Freestanding Chest Freezer Series, 99L, 142L and 199L
Black and White
Thank you for purchasing a Dellonda product. Manufactured to a high standard, this product will,
if used according to these instructions, and properly maintained, give you years of trouble free performance.
DH Freezer Series Issue 4 08/02/24
www.dellonda.co.uk
Power
Run
Models: DH111.V2, DH116.V2, DH120.V2, DH151.V2, DH152.V2 & DH153.V2
IMPORTANT INFORMATION
Please read these instructions carefully. Note the safe operational requirements, warnings & cautions. Use the product correctly and with care
for the purpose for which it is intended. Failure to do so may cause damage and/or personal injury and will invalidate the warranty. Keep these
instructions safe for future use.
• ELECTRICAL SAFETY
• WARNING! It is the user’s responsibility to check the following:
• Check all electrical equipment and appliances to ensure that they are safe before using. Inspect power supply leads, plugs and all electrical
connections for wear and damage. Dellonda recommend that an RCD (Residual Current Device) is used with all electrical products.
• Electrical safety information: It is important that the following information is read and understood.
• Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.
• Regularly inspect power supply cables and plugs for wear or damage and check all connections to ensure that they are secure.
• Important: Ensure that the voltage rating on the appliance suits the power supply to be used and that the plug is tted with the correct fuse - see
fuse rating in these instructions.
• DO NOT pull or carry the appliance by the power cable.
• DO NOT pull the plug from the socket by the cable.
• DO NOT use worn or damaged cables, plugs or connectors.
• Ensure that any faulty item is repaired or replaced immediately by a qualied electrician.
• If the cable or plug is damaged during use, switch off the electricity supply and remove from use.
• Ensure that repairs are carried out by a qualied electrician.
• GENERAL SAFETY
• WARNING! When positioning the appliance, ensure the supply cord is not trapped or damaged. If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly qualied persons in order to avoid a hazard.
• Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.
• DO NOT use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.
• DO NOT damage the refrigerant circuit.
• DO NOT use electrical appliances inside the storage compartment of the appliance i.e. hair dryers, heater elements etc.
• DO NOT store explosive substances such as aerosol cans with a ammable propellant in this appliance.
• WARNING! DO NOT locate multiple portable socket-outlets or portable power supplies at the rear of the appliance.
• To avoid a hazard due to instability of the appliance, it must be xed in accordance with the instructions.
• This appliance is intended to be used in household and similar applications such as:
• - staff kitchen areas in shops, ofces and other working environments;
• - farm houses and by clients in hotels, motels and other residential type environments;
• - bed and breakfast type environments;
• - catering and similar non-retail applications.
• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or
lack of knowledge and experience if they have been given supervision or instruction concerning the use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without
supervision.
• Children aged from 3 to 8 years are allowed to load and unload refrigerating appliances.
• To avoid contamination of foodstuffs, please respect the following instructions:
• - Opening the door for long periods can cause a signicant increase of the temperature in the compartment of the appliance.
• - Clean regularly surfaces that can come in contact with drink and accessible drainage systems.
• - If the appliance is left empty for long periods, switch off, defrost, clean, dry, and leave the lid ajar to prevent mould developing within the
appliance.
Refer to
instructions
Indoor use
only
Warning:
ammable
material
• SPECIFICATION
DH111.V2 / DH151.V2 DH120.V2 / DH152.V2 DH116.V2 / DH153.V2
Capacity 199L 142L 99L
Colour White / Black White / Black White / Black
Defrost Method Manual Manual Manual
Energy Efciency Class E E E
Frequency 50Hz 50Hz 50Hz
Fuse Rating 5A 5A 5A
Operating Sound Level Max 39dB Max 39dB Max 39dB
Power Cable Length 2.3m 2.3m 2.3m
Product Dimensions (WxDxH) 823x556x835mm 635x556x835mm 545x476x835mm
Rated Current 1A 0.5A 0.36A
Temperature Range -12
o
C to -24
o
C -12
o
C to -24
o
C -12
o
C to -24
o
C
Type Chest Freezer Chest Freezer Chest Freezer
Voltage 220-240V 220-240V 220-240V
• INSTALLATION
• The unit is designed to be free-standing. Ventilation Space - a minimum space of 100mm is required for the front, rear and both sides of the
freezer. This will maximise the efciency, performance and the life of the freezer and also ensure that there is sufcient space for the hinge to
operate effectively.
• Locate the unit away from direct sunlight or sources of heat i.e. radiator, stove etc. Extreme ambient temperatures may also prevent the unit
working effectively.
• DO NOT locate the unit in a damp or moist location.
• Ensure that the oor surface is strong and stable enough to support the unit when it is fully loaded.
• Level the unit when in location by using the adjustable levelling feet in each corner.
• Once in position allow the unit to rest for an hour before switching it on.
• Allow the unit 2-3 hours to reach set temperature after switching on before placing any items in the compartment.
• OPERATION
• The freezer has seven (7) possible settings numbered 1 to 7. Refer to table below.
• NOTE: Temperature values achieved can vary between +3
o
C / -3
o
C.
Setting Function Temperature Range
1 Refrigerator 5
o
C
2 - 4 Freezer -12
o
C~-18
o
C
4 - 7
Freezer
-18
o
C~-24
o
C
• NOTE: In Fast Freezer mode, the unit will run continuously. When the required freezing effect has been achieved, select a lower value.
• DEFROSTING (see g.1)
g.1
Power On Light
Freezer Running Light
Control Dial
• WARNING! Switch off freezer and remove the power plug from the supply when performing defrosting, cleaning or maintenance.
• Remove rubber cover from drain hole inside the freezer compartment, g.1.
• Place suitable water container under the drain cover in the lower left corner of the front panel, remove the drain cover, withdraw the drain body
and rotate it such that the drain hole is placed above the water container.
• Reverse the procedure when operation is complete.
• MAINTENANCE
• WARNING! Remove the power plug from the supply when performing cleaning or maintenance.
• DO NOT use abrasive or chemical cleaning materials on any surface of the unit.
• Wipe interior and exterior surfaces with a damp cloth and dry thoroughly with a clean dry cloth.
• For more soiled surfaces use a neutral detergent, wipe down with a clean damp cloth and dry thoroughly with a clean dry cloth.
Dellonda Limited, Sole UK Distributor of Baridi
Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757575 suppor[email protected] www.dellonda.co.uk
Environment Protection and Waste Protection and Electrical Equipment Regulations (WEEE)
Recycle unwanted packaging materials. When this product is no longer required, or has reached the end of it’s useful life, please dispose of it in an
environmentally friendly way. Drain any fluids (if applicable) into approved containers, in accordance with local waste regulations. It is our policy to
continually improve products and we reserve the right to alter data, specifications and parts without prior notice. No liability is accepted for incorrect
use of this product. Guarantee is 12 months from purchase date, proof of which is required for any claim.
Product Information Sheet. Refrigerating Appliances
SUPPLIER_NAME_OR_TRADEMARK Dellonda EU Ltd. DELEGATED_ACT EU/2019/2016
MODEL_IDENTIFIER DH151
ADDRESS
Farney Street, Carrickmacross, Co. Monaghan, A81 PK68 Ireland
PHONE_NUMBER 01284 757 500
EMAIL_ADDRESS [email protected]
Parameter Verification tolerances
Low-noise appliance No Design type Freestanding
Wine storage appliance No Other refrigerating appliance No
General product parameters
Height mm 835
Width mm 853 199
Depth mm 556
EEI 100 E
Airborne acoustical noise emissions (dB(a)
re 1 pW
39 C
Annual energy consumption kWh/a 200.00
SN = extended temperate(10-32°C)
N = temperate 16-32°C
ST = subtropical 16-38°C
T = tropical 16-43°C]
Minimum ambient temperature (°C) for
which the refrigerating appliance is
suitable.
16 38
Winter setting No
Baridi, Freestanding Chest Freezer, 199L, Garage and Outbuilding Safe, Adjustable
Thermostat, Black
Total volume. Litres.
Airborne acoustical noise emission class
Maximum ambient temperature (°C) for
which the refrigerating appliance is suitable.
Climate class
N/ST
Energy efficiency class
Compartment type
Volume.
Litres.
Recommended temperature setting for optimised food storage
Freezing capacity (kg/24 h)
Defrosting type
(auto = A Manual = D)
Pantry No FALSE FALSE
_
FALSE
Wine storage appliance No FALSE FALSE
_
FALSE
Beverage / Beer cooler No FALSE FALSE
_
FALSE
Cellar No FALSE FALSE
_
FALSE
Fresh food No FALSE FALSE
_
FALSE
Chill No FALSE FALSE
_
FALSE
0-star or ice-making No FALSE FALSE
_
FALSE
1-star No FALSE FALSE
_
FALSE
2-star No FALSE FALSE
_
FALSE
3-star No FALSE FALSE
_
FALSE
4-star Yes 199.0 -18 9.00 M
2-star section No FALSE FALSE
_
FALSE
Variable temperature compartment
Compartment
types
FALSE FALSE
_
FALSE
4-star compartments Light source parameters
Fast freeze facility No Type of light source LED
Energy efficiency class Exempt
Minimum duration of guarantee (years) 1
Suppliers website https://www.dellonda.co.uk/
