INSTRUCTION SHEET
©2021 Electrolux Home Products, Inc. Instruction Sheet A00343905 7.23.21
NOTE: All Hardware Pack components
mentioned throughout this instruction sheet
will have an “H” after the item number.
Single-Door All Refrigerator and All Freezer Trim Kit Installation
Product Line: All Refrigerator and All Freezer Models Serial Number Range: All Serial Number Ranges
Single Trim Kit Components (79˝ & 84˝ Tall Cabinet Cutouts)
Brand Kit # Single Trim Kit #
Frigidaire Professional TRMKTEZ1FL79 A16405201
Item # Part Number Description Qty
1A
A18684901
Side Trim, RH
1
2A
A18684902
Side Trim, LH
1
3A
A16766503
Top Trim, Flat RH
1
4A
A16766505
Top Trim, Flat LH
1
5
A18684505
Toe Kick, RH
1
6
A18684507
Toe Kick, LH
1
7
A17111301
Leveler Assembly
2
8
A20841303
Hardware Pack U19, Single
1
Brand Kit # Single Trim Kit #
Electrolux TRMKTSS1LV84 A19895901
Item # Part Number Description Qty
1B
A19036503
Side Trim, RH
1
2B
A19036504
Side Trim, LH
1
3B
A19036402
Top Trim, Louver RH
1
4B
A19036403
Top Trim, Louver LH
1
5
A18684506
Toe Kick, RH
1
6
A18684508
Toe Kick, LH
1
7
A17111301
Leveler Assembly
2
8
A20841304
Hardware Pack U19, Single
1
9
A19036701
Side Trim Attachment
2
7
1A
2A
3A
4A
5
6
1B
2B
9
3B
4B
Hardware Pack A20841303
ITEM PART NUMBER DESCRIPTION QTY
1H
A18695801 Tie-Bar, Top 1
2H
297142600 Screw, Flathead, #8-32 2
3H
050149 Screw, Round, #8-18 4
4H
A16955502 Bolt, M5 x 16 6
5H
A21188301 Bolt, ¼-20 2
6H
,
7H
A20706101 Trim Base Screw 1
Hardware Pack A20841304
ITEM PART NUMBER DESCRIPTION QTY
1H
A18695801 Tie-Bar, Top 1
2H
297142600 Screw, Flathead, #8-32 2
3H
050149 Screw, Round, #8-18 12
4H
A16955502 Bolt, M5 x 16 6
5H
A21188301 Bolt, ¼-20 2
6H 7H
1H
2H
3H
4H
5H
2.12" Ref
5" Ref
