THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
HW71585
Dining Table
Table à Manger
Before You Start
Please read all instructions carefully.
Retain instructions for future reference.
Separate and count all parts and hardware.
Read through each step carefully and follow the proper order.
We recommend that, where possible, all items are assembled near to the area in
which they will be placed in use, to avoid moving the product unnecessarily once
assembled.
Always place the product on a flat, steady and stable surface.
Keep all small parts and packaging materials for this product away from babies
and children as they potentially pose a serious choking hazard.
FR
Veuillez lire attentivement toutes les instructions.
Conservez les instructions pour vous y référer ultérieurement.
Vérifiez toutes les pièces et les accessoires.
Lisez attentivement chaque étape et suivez l'ordre correct.
Nous recommandons que, dans la mesure du possible, tous les produits
soient assemblés à proximité de la zone où ils seront utilisés, afin d'éviter tout
déplacement inutile du produit une fois assemblé.
Placez toujours le produit sur une surface plane et stable.
Conservez toutes les petites pièces de ce produit et les matériaux d'emballage
hors de portée des bébés et des enfants, car ils pourraient présenter un risque
d'étouffement.
Avant de Commencer
EN
02
03
Warning
The furniture has been pre-treated to be better protected against
sun, rain, stains and other wear and tear. However, we hope you
can protect your outdoor furniture from rain, sun, dirt, dust, pollen
and snow when not in use.
How to Re-Oil Furniture
Furniture finished with oil and wax will probably not need to be
re-oiled unless it becomes dry from being stored in extreme cold or
heat, or in constant direct sunlight or other drying conditions. If your
piece does become overly dry, follow the following instructions for
re-oiling.
1.Use turpentine or naptha applied with a clean cotton cloth to
remove the existing wax. Clean the surface with water and Soap,
using only as much liquid so as to make the cloth damp, not wet.
Allow the surface to dry completely.
2.Use super-fine grade #0000 steel wool to further prepare the
surface, using light, even pressure and always working with the
wood grain.
3.Apply a liberal amount of oil to the surface. We use a blend of 1/3
boiled linseed oil, 1/3 pure tung oil and 1/3 oil-based polyurethane
(Allow the oil to soak into the wood for about 10 to 15 minutes.)
4.Wipe off all excess oil using a clean cotton cloth. Allow the newly
oiled furniture to set for at least 24 hours.
5.To prepare for waxing, clean the surface with super-fine #0000
grade steel wool. Carefully wipe the surface clean with a soft cotton
cloth to remove all grit and residue.
6.If the wood still appears dry, you may re-apply oil and repeat the
steps 3 through 5.
Important safety note: Handle oily rags with caution, as there
is a risk of spontaneous combustion if they are stored improperly. Be
sure to spread oily rags flat and allow them to dry completely, after
which they can be discarded or washed.
1
1
2
3
4
5
6
8
5
4
3
7
04
PARTS LIST / LISTE DES PIÈCES
Table Top
/Plateau de table 1
Table Top
/Plateau de table 2
Apron Bar
/Barre de
tablier 3
Apron Bar
/Barre de
tablier 1
Apron Connector
/Connecteur de tablier
Apron Bar
/Barre de tablier 2
Table Top Connector
/Connecteur du
plateau de table
1
x2
2
x1
3
x2
4 x2
5 x2
6 x2
7
x2
8 x1
Parasol Cap
/Capuchon
de parasol
M4x30mm
Screw/Vis
M4x15mm
Screw/Vis
M4 Allen Key
/Clé Allen
A
x2
B x18
C x8
05
M6x15mm
Bolt/Boulon
Wooden Dowel
/Cheville en bois
M6x40mm
Bolt/Boulon
M6x16
Washer/Rondelle
D x4
E x8
F
x16
G x16
Please don't fasten the screw completely
during assembly process.
It will be likely to lead to an assembling
problem that screw hole position is not aligned.
You can fasten completely when all parts have
been assembled.
Veuillez ne pas serrer complètement la vis pendant le
processus d'assemblage.
Cela entraînera probablement un problème d'assemblage si la
position des trous de vis n'est pas alignée.
Vous pouvez serrer complètement lorsque toutes les pièces
ont été assemblées.
EN
FR
06
D x4
2
1
F x16
100%
G x16
x2
D
D
D
D
1
2
1
F
G
F
G
F
G
F
G
5
3
6
07
100%
Not included/Non inclus
3
4
E x8
100%
B x4
E
E
B
B
B
B
08
100%
Not included/Non inclus
100%
Not included/Non inclus
5
6
B x14
C x8
B
C
C
C
C
1
7
7
2
6.1
6.2
09
Finish / Terminé
7
8
8
10
Instructions De Retour / Réclamation De Dommages
Dans le cas où un retour est requis, l'article doit être retourné dans sa boîte
d'origine. Sans cela, votre retour ne sera pas accepté.
NE PAS jeter la boîte/l'emballage d'origine.
Prenez une photo des marquages de la boîte.
Prenez une photo des dommages (le cas échéant).
Envoyez-nous un e-mail avec les images demandées.
Une photo des marquages (texte) sur le côté de la boîte est requise au cas où
une pièce serait nécessaire pour le remplacement. Cela aide notre personnel à
identifier votre numéro de produit pour s'assurer que vous recevez les bonnes
pièces.
Une photo des dommages est toujours requise pour déposer une réclamation et
obtenir rapidement votre remplacement ou votre remboursement. Assurez-vous
d'avoir la boîte même si elle est endommagée.
Envoyez-nous un e-mail directement depuis le marché où votre article a été
acheté avec les images ci-jointes et une description de votre réclamation.
FR
In case a return is required, the item must be returned in original box. Without this
your return will not be accepted.
DO NOT discard the box / original packaging.
Take a photo of the box markings.
Take a photo of the damaged part (if applicable).
Send us an email with the images requested.
A photo of the markings (text) on the side of the box is required in case a part is
needed for replacement. This helps our staff identify your product number to
ensure you receive the correct parts.
A photo of the damage is always required to file a claim and get your replacement
or refund processed quickly. Please make sure you have the box even if it is
damaged.
Email us directly from marketplace where your item was purchased with the
attached images and a description of your claim.
EN
Return / Damage Claim Instructions
Instructions De Retour / Réclamation De Dommages
11
If you're having difficulty, our friendly
customer team is always here to help.
