Hikvision DS-K1108ADK Card Reader Keypad User Manual

DS-K1108A Series Card Reader

User Manual

Legal Informaon

About this Manual

The Manual includes instrucons for using and managing the Product. Pictures, charts, images and

all other informaon hereinaer are for descripon and explanaon only. The informaon

contained in the Manual is subject to change, without noce, due to rmware updates or other

reasons. Please

nd the latest version of this Manual at the Hikvision website ( hps://

www.hikvision.com/ ).

Please use this Manual with the guidance and assistance of professionals trained in

supporng the

Product.

Trademarks

and other Hikvision's trademarks and logos are the properes of

Hikvision in various

jurisdicons.

Other trademarks and logos menoned are the properes of their respecve owners.

Disclaimer

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT

DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED “AS IS” AND “WITH

ALL FAULTS AND ERRORS”. HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING

WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR

PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION

BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,

INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS

INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,

WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY,

OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN

ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.

YOU ACKNOWLEDGE THAT THE NATURE OF INTERNET PROVIDES FOR INHERENT SECURITY RISKS,

AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION, PRIVACY

LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS

INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY

TECHNICAL SUPPORT IF REQUIRED.

YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE

SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.

ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT

INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF

PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.

YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE

DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR

DS-K1108A Series Card Reader User Manual

PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED

TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN

RIGHTS ABUSES.

IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER

PREVAILS.

Data Protecon

During the use of device, personal data will be collected, stored and processed. To protect data,

the development of Hikvision devices incorporates privacy by design principles. For example, for

device with facial recognion features, biometrics data is stored in your device with encrypon

method; for ngerprint device, only ngerprint template will be saved, which is impossible to

reconstruct a ngerprint image.

As data controller, you are advised to collect, store, process and transfer data in accordance with

the applicable data

protecon laws and regulaons, including without limitaon, conducng

security controls to safeguard personal data, such as, implemenng reasonable administrave and

physical security controls, conduct periodic reviews and assessments of the

eecveness of your

security controls.

DS-K1108A Series Card Reader User Manual

Regulatory Informaon

FCC Informaon

Please take aenon that changes or modicaon not expressly approved by the party responsible

for compliance could void the user’s authority to operate the equipment.

FCC compliance: This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable

protecon against harmful interference in a residenal installaon. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in accordance

with the

instrucons, may cause harmful interference to radio communicaons. However, there is

no guarantee that interference will not occur in a parcular installaon. If this equipment does

cause harmful interference to radio or television

recepon, which can be determined by turning

the equipment o and on, the user is encouraged to try to correct the interference by one or more

of the following measures:

—Reorient or relocate the receiving antenna.

—Increase the

separaon between the equipment and receiver.

—Connect the equipment into an outlet on a circuit dierent from that to which the receiver is

connected.

—Consult the dealer or an experienced radio/TV technician for help

FCC

Condions

This device complies with part 15 of the FCC Rules. Operaon is subject to the following two

condions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause

undesired

operaon.

DS-K1108A Series Card Reader User Manual

iii

EU Conformity Statement

This product and - if applicable - the supplied accessories too are marked with "CE"

and comply therefore with the applicable harmonized European standards listed

under the EMC Direcve 2014/30/EU, the RoHS Direcve 2011/65/EU

2012/19/EU (WEEE direcve): Products marked with this symbol cannot be disposed

of as unsorted municipal waste in the European Union. For proper recycling, return

this product to your local supplier upon the purchase of equivalent new equipment,

or dispose of it at designated

collecon points. For more informaon see:

www.recyclethis.info

2006/66/EC (baery direcve): This product contains a baery that cannot be

disposed of as unsorted municipal waste in the European Union. See the product

documentaon for specic baery informaon. The baery is marked with this

symbol, which may include

leering to indicate cadmium (Cd), lead (Pb), or mercury

(Hg). For proper recycling, return the

baery to your supplier or to a designated

collecon point. For more informaon see:www.recyclethis.info

Industry Canada ICES-003 Compliance

This device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements.

DS-K1108A Series Card Reader User Manual

Safety Instrucon

These instrucons are intended to ensure that user can use the product correctly to avoid danger

or property loss.

The

precauon measure is divided into Dangers and Cauons:

Dangers: Neglecng any of the warnings may cause serious injury or death.

Cauons: Neglecng any of the cauons may cause injury or equipment damage.

Dangers: Follow these safeguards to prevent

serious injury or death.

Cauons: Follow these precauons to prevent

potenal injury or material damage.

Danger:

• All the electronic operaon should be strictly compliance with the electrical safety regulaons,

re prevenon regulaons and other related regulaons in your local region.

• Please use the power adapter, which is provided by normal company. The power consumpon

cannot be less than the required value.

• Do not connect several devices to one power adapter as adapter overload may cause over-heat

or re hazard.

• Please make sure that the power has been disconnected before you wire, install or dismantle the

device.

• When the product is installed on wall or ceiling, the device shall be

rmly xed.

• If smoke, odors or noise rise from the device, turn o the power at once and unplug the power

cable, and then please contact the service center.

• If the product does not work properly, please contact your dealer or the nearest service center.

Never

aempt to disassemble the device yourself. (We shall not assume any responsibility for

problems caused by unauthorized repair or maintenance.)

Cauons:

• Do not drop the device or subject it to physical shock, and do not expose it to high

electromagnesm radiaon. Avoid the equipment installaon on vibraons surface or places

subject to shock (ignorance can cause equipment damage).

• Do not place the device in extremely hot (refer to the

specicaon of the device for the detailed

operang temperature), cold, dusty or damp locaons, and do not expose it to high

electromagnec radiaon.

• The device cover for indoor use shall be kept from rain and moisture.

• Exposing the equipment to direct sun light, low venlaon or heat source such as heater or

radiator is forbidden (ignorance can cause re danger).

• Do not aim the device at the sun or extra bright places. A blooming or smear may occur

otherwise (which is not a

malfuncon however), and aecng the endurance of sensor at the

same

me.

DS-K1108A Series Card Reader User Manual

• Please use the provided glove when open up the device cover, avoid direct contact with the

device cover, because the acidic sweat of the ngers may erode the surface coang of the device

cover.

• Please use a so and dry cloth when clean inside and outside surfaces of the device cover, do

not use alkaline detergents.

• Please keep all wrappers

aer unpack them for future use. In case of any failure occurred, you

need to return the device to the factory with the original wrapper. Transportaon without the

original wrapper may result in damage on the device and lead to addional costs.

• Improper use or replacement of the

baery may result in hazard of explosion. Replace with the

same or equivalent type only. Dispose of used baeries according to the instrucons provided by

the baery manufacturer.

• Please take care of your card and report card loss in

me when card is lost.

• Mulple card types are supported. Please select an appropriate card type according to the card

performance and the usage scenarios.

DS-K1108A Series Card Reader User Manual

Available Models

Product Name Model

Card Reader DS-K1108AE

DS-K1108AEK

DS-K1108AM

DS-K1108AMK

Use only power supplies listed in the user instrucons:

Model Manufacturer Standard

TS-A018-120015Ec Shenzhen Transin Technologies

Co., Ltd

CEE

DS-K1108A Series Card Reader User Manual

vii

Contents

Chapter 1 Overview .................................................................................................................... 1

Chapter 2 Appearance ................................................................................................................ 2

2.1 Front View .............................................................................................................................. 2

2.2 Rear View ............................................................................................................................... 2

Chapter 3 Installaon ................................................................................................................. 4

3.1 DIP Switch Descripon ........................................................................................................... 4

3.2 Wiring Cables ......................................................................................................................... 4

3.2.1 Descripon of Cable ...................................................................................................... 5

3.2.2 Set RS-485

Communicaon Mode ................................................................................ 5

3.2.3 Set Wiegand Communicaon Mode ............................................................................. 6

Chapter 4 Sound Prompt and Indicator ....................................................................................... 8

Appendix A.

Prevenve and Cauonary Tips .............................................................................. 9

Appendix B. Communicaon Matrix and Device Command ...................................................... 10

DS-K1108A Series Card Reader User Manual

viii

Chapter 1 Overview

The card reader is a kind of high-performance product, with a 32 bit high-speed processor. It

communicates with access controller via either RS-485 protocol or Wiegand protocol. And a built-in

tamper-proof module helps to protect card reader from malicious damage. As to the physical

appearance, the PC+ABS material makes water proof and dust proof possible in poor environment.

DS-K1108A Series Card Reader User Manual

Chapter 2 Appearance

2.1 Front View

The front view of card reader is shown below:

Figure 2-1 Front View

2.2 Rear View

The rear view of card reader is shown below:

DS-K1108A Series Card Reader User Manual

Figure 2-2 Rear View

DS-K1108A Series Card Reader User Manual

Chapter 3 Installaon

3.1 DIP Switch Descripon

The DIP switch module is shown below. The No. of DIP switch from le to right is 1 to 8.

When the switch is towards ON, it means the switch is enabled, otherwise, the switch is o. If you

set the DIP switch like the gure displayed below, its binary value is 00001100, and its decimal

value is 12.

Table 3-1 Descripon of DIP Switch

No. Descripon DIP Switch Status

1 to 4 Address of RS-485 1: 1

0: 0

5 Card Security

Note

• For DS-K1108AE/AEK, the

DIP switch is reserved.

1: Enable M1 card encrypon

funcon, and disable door

open via NFC card.

0: Disable M1 card

encrypon

funcon,

enable door open via

NFC card, and read card No.

6 Wiegand protocol or RS-485

protocol.

1: Wiegand protocol

0: RS-485 protocol

7 Wiegand Protocol (available

when No. 6 is 1)

1: Wiegand protocol of 26-bit;

0: Wiegand protocol of 34-bit.

8 Matched Resistance (available

for RS-485 protocol)

1: Enable

0: Disable

3.2 Wiring Cables

Wire the cables between controller and card reader, thus to establish the communicaon between

them.

DS-K1108A Series Card Reader User Manual

3.2.1 Descripon of Cable

The descripon of 10 cables is shown below.

Table 3-2 Descripon of Cable

Color Descripon

Orange Wiegand ERR (Available for Wiegand Protocol)

Brown Wiegand OK (Available for Wiegand Protocol)

White Wiegand W1 (Available for Wiegand Protocol)

Green Wiegand W0 (Available for Wiegand Protocol)

Blue RS-485-

Yellow RS-485+

Red PWR (+12 VDC)

Black GND

Gray TAMPER Control

Purple Beep Control (Available for Wiegand Protocol)

3.2.2 Set RS-485 Communicaon Mode

Steps

1. Set the DIP switch of No. 6 as 0.

2. Set the DIP switch of No. 1 ~ 5 for RS-485 address and reading card mode. For details, refers to

DIP Switch

Descripon .

3. Wire the cable between controller and card reader as shown below.

DS-K1108A Series Card Reader User Manual

Figure 3-1 Wiring for RS-485 Communicaon Mode

3.2.3 Set Wiegand

Communicaon Mode

Steps

1. Set the DIP switch of No. 6 as 1.

2. Set the DIP switch of No. 5 and 7 for reading card mode and Wiegand protocol. For details,

refers to DIP Switch

Descripon .

3. Wiring the cable between controller and card reader as shown below.

DS-K1108A Series Card Reader User Manual

Figure 3-2 Wiring for Wiegand Communicaon Mode

DS-K1108A Series Card Reader User Manual

Chapter 4 Sound Prompt and Indicator

Aer the card reader is powered on, LED status indicator will turn green and ashing for 1 me.

Then it will turn red and ashing for 3 mes. At last the buzzer will send out a beep sound

indicang the starng up process is completed.

When using the card reader, it will send out dierent sounds prompt and the LED indicator on it

will have

dierent statuses. You can refer to tables below for detailed informaon.

Table 4-1 Descripon of Prompt Sound

Sound Prompt Descripon

One Beep Presenng card prompt

Pressing keys prompt

Prompt of pressing key for too long me when inpung card

No.

Time out prompt for pressing keys or presenng card.

For authencaon: prompt for entering the password aer

presenng the card.

Two Rapid Beeps The operaon of pressing keys or swiping card is valid.

Three Slow Beeps The operaon of pressing keys or swiping card is invalid.

Rapidly Connuous Beeps Prompt for tamper-proof alarm.

Prompt for buzzer alarm.

Slowly Connuous Beeps The card reader is unencrypted.

Table 4-2 Descripon of LED Switch

LED Indicator Status Descripon

Flashing Green for 1 Time and

Flashing Red for 3 Times

The card reader is power on.

Flashing Green For Card + Password authencaon: prompt for entering the

password aer presenng the card.

Solid Green for 2 s The operaon of pressing keys or presenng card is valid.

Solid Red Card reader is working normally.

Flashing Red for 3 Times The operaon of pressing keys or presenng card is invalid.

Flashing Red For RS-485 protocol: Registering failed or card reader is oine.

DS-K1108A Series Card Reader User Manual

Appendix A. Prevenve and Cauonary Tips

To guarantee the card reader works properly, please read and obey the notes below.

• If the card reader is powered by the controller, the power supply distance is recommended to be

no longer than 100m. If the distance is longer than 100 m, you are advised to power the card

reader by external 12 V (range: -%10 to +%10) DC power supply, which is non-switched and

linear.

• To guarantee the

communicaon between the controller and the card reader, you must use

RVVP cable above 0.5 to connect them.

• If the card reader is installed outside or in environment easy to permeable, it is advisable to

install a waterproof shield.

• If you need to install several card readers, the distance among them must over 30 cm.

• To reduce the noise in long distance transmission, the shield of cable should connect to the GND

of both controller and card reader terminal.

• Please take care of your card and report card loss in

me when card is lost.

• If you require a higher security level, use mulple authencaon modes.

• Mulple card types are supported. Please select an appropriate card type according to the card

performance and the usage scenarios.

DS-K1108A Series Card Reader User Manual

Appendix B. Communicaon Matrix and Device

Command

Communicaon Matrix

Scan the following QR code to get the device communicaon matrix.

Note that the matrix contains all communicaon ports of Hikvision access control and video

intercom devices.

Figure B-1 QR Code of Communicaon Matrix

Device Command

Scan the following QR code to get the device common serial port commands.

Note that the command list contains all commonly used serial ports commands for all Hikvision

access control and video intercom devices.

Figure B-2 Device Command

DS-K1108A Series Card Reader User Manual

UD18872B-A

Hikvision DS-K1108ADK Card Reader Keypad

Product's Documents

Hikvision DS-K1108ADK User Manual

Specifications

Hikvision DS-K1108ADK Questions and Answers
