDS
When using your iron, basic safety precautions should always be followed,
including the following:
❍ READ ALL INSTRUCTIONS BEFORE USING.
❍ Only use this iron for its intended use.
❍ To avoid the risk of electric shock, do not immerse the iron in water or other liquids.
❍ Always turn the iron off before plugging it into or unplugging it from an electrical
outlet. Never pull on the cord to disconnect the iron from the electrical outlet;
instead, grasp the plug and pull on the plug to disconnect the iron.
❍ Do not let the cord touch hot surfaces. Let the iron cool completely before putting
the iron away. Coil the cord loosely around the iron when storing.
❍ Always disconnect the iron from the electrical outlet before filling the iron with
water. Empty the water tank from the iron when the iron is not in use.
❍ Do not operate the iron with a damaged cord or in the event the iron has been
dropped or damged. To avoid the risk of electric shock, do not disassemble the iron.
Take it to a qualified serviceperson for examination and repair. Incorrect assembly
might result in a risk of electric shock when the iron is used after reassembly.
❍ Close supervision is necessary for any appliance used by or near children. Do not
leave the iron unattended while the iron is connected or on an ironing board.
❍ Burns can occur from touching hot metal parts, hot water or steam. Use caution
when you turn a steam iron upside down; there might be hot water in the reservoir.
❍ This appliance is not intended for use by people (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
❍ Children should be supervised to ensure that they do not play with the appliance.
❍ The iron must be used and rested on a stable surface.
- When placing the iron on its stand, ensure that the surface on which the stand
is placed is stable.
- The iron is not to be used if it has been dropped, if there are visible signs of
damage, or if it is leaking.
❍ The iron must not be left unattended while it is connected to the electrical outlet.
❍ The plug must be removed from the electrical outlet before the water reservoir is
filled with water.
❍ To avoid a circuit overload, do not operate an iron on the same circuit with another
high-wattage appliance.
❍ If an extension cord is absolutely necessary, a cord with an ampere rating equal to
or greater than the maximum rating of the iron should be used. A cord rated for
less amperage can result in a risk of fire or electric shock due to overheating. Care
shall be taken to arrange the cord so that it cannot be pulled or be tripped over.
SAVE THESE INSTRUCTIONS.
This product is for household use only.
POLARIZED PLUG (120V models only)
This appliance has a polarized plug (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended to fit
into a polarized outlet only one way. If the plug does not fit fully into
the outlet, reverse the plug. If it still does not fit, contact a qualified
electrician. Do not attempt to modify the plug in any way.
TAMPER-RESISTANT SCREW
Warning: This appliance is equipped with a tamper-resistant screw
to prevent removal of the outer cover. To reduce the risk of fire or
electric shock, do not attempt to remove the outer cover. There are
no user-serviceable parts inside. Repair should be done only by
authorized service personnel.
Note: If the power supply cord is damaged, it should be replaced by
qualified personnel; in Latin America, by an authorized service center.
1. Spray Nozzle
2. Water-Fill Opening
3. Steam Selector
4. Auto Clean Button
5. Spray Button
6. Steam Surge Button
7. Handle
8. Pivoting Cord
9. Heel Rest
10. Fabric And Temperature Dial
11. Water Tank
12. Ceramicglide
tm
Soleplate
13. Indicator Light
SPRAY
Use to dampen tough wrinkles at any setting.
1. Be sure the iron is filled with water.
2. On first use, pump the spray button a few times.
SURGE OF STEAM
Horizontal
Tip: Use to remove stubborn creases.
1. With the water tank filled to the "MAX" mark, set the fabric select dial to an appropriate
setting (between 4 and 6) for your fabric. Read garment’s label to help you determine
fabric type. Be sure there is water in the reservoir.
2. For best performance, use surge of steam at 5-second intervals.
3. When finished ironing, turn the fabric select dial to "MIN" and unplug the iron.
Important: Always stand the iron on its heel rest when powered on but not in use.
Vertical
Tip: Use for removing wrinkles from hanging clothes and drapes.
1. Be sure the water tank is filled to the "MAX" mark.
2. Hang the garment to be steamed on a clothes hanger (curtains or drapes can be steamed
once they are hung).
3. Set the fabric select dial to appropriate setting (between 5 and 6) for your fabric.
4. Hold the iron close to (but not touching) the fabric.
5. Pull the fabric tight in your free hand and press the button as you move the iron over
the fabric.
DRY IRONING
1. Turn the steam/dry selector to dry ( ).
2. Turn the fabric select dial to an appropriate setting for your fabric.
3. When you are finished ironing, make sure to unplug the iron.
EMPTYING THE WATER TANK
Note: It is not necessary to empty the water after each use.
1. Unplug the iron and let it cool.
2. If you want to empty the water, hold the iron over a sink with the tip pointing down.
Water will empty out of the water-fill opening.
Care and Cleaning
This product contains no user serviceable parts. Refer service to qualified service personnel.
CLEANING OUTSIDE SURFACES
1. Make sure iron is unplugged and has cooled completely.
2. Wipe the soleplate and outer surfaces with a soft cloth dampened with water and mild
household detergent.
3. Never use abrasives, heavy-duty cleansers, vinegar or scouring pads that may scratch or
discolor the iron.
4. After cleaning, steam iron over an old cloth to remove any residue from the steam vents.
AUTO-CLEAN™ SYSTEM
Tip: To keep the steam vents free of any buildup, follow these instructions about once
a month:
1. Fill the water tank well below the "MAX" line. Plug in the iron.
2. Turn the fabric select dial to 6 and stand the iron on its heel rest. Allow it to heat.
3. Turn fabric select dial to "MIN," unplug the iron, and hold the iron over a sink with the
soleplate facing downward.
4. Press and hold the AUTO-CLEAN™ button. Be careful, as hot water and steam will come
out of the steam vents. Continue to hold the AUTO-CLEAN™ button until all the water has
emptied. If necessary, rock iron side-to-side and front-to-back.
5. When finished, release the button, stand the iron on its heel rest and plug it in. Heat for
about 2 minutes to dry out any remaining water.
STORING YOUR IRON
1. Check that the fabric select dial is set to "MIN."
2. Unplug the iron and let it cool completely.
3. Store the iron on its heel rest. Storing iron on its soleplate can cause leaks or damage.
MINERAL GLIDE
MOONSTONE
MINERAL GLIDE
MOONSTONE
How to Use
This appliance is intended for household use only.
GETTING STARTED
Remove any labels, stickers, or tags attached to the body or soleplate of the iron.
Important: For optimum performance, let the iron stand for 90 seconds before beginning to iron.
Note: Use ordinary tap water for ironing. Do not use water processed through a home
softening system.
FILLING THE WATER TANK
1. Grasp the water-fill cover and pull it out to expose the water-fill opening.
2. Tilt the iron and use a clean measuring cup to pour water into opening until the water
reaches the "MAX" mark on the water tank. Do not overfill.
Important: Be careful not to overfi ll the iron. Do not add water beyond the "MAX" mark
on the water tank. This may cause water to spill out of the soleplate.
3. After filling, be sure to push the water-fill cover securely back into the water-fill opening.
4. Plug in the iron.
Tip: If you are unsure of a garment’s fiber, test a small area on an inside seam or hem)
before ironing.
INDICATOR LIGHT
The Indicator Light will illuminate when a temperature setting is selected. Once the soleplate has
reached the selected temperature, the Indicator Light will darken.
STEAM IRONING
1. Turn the fabric select dial to an appropriate setting (between 4 and 6) for your fabric.
Read garment’s label to help you determine fabric type. Be sure there is water in
the reservoir.
2. When finished ironing, turn the fabric select dial to "MIN" and unplug the iron.
Important: Always stand the iron on its heel rest when powered on but not in use.
Product may vary slightly from what is illustrated.
Please Read and Save this Use and Care Book.
IMPORTANT SAFEGUARDS
When using your iron, basic safety precautions should always be followed,
including the following:
❍ READ ALL INSTRUCTIONS BEFORE USING.
❍ Only use this iron for its intended use.
❍ To avoid the risk of electric shock, do not immerse the iron in water or other liquids.
❍ Always turn the iron off before plugging it into or unplugging it from an electrical
outlet. Never pull on the cord to disconnect the iron from the electrical outlet;
instead, grasp the plug and pull on the plug to disconnect the iron.
❍ Do not let the cord touch hot surfaces. Let the iron cool completely before putting
the iron away. Coil the cord loosely around the iron when storing.
❍ Always disconnect the iron from the electrical outlet before filling the iron with
water. Empty the water tank from the iron when the iron is not in use.
❍ Do not operate the iron with a damaged cord or in the event the iron has been
dropped or damged. To avoid the risk of electric shock, do not disassemble the iron.
Take it to a qualified serviceperson for examination and repair. Incorrect assembly
might result in a risk of electric shock when the iron is used after reassembly.
❍ Close supervision is necessary for any appliance used by or near children. Do not
leave the iron unattended while the iron is connected or on an ironing board.
❍ Burns can occur from touching hot metal parts, hot water or steam. Use caution
when you turn a steam iron upside down; there might be hot water in the reservoir.
❍ This appliance is not intended for use by people (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
❍ Children should be supervised to ensure that they do not play with the appliance.
❍ The iron must be used and rested on a stable surface.
- When placing the iron on its stand, ensure that the surface on which the stand
is placed is stable.
- The iron is not to be used if it has been dropped, if there are visible signs of
damage, or if it is leaking.
❍ The iron must not be left unattended while it is connected to the electrical outlet.
❍ The plug must be removed from the electrical outlet before the water reservoir is
filled with water.
❍ To avoid a circuit overload, do not operate an iron on the same circuit with another
high-wattage appliance.
❍ If an extension cord is absolutely necessary, a cord with an ampere rating equal to
or greater than the maximum rating of the iron should be used. A cord rated for
less amperage can result in a risk of fire or electric shock due to overheating. Care
shall be taken to arrange the cord so that it cannot be pulled or be tripped over.
SAVE THESE INSTRUCTIONS.
This product is for household use only.
POLARIZED PLUG (120V models only)
This appliance has a polarized plug (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended to fit
into a polarized outlet only one way. If the plug does not fit fully into
the outlet, reverse the plug. If it still does not fit, contact a qualified
electrician. Do not attempt to modify the plug in any way.
TAMPER-RESISTANT SCREW
Warning: This appliance is equipped with a tamper-resistant screw
to prevent removal of the outer cover. To reduce the risk of fire or
electric shock, do not attempt to remove the outer cover. There are
no user-serviceable parts inside. Repair should be done only by
authorized service personnel.
Note: If the power supply cord is damaged, it should be replaced by
qualified personnel; in Latin America, by an authorized service center.
1. Spray Nozzle
2. Water-Fill Opening
3. Steam Selector
4. Auto Clean Button
5. Spray Button
6. Steam Surge Button
7. Handle
8. Pivoting Cord
9. Heel Rest
10. Fabric And Temperature Dial
11. Water Tank
12. Ceramicglide
tm
Soleplate
13. Indicator Light
SPRAY
Use to dampen tough wrinkles at any setting.
1. Be sure the iron is filled with water.
2. On first use, pump the spray button a few times.
SURGE OF STEAM
Horizontal
Tip: Use to remove stubborn creases.
1. With the water tank filled to the "MAX" mark, set the fabric select dial to an appropriate
setting (between 4 and 6) for your fabric. Read garment’s label to help you determine
fabric type. Be sure there is water in the reservoir.
2. For best performance, use surge of steam at 5-second intervals.
3. When finished ironing, turn the fabric select dial to "MIN" and unplug the iron.
Important: Always stand the iron on its heel rest when powered on but not in use.
Vertical
Tip: Use for removing wrinkles from hanging clothes and drapes.
1. Be sure the water tank is filled to the "MAX" mark.
2. Hang the garment to be steamed on a clothes hanger (curtains or drapes can be steamed
once they are hung).
3. Set the fabric select dial to appropriate setting (between 5 and 6) for your fabric.
4. Hold the iron close to (but not touching) the fabric.
5. Pull the fabric tight in your free hand and press the button as you move the iron over
the fabric.
DRY IRONING
1. Turn the steam/dry selector to dry ( ).
2. Turn the fabric select dial to an appropriate setting for your fabric.
3. When you are finished ironing, make sure to unplug the iron.
EMPTYING THE WATER TANK
Note: It is not necessary to empty the water after each use.
1. Unplug the iron and let it cool.
2. If you want to empty the water, hold the iron over a sink with the tip pointing down.
Water will empty out of the water-fill opening.
Care and Cleaning
This product contains no user serviceable parts. Refer service to qualified service personnel.
CLEANING OUTSIDE SURFACES
1. Make sure iron is unplugged and has cooled completely.
2. Wipe the soleplate and outer surfaces with a soft cloth dampened with water and mild
household detergent.
3. Never use abrasives, heavy-duty cleansers, vinegar or scouring pads that may scratch or
discolor the iron.
4. After cleaning, steam iron over an old cloth to remove any residue from the steam vents.
AUTO-CLEAN™ SYSTEM
Tip: To keep the steam vents free of any buildup, follow these instructions about once
a month:
1. Fill the water tank well below the "MAX" line. Plug in the iron.
2. Turn the fabric select dial to 6 and stand the iron on its heel rest. Allow it to heat.
3. Turn fabric select dial to "MIN," unplug the iron, and hold the iron over a sink with the
soleplate facing downward.
4. Press and hold the AUTO-CLEAN™ button. Be careful, as hot water and steam will come
out of the steam vents. Continue to hold the AUTO-CLEAN™ button until all the water has
emptied. If necessary, rock iron side-to-side and front-to-back.
5. When finished, release the button, stand the iron on its heel rest and plug it in. Heat for
about 2 minutes to dry out any remaining water.
STORING YOUR IRON
1. Check that the fabric select dial is set to "MIN."
2. Unplug the iron and let it cool completely.
3. Store the iron on its heel rest. Storing iron on its soleplate can cause leaks or damage.
MINERAL GLIDE
MOONSTONE
MINERAL GLIDE
MOONSTONE
How to Use
This appliance is intended for household use only.
GETTING STARTED
Remove any labels, stickers, or tags attached to the body or soleplate of the iron.
Important: For optimum performance, let the iron stand for 90 seconds before beginning to iron.
Note: Use ordinary tap water for ironing. Do not use water processed through a home
softening system.
FILLING THE WATER TANK
1. Grasp the water-fill cover and pull it out to expose the water-fill opening.
2. Tilt the iron and use a clean measuring cup to pour water into opening until the water
reaches the "MAX" mark on the water tank. Do not overfill.
Important: Be careful not to overfi ll the iron. Do not add water beyond the "MAX" mark
on the water tank. This may cause water to spill out of the soleplate.
3. After filling, be sure to push the water-fill cover securely back into the water-fill opening.
4. Plug in the iron.
Tip: If you are unsure of a garment’s fiber, test a small area on an inside seam or hem)
before ironing.
INDICATOR LIGHT
The Indicator Light will illuminate when a temperature setting is selected. Once the soleplate has
reached the selected temperature, the Indicator Light will darken.
STEAM IRONING
1. Turn the fabric select dial to an appropriate setting (between 4 and 6) for your fabric.
Read garment’s label to help you determine fabric type. Be sure there is water in
the reservoir.
2. When finished ironing, turn the fabric select dial to "MIN" and unplug the iron.
Important: Always stand the iron on its heel rest when powered on but not in use.
Product may vary slightly from what is illustrated.
Please Read and Save this Use and Care Book.
IMPORTANT SAFEGUARDS
When using your iron, basic safety precautions should always be followed,
including the following:
❍ READ ALL INSTRUCTIONS BEFORE USING.
❍ Only use this iron for its intended use.
❍ To avoid the risk of electric shock, do not immerse the iron in water or other liquids.
❍ Always turn the iron off before plugging it into or unplugging it from an electrical
outlet. Never pull on the cord to disconnect the iron from the electrical outlet;
instead, grasp the plug and pull on the plug to disconnect the iron.
❍ Do not let the cord touch hot surfaces. Let the iron cool completely before putting
the iron away. Coil the cord loosely around the iron when storing.
❍ Always disconnect the iron from the electrical outlet before filling the iron with
water. Empty the water tank from the iron when the iron is not in use.
❍ Do not operate the iron with a damaged cord or in the event the iron has been
dropped or damged. To avoid the risk of electric shock, do not disassemble the iron.
Take it to a qualified serviceperson for examination and repair. Incorrect assembly
might result in a risk of electric shock when the iron is used after reassembly.
❍ Close supervision is necessary for any appliance used by or near children. Do not
leave the iron unattended while the iron is connected or on an ironing board.
❍ Burns can occur from touching hot metal parts, hot water or steam. Use caution
when you turn a steam iron upside down; there might be hot water in the reservoir.
❍ This appliance is not intended for use by people (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
❍ Children should be supervised to ensure that they do not play with the appliance.
❍ The iron must be used and rested on a stable surface.
- When placing the iron on its stand, ensure that the surface on which the stand
is placed is stable.
- The iron is not to be used if it has been dropped, if there are visible signs of
damage, or if it is leaking.
❍ The iron must not be left unattended while it is connected to the electrical outlet.
❍ The plug must be removed from the electrical outlet before the water reservoir is
filled with water.
❍ To avoid a circuit overload, do not operate an iron on the same circuit with another
high-wattage appliance.
❍ If an extension cord is absolutely necessary, a cord with an ampere rating equal to
or greater than the maximum rating of the iron should be used. A cord rated for
less amperage can result in a risk of fire or electric shock due to overheating. Care
shall be taken to arrange the cord so that it cannot be pulled or be tripped over.
SAVE THESE INSTRUCTIONS.
This product is for household use only.
POLARIZED PLUG (120V models only)
This appliance has a polarized plug (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended to fit
into a polarized outlet only one way. If the plug does not fit fully into
the outlet, reverse the plug. If it still does not fit, contact a qualified
electrician. Do not attempt to modify the plug in any way.
TAMPER-RESISTANT SCREW
Warning: This appliance is equipped with a tamper-resistant screw
to prevent removal of the outer cover. To reduce the risk of fire or
electric shock, do not attempt to remove the outer cover. There are
no user-serviceable parts inside. Repair should be done only by
authorized service personnel.
Note: If the power supply cord is damaged, it should be replaced by
qualified personnel; in Latin America, by an authorized service center.
1. Spray Nozzle
2. Water-Fill Opening
3. Steam Selector
4. Auto Clean Button
5. Spray Button
6. Steam Surge Button
7. Handle
8. Pivoting Cord
9. Heel Rest
10. Fabric And Temperature Dial
11. Water Tank
12. Ceramicglide
tm
Soleplate
13. Indicator Light
SPRAY
Use to dampen tough wrinkles at any setting.
1. Be sure the iron is filled with water.
2. On first use, pump the spray button a few times.
SURGE OF STEAM
Horizontal
Tip: Use to remove stubborn creases.
1. With the water tank filled to the "MAX" mark, set the fabric select dial to an appropriate
setting (between 4 and 6) for your fabric. Read garment’s label to help you determine
fabric type. Be sure there is water in the reservoir.
2. For best performance, use surge of steam at 5-second intervals.
3. When finished ironing, turn the fabric select dial to "MIN" and unplug the iron.
Important: Always stand the iron on its heel rest when powered on but not in use.
Vertical
Tip: Use for removing wrinkles from hanging clothes and drapes.
1. Be sure the water tank is filled to the "MAX" mark.
2. Hang the garment to be steamed on a clothes hanger (curtains or drapes can be steamed
once they are hung).
3. Set the fabric select dial to appropriate setting (between 5 and 6) for your fabric.
4. Hold the iron close to (but not touching) the fabric.
5. Pull the fabric tight in your free hand and press the button as you move the iron over
the fabric.
DRY IRONING
1. Turn the steam/dry selector to dry ( ).
2. Turn the fabric select dial to an appropriate setting for your fabric.
3. When you are finished ironing, make sure to unplug the iron.
EMPTYING THE WATER TANK
Note: It is not necessary to empty the water after each use.
1. Unplug the iron and let it cool.
2. If you want to empty the water, hold the iron over a sink with the tip pointing down.
Water will empty out of the water-fill opening.
Care and Cleaning
This product contains no user serviceable parts. Refer service to qualified service personnel.
CLEANING OUTSIDE SURFACES
1. Make sure iron is unplugged and has cooled completely.
2. Wipe the soleplate and outer surfaces with a soft cloth dampened with water and mild
household detergent.
3. Never use abrasives, heavy-duty cleansers, vinegar or scouring pads that may scratch or
discolor the iron.
4. After cleaning, steam iron over an old cloth to remove any residue from the steam vents.
AUTO-CLEAN™ SYSTEM
Tip: To keep the steam vents free of any buildup, follow these instructions about once
a month:
1. Fill the water tank well below the "MAX" line. Plug in the iron.
2. Turn the fabric select dial to 6 and stand the iron on its heel rest. Allow it to heat.
3. Turn fabric select dial to "MIN," unplug the iron, and hold the iron over a sink with the
soleplate facing downward.
4. Press and hold the AUTO-CLEAN™ button. Be careful, as hot water and steam will come
out of the steam vents. Continue to hold the AUTO-CLEAN™ button until all the water has
emptied. If necessary, rock iron side-to-side and front-to-back.
5. When finished, release the button, stand the iron on its heel rest and plug it in. Heat for
about 2 minutes to dry out any remaining water.
STORING YOUR IRON
1. Check that the fabric select dial is set to "MIN."
2. Unplug the iron and let it cool completely.
3. Store the iron on its heel rest. Storing iron on its soleplate can cause leaks or damage.
MINERAL GLIDE
MOONSTONE
MINERAL GLIDE
MOONSTONE
