USER GUIDE
6.5'' High Power Midrange Driver
PDMR6
Visit Our Website
SCAN ME
PyleUSA.com
Specications:
• Power Handling:
• RMS Power: 150 Watts
• Peak Power: 300 Watts
• Cone Material: 6.5'' Paper Coating Cone
• Voice Coil: 1'' High-Temperature KAPTON Voice Coil
• Magnet Structure: 25 oz
• Sensitivity: 93dB
• Frequency Response: 200-5KHz
• Impedance: 8 Ohms
• Mounting Depth: 2.76'' (inches)
Installation Instructions
Preparing the Mounting Area:
Ensure that the mounting surface is at and free from debris.
Mounting the Woofer:
Align the woofer with the pre-cut hole.
Use screws to securely fasten the woofer into place.
Make sure the screws are tightened evenly to avoid stress
on the frame.
Wiring:
Connect the positive (+) and negative (-) terminals of the
woofer to the amplier, making sure that the impedance
matches the system requirements (8 Ohms).
Questions or Comments?
We are here to help!
Phone: 1.718.535.1800
PyleUSA.com/ContactUs
California Prop 65 Warning
WARNING:
This product may expose you to chemicals, which is known to
the state of California to cause cancer, birth defects and other
reproductive harm. Do not ingest.
For more info go to: www.P65warnings.ca.gov
SPEAKER PARAMETER
73.5mm
73.5mm
MODEL
PDMR6
Fs (Hz)
321
Qms
7.55
Qes
5.48
Qts
3.18
Vas (CuFt)
0.17
SPL (dB)
93
MAX POWER (W)
300
www.PyleUSA.com
TEMPLATE FOR PDMR6
Register Product
Thank you for choosing PyleUSA. By registering your product, you ensure that you receive
the full benets of our exclusive warranty and personalized customer support. Complete
the form to access expert support and to keep your PyleUSA purchase in perfect condition.
Start Here
Model Number:
PDMR6
